Radio photonic technologies have emerged as a promising solution for addressing microwave frequency synthesis challenges in current and future communication and sensing systems. One particularly effective approach is the optoelectronic oscillator (OEO), a simple and cost-effective electro-optical system. The OEO can generate microwave signals with low phase noise and high oscillation frequencies, often outperforming traditional electrical methods. However, a notable disadvantage of the OEO compared to conventional signal generation methods is its significant frequency tuning step. This paper presents a novel approach for continuously controlling the output frequency of an optoelectronic oscillator (OEO) based on integrated photonics. This is achieved by tuning an integrated optical delay line within a feedback loop. The analytical model developed in this study calculates the OEO’s output frequency while accounting for nonlinear errors, enabling the consideration of various control schemes. Specifically, this study examines delay lines based on the Mach–Zehnder interferometer and microring resonators, which can be controlled by either the thermo-optic or electro-optic effect. To evaluate the model, we conducted numerical simulations using Ansys Lumerical software. The OEO that utilized an MRR-based electro-optical delay line demonstrated a tuning sensitivity of 174.5 MHz/V. The calculated frequency tuning sensitivity was as low as 6.98 kHz when utilizing the precision digital-to-analog converter with a minimum output voltage step of 40 μV. The proposed approach to controlling the frequency of the OEO can be implemented using discrete optical components; however, this approach restricts the minimum frequency tuning sensitivity. It provides an additional degree of freedom for frequency tuning within the OEO’s operating range, which is ultimately limited by the amplitude-frequency characteristic of the notch filter. Thus, the proposed approach opens up new opportunities for increasing the accuracy and flexibility in generating microwave signals, which can be significant for various communications and radio engineering applications. Full article

In an intelligent driving environment, monitoring the physiological state of drivers is crucial for ensuring driving safety. This paper proposes a method for monitoring and analyzing driver physiological characteristics by combining electronic vehicle identification (EVI) with multimodal biometric recognition. The method aims to efficiently monitor the driver’s heart rate, breathing frequency, emotional state, and fatigue level, providing real-time feedback to intelligent driving systems to enhance driving safety. First, considering the precision, adaptability, and real-time capabilities of current physiological signal monitoring devices, an intelligent cushion integrating MEMSs (Micro-Electro-Mechanical Systems) and optical sensors is designed. This cushion collects heart rate and breathing frequency data in real time without disrupting the driver, while an electrodermal activity monitoring system captures electromyography data. The sensor layout is optimized to accommodate various driving postures, ensuring accurate data collection. The EVI system assigns a unique identifier to each vehicle, linking it to the physiological data of different drivers. By combining the driver physiological data with the vehicle’s operational environment data, a comprehensive multi-source data fusion system is established for a driving state evaluation. Secondly, a deep learning model is employed to analyze physiological signals, specifically combining Convolutional Neural Networks (CNNs) and Long Short-Term Memory (LSTM) networks. The CNN extracts spatial features from the input signals, while the LSTM processes time-series data to capture the temporal characteristics. This combined model effectively identifies and analyzes the driver’s physiological state, enabling timely anomaly detection. The method was validated through real-vehicle tests involving multiple drivers, where extensive physiological and driving behavior data were collected. Experimental results show that the proposed method significantly enhances the accuracy and real-time performance of physiological state monitoring. These findings highlight the effectiveness of combining EVI with multimodal biometric recognition, offering a reliable means for assessing driver states in intelligent driving systems. Furthermore, the results emphasize the importance of personalizing adjustments based on individual driver differences for more effective monitoring. Full article

The utilization of chaotic optical communication, a physical layer security technology, has the potential to enhance the security of optical fiber networks. In this paper, we take knowledge acquired while teaching “A chaotic security system based on phase-intensity (P-I) electro-optic feedback” as an example and, in detail, introduce a teaching implementation process based on the combination of Optisystem and Matlab. Firstly, based on the Lang–Kobayashi (L-K) laser equation, the generation mechanism of electro-optic feedback chaos was explained. Secondly, the P-I electro-optic feedback chaos was analyzed theoretically with the help of Matlab. Finally, a laser chaotic optical communication system based on electro-optic feedback was built with the help of Optisystem (15.0.0) software, and the performance of the communication was simulated and analyzed through the design of system parameters. The teaching design model and facilitate the concretization of the abstract theory of “the principle of chaos generated by electro-optic feedback, the composition of chaotic optical communication system and the performance index of chaotic communication system”. Through after-class exercises and questionnaire surveys, it was verified that the teaching method is widely recognized by students and that it effectively improves the teaching effect of the course of laser chaotic communication and the students’ academic research ability. Full article

