Search Results (89)

The identification of structural damage types remains a key challenge in electromechanical impedance/admittance (EMI/EMA)-based structural health monitoring realm. This paper proposed a damage classification approach for concrete structures by using integrating discrete wavelet transform (DWT) decomposition of EMA signatures with supervised machine learning. In this approach, the EMA signals of arranged piezoelectric ceramic (PZT) patches were successively measured at initial undamaged and post-damaged states, and the signals were decomposed and processed using the DWT technique to derive indicators including the wavelet energy, the variance, the mean, and the entropy. Then these indicators, incorporated with traditional ones including root mean square deviation (RMSD), baseline-changeable RMSD named RMSDk, correlation coefficient (CC), and mean absolute percentage deviation (MAPD), were processed by a support vector machine (SVM) model, and finally damage type could be automatically classified and identified. To validate the approach, experiments on a full-scale reinforced concrete (RC) slab and application to a practical tunnel segment RC slab structure instrumented with multiple PZT patches were conducted to classify severe transverse cracking and minor crack/impact damages. Experimental and application results cogently demonstrated that the proposed DWT-based approach can precisely classify different types of damage on concrete structures with higher accuracy than traditional ones, highlighting the potential of the DWT-decomposed EMA signatures for damage characterization in concrete infrastructure. Full article

This study explores the use of embedded piezo sensor (EPS) employing the Electro-Mechanical Impedance (EMI) technique for real-time corrosion monitoring in reinforced E-waste concrete exposed to chloride-laden environments. With the growing environmental concerns over electronic waste (E-waste) and the demand for sustainable construction practices, printed circuit board (PCB) materials were incorporated as partial replacements for coarse aggregates in concrete. The experiment utilized M30-grade concrete mixes, substituting 15% of natural coarse aggregates with E-waste, aiming to assess both sustainability and structural performance without compromising durability. EPS configured with Lead Zirconate Titanate (PZT) patches were embedded into both conventional and E-waste concrete specimens. The EPS monitored the changes in the form of conductance and susceptance signatures across a 100–400 kHz frequency range during accelerated corrosion exposure over a 60-day period in a 3.5% NaCl solution. The corrosion progression was evaluated qualitatively through electrical impedance signatures, visually via rust formation and cracking, and quantitatively using the Root Mean Square Deviation (RMSD) of EMI signatures. The results showed that the EMI technique effectively captured the initiation and propagation stages of corrosion. E-waste concrete exhibited earlier and more severe signs of corrosion compared to conventional concrete, indicated by faster increases and subsequent declines in conductance and susceptance and higher RMSD values during the initiation phase. The EMI-based system demonstrated its capability to detect microstructural changes at early stages, making it a promising method for Structural Health Monitoring (SHM) of sustainable concretes. The study concludes that while the use of E-waste in concrete contributes positively to sustainability, it may compromise long-term durability in aggressive environments. However, the integration of EPS and EMI offers a reliable, non-destructive, and sensitive technique for real-time corrosion monitoring, supporting preventive maintenance and improved infrastructure longevity. Full article

Establishing dependable and resilient methodologies for identifying damage that may compromise the integrity of reinforced concrete (RC) infrastructures is imperative for preventing potential catastrophic failures. Continuous evaluation and Structural Health Monitoring (SHM) can play a key role in extending the lifespan of new or existing buildings. At the same time, early crack detection in critical members prevents bearing capacity loss and potential failures, enhancing safety and reliability. Furthermore, implementing discrete fibers in concrete has significantly improved the ductility and durability of Fiber-Reinforced Concrete (FRC). The present study employs a hierarchical clustering analysis (HCA) to identify damage in FRC by analyzing the raw Electromechanical Impedance (EMI) signature of piezoelectric lead zirconate titanate (PZT) transducers. The experimental program consisted of three FRC standard cylinders subjected to repeated loading. The loading procedure consists of 6 incremental steps carefully selected to gradually deteriorate FRC’s structural integrity. Additionally, three PZT patches were adhered across the height of its specimen using epoxy resin, and their EMI response was captured between each loading step. Subsequently, the HCA was conducted for each PZT transducer individually. The experimental investigation demonstrates the efficacy of HCA in detecting load-induced damage in FRC through the variations in the EMI signatures of externally bonded PZT sensors. Full article

