Active distribution networks (ADNs) with high DER penetration require coordinated decisions to ensure voltage security, limit losses, and support low-carbon targets. However, most reconfiguration-centric studies prioritize loss/cost and rarely integrate carbon pricing and emission accounting into a unified framework with verifiable optimality. This study develops a DistFlow-based mixed-integer second-order cone programming (MISOCP) model that co-optimizes feeder reconfiguration and resource active/reactive dispatch under a price-calibrated loss–emission objective. The framework coordinates PV/WT generation, MTs, aggregated PHEVs (V2G), and reactive-support devices (SVCs and switched capacitor banks (CBs)) and is solved by commercial CPLEX to global optimality for the SOCP-relaxed problem. On the IEEE 33-bus feeder, device coordination reduces losses from 0.203 MW to 0.0382 MW (81.18%) and CO₂ emissions from 2.3872 to 0.3433 tCO₂ (85.62%), while reducing operating cost from CNY 354.9357 to CNY 56.6271 (84.05%). Enabling reconfiguration further reduces losses to 0.0205 MW (89.90%), emissions to 0.2580 tCO₂ (89.19%), and operating cost to CNY 37.4677 (89.44%), while keeping voltages within 0.99–1.01 p.u. Relative to device-only operation, reconfiguration yields 46.34% loss reduction, 24.85% emission reduction, and 33.83% operating-cost reduction. The mixed-integer optimality gap is ~10⁻⁷, and the solution quality for the original non-convex model depends on the tightness of the SOCP relaxation, which is numerically tight in the cases we studied. These results show interpretable technical and environmental gains via coordinated dispatch and topology control in radial ADNs at scale. Full article

Optimizing the operation of active distribution networks (ADNs) has become more challenging because of the uncertainty created by the high penetration level of distributed photovoltaic (PV). From the convex optimization perspective, this paper proposes a two-layer optimization model to simplify the solution of the ADN optimal operation problem. Firstly, to pick out the ADN “key” nodes, a “key” nodes selection approach that used improved K-means clustering algorithm and two indexes (integrated voltage sensitivity and reactive power-balance degree) is introduced. Then, a two-layer ADN optimization model is built using various time scales. The upper layer is a long-time-scale model with on-load tap-changer transformer (OLTC) and capacitor bank (CB), and the lower layer is a short-time-scale optimization model with PV inverters and distributed energy storages (ESs). To take into account the PV users’ interests, maximizing PV active power output is added to the objective. Afterwards, under the application of the second-order cone programming (SOCP) power-flow model, a linearization method of OLTC model and its tap change frequency constraints are proposed. The linear OLTC model, together with the linear models of the other equipment, constructs a mixed-integer second-order cone convex optimization (MISOCP) model. Finally, the effectiveness of the proposed method is verified by solving the IEEE33 node system using the CPLEX solver. Full article

This work proposes multi-objective two-stage distribution optimal power flow (D-OPF) to coordinate the use of smart inverters (SIs) and existing voltage control legacy devices. The first stage of multi-objective D-OPF aims to solve a mixed-integer nonlinear programming (MINLP) formulation that minimizes both voltage variation and active power loss, with SI modes, SI settings, voltage regulator (VR) taps, and capacitor bank (CB) status as control variables. The Pareto Optimal Solutions obtained from the first-stage MINLP are used to determine the optimal active–reactive power dispatch from the SIs by solving a nonlinear programming formulation in the second stage of the proposed D-OPF. This model guarantees that the setpoints for active–reactive power align with the droop characteristics of the SIs, ensuring practicability and the autonomous dispatch of active–reactive power by the SIs according to IEEE 1547-2018. The effectiveness of the proposed method is tested on the IEEE 123 distribution network by contrasting the two proposed D-OPF models, with one prioritizing SIs for voltage control and power loss minimization and the other not prioritizing SIs. The simulation results demonstrate that prioritizing SIs with optimal mode and droop settings can improve voltage control and power loss minimization. The proposed model (with SI prioritization) also reduces the usage of traditional grid control devices and optimizes the dispatch of active–reactive power. The POS also shows that the SI modes, droops, and legacy device settings can be effectively obtained based on the desired objective priority. Full article

