In the Karaganda coal basin, deteriorating geomechanical conditions have been observed, including seam disturbances, diminished strength of argillite–aleurolite strata, water ingress, and pronounced floor heave, all of which markedly increase the labor intensity of maintaining developmental headings. The maintenance and operation of these entries for a reference coal yield of 1000 t necessitate 72–75 man-shifts, of which 90–95% are expended on mitigating ground pressure effects and restoring support integrity. Conventional heave control measures—such as relief drifts, slotting, drainage, secondary blasting, and the application of concrete or rock–bolt systems—deliver either transient efficacy or incur prohibitive labor and material expenditures while lacking unified methodologies for predictive forecasting and support parameter design. This study therefore advocates for an integrated framework that synergizes geomechanical characterization, deformation prognosis, and the tailored selection of reinforcement schemes (incorporating both sidewall and floor-anchoring systems with directed preloading), calibrated to seam depth, geometry, and lithological properties. Employing deformation state assessments to optimize reinforcement layouts for floor stabilization in coal mine workings is projected to curtail repair volumes by 30–40% whilst significantly enhancing operational safety, efficiency, and the punctuality of face preparation. Full article

A novel endplate bolted rigid joint is proposed in this study for connecting circular concrete-filled steel tube (CCFT) columns to wide-flange (WF) steel beams. The seismic performance and potential failure mechanisms of the proposed joint were investigated through quasi-static cyclic tests and finite element (FE) simulations. This study aims to address several engineering challenges commonly observed in existing joint configurations, including an irrational force-resisting mechanism, complicated detailing and installation, on-site construction difficulties, constraints on beam size, and limited repairability. By optimizing the force transfer path, the new joint effectively reduces the number of critical tension welds, thereby enhancing the ductility and reliability. The experimental results indicate that the joint exhibits adequate flexural strength, stiffness, and ductility, with stable moment–rotation hysteresis loops under cyclic loading. Moreover, full restoration of the joint can be achieved by replacing only the steel beam and endplate, facilitating post-earthquake repair. FE analysis reveals that, under the ultimate bending moment at the beam end, multiple through cracks develop in the high-strength grout—which serves as a key load-transferring component—and significant debonding occurs between the grout and the surrounding steel members. However, due to confinement from adjacent components, these internal cracks do not compromise the overall strength and stiffness of the joint. This research provides an efficient and practical connection solution, along with valuable experimental insights, for the application of CCFT columns in moment-resisting frames located in high seismic zones. Full article

End-users can design personalized furnishing products using remote web-based CAD systems. However, if these designs fail to incorporate design for disassembly (DfD) principles, the furniture’s subsequent repair, reconfiguration, recycling, and disposal can be significantly hindered. To address this drawback, this study supports DfD, a strategy that enables the creation of easily repairable, reusable, and recyclable furniture to reduce waste and environmental impact. Consequently, this review aims to classify and evaluate available furniture joinery systems for their suitability within DfD frameworks, ultimately promoting their implementation within CAD environments. To this end, various solutions were evaluated, including traditional joints, dowel/biscuit, hammered, directly screwed, snap-on, expandable, and cam/bolt fasteners. Based on a literature review and practical observations, the analyzed joinery systems were categorized into non-disassemblable, conditionally disassemblable, and fully disassemblable categories. Only the fully disassemblable solutions effectively align with DfD principles. The study postulates a preference for expandable and cam/bolt fasteners in furniture designs, noting that although snap-on fasteners can potentially support DfD, this outcome is not always ensured. To guarantee that the designed furniture adheres to the DfD principles, the following eight furniture design guidelines were formulated: develop web-accessible disassembly instructions, prioritize access to fast-wearing components, prioritize modularity, standardize parts in modules, label components, enable independent component removal, use materials that withstand repeated disassembly, and employ fully disassemblable joints. Full article

