Morse-type tapers at the head–stem junction in total hip replacements (THRs) provide many benefits to permit a successful surgical outcome. However, with the introduction of modular tapered devices comes complications associated with fluid ingress and motion at the interface that can cause fretting corrosion, which has been implicated in clinical failure. Increased surface roughness amplitude (R_a) and angular mismatch to ensure taper contact closer to the equator of the femoral head are design features introduced for use with ceramic heads but have been adopted by metal head couples. While increased surface roughness amplitude has been found to contribute to fretting corrosion, there is a distinct lack of systematic studies investigating the interactions between angular mismatch and R_a. This study measured the fretting corrosion and motion response of clinically representative samples, in part reference to ASTM F1875, when subjected to uniaxial incremental dynamic loading. The fretting corrosion response was measured in situ with an integrated three electrode electrochemical cell. Motion at the head–neck interface was measured with a bespoke motion measurement solution based on eddy-current principles which uses four sensors to allow motion to be fully characterised in three dimensions. Key findings from this study included a 5–10-fold increase in current measured in the increased roughness amplitude samples, suggesting an increased susceptibility to fretting corrosion without a corresponding increase in motion. The distal samples engaged around the opening of the taper interface and presented the lowest current measurements but most off-axis subsidence. Findings from this study indicate that optimisation of the taper interfaces in THR, in terms of fretting corrosion and motion, can be made and can be assessed using short-term preclinical tests. Full article

Three-dimensional (3D) ear morphology is critical for the design of in-the-ear hearing aids, earphones, transcutaneous auricular vagus nerve stimulation (taVNS) electrodes, and auricular reconstruction, yet most existing ear shape models still rely on manually placed landmarks. Here, a fully annotation-free pipeline is presented for constructing a 3D ear atlas and statistical shape model (SSM) of the auricular bowl from 50 surface meshes. Individual ears are iteratively registered to a current atlas using rigid the iterative closest point (ICP) algorithm followed by a bidirectional thin-plate spline (BiTPS) deformation, and dense surface correspondences are established by nearest-neighbour mapping. Registration quality is quantified using mean and maximum nearest-neighbour distance, symmetric Chamfer-$L_2$ distance and coverage. Furthermore, SSM-derived bowl height and width are validated against manual 3D mesh measurements in Geomagic Design X. Across five atlas iterations, the BiTPS pipeline substantially reduces registration errors and increases coverage, and principal component analysis (PCA) derived dimensions show excellent agreement with manual measurements (Pearson $r\ge 0.98$, ICC $\ge 0.98$). The proposed framework yields a stable, anatomically plausible ear atlas and an interpretable low-dimensional SSM without manual landmarks, providing a computational basis for the geometric optimization of ear-related medical and wearable devices. Full article

The contamination of aquatic environments, including treated and drinking water, by microplastics poses a significant threat to ecosystems and human health. Current detection methods often rely on slow laboratory-based tests and offline analysis, which do not support real-time monitoring. This paper presents a novel focusing and concentrating device designed to enhance the real-time detection of microplastics in flowing water. The device utilizes an electrokinetic manipulation mechanism to focus microplastics toward the center of the water flow inside a pipe or fluid channel. A set of 3D rectangular electrodes, with dimensions of 5 mm × 2.5 mm × 1 mm, are arranged circumferentially and longitudinally along the inner perimeter of the fluid channel to generate an intense, non-uniform electric field. Simulation results indicate that microplastics near the channel wall experience a repulsive force on the order of ${10}^{-16}$ to ${10}^{-10}$ N toward the channel center. The applied signal amplitude and the physical properties of the microplastics strongly influence this repulsive force. The trajectories and output concentration of microplastics are investigated under varied conditions. A Voltage of approximately 25 V and a flow rate of 0.05 m/s are found to be ideal for concentrating microplastics into a narrow particle stream, enabling more efficient downstream detection and analysis. Pre-concentrating microplastics in fluid channels prior to sensing is expected to increase sensor sensitivity and improve selectivity. Full article

