Aiming to develop high-performance flexible electrode materials for dielectric elastomer actuation systems applied to micro-crawling robots, this study proposes multi-dimensional filler composite electrode materials with a methyl vinyl silicone rubber matrix. Three types of conductive fillers—namely, zero-dimensional super-conductive carbon black, one-dimensional single-walled carbon nanotubes, and two-dimensional flaky micron-sized silver powder—were employed to construct a hierarchical multi-dimensional conductive network within the silicone rubber matrix via a three-stage fabrication strategy. The electrical conductivity and conductive stability of the as-prepared composite electrode materials were systematically investigated, where the intrinsic mechanisms and evolutionary laws of material electrical performance variations were analyzed. Furthermore, the effects of fillers with different dimensional morphologies on the comprehensive properties of the composites at each fabrication stage were explored, and the optimal filler dosage for each component was determined. Microstructural observations of the staged conductive network formation further verified the rationality of the stage-based functional design model. The optimized composite electrode delivers an initial electrical conductivity of 1.5 × 10⁴ S/m, with only a 14.9% conductivity attenuation under 50% tensile strain, demonstrating excellent electromechanical stability. Moreover, a prototype micro-crawling robot was fabricated using the optimized composite electrode, achieving a maximum linear crawling speed of 8 mm/s. These experimental results validate the feasibility and superiority of the proposed multi-dimensional filler composite strategy. This work provides a novel technical approach for the design and development of high-performance flexible electrode materials for flexible electronic and micro-robotic actuation applications. Full article

Commercial lead zirconate titanate (PZT) ceramics are widely employed in electromechanical devices due to their excellent piezoelectric response and operational stability. This study investigates the influence of polarization temperature and time on the electromechanical performance of commercial Sparkler PZT-4 (Navy Type I) ceramics. Samples were compacted, sintered at 1230 °C, and polarized under temperatures ranging from 80 to 110 °C for 2, 8, and 15 min using a constant electric field of 3.0 kV/mm. Microstructural, physical, and crystallographic analyses confirmed the successful processing of the ceramics, yielding an apparent density of 7.68 g/cm³, relative density of 96.02%, and the predominance of the tetragonal Pb(Zr,Ti)O₃ perovskite phase. Electromechanical characterization revealed a strong dependence of the piezoelectric coefficient (d₃₃) and electromechanical coupling factor (K_p) on the polarization conditions. Maximum values of d₃₃ = 325.8 pC/N and K_p = 0.509 were obtained under elevated temperatures and longer polarization times. A phenomenological Avrami approach indicated faster apparent domain alignment at higher temperatures, while ANOVA and Tukey tests confirmed the significant influence of polarization parameters on the electromechanical response. The results identify favorable polarization conditions for commercial PZT-4 ceramics used in sensors, actuators, and ultrasonic transducers. Full article

To address the bottlenecks of conventional valve-controlled marine steering systems—characterized by high throttling losses, low efficiency, and high leakage risk—as well as the insufficient power density and impact resistance of electro-mechanical actuators (EMAs) for high-load steering of large vessels, this paper proposes and validates a high-performance integrated solution for an electro-hydrostatic actuator (EHA) for ship steering. First, a fifth-order electro–hydraulic–mechanical coupled dynamic model comprising a permanent magnet synchronous motor, hydraulic pump, hydraulic cylinder, and load is established. The validity and applicability boundaries of three simplifying assumptions—neglecting leakage, pipeline pressure losses, and steady-state fluid compressibility effects—are quantitatively analysed, with a total introduced error ≤3%. These assumptions are justified under medium-pressure, short-pipeline, and well-sealed conditions typical of marine EHA systems. Second, a composite control architecture combining outer-loop sliding mode control with inner-loop motor PID dual-loop control is proposed. Parameter tuning is performed using pole placement for the sliding surface and the Ziegler–Nichols critical ratio method for the inner loops, effectively suppressing hydraulic system parameter perturbations and random wave-induced load disturbances. Quantitative comparisons show that the proposed method reduces overshoot by 11.63% and improves sinusoidal tracking accuracy by 90.13% compared to conventional single-loop PID control. An integrated drive-control structure is designed, and a three-phase full-bridge inverter main circuit with wide-voltage input capability—including EMI filtering, soft-start, and LC filtering—is developed to accommodate the ±20% voltage fluctuations typical of ship power grids, thereby enhancing system integration and grid adaptability. Phased bench tests demonstrate that the settling time from no-load start-up to 200 r/min is only 0.01 s. When a sudden 20 N·m load is applied, the speed drop is less than 3%, and the recovery time is less than 0.025 s. The steady-state steering angle error does not exceed 0.12°, the maximum average steering rate reaches 3.33°/s, and the steering response time is within 0.3 s. All core performance indicators exceed the general technical standards for marine steering systems, with a 65.7% improvement in steady-state accuracy and a 62.5% improvement in response speed over conventional PID control. The research findings provide an effective general technical solution and experimental data support for the performance optimization and engineering application of marine EHA systems. Full article

