The Super-Twisting Sliding Mode Controller (STSMC) is regarded as one of the most straightforward and most practical nonlinear control systems, due to its ease of application in industrial systems. Its application helps minimize the chattering problem and significantly improves the resilience of the system. This controller possesses multiple deficiencies and issues, as its use does not promote the expected improvement of systems. To overcome these shortcomings and optimize the efficiency and performance of this technique, a new method is suggested for the super-twisting algorithm (STA). This study proposes and uses a new STA approach, named the fast super-twisting algorithm (FSTA), utilized the conventional IFOC technique to mitigate fluctuations in torque, current, and active power. The results from this suggested the IFOC-FSTA method are compared with those of the traditional SMC and STA methods. The results obtained from this study demonstrate that the suggested method, which is based on FSTA, has outperformed the traditional method in terms of ripple ratio and response dynamics. This demonstrates the robustness of the proposed approach to optimize the generator performance and efficiency in the double-fed induction generator-based wind system. Full article

The present study investigates the control strategy of a novel doubled-fed induction generator (DFIG) with a series grid-side converter (SGSC) during grid faults. The rotor-side inverter is subject to a control strategy derived from the Model Predictive Current Control (MPCC) theory, which is implemented during periods of fault occurrence; for the series grid-side converter, the positive and negative sequence component control is implemented during both steady state and fault periods to enhance system stability and performance. The proposed coordinated control strategy is implemented on a doubly fed turbine with SGSC, while taking into account different degrees of symmetric and asymmetric faults to further evaluate the efficacy of the proposed method. The results of the simulations demonstrate the efficacy of the model-predictive current control scheme applied to the rotor-side converter under conditions of asymmetric faults. This enables the suppression of a range of phenomena, including rotor overcurrent, stator overcurrent, and overvoltage, electromagnetic torque ripple, and DC bus voltage during low-voltage ride-through (LVRT), among others. The present study confirms the viability of implementing positive and negative sequences of voltage separation control in the SGSC during both grid faults and steady state. This approach is expected to minimize the switching of SGSC control strategies and thereby reduce output power fluctuations. The Rotor Side Converter (RSC) and SGSC can perform coordinated control during faults, and the proposed method is able to improve low-voltage ride-through performance compared to existing methods, thereby preventing damage to the converter under multiple fault conditions. Full article

Existing approaches insufficiently analyze the quantitative relationship between frequency stability indices and wind power penetration rates. This limitation impedes rapid and accurate assessments of wind power’s grid integration potential. This paper first analyzed the impact mechanism of wind power integration on system inertia and static power-frequency characteristics from different aspects of the influence of double-fed induction generators (DFIGs) on the operating modes of synchronous machines. Subsequently, based on this analysis, the paper derived the quantitative relationship between key indicators reflecting transient frequency response characteristics during power shortages and wind power penetration rates. It also rapidly calculated the maximum wind power penetration rate based on constraints of frequency change rate and maximum frequency deviation, thereby enabling a quantitative evaluation of wind power grid connection capability. Finally, the IEEE 39-bus test system was used for case analysis. The research results indicate that the proposed method can accurately quantify the impact of wind power variation on system frequency stability and rapidly determine the maximum wind power penetration rate to ensure frequency stability, thereby improving the accuracy of the wind power grid connection capability assessment. Full article

Power network codes necessitate that any renewable source aligns with LVRT rules and assists in voltage restoration during voltage dips. This paper focuses on increasing the low-voltage ride through capability of a doubly fed induction generator-based wind turbine. Three different controllers are discussed in this article. The first is based on robust super-twisting sliding mode control, which is a recent robust control technique. The second uses a new metaheuristic optimizer called the Arctic Puffin optimizer (APO), and the third relies on the traditional PI controller. The grid-side converter sustains the potential of the DC converter link and the regulation of both the active and reactive power supplied to the power grid via three controllers. The rotor-side converter regulates the generator’s electromagnetic torque via two controllers. Doubly fed induction generator control is a challenging task as the two converters have five controllers, and it is vital to specify the ideal parameters for each controller. In the case of super-twisting sliding mode control, the APO is utilized to obtain the sliding surfaces needed for the five controllers. Moreover, the APO is exploited to obtain the optimal constants of the suggested PI regulators. The simulation results prove the excellent performance of both super-twisting- and APO-based controllers, with better performance demonstrated with super-twisting sliding mode control, which demonstrates excellent transient performance with the least overshoot among the three controllers. The super-twisting-based controller has a distinct feature, as it has good performance with parameter variations. Full article

