To mitigate the impacts of urbanisation and the attendant surface sealing, appropriate measures are required when adapting urban spaces and drainage infrastructure. In this context, the deployment of Sustainable Drainage Systems (SuDSs) has emerged as a viable alternative, delivering highly positive outcomes by enhancing hydrological, hydraulic and landscape performance while restoring ecosystem services to the community. This study evaluates the relative performance of five SuDS typologies, green roofs, bioretention cells, infiltration trenches, permeable pavements, and rain barrels, implemented in a 64 ha subbasin of the metropolitan area of Barcelona, Spain. Using Giswater integrated with the SWMM, the stormwater drainage network was modelled under multiple rainfall scenarios. Performance was assessed using two qualitative indicators, the junction index (I_j) and the conduit index (I_c), which measure surcharge levels in manholes and pipes, respectively. The results show that SuDS implementation affecting 42.8% of the drained area can enhance network performance by 35.6% and reduce flooded junctions by 67%. Among the typologies, rain barrels and bioretention cells were the most effective. The study concludes that SuDS construction, supported by open-source tools and performance-based indicators, constitutes a replicable and technically robust strategy for mitigating the effects of surface sealing and increasing urban resilience. Full article

With the weathering of iron sulfide minerals, acid rock drainage (ARD) emanates from the 60-millon tonne Main Waste Stockpile (MWS) at the Red Dog Mine. Following completion of the stockpile, a collection trench was constructed in 2012–2013 to capture and treat a portion of the ARD, and a cover system was emplaced from 2021 to 2025 to cover 90% of the stockpile. Select wells in the collection trench are associated with the different cover phases. Analysis of the water chemistry of samples collected at the wells indicates increased pH and decreased dissolved solids with each phase of the cover along with significant changes in flow and solutes such as aluminum, iron, sulfate, and zinc. Although the cover should continue to decrease ARD volume, acidity, and solute concentrations, an evaluation of historical acid production and iron sulfide consumption in the stockpile indicates a likely majority of the iron sulfide content remains available for weathering and acid production. Continued MWS ARD monitoring is necessary to evaluate the multi-year effect of the cover because of the variability of the pre-cover ARD, identification of seasonal and multi-year precipitation influences on ARD generation, and a yet to be determined influence of the cover on the volume of infiltrating precipitation. Full article

The implementation of a decentralized blue–green infrastructure (BGI) is a key strategy in climate adaptation and stormwater management. However, the integration of urban trees into the multifunctional infrastructure remains insufficiently addressed, particularly regarding rooting space in dense urban environments. Addressing this gap, the BoRSiS project developed the soil-pipe system (SPS), which repurposes the existing underground pipe trenches and roadway space to provide trees with significantly larger root zones without competing for additional urban space. This enhances tree-related ecosystem services, such as cooling, air purification, and runoff reduction. The SPS serves as a stormwater retention system by capturing excess rainwater during heavy precipitation events of up to 180 min, reducing the pressure on drainage systems. System evaluations show that, on average, each SPS module (20 m trench length) can store 1028–1285 L of water, enabling a moisture supply to trees for 3.4 to 25.7 days depending on the species and site conditions. This capacity allows the system to buffer short-term drought periods, which, according to climate data, recur with frequencies of 9 (7-day) and 2 (14-day) events per year. Geotechnical and economic assessments confirm the system stability and cost-efficiency. These findings position the SPS as a scalable, multifunctional solution for urban climate adaptation, tree vitality, and a resilient infrastructure. Full article

This paper presents a comprehensive experimental study on the mix design and performance of permeable concrete for geotechnical applications, focusing on its hydraulic conductivity, durability, and filter properties. Characterized by high porosity and minimal or no fine aggregates, classical pervious concretes are effectively utilized in various civil and environmental engineering applications, including drainage systems and erosion control. This research examines the influence of the particle size distribution of aggregates on the filter properties of permeable concrete for applications in geotechnical engineering (draining piles, deep trench drains, and draining backfill). It emphasizes the importance of resistance to clogging to maintain adequate residual hydraulic conductivity and to prevent the internal erosion of soils into which permeable concrete drains are installed. The experimental results indicate that including sand in the aggregates strongly enhances the filtering capacity of pervious concrete. These findings suggest that if the mix design of permeable concrete is developed considering the grain size distribution of the base soils, the concrete will meet long-term drainage requirements (sufficient residual hydraulic conductivity), exhibit good resistance to physical clogging, provide excellent protection for the base soils against internal erosion, and contribute to the overall stability of geotechnical systems. Full article

