Search Results (40)

Due to its advantages, such as its corrosive sulfur-free property and high purity, gas-to-liquid (GTL) oil is regarded as an excellent alternative to conventional naphthenic mineral oil in the oil/paper composite insulation of UHV converter transformers. In such application scenarios, under the condition of voltage polarity reversal, charge accumulation is likely to occur along the liquid/solid interface, which leads to the distortion of the electric field, consequently reducing the breakdown voltage of the insulating material, and leading to flashover in the worst case. Therefore, understanding such space charge characteristics under polarity-reversed voltage is key for the insulation optimization of GTL oil-filled converter transformers. In this paper, a typical GTL oil is taken as the research object with naphthenic oil as the benchmark. Electroacoustic pulse measurement technology is used to study the space charge accumulation characteristics and electric field distribution of different oil-impregnated paper insulations under polarity-reversed conditions. The experimental results show that under positive–negative–positive polarity reversal voltage, the gas-impregnated pressboard exhibits significantly higher rates of space charge density variation and electric field distortion compared with mineral oil-impregnated paper. In stage B, the dissipation rate of negative charges at the grounded electrode in GTL oil-impregnated paper is 140% faster than that in mineral oil-impregnated paper. In stage C, the electric field distortion rate near the electrode of GTL oil-impregnated paper reaches 54.15%. Finally, based on the bipolar charge transport model, the microscopic processes responsible for the differences in two types of oil-immersed papers are discussed. Full article

A cable accessory is a critical component in constructing high-voltage direct current (HVDC) power grids, and it is typically composed of multiple materials. Due to the discontinuity of the insulation medium, it is prone to failure. This study focuses on a two-layered composite insulation medium simplified from HVDC cable accessories, and its surface potential decay (SPD) characteristics are related to the space charge transport characteristics. Previous studies on surface charge migration have been limited and primarily focused on single-layered insulation materials. However, the actual insulation structure is mostly composite. Therefore, it is of great practical significance to explore the surface charge migration characteristics of two-layered structures. This study presents a bipolar charge transport model after pre-depositing surface charges to investigate the surface charge migration characteristics of an ethylene–propylene–diene monomer (EPDM)/polyethylene (PE) two-layered polymer film. The effects of charge injection and trap related to nano-doping, local defects, and thermal aging on the surface potential decay (SPD) and space charge distribution in EPDM/PE were analyzed. The results show that the increase in the electron injection barrier slows surface charge dissipation and inhibits charge accumulation at the interface. An increase in the trapping coefficient leads to a higher surface potential in the stable state and a greater space charge density. During the early depolarization stage, the SPD rate is weakly dependent on the trap depth, with charge migration primarily governed by the external electric field. Full article

Aqueous zinc-ion batteries (AZIBs) have attracted interest for their low cost and environmental friendliness. Two bipolar organic materials with different degrees of conjugation, pPMQT and pNTQT, were rationally designed and synthesized as cathode candidates for AZIBs based on 4,4′-diaminotriphenylamine (TPA), 2,7-diaminoanthraquinone (AQ), and two anhydrides. This molecular design features an increased conjugation and electron cloud density, thereby improving charge transport kinetics, specific capacity, and cycling stability. In comparison with pPMQ and pNTQ (n-type), pPMQT and pNTQT demonstrate better electrochemical characteristics. In this work, pNTQT shows outstanding performance. It exhibits an initial capacity of 349.79 mAh g⁻¹ at 0.1 A g⁻¹ and retains a specific capacity of 190.25 mAh g⁻¹ (87.6%) after 5000 cycles at 5 A g⁻¹. In comparison, pNTQ demonstrates a specific capacity of only 207.55 mAh g⁻¹ at 0.1 A g⁻¹, and after 5000 cycles at 5 A g⁻¹, its capacity retention rate is only 81.2%. At the same time, both pPMQT and pNTQT polymer films demonstrate attractive electrochromic (EC) properties, displaying reversible color transitions from yellow to dark blue in the UV–visible spectrum. This work lays the foundation for the further development of triphenylamine-based polyimide materials for application in AZIBs and electrochromism. Full article

