Search Results (28)

In the present work, the influence of a magnetron-sputtered copper interlayer on the process of electron beam welding of Ti6Al4V and Al6082-T6 plates was investigated. A sample without a filler was also prepared as a control. The microstructure, microhardness, and tensile properties of both samples were determined. Applying a copper interlayer resulted in the formation of an additional CuAl₂ intermetallic compound in the form of a eutectic structure along the boundary of the aluminum crystal grains. A noticeable shift in the preferred crystallographic orientation of the aluminum phase from the denser {111} family of crystallographic planes in the case of the sample prepared without a filler towards less-dense ones such as {110}, {100}, and {311} in the case of applying a copper filler was observed. This was most probably caused by the lower free surface energy of the crystals oriented towards the {111} family of crystal planes, which favored the chemical bonding between the aluminum solid solution and the CuAl₂ intermetallics. As a result of applying the copper interlayer, a noticeable increase in the microhardness of the weld seam was observed from 78 ± 2 HV0.05 to 136 ± 3 HV0.05. Applying a copper interlayer also led to an improved energy absorption capacity of the weld seam, as suggested by the increase in the UTS/YS ratio from 1.03 to 1.44. This could be explained by the smooth transition between the highly dissimilar Ti6Al4V and Al6082-T6 alloys. The UTS of the sample with the copper filler reached 208 MPa, which was about 60% of that of the base Al6082-T6 alloy. Full article

In this paper, we studied the deposition and characterization of monolithic and silver-doped copper coatings using RF magnetron sputtering. The main objective was to examine the impact of different Ag contents on natural and thermally induced aging when compared with monolithic copper coatings. For this purpose, the as-deposited surfaces were left exposed to normal temperature and humidity conditions during one year (natural) and were annealed at 200 °C in a non-controlled atmosphere. To evaluate the results of these treatments, the films were characterized in terms of surface and cross-section morphology, structure, chemical composition, wettability, and surface energy. The as-deposited monolithic copper films exhibit a clear face-centered cubic structure with a very strong preferential crystallographic orientation according to the (111) diffraction plane. The presence of Ag in the as-deposited coatings decreased the ability of the films to be wetted, increasing their hydrophobicity and jeopardizing crystallographic orientation development according to the (111)-Cu diffraction plane, particularly after annealing, when compared to Cu films. Through annealing, Cu₂O and Ag₂O were formed, leading to a significant decrease in surface energy and reduced wettability. These results can help elucidate and estimate the life span of smart windows, batteries, and solar panels, which are some of the many applications for these coatings. Full article

In this study, we conducted a theoretical simulation to compare the effects of various factors on the atomic and electronic structures and the magnetic properties of copper and gadolinium ions bonded to carboxylated species of (111) diamond surfaces. It was experimentally found that in the temperature range above 120 K, the magnetic moments of chelated Gd³⁺ and Cu²⁺ equal 6.73 and 0.981 Bohr magnetons, respectively. In the temperature range from 12 to 2 K, these magnetic moments sharply decrease to 6.38 and 0.88 Bohr magnetons. Specifically, we examined the effects of the number of covalent adatom–diamond substrate bridges, coordination of water molecules, and shallow carbon-inherited spins in the substrate on the physical properties of the metal center. Our simulation predicted that increasing the number of bonds between the chelated metal ion and substrate while decreasing the number of coordinating water molecules corresponded to a decrease in the magnetic moment of metal ions in a metal–diamond system. This is due to the redistribution of the electron charge density in an asymmetric metal–diamond system. By comparing our theoretical results with experimental data, we proposed configurations involving one and, in a minor number of cases, two surface –COO⁻ groups and maximum coordination of water molecules as the most realistic options for Cu- and Gd-complexes. Full article

