Search Results (40)

To address the freezing damage to tunnel lining caused by frost heaving of the surrounding rock in water-rich tunnels in cold regions, a numerical thermo-mechanical coupling model for tunnel-surrounding rock that considers the anisotropy of frost heave deformation was established by examining overall frost heaves in a freeze–thaw cycle. Using a COMSOL Multiphysics 6.0 platform and the sequential coupling method, the temperature field evolution of tunnel-surrounding rock, freezing cycle development, and distribution characteristics of the frost heaving force of a tunnel lining under different minimum temperatures, numbers of negative temperature days, frost heave ratios, and anisotropy coefficients of frost heave deformation were systematically simulated. The results revealed that the response of the temperature field of tunnel-surrounding rock to the external temperature varies spatially with time lags, the shallow surface temperatures and the area around the lining fluctuate with the climate, and the temperature of the deep surrounding rock is dominated by the geothermal gradient. The extent of the freezing cycle and the frost heaving force increase significantly when lowering the minimum temperature. The maximum frost heaving force usually occurs in the region of the side wall and the spring line, and tensile stress is prone to be generated at the spring line; the influence of slight fluctuations in the minimum temperature or the short shift in the coldest day on the frost heaving force is limited. A substantial increase in frost heaving force is observed with higher frost heave ratios; for example, an increase from 0.25% to 2.0% results in a 116% rise at the sidewall. Although the increase in the anisotropy coefficient of frost heave deformation does not change the overall distribution pattern of frost heaving force, it can exacerbate the directional concentration of frost heave strain, which can increase the frost heaving force at the periphery of the top arch of the lining. This study revealed the distribution pattern and key influencing factors of the freezing cycle and frost heaving force for tunnels, providing a theoretical basis and data reference for the frost resistance design of tunnels in cold regions. Full article

Icing on transmission lines in cold regions can cause asymmetry in the conductor cross-section. This asymmetry can lead to low-frequency, large-amplitude oscillations, posing a serious threat to the stability and safety of power transmission systems. In this study, the aerodynamic characteristics of crescent-shaped and sector-shaped iced eight-bundled conductors were systematically investigated over an angle of attack range from 0° to 180°. A combined approach involving wind tunnel tests and high-precision computational fluid dynamics (CFD) simulations was adopted. In the wind tunnel tests, static aerodynamic coefficients and dynamic time series data were obtained using a high-precision aerodynamic balance and a turbulence grid. In the CFD simulations, transient flow structures and vortex shedding mechanisms were analyzed based on the Reynolds-averaged Navier–Stokes (RANS) equations with the SST k-ω turbulence model. A comprehensive comparison between the two ice accretion geometries was conducted. The results revealed distinct aerodynamic instability mechanisms and frequency-domain characteristics. The analysis was supported by Fourier’s fourth-order harmonic decomposition and energy spectrum analysis. It was found that crescent-shaped ice, due to its streamlined leading edge, induced a dominant single vortex shedding. In this case, the first-order harmonic accounted for 67.7% of the total energy. In contrast, the prismatic shape of sector-shaped ice caused migration of the separation point and introduced broadband energy input. Stability thresholds were determined using the Den Hartog criterion. Sector-shaped iced conductors exhibited significant negative aerodynamic damping under ten distinct operating conditions. Compared to the crescent-shaped case, the instability risk range increased by 60%. The strong agreement between simulation and experimental results validated the reliability of the numerical approach. This study establishes a multiscale analytical framework for understanding galloping mechanisms of iced conductors. It also identifies early warning indicators in the frequency domain and provides essential guidance for the design of more effective anti-galloping control strategies in resilient power transmission systems. Full article

