Search Results (28)

This study presents a novel surface acoustic wave (SAW)-based solar-blind ultraviolet-C (UV-C) corona sensor, marking the first reported use of HfO₂ as a sensing material for UV-C corona sensing. A 222 MHz two-port SAW delay line structure was selected as a sensor platform, and its optimal parameters were determined through Coupling of Mode (COM) modeling analysis. COMSOL simulations were conducted to investigate the effect of UV-C exposure on the HfO₂ thin film, highlighting its contribution to conductivity changes. A 30 nm-thick HfO₂ thin film was deposited using atomic layer deposition (ALD) within the cavity of a two-port SAW delay line, providing sufficient volume and density of absorption sites for UV-C exposure. Comprehensive material characterization of the HfO₂ thin film was performed using X-ray diffraction (XRD), scanning electron microscopy (SEM), and energy-dispersive X-ray spectroscopy (EDS). The effect of annealing temperature was analyzed in detail, with results confirming that 500 °C is the optimal temperature for achieving the best performance in a SAW-based UV-C corona sensor. The sensor characteristics were measured using custom-made interface electronics, allowing frequency shifts to be visually observed on a PC monitor with compensation for environmental factors such as humidity and temperature. The developed sensor demonstrated response and recovery times of 2.8 s and 4 s, respectively, with a measured sensitivity of 563 ppm/(mW·cm⁻²). Furthermore, the effect of HfO₂ film thickness on the sensor’s response to UV-C exposure was examined in detail, showing that increased thickness leads to a higher frequency shift, thereby enhancing sensitivity. The feasibility of the sensor for real-world applications was validated through successful testing under simulated corona discharge detection. Full article

In cell or droplet separation, high acoustic wave energy of a surface acoustic wave (SAW) device is required to generate sufficient acoustic radiation force. In this paper, the electrode width-control floating electrode focused unidirectional interdigital transducer (EWC-FEFUDT) is proposed due to its enhanced focusing properties. The performance of the EWC-FEFUDT is investigated using the Coupling-of-Mode (COM) theory, and the COM parameter is extracted using the Finite Element Method (FEM). The four different forbidden band edge frequencies account for the unidirectionality of the proposed EWC-FEFUDT. A direction angle of ${\varphi }_{\kappa }-{\varphi }_{\zeta }=44.5°$ of the EWC-FEFUDT (Design 3) is obtained, being fairly close to the optimum value of 45°. The EWC-FEFUDT (Design 3) has a lower insertion loss (IL) of −5.1 dB and greater unidirectionality (20 × log₁₀($D$) = 13.8 dB). The SAW maximum amplitude of the EWC-FEFUDT (Design 3) is increased by about $1.5\times 10^{-4} \mu \mathrm{m}$ compared to that of the focused interdigital transducers (FIDTs). The maximum acoustic pressure of the EWC-FEFUDT is an order of magnitude higher than that of FIDTs. The EWC-FEFUDT exhibits enhanced focusing properties. The proposed EWC-FEFUDT may provide an alternative method for cell or droplet separation in an efficient manner. Full article

In this work, a surface acoustic wave (SAW) temperature sensor based on a quartz substrate was designed and investigated. Employing the Coupling-of-Modes (COM) model, a detailed analysis was conducted on the effects of the number of interdigital transducers (IDTs), the number of reflectors, and their spacing on the performance of the SAW device. The impact of the transversal mode of quartz SAWs on the device was subsequently examined using the finite element method (FEM). The simulation results indicate that optimizing these structural parameters significantly enhances the sensor’s sensitivity and frequency stability. SAW devices with optimal structural parameters were fabricated, and their resonant frequencies were tested across a temperature range of 25–150 °C. Experimental results demonstrate that the SAW temperature sensor maintains high performance stability and data reliability throughout the entire temperature range, achieving a Bode-Q of 7700. Furthermore, the sensor exhibits excellent linearity and repeatability. An analysis of the sensor’s response under varying temperature conditions reveals a significant temperature dependency on its Temperature Coefficient of Frequency (TCF). This feature suggests that the sensor possesses potential advantages for applications in industrial process control and environmental monitoring. Full article