Understanding cell migration is essential not only for fundamental biology but also for the development of targeted disease therapies. Traditional in vitro cell migration assays typically rely on optical microscopy to capture cell movements and subsequent image-based tracking to quantify cell migration characteristics, which often involve substantial experimental workload and analytical complexity. Therefore, there is a need for an automated and streamlined approach to monitor and analyze cell movements. In this work, a microfabricated impedance sensor integrating electrode pairs and selectively protein-coated channels was developed for real-time monitoring of single-cell migration. The optimized electrode dimensions with 10 μm width and 10 μm gap enabled sensitive detection of impedance magnitude increase induced by individual cells. The impedance magnitude changes were correlated with the cell coverage area on electrodes, allowing continuous tracking of single-mouse osteoblast MC3T3 cell movement across the electrode pair. Distinct impedance responses of signal duration and magnitude were observed under different surface coatings, revealing the influence of microenvironmental chemistry on cell motility and adhesion. Furthermore, comparative impedance profiling of MC3T3 and nasopharyngeal epithelial NP460 cells demonstrated that MC3T3 cells produced larger changes in impedance real part and phase due to larger spreading area and larger number of focal adhesions, whereas NP460 cells showed shorter impedance signal change durations, consistent with faster cell migration. These electrical signatures collectively captured intrinsic differences in cell morphology, adhesion, and motility. The developed impedance sensor provides a label-free approach for single-cell migration characterization and can be potentially applied to cell identification. Full article

Molecular-scale detection based on quantum tunnelling is promising for molecular electronics and high-sensitivity analysis, owing to its sensitivity to molecular structure and energy levels. However, conventional two-electrode tunnelling measurements suffer from overlapping conductivity of different molecules, limiting molecular discrimination in complex systems. To address this, we propose an electrochemical-gate-controlled nanoscale tunnelling strategy that expands the two-electrode system to a three-electrode configuration via a tunable gate potential, enabling the differentiation of distinct molecules at near-single-molecule sensitivity. Scanning the gate potential under constant tunnelling bias modulates the alignment between molecular orbitals and the electrode Fermi level, altering the statistical characteristics of molecular tunnelling transport. Experimental results show that target molecules induce a bimodal distribution of tunnelling current (background and molecule-correlated channels), with the second peak exhibiting distinct gate potential dependence. Comparative analysis of ascorbic acid (AA), acetylcholine (ACh), and uric acid (UA) reveals unique trajectories of characteristic peaks with gate potential, forming an electrochemical gate response fingerprint. This gate-dependent conductance trajectory provides a novel statistical dimension for molecular recognition, enabling differentiation of distinct molecules. Full article

This work presents wirelessly interrogated microelectromechanical system (MEMS) capacitive sensors for continuous intraocular pressure (IOP) monitoring. The sensor uses a passive inductor–capacitor (LC) tank circuit comprising a fixed, on-chip spiral inductor and a pressure-sensitive, variable-gap capacitor with parallel-plate membrane electrodes and side anchors. The membrane is designed with dimensions of 500 µm × 500 µm × 2 µm and a capacitive transducer gap of 2.5 µm. Applied pressure deflects the top membrane, producing a corresponding capacitance variation that changes the frequency and phase response of the LC tank circuit, enabling real-time and continuous IOP monitoring over a target detection range of 0–50 mmHg and beyond. Mutual inductive coupling between the sensor and the external readout coil is investigated as a reliable readout mechanism. Full article

