Multimodal large language models can read architectural images and design instructions but they still struggle to turn architectural rules into editable, executable models in professional modeling environments. To address this limitation, this paper presents MLLMto3D, an MCP-driven closed-loop framework that connects multimodal reasoning with Rhino-based modeling, feedback, and revision. The framework consists of five phases: visual parsing, JSON-based intent serialization, code synthesis, MCP-driven Rhino execution and feedback, and verification with bounded repair. Its core mechanism is JSON-based intent serialization, which converts image-derived architectural information into machine-readable modeling parameters under a predefined JSON schema. The schema separates geometric and compositional constraints, including height, bay rhythm, facade zones, and alignment rules, from design variables such as materials, openings, and ornament. Building on this mechanism, Skills modules externalize facade typology knowledge and safe Rhino scripting patterns, providing callable professional constraints for code synthesis to reduce design-intent deviation and API hallucination. The framework is evaluated through an experimental design case study on a site in Shanghai’s Hengfu Historic District, where the generation of new façades is informed by a nearby heritage architectural reference. The results show that MLLMto3D can generate a parametrically adjustable Rhino model while preserving the main compositional constraints, thereby advancing AI-assisted architectural 3D generation toward a controllable, verifiable, and iterative modeling process. Full article

Urban building color research has long been anchored in the “dominant-color” paradigm, which describes only the basic attributes of the most prevalent color and overlooks multi-color compositional relationships, thereby failing to reach evaluative dimensions such as color combination quality and spatial order. This study proposes a Fundamental–Compositional–Spatial (FCS) evaluation framework for building color quality, organizing ten indicators into three hierarchical layers: fundamental attributes, compositional structure, and spatial association. Using the Macao Special Administrative Region as an empirical case and drawing on building façade color data extracted from 8163 street-view sampling points, we systematically quantify the city-wide building color quality. Results show that (1) at 76.8% of the sampling points the dominant-color share lies within only 13–21%, so the dominant color holds no absolute areal advantage, and there is a significant intrinsic tension between colorfulness and harmony (r = −0.363) within the compositional structure; (2) Macao’s building colors are dominated by warm hues (warm-to-cool ratio ≈ 4.5:1), with saturation and value forming a systematic co-variation between a “dark-yet-colored” and a “bright-yet-colorless” mode, and color contrast exhibiting pronounced positive spatial autocorrelation (Moran’s I = 0.456); and (3) clustering based on the six C+S-layer indicators identifies four color-quality types—Subdued-Transitional (38.1%), Vibrant-Fragmented (13.5%), Dark-Harmonious (45.6%), and Monotonous-Clustered (2.7%)—whose spatial distribution is broadly consistent with the city’s historical construction strata. The study demonstrates that a multi-dimensional color-evaluation approach based on street-view big data can effectively transcend the limitations of dominant-color analysis and provides an operational technical pathway for fine-grained cognition and differentiated governance of urban color. Full article

Buildings account for a significant share of global energy consumption and carbon emissions, creating an urgent need for advanced energy retrofit technologies. This review critically examines the role of plasma-modified textile polymer materials in improving the energy efficiency and durability of building retrofit systems. Various textile polymers, including polyester (polyethylene terephthalate, PET), polypropylene (PP), polytetrafluoroethylene (PTFE), polyamide (PA), and fiber-reinforced composites, are evaluated in relation to plasma surface engineering approaches, including atmospheric plasma, dielectric barrier discharge (DBD), and plasma jet treatment. Reported studies demonstrate that plasma treatment significantly alters surface morphology and chemistry, resulting in increased surface roughness, enhanced wettability, improved coating adhesion, and superior hydrophobic behavior. Water contact angles increased from approximately 70° to 145° depending on polymer type and plasma conditions, while reflective coating performance improved with solar reflectance enhancements of approximately 10–15%. Plasma-treated reflective roofing and shading textiles also showed reductions in building cooling energy demand of approximately 18–25% and roof temperature decreases of 10–15 °C. Furthermore, plasma-induced surface activation improved durability, ultraviolet (UV) resistance, and weather stability of textile membranes used in facade and roofing applications. The review also discusses industrial challenges related to scalability, plasma aging effects, energy consumption, and long-term performance. Plasma-modified systems demonstrate strong potential for multifunctional, lightweight, and sustainable building envelope technologies for future energy-efficient construction. Full article