This paper proposes an improved method to calculate the mutual capacitance between interdigital transducer (IDT) electrodes to enhance the accuracy of the traditional coupling-of-modes (COM) model, which is commonly used to simulate surface acoustic wave (SAW) filters and duplexers. In this method, the boundary element method (BEM) is adopted to obtain the capacitance per unit length in a layered medium, while the partial capacitance (PC) method is used to derive the effective relative permittivity of the multi-layered IDT. Numerical results from commercially available software are provided for comparison with the results calculated using the proposed method. The consistent results verify the validity and accuracy of this method, which also demonstrates significantly faster calculation speed compared to commercially available software. Precise electrical response prediction of a dual-mode SAW (DMS) filter can be achieved by applying this method to the COM model, and this ultra-fast calculation method can also be included in filter design optimization. Full article

Continuous monitoring of vital signs based on advanced sensing technologies has attracted extensive attention due to the ravages of COVID-19. A maintenance-free and low-cost passive wireless sensing system based on surface acoustic wave (SAW) device can be used to continuously monitor temperature. However, the current SAW-based passive sensing system is mostly designed at a low frequency around 433 MHz, which leads to the relatively large size of SAW devices and antenna, hindering their application in wearable devices. In this paper, SAW devices with a resonant frequency distributed in the 870 MHz to 960 MHz range are rationally designed and fabricated. Based on the finite-element method (FEM) and coupling-of-modes (COM) model, the device parameters, including interdigital transducer (IDT) pairs, aperture size, and reflector pairs, are systematically optimized, and the theoretical and experimental results show high consistency. Finally, SAW temperature sensors with a quality factor greater than 2200 are obtained for real-time temperature monitoring ranging from 20 to 50 °C. Benefitting from the higher operating frequency, the size of the sensing system can be reduced for human body temperature monitoring, showing its potential to be used as a wearable monitoring device in the future. Full article

To ensure that surface acoustic wave (SAW) filters fulfill the requirements of Carrier Aggregation (CA) applications, the development of modeling tools that can forecast and simulate high-frequency spurious responses has been necessary. This paper presents an advanced methodology for extending the coupling-of-modes (COM) model to obtain precise modeling of the high-frequency spurious responses of incredible high-performance surface acoustic wave (I.H.P. SAW) devices. The extended COM (ECOM) model is derived by modifying the conventional COM model and extending it accordingly. The parameters used in this model are determined through numerical fitting. For validation, firstly, the ECOM model is applied to a one-port synchronous I.H.P. SAW resonator, and the simulation and measurement results match. Then, the structural parameters of the ECOM model are varied, and the accuracy of the model after the structural parameters are varied is verified. It is demonstrated that this model can be applied to the design work of SAW filters. Finally, the ECOM model is applied to the design of the I.H.P. SAW filter based on a 42°YX-LiTaO₃ (LT)/SiO₂/AlN/Si structure. By using this method, the I.H.P. SAW filter’s high-frequency spurious response can be predicted more accurately. Full article

This paper presents an advanced method that combines coupling-of-modes (COM) theory and the finite element method (FEM), which enables the quick extraction of COM parameters and the accurate prediction of the electroacoustic and temperature behavior of surface acoustic wave (SAW) devices. For validation, firstly, the proposed method is performed for a normal SAW resonator. Then, the validated method is applied to analysis of an I.H.P. SAW resonator based on a 29°YX−LT/SiO₂/SiC structure. Via optimization, the electromechanical coupling coefficient (K²) is increased up to 13.92% and a high quality (Q) value of 1265 is obtained; meanwhile, the corresponding temperature coefficient of frequency (TCF) is −10.67 ppm/°C. Furthermore, a double-mode SAW (DMS) filter with low insertion loss and excellent temperature stability is also produced. It is demonstrated that the proposed method is effective even for SAW devices with complex structures, providing a useful tool for the design of SAW devices with improved performance. Full article

