Search Results (77)

Electric wheelchairs significantly enhance mobility for individuals with disabilities, but navigating confined or crowded spaces remains a challenge. This paper presents a mechatronic anticollision system based on Time-of-Flight (ToF) sensors designed to improve wheelchair navigation in such environments. The system performs eight-plane 3D environmental scans in 214–358 ms, with a vertical field of view of 12.4° and a detection range of up to 4 m—sufficient for effective obstacle avoidance. Unlike existing solutions like the YDLIDAR T-mini Plus, which has a narrow vertical field of view and a longer detection range that may be excessive for indoor spaces, or the xLIDAR, which struggles with shorter detection ranges, our system balances an optimal detection range and vertical scanning area, making it especially suitable for wheelchair users. Preliminary tests confirm that our system achieves high accuracy, with a standard deviation as low as 0.003 m and a maximum deviation below 0.05 m at a 3-m range on high-reflectivity surfaces (e.g., white and light brown). Our solution offers low power consumption (140 mA) and USB communication, making it an energy-efficient and easy-to-integrate solution for electric wheelchairs. Future work will focus on enhancing angular precision and robustness for dynamic, real-world environments. Full article

This study evaluates the safety aspects of a prototype electric vehicle designed to enable wheelchair users to independently perform simple farm tasks in rural settings, like sample collection and crop monitoring. The vehicle, built at CREA, features four in-wheel electric motors, a pneumatic suspension system, and a secure wheelchair anchoring system. Tests at the CREA experimental farm assessed the vehicle’s whole-body vibrations on different surfaces (asphalt, headland, dirt road) using two tyre models and multiple speeds. A triaxial accelerometer on the wheelchair seat measured vibrations, which were analysed in accordance with ISO standards. Frequency analysis revealed significant vibrations in the 2–40 Hz range, with the Z-axis consistently showing the highest accelerations, which increased with the speed. Tyre A generally induced higher vibrations than Tyre B, likely due to the tread design. At high speeds, the effective accelerations exceeded safety thresholds on asphalt and headland. Statistical analysis confirmed speed as the dominant factor, with the surface type also playing a key role—headland generated the highest vibrations, followed by dirt road and asphalt. The results of these first tests highlighted the high potential of the vehicle to improve the agricultural mobility of disabled people, granting safety conditions and low vibration levels on all terrains at speeds up to 10 km h⁻¹. At higher speeds, however, the vibration levels may exceed the exposure limits, depending on the irregularities of the terrain and the tyre model. Overcoming these limitations is achievable through the optimization of the suspensions and tyres and will be the subject of the next step of this study. This technology could also support wheelchair users in construction, natural parks, and urban mobility. Full article

With the aging population and rising demand for assistive devices, electric wheelchairs have garnered significant attention. However, existing stair-climbing wheelchairs often suffer from complex structural complexity and limited flexibility. Spoke-wheel mechanisms, known for their simple structure and strong obstacle-crossing capabilities, hold promise but experience oscillation on flat terrain. This paper proposes an improved spoke-wheel mechanism (Flexwheel), which integrates springs into the spokes. These springs compress to varying lengths under gravitational force during ground contact, while sliding grooves and pre-compression constraints regulate spoke length, ensuring a stable height. A novel selection method for the optimal spring constant is developed based on mass, spoke length, and the number of spokes. This mathematical framework is applicable to stable, smooth ground motion under varying friction conditions between the upper and lower spokes. A wheelchair prototype equipped with four Flexwheels, a self-balancing mechanism, and multi-sensor fusion technology is designed. The simulation results indicate that Flexwheel reduces the range in body height from 10.75 mm (traditional spoke wheels) to 3.39 mm on flat terrain, a 68.47% improvement. During stair climbing, Flexwheel significantly reduces body oscillation compared to traditional spoke or circular wheels. Physical experiments validate that Flexwheel exhibits a 6.28 mm height fluctuation vs. traditional spokes wheels’ 12.13 mm, a 48.28% improvement, demonstrating its effectiveness in enhancing wheelchair stability and adaptability. Full article