Multifrequency operation in micromachined ultrasonic transducers, enabled by targeted excitation of specific vibrational modes, has emerged as an attractive approach for achieving tunable performance and configurability, well-suited for advanced ultrasound imaging and therapeutic applications. This paper presents a dual-electrode rectangular piezoelectric micromachined ultrasonic transducer (PMUT) designed for efficient dual-frequency operation through mode-selective actuation. The proposed architecture employs segmented electrodes that are spatially aligned with the strain distributions of two distinct flexural modes, enabling selective excitation of Mode 1 (fundamental) and Mode 3 (higher order) through appropriate electrode actuation. Finite element simulations and impedance analysis were used to guide the electrode configuration and validate the mode-selective behavior. The dual-mode PMUT was fabricated alongside a conventional single-electrode PMUT using identical membrane dimensions and material stack for direct comparison. Comprehensive electrical and underwater acoustic characterization confirmed that the conventional PMUT is limited to single-frequency operation at the fundamental resonance. In contrast, the proposed design achieved a substantial improvement in higher-order performance, with a threefold increase in acoustic pressure at Mode 3 compared to the conventional device. These results demonstrate that mode-aligned electrode segmentation enables efficient dual-mode operation without added fabrication complexity, making the design highly suitable for multifrequency ultrasonic applications such as biomedical imaging and sensing. Full article

Sub-15 nm line structures are key building blocks for advanced device prototyping, nanoscale electrodes, and lithography templates such as etch/deposition masks. Although ultrahigh-voltage (≥100 kV) electron-beam lithography (EBL) can more readily achieve extremely small critical dimensions, its tool and infrastructure requirements limit widespread adoption in many laboratories. In contrast, 30 kV field-emission SEM platforms are far more accessible; however, resolution-limit patterning at 30 kV is more sensitive to beam current, exposure dose, and development conditions, motivating the establishment of a reproducible process flow and a well-defined process window. Here, we investigate the resolution limit of isolated lines using a Zeiss Gemini 460 system operated at 30 kV and an in-house pattern generator with 950 k PMMA C2 resist. To demonstrate device-level applicability, we develop a stable lift-off process, and all critical dimensions are evaluated on metal lines after e-beam evaporation and lift-off. By screening beam current and scanning dose to build the dose-to-size relationship, we show that reducing beam current significantly improves the achievable minimum line width. Under 35 pA, using CD ≤ 15 nm as the criterion for sub-15 nm window extraction, the usable dose range is [700, 804.3] µC/cm², corresponding to a dose latitude of ~14.9%. The best performance is obtained at 700 µC/cm², yielding a transferred metal line width of 13.85 nm after lift-off. This work provides a practical resolution-limit process flow and a quantitative process window for performing sub-15 nm patterning on accessible 30 kV platforms, supported by product-level lift-off validation. Full article

This work presents the design and simulation of DEP electrodes with an interdigitated electrode (IDE) pattern for the alignment of 1D nanostructures using COMSOL simulations. The impact of electric field distribution with varying electrode geometry, voltage, and frequency were studied using these simulations. The maximum electric field value of 2.6 × 10⁶ V/m was observed at electrode edges and gaps. Moreover, a significant increase in the electric field was observed with a decrease in finger width. These simulation results for DEP electrodes have huge potential in advancing 1D nanowire-based flexible and wearable electronic devices in the future. Full article

Effective electrochemical CO₂ reduction to liquid fuels requires that the local catalytic environment facilitates the desired reactivity, yet a microscopic understanding of this environment is difficult to achieve from experiment alone. In this work, a 3D reaction-diffusion model was developed to explore the effects of electrode surface area and local geometry on the performance of a heterogeneous catalyst that performs a two-step CO₂ reduction cascade reaction to CO and then CH₃OH under aqueous conditions. Kinetic parameters for the model were inspired by experimental results using a cobalt phthalocyanine (CoPc) catalyst. Three-dimensional architectures composed of arrays of square pillars with varying dimensions and either smooth or periodically modulated surfaces were tested, revealing the extent to which geometry modulates the performance of the cascade reactions. Although structural variations modulate local concentration gradients, we find that electrochemically active surface area predominantly governs the overall cascade reaction. Moreover, the results suggest that supersaturation of CO, with concentrations up to ten-fold higher than the equilibrium solubility limit, might be critical for more efficient conversion to CH₃OH. For any given geometry, the spatially averaged ratio of [CO] to [CO₂] is dictated by the electrochemically active surface area and determines the yield of CH₃OH. For a fixed surface area, geometries that spatially confine the electrolyte yield moderate local [CO] to [CO₂] ratios within small volumes. In contrast, less confining geometries result in a broader distribution of local ratios spread over larger volumes, with both configurations yielding the same spatially averaged [CO] to [CO₂] ratio. These insights provide valuable design principles—highlighting the critical importance of surface area and possibly CO supersaturation—for engineering advanced electrode architectures that leverage intermediate trapping and CO supersaturation to enhance overall performance in tandem CO₂ reduction systems. Full article