Systematic interviews to technicians in charge of urban drainage were undertaken to assess the distribution of nature-based solutions (NBSs) for hydraulic risk mitigation in the Veneto region (Italy) and to investigate interventions that are priorities to address the challenges of urban growth and hydraulic risk. Specifically, this paper investigated stakeholders’ preference for green and gray infrastructure and for some NBSs in particular among those more frequently adopted, where they are predominantly implemented, and why. The results were interpreted in the context of significant geomorphological, socioeconomic, and regulatory parameters and how they relate to NBS implementation. The survey demonstrated that, among technical experts in one of Italy’s most developed regions, there may be a certain skepticism about the effectiveness of NBSs in counteracting the hydraulic risk of flooding, the close interrelation between political decisions in favour of NBS and the constrains of national and regional legislation, and the willingness to involve the population in the decision-making process. Further investigation showed that what (de)motivates the use of NBSs may be a partial disconnection between the academic, technical, and administrative sectors. Full article

A typical infiltration system (IS) consists of an urban sub-catchment that works in synergy with an engineered pervious sub-catchment (e.g., a trench). ISs for sustainable urban drainage meet multiple design objectives: returning water resources to the environment (circularity) and reducing hydraulic risk. ISs, by necessity, are realized in the public spaces which belong to historical city centers, industrial zones, densely populated urban areas or areas of recent urbanization. Available space conditions the shape of impervious drainage sub-basins and downstream trenches that hold and release runoff volume to the subsoil. Catchment shape and rainfall intensity have received relatively less attention in the designing and decision-making processes than rainfall volume. A hydrodynamic model (HM) offers the opportunity to systematically investigate the efficiency of ISs as shape and rain intensity change, overcomes the limits of the widespread bucket modelling approach, which is narrowly focused on rain volume, trench storage capacity and exfiltration capacity, and links the shape of IS to its efficiency and to the residual risk that occurs when events of intensity greater than the design event occur. The results of a systematic sensitivity analysis, conducted by the use of HM, suggest new criteria for evaluating whether ISs are suitable for achieving the design objectives, within the constraints of the available urban public space. Full article

Crystal blockages of tunnel drainage systems severely undermine the tunnel lining structure and operation safety. In order to reduce the risk of crystal blockages of tunnel drainage systems, the distribution of highway tunnel defects was identified through a field survey, indoor test, and literature analysis, and an optimization method of tunnel drainage structures was proposed. The research suggested the following: (1) Lining water leakage and construction joint water leakage were the most common defects in the tunnel drainage system of Renhua–Xinfeng Expressway and Yingde–Huaiji Expressway in Guangdong Province, accounting for 60% and 32% of total defects, respectively. The number of defects that occurred in the drainage system of the tunnel was larger in the granite formation, with the number of road seepage and inspection chamber crystallization incidents reaching 2.5/km and 2.8/km, respectively. (2) The groundwater was mainly alkaline with a pH value of 8~12, Ca²⁺ (107 mg/L) was the cation with the largest ion concentration, and HCO₃⁻ (165 mg/L) was the anion with the largest ion concentration. The crystals in the tunnel drainage system were predominantly square, spindle, and rhombic calcite and aragonite composed of CaCO₃, mixed with a small amount of sediment. (3) To reduce the risk of crystal blockages of the tunnel drainage system and ensure tunnel lining structure safety, a threefold optimization measure was proposed, namely, setting one-directional drainage pipes between the cable trench and the roadside blind drainage ditch, applying “π” type anti-crystallization drainage water-stop belts at the circular construction joints in the secondary lining, and both increasing the slope of the transverse drainage pipe and using an anti-crystallization drainage pipe. The research results will play an important role in guiding the design, construction, and maintenance of highway tunnel drainage systems in China. Full article

For the sustainable restoration of wet farm land degraded by the climate change-induced rise of ground water level (GWL) and soil salinity etc., the sheet pipe system is one of the most useful technologies which reduces cultivation obstacles due to the poor drainage by controlling the rapid drainage function and enabling farmers to produce profitable crops. This system is characterized mainly as a perforated polyethylene rolled-band sheet 180 mm in width and 1 mm thick which is drawn into the subsurface layer while transforming a drainage pipe with φ = 50 mm. The major advantage of this system is that since the sheet pipe is installed without trenching, the disturbance of land is minimized and the construction period can be shortened to about 1/4 (which reduces the cost approximately by 50%). In this study, by using the sheet pipe installed miniature-type model soil box, the drainage capacity of the sheet pipe was confirmed as being the same as the pipe-shaped standard drainage pipes. Based on the observations of the saturated–unsaturated flow and the maximum lowering rate of GWL was predicted. Finally, at the farm land wherein the free board of the adjoining canal was limited, the effectiveness of the sheet-pipe system was confirmed. Full article

