Partial discharge (PD) is not only a critical indicator but also a major accelerating factor of insulation degradation in power transformers. Accurate identification of PD types is essential for diagnosing insulation defects and locating faults in transformers. Traditional methods based on phase-resolved partial discharge (PRPD) patterns typically rely on expert interpretation and manual feature extraction, which are increasingly being supplanted by Convolutional Neural Networks (CNNs) due to their ability to automatically extract features and deliver high classification accuracy. However, the inherent subtlety and diversity of characteristic differences among PRPD patterns, coupled with substantial noise resulting from complex electromagnetic interference, present significant hurdles to achieving accurate identification. This paper proposes a transformer partial discharge identification method based on Deep Residual Shrinkage Network (DRSN) to address these challenges. The method integrates dual-path feature extraction to capture both local and global features, incorporates a channel-domain adaptive soft-thresholding mechanism to effectively suppress noise interference, and utilizes the Focal Loss function to enhance the model’s attention to hard-to-classify samples. To validate the proposed method, given the scarcity of diverse real-world transformer PD data, an experimental platform was utilized to generate and collect PD data by artificially simulating various discharge defect models, including tip discharge, surface discharge, air-gap discharge and floating discharge. Data diversity was then enhanced through sample augmentation and noise simulation, to minimize the gap between experimental data and real-world on-site data. Experimental results demonstrate that the proposed method achieves superior partial discharge recognition accuracy and strong noise robustness on the experimental dataset. For future work, it is essential to collect more real transformer PD data to further validate and strengthen the model’s generalization capability, thereby ensuring its robust performance and applicability in practical scenarios. Full article

Wireless power transfer (WPT) systems for autonomous underwater vehicles (AUVs) are gaining traction in marine exploration due to their operational convenience, safety, and flexibility. Nevertheless, disturbances from ocean currents and marine organisms frequently induce rotational, axial, and air-gap misalignments, significantly degrading the output power stability. To mitigate this issue, this paper proposes a novel reconfigurable WPT system utilizing coaxial antipodal dual DD (CAD-DD) coils, which strategically switches between a detuned S-LCC topology and a detuned S-S topology at a fixed operating frequency. By characterizing the output power versus the coupling coefficient (P-k) profiles under both reconfiguration modes, a parameter design methodology is developed to ensure stable power delivery across wide coupling variations. Experimental validation using a 1.2 kW AUV charging prototype demonstrates remarkable tolerance to misalignment: ±30° rotation, ±120 mm axial displacement, and 20–50 mm air-gap variation. Within this range, the output power fluctuation is confined to within 5%, while the system efficiency exceeds 85% consistently, peaking at 91.56%. Full article

This paper introduces a hybrid analytical model (HAM) for the evaluation of permanent-magnet (PM) eddy-current loss in dual-stator single-rotor axial flux permanent-magnet machine (AFPMM), accounting for stator saturation. The proposed model integrates the magnetic equivalent circuit (MEC) with an analytical model based on scalar magnetic potential, enabling simultaneous consideration of different rotor positions and stator slotting effects. The three-dimensional finite element method (3D-FEM) validates the no-load and armature reaction magnetic field calculated by HAM, as well as the PM eddy-current loss under both no-load and load conditions. Compared to 3D-FEM, the proposed model reduces the calculation time by more than 98% with an error of no more than 18%, demonstrating a significant advantage in terms of computational time. Based on the proposed model, the effects of air-gap length and slot opening width on PM eddy-current loss are analyzed; the results indicate that reducing the slot opening width can effectively mitigate PM eddy-current loss for AFPMM. Full article