This paper presents a numerical investigation studying the response of a new grounding system when submitted to different lightning current waveforms. This grounding system features an electrically conductive concrete (ECON) or geopolymer (ECG) square section with a standard steel rebar as an encased electrode (EE) at the center to potentially replace conventional copper or galvanized steel grounding grids in HV substations. Due to the specificity of this new grounding system called ECON/ECG-EE, we decided to perform different transient simulations using the RF module of the general FEM software Comsol Multiphysics 6.2 version. In the first step, both frequency (FD) and temporal domain (TD) analyses were validated using three grounding systems extracted from the literature. Next, several numerical new grounding system simulations were performed and compared with a conventional HV substation copper grid of the same dimensions equipped with vertical rods. We investigated the influence of several parameters, such as ECON/ECG and soil electrical conductivity, the rise-time in current lightning waveform and the frequency dependency of soil parameters. The numerical results obtained demonstrate that ECON/ECG-EE grounding systems submitted to lightning current pulse present a smaller peak impedance than conventional SGSs equipped with vertical rods, particularly in cases with high soil resistivity. Moreover, it was also demonstrated that with faster lightning current pulse, the ECON/ECG system’s peak impedance becomes significantly lower than those obtained for a copper grid with vertical rods. Full article

An ultrafast laser system combined with an optical delay line allowed ablation and in-scription at 1 kHz and 1 GHz pulse burst within transparent polyimide films. The two-photon-induced absorption results in clean surface ablation, while inscription results in polymer decomposition, creating carbonised regions within the polymer. Three pulse bursts at 1 GHz increased the observed coupling to the material significantly. Modified regions (with linewidths down to a few microns) were investigated using optical microscopy, white light interferometry, SEM and Raman spectroscopy, supporting the increasing carbon density relative to the pristine polymer. As depth of field was only a few microns at high NA, 3D micro-structuring was achieved. Polymer decomposition produces gaseous products, resulting in internal stress and thus affecting inscription fidelity. An inscribed subsurface electrode with dimensions of 5 mm × 0.3 mm × 3 μm connected to conducting vias had a resistance of R = 10.6 ± 0.2 kΩ, along with resistivity of ρ ~ 0.19 Ω cm; hence, it had DC conductivity, σ ~ 5.3 Scm⁻¹. This conductivity is similar to that of bulk graphite and could well form the basis of future flexible sensors, demonstrating single-step 3D subsurface inscription of carbon or laser-induced graphene structures. Full article