To address the limitations of the centralized hydraulic steering system used in the first-generation heavy-duty wheeled platform developed by our team, this study proposes a fully electrified steering system based on a compact direct-drive electro-mechanical actuator (DEMA) architecture. Compared with the original hydraulic system, the proposed solution reduces the steering-system weight from approximately 150 kg to 32 kg in the single-channel configuration and 40 kg in the dual-channel configuration, while significantly improving system integration and maintainability. For the single-channel DEMA steering system, a composite control strategy combining three-loop PID control with feedforward compensation is developed to improve dynamic response and position-tracking accuracy. AMESim simulation results under a steering resistance torque of 6000 ± 500 Nm show that the system achieves an overshoot below 2%, a steady-state error below 0.1°, and a tracking error below 0.4°. To reduce motor power and thermal-management requirements, a dual-channel DEMA steering architecture is further proposed. Considering inter-channel parameter differences, a primary–secondary synchronization control strategy is developed to suppress force-fighting behavior and improve motion consistency. Simulation results demonstrate that the proposed strategy effectively reduces synchronization errors and maintains highly consistent force output between channels while preserving excellent steering accuracy and tracking performance. The proposed fully electrified steering system and synchronization control strategy provide an effective solution for improving the dynamic performance, lightweight design, and reliability of heavy-duty wheeled platforms. Full article

To address the challenges of linguistic fuzziness, cognitive variability across fault modes, and the risk of model distortion during optimization, this paper proposes an interpretable belief rule-based fault diagnosis method for complex equipment considering linguistic fuzzy information. First, to address the difficulty experts face in providing precise probability values, an interval grey number table is constructed. By converting linguistic fuzzy information into interval grey representations, the approach quantifies the uncertainty inherent in expert judgments while fully preserving the boundary information of the underlying knowledge. Second, recognizing that expert familiarity varies across different fault modes, a certainty degree fusion method is introduced. This method utilizes fusion weights to mitigate the interference of low-confidence evidence during rule generation. Finally, an interpretable parameter optimization method featuring dynamic knowledge anchoring is designed to constrain model parameters within the reasonable bounds defined by expert knowledge. Validation on an electromechanical actuator demonstrates that the proposed method not only achieves superior diagnostic performance but also ensures model usability and interpretability in practical engineering applications. Full article

Designing an aircraft requires multidisciplinary analysis and data processing abilities, which are often spread over various partners. Effective collaboration across organisational boundaries is difficult, but essential. As the aerospace industry becomes increasingly digitalised, ever larger volumes of data and models must be exchanged. Heterogeneous tools, data formats, and infrastructures make it difficult to exchange data and to trace it. We propose using semantic graphs for data exchange to ensure interoperability, while semantic links between data models facilitate multidisciplinary and cross-organisational collaboration. Furthermore, our approach captures comprehensive metadata that describes the creation and modification of each dataset, thereby establishing a fully traceable data provenance chain. We demonstrate its functionality via a design process for an electromechanical actuator (EMA) given requirements from a different stakeholder (simulated). Having the requirements and the EMA models translated in Resource Description Framework (RDF) graphs, we are able to create links between them. This then enables the EMA model to be automatically re-evaluated when requirements change, ensuring that it complies with them. For the data exchange, we use the DLR SemanticHub, which utilises a graph database. By providing traceability of the data results provided in different data formats and the data origins, we enable transparency and accountability across organisational boundaries, which is important for trusted collaboration and compliance in intercorporational data exchange. Full article

Aggressive technology scaling has led to a significant increase in manufacturing process variations and transistor aging effects, which critically degrade the performance of radio frequency (RF) circuits. These reliability challenges are particularly pronounced in voltage-controlled oscillators (VCOs), where phase noise and operating frequency stability are compromised. While design strategies incorporating micro-electromechanical systems (MEMS) actuators enhance VCO performance by leveraging MEMS varactors or inductors with substantially higher quality factors (Q), this benefit is progressively undermined over time by process variations and aging-induced shifts in the threshold voltage and carrier mobility of the VCO’s transistors. This work presents an ultra-low-power current-reuse voltage-controlled oscillator (VCO) designed to maintain stable performance under process variability and reliability-induced parameter shifts. Robust operation is achieved using a self-detecting–correcting (SDC) bias scheme that senses performance drift and applies corrective feedback through body-bias control in the VCO core. Analytical relations are derived to describe the impact of threshold voltage and mobility variations, and the approach is validated via post-layout simulations in a 130 nm complementary metal-oxide semiconductor (CMOS). Under 18% variations in threshold voltage and carrier mobility, the proposed SDC scheme preserves oscillation frequency, phase noise, and figure of merit (FoM) while also mitigating the intrinsic output amplitude imbalance of conventional current-reuse VCOs. Monte Carlo analysis (500 runs) demonstrates low sensitivity to fabrication uncertainty, with a standard deviation below 0.14 dBc/Hz for phase noise, 210 kHz for oscillation frequency, and 0.4 dBc/Hz for FoM. The VCO operates from a 0.9 V supply, consumes 175 μW, and achieves −124 dBc/Hz phase noise at 1 MHz offset near 2.4 GHz (FoM ≈ −199 dBc/Hz). Full article