Electric wheelchairs are the primary means of transportation that enable individuals with disabilities to move independently to their desired locations. This paper introduces a novel, low-cost smart wheelchair system designed to enhance the mobility of individuals with severe disabilities through hand gesture recognition. Additionally, the system aims to support low-income individuals who previously lacked access to smart wheelchairs. Unlike existing methods that rely on expensive hardware or complex systems, the proposed system utilizes an affordable webcam and an Nvidia Jetson Nano embedded computer to process and recognize six distinct hand gestures—“Forward 1”, “Forward 2”, “Backward”, “Left”, “Right”, and “Stop”—to assist with wheelchair navigation. The system employs the “You Only Look Once version 8n” (YOLOv8n) model, which is well suited for low-spec embedded computers, trained on a self-collected hand gesture dataset containing 12,000 images. The pre-processing phase utilizes the MediaPipe library to generate landmark hand images, remove the background, and then extract the region of interest (ROI) of the hand gestures, significantly improving gesture recognition accuracy compared to previous methods that relied solely on hand images. Experimental results demonstrate impressive performance, achieving 99.3% gesture recognition accuracy and 93.8% overall movement accuracy in diverse indoor and outdoor environments. Furthermore, this paper presents a control circuit system that can be easily installed on any existing electric wheelchair. This approach offers a cost-effective, real-time solution that enhances the autonomy of individuals with severe disabilities in daily activities, laying the foundation for the development of affordable smart wheelchairs. Full article

Accidents involving electric wheelchairs are a growing concern, with users frequently encountering obstacles that lead to collisions, tipping, or loss of balance. These incidents underscore the need for advanced safety technologies tailored to electric wheelchair users. This research addresses this need by developing a driving assistance system to prevent accidents and enhance user safety. The system incorporates ultrasonic sensors and a front-facing camera to detect obstacles and provide real-time warnings. The proposed system operates independently of stable server communication and employs embedded hardware for fast object detection and environmental recognition, ensuring immediate guidance in various scenarios. In this research, we utilized the existing yolov8 model as is. But we attempted to improve performance by hardware acceleration of convolutional neural networks, supporting various layers such as convolution, deconvolution, pooling, batch normalization, and others. Thus, the YOLO model was accelerated during inference on the specialized hardware in our experiments. Performance was evaluated in diverse environments to assess its usability. Results demonstrated high accuracy in detecting obstacles and providing timely warnings. Leveraging hardware acceleration for YOLOv8 delivers faster, scalable, and robust object detection, making it a great platform for enhancing driving safety on edge and embedded devices. These findings provide a strong foundation for future advancements in safety assistance systems for electric wheelchairs and other mobility devices. Future research will focus on enhancing system performance and integrating additional features to create a safer environment for electric wheelchair users. Full article

Self-propelled manual wheelchairs offer several advantages over electric wheelchairs, including promoting physical activity and requiring less maintenance due to their simple design. While theoretical analyses provide valuable insights, laboratory testing remains the most reliable method for evaluating and improving the efficiency of manual wheelchair drives. This article reviews and analyzes the laboratory methods for assessing the efficiency of wheelchair propulsion documented in the scientific literature: (1) A wheelchair dynamometer that replicates real-world driving scenarios, quantifies the wheelchair’s motion characteristics, and evaluates the physical exertion required for propulsion. (2) Simultaneous measurements of body position, motion, and upper limb EMG data to analyze biomechanics. (3) A method for determining the wheelchair’s trajectory based on data from the dynamometer. (4) Measurements of the dynamic center of mass (COM) of the human–wheelchair system to assess stability and efficiency; and (5) data analysis techniques for parameterizing large datasets and determining the COM. The key takeaways include the following: (1) manual wheelchairs offer benefits over electric ones but require customization to suit individual user biomechanics; (2) the necessity of laboratory-based ergometer testing for optimizing propulsion efficiency and safety; (3) the feasibility of replicating real-world driving scenarios in laboratory settings; and (4) the importance of efficient data analysis techniques for interpreting biomechanical studies. Full article

This review reports on the use of sensors in wheelchair sports to monitor and analyze performance during match and training time. With rapid advancements in electronics and related technologies, understanding performance metrics in wheelchair sports is essential. We reviewed nine studies using various sensor types, including electric motors, inertial measurement units, miniaturized data loggers with magnetic reed switches, and smartphones with inbuilt accelerometers and gyroscopes, operating at frequencies from 8 Hz to 1200 Hz. These studies measured parameters such as angular and translational velocities, distance, number of starts/pushes, and other performance indicators in sports such as basketball, rugby, tennis, and racing. Despite differences in sport types and methodologies, most studies found sensor-derived data effective for assessment of performance. Future developments and research in this field should focus on multi-sensor systems that could provide real-time match analysis and deeper insights into performance metrics. Overall, sensor technologies show significant potential for improving wheelchair sport performance diagnostics, contributing to better athlete training and future wheelchair design, and enhancing competitive outcomes. This review emphasizes the need for continued innovation and standardization in applying sensor technologies in wheelchair sports. Full article

