Search Results (42)

The complex interference created by several sources for pipelines has not been sufficiently studied. In this study, four types of interference sources were monitored and analyzed. AC voltage monitoring, DC potential monitoring, current density monitoring, and excavation observation and measurement for test pieces and the decouplers were employed to assess the AC/DC interference of one real buried pipeline in situ. The peak value obtained from the second measurement at Pile 33 decreased from 1341.8 V to 143.7 V, indicating that the 1341.8 V in the first measurement may be caused by a sudden grounding of the electrode, while the 143.7 V may be caused by the normal induced voltage. The most negative DC interference potential between the pipeline and the Cu/CuSO₄ reference electrode was −11.946 V. The most positive DC interference potential between the pipeline and the Cu/CuSO₄ reference electrode was 4.862 V. Pile 3 had a maximum DC current density of 240 mA/m², and Pile 4 had a maximum AC current density of 0.615 A/m². After excavating the test piece at Pile 3, the point with maximum DC interference, there were obvious pitting corrosion characteristics, and the corrosion products were mainly γ-FeOOH and Fe₃O₄. It indicated that the coupling of long-term higher positive DC current density or (DC potential) and short-term higher transient AC voltage or (AC current density) may lead to corrosion. After excavating the test piece at the point with maximum AC interference, namely, Pile 4, there were no significant AC or DC corrosion characteristics. This finding suggested that the combination of long-term low AC current voltage or (low AC current density) and long-term more negative low DC current density or (DC potential) did not result in obvious corrosion. The decouplers in this measurement significantly reduced AC interference above 2 V, but the isolation of transient AC shocks and AC interference below 2 V were not significant. During analysis of AC and DC interference, in addition to considering the value of the interference, the duration time of the interference was also an important factor. Instantaneous sharp peaks cannot represent the long-term average voltage or potential current density. The average value should be used as the main basis for judgement, and the instantaneous value should be used as the secondary basis for judgement. Full article

In this study, a 3D model is developed to simulate multi-hole leakage scenarios in buried pipelines transporting hydrogen-blended natural gas (HBNG). By introducing three parameters—the First Dangerous Time (FDT), Ground Dangerous Range (GDR), and Farthest Dangerous Distance (FDD)—to characterize the diffusion hazard of the gas mixture, this study further analyzes the effects of the number of leakage holes, hole spacing, hydrogen blending ratio (HBR), and soil porosity on the diffusion hazard of the gas mixture during leakage. Results indicate that gas leakage exhibits three distinct phases: initial independent diffusion, followed by an intersecting accelerated diffusion stage, and culminating in a unified-source diffusion. Hydrogen exhibits the first two phases, whereas methane undergoes all three and dominates the GDR. Concentration gradients for multi-hole leakage demonstrate similarities to single-hole scenarios, but multi-hole leakage presents significantly higher hazards. When the inter-hole spacing is small, diffusion characteristics converge with those of single-hole leakage. Increasing HBR only affects the gas concentration distribution near the leakage hole, with minimal impact on the overall ground danger evolution. Conversely, variations in soil porosity substantially impact leakage-induced hazards. The outcomes of this study will support leakage monitoring and emergency management of HBNG pipelines. Full article

This study investigates the performance of Distributed Acoustic Sensing (DAS) for detecting gas pipeline leaks under controlled experimental conditions, using multiple fiber cable types deployed both internally and externally. A 21 m steel pipeline with a 1 m test section was configured to simulate leakage scenarios with varying leak sizes (¼”, ½”, ¾”, and 1”), orientations (top, side, bottom), and flow velocities (2–18 m/s). Experiments were conducted under two installation conditions: a supported pipeline mounted on tripods, and a buried pipeline laid on the ground and covered with sand. Four fiber deployment methods were tested: three internal cables of varying geometries and one externally mounted straight cable. DAS data were analyzed using both time-domain vibration intensity and frequency-domain spectral methods. The results demonstrate that leak detectability is influenced by multiple interacting factors, including flow rate, leak size and orientation, pipeline installation method, and fiber cable type and deployment approach. Internally deployed black and flat cables exhibited higher sensitivity to leak-induced vibrations, particularly at higher flow velocities, larger leak sizes, and for bottom-positioned leaks. The thick internal cable showed limited response due to its wireline-like construction. In contrast, the external straight cable responded selectively, with performance dependent on mechanical coupling. Overall, leakage detectability was reduced in the buried configuration due to damping effects. The novelty of this work lies in the successful detection of gas leaks using internally deployed fiber optic cables, which has not been demonstrated in previous studies. This deployment approach is practical for field applications, particularly for pipelines that cannot be inspected using conventional methods, such as unpiggable pipelines. Full article

