A low-complexity Hall-based measurement system implementing a dark/illuminated differential estimator of the majority-carrier photoconductive response is assessed on n-type crystalline silicon wafers with contrasting doping concentrations. The setup combines a Van der Pauw configuration, permanent neodymium magnets, a characterized white LED source, and a source–measure unit to extract an apparent Hall-derived differential indicator—not a calibrated majority-carrier density—under dark and illuminated steady-state conditions. At $1.81\mathrm{mW}{\mathrm{cm}}^{-2}$, the lightly doped wafer ($N_D\approx {10}^{14}{\mathrm{cm}}^{-3}$) shows a resolved response ($\Delta {\sigma }_{n,H}=29.61\pm 3.406\mathrm{mS}{\mathrm{cm}}^{-1}$), reported as mean ± sample standard deviation from 15 dark/light cycles. The heavily doped wafer ($N_D\approx {10}^{17}{\mathrm{cm}}^{-3}$) gives a nominal below-threshold response ($\Delta {\sigma }_{n,H}=1.167\pm 0.140\mathrm{mS}{\mathrm{cm}}^{-1}$) from the same cycling protocol; it should be interpreted only as an unresolved trend-level indication because it lies below the instrumental detection threshold. The contrast is qualitatively consistent with the expected doping dependence, but no quantitative performance ratio is claimed for the heavily doped wafer. A Macdonald–Cuevas comparison is used only as a qualitative physical-consistency benchmark. No independent QSSPC, SSPC, $\mu$-PCD, or carrier-resolved photo-Hall measurement was available for the same wafers; therefore, the system serves as a complementary low-cost screening tool for comparative trend analysis, not a replacement for calibrated photoconductance or photo-Hall techniques, and it does not constitute a new measurement principle. Full article

Sustainable and circular materials for renewable energy applications are essential for reducing the life-cycle burdens of photovoltaic (PV) power plants and improving the resource efficiency of low-carbon energy infrastructure. This study assesses the material-related environmental performance of an existing 2 MW mono-crystalline silicon (sc-Si) photovoltaic power plant in northern Poland and a prospective perovskite solar cell (PSC) module scenario modelled as an equivalent system with the same location, installed capacity, and annual electricity output. The functional unit was defined as 2000 MWh of electricity delivered annually. A cradle-to-grave life cycle assessment (LCA) was performed in SimaPro 9.4.0 using the ReCiPe 2016 method, complemented by an Intergovernmental Panel on Climate Change (IPCC)-based greenhouse gas assessment. The inventory included photovoltaic modules, support structures, electrical installations, inverter stations, and transformers, with landfill and recycling-oriented material recovery considered as alternative post-consumer management strategies for materials after the end of the technical facility’s life. The results show that material-intensive upstream production stages and key balance-of-system components are major contributors to life-cycle impacts, while recycling can reduce selected burdens through material recovery and avoided production of primary materials. These recycling benefits were modelled using material-specific recovery rates and avoided-production credits assigned only to recovered fractions assumed to meet secondary material quality requirements. Under the adopted modelling assumptions, the PSC module scenario indicates potential for lower life-cycle impacts than the sc-Si baseline. For the prospective perovskite module scenario, this potential benefit is conditional on intact encapsulation during operation and controlled collection, separation, and recovery of lead-containing fractions at the end of life. The study demonstrates that material composition, component design, and circular end-of-life management are decisive factors for improving the environmental performance of PV power plants. Full article

