Search Results (17)

Fans are essential electronic components for heat dissipation in electronic systems, with fan bearings being critical parts that determine fan performance and lifespan. This paper investigates the corrosion, wear, power consumption, temperature, and vibration characteristics of a newly designed and manufactured powder metallurgy bearing with herringbone oil grooves for fans under high-humidity and high-temperature conditions. Corrosion experiments on iron–copper powder metallurgy bearings show that a higher environmental temperature and humidity result in greater corrosion current and reduced corrosion resistance. Bearings operated under high humidity (85% RH) and a high temperature (80 °C) for 0, 3, and 8 days, respectively, revealed that wear and corrosion occur simultaneously. The longer the operating time, the more significant the wear and corrosion. After 3 and 8 days, the lubricating oil flow in the oil grooves decreased by 9.8% and 51.5%, respectively. When bearings subjected to varying degrees of corrosion were tested under the same standard operating conditions, it was found that the bearings corroded for 3 and 8 days, resulting in a significant increase in the number of wear debris particles, higher RMS vibration values, and a power consumption increase of 6.9% and 7.8%, respectively. The percentage of iron elements on the surface gradually decreased, with the copper elements being the primary wear particles during the wear process. However, due to the increased clearance between the rotating shaft and the bearing caused by wear, the fan temperature slightly decreased with increased surface wear. Full article

A novel microchannel heat sink (TFMCHS) with trapezoidal ribs and fan grooves was proposed, and the microchannel was manufactured using selective laser melting technology. Firstly, the temperature and pressure drop at different power levels were measured through experiments and then combined with numerical simulation to explore the complex flow characteristics within TFMCHSs and evaluate the comprehensive performance of microchannel heat sinks based on the thermal enhancement coefficient. The results show that, compared with rectangular microchannel heat sinks (RMCHSs), the average and maximum temperatures of TFMCHSs are significantly reduced, and the temperature distribution is more uniform. This is mainly caused by the periodic interruption and redevelopment of the velocity boundary layer and thermal boundary layer caused by ribs and grooves. And as the heating power increases, the TFMCHS has better heat dissipation performance. When $P=33 \mathrm{W}$ and the inlet flow rate is 32.5 $\mathrm{mL}/\min$, the thermal enhancement factor reaches 1.26. Full article

There is a limited description of magnetic resonance imaging (MRI) and no information on computed tomographic (CT) findings in the fetlock of non-lame, non-racing sports horses. This study aimed to document comparative CT, MRI and radiographic findings in the metacarpophalangeal joints of showjumpers in full work. Clinical and gait assessments, low-field MRI, fan-beam CT and radiographic examinations of both metacarpophalangeal joints were performed on 31 showjumpers. Images were analysed descriptively. In most limbs (53/62, 85.5%), there were CT and MRI changes consistent with densification in the sagittal ridge and/or condyles of the third metacarpal bone (McIII). Hypoattenuation (subchondral bone resorption) was seen in CT reconstructions in the metacarpal condyle dorsoproximally (n = 2) and dorsodistally (n = 1), in the sagittal groove (n = 2) and medial fovea (n = 1) of the proximal phalanx. The McIII resorptive lesions were detected on MR images but not the proximal phalanx lesions. None were identified on radiographs. In conclusion, MRI and CT abnormalities previously associated with lameness were seen in the front fetlocks of showjumpers without relevant lameness. Densification in the sagittal ridge and the metacarpal condyles likely reflects an adaptive change to exercise. Subchondral bone resorption may indicate an early stage of disease; follow-up information is needed to establish its clinical significance. Full article

Fissure in the third metacarpal/tarsal parasagittal groove and proximal phalanx sagittal groove is a potential prodromal pathology of fracture; therefore, early identification and characterisation of fissures using non-invasive imaging could be of clinical value. Thirty-three equine cadaver limbs underwent standing cone-beam (CB) computed tomography (CT), fan-beam (FB) CT, low-field magnetic resonance imaging (MRI), and macro/histo-pathological examination. Imaging diagnoses of fissures were compared to microscopic examination. Imaging features of fissures were described. Histopathological findings were scored and compared between locations with and without fissures on CT. Microscopic examination identified 114/291 locations with fissures. The diagnostic sensitivity and specificity were 88.5% and 61.3% for CBCT, 84.1% and 72.3% for FBCT, and 43.6% and 85.2% for MRI. Four types of imaging features of fissures were characterised on CT: (1) CBCT/FBCT hypoattenuating linear defects, (2) CBCT/FBCT striated hypoattenuated lines, (3) CBCT/FBCT subchondral irregularity, and (4) CBCT striated hypoattenuating lines and FBCT subchondral irregularity. Fissures on MRI appeared as subchondral bone hypo-/hyperintense defects. Microscopic scores of subchondral bone sclerosis, microcracks, and collapse were significantly higher in locations with CT-identified fissures. All imaging modalities were able to identify fissures. Fissures identified on CT were associated with histopathology of fatigue injuries. Full article