Contemporary glass façade systems play a crucial role in shaping both the environmental performance and the architectural expression of buildings. This study presents a comparative analysis of selected façade solutions, including internal louvres, adaptive façades, louvre systems combined with glass, and façades incorporating printed graphics. This research is based on in situ measurements of light reduction, digital analysis of enamel coverage, and a multi-criteria evaluation of compositional and communicative aspects. The analysis covers twelve European public buildings and focuses on the relationship between daylight modulation, solar protection, and the visual articulation of façades. The results indicate that façade systems differ significantly in their ability to control light and shape architectural expression. Adaptive façades and louvre-based systems demonstrate high efficiency in daylight modulation, while façade graphics integrated with selective glazing offer a balanced performance, combining effective solar protection with high daylight transmittance. This study highlights the role of façade design as a multi-functional element that integrates environmental performance with compositional and communicative functions. The proposed comparative framework provides a useful tool for evaluating façade strategies in the early stages of architectural design. The findings suggest that façade graphics, when integrated with contemporary glazing systems, provide a balanced solution combining environmental performance with architectural and communicative functions. Full article

Semantic segmentation of street-view imagery has become an important computational tool for urban morphological analysis and the evaluation of street spatial quality. However, existing methods still struggle in complex urban environments. Major challenges include large variations in building façade scales, degradation of boundary information, and severe class imbalance. These issues limit the ability of current models to capture structurally meaningful urban forms. To address these challenges, this study proposes a high-resolution street-view segmentation framework, termed HieraWaveSeg. The model aims not only to improve pixel-level segmentation accuracy but also to enhance the interpretability of urban morphology through structured representations of street space. Specifically, a Hiera Transformer backbone is employed to capture hierarchical spatial semantics. A Path Aggregation Network is further introduced to strengthen cross-scale feature interaction and improve structural consistency in complex scenes. In addition, a Wave Fusion module based on the Haar wavelet transform is incorporated to preserve fine-grained architectural details by enhancing high-frequency boundary and texture information during decoding. Unlike conventional segmentation approaches that primarily focus on object recognition, this study introduces a morphology-oriented semantic reconfiguration strategy. This strategy reorganizes original categories into functionally meaningful urban units. As a result, the segmentation outputs can be more directly linked to urban morphological indicators, such as façade continuity, spatial enclosure, and interface permeability, thereby improving interpretability in architectural and urban design contexts. To further address class imbalance, a composite loss function combining weighted cross-entropy and Dice loss is adopted, together with a median frequency balancing strategy. Experimental results on the CamVid and Cityscapes datasets demonstrate that the proposed method consistently outperforms several state-of-the-art baselines in both segmentation accuracy and structural preservation. Beyond quantitative improvements, the results indicate that the proposed framework generates more coherent and morphologically meaningful urban representations, supporting further quantitative analysis in urban morphology and architectural studies. Full article

This study presents a coupled building simulation framework that evaluates thermal and daylight performance concurrently within a unified multi-objective decision space. Unlike conventional sequential workflows, where daylight metrics are assessed after energy optimization or used primarily for compliance verification, the proposed approach embeds EnergyPlus and Radiance simulations directly within the same optimization loop. This structure enables a systematic exploration of non-linear interactions between Energy Use Intensity (EUI), cooling loads, Spatial Daylight Autonomy (SDA), and Annual Sunlight Exposure (ASE) during early-stage façade design. The framework is demonstrated through a medium-rise office building in India’s National Capital Region, a composite climate characterized by strong seasonal and directional variability. Parametric variation in façade orientation, window-to-wall ratio, and external shading configurations was explored using a multi-objective genetic algorithm to identify Pareto-optimal performance regimes. The results reveal distinct orientation-dependent trade-off structures between solar exposure, cooling demand, and daylight availability that are not evident in rule-based or sequential simulation approaches. In particular, a transitional East-facing façade regime emerges in which balanced shading and glazing proportions achieve near–North-facing cooling performance while maintaining high daylight autonomy under controlled sunlight exposure. Rather than proposing a single optimal solution, the study demonstrates how tightly coupled thermal–daylight simulation can function as a knowledge-discovery tool, enabling the extraction of transferable façade response patterns from simulation outputs. The findings highlight the limitations of prescriptive orientation hierarchies in composite climates and illustrate the value of integrated simulation workflows for performance-driven early-stage design across diverse climatic contexts. Although the study references thermal performance, the optimization objectives are limited to peak cooling load and annual Energy Use Intensity (EUI). Occupant comfort indices such as Predicted Mean Vote (PMV) and Predicted Percentage Dissatisfied (PPD) were not explicitly simulated. Therefore, results are interpreted as energy–daylight performance optimization rather than direct thermal comfort optimization. Full article