Resistive switching (RS) memory devices are gaining recognition as data storage devices due to the significant interest in their switching material, Halide perovskite (HP). The electrical characteristics include hysteresis in its current–voltage (I–V) relationship. It can be attributed to the production and migration of defects. This property allows HPs to be used as RS materials in memory devices. However, 3D HPs are vulnerable to moisture and the surrounding environment, making their devices more susceptible to deterioration. The potential of two-dimensional (2D)/quasi-2D HPs for optoelectronic applications has been recognized, making them a viable alternative to address current restrictions. Two-dimensional/quasi-2D HPs are created by including extended organic cations into the ABX₃ frameworks. By adjusting the number of HP layers, it is possible to control the optoelectronic properties to achieve specific features for certain applications. This article presents an overview of 2D/quasi-2D HPs, including their structures, binding energies, and charge transport, compared to 3D HPs. Next, we discuss the operational principles, RS modes (bipolar and unipolar switching), in RS memory devices. Finally, there have been notable and recent breakthroughs in developing RS memory systems using 2D/quasi-2D HPs. Full article

Herein we report on a facile sol-gel spin-coating technique to fabricate ZnO thin films that grow preferentially along the (002) plane on FTO substrates. By employing the magnetron sputtering technique to deposit a tungsten (W) top metal electrode onto these ZnO thin films, we successfully realize a W/ZnO/FTO memory device that exhibits self-rectifying and forming-free resistive switching characteristics. Notably, the as-prepared device demonstrates impressive nonvolatile and bipolar resistive switching behavior, with a high resistance ratio (R_HRS/R_LRS) exceeding two orders of magnitude at a reading voltage of 0.1 V. Moreover, it exhibits ultralow set and reset voltages of approximately +0.5 V and −1 V, respectively, along with exceptional durability. In terms of carrier transport properties, the low resistance state of the device is dominated by ohmic conduction, whereas the high resistance state is characterized by trap-controlled space-charge-limited current conduction. This work highlights the potential of the ZnO-based W/ZnO/FTO memory device as a promising candidate for future high-density nonvolatile memory applications. Full article

To achieve exceptional recyclable DC cable insulation material using thermoplastic polypropylene (PP), we have introduced the organic polar molecule styrene-maleic anhydride copolymer (SMA) into PP-based insulation materials following the principles of deep trap modification. PP, PP/SMA, PP/ethylene-octene copolymer (POE), and PP/POE/SMA insulating samples were prepared, and their meso-morphology, crystalline morphology, and molecular structure were comprehensively characterized. The results indicate that SMA can be uniformly dispersed in PP with minimal impact on the crystalline morphology of PP. The DC electrical properties of the materials were tested at temperatures of 30, 50, and 70 °C. The findings demonstrate that the introduction of SMA can improve the DC properties of the material in both PP and PP/POE. The thermal stimulated depolarization current results reveal that SMA can introduce deep traps into the material, thereby improving its DC properties, which is in agreement with the quantum chemical calculation results. Subsequently, a bipolar carrier transport model was employed for coaxial cables to simulate the space charge distribution in the insulation layer of the four sets of insulation samples as well as the actual cable in service. The results highlight that SMA can significantly suppress space charge in PP and PP/POE systems, and it exhibits excellent electric field distortion resistance. In summary, the results illustrate that SMA is expected to be used as an organic deep trap modifier in PP-based cable insulation materials. Full article

This paper proposes a nondestructive, separate transmitter-receiver (TX-RX) electromagnetic measurement system for near-surface detection. Different from the traditional dual-coil integrated design, the proposed transient electromagnetic (TEM) system performs shallow subsurface detection using independent TX coil and movable RX coils. This configuration requires a large primary field so that the far-away secondary field is able to generate reliably induced voltages. To achieve this goal, a bipolar current-pulsed power supply (BCPPS) with a late resonant charging strategy is designed to produce a sufficiently large magnetic moment for the exciting coil with low source interference. The magnetic dipole source (MDS) with a large proportion of weight is separated from the field observation device and does not need to be dragged or transported during the detection process. This setup lowers the weight of the scanning device to 3 kg and greatly improves the measurement efficiency. The results of the laboratory test verify the effectiveness of the separate MDS and RX module system. Field experimental detection further demonstrates that the proposed system can realize highly efficient and shallow surface detection within a 200 m range of the MDS device. Full article

