Search Results (105)

This paper presents an experimental investigation of a low-temperature ejector-based air-conditioning system designed to utilize waste heat from Combined Heat and Power (CHP) plants. The system operates with isobutane (R600a) as the working fluid and is driven by low-grade heat sources in the temperature range of 80–120 °C. A prototype experimental rig was developed to evaluate the influence of key operating parameters, including motive steam pressure and evaporator temperature, on the system’s Coefficient of Performance (COP) and entrainment ratio. The results demonstrate that the system can maintain stable operation even at ultra-low heat source temperatures, achieving a maximum COP of 0.35 under optimal conditions. The findings confirm the feasibility of using R600a in ejector-based systems for sustainable cooling applications. Furthermore, the study highlights the potential for integrating such systems into existing district heating networks to enhance overall energy efficiency. Overall, the presented results provide valuable experimental data supporting the development of sustainable, thermally driven cooling technologies that reduce reliance on grid electricity and high-GWP refrigerants. Full article

Variable geometry ejectors (VGEs) offer passive, compact, and energy-efficient solutions for fluid transport and thermal management in applications such as refrigeration, hydrogen fuel cells, and solar-driven desalination. By adjusting internal geometries, VGEs maintain high performance under off-design and transient conditions, overcoming limitations of fixed-geometry ejectors. This systematic review synthesizes experimental, numerical, and hybrid research on VGEs published between 30 June 1995 and 1 July 2025. Peer-reviewed journal and conference papers were identified through structured searches of Scopus, Web of Science, and Google Scholar, followed by PRISMA-guided screening. Forty-eight studies were qualitatively synthesized with respect to modulation mechanisms, actuation and control strategies, working fluids, modeling approaches, validation practices, performance metrics, and Technology Readiness Levels (TRLs). Risk of bias was assessed using the Mixed Methods Appraisal Tool (MMAT), complemented by an engineering-specific extension for experimental and numerical studies. Results indicate a strong reliance on numerical modeling, predominantly 2D axisymmetric CFD, with limited high-fidelity experimental validation. Adjustable nozzle throats dominate current designs, while multi-variable geometries and real-time closed-loop control remain underexplored. Most studies cluster at TRLs 2–4, with only two demonstrating full system-level integration. Overall, VGEs show strong potential for energy-efficient operation, but progress toward deployment requires integrated geometry–control co-design, standardized benchmarking, uncertainty-aware validation, and scalable experimental demonstration. This review was not registered. Full article

This study investigates the utilization of a sodium polyacrylate (SP)/CaCl₂ composite as an adsorbent in a low-grade-heat desalination configuration designed for Saudi Arabian conditions. A dynamic system model was developed and validated for an adsorption desalination (AD) cycle integrated with a dual-ejector and a humidification–dehumidification (HDH) unit. Two operating modes were evaluated, including a production-oriented configuration that applies internal evaporator–condenser heat recovery (HR) when no cooling effect is required. Without HR, the AD–EJ–HDH system achieves 41–56 m³/ton·day SDWP and 2.6–2.9 GOR, with a freshwater cost of 1.8–2.4 $/m³ under solar driving and 0.70–0.90 $/m³ under waste heat. With HR, performance increases to SDWP 95–155 m³/ton·day and GOR 2.9–3.1, while costs decrease to about 1.34 $/m³ (solar) and 0.38 $/m³ (waste heat) in June. The SP/CaCl₂ composite yields about 85% higher freshwater production than silica gel in the same system, highlighting the material’s potential for high-output hybrid adsorption desalination in hot-climate regions. Full article

Systematic investigation into the structural integrity of adjustable ejectors, particularly concerning thermal–fluid–structural (TFS) coupling, is currently lacking. Utilizing the Workbench platform, this study performs unidirectional steady-state TFS coupling numerical simulation of the adjustable air ejector under off-design conditions to systematically analyze its internal flow characteristics and structural mechanical responses across various needle openings. The results show that thermal load is the dominant factor governing the ejector’s structural stress and deformation. The overall deformation is primarily characterized by axial elongation, with the maximum thermal deformation localized at the ejector’s exit section. The nozzle exit is identified as the primary structural weak point, exhibiting the highest local stress, which peaks at 196.8 MPa when the needle opening is minimized. Shock train structures extending from the nozzle’s divergent section into the mixing chamber, coupled with the axial displacement of the needle, significantly influence the ejector’s thermal deformation and thermal stress. Based on the thermally dominated stress mechanism identified, this study proposes a composite nozzle design utilizing a nickel-plated Invar alloy substrate. This material fully leverages Invar alloy’s low thermal expansion to mitigate thermal stress and deformation while the nickel plating ensures corrosion resistance, thereby significantly enhancing the nozzle’s mechanical properties and operational reliability in thermal environments. The findings of this analysis are applicable to off-design evaluations under unidirectional steady-state coupling conditions, providing a valuable reference for the structural design and strength optimization of similar ejectors operating in high-temperature, unsteady environments. Full article