The need to strengthen the existing reinforced concrete (RC) elements is becoming increasingly crucial for modern cities as they strive to develop resilient and sustainable structures and infrastructures. In recent years, various solutions have been proposed to limit the undesirable effects of corrosion in RC elements. While C-FRP has shown promise in corrosion-prone environments, its use in structural applications is limited by cost, bonding, and anchorage challenges with concrete. To address these, the present research investigates the structural performance of RC beams reinforced with C-FRP bars under static loading using Structural Health Monitoring (SHM) with an Electro-Mechanical Impedance (EMI) system employing Lead Zirconate Titanate (PZT) piezoelectric transducers which are applied to detect damage development and enhance the protection of RC elements and overall, RC structures. This study underscores the potential of C-FRP bars for durable tensile reinforcement in RC structures, particularly in hybrid designs that leverage steel for compression strength. The study focuses on critical factors such as stiffness, maximum load capacity, deflection at each loading stage, and the development of crack widths, all analyzed through voltage responses recorded by the PZT sensors. Particular emphasis is placed on the bond conditions and anchorage lengths of the tensile C-FRP bars, exploring how local confinement conditions along the anchorage length influence the overall behavior of the beams. Full article

Arrangements of piezoelectric transducers, such as PZT (lead zirconate titanate), have been widely used in numerous structural health monitoring (SHM) applications. Usually, when two or more PZT transducers are placed close together, significant interference, namely crosstalk, appears. Such an effect is usually neglected in most SHM applications. However, it can potentially be used as a sensitive parameter to identify structural faults. Accordingly, this work proposes using the crosstalk effect in an arrangement of PZT transducers modeled as a multiconductor transmission line to detect structural damage. This effect is exploited by computing an impedance matrix representing a host structure with PZTs attached to it. The proposed method was assessed in an aluminum beam structure with two PZTs attached to it using finite element modeling in OnScale^® software to simulate both healthy and damaged conditions. Similarly, experimental tests were also carried out. The results, when compared to those obtained using a traditional electromechanical impedance (EMI) method, prove that the new approach significantly improved the sensitivity of EMI-based technique in SHM applications. Full article

Due to insufficient transverse reinforcement, the retrofitting of beam–column joints (BCJs) in existing reinforced concrete (RC) frame structures is commonly required to alter their brittle behavior. The construction industry has extensively embraced carbon-fiber-reinforced polymers (C-FRPs) as near-surface-mounted (NSM) reinforcement. Monitoring the performance of C-FRP retrofitting is crucial due to the wide range of factors influencing its effectiveness. A novel methodology has been implemented to assess the efficacy of the C-FRP retrofitting method in this study. This approach was validated through experimental investigation of full-scale BCJs, which were retrofitted with C-FRP ropes and subjected to cyclic loading. Furthermore, piezoelectric lead zirconate titanate (PZT) patches were placed on the NSM C-FRP ropes, and the electro-mechanical impedance (EMI) method was employed to monitor the retrofitting technique’s performance. A combination of the commonly used statistical damage index root mean squared deviation (RMSD) and a hierarchical clustering-based approach (HCA) was used to assess the performance of the C-FRP retrofitting technique. The experimental investigation results strongly indicate the proposed approach’s positive impact on the reliable assessment of C-FRP retrofitting performance. Thus, the proposed approach enhances the safety and resilience of retrofitted BCJs in RC structures. Full article

Real-time structural health monitoring (SHM) and accurate diagnosis of imminent damage are critical to ensure the structural safety of conventional reinforced concrete (RC) and fiber-reinforced concrete (FRC) structures. Implementations of a piezoelectric lead zirconate titanate (PZT) sensor network in the critical areas of structural members can identify the damage level. This study uses a recently developed PZT-enabled Electro-Mechanical Impedance (EMI)-based, real-time, wireless, and portable SHM and damage detection system in prismatic specimens subjected to flexural repeated loading plain concrete (PC) and FRC. Furthermore, this research examined the efficacy of the proposed SHM methodology for FRC cracking identification of the specimens at various loading levels with different sensor layouts. Additionally, damage quantification using values of statistical damage indices is included. For this reason, the well-known conventional static metric of the Root Mean Square Deviation (RMSD) and the Mean Absolute Percentage Deviation (MAPD) were used and compared. This paper addresses a reliable monitoring experimental methodology in FRC to diagnose damage and predict the forthcoming flexural failure at early damage stages, such as at the onset of cracking. Test results indicated that damage assessment is successfully achieved using RMSD and MAPD indices of a strategically placed network of PZT sensors. Furthermore, the Upper Control Limit (UCL) index was adopted as a threshold for further sifting the scalar damage indices. Additionally, the proposed PZT-enable SHM method for prompt damage level is first established, providing the relationship between the voltage frequency response of the 32 PZT sensors and the crack propagation of the FRC prisms due to the step-by-step increased imposed load. In conclusion, damage diagnosis through continuous monitoring of PZTs responses of FRC due to flexural loading is a quantitative, reliable, and promising application. Full article

