A composite bucket foundation (CBF) is a new type of supporting structure in offshore wind engineering. Its huge transition part is the key difference compared to other offshore foundations. Firstly, the vibration measurement system of a wind turbine with the CBF is introduced. A finite element method (FEM) was developed, and the rigid deformation performance of the transition part was characterized. Then, to clarify the influence of the transition part brings to wind turbines with CBFs, a three-DOF theoretical model was established by simplifying the transition part as a rigid body. Horizontal and rotational foundation stiffness were considered to present the constraint effect below the mudline. Sensitivity studies were conducted on the parameters (including mass, moment of inertia and mass center height) of the transition part. Further, the vibration properties of the CBF structures under different operation load conditions were compared through the theoretical model and the in situ data. The results show that the relative errors between the theoretical model and FEM model are 3.78% to 5.03%, satisfying the accuracy requirements. The parameters of the transition part have varying degrees of influence on the natural frequency, foundation stiffness and vibration response of the wind turbines with CBFs. Compared to wind and 1P loads, the 3P load has a greater influence if the 3P frequency is close to the natural frequency of the wind turbine. Full article

More and more clean energy is used worldwide and offshore wind power is an important part of clean energy. The difficulty of offshore construction is an important problem. The integrated floating transport technique of composite bucket foundation (CBF) provides an important method to solve this problem. The main purpose of this paper is to study and verify the safety of the integrated floating transport technique of the composite bucket foundation. Through the test method, we determine the location distribution where the contact force changes greatly and identify the factors that have a great impact on the contact force. We study the influencing factors of the contact force between the composite bucket foundation and the installation vessel during the towing process and verify the experimental results through project data monitoring. We conclude by proposing feasible suggestions for the safety assurance of the project based on the contact force problem. Full article

The composite bucket foundation (CBF) consists of a concrete curved transition section, a concrete beam-slab system, and a suction caisson and is increasingly used as the foundation for offshore wind turbines. The curved transition section transmits the upper load from the tower to the foundation, and its force and transmission characteristics are related to the safety of the entire wind turbine structure. The arced transition section has the characteristics of complex geometry, load conditions, and large curvature. It is difficult to determine its bearing characteristics and force transmission system. In this paper, the boundary conditions and loading device of the CBF model test are designed, and three 1:20 arced transition section model specimens are made. The mechanical characteristic experiments of CBF are used to analyze the failure process, failure characteristics, and seismic performance of the structure. Results show that the cracking effect of the arced transition section after prestressing is obviously better than that of a reinforced concrete arced transition section structure. The arced transition section specimens equipped with prestressed tendons can increase the structural cracking load ratio by about 35% for reinforced concrete members. The energy dissipation capacity of the specimens has been significantly improved, and the material properties can be fully utilized. The failure mode of the arced transition section structure under horizontal reciprocating load shows the characteristics of bending and shear failure. Full article

In this study, a composite bucket foundation (CBF) was investigated by taking into account the reflection and refraction effects of waves. A numerical model for the motion responses of the structure under different wave heights and wave periods was built based on the 3D potential flow theory. The model was verified against the test results for analyzing the stability and seakeeping performance of the foundation under the action of waves. Under the combined action of wind and waves, the possible scenarios of floating under wind and waves of different scales and directions were simulated, and the mooring force and motion response peaks and laws of the structure were established, aiming to improve the safety of composite bucket foundation transport and provide technical support for floating construction. Full article

The composite bucket foundation (CBF) for offshore wind turbines is the basis for a one-step integrated transportation and installation technique, which can be adapted to the construction and development needs of offshore wind farms due to its special structural form. To transport and install bucket foundations together with the upper portion of offshore wind turbines, a non-self-propelled integrated transportation and installation vessel was designed. In this paper, as the first stage of applying the proposed one-step integrated construction technique, the floating behavior during the transportation of CBF with a wind turbine tower for the Xiangshui wind farm in the Jiangsu province was monitored. The influences of speed, wave height, and wind on the floating behavior of the structure were studied. The results show that the roll and pitch angles remain close to level during the process of lifting and towing the wind turbine structure. In addition, the safety of the aircushion structure of the CBF was verified by analyzing the measurement results for the interaction force and the depth of the liquid within the bucket. The results of the three-DOF (degree of freedom) acceleration monitoring on the top of the test tower indicate that the wind turbine could meet the specified acceleration value limits during towing. Full article

