A novel dual-band multi-linear polarization reconfigurable (MLPR) antenna for body-centric wireless communication systems (BWCS) is presented in this paper. The design comprises five symmetrically arranged multi-branch radiating units, each integrating an elliptical patch and curved spring branch for the Medical Implant Communication Service (MICS) band (403–405 MHz), and a pair of orthogonal strip patches for the Industrial, Scientific and Medical (ISM) $2.45$ GHz band (2.40–2.48 GHz). By selectively biasing PIN diodes between each unit and a central pentagonal feed, five distinct LP states with polarization directions of $0^{\circ }$, ${72}^{\circ }$, ${144}^{\circ }$, ${216}^{\circ }$, and ${288}^{\circ }$ are achieved. A dual-line isolation structure is introduced to suppress mutual coupling between radiating units, ensuring cross-polarization levels (XPLs) better than $-15.0$ dB across the operation bands. Prototypes fabricated on a $160\times 160\times 1.5$ mm³ substrate demonstrate measured $|S_{11}|<-10$ dB across 401–409 MHz and 2.34–2.53 GHz and stable omnidirectional patterns despite biasing circuitry perturbations. The compact form and robust dual-band, multi-polarization performance make the proposed antenna a promising candidate for implantable device wake-up signals and on-body data links in dense indoor environments. Full article

Wireless Body Area Networks (WBANs) are human-centric wireless networks, and implantable antennas represent a vital communication component within WBANs. The dielectric properties of human tissue are highly complex, with each layer exhibiting distinct dielectric constants that significantly influence the performance of implanted antennas. It is therefore imperative that a compact broadband implantable antenna be designed in order to address the instability in communication of medical implant devices. The antenna, coated in silicone, is a single-layer structure fed by a coaxial cable, with a volume of just 6 mm × 6 mm× 0.53 mm. A metallic patch is etched on the upper surface of the substrate, and the compact antenna design is enhanced with the introduction of S-shaped, F-shaped, and rectangular slots on the patch. The bottom side of the substrate is etched with rectangular ground planes, which broaden the impedance bandwidth of the antenna. The simulation results demonstrate that the antenna attains an impedance bandwidth of 23.8% (2.08–2.64 GHz), encompassing the entirety of the Industrial, Scientific, and Medical (ISM) band (2.4–2.48 GHz). In order to simulate the working environment of the antenna within the human body, physical tests were conducted on the antenna in pork tissue. The test results demonstrate that the antenna exhibits a measured bandwidth of 28% (2.3–3.03 GHz), with a radiation pattern that displays omnidirectional radiation characteristics. The antenna’s impedance matching and radiation characteristics remain essentially consistent in both bent and unbent states, indicating structural robustness. In comparison to other implantable antennas, this antenna displays a wider impedance bandwidth, a lower Specific Absorption Rate (SAR), and superior implant performance. Full article

This review provides a comprehensive analysis of the design, materials, fabrication techniques, and applications of flexible wearable antennas, with a primary focus on their roles in Wireless Body Area Networks (WBANs) and healthcare technologies. Wearable antennas are increasingly vital for applications that require seamless integration with the human body while maintaining optimal performance under deformation and environmental stress. Return loss, gain, bandwidth, efficiency, and the SAR are some of the most important parameters that define the performance of an antenna. Their interactions with human tissues are also studied in greater detail. Such studies are essential to ensure that wearable and body-centric communication systems perform optimally, remain safe, and are in compliance with regulatory standards. Advanced materials, including textiles, polymers, and conductive composites, are analyzed for their electromagnetic properties and mechanical resilience. This study also explores innovative fabrication techniques, such as inkjet printing, screen printing, and embroidery, which enable scalable and cost-effective production. Additionally, solutions for SAR optimization, including the use of metamaterials, electromagnetic band gap (EBG) structures, and frequency-selective surfaces (FSSs), are discussed. This review highlights the transformative potential of wearable antennas in healthcare, the IoT, and next-generation communication systems, emphasizing their adaptability for real-time monitoring and advanced wireless technologies, such as 5G and 6G. The integration of energy harvesting, biocompatible materials, and sustainable manufacturing processes is identified as a future direction, paving the way for wearable antennas to become integral to the evolution of smart healthcare and connected systems. Full article

