This paper presents a minimally intrusive experimental methodology for identifying and modeling power losses in the electric powertrain of a battery electric vehicle, including the inverter, electric motor and speed reducer. Measurements are performed on a roller test bench equipped with an eddy current brake, using two complementary approaches to determine the mechanical power at the wheel: (i) a direct measurement based on an onboard rotary torque sensor integrated into a driveshaft; (ii) an indirect estimation derived from brake power measurements corrected for bench losses and tire longitudinal slip. The two approaches are systematically compared in order to quantify the accuracy loss associated with brake-based measurements and to identify the operating conditions under which they can reliably substitute direct torque measurements. The experimental results show that brake-based estimations provide acceptable accuracy at moderate–high torque levels, while significant deviations occur at low torque. Based on the experimental dataset, an overall power loss model is identified using a polynomial function of motor torque and speed. Two fitting strategies are investigated: an unconstrained least-squares approach, allowing all coefficients to vary freely, and a constrained formulation enforcing physically admissible (non-negative) loss terms; while the unconstrained method slightly improves the numerical fit, it may lead to non-physical coefficients and invalid efficiency predictions. In contrast, the constrained approach preserves physical interpretability and ensures consistent loss and efficiency maps. Finally, a step-by-step practical guide is provided to facilitate the implementation of the proposed methodology for powertrain loss identification on electric vehicles without extensive mechanical disassembly. Full article

According to the different excitation methods, automotive eddy current retarders (ECRs) can be divided into electrically excited retarders (EERs) and permanent magnet excited retarders (PMERs), and EERs and PMERs have certain complementarity in control and braking characteristics. Therefore, based on literature research, this article proposes a hybrid excitation rotary electromagnetic retarder (HERER) and conducts numerical simulation analysis and experimental research on the braking performance of the HERER. Firstly, the structure and working principle of the HERER are introduced. Secondly, based on the principles of electromagnetics, an equivalent magnetic circuit analysis model of the HERER is established. Then, a finite element analysis model of the HERER is established using Jmag 14 electromagnetic simulation software, and the braking performance of the HERER under different current and speed conditions is studied. Finally, bench tests are conducted on the air loss torque and eddy current braking performance of the HERER. The effectiveness of the finite element analysis model and equivalent magnetic circuit model of the HERER is verified. Full article

Based on the principle of eddy current braking and hydraulic braking, a new eddy current-hydrodynamic hybrid retarder (ECHHR) is proposed. Based on the introduction of the working principle and structure of the ECHHR, the finite element analysis models of the electromagnetic field and the flow field of the ECHHR were established, respectively. The electromagnetic field distribution, the flow field velocity, and the flow field pressure in the ECHHR were numerically simulated. The air gap magnetic density, the eddy current braking torque, and the hydraulic braking torque under different excitation currents and different liquid filling rates were calculated. Finally, the braking performance of the EHHR was tested via experiments, and the effectiveness of the finite element analysis method was verified. The test results indicated that as the speed increased, the composite braking torque of the ECHHR increased approximately linearly. When the speed was 1000 r/min, the composite braking torque reached 2100 N·m. Compared to separate hydraulic braking and eddy current braking, the composite braking torque was relatively high in the full-speed range. Full article

The ironless linear permanent magnet synchronous motor (ILPMSM) is highly compact, easy to control, and exhibits minimal thrust fluctuations, making it an ideal choice for direct loading applications requiring precise positioning accuracy in linear motor test rigs. To address the issue of temperature rise resulting from increased primary winding current and to simultaneously enhance thrust density while minimizing thrust fluctuations, this paper introduces a bilateral-type ILPMSM with a cooling water jacket integrated between the dual-layer windings of the primary movers. The primary winding of the motor adopts a dual-layer coreless structure where the upper and lower windings are closely spaced and cooled by a non-conductive metal cooling water jacket, while the dual-sided secondary employs a Halbach permanent magnet array. The motor’s overall braking force is a combination of the electromagnetic braking force generated by the energized windings and the eddy current braking force induced on the cooling water jacket. This paper specifically focuses on the analysis of the eddy current braking force. Initially, the motor’s geometry and working principle are presented. Subsequently, the equivalent magnetization intensity method is employed to determine the no-load air gap magnetic density resulting from the Halbach array. An analytical model is then developed to derive expressions for the eddy current density and braking force induced in the water-cooling jacket. The accuracy of the analytical method is validated through finite element analysis. Then, a comparative analysis of the braking forces in two primary cooling structures, namely the inter-cooled type and the two-side cooled type ILPMSM, is conducted. Moreover, the characteristics of the eddy current braking force are thoroughly examined concerning motor size parameters and operating conditions. This paper provides a solid theoretical foundation for the subsequent optimization design of the proposed motor. Full article