To improve the dynamic response speed of high-speed solenoid valves in electric fuel injection systems of marine diesel engines, a numerical simulation model of the solenoid valve is described in this paper. The accuracy of the simulation model was verified on the test bed of the solenoid valve. The effect of the punch position and the size of the dynamic response of the solenoid valve were investigated by using the distribution law of the electromagnetic force in the armature. The results of the test showed that armature drilling in the inter-yoke zone can optimize the solenoid closing response time, but it has little impact on the solenoid opening response time. From this rule, two groove schemes were further designed. Through comparison and calculation, it can be concluded that the fan groove scheme is better than the trapezoidal groove scheme, and that the opening and closing response times of the solenoid valve should be targeted in order to multi-target optimize the fan groove geometric parameters and the armature thickness. The results show that after optimization, the weight of the motion part is reduced by 21.6%, the opening response time of the solenoid valve is reduced by 11.1%, and the closing response time is reduced by 30.0%. While reducing the oil film damping of the armature motion, the overall dynamic response characteristics of the solenoid valve are improved. Full article

The specific features of the destruction of tool ceramics, associated with structural heterogeneity and defects formed during diamond grinding, largely determine their reduced reliability (dispersion of resistance). This is most pronounced at increased heat and power loads on the contact surfaces and limits the industrial application of ceramic cutting tools. The surface layer of industrially produced Al₂O₃+TiC cutting inserts contains numerous defects, such as deep grooves and torn grains. During the milling of hardened steels of the 100CrMn type with increased cutting parameters, the “wear–cutting time” curves have a fan-shaped character with different wear rates. The resistance of the tool that was taken from one batch before reaching the accepted failure criterion has a significant variation in values (VarT is 30%). The study is aimed to evaluate the influence of the condition of the surface layer of Al₂O₃+TiC inserts processed by various types of abrasive treatments, such as diamond grinding, lapping and polishing, on the quality of the (TiAl)N and (TiZr)N coatings and the reliability of prefabricated end mills. The obtained “wear–cutting time” curves are characterized as closely intertwined bundles. The coefficient of resistance variation (the tool’s reliability) decreases by more than two times (14%). This can be used further in coating development to improve the performance of CCT. Full article

To improve the aerodynamic performance and reduce the noise of multi-blade centrifugal fans used in air conditioners, a bionic groove structure was introduced into the blade tip design, inspired by the drag reduction characteristics of mantis shrimp. In this paper, the numerical method was used to investigate the effects of a blade tip bionic groove on the aerodynamic performance and noise characteristics of a multi-blade centrifugal fan. Firstly, the basic design parameters, such as groove width, groove depth, groove center distance, and groove number, were selected to define the shape of the blade tip bionic groove. Then, the effect of the design parameters on the aerodynamic performance of the multi-blade centrifugal fan was studied. Finally, the multi-blade centrifugal fan models with different groove shapes, such as rectangular bionic grooves, circular bionic grooves, and triangular bionic grooves, were established to compare the influence of blade tip groove structures on the aerodynamic performance of the multi-blade centrifugal fan. Through analysis of the aerodynamic performance and noise characteristics of the multi-blade centrifugal fan and the flow fields in the fan impeller, the flow control mechanism of the blade tip bionic groove was revealed. The results showed that the triangular bionic groove on the blade tip had a certain noise reduction effect, although the structural parameters of the bionic groove had little effect on the aerodynamic performance of the multi-blade centrifugal fan. This is because the triangular bionic groove structure can effectively inhibit the vortex shedding at the trailing edge of blade and reduce the flow separation in the impeller passages. As a result, the velocity distribution at the impeller tip became more uniform and the intensity of the tip vortex and the shedding vortex was weakened. Correspondingly, the noise of multi-blade centrifugal fan was also reduced to some extent. Full article

Hydro-viscous clutch is a speed-regulating device for heavy fans and water pumps. It has important engineering significance in the fields of soft-start for rotating machinery. More and more attention has been paid to its torque and control characteristics. This paper is focused on the torque formula for hydro-viscous clutch (HVC), assuming that multi-friction plates distribute ununiformly with different oil film thickness. A mathematical model of friction plates was constructed, then the distribution formula of the oil film thickness was obtained. A new expression was presented using a modified factor. Parameters such as pressure, viscous torque, and oil film thickness were obtained. The results show that each clearance of friction plates is not the same and the distribution of oil film thickness is influenced by pressing force, groove depth, angular ratio of groove/non-groove, and static friction force. To verify the proposed expression, relevant experiments were carried out on an HVC with multi-friction plates, and the experimental results indicate that the new expression is more accurate compared to the original one. Full article