As the penetration of distributed renewable energy increases, the phenomenon of bidirectional power flow in distribution networks becomes increasingly severe. Traditional regulation devices like OLTC (on-load tap changer) and CB (capacitor bank) cannot effectively mitigate reverse power flow in distribution networks due to their limitations. The transmission capacity of the distribution network under reverse power flow is approximately 50% of the rated capacity of the OLTC, leading to issues such as voltage limit violations and high wind and solar curtailment rates. This paper proposes a method for calculating the reverse power flow delivery capacity of distribution networks, quantitatively describing the distribution network’s delivery limits for reverse power flow. Based on this, a joint optimization model for multiple distribution networks with an SOP is established. The SOP is utilized to share reverse power flow delivery capacity among multiple distribution networks, enhancing operational economy and increasing the accommodation of the DG. Finally, the method’s effectiveness and correctness are verified in the IEEE 33-node system. The results validate that while joint operation does not enhance the reverse flow transmission capacity of a single distribution network, it can, through the shared reverse flow transmission capacity approach, elevate the reverse flow transmission capacity to approximately 70% during the majority of time periods. Full article

In this paper, an optimization approach based on an arithmetic optimization algorithm (AOA) is proposed for specifying the optimal allocation of distribution generations/generators (DGs) and capacitor banks (CBs) in radial distribution systems. The AOA is a new population-based meta-heuristic algorithm that is essentially based on using basic arithmetic operators in mathematics. The proposed approach is employed to specify the optimum placement, capacity, and power factor of DGs and CBs to decrease the distribution systems’ total power loss and voltage deviation. To state the performance of the proposed approach, DGs and CBs are placed in IEEE 33-bus and 69-bus systems separately or together. When only DGs are used and the parameters of location, capacity, and power factor of DGs are determined simultaneously, the total active power loss reductions in the IEEE 33-bus and 69-bus systems are achieved at 94.42% and 98.03%, respectively. When the results of other optimization algorithms are examined, it is seen that better results are obtained with AOA. Full article

To perform a capacitive current switching test (CCT) at AC extra-high-voltage (EHV) and above level, this paper proposes a new multi-transformer synthetic circuit (MTSC) test method that replaces the general synthetic test method using capacitor banks. An MTSC method has a simpler circuit structure compared to other synthetic testing methods and has higher equivalence (especially recovery voltage and TRV) and validity. Using this method, CCTs for circuit breakers (CBs) of the AC 420 kV voltage class were performed as a field test using the IEC 62271-100 standard. To verify that the test method was valid, test results were analyzed and compared with the requirements of a standard. Consequently, the MTSC method completely covered the requirements of the standard. Full article

Improving the performance of distribution systems is one of the main objectives of power system operators. This can be done in several ways, such as network reconfiguration, system reinforcement, and the addition of different types of equipment, such as distributed generation (DG) units, shunt capacitor banks (CBs), and voltage regulators (VRs). In addition, the optimal use of renewable and sustainable energy sources (RSESs) has become crucial for meeting the increase in demand for electricity and reducing greenhouse gas emissions. This requires the development of techno-economic planning models that can measure to what extent modern power systems can host RSESs. This article applies a new optimization technique called RUN to increase hosting capacity (HC) for a rural Egyptian radial feeder system called the Egyptian Talla system (ETS). RUN relies on mathematical concepts and principles of the widely known Runge–Kutta (RK) method to get optimal locations and sizes of DGs, CBs, and VRs. Furthermore, this paper presents a cost-benefit analysis that includes fixed and operating costs of the compensators (DGs, CBs, and VRs), the benefits obtained by reducing the power purchased from the utility, and the active power loss. The current requirements of Egyptian electricity distribution companies are met in the formulated optimization problem to improve the HC of this rural system. Uncertain loading conditions are taken into account in this study. The main load demand clusters are obtained using the soft fuzzy C-means clustering approach according to load consumption patterns in this rural area. The introduced RUN optimization algorithm is used to solve the optimal coordination problem between DGs, CBs, and VRs. Excellent outcomes are obtained with a noteworthy reduction in the distribution network power losses, improvement in the system’s minimum voltage, and improvement of the loading capacity. Several case studies are investigated, and the results prove the efficiency of the introduced RUN-based methodology, in which the probabilistic HC of the system reaches 100% when allowing reverse power flow to the utility. In comparison, this becomes 49% when allowing reverse power to flow back to the utility. Full article

Recently, the integration of distributed generators (DGs) in radial distribution systems (RDS) has been widely evolving due to its sustainability and lack of pollution. This study presents an efficient optimization technique named the honey badger algorithm (HBA) for specifying the optimum size and location of capacitors and different types of DGs to minimize the total active power loss of the network. The Combined Power Loss Sensitivity (CPLS) factor is deployed with the HBA to accelerate the estimation process by specifying the candidate buses for optimal placement of DGs and capacitors in RDS. The performance of the optimization algorithm is demonstrated through the application to the IEEE 69-bus standard RDS with different scenarios: DG Type-I, DG Type-III, and capacitor banks (CBs). Furthermore, the effects of simultaneously integrating single and multiple DG Type-I with DG Type-III are illustrated. The results obtained revealed the effectiveness of the HBA for optimizing the size and location of single and multiple DGs and CBs with a considerable decline in the system’s real power losses. Additionally, the results have been compared with those obtained by other known algorithms. Full article