Agricultural subsurface drainage systems are commonly installed on farmland to remove the excess water from poorly drained soils. Conventional methods for drainage mapping such as tile probes and trenching equipment are laborious, cause pipe damage, and are often inefficient to apply at large spatial scales. Knowledge of locations of an existing drainage network is crucial to understand the increased leaching and offsite release of drainage discharge and to retrofit the new drain lines within the existing drainage system. Recent technological developments in non-destructive techniques might provide a potential alternative solution. The objective of this study was to determine the suitability of unmanned aerial vehicle (UAV) imagery collected using three different cameras (visible-color, multispectral, and thermal infrared) and ground penetrating radar (GPR) for subsurface drainage mapping. Both the techniques are complementary in terms of their usage, applicability, and the properties they measure and were applied at four different sites in the Midwest USA. At Site-1, both the UAV imagery and GPR were equally successful across the entire field, while at Site-2, the UAV imagery was successful in one section of the field, and GPR proved to be useful in the other section where the UAV imagery failed to capture the drainage pipes’ location. At Site-3, less to no success was observed in finding the drain lines using UAV imagery captured on bare ground conditions, whereas good success was achieved using GPR. Conversely, at Site-4, the UAV imagery was successful and GPR failed to capture the drainage pipes’ location. Although UAV imagery seems to be an attractive solution for mapping agricultural subsurface drainage systems as it is cost-effective and can cover large field areas, the results suggest the usefulness of GPR to complement the former as both a mapping and validation technique. Hence, this case study compares and contrasts the suitability of both the methods, provides guidance on the optimal survey timing, and recommends their combined usage given both the technologies are available to deploy for drainage mapping purposes. Full article

Subsurface drainage systems are commonly used to remove surplus water from the soil profile of a poorly drained farmland. Traditional methods for drainage mapping involve the use of tile probes and trenching equipment that are time-consuming, labor-intensive, and invasive, thereby entailing an inherent risk of damaging the drainpipes. Effective and efficient methods are needed in order to map the buried drain lines: (1) to comprehend the processes of leaching and offsite release of nutrients and pesticides and (2) for the installation of a new set of drain lines between the old ones to enhance the soil water removal. Non-invasive geophysical soil sensors provide a potential alternative solution. Previous research has mainly showcased the use of time-domain ground penetrating radar, with variable success, depending on local soil and hydrological conditions and the central frequency of the specific equipment used. The objectives of this study were: (1) to test the use of a stepped-frequency continuous wave three-dimensional ground penetrating radar (3D-GPR) with a wide antenna array for subsurface drainage mapping and (2) to evaluate its performance with the use of a single-frequency multi-receiver electromagnetic induction (EMI) sensor in-combination. This sensor combination was evaluated on twelve different study sites with various soil types with textures ranging from sand to clay till. While the 3D-GPR showed a high success rate in finding the drainpipes at five sites (sandy, sandy loam, loamy sand, and organic topsoils), the results at the other seven sites were less successful due to the limited penetration depth of the 3D-GPR signal. The results suggest that the electrical conductivity estimates produced by the inversion of apparent electrical conductivity data measured by the EMI sensor could be a useful proxy for explaining the success achieved by the 3D-GPR in finding the drain lines. Full article

For those slopes where the piezometric regime acts as internal landslide predisposing factor, drainage may represent a more effective mitigation measure than other structural interventions. However, drainage trenches have been generally considered as mitigation measure solely for shallow landslides. More recently, instead, some authors show that the variation in piezometric conditions at large depth is not negligible when medium depth drainage trenches are involved. The paper presents the results of finite element analyses of the transient seepage induced by the installation of systems of drainage trenches of different geometric parameters, and the effect of the drainage system on the stability factor of the slip surface, through 2D limit equilibrium analyses. The pilot region is the Daunia Apennines, where field studies have led to recognize for most of the landslides a “bowl-shaped” slip surface; the results accounting for the Fontana Monte slope at Volturino (Italy), selected as prototype landslide in the assessment of the stabilization efficacy of deep drainage trench systems, is discussed in the following. The study aims at providing indications about the design of the drainage trenches to reduce the pore water pressures on a deep slip surface of such type. Full article

Sewer systems affect urban soil characteristics and subsoil water flow. The direct connection observed between baseflow in sewer systems under drainage infiltrations and piezometric levels influences the hydrological behavior of urban catchments, and must consequently be considered in the hydrologic modeling of urban areas. This research studies the groundwater contribution to sewer networks by first characterizing the phenomenon using experimental data recorded on a small urban catchment in Nantes (France). Then, the model MODFLOW was used to simulate the infiltration of groundwater into a sewer network and model dry weather flows at an urban catchment scale. This application of MODFLOW requires representing, in a simplified way, the interactions between the soil and the sewer trench, which acts as a drain. Observed average groundwater levels were satisfactorily simulated by the model while the baseflow dynamics is well reproduced. Nonetheless, soil parameters resulted to be very sensitive, and achieving good results for joint groundwater levels and baseflow was not possible. Full article