This study examines freeze–thaw deterioration patterns and predicts the service life of wet-sprayed concrete with composite cementitious materials in cold-region tunnels. The microstructure and particle size distribution of four materials (cement, fly ash, silica fume, and mineral powder) were analyzed. Subsequent tests evaluated the rebound rate, mechanical properties, and durability of wet-sprayed concrete with various compositions and proportions of cementitious materials, emphasizing freeze–thaw resistance under cyclic freezing and thawing. A freeze–thaw deterioration equation was developed using damage mechanics theory to predict the service life of early-stage wet-sprayed concrete in tunnels. The results indicate that proportionally combining cementitious materials with different particle sizes and gradations can enhance concrete compactness. Adding mineral admixtures increases concrete viscosity, effectively reducing rebound rates and dust generation during wet spraying. Concrete incorporating binary and ternary mineral admixtures shows reduced early-age strength but significantly enhanced later-age strength. Its frost resistance is also improved to varying degrees. The ternary composite binder fills voids between cement particles and at the interface between paste and aggregate, resulting in a dense microstructure due to a ‘composite superposition effect.’ This significantly enhances the frost resistance of wet-mixed shotcrete, enabling it to withstand up to 200 freeze–thaw cycles, compared to failure after 75 cycles in plain cement concrete. The relative dynamic modulus of elasticity of wet-shotcrete follows a parabolic deterioration trend with increasing freeze–thaw cycles. Except for specimen P5 (R² = 0.89), the correlation coefficients of deterioration models exceed 0.94, supporting their use in durability prediction. Simulation results indicate that, across all regions of China, the service life of wet-shotcrete with ternary admixtures can exceed 100 years, while that of plain cement concrete remains below 41 years. Full article

Snowdrift, as a natural disaster, constantly compromises railway traffic by affecting how snow accumulates on the subgrade. This paper establishes a unified set of similarity criteria for wind tunnel testing, using viscous silica sand to simulate snow particles. By employing a geometric scale model (1:30) and similarity criteria (size, motion, dynamics, accumulation patterns, and time scales), it systematically investigates the evolution patterns of wind-induced snow accumulation on two types of roadbed structures: embankments and excavations. This study also evaluates the effectiveness of snow fences, proposing optimized placement distances and quantifying the effects of snow accumulation platform width. The results showed the following: (1) Snow on embankments has a “U”-shaped distribution, with the lowest wind speed (<0.5 m/s) and maximum accumulation at the leeward slope’s foot. In excavations, snow forms an “M”-shaped distribution, with significantly reduced wind speeds (<1 m/s) on the accumulation platform. (2) Snow fences effectively manage snow placement by lowering wind speed (below 1 m/s). A single-row snow fence with a porosity of 50% and a height of 3 m performs best when placed at seven times its height (7 H) from the slope’s toe. (3) A 5 m snow accumulation platform in excavations reduces surface snow accumulation (distribution coefficient drops to 1.6), outperforming scenarios without a platform (coefficient of 2.0). These findings contribute to the prevention and control of snowdrift disasters along railway lines in cold regions. They offer practical guidance for optimizing snow fence configurations, while also laying a foundation for future improvements in experimental accuracy through advanced techniques such as PIV and real-snow testing. Full article

The excavation of the rock mass at the tunnel entrance in regions characterized by high altitudes and elevated stress levels results in the direct exposure of the surrounding rock to atmospheric conditions. This surrounding rock is subjected to the compounded effects of excavation-induced unloading damage and freeze–thaw erosion, which contribute to the degradation of its mechanical properties. Such deterioration has a negative impact on production and construction operations. Following tunnel excavation, the lateral stress exerted by the surrounding rock at the tunnel face is reduced, leading to a predominance of uniaxial compressive stress. As a result, the failure mode and mechanical behavior of the rock exhibit characteristics similar to those observed in uniaxial loading tests conducted in controlled laboratory environments. This study conducts laboratory-based uniaxial loading and unloading tests, as well as freeze–thaw tests, to examine the strength, deformation characteristics, and fracture attributes of unloading sandstone subjected to freeze–thaw erosion. A damage deterioration model for unloading sandstone under uniaxial conditions is developed, and the patterns of damage response are further analyzed through the identification of compaction points and the definition of damage response points. The results indicate that (1) as the degree of freeze–thaw erosion increases, the failure threshold of the sandstone significantly decreases, with the residual rock fragments on the fracture surface transitioning from hard and sharp to soft and sandy; (2) freeze–thaw erosion has a pronounced negative impact on the cohesion of the sandstone, while the reduction in the internal friction angle is relatively moderate; and (3) the strain induced by damage following three, six, and nine freeze–thaw cycles exhibits a gradual decline and appears to reach a state of stabilization when compared to conditions without freeze–thaw exposure. Investigating the mechanical properties and deterioration mechanisms of the rock in this specific context is crucial for establishing a theoretical foundation to assess the stability of the tunnel’s surrounding rock and determine the necessary support measures. Full article