External-rotor dual-armature flux-switching PM (ER-DA-FSPM) machines have high torque density and decent fault tolerance, making them promising candidates for in-wheel machine applications in electric vehicles. The torque output and optimal design parameters of ER-DA-FSPM machines are affected by the stator/rotor torque ratio, which is the focus of this paper. Firstly, this paper analyzes airgap flux density harmonics of ER-DA-FSPM to provide a clear insight into the torque-generation mechanism. Then, this paper investigates the influence of torque ratio on average torque under the same copper loss. It is found that the average torque decreases with torque ratio increasing due to the reduction of the positive torque component generated by the sixth airgap field harmonics and the rise in the negative torque component from the eighth harmonics. Moreover, this paper also provides the optimal parameter recommendation to guide the machine design. The split ratio should increase, and the arc of PMs should decrease for a larger torque ratio, whilst the other parameters are hardly influenced. Next, this paper makes a comparison among the ER-DA-FSPM machine, external rotor flux-switching PM (ER-FSPM) machine, and surface-mounted PM (ER-SPM) machines. It shows that the ER-DA-FSPM machine, with the torque ratio being 2, can lead to a much larger total torque. In addition, in the event of rotor winding failure, which is more possible due to the existence of slip rings than stator winding failure, the stator can still provide an average torque larger than that of ER-SPM machine and 92.0% that of the ER-FSPM machine, respectively. Finally, the theoretical analysis is verified by the experiments. Full article

This paper proposes a high torque density dual-stator flux-reversal-machine with multiple poles Halbach excitation (MPHE-DSFRM), which uses two pole pairs’ numbers (PPNs) of PM excitation on one outer stator tooth, and one PPN of PM excitation on one inner stator tooth. The introduction of different PPNs of PM excitation on the outer and the inner stators can optimize magnetic circuit and airgap flux density. A Halbach array is formed by inserting three pieces of circumferentially magnetized PMs into four pieces of radially magnetized permanent magnets (PMs) on the outer stator, which aims to further enhance torque density, and reduce torque ripple. Based on the flux modulation effect, the analytical modeling of the proposed MPHE-DSFRM is established, together with the evolution process, and the working principle is presented. Then, the key design parameters of MPHE-DSFRM are optimized to achieve high torque density and low torque ripple for high torque quality. Three representative DSFRMs and a conventional FRM are designed and analyzed, and they share the same design key parameters, including PM usage, outer radius of the outer stator, and active airgap length. The electromagnetic performances, including airgap flux density, back electromotive force (back-EMF), and torque characteristics, are analyzed and compared by finite element analysis (FEA). The calculated results show that the proposed MPHE-DSFRM can provide high torque density and high PM utilization. Full article

Hybrid excitation generators combine the advantages of electric excitation motors and permanent magnet generators. Focusing on a permanent magnet generator as the object of study, an auxiliary excitation winding is introduced for voltage regulation. The main magnetic field is established by the permanent magnet, and the auxiliary excitation winding provides the magnetic potential required to regulate the air-gap magnetic field. While improving the voltage regulation performance of permanent magnet generators, it also reduces the loss of excitation windings in electrically excited generators. Based on a hybrid excitation generator with dual excitation windings, in the following article, we present a hybrid excitation generator equivalent to a full permanent magnet motor with the minimum output voltage, and an accurate subdomain model of the full permanent magnet motor is established considering the influence of slot opening. By establishing a matrix, the distribution curve of air-gap magnetic density was solved and ultimately verified using finite element analysis. The results of the present study lay a solid foundation for solving the air-gap magnetic density distribution of various parts of the hybrid excitation generator and studying its performance in the future. Full article

This paper investigates the use of fractional-slot concentrated windings (FSCWs) in large-scale (MW level) offshore wind generators. It focuses specifically on a power rating of 3 MW and uses an existing direct-drive synchronous PM machine (DD-SPM) with 480s/160p and dual three-phase integer-slot winding (ISW) as a baseline. A multiple of the common 12s/10p FSCW machine is used that matches the electrical frequency of the ISW machine, yielding a 192s/160p dual three-phase machine. The hybrid star–delta connection has grown increasingly popular owing to its unique harmonic cancellation properties, which can help reduce rotor and PM eddy current losses in FSCW machines. In this paper, two dual three-phase star–delta-wound machines are scaled to 3 MW and included in the investigation. Specifically, a 384s/160p dual three-phase and dual star–delta winding machine, which is a multiplication of the 24s/10p machine, and a 192s/176p dual three-phase and dual star–delta winding machine, which is a multiplication of the 24s/22p machine, are used. These machines are investigated using finite element analysis (FEA) and compared on the basis of their air-gap flux density harmonics, open-circuit electro-motive force (EMF), torque performance, and losses and power. It is found that the proposed 384s/160p dual star–delta winding machine has the best electromagnetic performance of all, with a stator power that is 1.2% greater than that of the baseline ISW machine. However, this machine has a coil pitch of 2 and so loses the manufacturing and fault-tolerant advantage of having concentrated windings. If concentrated windings are desired, then the proposed 192s/176p dual star–delta winding machine is the best choice, with the stator power only 2.6% less than that of the baseline ISW machine, but unfortunately still has significant rotor and PM eddy current losses. Full article

