To improve the dynamic response, linearity, and control accuracy of the YYSCT-250-3 tractor multi-circuit hydraulic output power tester, this study develops a particle swarm optimization (PSO)-tuned fuzzy-proportional–integral–derivative (Fuzzy-PID) control strategy. By modulating the actuator-driven ball valve’s rotation angle (0–90°) in the proportional flow valve, the controller uses both the flow rate error and its rate of change between the setpoint and the flow meter feedback as fuzzy inputs to adjust the PID outputs. A detailed mathematical model of the electro-hydraulic proportional flow system is established, incorporating hydraulic resistance torque on the ball valve spool and friction coefficients to enhance accuracy. Through MATLAB/Simulink (R2022a) simulations, the PSO algorithm optimizes the fuzzy membership functions and PID gains, yielding faster response, reduced overshoot, and minimal steady-state error. The optimized controller achieved relative steady-state flow errors within ±1.0% and absolute flow control errors within ±0.5 L/min, significantly outperforming the traditional PID controller. These results demonstrate that the PSO-optimized Fuzzy-PID approach effectively addresses the flow control challenges of the YYSCT-250-3, enhancing both testing efficiency and precision. This work provides a robust theoretical framework and practical reference for rapid, high-precision flow control in multi-channel hydraulic power testing. Full article

The independent metering control system is renowned for its ability to independently regulate the flow and pressure of various actuators, achieving high efficiency and energy savings in hydraulic systems. The high-speed digital valve is known for its fast response to control signals and precise fluid control. However, challenges such as jitter in the position control of hydraulic cylinders, unknown dead zone nonlinearity, and time variance in electro-hydraulic proportional systems necessitate further investigation. To address these issues, this study initially establishes an independent metering control system with digital valves. Based on the state space equation and Lyapunov stability judgment conditions, a high-order sliding mode controller is designed. In addition, a radial basis function (RBF) neural network is constructed to approximate uncertainties arising from the modeling process, the accuracy error indicator uses Mean Absolute Error (MAE), and a finite time generalized extended state observer (GESO) is introduced to conduct online disturbance observation for the external disturbances present within the control system. Consequently, a variable structure high-order sliding mode control strategy, augmented by RBF neural networks and finite time generalized extended state observer (RBF-GESO-SMC), is proposed. Finally, simulations and experimental verification are performed, followed by a comprehensive analysis of the experimental results. Compared with the sliding mode control (SMC), the RBF-GESO-SMC diminishes the displacement-tracking control accuracy error by 63.7%. Compared with traditional Proportional-Integral-Derivative (PID) control, it reduces the displacement-tracking control accuracy error by 78.1%. The results indicate that, through the comparison with SMC and PID control, RBF-GESO-SMC exerts significant influence on the improvement of position accuracy, anti-interference ability, transient response performance, and stability. Full article

The article is devoted to designing novel multivariable robust μ-control of an open-circuit axial piston pump. In contrast with classical solutions of displacement volume control, in our case, the hydro-mechanical controller (by pressure, flow rate, or power) is replaced by an electro-hydraulic proportional valve which receives a control signal from an industrial microcontroller. The valve is used as the actuator of the pump swash plate. The pump swash plate swivel angle determines the displacement volume and the flow rate of the pump. The μ-controller design is performed on the basis of a one-input, two-output model with multiplicative output uncertainty. This model is estimated and validated from experimental data at various loads by multivariable identification. The designed control system achieves robust stability and robust performance for the wide working mode of an axial piston pump. To conduct this experimental study, the authors have developed a laboratory test bench, enabling a real-time function of the control system via USB/CAN communication. The designed controller is implemented in a rapid prototyping system, and real-time experiments are performed. They show the advantages of μ-control and confirm the possibility of its implementation in the case of the real-time control of an axial piston pump. Full article

Autonomous tractors are emerging as a pivotal technology in agricultural automation. Precise steering control in these tractors requires high-performance electrohydraulic proportional valves (EHPVs). To optimize EHPV performance and reduce development costs and time, simulation analysis serves as a valuable pre-testing tool. This study aimed to develop a simulation model capable of predicting the hydraulic characteristics of EHPVs under real-world operating conditions. The model was created using AMESim, incorporating actual tractor operating conditions and valve control signals. The proposed model was validated through experiments conducted on a tractor equipped with an EHPV, evaluating hydraulic characteristics across various engine speeds and steering angular velocities. The simulation model was utilized to analyze the priority valve control flow characteristics of the automatic steering system and the hydraulic response of the EHPV under step inputs at specific engine speed points. The results indicate that the simulation model demonstrated a mean absolute percentage error (MAPE) ranging from 7.45% to 9.79% for hydraulic power. A t-test analysis of hydraulic power indicated no statistically significant difference between the simulation and experimental values under all test conditions. The proposed EHPV simulation model can be utilized for the optimal future design of EHPV systems. Full article