Oil-impregnated paper condenser transformer bushings are an important part of transformer equipment, and partial discharge (PD) occurred when defects exist on the condenser aluminum foil layers. Firstly, to study the PD process of the oil-paper insulated capacitance graded bushing with the defect of broken aluminum foil, a defective oil-paper bushing discharge sample is constructed to study the PD parameters and capacitance, and to discharge carbonization traces at different voltage levels. Then, in order to verify the process of condenser aluminum foil layer discharge and the space charge variation in the oil-paper insulation system of a sample model, the surface flashovers of a needle-plane discharge model based on the bipolar charge transport model and the hydrodynamic model was built. The simulation, by Transport of Diluted Species physics of COMSOL Multiphysics software, points out the discharge process of aluminum foil electrode caused by space charge action and electric field distortion under an electric field at different voltages. The results of simulation and sample bushing experiments showed that the PD process of the defective condenser foil layer is mainly divided into three stages: tip corona discharge, streamer in oil, and surface flashovers. The voltage amplitude is larger the more electrical branches are discharged and the shorter the discharge time is. The findings of the article have important implications for the discharge of the foil layer inside the oil-paper bushing. Full article

Innovative ion exchange membranes have become commercially available in recent years. However, information about their structural and transport characteristics is often extremely insufficient. To address this issue, homogeneous anion exchange membranes with the trade names ASE, CJMA-3 and CJMA-6 have been investigated in Na_xH_(3−x)PO₄ solutions with pH 4.4 ± 0.1, 6.6 and 10.0 ± 0.2, as well as NaCl solutions with pH 5.5 ± 0.1. Using IR spectroscopy and processing the concentration dependences of the electrical conductivity of these membranes in NaCl solutions, it was shown that ASE has a highly cross-linked aromatic matrix and mainly contains quaternary ammonium groups. Other membranes have a less cross-linked aliphatic matrix based on polyvinylidene fluoride (CJMA-3) or polyolefin (CJMA-6) and contain quaternary amines (CJMA-3) or a mixture of strongly basic (quaternary) and weakly basic (secondary) amines (CJMA-6). As expected, in dilute solutions of NaCl, the conductivity of membranes increases with an increase in their ion-exchange capacity: CJMA-6 < CJMA-3 << ASE. Weakly basic amines appear to form bound species with proton-containing phosphoric acid anions. This phenomenon causes a decrease in the electrical conductivity of CJMA-6 membranes compared to other studied membranes in phosphate-containing solutions. In addition, the formation of the neutral and negatively charged bound species suppresses the generation of protons by the “acid dissociation” mechanism. Moreover, when the membrane is operated in overlimiting current modes and/or in alkaline solutions, a bipolar junction is formed at the CJMA- 6/depleted solution interface. The CJMA-6 current-voltage curve becomes similar to the well-known curves for bipolar membranes, and water splitting intensifies in underlimiting and overlimiting modes. As a result, energy consumption for electrodialysis recovery of phosphates from aqueous solutions almost doubles when using the CJMA-6 membrane compared to the CJMA-3 membrane. Full article

In this study, the bipolar switching properties and electrical conduction behaviors of the ITO thin films RRAM devices were investigated. For the transparent RRAM devices structure, indium tin oxide thin films were deposited by using the RF magnetron sputtering method on the ITO/glass substrate. For the ITO/ITO_X/ITO/glass (MIM) structure, an indium tin oxide thin film top electrode was prepared to form the transparent RRAM devices. From the experimental results, the 10² On/Off memory ratio and bipolar switching cycling properties for set/reset stable states were found and discussed. All transparent RRAM devices exhibited the obvious memory window and low set voltage for the switching times of 120 cycles. The electrical transport mechanisms were dominated by the ohmic contact and space charge limit conduction (SCLC) models for set and reset states. Finally, the transmittances properties of the transparent ITO/ITO_X/ITO RRAM devices for the different oxygen growth procedures were about 90% according to the UV–Vis spectrophotometer for the visible wavelength range. Full article