This study presents a concrete stress monitoring method utilizing 1D CNN deep learning of raw electromechanical impedance (EMI) signals measured with a capsule-like smart aggregate (CSA) sensor. Firstly, the CSA-based EMI measurement technique is presented by depicting a prototype of the CSA sensor and a 2 degrees of freedom (2 DOFs) EMI model for the CSA sensor embedded in a concrete cylinder. Secondly, the 1D CNN deep regression model is designed to adapt raw EMI responses from the CSA sensor for estimating concrete stresses. Thirdly, a CSA-embedded cylindrical concrete structure is experimented with to acquire EMI responses under various compressive loading levels. Finally, the feasibility and robustness of the 1D CNN model are evaluated for noise-contaminated EMI data and untrained stress EMI cases. Full article

This study presents a novel approach to conducting the electromechanical impedance (EMI) technique for delamination detection in composite structures without the need for permanently attaching PZT (Lead Zirconate Titanate) transducers to the surface. Instead, a device is created that can be simply placed on top of the composite structure, enabling one to perform the EMI technique for detecting damage. The primary objective is to investigate the effectiveness of this device in detecting delamination within composite materials. Additionally, this study explores the impact of placing additional weight on top of the transducer to investigate the performance of the device subjected to higher pressure. Experimental results and analysis will be presented to evaluate the feasibility and reliability of this approach for non-destructive testing and structural health monitoring of composite components. This research is significant as it lays the groundwork for developing automated damage detection systems using robotics in the near future. By demonstrating the proposed concept that can be easily integrated into robotic platforms, this study contributes to the advancement of automation in structural health monitoring. Implementing this technique in robotic systems has the potential to revolutionize maintenance practices by enabling continuous, real-time monitoring of composite structures, enhancing safety, and minimizing downtime due to structural defects. Moreover, the investigation into the impact of additional weight on the transducer’s performance is crucial for setting minimum weight limits in robotic systems, ensuring optimal functionality and accuracy during automated damage detection tasks. Full article

Interface bonding conditions between concrete and steel materials play key roles in ensuring the composite effect and load-carrying capacity of concrete–steel composite structures such as concrete-filled steel tube (CFST) members in practice. A method using both surface wave and electromechanical impedance (EMI) measurement for detecting the existence and the location of inaccessible interface debonding defects between the concrete core and steel tube in CFST members using piezoelectric lead zirconate titanate (PZT) patches as actuators and sensors is proposed. A rectangular CFST specimen with two artificially mimicked interface debonding defects was experimentally verified using PZT patches as the actuator and sensor. By comparing the surface wave measurement of PZT sensors at different surface wave travelling paths under both a continuous sinusoidal signal and a 10-period sinusoidal windowed signal, three potential interface debonding defects are quickly identified. Furthermore, the accurate locations of the three detected potential interface debonding defects are determined with the help of EMI measurements from a number of additional PZT sensors around the three potential interface debonding defects. Finally, the accuracy of the proposed interface debonding detection method is verified with a destructive observation by removing the local steel tube at the three detected interface debonding locations. The observation results show that the three detected interface debonding defects are two mimicked interface debonding defects, and an unexpected debonding defect occurred spontaneously due to concrete shrinkage in the past one and a half years before conducting the test. Results in this study indicate that the proposed method can be an efficient and accurate approach for the detection of unknown interface debonding defects in existing CFST members. Full article

Reinforced Concrete (RC) members in existing RC structures are susceptible to shear-critical due to their under-reinforced design. Thus, implementing a retrofitting technique is essential to eliminate the casualties that could arise from sudden and catastrophic collapses due to these members’ brittleness. Among other proposed techniques, using Carbon-Fiber Reinforced Polymers (C-FRP) ropes to increase the shear strength of RC structural elements has proved to be a promising reinforcement application. Moreover, an Electro-Mechanical Impedance (EMI-based) method using Lead Zirconate Titanate (PZT-enabled) was employed to assess the efficiency of the strengthening scheme. Initially, the proposed technique was applied to C-FRP rope under the subjection of pullout testing. Thus, a correlation of the rope’s tensile strength with the EMI responses of the PZT patch was achieved using the Root Mean Square Deviation (RMSD) metric index. Thereafter, the method was implemented to the experimentally acquired data of C-FRP ropes, used as shear reinforcement in a rectangular deep beam. The ropes were installed using the Embedded Through Section (ETS) scheme. Furthermore, an approach to evaluate the residual shear-bearing capacity based on the EMI responses acquired by being embedded in and bonded to the ropes’ PZTs was attempted, demonstrating promising results and good precision compared to the analytical prediction of the C-FRP ropes’ shear resistance contribution. Full article