This paper investigates an anticipatory activation anti-windup approach based on Linear Active Disturbance Rejection Control (LADRC) to address the influences of accelerated saturation on the actuators in a Miniaturized Inertial Stabilized Platform (MISP) with extreme external disturbance. The proposed method aims to eliminate the high-frequency vibrations on the Line of Sight (LOS) of electro-optical devices during actuator saturation. To achieve this, the Linear Extended State Observer (LESO) is modified by adding saturation feedback to the total disturbance observed state variable, which is operated as an anticipatory activation anti-windup compensator. The stability of the proposed controller is discussed, and the gains are optimized by the Linear Matrix Inequality (LMI) constraints though quadratic programming and an H-infinite performance indicator. Additionally, as the multiple activated scheme for anti-windup, the effectiveness of immediate activation in dealing with accelerated saturation is compared and analyzed. These comparisons and verification are implemented through simulations, where the external disturbance is introduced using recorded attitude data from USV sailing. Finally, experiments are conducted on an MISP for a visual tracking system, demonstrating that the anticipatory activation mothed effectively suppresses high-frequency vibrations on the LOS during instances of accelerated saturation. Full article

A multi-channel phase-compensated active disturbance rejection control (MPADRC) incorporating an improved backstepping strategy is proposed in this paper to handle the phase lag in the extended state observer (ESO) and the residual uncertainty in the system. Firstly, a multi-channel phase-compensated ESO (MPESO) is constructed by adding phase-advanced networks to all output channels of the ESO, which allows disturbances and system states to be compensated and feedback in a more timely manner, respectively. Then, to estimate and offset the residual uncertainty in the system, an improved backstepping control method is employed and a Lyapunov function is designed to verify the convergence of the error between the estimated and actual values of the residual uncertainty. After that, the improved backstepping control is combined with MPADRC, and comparisons with the conventional linear active disturbance rejection control (LADRC) are conducted for a range of cases. Finally, on an inertial stabilization platform in the electro-optical tracking system (ETS), simulation and experimental results verified the effectiveness of the proposed method. Full article

To improve the adaptability of aerial reflective opto-mechanical structures (mainly including the primary mirror and secondary mirror) to low-temperature environments, typically below −40 °C, an optimized thermal control design, which includes passive insulation and temperature-negative feedback-variable power zone active heating, is proposed. Firstly, the relationship between conventional heating methods and the axial/radial temperature differences of mirrors with different shapes is analyzed. Based on the heat transfer analyses, it is pointed out that optimized thermal control design is necessary to ensure the temperature uniformity of the fused silica mirror, taking into account the temperature level when the aerial electro-optics system is working in low-temperature environments. By adjusting the input voltage based on the measured temperature, the heating power of the subregion is changed accordingly, so as to locally increase or decrease the temperature of the mirrors. The thermal control scheme ensures that the average temperature of the mirror fluctuates slowly and slightly around 20 °C. At the same time, the temperature differences within a mirror and between the primary mirror and the secondary mirror can be controlled within 5 °C. Thereby, the resolution of EO decreases by no more than 11.4%. Full article