Current transient stability analysis of power systems with doubly fed induction generators (DFIGs) draws upon the assumption that nodal electromagnetic power equals to zero during the fault period. The omission of electromagnetic power degrades the fidelity of transient stability analysis and renders the analytical impact of fault location on stability indiscernible. To address this limitation, a DFIG-integrated power system-oriented transient stability mechanism analysis method is proposed involving fault location factors. Firstly, a foundational analysis model is established by integrating a simplified DFIG representation with the improved DC power flow corrected by the fault’s instantaneous short-circuit voltage. Secondly, the non-metallic symmetrical short-circuit fault is equivalently treated as a power injection source, and the faulted electromagnetic power of generators is derived. The proposed equivalence is roughly correct, as its faulted energy integral is validated to approximate ground-truth. Lastly, combining the above analytical formulas and extended equal area criterion (EEAC), a time-domain simulation-free explicit transient stability criterion incorporating fault location factor is settled. Simulation results in a double-generator system with DFIG integration confirm that, compared to existing transient stability criterion, the proposed criterion can expand the stability assessable area by approximately 10% while maintaining accuracy. Full article

This work analyzes high-power wind turbines (WTs) from the Oravita region, Romania. These WTs are based on slip ring induction generator with wound rotor and we propose a modified architecture with two power converters on both the stator and on the rotor, functioning at variable wind speeds spanning a large interval. Investigations developed around a realistic WT model with doubly fed induction generator show how WT control enables variable wind speed operations at optimal mechanical angular speed (MAS), guaranteeing maximal power point (MPP), but only up to a critical wind speed value, after which the electrical power must saturate for reliable operation. In this reliable operating region, blade pitch angle control must be enforced. Variable wind speed acts as a time-varying parameter disturbance but also imposes the MPP operation setpoint in one of the two analyzed regions. To achieve null tracking errors, a double integrator must appear within the MAS controller when the wind speed disturbance is realistically modeled as a ramp-like input; however, inspecting the linearized model reveals several difficulties as described in the paper, together with the proposed solution tradeoff. The study developed around the Fuhrlander-FL-MD-70 1.5[MW] WT model shows that several competitive controllers are designed and tested in the identified operating regions of interest, as they validate the reliable and performant functioning specifications. Full article

The significance of low voltage ride-through (LVRT) capability in wind energy conversion systems (WECSs) is paramount for ensuring grid stability and reliability during voltage dips. This systematic review delves into the advancements, challenges, and methodologies associated with LVRT capabilities in WECSs. By synthesizing recent research findings, this review highlights technological innovations, control strategies, and regulatory requirements that influence LVRT performance. Key insights include the efficacy of various LVRT techniques, the role of grid codes in shaping LVRT standards, and the integration of advanced control algorithms to improve system resilience. The study offers a comprehensive understanding of the current landscape of LVRT in WECSs and pinpoints future research directions to optimize their performance in increasingly complex grid environments. During the LVRT process, the stator of a double-fed induction generator (DFIG) is directly linked to the power grid. When the external power grid experiences a failure, the stator flux produces a significant transient component, resulting in substantial overvoltage and overcurrent on the rotor side of the DFIG. Failure to implement preventative measures may result in damage to the converter, therefore compromising the safety and stability of how the power system functions. Full article