The Böhme abrasion test (EN 14157) is widely used to evaluate the wear resistance of natural stones; however, the abrasive powder specified by TS 699 requiring 70–80 wt.% crystalline Al₂O₃ is not commercially available in the Turkish market. Commercially supplied abrasives deviate substantially from both the prescribed chemical composition and the grain-size distribution of TS 699, introducing a recognized but unresolved source of variability in Böhme abrasion measurements. This study evaluates the influence of abrasive type and particle-size distribution on Böhme abrasion performance with the aim of identifying which available abrasive material yields the most reliable and reproducible test results. The emphasis is therefore metrological—on test repeatability and standardization—rather than on ranking the abrasion resistance of the stones. Six natural stones representing contrasting lithologies—four crystalline marbles, one limestone, and one granite—were tested using five abrasive powders: two locally produced natural emery abrasives (Emery-1 and Emery-2), silicon carbide (SiC), white corundum, and brown corundum. Each abrasive was evaluated under both standardized graded conditions prepared in accordance with TS 699 and heterogeneous ungraded conditions reflecting common industrial practice. Chemical analyses confirmed that both emery abrasives deviate markedly from TS 699 specifications, with Al₂O₃ contents (~57.7 wt.%) well below the required range and Fe₂O₃ (~24 wt.%) considerably exceeding the standard limit. Sieve analyses further revealed substantial particle-size deviations in several commercial abrasives. One-way ANOVA demonstrated that abrasive type exerts a statistically significant influence on abrasion performance (F = 8.99, p < 0.05, η² = 0.297). SiC consistently produced the highest abrasion values, followed by corundum-based abrasives, while emery abrasives showed comparatively lower but stable performance. Independent-samples t-tests showed that particle-size grading significantly affected abrasion performance only for brown corundum (p < 0.05), attributable to its markedly elevated coarse particle fraction. Petrographic analysis, XRD, and SEM–EDS characterization of the investigated rocks confirmed that abrasion response is additionally modulated by rock mineralogy and microstructure. Under standardized grading conditions, SiC provided the most consistent and reproducible results across all lithologies, supporting its suitability as the reference abrasive for inter-laboratory Böhme testing. Locally produced emery abrasives, despite their chemical non-compliance with TS 699, yielded stable and reproducible outcomes under controlled grading, supporting their potential as cost-effective alternatives for routine testing. Full article

ZnS is one of the most promising wide-bandgap semiconductors for optoelectronic and sensing applications owing to its efficient ultraviolet–blue emission, high exciton binding energy, and chemical stability. However, the synthesis of ZnS nanocrystals in silicon-compatible porous matrices remains largely unexplored. In this work, ordered arrays of ZnS nanocrystals were synthesized for the first time in SiO₂/Si track templates fabricated by swift heavy ion irradiation followed by selective chemical etching. ZnS nanocrystals were deposited by electrochemical deposition from aqueous solutions containing ZnCl₂ and thiourea precursors. The structural, optical, and electrical properties of the resulting ZnS/SiO₂/Si nanocomposites were investigated using scanning electron microscopy, X-ray diffraction, Raman spectroscopy, photoluminescence spectroscopy, and electrical measurements. The fabricated templates contained vertically aligned pores with a density of approximately 10⁸ cm⁻² and an average diameter of about 500 nm. Electrochemical deposition resulted in a pore filling efficiency of approximately 88%. X-ray diffraction analysis confirmed the formation of crystalline ZnS with a cubic zinc blende structure. The nanocomposites exhibit intense ultraviolet–blue photoluminescence in the 335–477 nm range, with pronounced emission peaks at 372 and 400 nm characteristic of ZnS nanocrystals. Current–voltage measurements indicate predominantly electronic conductivity, with a conductivity of 1.54 × 10⁻⁶ Ohm⁻¹·cm⁻¹, comparable to values reported for polycrystalline ZnS films. To support the experimental observations, the electronic structure of ZnS was analyzed using density functional theory within the LCAO framework. The calculated bandgap of 3.4 eV is consistent with previously reported theoretical and experimental data. The obtained results demonstrate that SiO₂/Si track templates provide a promising platform for the fabrication of ordered ZnS nanoarrays with potential applications in silicon-compatible optoelectronic and sensing devices. Full article

Traditional tunable Bragg waveguide grating filters, which rely on thermo-optic or carrier effects, often face limitations such as high energy consumption, low tuning efficiency, and difficulty in achieving independent multi-parameter control. To overcome these bottlenecks, this work proposes a novel optical waveguide filter based on the heterogeneous integration of silicon nitride and the phase-change material Sb₂Se₃. The device leverages the substantial refractive index contrast between crystalline and amorphous states of Sb₂Se₃ to construct a programmable Bragg grating within the thin film layer. This is realized through laser-induced phase transition method, enabling nonvolatile manipulation of the light field. Simulation results indicate that the independent tuning of central wavelength over 19.2 nm range was achieved by adjusting the grating width and ripple width simultaneously. Likewise, the extinction ratio could be independently controlled over 22.3 dB through coordinated adjustments of the grating length and position shift. Beyond its tuning capabilities, the proposed device theoretically exhibits exceptional performance characteristics, including an ultra-low insertion loss of 0.1 dB and strong side lobe suppression. These advantages highlight the potential of this approach to provide a low energy consumption, multifunctional solution for integrated photonic devices, offering a promising pathway for the next generation of programmable photonic integrated circuits. Full article