Levees with double-layered foundations are characterized by a weakly permeable upper layer and a highly permeable sand layer beneath, which makes them susceptible to internal erosion, particularly backward erosion piping (BEP). Therefore, locating BEP channels before the failure of a levee is crucial for ensuring the safety of levee projects. In this study, a novel method is proposed for detecting BEP channels efficiently. This method involves applying the successive linear estimator (SLE) to fuse multipoint measured voltage to characterize the inner levee structure. Therefore, the BEP channels can be recognized from the details of the levee structure. This method is named three-dimensional geostatistical electrical resistivity tomography (3D GERT) in this study. To validate the performance of GERT, a custom-developed indoor sandbox device was used for physical BEP conductivity detection tests, and the results were analyzed via the SLE to assess the accuracy of channel engraving. The tests revealed that the surface sand was initially expelled from the piping exit, followed by the formation of a concentrated piping channel that extended upstream. The erosion depth at the piping exit was observed to be deeper than that of the main channel. This study demonstrated that 3D GERT, when the SLE was used as the inversion algorithm, detected BEP channels and achieved an internal erosion dimension deviation of less than 25.5% and a positional erosion dimension deviation within 16.5%. The accuracy of the SLE in mapping BEP channels improved with the use of a more comprehensive electrode distribution and an increased number of electrodes, thus yielding a more precise representation of the channel scale and pattern. The coefficient of determination (R²) between the acquired data and the simulated data generated by 3D GERT was greater than 0.85, demonstrating the capability of the simulated values to track and reproduce the variation trends observed in the acquired data. Thus, the SLE, when used as the inversion algorithm for 3D GERT, reliably represents BEP channels. Full article

This study proposes 4D-MRSimNet, a framework that employs attention mechanisms to focus on distinct dimensions. The approach applies enhancements to key responses in the spatial and spectral domains and provides a characterization of dynamic evolution in temporal domain, which extracts and integrates complementary emotional features to facilitate final classification. At the feature level, differential entropy (DE) and power spectral density (PSD) are combined within four core frequency bands ($\theta$, $\alpha$, $\beta$, and $\gamma$). These bands are recognized as closely related to emotional processing. This integration constructs a complementary feature representation that preserves both energy distribution and entropy variability. These features are organized into a 4D representation that integrates electrode topology, frequency characteristics, and temporal dependencies inherent in EEG signals. At the network level, a multi-resolution convolutional module embedded with SimAM attention extracts spatial and spectral features at different scales and adaptively emphasizes key information. A bidirectional GRU (BiGRU) integrated with temporal attention further emphasizes critical time segments and strengthens the modeling of temporal dependencies. Experiments show that our method achieves an accuracy of 97.68% for valence and 97.61% for arousal on the DEAP dataset and 99.60% for valence and 99.46% for arousal on the DREAMER dataset. The results demonstrate the effectiveness of complementary feature fusion, multidimensional feature representation, and the complementary dual attention enhancement strategy for EEG emotion recognition. Full article

This study aims to establish a method-integrative framework for emotion-oriented architectural image generation. The framework combines Stable Diffusion with targeted LoRA (Low-Rank Adaptation), a lightweight and parameter-efficient fine-tuning approach, together with ControlNet-based structural constraints, to examine how controllable design-element manipulations influence emotional responses. The methodology follows a closed-loop “generation–evaluation” workflow, with each LoRA module independently targeting a single design element. Guided by the relaxation–arousal emotional dimension, the framework is evaluated using subjective ratings and electroencephalogram (EEG) measures. Twenty-seven participants viewed six architectural space categories, each comprising four conditions (baseline, color, material, and form modification). EEG α/β power ratio (RAB) served as the primary neurophysiological marker of arousal. Statistical analysis indicated that LoRA-based modifications of design elements produced distinct emotional responses: color and material changes induced lower arousal, whereas changes in form elicited a bidirectional pattern involving relaxation and arousal. The right parietal P4 electrode site showed the most sensitive emotional response to design element changes, with consistent statistical significance. P4 is a human scalp EEG location associated with cortical activity related to visuospatial processing. Descriptive results suggested opposite directional effects with similar intensity trends; however, linear mixed-effects model (LMM) inference did not support significant group-level linear coupling, indicating individual variation. This study demonstrates the feasibility of emotion-guided architectural image generation, showing that controlled manipulation of color, material, and form can elicit measurable emotional responses in human brain activity. The findings provide a methodological basis for future multimodal, adaptive generative systems and offer a quantitative pathway for investigating the relationship between emotional states and architectural design elements. Full article