Frost damage is one of the main influencing factors for the deterioration of support structures in cold-region tunnels. A new dual transverse isotropic model of frozen rock mass is first proposed based on parameter strain and elastic modulus to serve as the theoretical basis for tunnel operation safety in cold regions. Subsequently, a unified elasto-plastic solution for high-speed railway tunnels in cold regions is derived based on the new dual transverse isotropic model, and the accuracy of the analytical solution is verified by comparisons with existing models and experimental results. Finally, the effect of the model parameters on stress and displacement is explored. The results reveal a significant negative correlation between the plastic radius of the frozen rock mass zone and the pressure acting on the inner surface of the support structure, the influence coefficient of intermediate principal stress, radial-gradient influence coefficient of the frozen rock mass, and anisotropic frost heave coefficient of the frozen rock mass, as well as between the frost-heaving force and the influence coefficient of intermediate principal stress parameter. However, the frost-heaving force is positively correlated with the pressure acting on the inner surface of the support structure, the radial gradient influence coefficient of the frozen rock mass, and the anisotropic frost heave coefficients of the frozen rock mass. Therefore, the pressure acting on the inner surface of the support structure, the radial gradient influence co-efficient of the frozen rock mass, and the anisotropic frost heave coefficients of frozen rock mass should be reasonably considered, but the strength theory of the surrounding rock should be strongly considered in the design of tunnel structures in cold regions. Full article

To improve the safety and stability of tunnel structures, developing grouting materials suitable for cold regions with excellent performance is crucial. Herein, waterborne polyurethane (WPU) was used to modify cement grouting materials. Through orthogonal testing analysis, the optimal mixing ratio of the modified cement grouting materials was determined to be as follows: a water–cement ratio of 0.5, hydroxypropyl methyl cellulose (HPMC) content of 0.05%, WPU content of 5%, water-reducing agent (WRA) content of 0.2%. Furthermore, the dynamic mechanical properties of grouting concretion stones were studied. The influence of various external parameters on the compressive strength of the grouting concretion stones cured for different ages was evaluated. The influence degree of stone particle size on the dynamic compressive strength of the grouting stone body was d_{5–10 mm} > d_{5–20 mm} > d_{5–30 mm}. The split Hopkinson pressure bar experiment was performed to show that for the same strain rate, the absorbed energy and energy utilization rate first increase and then decrease with increasing stone particle size. When the stone particle size was 5–20 mm, the absorption energy and energy utilization rate of the grouting stone body were the highest. Full article

Freezing damage to tunnels in cold regions has long posed a threat to the safe operation of high-speed trains and other means of transportation. Finding a reasonable and effective solution to this problem, while also considering green, low-carbon, energy-saving, and environmental protection measures, has garnered widespread attention. Herein, the concept of a novel coupled energy tunnel is proposed, which combines the technologies of an air curtain and ground source heat pump (GSHP). The aim is to effectively address the issue of freezing damage in tunnels located in cold regions, while ensuring traffic safety. First, the multifunctional experimental apparatus for testing the anti-freezing and insulation performance of a coupled energy tunnel was independently designed and developed for laboratory experiments. Second, single-factor experiments and orthogonal experiments are conducted, and the influences of five key factors (i.e., the air outlet hole diameter, air outlet hole spacing, circulating water temperature of the GSHP, wind speed at the tunnel model entrance, and airflow jet angle) on the internal temperature field of the tunnel model are discussed. Third, combined with range analysis and variance analysis, the ranking of importance for each key factor and the optimal scheme of the coupled energy tunnel are obtained as follows: wind speed at the tunnel model entrance D > circulating water temperature of GSHP C > airflow jet angle E > air outlet hole spacing B > air outlet hole diameter A, and the optimal scheme is A₂B₁C₄D₁E₂, i.e., the air outlet hole diameter is 3 mm, the air outlet hole spacing is 10 mm, the circulating water temperature of GSHP is 50 °C, the wind speed at the tunnel model entrance is 1.5 m/s and the airflow jet angle is 45°. In conclusion, the research achievements presented in this paper can offer a new perspective for the structural design of tunnels in cold regions. Additionally, they contribute to the early achievement of a carbon dioxide emissions peak and carbon neutrality, and provide some valuable and scientific references for both innovators and practitioners. Full article