Composite bucket foundations, which have been successfully transported, installed, and operated at the Qidong, Xiangshui, and Dafeng offshore wind farms in China, are economically advantageous due to the relatively simple transportation and installation process. The innovative one-step transportation and installation technology of foundation-tower-nacelle is the key phase in saving costs. In this paper, a “foundation lift ship” overall transport mode is proposed and introduced for the first time. Prototype data measurement, preliminary numerical simulation, and theoretical calculations were conducted to investigate whether the foundation-ship integrity, tower hoop stability, and various indexes of the nacelle met the requirements under the influences of various environmental factors. The multi-system coupling motion mechanism and analysis method of this new structure and transportation mode were expounded. Through the prototype observation data of the one-step overall transportation, the ship-foundation system reliability of the structure in the case of large wind and wave was confirmed. Furthermore, it was found that in the one-step overall transportation, the importance of factors to nacelle acceleration decreased in the order of wave height, current speed, and wind speed by the time and frequency domain analysis and data statistics. Full article

Composite bucket foundation (CBF) is an environmentally friendly form of offshore wind power foundation. By virtue of the air-floating subdivision structure in the bucket, the foundation has a self-floating characteristic and can allow for long-distance air-floating towing and transport. In this study, first, a numerical analysis was performed on the towing motion characteristics of CBF, and the formula for foundation stability was deduced; then, we probed into the variation rules of the natural period of the foundation with draft and analyzed the response amplitude operator (RAO) responses, added mass coefficients, radiation damping coefficients, and exciting forces (moments) of the composite bucket foundation under different drafts and different wave directions. Finally, we clarified the basic hydrodynamic characteristics of the composite bucket foundation in the frequency domain and adopted multiple random wave models to investigate the effects of different wave heights, periods, and spectral peak factors on the towing motion characteristics of composite bucket foundation. Full article

The composite bucket foundation (CBF) with seven honeycomb subdivisions is a new foundation for offshore wind turbine structures. The bearing capacity of CBF can be improved by consolidation of soil inside the CBF, which is caused by the vacuum preloading method after installation. A three-dimensional numerical model is established to simulate the consolidation process of soil for CBF with and without subdivisions in terms of vertical settlement, pore water pressure and void ratio of the soil. This analysis investigates the reinforcement effect of the two foundation types to assess the influence of the bulkheads. The results obtained show that there are obvious reinforcement effects for both foundation types. In the early stage of consolidation, vertical settlement is rapid, and this becomes stable with time. The depth at which the pore water pressure becomes negative is the depth showing the main reinforcement. Vacuum pressure decreases continuously with increase in soil depth and time. In addition, the excess pore water pressure in the soil dissipates, which turns into the soil effective stress. Bulkheads provide vertical drainage channels in the soil and shorten the seepage path, allowing the extraction of more pore water. This is conducive to the improvement of shallow soil, while also decreasing the extraction of pore water in deep soil and the region of the soil that can be reinforced. Full article

Offshore wind power is an important of source renewable energy. As a new technology, the one-step integrated transportation and installation technology of offshore wind power has broader application prospects. In order to ensure stability during the towing process, it is necessary to study the behavior of the wind turbine transportation structure. The numerical model of the specialized transportation vessel was set up by MOSES software. An analysis in the frequency domain and time domain was conducted considering the effects of draft, speed, and wave height on the towing stability of the wind turbine transportation vessel. The results show that the one-step integrated transportation method can ensure stability of the wind turbine during the towing process. Reducing draft, increasing speed, and increasing wave height will reduce the towing stability of the wind turbine. In the practical towing process, the combination of various adverse situations will be avoided. Full article

