Search Results (366)

This study systematically investigates the high-velocity impact response and energy absorption characteristics of carbon fiber-reinforced plastic (CFRP)—aluminum foam (AlF) hybrid composite structures, aiming to address the growing demand for lightweight yet high-performance energy-absorbing materials in aerospace and protective engineering applications. Particular emphasis is placed on elucidating the influence of key geometric and material parameters, including the aspect ratio of the columns and the relative density of the AlF core. Experimental characterization was first performed using a split Hopkinson pressure bar (SHPB) apparatus to evaluate the dynamic compressive behavior of AlF specimens with four different relative densities (i.e., 0.163, 0.245, 0.374, and 0.437). A finite element (FE) model was then developed and rigorously validated against the experimental data, demonstrating excellent agreement in terms of deformation modes and force–displacement responses. Extensive parametric studies based on the validated FE framework revealed that the proposed CFRP-AlF composite structure achieves a balance between specific energy absorption (SEA) and peak crushing force, showing a significant improvement over conventional CFRP or AlF. The confinement effect of CFRP enables AlF to undergo progressive collapse along designated orientations, thereby endowing the CFRP-AlF composite structure with superior impact resistance. These findings provide critical insight for the design of next-generation lightweight protective structures subjected to extreme dynamic loading conditions. Full article

Carbon fiber-reinforced plastics (CFRPs) offer excellent in-plane mechanical performance, but their relatively low interlaminar fracture toughness makes them vulnerable to delamination, particularly around intralaminar discontinuities such as resin-rich regions or fiber gaps. This study investigates the effectiveness of polyamide (PA) mesh inserts in improving interlaminar toughness and suppressing delamination in CFRP laminates with such features. Two PA mesh configurations were evaluated: a fully embedded continuous layer and a 20 mm cut mesh strip placed between continuous and discontinuous plies near critical regions. Fracture toughness tests showed that PA mesh insertion improved interlaminar toughness approximately 2.4-fold compared to neat CFRP, primarily due to a mechanical interlocking mechanism that disrupts crack propagation and enhances energy dissipation. Uniaxial tensile tests with digital image correlation revealed that while initial matrix cracking occurred at similar stress levels, the stress at which complete delamination occurred was approximately 60% higher in specimens with a 20 mm mesh and up to 92% higher in specimens with fully embedded mesh. The fully embedded mesh provided consistent delamination resistance across the laminate, while the 20 mm insert localized strain redistribution and preserved global mechanical performance. These findings demonstrate that PA mesh is an effective interleaving material for enhancing damage tolerance in CFRP laminates with internal discontinuities. Full article

This study investigates mesh sensitivity in the buckling analysis of composite cylindrical shells using the finite element methods. Two Carbon Fiber-Reinforced Plastic (CFRP) models with distinct layups were subjected to linear (Eigenvalue) and non-linear (Riks) analyses under axial compression. Mesh sizes ranging from 50 mm to 2.5 mm were tested using Abaqus. The results revealed that the non-linear analysis is more mesh-sensitive and computationally demanding. Model-1 showed better convergence in non-linear analysis, with <1% error, while Model-2 favored linear analysis, with <0.5% error at finer meshes. The comparison of models results with the experimental data highlights the importance of an empirical correction factor. These findings provide practical guidelines for mesh selection in composite shell analysis. Full article

The thermal stability of carbon fiber-reinforced plastic (CFRP) materials is constrained by the low thermal conductivity of its polymer matrix, resulting in inefficient heat dissipation, local overheating, and accelerated degradation during thermal loads. To overcome these limitations, composite materials can be modified with buckypapers—thin, densely interconnected layers of carbon nanotubes (CNTs). In this study, sixteen 8552/IM7 prepreg plies were processed with up to nine buckypapers and strategically placed at various positions. The resulting nanocomposites were evaluated for manufacturability, material properties, and thermal resistance. The findings reveal that prepreg plies provide only limited matrix material for buckypaper infiltration. Nonetheless, up to five buckypapers, corresponding to 8 wt.% CNTs, can be incorporated into the material without inducing matrix depletion defects. This integration significantly enhances the material’s thermal properties while maintaining its mechanical integrity. The nanotubes embedded in the matrix achieve an effective thermal conductivity of up to 7 W/(m·K) based on theoretical modeling. As a result, under one-sided thermal irradiation at 50 kW/m², thermo-induced damage and strength loss can be delayed by up to 20%. Therefore, thermal resistance is primarily determined by the nanotube concentration, whereas the arrangement of the buckypapers affects the material quality. Since this innovative approach enables the targeted integration of high particle fractions, it offers substantial potential for improving the safety and reliability of CFRP under thermal stress. Full article