A conformal tri-band antenna tailored for flexible devices and body-centric wireless communications operating at the key frequency bands is proposed. The antenna is printed on a thin Rogers RT 5880 substrate, merely 0.254 mm thick, with an overall geometrical dimension of 15 × 20 × 0.254 mm³. This inventive design features a truncated corner monopole accompanied by branched stubs fed by a coplanar waveguide. The stubs, varying in length, serve as quarter-wavelength monopoles, facilitating multi-band functionality at 2.45, 3.5, and 5.8 GHz. Given the antenna’s intended applications in flexible devices and body-centric networks, the conformability of the proposed design is investigated. Furthermore, an in-depth analysis of the Specific Absorption Rate (SAR) is conducted using a four-layered human tissue model. Notably, the SAR values for the proposed geometry at 2.45, 3.5, and 5.8 GHz stand at 1.48, 1.26, and 1.1 W/kg for 1 g of tissue, and 1.52, 1.41, and 0.62 W/kg for 10 g of tissue, respectively. Remarkably, these values comfortably adhere to both FCC and European Union standards, as they remain substantially beneath the threshold values of 1.6 W/kg and 2 W/kg for 1 g and 10 g tissues, respectively. The radiation characteristics and performance of the antenna in flat and different bending configurations validate the suitability of the antenna for flexible devices and body-centric wireless communications. Full article

Medical cyber-physical systems (MCPS) represent a platform through which patient health data are acquired by emergent Internet of Things (IoT) sensors, preprocessed locally, and managed through improved machine intelligence algorithms. Wireless medical cyber-physical systems are extensively adopted in the daily practices of medicine, where vast amounts of data are sampled using wireless medical devices and sensors and passed to decision support systems (DSSs). With the development of physical systems incorporating cyber frameworks, cyber threats have far more acute effects, as they are reproduced in the physical environment. Patients’ personal information must be shielded against intrusions to preserve their privacy and confidentiality. Therefore, every bit of information stored in the database needs to be kept safe from intrusion attempts. The IWMCPS proposed in this work takes into account all relevant security concerns. This paper summarizes three years of fieldwork by presenting an IWMCPS framework consisting of several components and subsystems. The IWMCPS architecture is developed, as evidenced by a scenario including applications in the medical sector. Cyber-physical systems are essential to the healthcare sector, and life-critical and context-aware health data are vulnerable to information theft and cyber-okayattacks. Reliability, confidence, security, and transparency are some of the issues that must be addressed in the growing field of MCPS research. To overcome the abovementioned problems, we present an improved wireless medical cyber-physical system (IWMCPS) based on machine learning techniques. The heterogeneity of devices included in these systems (such as mobile devices and body sensor nodes) makes them prone to many attacks. This necessitates effective security solutions for these environments based on deep neural networks for attack detection and classification. The three core elements in the proposed IWMCPS are the communication and monitoring core, the computational and safety core, and the real-time planning and administration of resources. In this study, we evaluated our design with actual patient data against various security attacks, including data modification, denial of service (DoS), and data injection. The IWMCPS method is based on a patient-centric architecture that preserves the end-user’s smartphone device to control data exchange accessibility. The patient health data used in WMCPSs must be well protected and secure in order to overcome cyber-physical threats. Our experimental findings showed that our model attained a high detection accuracy of 92% and a lower computational time of 13 sec with fewer error analyses. Full article

The ever-growing ecosystem of the Internet of Things (IoT) integrating with the ever-evolving wireless communication technology paves the way for adopting new applications in a smart society. The core concept of smart society emphasizes utilizing information and communication technology (ICT) infrastructure to improve every aspect of life. Among the variety of smart services, eHealth is at the forefront of these promises. eHealth is rapidly gaining popularity to overcome the insufficient healthcare services and provide patient-centric treatment for the rising aging population with chronic diseases. Keeping in view the sensitivity of medical data, this interfacing between healthcare and technology has raised many security concerns. Among the many contemporary solutions, attribute-based encryption (ABE) is the dominant technology because of its inherent support for one-to-many transfer and fine-grained access control mechanisms to confidential medical data. ABE uses costly bilinear pairing operations, which are too heavy for eHealth’s tiny wireless body area network (WBAN) devices despite its proper functionality. We present an efficient and secure ABE architecture with outsourcing intense encryption and decryption operations in this work. For practical realization, our scheme uses elliptic curve scalar point multiplication as the underlying technology of ABE instead of costly pairing operations. In addition, it provides support for attribute/users revocation and verifiability of outsourced medical data. Using the selective-set security model, the proposed scheme is secure under the elliptic curve decisional Diffie–Hellman (ECDDH) assumption. The performance assessment and top-ranked value via the help of fuzzy logic’s evaluation based on distance from average solution (EDAS) method show that the proposed scheme is efficient and suitable for access control in eHealth smart societies. Full article