Accurate localization of buried water pipelines in rural areas is crucial for maintenance and leak management but is often hindered by outdated maps and the limitations of traditional geophysical methods. This study aimed to develop and validate a multi-source remote-sensing workflow, integrating UAV (unmanned aerial vehicle)-borne near-infrared (NIR) surveys, multi-temporal Sentinel-2 imagery, and historical Google Earth orthophotos to precisely map pipeline locations and establish a surface baseline for future monitoring. Each dataset was processed within a unified least-squares framework to delineate pipeline axes from surface anomalies (vegetation stress, soil discoloration, and proxies) and rigorously quantify positional uncertainty, with findings validated against RTK-GNSS (Real-Time Kinematic—Global Navigation Satellite System) surveys of an excavated trench. The combined approach yielded sub-meter accuracy (±0.3 m) with UAV data, meter-scale precision (≈±1 m) with Google Earth, and precision up to several meters (±13.0 m) with Sentinel-2, significantly improving upon inaccurate legacy maps (up to a 300 m divergence) and successfully guiding excavation to locate a pipeline segment. The methodology demonstrated seasonal variability in detection capabilities, with optimal UAV-based identification occurring during early-vegetation growth phases (NDVI, Normalized Difference Vegetation Index ≈ 0.30–0.45) and post-harvest periods. A Sentinel-2 analysis of 221 cloud-free scenes revealed persistent soil discoloration patterns spanning 15–30 m in width, while Google Earth historical imagery provided crucial bridging data with intermediate spatial and temporal resolution. Ground-truth validation confirmed the pipeline location within 0.4 m of the Google Earth-derived position. This integrated, cost-effective workflow provides a transferable methodology for enhanced pipeline mapping and establishes a vital baseline of surface signatures, enabling more effective future monitoring and proactive maintenance to detect leaks or structural failures. This methodology is particularly valuable for water utility companies, municipal infrastructure managers, consulting engineers specializing in buried utilities, and remote-sensing practitioners working in pipeline detection and monitoring applications. Full article

Monitoring and early warning systems for cross-fault buried pipelines are critical measures to ensure the safe operation of oil and gas pipelines. Accurately acquiring pipeline strain response serves as the fundamental basis for achieving this objective. This study proposes a comprehensive analytical methodology combining finite element analysis (FEA) and experimental verification to investigate strain responses in cross-fault buried pipelines. Firstly, a finite element modeling approach with equivalent-spring boundaries was established for cross-fault pipeline systems. Secondly, based on the similarity ratio theory, an experimental platform was designed using Φ89 mm X42 steel pipes and in situ soil materials. Subsequently, the finite element model of the experimental conditions was constructed using the proposed FEA. Guided by simulation results, strain sensors were strategically deployed on test pipelines to capture strain response data under mechanical loading. Finally, prototype-scale strain responses were obtained through similarity ratio inverse modeling, and a comparative analysis with full-scale FEA results was performed. The results demonstrate that strike-slip fault displacement induces characteristic “S”-shaped antisymmetric deformation in pipelines, with maximum strain concentrations occurring near the fault plane. Both the magnitude and location of maximum strain derived from similarity ratio inverse modeling show close agreement with FEA predictions, with relative discrepancies within 18%. This consistency validates the reliability of the experimental design and confirms the accuracy of the finite element model. The proposed methodology provides valuable technical guidance for implementing strain-based monitoring and early warning systems in cross-fault buried pipeline applications. Full article