Blast furnace tuyeres are the primary dust emission source in ironmaking facilities (accounting for over 30% of total pollutants). High-temperature dust plumes with intense thermal energy are prone to dispersion, while China’s steel industry ultra-low emission standards (particulate matter ≤ 10 mg/m³) impose strict requirements on capture efficiency. Existing technologies often neglect crosswind interference and lack coordinated design between air volume regulation and hood structure, leading to excessive fugitive emissions and non-compliance. This study established a localized numerical model for high-temperature dust capture at blast furnace tuyeres, investigating air volume’s impact on velocity fields and capture efficiency, revealing crosswind interference mechanisms, and proposing optimization strategies (adding hood baffles, adjusting dimensions, installing ejector fans). Results show crosswind significantly reduces efficiency—only 78% at 1.5 m/s crosswind and 400,000 m³/h flow rate. The optimal configuration (2.5 m side flaps plus1.4 m baffles) achieves 99% efficiency, maintaining high performance at lower flow rates: 350,000 m³/h (1.5 m/s crosswind) and 250,000 m³/h (0.9 m/s crosswind). This study provides technical support for blast furnace tuyere dust control and facilitates ultra-low emission compliance in the steel industry. This study supports blast furnace tuyere dust control and aids the steel industry in meeting ultra-low emission standards. Notably, the proposed optimization scheme boasts simple structural adjustments, low retrofitting costs, and good compatibility with existing production lines, enabling direct industrial promotion and notable environmental and economic gains. Full article

As an energy-saving fluid machinery component, the ejector holds significant potential for promoting energy conservation and sustainable transformation in aerospace. This review synthesizes recent progress, identifies persistent challenges, and outlines future directions for ejector technology in this field, addressing a gap in existing reviews. (1) In aero-engine systems, performance faces constraints from high-speed compression effects and flow losses. These systems require optimized design across a wide range of speeds. A mixed configuration incorporating a blade mixer achieved a 5~7% thrust increase under static conditions. (2) In high-altitude test facilities, transient start-up and flow instability under off-design conditions demand more precise models and control strategies. An alternative solution using a second throat exhaust diffuser reduced the start-up time by 50~70%. (3) In rocket-based combined cycle engines, development is limited by thermal choking, mode transition, and combustion-flow coupling issues. Optimization of the rocket layout and geometric throat increased the bypass ratio in ejector mode by 35% and improved the specific impulse by 12.5%. Future efforts should focus on constructing multi-physics coupling numerical simulation models for ejectors, analyzing unsteady flow behavior and thermal effects within ejectors, and developing performance optimization strategies based on intelligent control. These approaches are expected to enhance the engineering applicability and system efficiency of ejector technology in the aerospace field, which is increasingly focused on energy conservation and sustainable transformation. Full article

This paper presents an experimental and computational investigation of novel, ejector-based, Coandă-surface-assisted tip leakage mitigation schemes. The predicted changes in the key performance metrics are presented after explaining the aerodynamic concept development for the novel tip geometries. The performance metrics are the stage total-to-total isentropic efficiency, tip-gap mass flow rate, and a figure of merit based on rotor exit total pressure. The schemes are based on direct geometric modifications to the turbine blade tip, effectively promoting an effective redirection of tip leakage fluid via specific channels. The proposed ejector channels operate in conjunction with strategically located Coandă surfaces to alter the path of the leakage fluid, promoting an effective leakage fluid delivery into the blade’s wake. Multiple schemes are assessed, including single-ejector, single-ejector with “hybrid” squealer, double-channeled, and triple-channeled designs. The designs are evaluated computationally for the HP stage of the Axial Flow Turbine Research Facility AFTRF at Penn State University. Extensive experimental validation of the baseline flow computations for the HP stage is also presented. Upper-bound efficiency gains of 0.49% and mass flow reductions of 14.80% compared to an untreated flat tip for the large-scale turbine test rig AFTRF are reported. Evaluation of the current tip designs in a high-speed turbine cascade environment with a transonic exit flow has also been completed. The detailed results from the high-speed investigation and heat transfer impact are in the process of being published. Implementation in the high-speed environment of the same design concepts also returned non-negligible performance gains. Full article