The composite bucket foundation for offshore wind turbine bears the vertical load from not only the superstructure and the horizontal load, caused by wind and wave, but also from the torque load caused by rotating structures, such as blades. Based on layered soil foundation, the influence of the skirt height, the friction coefficient between soil and bucket foundation and the diameter of the bucket foundation on the stress of the bucket skirt under the torque load are studied in this paper. Moreover, the envelope curves of the bearing capacity of H–T and V–H–T are obtained by the fixed displacement ratio loading method. The bearing capacity characteristics of composite bucket foundation under different loading combinations are analyzed. The results show that: (1) The effect of inside soil on the bucket skirt is greater than that of the outside soil; (2) when composite loads are applied, the torque-bearing capacity decreases slowly with the increase of horizontal force, and when the horizontal force increases to a certain value, the value of the torque decreases significantly; and (3) the shape of the H–T failure envelope of the bucket foundation has no obvious change, vertical load have less effect on horizontal and torque load. Full article

Offshore wind turbine (OWT) structures are highly sensitive to complex ambient excitations, especially extreme winds. To mitigate the vibrations of OWT structures under windstorm or typhoon conditions, a new eddy current with tuned mass damper (EC-TMD) system that combines the advantages of the eddy current damper and the tuned mass damper is proposed to install at the top of them. In the present study, the electromagnetic theory is applied to estimate the damping feature of the eddy current within the EC-TMD system. Then, the effectiveness of the EC-TMD system for vibration mitigation is demonstrated by small-scale tests. Furthermore, the EC-TMD system is used to alleviate structural vibrations of the OWT supported by composite bucket foundations (CBF) under extreme winds at the Xiangshui Wind Farm of China. It is found that the damping of the EC-TMD system can be ideally treated as having linear viscous damping characteristics, which are influenced by the gaps between the permanent magnets and the conductive materials as well as the permanent magnet layouts. Meanwhile, the RMS values of displacements of the OWT structure can be mitigated by 16% to 28%, and the acceleration can also be reduced significantly. Therefore, the excellent vibration-reducing performance of the EC-TMD system is confirmed, which provides meaningful guidance for application in the practical engineering of OWTs. Full article

A two-step structural optimization method was proposed to select the transition section of a composite bucket foundation (CBF). In the first step, based on the variable density method, a solid isotropic microstructures with penalization (SIMP) interpolation model was established under specific load conditions and boundary conditions. The solution of force transmission path and the topology of the transition section in six forms (e.g., linear, arc-shaped, linear thin-walled, and arc-shaped thin-walled) were optimized. Afterwards, finite element software ABAQUS was used to verify this model. Results show that the utilization rate of the arc-shaped thin-walled structure was the largest, and its basic transmission force was more straightforward together with smaller cross-section size at the same height and smaller influence on spoiler flow. In the second step, the detailed optimization of CBF was carried out using mathematical programming. Under the premise of minimum total construction cost, the body shape parameters of each part were set as design variables satisfying the corresponding strength, stiffness, and stability conditions; meanwhile, the minimum total structure weight was set as the objective function. MATLAB was used to solve the sequence quadratic programming (SQP) algorithm and hybrid genetic algorithm, and the optimal body parameters were obtained. Full article

This paper elaborates on a new composite bucket foundation (CBF) structural system for offshore wind turbines. The proposed CBF consists of a special force transition section, a beam system structure upper steel bucket cover and a large-scale steel bucket with honeycomb structure rooms. It can be prefabricated onshore, self-floated on the sea and then towed to the appointed sea area before sinking to the sea soil under negative pressure. This is called the “one-step” installation technology. Arc- and line-type bucket foundations are calculated by both theory and the finite element method to discuss their force transfer paths and bearing modes. Owning to the special structural form, the transition section can effectively convert the huge load and bending moment into controllable tension and compressive stress, as well as adjust the structure balance. The bearing model and percentage of each part of the composite foundation under monotonous and ultimate load conditions are also calculated. Results indicate that the bearing mode of CBF is a typical top cover mode. In addition, the curvature impact of arc-type is studied and the results reveal that the structure type of the transition section is more important than the diameter ratio between the bottom transition section and the bucket. Full article