Hybrid MTMS–silica aerogels incorporating calcium silicate hydrate (C–S–H), the primary hydration product in cementitious systems, were synthesized via sol–gel processing followed by freeze-drying. The influence of C–S–H loading on pore structure, density, wettability, and thermal transport was investigated. The lowest thermal conductivity (0.068 W/m·K) and tap density (0.30 g/cm³) were obtained at 10% C–S–H loading (wM-CSH10), while the thermal conductivity increases to approximately 0.075–0.082 W/m·K at higher C–S–H content. All samples exhibit mesoporous structures with pore diameters in the range of 10–21 nm. Increasing C–S–H content progressively densified the network, reduced mesopore volume, and enhanced high-temperature mass retention up to 540 °C. FTIR analysis confirmed Si–O–Ca interfacial interactions, while nitrogen adsorption demonstrated persistent mesoporosity across all compositions. Thermal conductivity showed a positive correlation with density, indicating that bulk densification governs heat transport in the hybrid system. Beyond structural modification, the incorporation of C–S–H introduces chemical and microstructural features relevant to cement-based materials, suggesting potential compatibility with cementitious matrices. The results highlight the compositional trade-off between insulation efficiency and structural stability and demonstrate the potential of C–S–H-modified MTMS–silica aerogels for future integration into cement-based composites. These findings provide fundamental insight into their possible use in thermal insulation applications, such as building envelope systems (walls, façades, and roofs used for thermal insulation). Full article

Decarbonizing the construction sector requires high-volume replacement of Portland clinker with non-calcined supplementary cementitious materials (SCMs). This study investigates white cement pastes incorporating raw Algerian diatomite—a silica-rich biogenic mineral—at substitution levels from 40% to 95% (5% increments) and a fixed water-to-binder ratio of 0.5. The target application is ultra-lightweight, multifunctional composites for non-structural uses such as decorative panels and partition elements. Increasing diatomite content progressively reduced bulk density from 1.483 g/cm³ (D40) to 0.557 g/cm³ (D95) and increased porosity. 28-day compressive strength decreased monotonically from 16 MPa (D40) to 2.4 MPa (D95) as clinker dilution intensified. Ultrasonic pulse velocity dropped from 6205 m/s to 1495 m/s, reflecting progressive pore development and confirming the material’s lightweight potential. Statistically significant strength gains beyond 28 days were recorded ($+25.87\%$ for compression, p-value $< 0.05$), evidencing delayed pozzolanic activity. These results confirm that raw, non-calcined diatomite is a viable SCM for eco-efficient, low-density construction systems. To overcome the extrapolation instability of purely data-driven approaches, a Meta-Avrami Hybrid Framework was developed. It anchors Gradient Boosting residual learning to a sigmoidal Avrami hydration kernel. The model achieved high predictive accuracy ($R^2\approx 0.999$, $\mathrm{RMSE}\approx 0.010$) under 10-fold cross-validation. Generalization was well-controlled, with a low overfitting gap ($\Delta R^2=0.0226$) and stable fold-to-fold performance ($\mathrm{Std}=0.0204$). These metrics confirm suitability for unseen mix designs. This is particularly relevant for service-life assessment of partition panels and lightweight façade elements, where long-term performance guarantees are required. The physics-informed architecture ensures asymptotic strength stabilization up to a 10-year horizon (amplification ratios 1.03–1.05). This prevents the non-physical divergence observed in polynomial and power-law hybrids (ratios 1.36–1.70). The framework provides a reliable and interpretable tool for service-life design of sustainable low-carbon cementitious systems. Full article