Electro-optical detection systems face numerous challenges due to the complexity and difficulty of targeting controls for “low, slow and tiny” moving targets. In this paper, we present an optimal model of an advanced n-step adaptive Kalman filter and gyroscope short-term integration weighting fusion (nKF-Gyro) method with targeting control. A method is put forward to improve the model by adding a spherical coordinate system to design an adaptive Kalman filter to estimate target movements. The targeting error formation is analyzed in detail to reveal the relationship between tracking controller feedback and line-of-sight position correction. Based on the establishment of a targeting control coordinate system for tracking moving targets, a dual closed-loop composite optimization control model is proposed. The outer loop is used for estimating the motion parameters and predicting the future encounter point, while the inner loop is used for compensating the targeting error of various elements in the firing trajectory. Finally, the modeling method is substituted into the disturbance simulation verification, which can monitor and compensate for the targeting error of moving targets in real time. The results show that in the optimal model incorporating the nKF-Gyro method with targeting control, the error suppression was increased by up to 36.8% compared to that of traditional KF method and was 25% better than that of the traditional nKF method. Full article

This paper presents a novel approach to addressing the issue of temperature-induced instability in an optical, single-sideband transmitter based on a micro-ring resonator (MRR) suitable for millimeter-wave (mmW) radio-over-fiber (RoF) communications. We propose utilizing the drop port of the MRR to provide a feedback signal to the closed-loop control (CLC) system. The latter serves to maintain the optimal alignment between the laser’s carrier and the MRR’s resonant wavelength, thus mitigating the adverse effects of chromatic-dispersion-induced power fading at the receiving end. Since the feedback information is extracted from the otherwise-wasted resonant energy at the drop port, the control system does not compromise the delicate optical signal at the through port. A CLC was synthesized, designed, and prototyped to provide real-time wavelength tuning of the heat-pump-controlled laser based on the feedback signal. Experimental evaluations demonstrate that the wavelength of the laser could be successfully locked to the MRR’s resonance with a wavelength dither of less than 0.004 nm (~491 MHz). This allowed us to limit the power-penalty deterioration to less than 2 dB for a RoF link with a 2.5-km standard telecommunication single-mode fiber (SMF), a modulation frequency of 37.8 GHz, and a carrier wavelength of 1563.97 nm (~191.820 THz). The proposed solution offers an alternative approach for the carrier and the MRR’s resonant wavelength interlocking without the need for complex photonics like thermo-optic or electro-optic structures to control the temperature or phase velocity, respectively. Full article

A small deviation in the time-delay of the image tracker is essential for improving the tracking precision of an electro-optical system, and for future advances in actuator technology. The core goal of this manuscript is to address issues such as tracking the controller time-delay compensation and the precision of an electro-optical detection system using an advanced filter design, a fire control modeling, and an anti-occlusion target detection system. To address this problem, a small deviation in the time-delay prediction and control method of the image tracker is proposed based on the principle of linear motion transformation. The time-delay error formation is analyzed in detail to reveal the scientific mechanism between the tracking controller feedback and the line-of-sight position correction. An advanced N-step Kalman filtering controller model is established by combining a line-of-sight firing control judgment and a single-sample training anti-occlusion DSST target tracking strategy. Finally, an actuator platform with three degrees of freedom is used to test the optical mechatronics system. The results show that the distribution probability of the line-of-sight measuring error in a circle with a radius of 0.15 mrad is 72%. Compared with the traditional control method, the tracking precision of the optimal method is improved by 58.3%. Full article

A novel simplifying Volterra structure algorithm is proposed for an intensity modulation direct detection (IM-DD) optical fiber short distance communication system using the decision feedback equalization algorithm (DFE). Based on this algorithm, the signal damage for the four-level pulse amplitude modulation signal (PAM-4) is compensated, which is caused by device bandwidth limitation and dispersion during transmission. Experiments have been carried out using a 25 GHz Electro-absorption Modulated Laser (EML), showing that PAM-4 signals can transmit over 10 km in standard single-mode fiber (SSMF). The 112 Gbps and 128 Gbps signals can reach the error rate threshold of KP4-FEC (BER = 2 × 10⁻⁴) and HD-FEC (BER = 3.8 × 10⁻³), respectively. The simplified principle and process of the proposed Volterra-based equalization algorithm are presented. Experimental results show that the algorithm complexity is greatly reduced by 75%, which provides effective theoretical support for the commercial application of this algorithm. Full article