Polycrystalline silicon (poly-Si) is a promising channel material for three-dimensional (3D) stacked memory architecture owing to its process compatibility and excellent manufacturability. However, its practical application is hindered by intrinsic limitations, such as reduced carrier mobility and elevated off-state current (I_off), which originate from localized electric fields and trap states at grain boundaries. In this study, the structural characteristics, including the crystallization behavior and grain morphologies, of silicon films deposited by sputtering and low-pressure chemical vapor deposition (LPCVD) were comparatively investigated. Raman spectroscopy and cross-sectional transmission electron microscopy (TEM) results confirmed that LPCVD poly-Si annealed at 800 °C exhibits over 95% crystallinity and a columnar-like grain structure. Based on this structural superiority, transistor-level electrical characterizations were exclusively conducted on LPCVD-based devices. The results show that the I_off of annealed poly-Si depends on the channel width, with normalized I_off values being lower when the channel is narrower than the average grain size. Further, a larger grain size with a columnar structure in poly-Si can maintain acceptable I_off levels in 3D stacked memory devices incorporating narrow channel widths. Full article

The present study investigates the application of electric resistive heating to photovoltaic (PV) panels, aimed at enabling their subsequent thermo-mechanical delamination. The key process parameters—namely current magnitude and applied voltage—required for direct electro-resistive heating are identified, and the process is experimentally demonstrated under laboratory conditions. The electric resistive heating of a composite photovoltaic panel, consisting of a solar cell layer (crystalline silicon, c-Si, with a metallic grid), a backsheet, and a glass layer, is analyzed in detail using a virtual model of a single-crystal silicon solar cell implemented as coupled electric-thermal analysis. The temperature dependence of the electrical resistance of the solar cell layer is experimentally measured, and exponential relationships are derived and subsequently incorporated into the numerical model. The virtual model results are validated, demonstrating that, for a given geometry and configuration of the conductive metallic grid (busbars and fingers), the electrical resistance of the semiconductor layer containing the p–n junction governs the temperature achieved during electro-resistive heating as a function of the applied current. Furthermore, results for the terminal current and voltage, current density in the busbars and fingers, electric field intensity, and the resulting temperature within the semiconductor layer of the single-crystal silicon solar cell are presented and analyzed. Full article

The rapid expansion of solar photovoltaic (PV) deployment has led to increasing concerns regarding end-of-life module management and the sustainability of material supply chains, where waste volumes are projected to reach 3.3–5.6 million tons by 2045. This study evaluates the environmental and economic impact of advanced photovoltaic recycling in Germany, focusing on high-value material recovery from crystalline silicon modules. A Full Recovery of End-of-Life Photovoltaics (FRELP) pathway is developed, integrating light-pulse delamination and molten salt etching, and a comparative life cycle assessment and economic assessment framework is applied. The results indicate that advanced recycling achieves high recovery rates for silicon, silver, aluminum, copper and low-iron glass, yielding around €1174.88 per ton of panels recycled. Economic analysis shows that manufacturing PV modules from recycled materials reduces costs by approximately 60–77% compared to virgin material production, mainly due to avoided energy-intensive upstream processes. From an environmental perspective, the recycling-based pathway yields net benefits across impact categories, as avoided impacts from primary material extraction outweigh additional burdens associated with recycling. Overall, PV recycling in Europe is shown to be environmentally and economically favorable; however, technological maturity and policy constraints remain key barriers to large-scale implementation and a holistic overall recycling process, indicating the need for targeted policy support. Full article