Comparative results of calculation and measurement of the frequency responses of the surface acoustic waves filter on a piezoelectric substrate of 64°YX-cut lithium niobate and delay line on a piezoelectric substrate of 128°YX-cut lithium niobate is presented. The calculation was performed on the basis of two approaches—the finite element method in the COMSOL Multiphysics software and using the model of coupling of modes based on P-matrices. A brief overview and features of each approach are presented. The calculation results based on the two approaches are in good agreement with each other and with the experimental results of measurements of the characteristics of the bandpass filter. The delay line operating with the use of the third harmonic frequency is calculated by FEM. The results showed a good match between numerical simulation and experiment. The considered approaches for designing SAW devices allow us to relatively quickly and accurately predict the frequency responses at the simulation stage, thereby reducing the number of experimental iterations and increasing the efficiency of development. Full article

In this paper, we present how complementary characterization techniques, such as electrical measurements with a vector network analyzer (VNA), optical measurements with a laser Doppler vibrometer (LDV), and numerical simulations with the finite element method, coupled with spectral domain analysis (FEMSDA), allow us to independently access different properties of a SAW device and fully characterize its operation using the coupling-of-modes theory (COM). A set of chemical SAW sensors coated with parylene C layers of different thicknesses (1, 1.5, and 2 µm) and an uncoated sensor were used as test samples. The sensors represent dual-channel electroacoustic delay lines operating in the vicinity of 77 MHz. The IDTs consist of split aluminum electrodes deposited on a AT-cut quartz substrate. The thickness-dependent influence of the parylene C layer was observed on the operating frequency (SAW velocity), static capacitance, attenuation, crosstalk, and reflection coefficient. COM parameters were reported for the four cases considered; measured and simulated data show good agreement. The presented approach is suitable for the design, characterization, and validation of polymer film-coated SAW sensors. Full article

This paper presents a new numerical approach for the full extraction of the coupling-of-modes (COM) parameters by stationary and eigenfrequency analyses in the finite element method (FEM). This is a fast method extracting from the results of static analysis and eigenfrequency analysis. It avoids the long calculation time of admittance frequency response analysis, which is commonly used in extracting COM parameters. In addition to the usual COM parameters (velocity, reflection coefficient, transduction coefficient and capacitance), the phases of reflection and transduction coefficient can be also extracted with this method. The proposed method was applied to different cutting types LiNbO₃ with different types of thicknesses in a varying interdigital transducer (IDT). These examples show that our approach has great potential in extracting all the COM parameters of the Rayleigh SAW for all kinds of IDT structures. Therefore, it is a fast, accurate, general and full extraction approach of COM parameters. Full article

The finite element method (FEM) has been applied to extract the coupling-of-modes (COM) parameters of surface acoustic wave (SAW) devices for a long time. It always involves calculating the dispersive curves or harmonic admittance, which makes the extraction process and results sophisticated, time-consuming and inaccurate. Therefore, a simple method is proposed to extract all COM parameters of the SAW devices rapidly and accurately in this paper. It is based on the FEM and combines the stationary analysis with modal analysis. We have described in detail the basic principles and procedures of the proposed method, and made a comprehensive comparison between the proposed method and the other two existing methods. We have also examined the proposed method by extracting COM parameters of some common SAW substrate, and compared our extracted results with those reported in the other literatures. Results show that our proposed method holds higher accuracy and more efficiency (~s order) than the others (~h order). Moreover, our extracted COM parameters are in an excellent agreement with those reported in the other literatures. Full article