Designing minimally invasive, defect-free coatings based on conformal graphene layers to shield metals from both abiotic and biotic forms of corrosion is a persistent challenge. Single-layer graphene (SLG) grown on polycrystalline copper (PC-Cu) surfaces often have inherent defects, particularly at Cu grain boundaries, which weaken their barrier properties and worsen corrosion through grain-dependent mechanisms. Here, we report that an SLG grown via chemical vapor deposition (CVD) on Cu (111) single crystal serves as a high-performance coating to lower corrosion by nearly 4–6 times (lower than bare Cu (111)) in abiotic (sulfuric acid) and microbiologically influenced corrosion (MIC) environments. For example, the charge transfer resistance for SLG/Cu (111) (3.95 kΩ cm²) was 2.5-fold higher than for bare Cu (111) (1.71 kΩ cm²). Tafel analysis corroborated a reduced corrosion current (42 ± 3 µA cm⁻²) for SLG/Cu (111) compared to bare Cu (111) (115 ± 7 µA cm⁻²). These findings are consistent with the results based on biofilm measurements. The SLG/Cu (111) reduced biofilm formation by 3-fold compared to bare Cu (111), increasing corrosion resistance, and effectively mitigating pitting corrosion. The average depths of the pits (3.4 ± 0.6 µm) for SLG/Cu (111) were notably shallower than those of bare Cu (111) (6.5 ± 1.2 µm). Surface analysis of the corrosion products corroborated these findings, with copper sulfide identified as a major component across both surfaces. The absence of grain boundaries in Cu (111) resulted in high-quality SLG manifesting higher barrier properties compared to SLG on PC-Cu. Our findings show promise for using the presented strategy for developing durable graphene coatings against diverse forms of corrosion. Full article

In this paper, Cu thin films were deposited on Si (100) substrates by the high−power impulse magnetron sputtering (HiIPMS) technique, and the effects of different duty cycles (from 2.25% to 5.25%) on the plasma discharge characteristics, microstructure, and electrical properties of Cu thin films were investigated. The results of the target current test show that the peak target current remains stable under 2.25% and 3% duty cycle conditions. Under the conditions of a 4.5% and 5.25% duty cycle, the target peak current shows a decreasing trend. The average power of the target shows a rising trend with the increase in the duty cycle, while the peak power of the target shows a decreasing trend with the increase in the duty cycle. The results of OES show that with the increase in the duty cycle, the total peak intensity of copper and argon emissions shows an overall increasing trend. The duty cycle from 3% to 4.5% change in copper and argon emission peak total intensity change is not obvious. The deposition rate and surface morphology of the copper film were investigated by scanning electron microscopy, and the deposition rate of the copper film increased with the increase in the duty cycle, which was mainly due to the increase in the average power. The surface roughness of the copper film was evaluated by atomic force microscopy. X−ray diffraction (XRD) was used to analyze the grain size and texture of the Cu film, and the results showed that the average grain size of the Cu film increased from 38 nm to 59 nm on the (111) and (200) crystal planes. Four−probe square resistance test copper film resistivity in 2.25%, 3% low duty cycle conditions of the copper film resistivity is generally higher than 4.5%, 5.25% high duty cycle conditions, the copper film resistivity shows the trend of change is mainly affected by the copper film grain size and the (111) face of the double effect of the optimal orientation. The lowest resistivity of the copper film measured under the 4.5% duty cycle condition is 1.7005 μΩ·cm, which is close to the intrinsic resistivity of the copper film of 1.67 μΩ·cm. Full article

The factors that influence the formation of helium blisters in copper were studied, including crystallographic grain orientation and thermomechanical conditions. Helium implantation experiments were conducted at 40 KeV with a dose of 5 × 10¹⁷ ions/cm², and the samples were then subjected to post-implantation heat treatments at 450 °C for different holding times. A scanning electron microscope (SEM) equipped with an electron backscatter diffraction (EBSD) detector was used to analyze the samples, revealing that the degree of blistering erosion and its evolution with time varied with the crystallographic plane of the free surface in different ways in annealed and cold rolled copper. Out of the investigated states, rolled copper with a (111) free surface had superior helium blistering durability. This is explained by the consideration of the multivariable situation, including the role of dislocations and vacancies. For future plasma-facing component (PFC) candidate material, similar research should be conducted in order to find the optimal combination of material properties for helium blistering durability. In the case of Cu selection as a PFC, the two practical approaches to obtain the preferred (111) orientation are cold rolling and thin layer technologies. Full article

Recently, it was demonstrated that inelastic helium atom scattering from conducting surfaces provides a direct measurement of the surface electron–phonon coupling constant (mass enhancement factor λ) via the temperature or the incident wave vector dependence of the Debye–Waller exponent. Here, previous published as well as unpublished helium atom scattering diffraction data from the vicinal surfaces of copper (Cu(11α), with α = 3, 5, 7) and aluminum (Al(221) and Al(332)) were analyzed to determine λ. The results suggested an enhancement with respect to the corresponding data for the low-index surfaces (111) and (001) above the roughening transition temperature. The specific role of steps compared to that of terraces is briefly discussed. Full article