This paper proposes a model for the electromagnetic performance of the dual air-gap liquid-cooled eddy current retarder (DAL-ECR) considering the transient permeability. First, the structure and working principle of the DAL-ECR are introduced. Next, the analysis model of the static air-gap flux density considering the flux leakage and end effect is established based on the piecewise function method and the magnetic equivalent circuit (MEC). Then, based on the skin effect of the electromagnetic field in the retarder, an iterative method for solving the transient permeability of the stator is proposed. According to Faraday’s and Ampere’s laws, the analysis model of the static air-gap flux density, and the transient permeability, the analysis model of the transient air-gap flux density is established. The braking torque of the DAL-ECR is then calculated while taking the actual path of the eddy current and the skin effect on the permeability of the stator into consideration. Finally, the calculation accuracy of the model was verified by the finite element method (FEM) and the bench test. Full article

Permanent magnet eddy current couplers (PMECCs) have the characteristics of contactless torque transmission, removal of torque ripple, smooth dynamic process, and adjustable speed, and can be used as couplings, dampers, brakes, and speed governors. Their applications in industry, vehicles, and energy fields are gradually expanding. At the same time, the requirements for the torque density and dynamic performance of PMECCs are increasing. Therefore, a large amount of research work has focused on the fast and accurate modeling, design, and optimization of PMECCs. This paper provides a survey on the development of PMECCs technology. The main topics include the structure and classification of PMECCs, modeling methods, loss and heat transfer analysis modeling, and optimization design. In addition, this paper shows the future trends of PMECCs research. All the highlighted insights and suggestions of this review will hopefully lead to increasing efforts toward the model’s construction and the optimal design of PMECCs for future applications. Full article

As environmental regulations on automotive exhaust gas are gradually strengthened to cope with climate change, internal combustion engines, including those in hybrid electric vehicles, are continuously being downsized. Supercharging technologies are essential to compensate for the reduced engine power. One of the supercharging technologies, the turbocharger, has a response delay in the low-speed region, which is known as turbo lag. Various technologies have emerged to reduce turbo lag. Recently, electric supercharging technologies capable of reducing turbo lag using high-speed motors have been developed and commercialized. However, they are difficult to obtain for high-speed motors because of the cost of load performance test equipment. For this reason, many previous studies have compared analysis and experiment results under no-load conditions, or they have estimated performance in the high-speed region from results at low speed with light loads. This makes it difficult to know exactly how the performance of the motor is affected under loads applied to an actual system. In this study, performance test evaluation was conducted using a high-speed torque sensor, eddy current brake, and inertial dynamometer. Input/output power and efficiency were calculated using the measured voltage, current and output side torque and speed, and the results were compared. Full article

As an extension of a paper published at the 24th International Conference on Mechatronics Technology, ICMT 2021 conference, this paper shows the concept, design method, and model of a hybrid brake with additional validation. An eddy current brake cannot be used to decelerate a vehicle to a standstill. However, the magnetic attraction force between the rotor and stator of an eddy current brake can be used to generate an additional mechanical friction torque. By using a disc spring between the rotor and stator, the eddy current brake is extended to a so-called hybrid brake. In particular, the model and design method of the disc spring are the focus of this work. Using a system model that includes the electromagnetic and mechanical domains, the wear reduction compared to a conventional friction brake and the dynamic behaviour depending on the spring parameters are investigated. Finally, a disc spring is designed in FEM with the desired force–displacement curve. In addition, a working demonstrator of a hybrid brake is constructed, and the electromagnetic and mechanical system models are compared with the experimental results. For the first time, it is shown that the concept of using the magnetic attraction force between the rotor and stator of an eddy current brake for braking to a stop is working. In a speed range of 0–7500 rpm, it is possible to generate a torque of 100 Nm, whereby at speeds higher than 3500 rpm, the torque is generated in a wear-free manner by eddy currents. However, in order to be valid, the model must be extended to represent the deformation of the rotor. Full article