Based on a comprehensive research method combining a field test and numerical simulation, the dynamic response characteristics of a buried corroded gas pipeline under blasting are deeply explored, the numerical model parameters are verified, and the stress distribution of the pipeline is analyzed. It was found that the stress change of the pipeline is significantly affected by the elastic modulus, thickness, and defect length under the same blasting parameters. Increased elastic modulus and thickness can decrease stress, while increasing defect length can increase stress. Therefore, it is suggested that high-elastic-modulus materials should be given priority in pipeline design and material selection, pipeline thickness should be strictly controlled, and regular inspection and maintenance should be carried out. Especially for pipe sections with long defect length, monitoring and maintenance should be strengthened, and safety assessment and protection measures should be formulated before blasting operation to ensure the safe operation of the corrosive gas pipeline under the action of blasting vibration. Full article

To explore the calculation method of settlement and deformation of existing tunnels induced by excavation, the energy method is adopted to analyze the work done by the existing tunnels with additional loads during excavation and the additional stresses caused by shield cutter thrust, shield shell, etc. The study integrates Mindlin’s stress solution and three-dimensional Loganathan’s formula to determine the friction, grouting pressure, and stratum loss. The primary objective of this approach is to identify the settlement and deformation of the existing tunnel. It is envisaged that the deformation of tunnels can be resolved by minimizing the total potential energy of the system. Relying on a new construction project, part of the Macao Sewerage Pipeline, the reasonableness and accuracy of theoretical model are verified by comparing it with the results of on-site monitoring and numerical analysis. Meanwhile, parameter sensitivity analysis is carried out to determine the sensitivity factors, including tunnel depth, diameter, and ground loss rate, on the settlement of existing tunnel, and suggestions for optimization on project are provided. The findings demonstrate the efficacy of the theoretical method in predicting the settlement and deformation of existing tunnels. Furthermore, it is evident that it can mitigate the settlement of existing tunnels by increasing the depth of new tunnels. Additionally, expanding the diameter of excavation is also a significant factor. Conversely, an increase in excavation rate will lead to an enhancement in the loss of ground layer, thereby augmenting the settlement of existing tunnels. It is noteworthy that the diameter of excavation exerts the most substantial influence on the settlement, followed by the rate of loss of ground layer, and to a lesser extent, the depth of the buried tunnel. Full article

Water pipelines in water diversion projects can leak, leading to soil deformation and ground subsidence, necessitating research into soil deformation monitoring technology. This study conducted model tests to monitor soil deformation around leaking buried water pipelines using distributed fiber optic strain sensing (DFOSS) technology based on optical frequency domain reflectometry (OFDR). By arranging strain measurement fibers in a pipe–soil model, we investigated how leak location, leak size, pipe burial depth, and water flow velocity affect soil strain field monitoring results. The results showed that pipeline leakage creates a “saddle-shaped” spatial distribution of soil strain above the pipeline, effectively indicating ground subsidence locations. When only one survey line is arranged, it is preferable to place the optical fiber directly above the pipeline. Surface monitoring fibers primarily detected tensile strain, with more pronounced peak values observed under conditions of larger leak size, higher flow velocity, shallow burial depth, and top-pipe leakage location. Monitoring fibers below the pipeline showed mainly unimodal distribution, with peak strain coinciding with the leak location. The sequential timing of strain changes at different fiber positions enabled the determination of soil seepage direction. This study demonstrates that DFOSS technology can provide important support for the early warning of such geological disasters. Full article