In recent times, fiber reinforced polymer composite materials have become more popular due to their remarkable features such as high specific strength, high stiffness and durability. Particularly, Carbon Fiber Reinforced Polymer (CFRP) composites are one of the most prominent materials used in the field of transportation and building engineering, replacing conventional materials due to their attractive properties as mentioned. In this work, a CFRP laminate is fabricated with carbon fiber mats and epoxy by a hand layup technique. Alumina (Al₂O₃) micro particles are used as a filler material, mixed with epoxy at different weight fractions of 0% to 4% during the fabrication of CFRP laminates. The important objective of the study is to investigate the influence of alumina micro particles on the mechanical performance of the laminates through characterization for various physical and mechanical properties. It is revealed from the results of study that the mass density of the laminates steadily increased with the quantity of alumina micro particles added and subsequently, the porosity of the laminates is reduced significantly. The SEM micrograph confirmed the constituents of the laminate and uniform distribution of Al₂O₃ micro particles with no significant agglomeration. The hardness of the CFRP laminates increased significantly for about 60% with an increase in weight % of Al₂O₃ from 0% to 4%, whereas the water gain % gradually drops from 0 to 2%, after which a substantial rise is observed for 3 to 4%. The improved interlocking due to the addition of filler material reduced the voids in the interfaces and thereby resist the absorption of water and in turn reduced the plasticity of the resin too. Tensile, flexural and inter-laminar shear strengths of the CFRP laminate were improved appreciably with the addition of alumina particles through extended grain boundary and enhanced interfacial bonding between the fibers, epoxy and alumina particles, except at 1 and 3 wt.% of Al₂O₃, which may be due to the pooling of alumina particles within the matrix. Inclusion of hard alumina particles resulted in a significant drop in impact strength due to appreciable reduction in softness of the core region of the laminates. Full article

Prefabricated unidirectional carbon fiber reinforced polymer (CFRP) composite strips are extensively used as a means of infrastructure rehabilitation through adhesive bonding to the external surface of structural concrete elements. Most data to date are from laboratory tests ranging from a few months to 1–2 years providing an insufficient dataset for prediction of long-term durability. This investigation focuses on the assessment of the response of three different prefabricated CFRP systems exposed to water, seawater, and alkaline solutions for 5 years of immersion in deionized water conducted at three temperatures of 23, 37.8 and 60 °C, all well below the glass transition temperature levels. Overall response is characterized through tensile and short beam shear (SBS) testing at periodic intervals. It is noted that while the three systems are similar, with the dominant mechanisms of deterioration being related to matrix plasticization followed by fiber–matrix debonding with levels of matrix and interface deterioration being accelerated at elevated temperatures, their baseline characteristics and distributions are different emphasizing the need for greater standardization. While tensile modulus does not degrade appreciably over the 5-year period of exposure with final levels of deterioration being between 7.3 and 11.9%, both tensile strength and SBS strength degrade substantially with increasing levels based on temperature and time of immersion. Levels of tensile strength retention can be as low as 61.8–66.6% when immersed in deionized water at 60 °C, those for SBS strength can be 38.4–48.7% at the same immersion condition for the three FRP systems. Differences due to solution type are wider in the short-term and start approaching asymptotic levels within FRP systems at longer periods of exposure. The very high levels of deterioration in SBS strength indicate the breakdown of the materials at the fiber–matrix bond and interfacial levels. It is shown that the level of deterioration exceeds that presumed through design thresholds set by specific codes/standards and that new safety factors are warranted in addition to expanding the set of characteristics studied to include SBS or similar interface-level tests. Alkali solutions are also shown to have the highest deteriorative effects with deionized water having the least. Simple equations are developed to enable extrapolation of test data to predict long term durability and to develop design thresholds based on expectations of service life with an environmental factor of between 0.56 and 0.69 for a 50-year expected service life. Full article

In the domain of agricultural machinery, the utilization of carbon fiber-reinforced plastics (CFRP) for structural components, such as the chassis, facilitates substantial weight reduction. To integrate additional components, stainless-steel connection points can be bonded to the CFRP chassis using adhesives. This study investigates surface preparation methods to enhance adhesive bonding strength at the coupon level. Three adhesives (DP490, MA8110, SG300) were tested on untreated, sandblasted, and sandpaper-grinded steel surfaces. Contrary to predictions, the highest strength (28.7 MPa) for DP490 was achieved after simple acetone cleaning, despite lower surface roughness (Ra = 1.60 µm), while sandblasting (Ra = 3.71 µm, 22 MPa) and grinding (Ra = 2.78 µm, 25.95 MPa) performed worse due to incomplete adhesive penetration. Subsequent tests on DP490 with laser structuring (Ra = 88.8 µm) and sandblasting with coating (Ra = 1.94 µm) provided strengths of 27.5 MPa and 29.3 MPa, respectively. The findings indicate that, under the examined conditions, surface cleanliness plays a more critical role in adhesive bonding strength than surface roughness. Practically, acetone cleaning is a cost-effective and time-efficient alternative to treatments like sandblasting or laser structuring. This makes it attractive for industrial use in agricultural machinery. While this study focuses on coupon-level surfaces, the findings provide a basis for scaling to component-level applications in future research. Full article