In the speed-sensorless vector control of induction motors (IMs), the speed estimation accuracy suffers from the deteriorated current measurement caused by the current sensor faults, such as open circuit in one phase, DC bias, and odd harmonics. In this paper, a novel speed estimation strategy based on the current sensor fault-tolerant control is proposed to improve the speed estimation accuracy under the current sensor faults. First, to detect the current sensor faults in real time, the sequential probability ratio test is introduced to the system by using the innovations of the extended Kalman filter (EKF). Second, to ensure speed estimation accuracy, a double-cascading second-order generalized integrator (DSOGI) is employed to reconstruct the faulty current information when a fault is identified. Finally, the reconstructed current information is fed back to the sequential probability extended Kalman filter (SPEKF), which estimates the rotor speed of the IM, and high-accuracy speed estimation under the condition of current sensor faults is achieved. The effectiveness of the proposed strategy is validated by a series of experiments, which were conducted on a 3 kW induction motor drive platform. Full article

To address the challenge of wind turbines meeting primary frequency regulation requirements, incorporating energy storage devices to handle most of the frequency regulation tasks would result in increased operational costs. When a wind turbine rotor accelerates, it deviates from the maximum power tracking point (MPPT), leading to reduced output while retaining significant rotational kinetic energy. Based on this characteristic, a primary frequency regulation strategy is proposed that coordinates the rotor kinetic energy of a double-fed induction generator (DFIG) with supercapacitors (SCs). Supercapacitors provide power support during low-frequency conditions, while accelerating the wind turbine rotor reduces output during high-frequency conditions. Additionally, continuous attention is given to subsequent frequency changes. In case of short-term, low-frequency conditions, stored kinetic energy is released for power support, establishing a mechanism for wind turbine kinetic energy recovery and release. This mechanism reduces charging and discharging requirements for supercapacitors, extends their service life, and considers both wind turbine frequency regulation requirements and economy. Finally, using MATLAB 2020/Simulink platform allows for the verification of the effectiveness and rationality of this proposed method. Full article

This article presents a second-order adaptive fuzzy logic controller (SO-AFLC) to improve the performance of a grid-connected double-fed induction generator (DFIG) in an oscillating water column power plant (OWCPP). The proposed SO-AFLC was used to improve the maximum power point tracking (MPPT), DC link voltage stability, and reactive power tracking for the DFIG oscillating water column power plant. The SO-AFLC reduces oscillations, overshooting, and mean square error. The SO-AFLC improved the mean square error by 40.4% in comparison to the adaptive fuzzy logic controller (AFLC) and by 84.9% in comparison to the proportional–integral differential controllers (PIDs). To validate the simulation results, an experimental investigation was performed on the Dspace DS 1104 control board. The SO-AFLC shows a faster response time, reduced undershooting, lower peak overshooting, and very low steady-state error in terms of DC link voltage, rotor speed, and maximum power point tracking. Moreover, the integral absolute error (IAE) index of the oscillating water column turbine was calculated. This index is meant to evaluate the SO-AFLC’s feasibility against the PID and AFLC under the same wave conditions. Full article

With the prevalence of renewable energy sources such as wind power in the power system, analyzing the fault characteristics of systems composed of DFIGs is becoming increasingly important. Therefore, this article analyzes, at first theoretically, the fault characteristics of a doubly fed induction generator (DFIG) during fault periods. It was found that the fault current of the DFIG exhibited the frequency offset phenomenon, which is affected by the depth of voltage dips and can negatively impact traditional distance protection. Furthermore, a method using a dynamic voltage restorer (DVR) based on superconducting magnetic energy storage (SMES) was adopted to compensate for the fault voltage of DFIG, which can mitigate the voltage dips of the DFIG. This method can not only achieve the fault ride through for DFIG but also significantly improve the frequency offset of the fault current during fault periods. Finally, a model composed of a 2.5 MW DFIG-based wind turbine and a 2.5 MW DVR-based SMES was built using a real-time digital simulator (RTDS) platform, and the simulation results showed that the fault stator voltage of DFIG can be compensated at a rated value of 0.69 kV, and the frequency of fault current can be maintained at 50 Hz These results validate the excellent performance of the method in achieving the fault ride through of DFIG and improving the frequency offset of the fault current by comparing multiple type faults while employing different protection methods. Full article