The ejector-based hydrogen recirculation systems in vehicular proton exchange membrane fuel cells (PEMFCs) have been the research focus of fuel cell technology. However, the anode pressure fluctuations and nonlinear characteristics urgently need to be addressed under the varying operating conditions of the ejector-based hydrogen recirculation system. In this paper, an Adaptive Model Predictive Control strategy is proposed to stabilize anode pressure and smooth pressure fluctuations during current changes and purges. An ejector is designed and a nonlinear control model is established for the ejector-based hydrogen recirculation system of the 110 kW PEMFC. The proposed strategy achieves the mean absolute error (MAE) of 0.044 kPa and the root mean square error of 1.041 kPa in anode pressure management, outperforming traditional Model Predictive Control and Proportional-Integral-Derivative strategies. The hydrogen excess ratio exceeding 1.5 ensures compliance with the operational requirements of system. The experimental results with the pressure MAE of 0.482 kPa and the current fluctuation of ±0.7 A validate the effectiveness of the proposed strategy in practical applications. Full article

A distillation system with an ejector for secondary steam utilization can effectively improve energy efficiency. However, the poor performance of the ejector under varying operating conditions makes it difficult for the distillation system to adapt to wide-range operational requirements. To address this challenge, a distillation system using a combined ejector with staged and continuous adjustment is proposed, and its performance and economic feasibility under wide load conditions is analyzed. The results show that when a combined ejector is used—composed of four fixed-structure ejectors with capacities of 6.25%, 12.5%, 25%, and 50%, along with a nozzle needle-adjustable ejector with a capacity range of 0–6.25%—the distillation system can combine the advantages of both staged and continuous adjustment. This system can utilize secondary steam across a load range of 2.53–100%, whereas a distillation system with a single continuously adjustable ejector can only utilize secondary steam within a load range of 40.5–100%. As the load varies from 0 to 100%, the proposed system achieves an average entrainment ratio of 0.525, with an efficiency not less than 50% of the design value over 95.23% of the range. In contrast, the conventional single continuously adjustable ejector has an average entrainment ratio of 0.177, and the distillation system efficiency remains above 50% of the design value for only 25.32% of the range. In a solar-assisted distillation system, the combined ejector improves the coefficient of performance (COP) by over 30%, with a payback period of less than one year. The findings highlight the system’s superior adaptability, efficiency, and economic viability for applications with unstable energy supply. Full article

Stable adhesion on non-magnetic, steep, and irregular underwater surfaces (e.g., concrete dams with cracks or biofilms) remains a challenge for inspection robots. This study develops a novel adsorption mechanism based on the synergistic operation of a Venturi-ejector and a composite suction cup. The mechanism utilizes the Venturi effect to generate stable negative pressure via hydrodynamic entrainment and innovatively adopts a composite suction cup—comprising a rigid base and a dual-layer EPDM sponge (closed-cell + open-cell)—to achieve adaptive sealing, thereby reliably applying the efficient negative-pressure generation capability to rough underwater surfaces. Theoretical modeling established the quantitative relationship between adsorption force (F) and key parameters (nozzle/throat diameters, suction cup radius). CFD simulations revealed optimal adsorption at a nozzle diameter of 4.4 mm and throat diameter of 5.8 mm, achieving a peak simulated F of 520 N. Experiments demonstrated a maximum F of 417.9 N at 88.9 W power. The composite seal significantly reduced leakage on high-roughness surfaces (Ra ≥ 6 mm) compared to single-layer designs. Integrated into an inspection robot, the system provided stable adhesion (>600 N per single adsorption device) on vertical walls and reliable operation under real-world conditions at Balnetan Dam, enabling mechanical-arm-assisted maintenance. Full article

More energy efficient heat pumps can be designed if the industry is able to identify reliable optimization schemes able to predict how a fixed amount of money is best spent on the different individual components. For example, how to optimally design and size the different heat exchangers (HEs) in a heat pump with respect to cost and performance. In this work, different optimization algorithms and HE area integral approximations are compared for heat pumps with two and three HEs, with or without ejectors. Since the main goal is to identify optimal numerical schemes, not optimal designs, heat transfer is simplified, assuming a constant U-value for all HEs, which reduces the computational work significantly. Results show that high-order HE area approximations are $10-400$ times faster than conventional trapezoidal and adaptive integral methods. High-order schemes with $45$ grid points ($N$) obtained $80-100$% optimization success rates. For subcritical processes, the LMTD method produced accurate results with $N\le 5$, but such schemes are unreliable and difficult to extend to real HE models with non-constant U. Results also show that constrained gradient-based optimizations are $10$ times faster than particle swarm, and that conventional GA optimizations are extremely inefficient. This study therefore recommends applying high-order HE area approximations and gradient-based optimizations methods developing accurate optimization schemes for the industry, which include realistic heat transfer coefficients. Full article