This paper reviews some prominent applications and approaches to developing smart fabrics for wearable technology. The importance of flexible and electrically conductive textiles in the emerging body-centric sensing and wireless communication systems is highlighted. Examples of applications are discussed with a focus on a range of textile-based sensors and antennas. Developments in alternative materials and structures for producing flexible and conductive textiles are reviewed, including inherently conductive polymers, carbon-based materials, and nano-enhanced composite fibers and fibrous structures. Full article

Long-range, low-power wireless technologies such as LoRa have been shown to exhibit excellent performance when applied in body-centric wireless applications. However, the robustness of LoRa technology to Doppler spread has recently been called into question by a number of researchers. This paper evaluates the impact of static and dynamic Doppler shifts on a simulated LoRa symbol detector and two types of simulated LoRa receivers. The results are interpreted specifically for body-centric applications and confirm that, in most application environments, pure Doppler effects are unlikely to severely disrupt wireless communication, confirming previous research, which stated that the link deteriorations observed in a number of practical LoRa measurement campaigns would mainly be caused by multipath fading effects. Yet, dynamic Doppler shifts, which occur as a result of the relative acceleration between communicating nodes, are also shown to contribute to link degradation. This is especially so for higher LoRa spreading factors and larger packet sizes. Full article

The development of biomedical devices benefits patients by offering real-time healthcare. In particular, pacemakers have gained a great deal of attention because they offer opportunities for monitoring the patient’s vitals and biological statics in real time. One of the important factors in realizing real-time body-centric sensing is to establish a robust wireless communication link among the medical devices. In this paper, radio transmission and the optimal characteristics for impedance matching the medical telemetry of an implant are investigated. For radio transmission, an integral coupling formula based on 3D vector far-field patterns was firstly applied to compute the antenna coupling between two antennas placed inside and outside of the body. The formula provides the capability for computing the antenna coupling in the near-field and far-field region. In order to include the effects of human implantation, the far-field pattern was characterized taking into account a sphere enclosing an antenna made of human tissue. Furthermore, the characteristics of impedance matching inside the human body were studied by means of inherent wave impedances of electrical and magnetic dipoles. Here, we demonstrate that the implantation of a magnetic dipole is advantageous because it provides similar impedance characteristics to those of the human body. Full article

In this paper a dual band, a dual band Planar Inverted F antenna (PIFA) is designed for wireless communication intended to be used in wireless body sensor networks. The designed PIFA operates at two different frequency bands, 2.45 GHz Industrial, Scientific and Medical band (ISM) and 5.2 GHz (HiperLAN band). In body-centric wireless networks, antennas need to be integrated with wireless wearable sensors. An antenna is an essential part of wearable body sensor networks. For on-body communications, antennas need to be less sensitive to human body effects. For body-centric communications, wearable devices need to communicate with the devices located over the surface, and there is a need of communication from on-body devices to off-body units. Based on this need, a dual band planar inverted F antenna is designed that works at two different frequency bands, i.e., 2.45 GHz and 5.2 GHz. The 2.45 GHz is proposed for establishing communication among the wireless sensor devices attached to the human body, while 5.2 GHz is proposed for the communications for from on-body to off-body devices. The proposed antenna is very compact, and due to having ground plane at the backside it is less sensitive to the effects of the human body tissues. Computer Simulation Technology (CST) microwave studio™ was used for antenna design and simulation purposes. Performance parameters such as return loss, bandwidth, radiation pattern and efficiency of this antenna are shown and investigated. These performance parameters of the proposed antenna have been investigated at free space and close proximity to the human body. Simulation results and analysis show that the performance parameters produce very good results for both frequency bands. Due to its compact size, low sensitivity to human body tissues, and dual band functionality, it will be a good candidate for wireless wearable body sensor networks. Full article