Lack of synchronization between high voltage DC systems linking offshore wind farms and the onshore grid is a natural consequence owing to the stochastic nature of wind energy. The poor synchronization results in increased system disturbances, grid contingencies, power loss, and frequency instability. Emphasizing frequency stability analysis, this research investigates a dynamic coordination control technique for a Double Fed Induction Generator (DFIG) consisting of OWFs integrated with a hybrid multi-terminal HVDC (MTDC) system. Line commutated converters (LCC) and voltage source converters (VSC) are used in the suggested control method in order to ensure frequency stability. The adaptive neuro-fuzzy inference approach is used to accurately predict wind speed in order to further improve frequency stability. The proposed HVDC system can integrate multiple distributed OWFs with the onshore grid system, and the control strategy is designed based on this concept. In order to ensure the transient stability of the HVDC system, the DFIG-based OWF is regulated by a rotor side controller (RSC) and a grid side controller (GSC) at the grid side using a STATCOM. The devised HVDC (MTDC) is simulated in MATLAB/SIMULINK, and the performance is evaluated in terms of different parameters, such as frequency, wind power, rotor and stator side current, torque, speed, and power. Experimental results are compared to a conventional optimal power flow (OPF) model to validate the performance. Full article

The converter is an important component of a wind turbine, and its control system has a significant impact on the dynamic output characteristics of the wind turbine. For the double-fed induction generator (DFIG) converter, the control parameter identification method is proposed. In this paper, a detailed dynamic model of DFIG with the converter is built, and the trajectory sensitivity method is used to study the observation points that are sensitive to the change of control parameters as the observation quantity for control parameter identification; the Whale Optimization Algorithm (WOA) is used to study the converter control system parameters that dominate the output characteristics of DFIG in the dynamic full-process simulation. To validate the proposed method, four classical test functions are used to verify the effectiveness of the algorithm, and the control parameters are identified by setting a three-phase grounded short-circuit fault under maximum power point tracking (MPPT), and the identification results are compared with particle swarm optimization (PSO) and chaotic particle swarm optimization (CPSO) to show the superiority of the proposed method. The final results show that the proposed WOA can identify the control system parameters faster and more accurately. Full article

Computer modelling and digitalization are integral to the wind energy sector since they provide tools with which to improve the design and performance of wind turbines, and thus reduce both capital and operational costs. The massive sensor rollout and increase in big data processing capacity over the last decade has made data collection and analysis more efficient, allowing for the development and use of digital twins. This paper presents a methodology for developing a hybrid-model-based digital twin (DT) of a power conversion system of wind turbines. This DT allows knowledge to be acquired from real operation data while preserving physical design relationships, can generate synthetic data from events that never happened, and helps in the detection and classification of different failure conditions. Starting from an initial physics-based model of a wind turbine drivetrain, which is trained with real data, the proposed methodology has two major innovative outcomes. The first innovation aspect is the application of generative stochastic models coupled with a hybrid-model-based digital twin (DT) for the creation of synthetic failure data based on real anomalies observed in SCADA data. The second innovation aspect is the classification of failures based on machine learning techniques, that allows anomaly conditions to be identified in the operation of the wind turbine. Firstly, technique and methodology were contrasted and validated with operation data of a real wind farm owned by Engie, including labelled failure conditions. Although the selected use case technology is based on a double-fed induction generator (DFIG) and its corresponding partial-scale power converter, the methodology could be applied to other wind conversion technologies. Full article

The modular multilevel converter (MMC) has become a very promising technology for long-distance and large-capacity transmission of offshore wind power. However, both sides of the AC transmission line at the sending end are controllable electronic power devices, resulting in difficulty in fault identification and inapplicability of traditional differential protection schemes. In order to solve this problem, a wave-similarity-based protection scheme is proposed for AC transmission line faults. Firstly, the symmetrical and asymmetrical fault current characteristics of the double-fed induction generator (DFIG) and MMC are studied, indicating that the fault current characteristics are obviously different from the synchronous units. Secondly, the wave-similarity-based protection scheme is proposed based on the different wave forms of the fault currents of the MMC and DFIG. When the similarity coefficient is less than the margin coefficient, there is a fault in this phase. Moreover, the proposed wave-similarity-based protection scheme can identify all types of short-circuit faults correctly and is not affected by the transition resistance. Finally, simulations of an MMC-HVDC system with offshore wind farms are conducted to validate the effectiveness and correctness of the proposed protection scheme. Full article