The territory of Lithuania is characterized by a prevailing moisture excess, therefore in order to timely remove excess water from arable lands, the drainage systems have long been installed. In order to drain excess water people used to dig trenches, to regulate (deepen or straighten) natural streams. The length of regulated streams has reached 46,000 km and they are deteriorated ecosystems. Investigations showed that the self-purification of streams from nitrates and phosphates is more effective in natural stretches than in stretches regulated for drainage purposes. Decrease in the average concentration of nitrates in natural and regulated stretches are 8.8 ± 5.0 and 3.0 ± 2.9 mg ${\mathrm{NO}}_3^{-}$ L⁻¹, respectively. The average coefficient of nitrate self-purification, at a confidence level of 95% in natural stream stretches is 0.50 ± 0.22, and in regulated is −0.15 ± 0.21 km⁻¹, and this difference is essential. The change in the average concentration of phosphates in natural and regulated stretches is almost the same, 0.2 ± 0.1 and 0.2 ± 0.2 mg ${\mathrm{PO}}_4^{3-}$ L⁻¹, respectively. The average coefficient of phosphate self-purification, at a confidence level of 95%, in natural stream stretches is 0.28 ± 0.12, in regulated −0.14 ± 0.12 km⁻¹, and this difference is not essential. In terms of the need for the renovation of drainage systems it is suggested that soft naturalization measures are first applied in the streams of Western (Samogitian) Highlands, Coastal Lowlands, and South-Eastern Highlands to improve their self-purification processes. Full article

The Early Medieval Fossa Carolina is the first hydro-engineering construction that bridges the Central European Watershed. The canal was built in 792/793 AD on order of Charlemagne and should connect the drainage systems of the Rhine-Main catchment and the Danube catchment. In this study, we show for the first time, the integration of Airborne LiDAR (Light Detection and Ranging) and geoarchaeological subsurface datasets with the aim to create a 3D-model of Charlemagne’s summit canal. We used a purged Digital Terrain Model that reflects the pre-modern topography. The geometries of buried canal cross-sections are derived from three archaeological excavations and four high-resolution direct push sensing transects. By means of extensive core data, we interpolate the trench bottom and adjacent edges along the entire canal course. As a result, we are able to create a 3D-model that reflects the maximum construction depth of the Carolingian canal and calculate an excavation volume of approx. 297,000 m³. Additionally, we compute the volume of the present dam remnants by Airborne LiDAR data. Surprisingly, the volume of the dam remnants reveals only 120,000 m³ and is much smaller than the computed Carolingian excavation volume. The difference reflects the erosion and anthropogenic overprint since the 8th century AD. Full article

The implementation of sustainable urban drainage systems (SUDS) is increasing due to their advantages, which transcend runoff control. As a result, it is important to find the appropriate SUDS locations to maximize the benefits for the watershed. This study develops a multiscale methodology for consolidated urban areas that allows the analysis of environmental, social, and economic aspects of SUDS implementation according to multiple objectives (i.e., runoff management, water quality improvements, and amenity generation). This methodology includes three scales: (a) citywide, (b) local, and (c) microscale. The citywide scale involves the definition of objectives through workshops with the participation of the main stakeholders, and the development of spatial analyses to identify (1) priority urban drainage sub-catchments: areas that need intervention, and (2) strategic urban drainage sub-catchments: zones with the opportunity to integrate SUDS due the presence of natural elements or future urban redevelopment plans. At a local scale, prospective areas are analyzed to establish the potential of SUDS implementation. Microscale comprises the use of the results from the previous scales to identify the best SUDS placement. In the latter scale, the SUDS types and treatment trains are selected. The methodology was applied to the city of Bogotá (Colombia) with a population of nearly seven million inhabitants living in an area of approximately 400 km². Results include: (a) The identification of priority urban drainage sub-catchments, where the implementation of SUDS could bring greater benefits; (b) the determination of strategic urban drainage sub-catchments considering Bogotá’s future urban redevelopment plans, and green and blue-green corridors; and (c) the evaluation of SUDS suitability for public and private areas. We found that the most suitable SUDS types for public areas in Bogotá are tree boxes, cisterns, bioretention zones, green swales, extended dry detention basins, and infiltration trenches, while for private residential areas they are rain barrels, tree boxes, green roofs, and green swales. Full article