The eddy current brake (ECB) is an electromechanical energy conversion device that can be used as a load emulator to load a motor according to the intended load scenario. However, conducting an analysis in the time domain is difficult due to its complex behavior involving mechanical, electrical, and magnetic phenomena. The challenges with the time domain analysis of the ECB require new modeling approaches that provide reliability, robustness, and controllability over a wide speed interval. If the ECB can be modeled with high accuracy, it can be controlled like a load emulator that can simulate nonlinear industrial loads. This paper describes a neuromodeling approach taken to develop an ECB. The nonlinear characteristic of the brake system was modeled with a high performance by using an artificial neural network (ANN), which is a potent nonlinear system identification tool. Several characteristics of a designed and optimized brake system undergoing various excitation currents in whole speed regions are described and verified experimentally. Eventually, an electromechanical brake system is proposed that aims to provide the required linear or nonlinear load model dynamics throughout an emulation process in line with the obtained neuromodel. To identify the most suitable ANN architecture for the problem, various ANN configurations, ranging from 1 neuron to 20 neurons in the hidden layer, as well as a statistical approach that differs from the existing literature, are presented. Additionally, the suggested model’s scalability is discussed. Full article

The eddy current brake (ECB) is a braking technology that continues to be developed. The use of the ECB has excellent potential to be applied to vehicles. Various studies have proposed the design, characteristics, and advantages of each. However, further analysis is needed to assess the performance of the ECB and what factors affect the performance. However, no studies have been found that discuss eddy current brakes using bibliometric analysis. Bibliometric analysis is a method used for mapping and knowledge of existing gaps in a particular topic. This article aims to provide a complete discussion with bibliometric statistical methods that have never been presented before in the field of eddy current brakes, especially the phenomenon of heat generation. In addition, the prediction of research gaps in this field can be identified as the initial results of further research. The analysis was carried out using VOSviewer and Biblioshiny integrated through the RStudio tool. The data are obtained through the Scopus database, which is then exported in CSV form. Obtaining the data depends on the keywords used. In this case, the obtained document is filtered with the features provided by Scopus. From the analysis conducted, it was found that the topic related to heat in eddy current brakes is still a recent discussion. Discussions on the heat increase in the ECB are still limited and require mapping and analysis of what parts still need development. The phenomenon of heat generation is one novelty that allows it to be researched. One example from the scientific data obtained is that there are 207 documents in the form of articles and conference papers with a total of 533 authors. Full article

High-temperature superconducting (HTS) magnetic levitation (maglev) trains for designed high speed need a non-contact braking method that can produce stable and sufficient braking forces to ensure the safety of the train during emergency braking. In order to study the braking effects of permanent magnet eddy current braking (PMECB) used in HTS maglev vehicles and its effects on the levitation performance of HTS maglev vehicles, an equivalent two-dimensional simulation model of PMECB for a HTS maglev test vehicle under different working air gaps of 5 mm, 10 mm, 15 mm and 20 mm was established in Maxwell software. Then, a 6 degree of freedom dynamic model of the vehicle was established in Universal Mechanism software. In the dynamic simulation, the normal force of PMECB was not considered, and only the detent force of PMECB was taken as the excitation of the vehicle. The simulation results show that PMECBs can reduce the vehicle to relatively low speed in a few seconds. During the operation of PMECBs, the levitation height and levitation force of the maglev Dewar will be affected, and maximum variations in levitation heights and levitation forces occur on the Dewars at both ends of the vehicle. These help us to understand the braking and levitation performance of HTS maglev vehicles under the action of PMECBs and enrich the design idea of braking and levitation systems of HTS maglev vehicles equipped with PMECBs. Full article