Electrical burn injuries to the scalp are at risk of extensive tissue damage and neurological complications. We present the case of a patient who came into contact with a high-voltage power line while cherry picking, resulting in a large full-thickness scalp defect. Early on in his presentation, he developed progressive global weakness which remained relatively static during his admission. An incidental finding of an extradural abscess complicated his management, requiring urgent surgical intervention with definitive tissue coverage. The scalp was reconstructed using a free myocutaneous anterolateral thigh flap. There were no postoperative complications. Following rehabilitation, the patient was discharged home with limited functional recovery. He mobilises independently with a wheelchair and requires full-time carers. Full article

In Japan, the number of power wheelchair users is increasing as the country becomes an aging society. This trend is expected to continue in the future. Electric wheelchairs currently on the market include (1) bar-handle-type power wheelchairs for older users and (2) joystick-type power wheelchairs that change direction by operating a joystick. When such electric wheelchairs are used outdoors, the problem is curb-climbing at the boundary between the roadway and the sidewalk. It would be difficult for a wheelchair with a small front wheel diameter of 200 mm to overcome a curb height of 50 mm. Therefore, users are forced to take a detour or drive on the street to avoid the curb step. One of the most effective ways to solve this problem is to increase the wheel diameter. However, larger wheels make it more difficult for users to get in and out of the wheelchair. In addition, there are problems such as an increased footprint when turning, which makes the wheelchairs difficult to use on narrow streets. In this paper, using a joystick-type six-wheel electric wheelchair as an example, we examined the mechanism by which an electric wheelchair can overcome curb climbing and consider improvements to the chassis with a method that does not rely on increasing the wheel diameter. As a result, it became possible to overcome a curb of 96 mm in height with a front-wheel diameter of 200 mm. Full article

We propose a hands-free control system for a human-guided smart stroller. The proposed method uses real-time peer-to-peer localization technology of the human and stroller to realize an intuitive hands-free control system based on the relative position between the human and the stroller. The control method is also based on functional and mechanical safety to ensure the safety of the stroller’s occupant (child) and the pilot (parent) during locomotion. In this paper, first, we present a preliminary investigation of the humans’ preference for the relative position in the context of hands-free guided strollers. Then, we present the control method and a prototype implemented with an electric wheelchair and UWB sensors for localization. We present an experimental evaluation of the proposed method with 14 persons walking with the developed prototype to investigate the usability and soundness of the proposed method compared to a remote joystick and manual operation. The evaluation experiments were conducted in an indoor environment and revealed that the proposed method matches the performance of joystick control but does not perform as well as manual operation. Notably, for female participants, the proposed method significantly surpasses joystick performance and achieves parity with manual operation, which shows its efficacy and potential for a smart stroller. Also, the results revealed that the proposed method significantly decreased the user’s physical load compared to the manual operation. We present discussions on the controllability, usability, task load, and safety features of the proposed method, and conclude this work with a summary assessment. Full article

A system has been developed to convert manual wheelchairs into electric wheelchairs, providing assistance to users through the implemented algorithm, which ensures safe driving and obstacle avoidance. While manual wheelchairs are typically controlled indoors based on user preferences, they do not guarantee safe driving in areas outside the user’s field of vision. The proposed model utilizes the dynamic window approach specifically designed for wheelchair use, allowing for obstacle avoidance. This method evaluates potential movements within a defined velocity space to calculate the optimal path, providing seamless and safe driving assistance in real time. This innovative approach enhances user assistance and safety by integrating state-of-the-art algorithms developed using the dynamic window approach alongside advanced sensor technology. With the assistance of LiDAR sensors, the system perceives the wheelchair’s surroundings, generating real-time speed values within the algorithm framework to ensure secure driving. The model’s ability to adapt to indoor environments and its robust performance in real-world scenarios underscore its potential for widespread application. This study has undergone various tests, conclusively proving that the system aids users in avoidance obstacles and ensures safe driving. These tests demonstrate significant improvements in maneuverability and user safety, highlighting a noteworthy advancement in assistive technology for individuals with limited mobility. Full article