A new quasi-one-dimensional ejector model for the prediction of ejector performance is carried out, which is based on the theory of ideal gas expansion and free layer development. The model is proposed for calculation of the variable area bypass injector (VABI) and ejector nozzle in the variable cycle engine (VCE), both at the design point and off-design point. The internal structure of ejector nozzle is determined based on an analysis of the flow field of the 2D ejector nozzle Computational Fluid Dynamics (CFD) result. The flow during the expansion section is divided into three parts: primary flow, secondary flow, and mixed layer flow. Combined with the growth rate of mixing layer thickness, the calculation methods of ejector nozzle exit parameters under critical working conditions and blocking working conditions are given, and the calculated results demonstrate a strong consistency with CFD results, maintaining relative errors below 3%. This method is used to evaluate the ejector nozzle capacity quickly in the overall design stage, which provides theoretical support for the design of the main bypass system of a variable cycle engine. Full article

This review focuses on the advancements of CO₂ transcritical cycle technology in building indoor environmental regulation, particularly in combined heating and cooling applications. The paper highlights the energy efficiency and environmental benefits of CO₂ as a natural refrigerant, which has zero ozone depletion potential (ODP) and very low global warming potential (GWP). It provides a comprehensive overview of recent optimization strategies, including distributed compression, the integration of ejectors and expanders, and the design improvements of key components such as gas coolers, compressors, and throttling valves. Through optimization strategies such as dual-system cycles, this technology can achieve a COP improvement of 15.3–46.96% in heating scenarios; meanwhile, with the help of distributed compression technology, its cooling capacity can be enhanced by up to 26.5%. The review also examines various operating conditions such as discharge pressure and subcooling, which significantly affect system performance. The paper concludes by identifying the current challenges in the application of CO₂ systems, such as high initial costs and system stability under extreme conditions, and suggests future research directions to overcome these limitations and improve the practical application of CO₂ transcritical cycles in the building industry. Overall, it is concluded that the development of expander-compressors holds great potential for achieving better performance and represents a promising direction for future advancements in this field. Full article

Rail transit as a high-energy consumption field urgently requires the adoption of clean energy innovations to reduce energy consumption and accelerate the transition to new energy applications. As an energy-saving fluid machinery, the ejector exhibits significant application potential and academic value within this field. This paper reviewed the recent advances, technical challenges, research hotspots, and future development directions of ejector applications in rail transit, aiming to address gaps in existing reviews. (1) In waste heat recovery, exhaust heat is utilized for propulsion in vehicle ejector refrigeration air conditioning systems, resulting in energy consumption being reduced by 12~17%. (2) In vehicle pneumatic pressure reduction systems, the throttle valve is replaced with an ejector, leading to an output power increase of more than 13% and providing support for zero-emission new energy vehicle applications. (3) In hydrogen supply systems, hydrogen recirculation efficiency exceeding 68.5% is achieved in fuel cells using multi-nozzle ejector technology. (4) Ejector-based active flow control enables precise ± 20 N dynamic pantograph lift adjustment at 300 km/h. However, current research still faces challenges including the tendency toward subcritical mode in fixed geometry ejectors under variable operating conditions, scarcity of application data for global warming potential refrigerants, insufficient stability of hydrogen recycling under wide power output ranges, and thermodynamic irreversibility causing turbulence loss. To address these issues, future efforts should focus on developing dynamic intelligent control technology based on machine learning, designing adjustable nozzles and other structural innovations, optimizing multi-system efficiency through hybrid architectures, and investigating global warming potential refrigerants. These strategies will facilitate the evolution of ejector technology toward greater intelligence and efficiency, thereby supporting the green transformation and energy conservation objectives of rail transit. Full article

Integrating ejectors into CO₂ transcritical refrigeration systems to reduce energy consumption has been performed successfully throughout the industry in recent years. The objective of the present work is to investigate the effect of indoor and outdoor operating conditions on the energy efficiency of ejector expansion supermarket refrigeration plants. The analysis uses the measured energy consumptions and loads for two supermarket refrigeration plants operating in two cities in the Republic of Moldova (Chisinau and Balti). A model for the prediction of the plant’s annual energy consumption and the loads of the refrigeration and freezing compressors is developed using experimental results. Although there are theoretical and experimental analyses of the investigated systems in the specialized literature, no studies were found in the specialized literature regarding energy consumption increase due to pressure losses through the pipe route in transcritical CO₂ refrigeration installations with an ejector for supermarkets. The results indicate that refrigeration compressors have a greater increase in energy consumption than freezing compressors with increases in the outdoor temperature. The study shows that the additional drop in evaporating pressure at the compressor rack due to incorrect sizing of the pipe route leads to higher energy consumption compared to what the same plant would consume if the pipe route were correctly sized and executed. For every one-degree increase in temperature loss due to additional pressure drop through the pipeline, the entire plant consumes around 1.5% more energy. Knowledge of these performance data of real systems provides designers and manufacturers with clues to understand the importance of the correct design of the pipe route to obtain maximum energy efficiency. Full article