Existing research into this topic primarily focuses on low-altitude areas, neglecting the impact of extreme environmental conditions such as low temperature, low oxygen level, and low pressure in high-altitude regions. Based on the smoke diffusion theory, a series of CFD numerical simulations were conducted in order to investigate the characteristics of smoke diffusion in the highway tunnel at high altitude. The results indicated that the increase in altitude would enhance the longitudinal propagation velocity of smoke, leading to a more pronounced impact on temperature, CO concentration, and visibility at characteristic heights. Meanwhile, the altitude intensifies the inhibitory impact of longitudinal ventilation on smoke diffusion upwind of the fire source and augments the acceleration effect on smoke diffusion downwind, thereby impeding personnel evacuation on the downwind side. By taking the hazardous range at a characteristic height under the impact of wind velocity and the deceleration of evacuation velocity due to altitude into consideration, a new recommended reduction factor was deduced to design adits for people passing spacing in highway tunnels at high altitude. The findings can serve as a valuable reference for the personal evacuation in high-altitude highway tunnel fires and the design of spacing between adits for people passing within such tunnels. Full article

The freeze–thaw effect has a significant impact on the strength deterioration of tunnel-lining concrete in cold regions. Therefore, the strength deterioration characteristics of concrete in a tunnel were studied, and silicone coating materials were used to improve its frost resistance and durability under freeze–thaw cycles. Freeze–thaw cycle tests were conducted on concrete specimens with different coatings. The freeze–thaw damage phenomenon, dynamic elastic modulus, and mass loss of the specimens were used to evaluate the freeze–thaw durability of concrete strengthened with coatings. The results demonstrated that silicone coatings effectively prevented moisture and corrosive substances from infiltrating the concrete, thereby enhancing its durability; the silicone–polyether hybrid had the most significant frost resistance at 500 g/m² and silane type III at 300 g/m², with freezing resistance times of 175 and 300, respectively. During the freeze–thaw process, the strength reduction rate of specimens was much greater than the mass loss rate of concrete. Taking into account the water environment surrounding the lining concrete and the site temperature, an equivalent indoor freeze–thaw cycle conversion model was established. The results can provide an experimental basis for selecting better frost-resistant materials for tunnel concrete in cold regions. Full article

(1) Background: Lining voids and macroscopic water freezing are both prominent issues that threaten driving safety in high-speed railway tunnels. With the continuous expansion of the scale of high-speed rail tunnels in extremely cold areas in China, the issues of lining voids, water accumulation, and frost heaving have triggered heated discussions. The need to reveal the frost-heave mechanism is urgent. (2) Methods: Firstly, a simulation experiment of the frost heaving of accumulated water was carried out based on the discharge conditions of accumulated water. Secondly, a numerical model was used to study the evolution process of frost heaves caused by accumulated water in voids. Finally, a drainage coefficient was introduced to propose a method for calculating the frost-heave force of accumulated water in voids. (3) Results: The blockage of the drainage channel leads to the generation of frost-heave force; the freezing/thawing process of the void water develops from the thinnest part to the thickest part of the void edge, and the freeze/thaw cycle of the water body causes the frost-heave force to become greater and greater in the evacuated cavity. The higher the height and the closer the drainage channel is to the hollow bottom, the greater the frost-heave force when the accumulated water freezes. (4) Conclusions: When the evacuated water freezes, it develops from the thinner edge to the thicker center. The magnitude of the frost-heave force is affected by the freeze/thaw cycle, the height of the evacuated cavity, and the position of the drainage channel. Full article

Wind turbines in cold and humid regions face significant icing challenges. Heating is considered an efficient strategy to prevent ice accretion over the turbine’s blade surface. An ice protection system is required to minimize freezing of the runback water at the back of the blade and the melting state of the ice on the blade; the law of re-freezing of the runback water is necessary for the design of wind turbine de-icing systems. In this paper, a wind tunnel test was conducted to investigate the de-icing process of a static heated blade under various rime icing conditions. Ice shapes of different thicknesses were obtained by spraying water at 5 m/s, 10 m/s, and 15 m/s. The spray system was turned off and different heating fluxes were applied to heat the blade. The de-icing state and total energy consumption were explored. When de-icing occurred in a short freezing time, the ice layer became thin, and runback water flowed out (pattern I). With an increase in freezing time at a low wind speed, the melting ice induced by the dominant action of inertial force moved backward due to the reduction in adhesion between the ice and blade surface (pattern II). As wind speed increased, it exhibited various de-icing states, including refreezing at the trailing edge (pattern III) and ice shedding (pattern IV). The total energy consumption of ice melting decreased as the heat flux increased and the ice melting time shortened. At 5 m/s, when the heat flux was q = 14 kW/m², the energy consumption at E_A at t_δ = 1 min, 5 min, and 7 min were 0.33 kJ, 0.55 kJ, and 0.61 kJ, respectively. At 10 m/s, when the heat flux was q = 14 kW/m², the energy consumption at E_A at t_δ = 1 min, 3 min, and 5 min were 0.77 kJ, 0.81 kJ, and 0.80 kJ, respectively. Excessive heat flow density increased the risk of the return water freezing; thus, the reference de-icing heat fluxes of 5 m/s and 10 m/s were 10 kW/m² and 12 kW/m², respectively. This paper provides an effective reference for wind turbine de-icing. Full article