In this paper, a novel dual-three-phase dual-rotor flux-switching permanent magnet (PM) (DRFSPM) machine, building upon conventional FSPM machines, is proposed, where the stator is equipped with dual PMs and dual armature windings, enabling it to operate in various working modes and provide fault tolerance in the event of PM or armature winding faults. Depending on the magnetization directions of the PMs, the proposed DRFSPM machine’s structure can be categorized as 6N-DRFSPM or NS-DRFSPM. In order to assess the electromagnetic performance of the proposed DRFSPM machines with two different magnetizing modes, the topology and operating principle of the two DRFSPM machines are introduced first. Then, the no-load air-gap flux density of the two proposed machines is investigated for a more optimized and purposeful design. Finally, a comparison of the electromagnetic performance between the two proposed DRFSPM machines is conducted by finite-element analysis (FEA), and the FEA-predicted results indicate that the proposed 6N-DRFSPM machine outperforms the NS-DRFSPM machine, as it exhibits a larger back-EMF and average torque and a smaller cogging torque and torque ripple. Full article

A dual-rotor yokeless and segmented armature (YASA)-type axial-flux permanent magnet (AFPM) motor with a surface-mounted permanent magnet (SPM) array type was developed for urban air mobility (UAM) aircraft in this work. The proposed AFPM motor had rated and peak output powers of 75.5 and 104 kW, respectively, with rated and peak rotational speeds of 1800 rpm. To achieve a high torque, a cobalt–iron alloy core material was used for the stator core. The prototype AFPM motor, developed by KSEP in the Republic of Korea, was successfully manufactured and verified through experimentation. Additionally, the thermal stability of the winding and permanent magnets (PMs) was confirmed with a water-cooling system. A structure analysis of the proposed AFPM motor was conducted due to the detachment of an uneven air-gap length in the prototype AFPM motor. An output performance comparison based on core materials for the stator and rotor was carried out to explore the material cost reduction. Subsequently, the design for performance improvement by applying a Halbach permanent magnet (HPM) array type was investigated for further research. Full article

Electric motors with a double air-gap structure offer increased power or torque density compared to their single air-gap counterparts, achievable through double-stator or double-rotor configurations. In a previous study, the authors proposed a double-stator permanent magnet synchronous motor (PMSM) with a magnetic screen placed in the middle of the rotor to isolate the outer and inner motors. However, the analysis of the magnetic screen was not provided in that study, as the design was arbitrarily chosen. This research focuses on the effects of the magnetic screen size and selects the appropriate dimensions for optimal motor performance. Finite element analysis (FEA) is employed to assess the electromagnetic characteristics of the screen. Subsequently, the motor is manufactured and tested. The results show that the chosen magnetic screen size contributes to significant efficiency improvements. In particular, the motor achieved an efficiency of 95.2% during the qualification test, surpassing the efficiency obtained in the previous study. Full article

The Double Permanent Magnet Vernier (DPMV) machine is well known for its high torque density and magnet utilization ratio. This paper aims to investigate the torque generation mechanism and its improved design in DPMV machines for hub propulsion based on the field modulation principle. Firstly, the topology of the proposed DPMV machine is introduced, and a commercial PM machine is used as a benchmark. Secondly, the rotor PM, stator PM, and armature magnetic fields are derived and analyzed considering the modulation effect, respectively. Meanwhile, the contribution of each harmonic to average torque is pointed out. It can be concluded that the 7th-, 12th-, 19th- and 24th-order flux density harmonics are the main source of average torque. Thanks to the multi-working harmonic characteristics, the average torque of DPMV machines has significantly increased by 31.8% compared to the counterpart commercial PM machine, while also reducing the PM weight by 75%. Thirdly, the auxiliary barrier structure and dual three-phase winding configuration are proposed from the perspective of optimizing the phase and amplitude of working harmonics, respectively. The improvements in average torque are 9.9% and 5.4%, correspondingly. Full article