Based on the research on concrete-filled circular steel tubular columns, the influence of carbon-fiber-reinforced polymers (CFRPs) on the ultimate bearing capacity of concrete-filled steel tubes (CFSTs) was further explored in this paper. Ten different concrete-filled circular CFRP–steel middle long columns were made for an axial compression test, and the influence of the CFRP layers, the concrete strength grades, the steel tube wall thickness, and the slenderness ratio on the ultimate bearing capacity was discussed. Combined with theoretical analysis, the calculation method of ultimate bearing capacity of it was found. The load midspan deflection diagram was obtained by numerical simulation with finite element analysis software ANSYS2021R1, and the test results were compared. The results demonstrate that CFRP layers significantly enhance the ultimate bearing capacity of circular steel tube–CFRP confined concrete columns, with one to three layers increasing the capacity by 42.5%, 69.4%, and 88.4%, respectively, under identical conditions. In comparison, the concrete strength, the steel tube thickness, and the slenderness ratio showed lesser effects (<20% improvement), providing critical support for engineering applications of CFRP-confined circular steel tubular columns. Moreover, the error of ANSYS calculation results is small, which is in line with the test. This is of great significance to verify the correctness of the test of concrete-filled circular CFRP–steel middle long columns. Full article

Accurately evaluating the strength of adhesively bonded joints is essential for ensuring structural reliability, but size-dependent effects remain a challenge in consistent strength assessment. This study performs finite element simulations of Single Lap Shear (SLS) tests, focusing on the local stress state at fracture initiation. The analysis considers unidirectional and quasi-isotropic carbon fiber reinforced plastic (CFRP) adherends combined with three adhesives: polyphenylene sulfide (PPS), polyether ether ketone (PEEK), and epoxy. Adhesive thicknesses ranging from 0.1 mm to 0.5 mm are evaluated. The results indicate that the optimal thickness ranges between 0.1–0.3 mm to maximize joint strength, while excessively thin or thick layers reduce performance. These findings align with experimental trends and support the development of precise design guidelines for polymer-based joints in structural applications. Full article

Recycling carbon-fiber-reinforced plastics (CFRPs) is crucial for sustainable material utilization, particularly in aerospace applications, where large quantities of prepreg waste are generated. This study investigated the mechanical properties of highly oriented recycled CFRP (rCFRP) molded using vacuum-assisted resin transfer molding (VaRTM), wet-layup, and traditional RTM methods. Recycled carbon fibers (rCFs) obtained via solvolysis and pyrolysis were processed into nonwoven preforms to ensure fiber alignment through carding. The influence of molding methods, fiber recycling techniques, and fiber orientation on mechanical performance was examined through tensile tests, fiber volume fraction (Vf) analysis, and scanning electron microscopy observations. The results indicated that the solvolysis-recycled rCF exhibited superior interfacial adhesion with the resin, leading to a higher tensile strength and stiffness, particularly in the RTM process, where a high Vf was achieved. Wet-layup molding effectively reduced the void content owing to autoclave curing, maintaining stable properties even with pyrolyzed rCF. VaRTM, while enabling vacuum-assisted resin infusion, exhibited a higher void content, limiting improvements in mechanical performance. This study highlights that tailoring the molding method according to the desired performance, such as increasing stiffness potential by enhancing Vf in RTM or improving tensile strength by improving fiber–matrix adhesion in wet-layup molding, is critical for optimizing rCFRP properties, providing important insights into sustainable CFRP recycling and high-performance material design. Full article

To achieve laminates with constant bending stiffness to match the high precision requirement of optical systems made of carbon fiber reinforced plastic (CFRP), a new method, the normalized direction factor of bending stiffness (NDFBS), is proposed based on the normalized geometric factor of bending stiffness. Using NDFBS and its variance (VNDFBS), we investigate two common stacking patterns, I and II ([(θ₁)_m/(θ₂)_m/…/(θ_p)_m]_S and [(θ₁/θ₂/…/θ_p)_m]_S) and our proposed new stacking pattern, Pattern III ([(θ₁/θ₂/…/θ_p)_S]_m) based on the initial quasi-isotropic laminates, [θ₁/θ₂/…/θ_p]. The bending stiffness of the stacking sequence [(45/−45/0/90)_S]₂ tends to be more uniform than that of [45/−45/0/90]_2S, and the order of uniformity in bending stiffness of other stacking sequences is [(60/0/−60)_S]₄ > [60/0/−60]_4S > [(60/0/−60)_S]₂ > [60/0/−60]_2S. Both theoretical deviations and experimental observations confirm that as the cycle number m increased, the uniformity in bending stiffness is improved gradually, except for that of Pattern I. As the cycle number increased, the speed of Pattern III approaching the constant bending stiffness was faster than that of Patterns I and II_. Notably, to achieve a nearly identical uniformity in bending stiffness, only the square root of the cycle number of Pattern II was enough for Pattern III. Based on the same initial laminate and cycle number, Pattern III exhibited more uniform bending stiffness and strength, which are appropriate for precision optical components that require dimensional stability, such as space mirrors. Full article