This study investigates the impact of natural gas pipeline leakage on the soil temperature field through numerical simulations. Physical and mathematical models were developed to analyze the temperature and flow field changes resulting from pipeline leaks. The study explores the influence of various leakage factors on the temperature distribution in the surrounding soil. Key findings include the identification of the buried pipeline temperature as a critical factor influencing the soil temperature gradient when surface temperatures are similar to the subsurface constant temperature. Upon leakage, the pressure distribution around the leak is symmetrical, with a higher pressure at the leak point, and the Joule–Thomson effect causes a rapid decrease in gas temperature, forming a permafrost zone. The study also reveals that increased transport pressure expands the permafrost area, with pressure playing a significant role in the temperature field distribution. Additionally, an increase in the leak orifice diameter accelerates the expansion of the permafrost area and reduces the time for temperature stabilization at monitoring points. Conversely, changes in the leak direction mainly affect the spatial distribution of the permafrost zone without significantly altering its size. The findings provide valuable insights for monitoring natural gas pipeline leaks through temperature field variations. Full article

The implementation of large-diameter flood diversion pipelines in urban areas serves as an effective strategy to address urban waterlogging issues, which can enhance the resilience of cities to a certain extent against extreme precipitation events. This case study delineates the Zhengzhou Jinshui River flood diversion project, which employs the ultra-large-buried jacking prestressed concrete cylinder pipe (JPCCP), offering a summary and analysis of the pipe design and construction technologies employed in the JPCCP project within collapsible loess stratum, and the study also analyzes the pull-back scheme of the incident involving the front-end sinking of the machine head. Through on-site monitoring experiments, the variation patterns of contact pressure and slurry pressure of large-diameter JPCCPs were analyzed. The results demonstrate that the trends in contact pressure and slurry pressure exhibit a general consistency. During the jacking process, the pressure around the pipe can be categorized into three distinct phases based on grouting frequency or pressure, with notable variations in the pipe–soil–slurry contact state. The difference between the contact pressure and slurry pressure (termed as effective soil pressure) serves as a more accurate method for determining the pipe’s operational state. Moreover, the effective earth pressure at the pipe top demonstrates a higher degree of consistency with the calculation results prescribed by the standards ATV A161 and ASCE 27. Full article

This paper investigates the influence of harmonic content on the root mean square value of electromagnetic fields emitted by overhead power lines. The paper presents a methodology to assess the intensity of electric field and magnetic flux density, incorporating both fundamental frequencies and harmonics. The results of our calculations indicate that harmonic distortion in current waveforms can significantly increase the RMS value of magnetic flux density but its effect on electric field intensity is minimal. Additionally, our findings highlight a potential increase in induced voltages on buried or overhead steel pipelines in the vicinity of OPLs, which could pose risks such as pipeline damage and increased corrosion. This underscores the importance of considering harmonic content in EMF exposure evaluations to address both health risks and potential infrastructure impacts comprehensively. Effective harmonic management and rigorous infrastructure monitoring are essential to prevent potential hazards and ensure the reliability of protective systems. Full article

Research on the deformation characteristics and failure modes of buried pipelines under local suspension conditions caused by groundwater loss in coal mining subsidence areas is conducive to grasping the failure evolution law of pipelines and providing technical support for the precise maintenance of gathering and transportation projects and the coordinated mining of gas and coal resources. First, a test system for monitoring the deformation of pipelines under loading was designed, which mainly includes pipeline load application devices, end fixing and stress monitoring devices, pipeline end brackets, and stress–strain monitoring devices. Then, a typical geological hazard faced by oil and gas pipelines in the gas–coal overlap area—local suspension—was used as the engineering background to simulate the field conditions of a 48 mm diameter gas pipeline with a localized uniform load. At the same time, deformation, top–bottom strain, end forces, and damage patterns of the pipeline were monitored and analyzed. The results show that the strain at the top and bottom of the pipeline increased as the load increased. In this case, the top was under pressure, and the bottom was under tension, and the conditions at the top and bottom were opposite.. For the same load, the strain tended to increase gradually from the end to the middle of the pipeline, and at the top, it increased significantly more than at the bottom. The tensile force carried by the end of the pipeline increased as the applied load increased, and the two were positively correlated by a quadratic function. The overall deformation of the pipeline evolved from a flat-bottom shape to a funnel and then to a triangular shape as the uniform load increased. In addition, plastic damage occurred when the pipeline deformed into a triangular shape. The results of the investigation clarify for the first time the mathematical relationship between local loads and ultimate forces on pipelines and analyze the evolution of pipeline failure, providing a reference for pipeline field maintenance. Based on this, the maximum deformation of and the most vulnerable position in natural gas pipelines passing through a mining subsidence area can be preliminarily judged, and then the corresponding remedial and protection measures can be taken, which has a certain guiding role for the protection of natural gas pipelines. Full article