This paper proposes a model for the electromagnetic performance of the dual air-gap liquid-cooled eddy current retarder (DAL-ECR) considering the transient permeability. First, the structure and working principle of the DAL-ECR are introduced. Next, the analysis model of the static air-gap flux density considering the flux leakage and end effect is established based on the piecewise function method and the magnetic equivalent circuit (MEC). Then, based on the skin effect of the electromagnetic field in the retarder, an iterative method for solving the transient permeability of the stator is proposed. According to Faraday’s and Ampere’s laws, the analysis model of the static air-gap flux density, and the transient permeability, the analysis model of the transient air-gap flux density is established. The braking torque of the DAL-ECR is then calculated while taking the actual path of the eddy current and the skin effect on the permeability of the stator into consideration. Finally, the calculation accuracy of the model was verified by the finite element method (FEM) and the bench test. Full article

Transient response performance and steady-state operation performance are the two most important performance indicators of a motor drive system. In order to solve these two problems, this study proposes a new induction motor (IM) model, and then designs a new simplified linearization controller method. First, the tangential force that determines the transient process of the motor is represented by electromagnetic torque, and the radial force is represented by reactive torque. Then, the dual-torque model of IM is derived, which not only accurately shows the rotating air-gap magnetic field through the amplitude and rotating angular frequency, but also visually demonstrates the physical essence of the transient process of IM. Then, this study proposes a simplified feedback linearization method without the analysis of zero dynamic. In addition, a time-scale hierarchical control system is designed to reduce the ripple caused by the coupling of different time-scale variables. The experimental results show that the steady-state torque ripple of the proposed method is 65% lower than that of RFOC, and the torque response speed is 10% higher than that of DTC. Full article

Increasing industrial development puts forward high requirements for the performances of stator permanent magnet (PM) machines, such as torque density and efficiency. The paper proposes a new dual stator PM machine based on field modulation theory (DSPMM), which employs the intermediate rotor participating in the electromechanical energy conversion of the internal and external machine. The proposed machine has the advantages of high torque density and high efficiency and solves the problem of insufficient space utilization of a single stator machine. The evolution process and working principle of the proposed DSPMM are studied. The flux-switching-type PM (FSPM) and the flux-reversal-type PM (FRPM) are employed in the proposed DSPMM, which forms four representative machines. For a fair comparison, the proposed machines employ identical key parameters, i.e., PM volume, the outer radius of the outer stator, and active airgap length. Based on finite element analysis (FEA), the electromagnetic performances of the four representative DSPMM under no-load and rated load, and different copper consumption conditions are analyzed and compared. The calculated results show that the proposed DSPMM with inner FSPM stator and outer FRPM stator can provide high output torque, low torque ripple, high power factor, and high efficiency. Full article

The most permanent magnets in current electromagnetic velocity sensors are magnet cylinders that have been axially magnetized, with magnetic boots changing the propagation direction of the magnetic induction lines of the magnet cylinders. However, the magnetic field generated by the magnet cylinders is not fully utilized, which leads to uneven magnetic field intensity of the working air-gap and high magnetic field intensity of the nonworking air-gap. We propose a novel dual-magnet structure (DM) mainly consisting of two magnet loops that are magnetized radially and a magnetic conductive shaft, adopting a concentric nested configuration. The dual-magnet structure can make the magnetic induction lines enter the working air-gap directly from the magnet and increase the effective magnetic field, which is perpendicular to the coils in the working air-gap. This design can further improve the sensitivity of a velocity sensor and enhance its ability to detect weak signals in microtremor exploration. The validity of the dual-magnet structure has been established by numerical simulations and verified by experiments. The results reveal that the magnetic field intensity is increased by 29.18% and the sensitivity is improved by 23.9%, when the total volume and material of the magnet are unchanged. The full utilization of the material is achieved without increasing the complexity of the structure. Full article