The recycling of waste materials that are usually expensive to dispose of, such as carbon fiber reinforced plastic (CFRP) dust and ferrous dust or sludge, can open up interesting economic prospects and free up landfill space. The agglomeration process is used to combine these two types of waste and produce an aggregate that can be used in shaft furnaces. The carbon contained in the CFRP dust serves as a potential reducing agent in metallurgical processes. The report shows the technical parameters of the wet agglomeration with subsequent sintering for the production of the pellets and provides evidence of the material recycling of the carbon fiber waste. A comparison with primary pellets shows the suitability. Full article

Fiber-reinforced polymers (FRPs) are effective for strengthening masonry walls. Debonding at the polymer–masonry interface is a major concern, requiring further investigation into interface behavior. This study utilizes detailed micro-modeling finite element (FE) analysis to predict failure mechanisms and analyze the behavior of brick masonry walls strengthened with externally bonded carbon fiber-reinforced polymer (CFRP) under in-plane loading. The research investigates three CFRP strengthening configurations (X, I, and H). The FE model incorporates the nonlinear behavior of brick masonry components using the Concrete Damage Plasticity (CDP) model and uses a cohesive interface approach to model unit–mortar interfaces and the bond joints between masonry and CFRPs. The results demonstrate that diagonal CFRP reinforcement enhances the ductility and capacity of masonry wall systems. The FE model accurately captures the crack propagation, fracture mechanisms, and shear strength of both unreinforced and reinforced walls. The study confirms that the model can reliably predict the structural behavior of these composite systems. Furthermore, the study compares predicted shear strengths with established design equations, highlighting the ACI 440.7R-10 and CNR-DT 200/2013 models as providing the most accurate predictions when compared to experimental results. Full article

In the present research, laser circle welding (LCW) was proposed to join dual-phase steel (DP980) and carbon fiber-reinforced plastic (CFRP). The welding appearance, cross-section of the welded joint and fracture surfaces were subjected to multi-scale characterizations. Joining strength was evaluated by the single-lap shear test. Moreover, a numerical model was established based on the in-house finite element (FE) code JWRIAN-Hybrid to reproduce the thermal process of LCW. The results showed that successful bonding was achieved with a laser power higher than 300 W. The largest joining strength increased to about 1353.2 N (12.2 MPa) with 450 W laser power and then decreased under higher heat input. While the welded joint always presented brittle fracture, the joining zone could be divided into a squeezed zone (SZ), molten zone (MZ) and decomposition zone (DZ). The morphology of CFRP and chemical bonding information were distinct in each subregion. The chemical reaction between the O-C=O bond on the CFRP surface and the -OH bond on the DP980 sheet provided the joining force between dissimilar materials. Additionally, the developed FE model was effective in predicting the interfacial maximum temperature distribution of LCW. The influence of laser power on the joining strength of LCW joints was dualistic in character. The joining strength variation reflected the competitive result between joining zone expansion and local bonding quality change. Full article

The thermal protection system of a re-entry vehicle requires a high-heat-resistant heat shield to protect the spacecraft. Most of the ablative materials developed so far have high heat resistance but have technical issues such as long production times. In this study, we propose a new ablative material (LATS/PEEK) consisting of PEEK and carbon felt as a material that can solve these problems. PEEK has excellent properties such as a short production time and its ability to be produced using 3D printer technology. In addition, PEEK can be molded with a variety of fusion bonding methods, so it is possible to mold the heat shield and structural components as a single structure. However, heating tests conducted in previous research have confirmed the expansion phenomenon of CF/PEEK produced by 3D printers. The expansion of the ablative material is undesirable because it changes the aerodynamic characteristics during re-entry flight. Therefore, the purpose of this research is to clarify the mechanism of the expansion phenomenon of the ablative material based on PEEK resin. Therefore, we conducted thermal gravimetric analysis (TGA) and thermomechanical analysis (TMA) and concluded that the expansion phenomenon during the heating test was caused by the pressure increase inside the ablative material due to pyrolysis gas. Based on this mechanism, we developed a new 3D LATS/PEEK with a structure that can actively release pyrolysis gas, and we conducted a heating test using an arc-heating wind tunnel. As a result, it was found that 3D LATS/PEEK had less expansion and deformation during the heating test than CF/PEEK manufactured using a 3D printer. Full article