The pier-type repair equipment for bridges is a crucial branch of bridge emergency repair. However, the existing bridge pier repair equipment predominantly utilizes rod systems, which require substantial assembly work, hindering the rapid restoration of damaged bridges. Modular steel structure buildings, as a highly integrated form of prefabricated construction, can play a significant role in emergency rescue operations. Based on the modular architectural design concept, this paper proposes a new type of modular steel structure emergency repair pier joint that facilitates rapid assembly and connection between modular units. Using ABAQUS 2022 software to establish a finite element model of the joint, the bending performance under lateral displacement loads perpendicular to the joint opening direction (X-direction in the model coordinate system) and parallel to the joint opening direction (Z-direction in the model coordinate system) is analyzed. The influence of the width-to-thickness ratio of the upper corner piece base plate D/t₁ (where D is the width of the upper corner piece base plate and t₁ is the thickness of the upper corner plate), the height-to-thickness ratio of the lower corner piece top plate h/t₂ (where h is the height of the protrusion of the lower corner piece and t₂ is the thickness of the lower corner piece top plate), the height of the protrusion of the lower corner piece (h), and the bolt diameter (d) on the bending performance of the joint is investigated. Recommendations for the design values of the joint are provided. Then, the flexural behavior of the joint under 0.1, 0.2, and 0.3 axial compression ratios is studied, respectively. The results show that with the increase of axial compression ratio, the yield rotation angle and ultimate rotation angle of the joint decrease, and the bearing capacity decreases faster after the joint reaches the ultimate bearing capacity. When the joint is subjected to the X-direction horizontal lateral displacement load, the initial flexural stiffness and flexural capacity of the joint increase with an increase in the axial compression ratio. When subjected to the horizontal lateral displacement load in the Z-direction, the initial bending stiffness of the joint increases with an increase in the axial compression ratio, and the bending capacity does not change much. In addition, the joint is classified; from the perspective of load-bearing capacity, it is a partially resistant joint, and from the perspective of stiffness, it is a semi-rigid joint. Finally, a simplified calculation model for the joint is proposed based on the component method. Full article

Steel bridges often experience bolt loosening and even fatigue fracture due to fatigue load, forced vibration, and other factors during operation, affecting structural safety. This study proposes a high-precision bolt key point positioning and recognition method based on deep learning to address the high cost, low efficiency, and poor safety of current bolt loosening identification methods. Additionally, a bolt loosening angle recognition method is proposed based on digital image processing technology. Using image recognition data, the angle-preload curve is revised. The established correlation between loosening angle and pretension for commonly utilized high-strength bolts provides a benchmark for identifying loosening angles. This finding lays a theoretical foundation for defining effective detection intervals in future bolt loosening recognition systems. Consequently, it enhances the system’s ability to deliver timely warnings, facilitating swift manual inspections and repairs. Full article

Composite materials are widely used in aircraft due to the urgent need for high-quality structures in aerospace engineering. In order to verify the effectiveness of complex bolt repairs on composite structures, compression tests have been performed on three types (intact, damaged, and repaired) of composite plate specimens, and finite element simulation results of these three types’ specimens were obtained. The experimental results show that for damaged composite laminates, the strength recovery after bolt repair can reach an impressive 107%, and the delamination propagation caused by over-buckling deformation is considered to be the main cause of failure, which also suggests that although bolt repair can improve the strength of the specimens, it has a limited ability to inhibit delamination propagation. The simulation results of the finite element model in this paper are in good agreement with the actual experimental results, and the maximum error does not exceed 7.9%. In conclusion, this paper verifies the suitability of the proposed repair scheme in engineering applications and the correctness of the modeling method for repaired composite laminates. Full article

This paper introduces a modular, assembled steel beam-column flange connection joint that efficiently connects prefabricated beams and columns using high-strength bolts. It enables the rapid repair of damaged joints after earthquakes by replacing flange connectors and high-strength bolt groups. Four joint specimens with varying thicknesses and lengths of the inner flange sleeve, scaled at a 1:2 ratio, were fabricated to evaluate performance. These specimens were subjected to low circumferential reciprocal loads to investigate damage modes, hysteresis curves, skeleton curves, ductility performance, energy dissipation capacity, and seismic performance, including stiffness degradation. The test and analysis results reveal that the primary failure mode is characterized by bulging of the flange jacket cover, with damage concentrated in the plastic hinge zone at the beam end. The flange connection joint exhibits excellent load-bearing, rotational, and energy dissipation capacities. The ‘secondary strengthening’ feature significantly enhances joint load-bearing capacity, ductility performance, and energy dissipation, increasing overall safety redundancy. Increasing the thickness and length of the flange connector substantially improves seismic performance and enlarges the plastic development area. Full article