Integration of Distributed generations (DGs) and capacitor banks (CBs) in distribution systems (DS) have the potential to enhance the system’s overall capabilities. This work demonstrates the application of a hybrid optimization technique the applies an available renewable energy potential (AREP)-based, hybrid-enhanced grey wolf optimizer–particle swarm optimization (AREP-EGWO-PSO) algorithm for the optimum location and sizing of DGs and CBs. EGWO is a metaheuristic optimization technique stimulated by grey wolves, and PSO is a swarm-based metaheuristic optimization algorithm. Hybridization of both algorithms finds the optimal solution to a problem through the movement of the particles. Using this hybrid method, multi-criterion solutions are obtained, such as technical, economic, and environmental, and these are enriched using multi-objective functions (MOF), namely minimizing active power losses, voltage deviation, the total cost of electrical energy, total emissions from generation sources and enhancing the voltage stability index (VSI). Five different operational cases were adapted to validate the efficacy of the proposed scheme and were performed on two standard distribution systems, namely, IEEE 33- and 69-bus radial distribution systems (RDSs). Notably, the proposed AREP-EGWO-PSO algorithm compared the AREP at the candidate locations and re-allocated the DGs with optimal re-sizing when the EGWO-PSO algorithm failed to meet the AREP constraints. Further, the simulated results were compared with existing optimization algorithms considered in recent studies. The obtained results and analysis show that the proposed AREP-EGWO-PSO re-allocates the DGs effectively and optimally, and that these objective functions offer better results, almost similar to EGWO-PSO results, but more significant than other existing optimization techniques. Full article

Distributed generation (DG) and capacitor bank (CB) allocation in distribution systems (DS) has the potential to enhance the overall system performance of radial distribution systems (RDS) using a multiobjective optimization technique. The benefits of CB and DG injection in the RDS greatly depend on selecting a suitable number of CBs/DGs and their volume along with the finest location. This work proposes applying a hybrid enhanced grey wolf optimizer and particle swarm optimization (EGWO-PSO) algorithm for optimal placement and sizing of DGs and CBs. EGWO is a metaheuristic optimization technique stimulated by grey wolves. On the other hand, PSO is a swarm-based metaheuristic optimization algorithm that finds the optimal solution to a problem through the movement of the particles. The advantages of both techniques are utilized to acquire mutual benefits, i.e., the exploration ability of the EGWO and the exploitation ability of the PSO. The proposed hybrid method has a high convergence speed and is not trapped in local optimal. Using this hybrid method, technical, economic, and environmental advantages are enhanced using multiobjective functions (MOF) such as minimizing active power losses, voltage deviation index (VDI), the total cost of electrical energy, and total emissions from generation sources and enhancing the voltage stability index (VSI). Six different operational cases are considered and carried out on two standard distribution systems, namely, IEEE 33- and 69-bus RDSs, to demonstrate the proposed scheme’s effectiveness extensively. The simulated results are compared with existing optimization algorithms. From the obtained results, it is observed that the proposed EGWO-PSO gives distinguished enhancements in multiobjective optimization of different conflicting objective functions and high-level performance with global optimal values. Full article

Reactive power compensation with Capacitor Banks (CBs) is one of the most successful approaches used in distribution systems, mainly due to their versatility, long-term acceptance in the power industry, and reduced costs. Most allocation methods, however, lack specific strategies to handle the limited discrete nature of CBs sizes seeking to improve the overall optimization and computational performance. We present an algorithm for the Optimal Placement of Capacitor Banks (OPCB) in distribution systems by means of a hybrid Flower Pollination Algorithm (FPA)–Exhaustive Search (ES) approach. The pollination process itself determines the sets of buses for placement, while CBs sizes and the final fitness values of each pollen are selected after a full-search is conducted in the sizing space. As the sizing phase works on the limited search space of predetermined discrete bank values, the computational effort to find the optimum CB capacity is greatly reduced. Tests were performed on distribution systems of 10, 34, and 85 buses with respect to the objective function, final losses, and voltage profile. The algorithm offers an excellent compromise between solution quality and computational effort, when compared to similar approaches. Full article