We present a family of compact, programmable wavelength demultiplexers enabled by an etchless silicon nitride platform integrated with the low-loss phase-change material Sb₂Se₃. Using topology optimization (LumOpt) with a p-norm (p = 2) figure-of-merit defined over a 10 nm bandwidth, we design several devices within a common 24 × 24 μm² design region: single-wavelength routers (1530, 1550, 1570, 1590 nm), two-channel (1550/1570 nm), three-channel (1530/1550/1570 nm), and four-channel (1530–1590 nm) coarse wavelength-division demultiplexers, all sharing the same input/output waveguide configuration. Simulation results show that all devices achieve low insertion loss at target wavelengths (peak transmission better than −1.21 dB across all channels), high average transmission over the respective 10 nm bands (typically within 0.1 dB of the peak), and suppressed crosstalk (worst case below −11.52 dB). Leveraging the reversible amorphous-to-crystalline phase transition of Sb₂Se₃ via laser pulses, all devices support post-fabrication reconfiguration, overcoming the static functionality of conventional etched photonic circuits. This work establishes a scalable, software-defined platform that combines inverse design and phase-change materials for high-density, reconfigurable wavelength-routing photonic integrated circuits. Full article

This review evaluates the role of advanced materials in optimizing the efficiency, sustainability, and market integration of solar photovoltaic (PV) technologies. Our work bridges insights from both mature (crystalline silicon (c-Si)) and novel perovskites (PSs), organic photovoltaics (OPVs), and quantum dot solar cell (QDSC) materials, thereby providing a unified view of the present and the future of PV research. We highlight the key breakthroughs for the different material classes, describing their unique features, record performance, and contribution to lowering the cost of solar energy. In particular, while some progress has been made, we recognize that challenges such as the stability of the device under varying environmental conditions, the environmental impact of the materials, and the scalability of the manufacturing processes are still there. In conclusion, we give an overview of the research topics that can pave the way for the future. We support the formation of hybrid structures, the finding of lead-free alternatives, multi-junction architectures, and integrated solutions that not only help to overcome the current limitations but also facilitate the global energy transition. Full article

The efficiency of perovskite solar cells has increased to a certified value of 27% over the past decade, benefiting from the superior properties of metal halide perovskite materials. However, their long-term operational stability is still far inferior to that of commercial crystalline silicon solar cells. A key source of this instability is field-driven ion migration in vertical architectures, along with the consequent degradation at the absorber–electrode interfaces. Compared with the widely investigated vertical structures, back-contacted (BC) perovskite solar cells—wherein both electrodes are positioned on the same side of the absorber—offer a unique route to suppress interfacial ion migration and thereby enhance long-term device stability. These advantages are especially pronounced when combined with single-crystal perovskites, which possess low charge trap densities, long carrier diffusion lengths, and high bulk ion migration barriers. Unfortunately, only a handful of research groups have participated in the development of single-crystal BC perovskite solar cells; thus, the advancement of this area lags far behind that of its vertical counterpart. Therefore, a review that discusses the recent developments and challenges of single-crystal BC perovskite solar cells is urgently required to provide guidelines for this emerging field. In this progress report, we first introduce the main growth methods of single-crystal wafers compatible with BC architectures, followed by an outline of the developmental history of BC perovskite solar cells. Finally, the core bottlenecks facing single-crystal BC devices and corresponding optimization strategies are discussed in detail. Full article

In this study, cathodic arc deposition was employed to synthesize CrAlN/TiSiN nanostructured multilayer coatings on silicon wafer substrates. The effects of the multilayer architecture on the microstructure and corrosion resistance of the coatings were systematically investigated. The structural characteristics and performance of the deposited films were analyzed using scanning electron microscopy (SEM), energy-dispersive spectroscopy (EDS), X-ray diffraction (XRD), and electrochemical polarization measurements. The experimental results demonstrate that various CrAlN/TiSiN multilayer configurations were successfully deposited, forming dense multilayer coatings with a thickness of approximately 1–2 μm and a dominant FCC β₁-NaCl crystalline structure. The presence of nanostructured multilayer interfaces effectively inhibited columnar grain growth and contributed to microstructural refinement. XRD analysis revealed competitive growth between the (111) and (200) crystallographic orientations, indicating that the crystallization behavior is influenced by the interplay between surface energy minimization and strain energy accumulation. Contact angle measurements showed that all the coatings exhibited water contact angles exceeding 90°, indicating hydrophobic characteristics and potential anti-fouling capacity. In particular, the CrAlN outer layer structure presented lower surface free energy, which further enhances the coating system’s anti-fouling capacity. Electrochemical polarization results indicate that the corrosion current density of all the coatings remained in the order of 10⁻⁷ A/cm², demonstrating excellent chemical stability. Overall, the CrAlN/TiSiN nanostructured multilayer coatings exhibit pronounced interface strengthening and densification growth mechanisms, which effectively enhance the chemical stability of silicon-based material surfaces. These results could provide valuable insights for the structural design and optimization of high-performance protective coatings. Full article