To examine the biomechanical demands of manual wheelchair propulsion, it is crucial to determine the wheelchair user’s (WCU) force for propulsion technique parameter calculation. When using a pushrim-activated power-assisted wheelchair (PAPAW) on a wheelchair ergometer, a combined propulsion force from the WCU and PAPAW is exerted. To understand PAPAW’s assistance and distinguish the WCU’s force application from the force exerted by the PAPAW, both propulsion components must be assessed separately. In this study, a calibration of the PAPAW on an ergometer was developed to achieve this separation. The calibration consists of five steps: (I) Collecting data on force and velocity measured from the ergometer, along with electrical current and velocity from the PAPAW. (II) Synchronizing the velocity signals of the wheelchair ergometer and PAPAW using cross-correlation. (III) Calibrating the PAPAW’s electromotors to convert electrical current (mA) to force (N). A product-specific motor constant of 0.30, provided an average ICC of 0.563, indicating a moderate agreement between the raw ergometer data (N) and the motor constant-converted drive-rim (PAPAW) data (from mA to N). (IV) Subtracting the PAPAW’s force signal from the ergometer’s measured force to isolate forces generated by the WCU. (V) Using markerless motion capture to determine and validate the phase of hand contact with the handrim. This technical note provides an example of PAPAW calibration for researchers and clinicians. It emphasizes the importance of integrating this calibration into the development of PAPAW devices to reveal the complex interaction between PAPAW and WCU during wheelchair propulsion. Full article

Even though Electric Powered Wheelchairs (EPWs) are a useful tool for meeting the needs of people with disabilities, some disabled people find it difficult to use regular EPWs that are joystick-controlled. Smart wheelchairs that use Brain–Computer Interface (BCI) technology present an efficient solution to this problem. This article presents a cutting-edge intelligent control wheelchair that is intended to improve user involvement and security. The suggested method combines facial expression analysis via a camera with EEG signal processing using the EMOTIV Insight EEG dataset. The system generates control commands by identifying specific EEG patterns linked to facial expressions such as eye blinking, winking left and right, and smiling. Simultaneously, the system uses computer vision algorithms and inertial measurements to analyze gaze direction in order to establish the user’s intended steering. The outcomes of the experiments prove that the proposed system is reliable and efficient in meeting the various requirements of people, presenting a positive development in the field of smart wheelchair technology. Full article

This paper delineates the design and realization of a Wheelchair-Mounted Robotic Arm (WMRA), envisioned as an autonomous assistance apparatus for individuals encountering motor difficulties and/or upper limb paralysis. The proposed design solution is based on employing a 3D printing process coupled with optimization design techniques to achieve a cost-oriented and user-friendly solution. The proposed design is based on utilizing commercial Arduino control hardware. The proposed device has been named Pick&Eat. The proposed device embodies reliability, functionality, and cost-effectiveness, and features a modular structure housing a 4-degrees-of-freedom robotic arm with a fixing frame that can be attached to commercial wheelchairs. The arm is integrated with an interchangeable end-effector facilitating the use of various tools such as spoons or forks tailored to different food types. Electrical and sensor components were meticulously designed, incorporating sensors to ensure user safety throughout operations. Smooth and secure operations are achieved through a sequential procedure that is depicted in a specific flowchart. Experimental tests have been carried out to demonstrate the engineering feasibility and effectiveness of the proposed design solution as an innovative assistive solution for individuals grappling with upper limb impairment. Its capacity to aid patients during the eating process holds promise for enhancing their quality of life, particularly among the elderly and those with disabilities. Full article

Wheelchairs are widely used globally and are essential for providing autonomy and mobility to elderly and disabled people who have movement restrictions. Manual wheelchairs require operation through turning the wheels or pushing the wheelchair directly, thus posing mobility limitations for the user and caregiver. In contrast, electric wheelchairs, when used by the user, allow for improved flexibility by operating the wheelchair through a single control mechanism. However, the use of electric wheelchairs poses challenges in accessing areas with stairs and curbs, limiting the range of activity and thereby diminishing the quality of life for users and those reliant on electric wheelchairs. The electric wheelchair developed in this research incorporates a single motor for lightweight design. It uses a wheel travel variation actuator, eliminating the need for synchronization and allowing for low-power operation. This design reduces power loss from the caterpillar’s idling during wheel movement and includes the implementation of a pulley system. The optimal pulley belt length was calculated, and a deceleration device was installed inside the caterpillar, enabling a design that is compact, lightweight, and capable of high deceleration. On paved roads and flat terrain, the electric wheelchair is designed for high-speed travel using two pairs of front omni wheels and drive wheels. For terrains with stairs, speed bumps, unpaved roads, and unavoidable obstacles, the wheelchair is powered by caterpillars. The electric wheelchair developed through the research presented in this paper has verified the reliability of its transmission system through gear stress and deformation analysis. Additionally, an electric wheelchair based on the proposed concept was constructed to validate the drivability, safety, operability, and convenience of its driving unit. Furthermore, a user rode the constructed electric wheelchair to confirm that there were no issues with its drivability. Full article