The AC rotary head, serving as a dual-axis direct-drive rotary actuation unit in five-axis CNC machine tools, integrates torque motors for A- and C-axis actuation, and its structural static and dynamic characteristics directly govern the actuation accuracy, dynamic response, and stability of the electromechanical system. Its complex spatial pose variations further complicate performance prediction. To overcome the difficulty of existing local optimization methods in balancing stiffness-mass matching for such complex actuation assemblies, this paper proposes a static and dynamic performance optimization method based on stiffness-mass matching. First, a pose-dependent semi-analytical dynamic model is established using dynamic condensation and component mode synthesis (CMS) to reveal performance distribution laws across the workspace and identify weak poses. Then, Sobol’ sensitivity analysis identifies key joints and structural components, and the NSGA-II algorithm optimizes their stiffness-mass matching. Finally, a surrogate model performs dimensional parameter optimization targeting the optimized matrices. Results show that the first-order natural frequency increases by 10.5%, translational static stiffness in the X and Y directions improves by over 20%, and other directions by 4.2–18.6%. The proposed method effectively enhances global static and dynamic performance, providing theoretical guidance for the structural design of direct-drive rotary actuators in electromechanical actuation systems. Full article

Magnetic reciprocating engines (MREs) offer an emission-free alternative to internal combustion engines; however, their practical implementation requires precise speed regulation, a challenge compounded by coupled electromechanical dynamics and inductive actuator lag. This paper presents the design, implementation, and experimental comparison of two intelligent control strategies for speed regulation in an MRE prototype: a neural ignition-angle controller that dynamically adjusts ignition timing using an online neural network, and a Voltage Feedforward Neural Network (FFNN) controller that combines a PID feedback loop with an offline-trained inverse neural model as a feedforward compensator. The experimental results confirm that both controllers achieve effective speed tracking. The FFNN approach demonstrates superior performance, exhibiting reduced control effort and a more stable transient response compared with the neural angle controller, while maintaining precise tracking across different operating conditions. Full article

The electromechanical transmission (EMT) systems of hybrid special vehicles are highly susceptible to severe transient torsional resonance under frequent start-stop operating conditions. Traditional entire-frequency domain H_∞ active vibration reduction strategies are often limited by insufficient gain, failing to achieve ultimate suppression within the core resonance frequency band. To address this issue, this paper proposes a finite-frequency H_∞ active torsional vibration suppression strategy based on a motor dual-loop control architecture. This strategy achieves a profound physical decoupling between torsional vibration suppression and steady-state driving tasks. Furthermore, by introducing the Generalized Kalman–Yakubovich–Popov (GKYP) lemma and Linear Matrix Inequalities (LMIs) into the secondary loop, the control degrees of freedom are precisely concentrated on the 8–30 Hz frequency band, where the transient resonance energy is highly localized. This thoroughly eliminates the conservatism inherent in entire-frequency designs. To mitigate the instability risks caused by unmeasurable states and actuator response lags in practical engineering applications, a robust controller integrating input time-delay compensation and dynamic output feedback is subsequently constructed. Numerical case studies and hardware-in-the-loop (HIL) test results based on a specific EMT configuration demonstrate that the proposed strategy effectively overcomes the instability induced by system delays. It achieves an outstanding resonance peak attenuation of up to 93% and strictly constrains output shaft torque fluctuations within a safe threshold of 50 N·m. Ultimately, this study provides an efficient and robust closed-loop engineering solution for the transient vibration management of high-power electromechanical transmission systems and the enhancement of overall vehicle NVH performance. Full article