Considering the complexity and difficulty of obtaining certain parameters in the electro-hydraulic proportional control system, a precise transfer function of the system was derived through parameter identification using experimental data obtained from an Amesim simulation model after establishing a basic mathematical model. This approach reduces the reliance on accurate parameters of individual components. A feedforward-feedback composite controller was designed, and its effectiveness was validated in Simulink using the system’s transfer function. Subsequently, the dead zone range of the proportional valve was determined through experiments, and a dead zone compensation strategy was designed, which reduced the time required for the proportional valve to traverse the dead zone by 89.4%. Based on the dead zone compensation, trajectory tracking experiments were conducted to validate the effectiveness of the feedforward-feedback composite controller. Under fixed disturbances, the trajectory tracking error was reduced by 53.8% compared to feedback control. Under time-varying load disturbances, the trajectory tracking error was reduced by 51.2% compared to feedback control. Full article

This article presents the methodology and process of the modeling, designing, and testing of a research station enabling the identification, tuning, and verification of Digital Twin (DT) in control systems in power hydraulics. The concept of the station is presented, the main part of which is a subsystem forcing a dynamic, variable load using a hydraulic actuator controlled by a proportional valve, together with data acquisition and processing systems and software. The load application subsystem can subject the tested power hydraulic system, usually consisting of an actuator with its own control system, to controlled dynamic loads, which allows for the determination of its characteristics and tuning of the DT. This article describes the electro-hydraulic elements used to adjust the position of the actuators and the designed hydraulic and electrical diagrams of the station. The process of identifying, modeling, and selecting a controller for a subsystem simulating an external load is presented. The test station is built and tested. The identification, modeling, and tuning of DTs, for example, actuators and controllers, are described. A satisfactory convergence of the simulation and modeling results with the operation of the real system is achieved, which allows the obtaining of a reliable DT for actuator control systems operating under variable load. Full article

This article is devoted to a comparison of two advanced control techniques applied to the same plant. The plant is a certain type of axial-piston pump. A linear-quadratic (LQR) controller and an H-infinity (H_∞) controller were synthesized to regulate the displacement volume of the pump. The classical solution to such a problem is to use a hydro-mechanical controller (by pressure, flow rate, or power) but, in the available sources, there are solutions that implement proportional-integral-derivative (PID), LQR, model predictive control (MPC), etc. Unlike a classical solution, in our case, the hydro-mechanical controller is replaced by an electro-hydraulic proportional valve, which receives a reference signal from an industrial microcontroller. It is used as the actuator of the pump swash plate. The pump swash plate swivel angle determines the displacement volume, respectively, and the flow rate of the pump. The microcontroller is capable of embedding various control algorithms with different structures and complexities. The developed LQR and H_∞ controllers are compared in the simulation and real experiment conditions. For this purpose, the authors have developed a laboratory experimental test bench, enabling a real-time function of the control system via USB/CAN communication. Both controllers are compared under different pump loading modes. Also, this paper contributes an uncertain model of an axial-piston pump with proportional valve control that is obtained from experimental data. Based on this model, the robust stability of the closed-loop system is investigated by comparing the structured singular value (μ). The investigations show that both control systems achieved robust stability. Moreover, they can tolerate up to four times larger uncertainties than modeled ones. The system with the H_∞ controller attenuates approximately at least 30 times the disturbances with frequency up to 1 rad/s while the system with the LQR controller attenuates at least 10 times the same disturbances. Full article