The pursuit of energy efficiency and sustainability in the built environment has placed façade systems at the forefront of innovation in architectural design. This study proposes an integrated framework that combines generative design techniques with artificial intelligence (AI) to optimize composite façade configurations for next-generation smart buildings. Using parametric modeling, a wide design space of façade geometries and material compositions was generated, capturing trade-offs between thermal performance, daylight, structural strength, and aesthetic variability. Artificial intelligence algorithms, particularly machine learning models, are trained on simulation-derived performance datasets to rapidly predict key indicators such as energy consumption, thermal transmittance (U-value) and solar heat gain coefficients. The proposed approach achieved a predictive accuracy of 99.85%, enabling efficient exploration of optimal solutions across high-dimensional design alternatives. A multi-objective optimization strategy was further implemented to balance energy efficiency with structural and aesthetic constraints, producing façade configurations that outperform conventional designs. The findings demonstrate that integrating generative design with AI-based prediction not only accelerates the façade design process but also provides actionable pathways toward net-zero energy buildings. This research highlights the transformative potential of AI-driven generative workflows in advancing sustainable architecture and delivering intelligent, adaptive and performance-oriented façades for future urban environments. Full article

The use of sustainable building materials is becoming increasingly important in order to reduce their environmental impact. This article draws attention to the lack of life cycle assessment (LCA) of building façades, which would take into account national conditions. The aim of the work is to assess the environmental impact of various building façade solutions. The analysis concerned a ventilated façade on an aluminum substructure with a fiber cement board and external thermal insulation composite system (ETICS) with expanded polystyrene (EPS). The assessed façades differed with regard to the used insulation materials. The study aims to select more ecological façades, while at the same time taking into account national conditions, which is important at the stage of designing a building. The study also aims to fill a gap in the existing literature by providing information concerning the environmental analysis of building façades based on real data. Based on a comparative analysis, it was shown that ETICSs with EPS have higher façade-damage category indicators in all impact categories except for eutrophication, human toxicity (carcinogenic and non-carcinogenic), and resource use related to minerals and metals, for which the ventilated façade shows higher values. Additionally, hot-spots for the analyzed façades were also presented. In the case of a ventilated façade, the determinant is the used insulating material, which is mineral wool. In the case of ETICS, it is the finish coat. For the first time in Poland, the LCA of a ventilated façade and ETICS was presented based on real data. The results of this study can be used as the first step of a full cradle-to-grave LCA for buildings. Full article

Solar absorbers (SAs) are central to building-integrated solar-thermal systems; however, conventional black SAs, despite their high solar absorptance (α_s), offer limited aesthetic flexibility and are therefore poorly suited to modern architectural façades. Brightly colored SAs are widely assumed to suffer from intrinsically low α_s, creating a long-standing trade-off between color vibrancy and energy performance. Here this study reports a dielectric/absorber/dielectric/absorber (D/A/D/A) multilayer architecture, in which the absorber layer is composed of a TiO₂–TiON–C composite, that overcomes this limitation and enables colored solar absorbers (CSAs) with reflectance >20%, α_s > 0.90, wide viewing angles, strong self-cleaning capability, high corrosion resistance and exceptionally long projected service lifetimes. These results demonstrate that vivid coloration and high solar absorptance can be simultaneously achieved without compromising environmental durability. To highlight architectural applicability, we further implement a complementary-color contrast strategy for façade design, yielding visually striking, highly recognizable, and low-cost exterior surfaces. This approach enhances aesthetic integration while significantly strengthening the marketability of CSA-based building envelopes for next-generation sustainable architectural systems. Full article

Interference patterns are increasingly explored in contemporary architectural façades as visual configurations generated through the superposition of repetitive and layered geometric structures. This study examines the role of interference patterns in contemporary architecture, with particular attention to the perceptual effects and illusion-related phenomena that may emerge during their observation. The research is based on a comparative, case-based analysis of selected architectural examples in which interference patterns are introduced through façade articulation, layered glazing systems, spatial textures, or form-related strategies. The analysed material is classified into four groups: semi-spatial façades, façade graphics applied to multi-layer glass systems, spatial textures, and interference embedded in the overall building form. The analysis focuses on identifying recurring perceptual effects associated with interference patterns, such as illusion-related phenomena, including visual aliasing, motion parallax, apparent depth, figure–ground ambiguity, flicker effects, and dynamic perspective. The comparative analysis indicates that interference patterns can significantly influence the perception of architectural space within its urban context. This influence extends beyond visual appearance and aesthetic composition, contributing to architectural communication, meaning-making processes, and the cognitive engagement of the viewer with spatial and visual structures. The study provides a structured analytical framework that may support further research on perceptual strategies in contemporary architectural design. Full article