The braking system is one of the most important components of a vehicle. In general, the brakes will generate heat due to the braking process. The heat generated must be released into the environment to maintain braking performance at optimal conditions. In extreme conditions, braking will fail. The braking system can be developed as a braking support system is a non-contact braking system. One form of the non-contact braking system is the eddy current brake (ECB). ECB is an electric braking system with the principle of eddy current. In the ECB, overheating will result in decreased performance. The approach that can be taken to determine braking performance during heat generation is the modeling process using FEM. This study uses FEM to analyze the heat generated during braking. In addition to using FEM, research was carried out using experiments as a comparison. Analysis of heat generation in braking is needed to determine whether braking with ECB can be a backup and its potential as a substitute for friction brakes. The results show that the ECB heat generation event that affects the temperature rise reduces the braking torque performance. Research indicates that when overheating occurs, braking performance will decrease by up to 10% when the disk surface temperature rises more than 20 °C. It shows the importance of managing heat that occurs in the ECB. Full article

The design and application of eddy current brakes (ECBs) should be simple; further, ECBs should be used semi-permanently. This study aimed to determine major parameters for designing an ECB that can be applied to a small-scale wind turbine generator. To this end, an ECB was developed that could actuate without additional power, thus improving the efficiency of the generator. A series of simulations were conducted for a parametric study to pre-design ECBs suitable for small wind turbines. The six parameters chosen were disk thickness, number of magnets, radial location of magnets from center of disk, magnet pole arrangement, magnetic flux density, and rotational speed. The simulations were conducted on COMSOL Multiphysics. The results indicated that the number of magnets and magnet pole arrangements can significantly affect the performance curve of ECBs. Moreover, the disk thickness and rotational speed are linearly proportional to the braking torque. Full article

Electromagnetic fields have emerged as powerful tools for addressing current problems in thin slab continuous casting processes in the iron and steel industry. Substantial studies have been undertaken on the fundamental effects of electromagnetic brakes (EMBr) and strand electromagnetic stirring (SEMS). However, little attention has been focused on melt flow and solidification in a thin slab continuous caster with the simultaneous application of an EMBr and SEMS. The present study aimed to predict transient fields in the caster using a large eddy simulation and an enthalpy-porosity method. The electric potential method was applied in the braking process, and the conductivity change with solidification was considered. The suppressive effect on the intensity of the nozzle jet, the balance effect on the mold flow, and a dispersion effect could be observed. The dispersion effect was a novel finding and was beneficial to a flatter nozzle jet. In contrast, SEMS caused a highly turbulent flow in the strand. A large vortex could be observed in the casting direction. The solidified shell became more uniform, and the solidification rate became obviously slower. These findings supported the view that a high-quality thin slab can be produced by the application of an EMBr and SEMS. Full article

Based on the principle of permanent magnet electrodynamic suspension (PMEDS), a new concept maglev car was designed by using rotary magnetic wheels and a conductor plate. It has the advantages of being high-speed, low-noise, environmentally friendly, safe and efficient. The PMEDS car is designed to use a permanent magnet electrodynamic wheel (EDW) to achieve the integration of levitation force and driving force. The levitation force is generated by the repulsive force of the eddy current magnetic field, and the driving force is generated by the reaction force of magnetic resistance. A simplified electromagnetic force model of the EDW and a dynamics model of the PMEDS car were established to study the operating mode. It shows that the PMEDS car can achieve suspension when the rotational speed of the EDWs reaches a certain threshold and the critical speed of the EDWs is 600 rpm. With the cooperation of four permanent magnet EDWs, the PMEDS car can achieve stable suspension and the maximum suspension height can reach 7.3 mm. The working rotational speed of EDWs is 3500 rpm. At the same time, the movement status of the PMEDS car can be controlled by adjusting the rotational speed of rear EDWs. The functions of propulsion, acceleration, deceleration, and braking are realized and the feasibility of the PMEDS car system is verified. Full article