The article presents the results of work on an effective numerical study of selected transient states of a low-power electrical machine. The object of detailed research was a synchronized squirrel-cage induction motor. Its ability to work at a synchronous speed was enabled by obtaining reluctance torque, caused by an imposed asymmetry between the direct and quadrature reluctances of the rotor. The difference between the reluctances was achieved by changing the rotor geometry by milling additional deep grooves. The modifications of the rotor did not damage the continuity of the rotor cage. Imposed lots were arranged symmetrically around the rotor circumference. In order to study the performance of the modified motor, a parameterized, numerical model of the machine was developed to evaluate the impact of the geometry of the slots. The developed three dimensional (3D) model of the electromagnetic phenomena in the studied magnetic circuit employs the finite element method (FEM). The model takes into account the saturation of the machine’s magnetic circuit and the skew of the rotor cage bars as well as the mechanical equilibrium of the terrain system including the moment of inertia and frictional torque in the bearings as well as the load torque resulting from the operation of the internal fan. The simulation study concerned the starting process of the machine under different values of the load. The influence of the supply voltage phase angle at the moment of start-up and the initial position of the rotor in relation to the stator was investigated. In order to calibrate the model, tests of the physical object were performed. The corrections introduced concerned the magnetization characteristics of the magnetic circuit. The results obtained confirm the correctness of the adopted strategy of testing the operational properties of the considered engine. Full article

Oscillatory flow has many applications in micro-scaled devices. The methods of realizing microfluidic oscillators reported so far are typically based on the impinging-jet and Coanda effect, which usually require the flow Reynolds number to be at least at the order of unity. Another approach is to introduce elastomeric membrane into the microfluidic units; however, the manufacturing process is relatively complex, and the membrane will become soft after long-time operation, which leads to deviation from the design condition. From the perspective of the core requirement of a microfluidic circuit, i.e., nonlinearity, the oscillatory microfluidic flow can be realized via the nonlinear characteristics of viscoelastic fluid flow. In this paper, the flow characteristics of viscoelastic fluid (Boger-type) in a T-shaped channel and its modified structures are studied by two-dimensional direct numerical simulation (DNS). The main results obtained from the DNS study are as follows: (1) Both Weissenberg (Wi) number and viscosity ratio need to be within a certain range to achieve a periodic oscillating performance; (2) With the presence of the dynamic evolution of the pair of vortices in the upstream near the intersection, the oscillation intensity increases as the elasticity-dominated area in the junction enlarges; (3) Considering the simplicity of the T-type channel as a potential oscillator, the improved structure should have a groove carved toward the entrance near the upper wall. The maximum oscillation intensity measured by the standard deviation of flow rate at outlet is increased by 129% compared with that of the original standard T-shaped channel under the same condition. To sum up, with Wi number and viscosity ratio within a certain range, the regular periodic oscillation characteristics of Oldroyd-B type viscoelastic fluid flow in standard T-shaped and its modified channels can be obtained. This structure can serve as a passive microfluidic oscillator with great potential value at an extremely low Reynolds number, which has the advantages of simplicity, no moving parts and fan-out of two. Full article

Assessment of the quality of the operation of agricultural nozzles on the basis of transverse volume distribution and spatial methods of analysis for stream spraying spectra is insufficient, and positive result do not guarantee that the intended and effective spraying effects are obtained. Tests were carried out to assess the quality of nozzles on the basis of transverse volume distribution analysis, microstructure characteristics, and detailed analysis of places where an unexpected change in the nature of the transverse volume distribution (increase in volume) was noted. The subjects of the study were RS11003 flat fan nozzles and a measuring stand equipped with a grooved table, which was used to carry out tests. During the tests, the unit flow rate from the nozzles, the transverse volume distribution of liquids from individual table grooves, and the corresponding CV distribution coefficients of variation were recorded. Detailed tests were carried out for the selected nozzle, consisting of spot measurement of droplet characteristics in individual liquid stream bands. The widths of these bands were constant and equal to the width of the measuring table groove. Measurements were made using analyzer 2D-Laser Doppler Anemometry/Phase Doppler Anemometry (2D-LDA/PDA) from Dantec Dynamics. The analysis of the results obtained from the grooved table and the droplet characteristics in individual stream bands showed clear and unexpected changes in the nature of the transverse volume distribution for all tested nozzles. These changes, consisting of a local increases in droplet diameters (with a reduced number of occurrences), can cause a significant reduction in the quality and effectiveness of spraying, despite the positive fulfillment of generalized normative criteria for their assessment. Full article