This study focuses on the analyses of nano-twinned copper (Cu) films deposited through magnetron sputtering on silicon carbide (SiC) chips. The investigation encompasses the utilization of a chromium (Cr) adhesive layer coupled with varying voltage bias conditions. The goal is to comprehensively examine the influence of the adhesive layer and negative bias voltages, contributing to an enhanced understanding of materials engineering and bonding technologies for advanced applications. The formation of a nano-twinned structure and (111) surface orientation can be properly controlled by applied substrate bias. High-density nanotwinned structures were introduced into Cu films sputtered on SiC substrates with 82.3% of (111) orientation proportion at −150 V, much higher than the Cu film sputtered with another substrate bias. It is concluded that the sputtered Cu nanotwinned film formed with −150 V bias voltage has the potential to be employed as the interlayer for low-temperature direct bonding. Full article

In this study, we investigate the crystal structure, surface energy, and atomic arrangement of Cu₂O. Understanding these properties is crucial for exploring the potential applications and understanding the behavior of this material. We employ the Wulff construction method and an artificial neural network (ANN) model to analyze the relative surface energies of different crystal facets and predict the surface energy of Cu₂O. The ANN model exhibits excellent performance, demonstrating its effectiveness in predicting material properties and providing automated feature-learning and nonlinear-modeling capabilities. Moreover, we analyze the atomic arrangements on various crystal facets and observe the presence of oxygen atoms on the {100} facet, as well as exposed under-coordinated copper atoms on the {111} and {110} facets. High-index facets such as {211} exhibit a higher atomic step density and screw dislocation density. By precisely controlling the synthesis process, it is possible to manipulate the proportion of high-index facets. These findings highlight the significance of understanding the surface energy and atomic arrangement of Cu₂O crystals for comprehending their properties and surface reactions. In summary, this study provides valuable insights into the crystal structure, surface energy, and atomic arrangement of Cu₂O, offering inspiration for its properties and potential applications. The combination of the Wulff construction method and ANN modeling provides a comprehensive understanding of Cu₂O crystals and their surface behavior, contributing to the field of materials science and laying the foundation for various future applications utilizing the unique properties of Cu₂O. Full article

Copper nitride (Cu₃N) has gained significant attention recently due to its potential in several scientific and technological applications. This study focuses on using Cu₃N as a solar absorber in photovoltaic technology. Cu₃N thin films were deposited on glass substrates and silicon wafers via radio-frequency magnetron sputtering at different nitrogen flow ratios with total pressures ranging from 1.0 to 5.0 Pa. The thin films’ structural, morphology, and chemical properties were determined using XRD, Raman, AFM, and SEM/EDS techniques. The results revealed that the Cu₃N films exhibited a polycrystalline structure, with the preferred orientation varying from 100 to 111 depending on the working pressure employed. Raman spectroscopy confirmed the presence of Cu-N bonds in characteristic peaks observed in the 618–627 cm⁻¹ range, while SEM and AFM images confirmed the presence of uniform and smooth surface morphologies. The optical properties of the films were investigated using UV-VIS-NIR spectroscopy and photothermal deflection spectroscopy (PDS). The obtained band gap, refractive index, and Urbach energy values demonstrated promising optical properties for Cu₃N films, indicating their potential as solar absorbers in photovoltaic technology. This study highlights the favourable properties of Cu₃N films deposited using the RF sputtering method, paving the way for their implementation in thin-film photovoltaic technologies. These findings contribute to the progress and optimisation of Cu₃N-based materials for efficient solar energy conversion. Full article

In this work, the deposition of titanium nitride (TiN) thin film using direct current (DC) sputtering technique and its application as diffusion barriers against copper interconnect was presented. The deposited film was analyzed by using X-ray diffraction (XRD), field-emission scanning electron microscopy (FESEM), and X-ray photoelectron spectroscopy (XPS) techniques. XRD patterns showed the face-centered cubic (FCC) structure for the TiN/SiO₂/Si film, having (111) and (200) peaks and TiN (111), Cu(111), and Cu(200) peaks for Cu/TiN/SiO₂/Si film. FESEM images revealed that the grains were homogeneously dispersed on the surface of the TiN film, having a finite size. XPS study showed that Ti2p doublet with peaks centered at 455.1 eV and 461.0 eV for TiN film was observed. Furthermore, the stoichiometry of the deposited TiN film was found to be 0.98. The sheet resistance of the TiN film was analyzed by using a four-point probe method, and the resistivity was calculated to be 11 μΩ cm. For the utilization, TiN film were tested for diffusion barrier performance against Cu interconnect. The results exhibited that TiN film has excellent performance in diffusion barrier for copper metallization up to a temperature of 700 °C. However, at a higher annealing temperature of 800 °C, the formation of Cu₃Si and TiSi₂ compounds were evident. Thus, stoichiometric TiN film with high thermal stability and low resistivity produced in this study could be applied for the fabrication of microelectronic devices. Full article