This paper describes an innovative method developed by the authors to support basic decisions concerning the structural restoration of a large historical panel painting which had been damaged by inappropriate attachment to a wall and ongoing exposure to severe changes in environmental humidity. The Lapidazione di Santo Stefano is a large panel (2.78 × 3.92 m²) painted by Giorgio Vasari in 1571 and has been housed since then in the Church of Santo Stefano dei Cavalieri in Pisa (Italy). Its wooden support is made of large horizontal planks glued together along their edges and stiffened by vertical, dovetailed crossbeams. The panel was tightly fastened to a church wall with several rigid bolts; due to the moisture cycling produced by rainwater leakage and a subsequent “compression set”, it had developed severe tension stresses perpendicular to the grain, resulting in cracks affecting both the wood and the paint layers. To decide how to carry out the structural restoration of the panel, it was necessary to know whether slippage could occur between the panel and crossbeams during seasonal variations in environmental humidity. Without slippage, tensile stresses would be generated in the wood and could produce further cracks and damage the paint layers. An in situ monitoring method for assessing the possibility of slippage was developed and implemented. An analysis of data collected over a period of 6 months before the structural restoration confirmed that adequate slippage was possible; hence, the decision to fully repair the cracks was taken. Monitoring continued for a year after restoration and confirmed the previous findings. This paper describes the monitoring method, the equipment used, the results of its implementation and its value as a preventive conservation tool. Full article

High-strength bolts play a crucial role in ultra-high-pressure equipment such as bridges and railway tracks. Effective monitoring of bolt conditions is of paramount importance for common fault repair and accident prevention. This paper aims to detect and classify bolt corrosion levels accurately. We design and implement a bolt corrosion classification system based on a Wireless Acoustic Emission Sensor Network (WASN). Initially, WASN nodes collect high-speed acoustic emission (AE) signals from bolts. Then, the ReliefF feature selection algorithm is applied to identify the optimal feature combination. Subsequently, the Extreme Learning Machine (ELM) model is utilized for bolt corrosion classification. Additionally, to achieve high prediction accuracy, an improved goose algorithm (GOOSE) is employed to ensure the most suitable parameter combination for the ELM model. Experimental measurements were conducted on five classes of bolt corrosion levels: 0%, 25%, 50%, 75%, and 100%. The classification accuracy obtained using the proposed method was at least 98.04%. Compared to state-of-the-art classification diagnostic models, our approach exhibits superior AE signal recognition performance and stronger generalization ability to adapt to variations in working conditions. Full article

Uneven settlement of transmission tower foundations can result in catastrophic events, such as tower collapse and line failures, disrupting power transmission operations. To address the challenging repairs caused by uneven foundation settlement of transmission towers, we propose an adjustable foundation bolt (AFB). This paper provides a detailed theoretical analysis of the AFB’s stability and load-bearing capacity, including critical buckling force formulas and maximum normal stress expressions. Finite element simulations confirm the precision of our theoretical formulations. Additionally, we introduce a method using baffles to enhance its load-bearing capacity, analyzing the impact of different numbers of baffles through numerical simulations. The experimental results validate the effectiveness of baffles in enhancing structural load-bearing capacity. The device brings convenience and efficiency to the maintenance of transmission towers. Full article

To reduce the damage to reinforced concrete shear walls in earthquakes and repair costs, a self-centering wall with sloped plane friction dampers (SPFDs) is proposed. In addition to the SPFDs, the proposed wall includes a precast composite wall, steel wall toes, and post-tensioned (PT) tendons. The steel wall toes embedded in the base of the precast wall were used to improve its strength, and the SPFDs installed in the steel toes were used to increase its energy dissipation capacity. To investigate the effect of the initial PT force and prestressing clamping force of the friction bolt on the seismic performance of the wall, quasistatic cyclic loading tests were carried out on three precast wall specimens. The damage to the self-centering walls was slight, the residual drift was small, and the energy dissipation met the specification requirements. The wall with the greater initial PT force showed higher self-centering and bearing capacity, and the wall with higher prestressing clamping forces showed greater energy dissipation capacity. Additionally, a calculation method for the bearing capacity of the precast wall, which was verified by comparison with the test results, is suggested. Full article