This paper proposes a coordinated voltage regulation method for active distribution networks (ADNs) to mitigate nodal voltage fluctuations caused by photovoltaic (PV) power fluctuations, where a three-stage optimization scheme is developed to coordinate and optimize the tap position of on-load tap changers (OLTCs), the reactive power of capacitor banks (CBs), and the active and reactive power of soft open points (SOPs). The first stage aims to schedule the OLTC and CBs hourly using the rolling optimization algorithm. In the second stage, a multi-objective optimization model of SOPs is established to periodically (15 min) optimize the active and reactive power of each SOP. Meanwhile, this model is also responsible for optimizing the Q-V droop control parameters of each SOP used in the third stage. The aim of the third stage is to suppress real-time (1 min) voltage fluctuations caused by rapid changes in PV power, where the Q-V droop control is developed to regulate the actual reactive power of SOPs automatically, according to the measured voltage at the SOPs’ connection points. Furthermore, numerous simulations and comparisons are carried out on a modified IEEE 33-bus distribution network to verify the effectiveness and correctness of the proposed voltage regulation method. Full article

Energy losses and bus voltage levels are key parameters in the operation of electricity distribution networks (EDN), in traditional operating conditions or in modern microgrids with renewable and distributed generation sources. Smart grids are set to bring hardware and software tools to improve the operation of electrical networks, using state-of the art demand management at home or system level and advanced network reconfiguration tools. However, for economic reasons, many network operators will still have to resort to low-cost management solutions, such as bus reactive power compensation using optimally placed capacitor banks. This paper approaches the problem of power and energy loss minimization by optimal allocation of capacitor banks (CB) in medium voltage (MV) EDN buses. A comparison is made between five metaheuristic algorithms used for this purpose: the well-established Genetic Algorithm (GA); Particle Swarm Optimization (PSO); and three newer metaheuristics, the Bat Optimization Algorithm (BOA), the Whale Optimization Algorithm (WOA) and the Sperm-Whale Algorithm (SWA). The algorithms are tested on the IEEE 33-bus system and on a real 215-bus EDN from Romania. The newest SWA algorithm gives the best results, for both test systems. Full article

This paper proposes a hierarchical look-ahead framework to conduct conservation voltage reduction (CVR) when distributed energy resources such as solar photovoltaic (PV) systems and energy storage systems (ESSs), and demand response programs are integrated into distribution systems. With the increasing deployment of PV systems in distribution systems, their frequently varying power output due to cloud movements could have a detrimental impact on the consumer’s voltage quality, consequently leading to degraded CVR performance. A two-level CVR framework for the coordination of an on-load tap changer (OLTC), capacitor banks (CBs), and the smart inverters of PV systems/ESSs is presented, in which these elements operate to reduce the voltage profile along the distribution feeder at different temporal scales. At the global level, the operations of the OLTC and the CBs are scheduled every hour to achieve the best CVR performance in an optimization problem using mixed-integer linear programming. When voltage violations occur rapidly, the smart inverters of PV systems and ESSs help to maintain a lower voltage profile every second based on the proposed piecewise droop control functions at the local level. A simulation study is carried out in an IEEE 33-bus distribution system with an OLTC, CBs, PV systems, and ESSs, and our results demonstrate the advantages of the proposed approach in terms of voltage level and energy savings. Furthermore, the impact of demand reduction on the proposed approach is quantified, and we verify that a higher demand reduction yields more energy savings in the proposed framework. Full article

Monitoring of abnormal events in a distribution feeder by using a single technique is a challenging task. A number of abnormal events can cause unsafe operation, including a high impedance fault (HIF), a partial breakdown to a cable insulation, and a circuit breaker (CB) malfunction due to capacitor bank de-energization. These abnormal events are not detectable by conventional protection schemes. In this paper, a new technique to identify distribution feeder events is proposed based on the complex Morlet wavelet (CMW) and on a decision tree (DT) classifier. First, the event is detected using CMW. Subsequently, a DT using event signatures classifies the event as normal operation, continuous and non-continuous arcing events (C.A.E. and N.C.A.E.). Additional information from the supervisory control and data acquisition (SCADA) can be used to precisely identify the event. The proposed method is meticulously tested on the IEEE 13- and IEEE 34-bus systems and has shown to correctly classify those events. Furthermore, the proposed method is capable of detecting very high impedance incipient faults (IFs) and CB restrikes at the substation level with relatively short detection time. The proposed method uses only current measurements at a low sampling rate of 1440 Hz yielding an improvement of existing methods that require much higher sampling rates. Full article