The impact of device parameters, including AlN film thickness (h_AlN), number of interdigital transducers (N_IDT), and acoustic propagation direction, on the performance of c-plane AlN/sapphire-based SAW temperature sensors with an acoustic wavelength (λ) of 8 μm, was investigated. The results showed that resonant frequency (f_r) decreased linearly, the quality factor (Q) decreased and the electromechanical coupling coefficient $\left(K_t^2\right)$ increased for all the sensors with temperature increasing from −50 to 250 °C. The temperature coefficients of frequency (TCFs) of sensors on AlN films with thicknesses of 0.8 and 1.2 μm were −65.57 and −62.49 ppm/°C, respectively, indicating that a reduction in h_AlN/λ favored the improvement of TCF. The acoustic propagation direction and N_IDT did not obviously impact the TCF of sensors, but they significantly influenced the Q and $K_t^2$ of the sensors. At all temperatures measured, sensors along the a-direction exhibited higher f_r, Q and $K_t^2$ than those along the m-direction, and sensors with N_IDT of 300 showed higher Q and $K_t^2$ values than those with N_IDT of 100 and 180. Moreover, the elastic stiffness of AlN was extracted by fitting coupling of modes (COM) model simulation to the experimental results of sensors along different directions considering Euler transformation of material parameter-tensors. The higher f_r of the sensor along the a-direction than that along the m-direction can be attributed to its larger elastic stiffness c₁₁, c₂₂, c₄₄, and c₅₅ values. Full article

Electrode-width-controlled (EWC) single-phase unidirectional transducers (SPUDT) contribute to reduction of insertion loss of surface acoustic wave (SAW) devices due to their strong unidirectional properties. In this work, we propose a method to optimize the unidirectionality of EWC-SPUDT based on our research results that the unidirectionality of the EWC-SPUDT cell is strongly related to its reflectivity and its unidirectional angle. Furthermore, in order to ensure strong unidirectionality to achieve low insertion loss, a simulator based on the finite element method (FEM) is used to study the relationship between geometrical configuration of the EWC-SPUDT cell and its reflection coefficient, as well as its transduction coefficient. Simulation results indicate that the reflection coefficient of the optimized EWC-SPUDT cell composed of 128° YX lithium niobite (LiNbO₃) substrate and Al electrodes with thickness of 0.3μm reaches the optimal value of 5.17% when the unidirectional angle is designed to be −90°. A SAW delay line is developed with the optimized EWC-SPUDT cell without weighing, and the simulation results are verified by experiments. The experimental results show that the directivity exceeds 30 dB at the center frequency and the insertion loss is just 6.7 dB. Full article

A surface acoustic wave (SAW) temperature sensor with high accuracy was developed and wirelessly characterized in this work. The sensing chip with reflective delay line pattern was simulated using typical coupling of modes (COM) model and prepared by the standard photolithographic technique. Sharp reflection peaks with high signal-to-noise (SNR) were observed from the developed sensing chip operating at 433 MHz. Referring to the frequency-stepped continuous wave (FSCW)-based transceiver, planar antennas, and the developed SAW chip, the wireless and passive temperature sensor system was built. Adaptive Least Mean Square (LMS) algorithm was used for the first time in the SAW sensor signal processing to significantly improve the system SNR, and the corresponding phase fluctuation is down to only 3${}^{°}$. High temperature sensitivity of 36.5 ${}^{°}$C and very high accuracy of ±0.2 ${}^{°}$C in the range of −30 ${}^{°}$C∼100 ${}^{°}$C were achieved successfully by wireless measurement. Full article

In order to accurately investigate the disturbance of complex distributed mass loading on surface acoustic wave (SAW) propagation characteristics, two-dimensional coupling-of-modes (2-D COM) theory and finite element method (FEM) were used to simulate the responses of SAW sensors. By using the PDE mode of FEM software, four SAW resonators with the loads in different distribution patterns were modeled. Also, we fabricated and measured a series of SAW resonators accordingly. The results showed that the 2-D COM theory combined with the finite element method was able to simulate the transverse modes of the device and the disturbance of the mass loading on the transverse mode effectively, making the simulation more accurate. Full article