Josip Vojnović (Omiš, 1929–Split, 2008) is a prominent Croatian architect, primarily known in professional circles for organising the construction of Split 3, the expansion of Split during the 1970s. His professional career began with the design of primarily residential buildings and concluded with his position as a university professor. This article analyses the URBS 1 standard residential buildings constructed during the 1960s, which were intended to address the housing shortage in post-war Split. These buildings—the most notable part of Vojnović’s design work—were built in several locations throughout Dalmatia. Even at the time of their construction, they were recognised as a significant example of designed and executed standardised residential architecture. This research is based on archival materials from the State Archives in Split, the Archive of the Urban Planning Institute of Dalmatia–Split, as well as research in situ. The article examines the design of the standard building, including a functional analysis of the residential unit and all the floors, as well as a formal and compositional analysis of the façade. The URBS-1 buildings are an illustrative example of housing construction, due to their number, distribution and architectural features shaped by the economic, technological, social and cultural context of the time. Full article

Heritage buildings pose persistent challenges for documentation and conservation due to their geometric complexity, material heterogeneity, and the fragmentation of spatial and semantic datasets. To address these limitations, this study proposes a geospatially enabled HBIM–GIS framework that integrates hybrid photogrammetric survey data with semantic modeling and spatial analysis to support evidence-based conservation planning. A multi-source acquisition strategy combining terrestrial digital photogrammetry (TDP), Unmanned aerial vehicle digital photogrammetry (UAVDP), and spherical photogrammetry (SP) was employed to capture accurate geometric and semantic information across multiple spatial scales. Staged point-cloud fusion (UAVDP → TDP via ICP; SP → UAV–TDP via SICP) generated a high-density, georeferenced composite, achieving RMS residuals below 0.013 m and resulting in an integrated dataset exceeding 360 million points. From this composite, authoritative 2D drawings and a reality-based 3D HBIM model were developed, while GIS thematic mapping translated heterogeneous observations into structured, queryable layers representing materials, cracks, detachments, deformations, and construction phases. The proposed framework enabled the spatial diagnosis of deterioration mechanisms, revealing moisture-driven decay from plinth to mid-wall and concentrated cracking at openings and architectural transitions; side-to-side cracks accounted for approximately 55% and 65% of mapped fissures on the most affected façades. By embedding these diagnostics as element-level attributes within the HBIM environment, the framework supports precise localization, quantification, and prioritization of conservation interventions, ensuring material-compatible and location-specific decision making. The applicability of the framework is demonstrated through its implementation on a complex historic mosque in Yemen, validating its robustness under constrained access and resource-limited conditions. Overall, the study demonstrates that geospatially integrated HBIM–GIS workflows provide a reproducible, scalable, and transferable solution for the sustainable documentation and conservation of heritage buildings, supporting long-term monitoring and informed management of cultural heritage assets worldwide. Full article

The thermally efficient and lightweight TRC/CLCi composite panels for functional and smart building envelopes, funded by the iclimabuilt project (Grant Agreement no. 952886), offer innovative solutions to sustainably address common failure risks in facade systems. This work specifically emphasizes strategies for mitigating structural, thermal, and fire-related failures through targeted material selection, advanced design methodologies, and rigorous validation protocols. To effectively mitigate structural failures, high-pressure concrete (HPC) reinforced with carbon fibers is utilized, significantly enhancing tensile strength, reducing susceptibility to cracking, and improving overall durability. To counteract thermal bridging—a critical failure mode compromising energy efficiency and structural integrity—the panels employ specially designed glass-fiber reinforced pins connecting HPC outer layers through the cellular lightweight concrete (CLC) insulation core that has a density of around 70 kg/m³ and a thermal conductivity in the range 35 mW/m∙K comparable to those of expanded polystyrene and Rockwool. These connectors ensure effective load transfer and maintain optimal thermal performance. A central focus of the failure mitigation strategy is robust fire behavior. The developed panels undergo rigorous standardized fire tests, achieving an exceptional reaction to fire classification of A2. This outcome confirms that HPC layers maintain structural stability and integrity even under prolonged fire exposure, effectively preventing catastrophic failures and ensuring occupant safety. In conclusion, this work highlights explicit failure mitigation strategies—reinforced concrete materials for structural stability, specialized glass-fiber connectors to prevent thermal bridging, rigorous fire behavior protocols, and comprehensive thermal performance validation—to produce a facade system that is robust, energy-efficient, fire-safe, and sustainable for modern buildings. Full article