The demand for wearable technologies has grown tremendously in recent years. Wearable antennas are used for various applications, in many cases within the context of wireless body area networks (WBAN). In WBAN, the presence of the human body poses a significant challenge to the wearable antennas. Specifically, such requirements are required to be considered on a priority basis in the wearable antennas, such as structural deformation, precision, and accuracy in fabrication methods and their size. Various researchers are active in this field and, accordingly, some significant progress has been achieved recently. This article attempts to critically review the wearable antennas especially in light of new materials and fabrication methods, and novel designs, such as miniaturized button antennas and miniaturized single and multi-band antennas, and their unique smart applications in WBAN. Finally, the conclusion has been drawn with respect to some future directions. Full article

Nano-scaled structures, wireless sensing, wearable devices, and wireless communications systems are anticipated to support the development of new next-generation technologies in the near future. Exponential rise in future Radio-Frequency (RF) sensing systems have demonstrated its applications in areas such as wearable consumer electronics, remote healthcare monitoring, wireless implants, and smart buildings. In this paper, we propose a novel, non-wearable, device-free, privacy-preserving Wi-Fi imaging-based occupancy detection system for future smart buildings. The proposed system is developed using off-the-shelf non-wearable devices such as Wi-Fi router, network interface card, and an omnidirectional antenna for future body centric communication. The core idea is to detect presence of person along its activities of daily living without deploying a device on person’s body. The Wi-Fi signals received using non-wearable devices are converted into time–frequency scalograms. The occupancy is detected by classifying the scalogram images using an auto-encoder neural network. In addition to occupancy detection, the deep neural network also identifies the activity performed by the occupant. Moreover, a novel encryption algorithm using Chirikov and Intertwining map-based is also proposed to encrypt the scalogram images. This feature enables secure storage of scalogram images in a database for future analysis. The classification accuracy of the proposed scheme is 91.1%. Full article

Presently, smart and connected wearable systems, such as on-body sensors and head-mounted displays, as well as other small form factor but powerful personal computers are rapidly pervading all areas of our life. Motivated by the opportunities that next-generation wearable intelligence is expected to provide, the goal of this work is to build a comprehensive understanding around some of the user-centric security and trust aspects of the emerging wearable and close-to-body wireless systems operating in mass events and under heterogeneous conditions. The paper thus intends to bring the attention of the research community to this emerging paradigm and discuss the pressing security and connectivity challenges within a popular consumer context. Our selected target scenario is that of a sports match, where wearable-equipped users may receive their preferred data over various radio access protocols. We also propose an authentication framework that allows for delivery of the desired content securely within the considered ecosystem. Full article

Body-worn sensor networks are important for rescue-workers, medical and many other applications. Sensitive data are often transmitted over such a network, motivating the need for encryption. Body-worn sensor networks are deployed in conditions where the wireless communication channel varies dramatically due to fading and shadowing, which is considered a disadvantage for communication. Interestingly, these channel variations can be employed to extract a common encryption key at both sides of the link. Legitimate users share a unique physical channel and the variations thereof provide data series on both sides of the link, with highly correlated values. An eavesdropper, however, does not share this physical channel and cannot extract the same information when intercepting the signals. This paper documents a practical wearable communication system implementing channel-based key generation, including an implementation and a measurement campaign comprising indoor as well as outdoor measurements. The results provide insight into the performance of channel-based key generation in realistic practical conditions. Employing a process known as key reconciliation, error free keys are generated in all tested scenarios. The key-generation system is computationally simple and therefore compatible with the low-power micro controllers and low-data rate transmissions commonly used in wireless sensor networks. Full article

In this paper, a dual band planar inverted F antenna (PIFA) has been investigated for cooperative on- and off-body communications. Free space and on-body performance parameters like return loss, bandwidth, radiation pattern and efficiency of this antenna are shown and investigated. The on- and off-body radio propagation channel performance at 2.45 GHz and 1.9 GHz have been investigated, respectively. Experimental investigations are performed both in the anechoic chamber and in an indoor environment. The path loss exponent has been extracted for both on- and off-body radio propagation scenarios. For on-body propagation, the path loss exponent is 2.48 and 2.22 in the anechoic chamber and indoor environment, respectively. The path loss exponent is 1.27 for off-body radio propagation situation. For on-body case, the path loss has been characterized for ten different locations on the body at 2.45 GHz, whereas for off-body case radio channel studies are performed for five different locations at 1.9 GHz. The proposed antenna shows a good on- and off-body radio channel performance. Full article