Railway mountain tunnels were constructed in cold regions of Korea recently, and freezing has been generated. Most mountainous railway tunnels are designed with waterproofing membranes since groundwater exists on the backside of the tunnels. The lower air temperature inside the tunnel is transferred to the back of the tunnel lining as the outside air temperature drops below zero in winter, causing the groundwater behind the waterproofing membrane to freeze. There have been cases of freezing-related damage, such as the obstruction of drainage flow and freezing groundwater leakage. Therefore, the freezing conditions inside the tunnel should be analyzed by each tunnel length after the air temperature variation in the tunnel is measured. In this study, the air temperature inside a railway tunnel located in a cold region was measured using thermometers. The inside air temperature over time was changed by the DTR (diurnal temperature range) every 24 h. The DTR inside the tunnel was also reduced far from the entrance. Heat transfer analysis was implemented considering the air temperature variation inside the tunnel. Assuming that the minimum air temperature freezing inside the tunnel lasts seven days, the higher the minimum air temperature the longer the tunnel length. The research results show that the freezing inside a tunnel can be estimated from the tunnel length and the minimum air temperature inside the tunnel. Full article

Green construction is an advanced concept and development trend in engineering construction. It is cold and arid in frigid plateau regions in western China, where the ecological environment is vulnerable to engineering constructions and other human activities. Hence, the time and cost for environmental remediation are much larger than in other areas. Based on the principles and category of green construction, this paper discusses the overall and partial relationship between green construction and green construction operation, presents the technical construction process of the green construction of a tunnel, and puts forward the key points of green construction with the construction practice for tunnels in frigid plateau regions as the engineering background. The main contents and results are as follows: (1) The breakthrough points of the research on green construction include five first-level evaluation indicators of savings the land, energy, water resources, materials, and human resources, as well as protection for personnel health and environment, i.e., five savings and two protections. A comprehensive evaluation system suitable for green construction is proposed and established. (2) The paper summarizes the following essential aspects: the fine classification and safety evaluation of surrounding rock, the changes in the seepage field in the construction process, and the establishment of a standardized construction system. (3) A green construction evaluation was conducted on the tunnel of the Yindajihuang Project, and the green evaluation results were obtained. The evaluation results are basically consistent with the actual situation. In addition, intelligent construction technology should be the orientation of green construction for tunnels. The research would be helpful to the implementation of green construction ideas and technologies for tunnels in frigid plateau regions and the persistence of green and sustainable development. Full article

The design of tunnels in cold regions contributes greatly to the feasibility and sustainability of highways. Based on the heat transfer mechanism of the tunnel surrounding rock–lining–air, this paper uses FEPG software to carry out secondary excavation and development, then the air heat convection calculation model is established by using a three-dimensional extension of the characteristic-based operator-splitting (CBOS) finite-element method and the explicit characteristic–Galerkin method. By coupling with the heat conduction model of the tunnel lining and surrounding rock, the heat conduction-thermal convection fluid–structure interaction finite-element calculation model of tunnels in cold regions is established. Relying on the Qinghai Hekashan tunnel project, the temperature field of the tunnel portal section is calculated and studied by employing the fluid–structure interaction finite-element model and then compared with the field monitoring results. It is found that the calculated values are basically consistent with the measured values over time, which proves the reliability of the model. The calculation results are threefold: (1) The temperature of the air, lining, and surrounding rock in the tunnel changes sinusoidally with the ambient temperature. (2) The temperature of each layer gradually lags behind, and the temperature variation amplitude of the extreme value of the layer temperature gradually decreases with the increase in the radial distance of the lining. (3) In the vicinity of the tunnel entrance, the lining temperature of each layer remains unchanged, and the temperature gradually decreases or increases with the increase in the depth. The model can be used to study and analyze the temperature field distribution law of the lining and surrounding rock under different boundary conditions, and then provide a calculation model with both research and practical value for the study of the temperature distribution law of tunnels in cold regions in the future. Full article