The advancement of microelectromechanical systems (MEMS) drives the demand for multifunctional ferroelectrics that synergistically combine substantial strain with competitive energy storage capabilities. In this work, the simultaneous enhancement of electromechanical strain and energy storage properties is achieved in (1−x)(Bi_0.5Na_0.5)_0.94Ba_0.06(Ti_0.98Mn_0.02)O₃-xSrTiO₃ (0 ≤ x ≤ 0.3) ceramics by synergistically employing A-site defect engineering and the nonergodic/ergodic relaxor (NR/ER) phase boundary design. The incorporation of Sr²⁺ plays a dual role: it induces cationic disorder that expands the polarization difference (ΔP = P_max − P_r), thereby effectively boosting the recoverable energy density (W_rec). Concurrently, it stabilizes a critical NR/ER phase ratio near room temperature, which maximizes the strain while minimizing the strain hysteresis. Consequently, when x = 0.15, the optimized system delivers a large strain of 0.45% (d₃₃* = 562 pm/V) with low hysteresis (H = 10.8%). In addition, the x = 0.25 composition exhibits an enhanced W_rec of 1.06 J/cm³, a competitive energy-storage potential (W_rec/E) of 0.013 mC/cm², and a high efficiency (η) of 81% under 80 kV/cm. This work provides an effective strategy for developing multifunctional lead-free materials for integrated actuators and energy storage devices. Full article

A comprehensive numerical method was developed to ensure energy-efficient operating modes of a linear motion module powered by an induction motor. The proposed approach is based on minimizing inertial torque, accounting for the inertial properties of the drive components and the load carriage, followed by structural-parametric optimization and dynamic modeling. For the optimization of the drive system, comprising an intermediate gear stage and a primary ball screw mechanism, a normalization-based method combined with numerical parameter sweep was employed. The optimization process yielded optimal values of the screw lead and the number of gear teeth, which were further validated in terms of Pareto optimality. The carriage design was optimized with respect to mass, strength constraints, and dynamic stiffness using the finite element method. For the developed linear motion module, dynamic behavior was simulated by means of a system of nonlinear differential equations, taking into account the electromagnetic characteristics of the induction motor and the nonlinearities of the gear mesh. As a result of the comprehensive approach, the kinematic, force, and energy characteristics of the linear motion module, which was optimized at the design stage, were determined. Full article

Reliable front-end pressure-pulse generation is critical to mud-pulse telemetry because waveform distortion introduced at the rotary valve propagates through the telemetry chain and reduces downstream recoverability. This paper targets accurate and computationally tractable control of an intelligent drill-bit rotary valve under actuator limits, parameter drift, and downhole-like disturbances. A control-oriented electromechanical–hydraulic grey-box model is established, and a real-time lexicographic model predictive control (MPC) framework with candidate pre-screening, move blocking, and online correction/compensation is developed and compared with proportional–integral–derivative (PID) control and conventional MPC. Under a sampling period of $T_s=20\mathrm{ms}$, the proposed controller reduces the step-tracking rise time from $2.18\mathrm{s}$ to $1.76\mathrm{s}$ and the steady-state pressure error from $0.1208\mathrm{MPa}$ to $0.0292\mathrm{MPa}$ relative to conventional MPC. In the pulse-output and mismatch–disturbance scenarios, it further maintains lower steady-state pressure error while reducing the cumulative input variation from $51.0$ to $11.5$ and from $121.5$ to $19.5$, respectively. The observed 99th-percentile and worst-case MATLAB workstation execution times remain below one sampling period, while supplementary mismatch–disturbance sensitivity maps indicate a favorable accuracy–timing compromise within the tested numerical envelope. These results support the proposed method as a simulation-validated candidate for low-complexity rotary-valve control and motivate subsequent bench/hardware-in-the-loop (HIL) validation rather than field-qualified deployment claims. Full article

In the context of reducing air transport emissions, operational costs and transitioning to more electric aircraft, there is a growing need to develop new ice protection systems. Resonant electromechanical de-icing (EM-DI) systems take advantage of the resonance to amplify vibration amplitudes applied through piezoelectric actuators, generating stress in the ice layer, enabling its removal. Research conducted on such systems has been focused on simplified or reduced models, and assessment of aircraft-level requirements has seldom been conducted. To overcome this shortcoming, this work proposes a pre-sizing methodology to evaluate the requirements (power consumption and piezoelectric mass) of EM-DI systems. After dividing the protected area into modules to cycle the aircraft de-icing, finite element models including the ice and the modules’ structure are developed. A modal analysis is performed to identify the extensional resonance modes that enable de-icing, and to calculate the necessary power and piezoelectric mass based on shedding criteria. The methodology is illustrated for two typical aircraft configurations: a jet engine single-aisle aircraft (SA) and a regional turboprop aircraft (TP). The results obtained for the EM-DI technology are promising, with apparent power estimates of as little as $2.7\mathrm{kVA}/{\mathrm{m}}^2$ for the SA and $1.28\mathrm{kVA}/{\mathrm{m}}^2$ for the TP. Full article