The China–Russia crude oil pipeline (CRCOP) operates at a temperature that continuously thaws the surrounding permafrost, leading to secondary periglacial phenomena along the route. However, the evolution and formation mechanisms of these phenomena are still largely unknown. We used multi-temporal airborne light detection and ranging (LiDAR), geophysical, and field observation data to quantify the scale of ponding and icing, capture their dynamic development process, and reveal their development mechanisms. The results show that the average depth of ponding within 5 m on both sides of the pipeline was about 31 cm. The volumes of three icings (A–C) above the pipeline were 133 m³, 440 m³, and 186 m³, respectively. Icing development can be divided into six stages: pipe trench settlement, water accumulation in the pipe trench, ponding pressure caused by water surface freezing, the formation of ice cracks, water overflow, and icing. This study revealed the advantages of airborne LiDAR in monitoring the evolution of periglacial phenomena and provided a new insight on the development mechanisms of the phenomena by combining LiDAR with geophysics and field observation. The results of our study are of great significance for developing disaster countermeasures and ensuring the safe operation of buried pipelines. Full article

Buried pipelines, as the most common method of natural gas transportation, are prone to pipeline leakage accidents and are difficult to detect due to their harsh and concealed environment. This paper focused on the problem regarding the free dissipation of residual gas in buried gas pipelines and soil after closing the gas supply end valve after a period of leakage by numerical simulation. A multiple non-linear regression model was established based on the least squares method and multiple regression theory, and MATLAB 2016b mathematical calculation software was used to solve the problem. The research results indicated that compared to the gas leakage diffusion stage, the pressure and velocity distribution during the free dissipation stage were significantly reduced. The increase in leakage time, pipeline pressure, leakage size, and pipeline burial depth led to a large accumulation of natural gas, which increased the concentration and distribution range of gas on the same free dissipation stage monitoring line. A prediction model for natural gas concentration in the free dissipation stage was established with an average error of 7.88%. A calculation model for the safety repair time of buried gas pipeline leakage accidents was further derived to determine the safety repair time of leakage accidents. Full article

Distributed optical fibre sensing (DOFS)-based strain measurement systems are now routinely deployed across infrastructure health monitoring applications. However, there are still practical performance and measurement issues associated with the fibre’s attachment method, particularly with thermoplastic pipeline materials (e.g., high-density polyethylene, HDPE) and adhesive affixment methods. In this paper, we introduce a new optical fibre installation method that utilises a hot-weld encapsulation approach that fully embeds the fibre onto the pipeline’s plastic surface. We describe the development, application and benefits of the new embedment approach (as compared to adhesive methods) and illustrate its practical performance via a full-scale, real-world, dynamic loading trial undertaken on a 1.8 m diameter, 6.4 m long stormwater pipeline structure constructed from composite spiral-wound, steel-reinforced, HDPE pipe. The optical frequency domain reflectometry (OFDR)-based strain results show how the new method improves strain transference and dynamic measurement performance and how the data can be easily interpreted, in a practical context, without the need for complex strain transfer functions. Through the different performance tests, based on UK rail-road network transport loading conditions, we also show how centimetre- to metre-scale strain variations can be clearly resolved at the frequencies and levels consistent with transport- and construction-based, buried infrastructure loading scenarios. Full article