Mixed flow fan is a kind of widely used turbomachine, which has faced problems of further performance improvement in traditional design methods in recent decades. Inspired by the microgrooves such as riblets and denticles on bird feathers and shark skins, we here propose biomimetic designs of various blades with the bio-inspired grooves, aiming at the improvement of the aeroacoustic performance. Based on a systematic study with computational fluid dynamic analyses, we found that these designs had the potential in noise suppression even with macroscopic grooves. Our best design can suppress turbulence kinetic energy by approximately 38% at the blade leading edge with aerodynamic efficiency loss of only 0.3 percentage points. This improvement is achieved by passive flow control. The vortical structures are changed in a favorable way at the leading edge due to the grooves. We believe that these biomimetic designs could provide a promising future of enhancing the performance of mixed flow fans by making grooves of ideal flow passages on the suction faces of blades in accord with the theory of pump design. Full article

Multiple resonance modes have important applications since they can provide multi-frequency operation for devices and bring great flexibility in practice. In this paper, based on a fan-shaped cavity coupled to a metal-isolator-metal (MIM) waveguide, a new kind of ultracompact plasmonic nanostructure is proposed to realize multiple resonance modes with dense distribution in a broad spectral range, and demonstrated through finite-element method (FEM) simulations. As many as ten resonance modes with an average interval of about 30 nm are obtained. They originate from the coexistence and interference of three types of basic modes in the fan-shaped cavity, i.e., the ring-waveguide modes, the modes in a ring array of periodic air grooves, and the metal-core-cavity modes. The dependence of resonance modes on structure parameters is investigated, which can provide an effective guide for choosing appropriate multiple-resonance-mode structures. Furthermore, by means of adjusting the geometrical asymmetry induced by the axial offset of the metal core in the fan-shaped cavity, the resonance modes can be effectively modulated, and some new modes appear because the wave path in the cavity is changed. The result proposes a novel way to create multiple resonance modes in plasmonic nanostructures, providing additional degrees of freedom for tailoring the resonance spectra and promising applications in various plasmonic devices, such as optical filters, ultrafast switches, biochemical sensors, and data storages. Full article

In the last two decades, various flexural plate-wave (FPW)-based biosensors with low phase velocity, low operation frequency, high sensitivity, and short response time, have been developed. However, conventional FPW transducers have low fabrication yield because controlling the thickness of silicon/isolation/metal/piezoelectric multilayer floating thin-plate is difficult. Additionally, conventional FPW devices usually have high insertion loss because of wave energy dissipation to the silicon substrate or outside area of the output interdigital transducers (IDTs). These two disadvantages hinder the application of FPW devices. To reduce the high insertion loss of FPW devices, we designed two focus-type IDTs (fan-shaped and circular, respectively) that can effectively confine the launched wave energy, and adopted a focus-type silicon-grooved reflective grating structure (RGS) that can reduce the wave propagation loss. To accurately control the thickness of the silicon thin-plate and substantially improve the fabrication yield of FPW transducers, a 60 °C/27 °C two-step anisotropic wet etching process was developed. Compared with conventional FPW devices (with parallel-type IDTs and without RGS), the proposed FPW devices have lower insertion loss (36.04 dB) and higher fabrication yield (63.88%). Furthermore, by using cystamine-based self-assembled monolayer (SAM) nanotechnology, we used the improved FPW device to develop a novel FPW-based carcinoembryonic antigen (CEA) biosensor for detection of colorectal cancer, and this FPW-CEA biosensor has a low detection limit (5 ng/mL), short response time (<10 min), high sensitivity (60.16–70.06 cm²/g), and high sensing linearity (R-square = 0.859–0.980). Full article

Flow characteristics and heat transfer performances of carboxymethyl cellulose (CMC) aqueous solutions in the microchannels with flow control structures were investigated in this study. The researches were carried out with various flow rates and concentrations of the CMC aqueous solutions. The results reveal that the pin-finned microchannel has the most uniform temperature distribution on the structured walls, and the average temperature on the structured wall reaches the minimum value in cylinder-ribbed microchannels at the same flow rate and CMC concentration. Moreover, the protruded microchannel obtains the minimum relative Fanning friction factor f/f₀, while, the maximum f/f₀ is observed in the cylinder-ribbed microchannel. Furthermore, the minimum f/f₀ is reached at the cases with CMC2000, and also, the relative Nusselt number Nu/Nu₀ of CMC2000 cases is larger than that of other cases in the four structured microchannels. Therefore, 2000 ppm is the recommended concentration of CMC aqueous solutions in all the cases with different flow rates and flow control structures. Pin-finned microchannels are preferred in low flow rate cases, while, V-grooved microchannels have the minimum relative entropy generation S’/S₀’ and best thermal performance TP at CMC2000 in high flow rates. Full article