Digital twins are an emerging technology that can be harnessed for the digitalization of the industry. Steel industry systems contain a large number of electro-hydraulic components as proportional valves. An input–output model for a water proportional cartridge valve was derived from physical modeling based on fluid mechanics, dynamics, and electrical principles. The valve is a two-stage valve with two two/two-way water proportional valves as the pilot stage and a marginally stable poppet-type cartridge valve as the main valve. To our knowledge, this is the first time that an input–output model was derived for a two-stage proportional cartridge valve with a marginally stable main valve. The orifice equation, which is based on Bernoulli principles, was approximated by a polynomial, which made the parameter estimation easier and modeling possible without measuring the pressure of the varying control volume, in contrast with previous studies of similar types of valves situated in the pilot stage part of the valve. This work complements previous studies of similar types of valves in two ways: (1) data were collected when the valve was operating in a closed loop and (2) data were collected when the valve was part of a press mill machine in a steel manufacturing plant. Model parameters were identified from data from these operating conditions. The parameters of the input–output model were estimated by convex optimization with physical constraints to overcome the problems caused by poor system excitation. For comparison, a simple linear model was derived and the least squares method was used for the parameter estimation. A thorough estimation of the parameters’ relative errors is presented. The model contains five parameters related to the design parameters of the valve. The modeled position output was in good agreement with experimental data for the training and test data. The model can be used for the real-time monitoring of the valve’s status by the model parameters. One of the model parameters varied linearly with the production cycles. Thus, the aging of the valve can be monitored. Full article

At present, the hydraulic support pushing system in coal mines usually uses an electrohydraulic directional valve as the control component. However, the existing control methods based on high-speed on–off valve, servo, and proportional control methods are not suitable for solving such problems because of the nonideal characteristics of the electrohydraulic directional valve, such as discrete input values, low switching frequency, and time delay. This paper proposes a positioning control scheme based on online predictive feedback for the control of hydraulic cylinders by electrohydraulic directional valves. In this scheme, the recursive least-squares estimation algorithm with genetic factors is used to identify the required prediction model in real time, and an improved radial basis function network based on generalized growth and shear is used to realize the online fitting of the target trajectory function. The online learning algorithm provides accurate prediction information for the switching control method, and finally, the hydraulic cylinder can be positioned near the target position using the optimal control method. By using the above methods, a well-designed model can be accurately identified, fundamentally solving the problem of control difficulties caused by the nonideal characteristics of the electrohydraulic directional valve. Finally, the effectiveness of the control scheme is verified through simulation analysis and physical experiment research, which proves that the control strategy can realize accurate and fast positioning control for the hydraulic support pushing system of a fully mechanized mining face. Full article

The high-speed and high-accuracy current control circuit is a key component for the high-performance electro-hydraulic proportional valve. In this paper, a new capacitive reservoir-based PWM digital circuit (CRPDC) is designed, modeled, and analyzed. The proposed CRPDC employs a capacitive reservoir circuit to acquire electricity from the DC power supply while the PWM control signal is at a high level and the supply current for the proportional valve coil while the PWM control signal is at a low level, which will result in a small ripple and fast response of the coil current. For the proposed CRPDC, the charging and discharging mathematical models are specially established to reveal the response characteristics of the proportional-valve coil current. The coil current control performance of the proposed CRPDC is simulated by the mathematical models and the Multisim models. Simulation results demonstrate that the designed CRPDC can energize the coil current in a high-accuracy and fast-speed manner. In summary, the designed CRPDC has wide application in the current control of the proportional valve coil. Full article

In this paper, a new solution for an electro-hydraulic servo drive is proposed, which consists of two electro-hydraulic servo drives: one with a hydraulic cylinder and one with a hydraulic rotary motor. In the proposed drive, the linear actuator is attached to a horizontal base and the hydraulic motor is mounted on the actuator piston rod. Thus, the output signal of the drive is the lifting and lowering of the element suspended on the rope. The paper describes the structure, kinematics, dynamics, and control of a novel electro-hydraulic servo drive. A servo valve and a proportional valve are used to control the flow of the hydraulic cylinder and the hydraulic motor. Special attention is paid to the construction of two actuators in one drive unit. The controller is based on the PLC controller. The measuring system uses laser displacement sensors and an encoder. The results of laboratory investigations are discussed in the paper. The proposed drive contains all of the characteristics of a mechatronic device. The main contribution of this study is the proposal of the controller architecture and the algorithm to control the speed and position when lifting or lowering loads. Full article