Engineering the surface orientation of face-centered cubic (fcc) metals to the close-packed {111} plane can significantly enhance their oxidation resistance. However, owing to the synergetic effect of surface energy density ($\dot{\gamma }$) and strain energy density ($\omega$), such close-packed surface orientation can currently only be achieved by atomic-level thin film epitaxy or monocrystallization of polycrystalline metals. In this study, we characterized the microstructures of pure copper (Cu) foil and two types of graphene-coated Cu (Gr/Cu) foils and observed a 12~14 nm thick reconstructed surface layer with the {111} orientation in the high-temperature deposited Gr/{001} Cu surface. Combining the statistical results with thermodynamic analysis, we proposed a surface melting-solidification mechanism for the reconstruction of the Cu surface from {001} orientation to {111} orientation. This process is dominated by Gr/Cu interfacial energy and is particularly promoted by high-temperature surface melting. We also validated such a mechanism by examining Cu surfaces coated by h-BN (hexagonal boron nitride) and amorphous carbon. Our findings suggest a possible strategy to enhance the surface properties of fcc metals via engineering surface crystallography. Full article

The variety of conductive fibers has been constantly enriched in recent years, and it has made rapid development in the fields of electronic textiles, intelligent wearable, and medical care. However, the environmental damage caused by the use of large quantities of synthetic fibers cannot be ignored, and there is little research on conductive fibers in the field of bamboo, a green and sustainable material. In this work, we used the alkaline sodium sulfite method to remove lignin from bamboo, prepared a conductive bamboo fiber bundle by coating a copper film on single bamboo fiber bundles using DC magnetron sputtering, and analyzed its structure and physical properties under different process parameters, finding the most suitable preparation condition that combines cost and performance. The results of the scanning electron microscope show that the coverage of copper film can be improved by increasing the sputtering power and prolonging the sputtering time. The resistivity of the conductive bamboo fiber bundle decreased with the increase of the sputtering power and sputtering time, up to 0.22 Ω·mm; at the same time, the tensile strength of the conductive bamboo fiber bundle continuously decreased to 375.6 MPa. According to the X-ray diffraction results, Cu in the copper film on the surface of the conductive bamboo fiber bundle shows the preferred orientation of (111) the crystal plane, indicating that the prepared Cu film has high crystallinity and good film quality. X-ray photoelectron spectroscopy results show that Cu in the copper film exists in the form of Cu⁰ and Cu²⁺, and most are Cu⁰. Overall, the development of the conductive bamboo fiber bundle provides a research basis for the development of conductive fibers in a natural renewable direction. Full article

The electrochemical reduction of CO₂ is an efficient method to convert CO₂ waste into hydrocarbon fuels, among which methanol is the direct liquid fuel in the direct methanol fuel cells (DMFC). Copper is the most widely used catalyst for CO₂ reduction reaction (CO₂RR); the reaction is affected by the surface morphology of the copper. Here, the morphology effect and the mechanism of CO₂RR on three typical low-index Cu (100), Cu (110) and Cu (111) surfaces are studied. According to our results, Cu (110) provides the optimum surface for the CO₂RR via CO₂ → *COOH → *CO → *CHO → *CH₂O → *CH₂OH → CH₃OH pathway, where the reduction reaction of CO₂ to *COOH is the potential-determining step (PDS). This is because Cu (110) has the highest d band center, which promotes the adsorption of *COOH. Full article

Diamond/Cu composites are widely studied as a new generation of thermal management materials in the field of electronic packaging and heat sink materials. The surface modification of diamond can improve interfacial bonding between the diamond and Cu matrix. The Ti-coated diamond/Cu composites are prepared via an independently developed liquid-solid separation (LSS) technology. It is worth noting that there are obvious differences for the surface roughness between the diamond-{100} and -{111} face by AFM analysis, which may be related to the surface energy of different facets. In this work, the formation of titanium carbide (TiC) phase makes up the chemical incompatibility between the diamond and copper, and the thermal conductivities of 40 vol.% Ti-coated diamond/Cu composites can be improved to reach 457.22 W·m⁻¹·K⁻¹. The results estimated by the differential effective medium (DEM) model illustrate that the thermal conductivity for 40 vol.% Ti-coated diamond/Cu composites show a dramatic decline with increasing TiC layer thickness, giving a critical value of ~260 nm. Full article