A new method for the determination of the dynamic modulus of elasticity (E_d) of pine wood, based on the transverse vibration excitation and electromechanical impedance (EMI) response of the lead zirconate titanate (PZT) transducer is proposed. The influence of the length to thickness ratio of the pine specimen on the measurement accuracy was studied through modal simulation analysis. Based on the results of the modal simulation, the size of the pine specimen was optimized, and the scanning frequency range of the EMI response was determined. On this basis, the EMI simulation and test of the pine specimen coupled with a PZT patch were carried out to verify the effectiveness of the novel method. The impedance simulation results of three kinds of pine specimens show that a unique and significant formant appears in the real part of each EMI response curve, and the maximum relative errors of the rectangular PZT patch and circular PZT patch are 1.34% and 1.81%, respectively. The impedance test results of three kinds of pine specimens indicate that the maximum relative errors of the rectangular PZT patch and circular PZT patch are 1.41% and 1.68%, respectively, compared with the corresponding results obtained by the traditional transverse vibration method. Simulation and experimental results verify the validity of the proposed method for the elastic modulus determination of pine wood. Full article

This study investigates the application of electro-mechanical impedance (EMI) sensing technology to evaluate the hardness of cosmetic creams. Traditional methods, like penetration resistance testing, can be intrusive and disrupt continuous monitoring by impacting internal structures. To overcome this limitation, a piezoelectric sensor is embedded in cosmetic creams to capture EMI signals. This experiment explores varying wax content levels in the creams, establishing correlations between conventional hardness values and EMI signals. The results demonstrate a positive relationship between wax content, hardness values, and the magnitude of EMI resonance peaks. This study emphasizes a robust correlation between established hardness metrics and EMI signals, showcasing the potential of non-destructive testing to drive advancements in cosmetic industry practices. Full article

Effective damage identification is paramount to evaluating safety conditions and preventing catastrophic failures of concrete structures. Although various methods have been introduced in the literature, developing robust and reliable structural health monitoring (SHM) procedures remains an open research challenge. This study proposes a new approach utilizing a 1-D convolution neural network to identify the formation of cracks from the raw electromechanical impedance (EMI) signature of externally bonded piezoelectric lead zirconate titanate (PZT) transducers. Externally bonded PZT transducers were used to determine the EMI signature of fiber-reinforced concrete specimens subjected to monotonous and repeatable compression loading. A leave-one-specimen-out cross-validation scenario was adopted for the proposed SHM approach for a stricter and more realistic validation procedure. The experimental study and the obtained results clearly demonstrate the capacity of the introduced approach to provide autonomous and reliable damage identification in a PZT-enabled SHM system, with a mean accuracy of 95.24% and a standard deviation of 5.64%. Full article

Fiber-reinforced polymer (FRP) strengthening systems have been considered an effective technique to retrofit concrete structures, and their use nowadays is more and more extensive. Externally bonded reinforcement (EBR) and near-surface mounted (NSM) technologies are the two most widely recognized and applied FRP strengthening methods for enhancing structural performance worldwide. However, one of the main disadvantages of both approaches is a possible brittle failure mode provided by a sudden debonding of the FRP. Therefore, methodologies able to monitor the long-term efficiency of this kind of strengthening constitute a challenge to be overcome. In this work, two reinforced concrete (RC) specimens strengthened with FRP and subjected to increasing load tests were monitored. One specimen was strengthened using the EBR method, while for the other, the NSM technique was used. The multiple cracks emanating in both specimens in the static tests, as possible origins of a future debonding failure, were monitored using a piezoelectric (PZT)-transducer-based electromechanical impedance (EMI) technique and a digital image correlation (DIC) system. Clustering approaches based on impedance measurements of the healthy and damaged states of the specimens allowed us to suspect the occurrence of cracks and their growth. The strain profiles captured in the images of the DIC system allowed us to depict surface hair-line cracks and their propagation. The combined implementation of the two techniques to look for correlations during incremental bending tests was addressed in this study as a means of improving the prediction of early cracks and potentially anticipating the complete failure of the strengthened specimens. Full article