Gallium oxide is an ultra-wide bandgap semiconductor with excellent opto-electronic properties, making it a highly promising material for a wide range of applications and devices. In this article, we report how the optical, morphological, structural, and compositional properties of $\beta$-Ga₂O₃ thin films deposited by RF Sputtering on silicon substrates are affected by thermal treatments. Ellipsometric spectra recorded at multiple angles of incidence from several samples subjected to thermal annealing in the range of 550–1000 °C were analyzed to extract the optical functions using appropriate multilayer models. This analysis is complemented by compositional, structural, and morphological characterization techniques. We observed two main stages of crystallization with increasing annealing temperature; up to 700 °C, there is an increase in density and then, for 700–1000 °C, there is an improvement in crystallinity. While the refractive index increases continuously throughout this process, we found that the polarizability of the samples decreases in the first stage and increases in the second. These observations demonstrate that thermal treatments are a powerful tool to tune the optical properties of Ga₂O₃ thin films for device applications. Full article

This article focuses on the research and development of innovative polymer-concrete composites for the manufacture of precision machine tool frames and critical mechanical engineering components. The relevance of this work stems from the need to replace traditional cast iron and cement concrete with materials with superior damping properties and thermal stability. The polymer matrix used in this study was ED-20 epoxy-diane resin, modified with (FAM) furan resin and cured with polyethylenepolyamine (PEPA), which together ensured minimal linear shrinkage (less than 0.5–1%) during polymerization. The focus was on the effect of multimodal filler distribution, including quartz sand, gabbro, and basalt, as well as reinforcing additives such as silicon carbide and fiberglass, on the final performance characteristics of the material. Experimental studies determined the key physical and mechanical parameters of the obtained samples. The results showed that the optimized composition (Smp_001) exhibited compressive strength up to 92.3 MPa, significantly exceeding that of standard high-strength concrete. It was established that the use of silicon carbide and glass fiber promotes the formation of a dense heterogeneous microstructure characterized by extremely low porosity (1.2–2.5%) and record-low water absorption (less than 0.05%). These characteristics guarantee high dimensional stability of the frames during prolonged contact with process fluids and cutting fluids. The scanning electron microscopy (SEM) and (EDS) energy dispersive X-ray spectroscopy methods confirmed the dense packing and high degree of interaction of the polymer matrix with the crystalline phases of the filler. This condition of the interfacial boundaries guarantees stable stress transfer throughout the entire volume of the material, which minimizes the risk of local damage during operation. The study confirmed that the developed material has vibration damping properties 6–10 times more effective than gray cast iron, a critical factor in improving machining accuracy on modern metal-cutting machines. The scientific novelty of the study lies in its substantiation of the synergistic effect of the combined use of basalt fillers and silicon carbide to achieve the precision properties of a structural material. Its practical significance is confirmed by the possibility of producing large-scale parts by casting without the need for complex finishing, opening up new prospects for modernizing the machine tool industry. Full article

Pulsed laser-induced phase change in silicon underpins applications from photonic device trimming to stealth dicing, yet predictive models that capture the non-equilibrium kinetics governing the competition between epitaxial recrystallization and amorphization remain limited. In this work, we developed a two-dimensional axisymmetric numerical model at the continuum level for picosecond laser-induced melting, resolidification, and amorphization of crystalline silicon at 532 nm laser wavelength, coupling transient heat conduction with Wilson–Frenkel interface kinetics and Lagrangian marker-based interface tracking. The model predicts a bounded amorphization window defined by lower and upper fluence thresholds, within which the central amorphous thickness exhibits a bell-shaped fluence dependence. Under a Gaussian beam, this window governs a morphological transition from a central amorphous spot to an amorphous ring. The predicted amorphization threshold of ≈0.22 J/cm² agrees with published experimental data for 20 ps, 532 nm irradiation. Parametric studies reveal that reducing the spot diameter or substrate temperature shifts or eliminates the upper threshold, transforming the bounded window into a monotonically increasing function, while increasing the pulse duration narrows the window symmetrically until collapse. These results provide quantitative guidelines for selecting irradiation parameters to control phase change in silicon photonic and laser processing applications. Full article