In this paper, we propose a method for cracking the key parameters of an electro-optic self-feedback temporal optical phase encryption system and experimentally demonstrate the feasibility of the scheme. By scanning a tunable dispersion compensation (TDC) module at the receiver, the time delay signature (TDS) of an encrypted signal can be exposed, making it possible to extract other key parameters of the system and reconstruct a decryption setup. The TDS characteristics for three typical modulation formats are investigated, revealing that while such an encryption system is secure against power detection attack, there is a risk of TDS leakage. The findings can guide the design of advanced optical encryption schemes with TDS suppression for security enhancement. Full article

This article discusses application considerations in the micro-electro-mechanical system’s optical sensor. Furthermore, the provided analysis is limited to application issues occurring in research or industrial applications. In particular, a case was discussed where the sensor was used as a feedback signal source. Its output signal is used to stabilize the flux of an LED lamp. Thus, the function of the sensor was the periodic measurement of the spectral flux distribution. The application problem of such a sensor is the output analogue signal conditioning. This is necessary to perform analogue-to-digital conversion and further digital processing. In the discussed case, design limitations come from the specifics of the output signal. This signal is a sequence of rectangular pulses, which can have different frequencies, and their amplitude varies over a wide range. The fact such a signal must be conditioned additionally discourages some optical researchers from using such sensors. The developed driver allows measurement using an optical light sensor in the band from 340 nm to 780 nm with a resolution of about 12 nm; in the range of flux values from about 10 nW to 1 μW, and frequencies up to several kHz. The proposed sensor driver was developed and tested. Measurement results are presented in the paper’s final part. Full article

Lab-on-a-chip systems are currently one of the most promising areas in the development of ultra-compact sensor systems, used primarily for gas and liquid analysis to determine the concentration of impurities. Integrated photonics is an ideal basis for designing “lab-on-a-chip” systems, advantageous for its compactness, energy efficiency, and low cost in mass production. This paper presents a solution for “lab-on-a-chip” device realization, consisting of a sensor and an interrogator based on a silicon-on-insulator (SOI) integrated photonics platform. The sensor function is performed by an all-pass microring resonator (MRR), installed as a notch filter in the feedback circuit of an optoelectronic oscillator based on an electro-optic phase modulator. This structure realizes the frequency interrogation of the sensor with high accuracy and speed using a conventional single-mode laser source. The system sensitivity for the considered gases is 13,000 GHz/RIU. The results show that the use of frequency interrogation makes it possible to increase the intrinsic LoD by five orders. The proposed solution opens an opportunity for fully integrated implementation of a photonic “laboratory-on-a-chip” unit. Full article

With the widespread application of big data, the amount of data transmitted through optical networks has been increasing dramatically. Correlated random bit generation (CRBG) is one of the key technologies in secure communication systems to ensure security performance and transmission efficiency. We propose and demonstrate a CRBG scheme based on a Mach–Zehnder modulator (MZM) electro-optic feedback loop to improve the security and speed of communication systems. In this scheme, common-signal-induced synchronization is accomplished to generate wideband complex physical entropy sources, and a private hardware module is employed to perform post-processing and nonlinear transformation of the synchronized signal. The simulation results show that the effective bandwidth of the output chaotic signal is significantly increased to 27.76 GHz, and high-quality synchronization with a correlation coefficient of over 0.98 is reached. A high-rate CRBG of up to 5.3 Gb/s is successfully achieved between two synchronized wideband physical entropy sources, and the hardware key space is enhanced to ∼2${}^{42}$, which greatly improves the privacy of physical entropy sources. The proposed scheme provides a promising approach for high-speed private CRBG, which is expected to be used in high-speed secure key distribution and optical communication systems. Full article

We report an electro-absorption modulator integrated with a distributed feedback Bragg laser fabricated by butt-joint technology. The lasing wavelength of the EML laser was 1311.71 nm, the output power was 10.04 mW when the current of the DFB section was 100 mA, the side-mode suppression ratio was greater than 50 dB, and the small-signal bandwidth was 29.40 GHz when the bias voltage of the modulator was −2 V. A 50 Gb/s data transmission over a single-mode fiber of up to 10 km was realized, which could be used as a light source for 50 G passive optical network systems. Full article