The use of column-tree connections is common in controlled shop environments due to their cost-effectiveness in achieving ductile welds. Field bolts are also easy to install and inspect. However, there is currently no prequalification available for these connections, their performance is not fully understood, and the cost of aftermath repairs is still a major concern for owners. In this research, analytical and numerical studies were performed to assess the cyclic behavior considering the effects of the bolted splice location, bolt slippage, and splice plate thickness. Fourteen numerical models using the finite element method in ANSYS software were analyzed to evaluate the nonlinear behavior of moment connection configurations in terms of the strength, stiffness, ductility, energy dissipation, and overall cyclic response. The results showed that appropriately proportioned bolted splice connections can meet the requirements for prequalified moment connections. The models complied with the criteria established in AISC 358 and achieved flexural resistance that was higher than 80% of the beam plastic moment at 4% of the interstory drift ratio. The weakened plates concentrated the inelastic action, which allowed us to prevent the brittle behavior and damage to the column, welding, and other components of the moment connection. Complex geometries or specially fabricated parts were not required, providing a cost-effective way to control seismic-related damage. Also, required repairs are based on the replacement of standard parts, reducing operational detentions in facilities. Finally, the moment connection studied is classified as partially restrained (PR) according to the requirements established in AISC 360. Full article

To prevent brittle damage and improve the post-earthquake rapid repair capability of beam-column connections, a precast reduced beam section (PRBS) connection joint that can be rapidly repaired under earthquake action was proposed in this study. Four specimens, including a repaired specimen, were subjected to a quasi-static test to investigate the seismic performance and repair ability of the connection. Seismic performance indices such as the failure mode, hysteresis curve, skeleton curve, strain distribution, and ductility were obtained through observations and analyses. The results indicated that the novel connection exhibited superior load-bearing, energy dissipation, and rotation capacities, compared to the welded flange-bolted web and traditional bone-weakened connections. This novel connection effectively relocated the plastic hinge to alter the failure mode and prevent brittle damage. Additionally, rapid post-earthquake repair was achieved by replacing the dog-bone-style splice section, maintaining a high load-bearing capacity and seismic performance. Finite element (FE) models were established to analyze the mechanical behavior of the specimens, and a parametric analysis was conducted to study the influence of different parameters on the load-bearing capacity of the connection. Based on the experimental and FE analysis results, the possible yield and failure modes of the connection were analyzed, and a calculation method for the bearing capacity of the PRBS connection was proposed. A comparative result demonstrates that the proposed calculation method can accurately predict the load-carrying capacity of a connection. Full article

The use of FRP materials to repair cracked/damaged steel structures has gradually been adopted by researchers. This paper investigates the repairing effect of bolted FRP plates for cracked steel plates based on experimental and numerical simulation methods. In the experimental investigation, the tensile strengths of six specimens, including three repaired specimens and three pure cracked steel specimens, were evaluated. The test outcomes indicated that the bolt repairing method significantly enhanced the tensile strengths of the cracked steel plates. As an example, the failure of a pure steel plate with a 1 mm width crack occurred at 813 N, whereas after being repaired, a tensile strength of 1298 N was observed. Based on finite element (FE) analysis, the influence of bolt preloads and interfacial friction coefficients were verified. The stress-relative ratio for specimens was contingent on the bolt preload magnitude and gradually decreased as the preload was augmented. By exploring the repairing effect for varied friction coefficients, it was concluded that using a higher bolt preload can aid in eliminating the performance discrepancy of the overall component caused by interface treatment errors. Full article

With the continuous utilization of renewable energy, the number of onshore wind turbines is increasing. Small design improvements can save costs and facilitate the maintenance and repair of the wind turbine foundation. In this paper, an existing gravity expansion foundation with an anchor cage is improved. Our improvements further expand the space inside the foundation and reduce the length of the anchor bolt, which could reduce the costs and facilitate construction. To study the performance of the new foundation, a three-dimensional finite element model of the foundation–soil–anchor bolt was established via a finite element simulation. The damage evolution of the foundation was simulated with the concrete damage plasticity model (CDP). The separation ratio, foundation settlement, inclination ratio, reinforcement stress, foundation stress, and foundation damage of the new foundation under ultimate load conditions were analyzed. The influence of parameters h1 and b3 on the performance of the foundation was further studied. The finite element analysis results show that the tensile stress of concrete can be effectively reduced by appropriately increasing the corbel height and ring beam width of the foundation. The results also show that the improved wind turbine foundation force is reasonable and can meet the use of the actual project requirements on the level of finite element analysis. Full article