At present, the positioning control of the hydraulic support pushing systems in fully mechanized mining faces uses an electrohydraulic directional valve as the control component, while the current research mainly focuses on servo valves, proportional valves, high−speed on−off valves, and electromagnetic directional valves. At present, the positioning control for electrohydraulic directional valves is only a simple logical control. Therefore, in order to improve the positioning control accuracy of the hydraulic support pushing system, a predictive positioning control strategy based on iterative learning was designed. Firstly, mathematical modeling of the hydraulic support pulling process was carried out, and its state−space equation was established. Secondly, an iterative learning controller with a state observer was designed, in which the iterative learning method was used to predict the control advance in the positioning process, and the state observer was used to estimate the parameters that could not be measured by the system, so as to improve the control accuracy in the broaching process. Then, a SimulationX–Simulink joint simulation model of the position control system of a multi−cylinder pulling hydraulic support was built, and the designed iterative learning controller was compared with the BP neural network controller. Finally, a test platform for the hydraulic support pushing system was built, and the proposed control strategy was experimentally verified. The research results show that the iterative learning control strategy proposed for the electrohydraulic directional valve not only simplifies the design process of the controller but also has higher positioning control accuracy. The single−cylinder positioning control accuracy can be controlled within 10 mm, and the multi−cylinder coordinated positioning control accuracy can be controlled within 15 mm, which meets the accuracy requirements of the site. Full article

This paper presents the design and experimental validation of a novel human–machine redundant braking system (HMRBS) for aftermarket low-speed electric vehicles (LSEVs) to realise the backup redundancy ability and improve active safety. First, the HMRBS is designed by connecting the electro-hydraulic braking (EHB) unit oil pipelines in parallel with the manual braking (MB) unit through two three-way shuttle valves. Then, the mathematical model of the EHB subsystem is built, and a master cylinder pressure controller with adaptive fuzzy proportion integration differentiation (PID) and a servo motor speed controller with double-closed-loop proportion integration (PI) are proposed to improve the system response performance. Following this, the co-simulation model of the proposed closed-loop system is established based on AMESim and MATLAB/Simulink to validate the feasibility of the proposed control strategy. Finally, the effectiveness of the HMRBS is also validated by test rig and vehicle experiments. The results imply that the modified LSEV with the HMRBS meets the requirements of vehicle active braking ability and manual braking redundancy. Furthermore, the proposed controller can significantly enhance pressure control accuracy compared to the classical PID controller. The deceleration fluctuation and braking distance in the active braking mode are smaller than those in the manual braking mode, indicating that the proposed system makes the braking effect more stable and safer. Full article

The performance of the electrohydraulic proportional control valve (EHPV) employed in a tractor’s automatic steering system directly influences the steering performance. To develop a highly reliable EHPV, it is essential to analyze the hydraulic characteristics of the EHPV for several working conditions of tractors. This study aimed to measure and analyze the hydraulic characteristics of the EHPV according to tractor working conditions. The flow rate and pressure data of the EHPV were computed through the valve measuring system, and the required power was computed. The experimental conditions were selected based on engine rotational speed and tractor steering angle. As a result, it was discovered that the flow rate, pressure, and power all increased when the engine rotation speed and steering angle conditions increased. Furthermore, the rates of increase in flow rate, pressure, and power based on the increase in the steering angle were higher than when the engine rotation speed increased. In the regression analysis results between the two variables and the hydraulic characteristics of EHPVs, the steering angle demonstrated a higher correlation than the engine rotation speed. In conclusion, the steering angle and engine rotational speed are the major variables in the hydraulic characteristics of EHPVs, and the influence of the steering angle is greater. Full article

The EHA (electro hydraulic actuator) has a notable advantage over conventional hydraulic actuators as it uses a closed-loop circuit, reducing the size and volume of oil, and eliminates pressure losses caused by valve orifices. However, accurate control performance of EHA is difficult to achieve using a traditional PID (proportional integral derivative) controller due to the strongly nonlinear, time-varying, and unknown dynamics of the system. Hence this paper seeks to address this problem by proposing a design of an intelligent controller for the EHA. The proposed adaptive fuzzy sliding mode controller (AFSMC) is developed as a hybrid of the adaptive, fuzzy logic, and sliding mode algorithms. To reduce costs and time, a virtual prototype approach is also proposed instead of experimentations to evaluate the performance of the proposed controller. The virtual model of the EHA is built in Amesime software, and then embedded into Matlab/Simulink where the AFSMC is developed and tested to obtain the position responses of the EHA. The results show that the AFSMC is highly successful and more efficient than the traditional PID at controlling the position of the piston accurately. Full article