New derivatives of carbazole and diphenyl imidazole for potential multiple applications were synthesized and investigated. Their properties were studied by thermal, optical, photophysical, electrochemical, and photoelectrical measurements. The compounds exhibited relatively narrow blue light-emission bands, which is favorable for deep-blue electroluminescent devices. The synthesized derivatives of imidazole and carbazole were tested as fluorescent emitters for OLEDs. The device showed deep-blue emissions with CIE color coordinates of (0.16, 0.08) and maximum quantum efficiency of 1.1%. The compounds demonstrated high triplet energy values above 3.0 eV and hole drift mobility exceeding 10⁻⁴ cm²/V·s at high electric fields. One of the compounds having two diphenyl imidazole moieties and tert-butyl-substituted carbazolyl groups showed bipolar charge transport with electron drift mobility reaching 10⁻⁴ cm²/V·s at electric field of 8 × 10⁵ V/cm. The synthesized compounds were investigated as hosts for green, red and sky-blue phosphorescent OLEDs. The green-, red- and sky-blue-emitting devices demonstrated maximum quantum efficiencies of 8.3%, 6.4% and 7.6%, respectively. Full article

Molecules with donor–spacer–acceptor configuration have been developed rapidly given their peculiar properties. How to utilize intermolecular interactions and charge transfers for solution-processed organic light-emitting diodes (OLEDs) greatly relies on molecular design strategy. Herein, soluble luminophores with D-spacer-A motif were constructed via shortening the alkyl chain from nonane to propane, where the alkyl chain was utilized as a spatial linker between the donor and acceptor. The alkyl chain blocks the molecular conjugation and induces the existence of aggregation-induced intermolecular CT emission, as well as the improved solubility and morphology in a solid-state film. In addition, the length of the alkyl chain affects the glass transition temperature, carrier transport and balance properties. The mCP-3C-TRZ with nonane as the spacer shows better thermal stability and bipolar carrier transport ability, so the corresponding solution-processable phosphorescent organic light-emitting diodes exhibit superior external quantum efficiency of 9.8% when using mCP-3C-TRZ as a host material. This work offers a promising strategy to establish a bipolar host via utilizing intermolecular charge transfer process in an aggregated state. Full article

Zero-emission transportation is currently a public priority, especially in big cities. For this reason, the use of electric vehicles (EVs) is receiving much attention. To facilitate the adoption of EVs, a proper charging infrastructure together with energy management is essential. This article proposes a design guideline for a direct current (DC) charging station with bipolar properties. A bipolar system can convert a two-wire system into three wires in a microgrid system with a neutral line. The configuration of the bipolar system supports different loads; therefore, the unbalanced operation is inherent to the system. The proposed bipolar DC charging station (CS) has a three-level balancing converter that reduces the step-down effort chargers. Moreover, this paper proposes the continuous-control-set model predictive control (CCS-MPC)-based balancing strategy that allows the handling of different output loads while keeping the neutral-line voltage efficiently regulated with improved dynamic performance compared to a traditional controller. Stability and parameter robustness analyses are also performed for the control parameter selection. To ensure the performance of the proposed method, both simulation and experimental results are presented and compared with those obtained from the traditional methods. Full article

During the operation of HVDC extruded cables, voltage polarity reversal (VPR) is considered one of the most severe conditions for cable insulation. In this paper, a bipolar charge transport model developed for cylindrical geometry is improved by introducing ionic carriers from impurity dissociation for the simulation of space charge and electric field in an HVDC extruded cable with thick polymeric insulation under VPR, and the construction of the geometric model is based on a practical 160 kV DC polymeric cable. The influence of polarity reversal period (PRP) and temperature gradient (TG), formed by the load current flowing through the conductor, on the space charge evolution and the electric field distribution are investigated. The mechanisms of the charge dynamics and the field distortion affected by the PRP and the TG are also discussed. The results show that under TG, the maximum transient field appears near the interface between the conductor shield and insulation in the early stage of complete VPR. In addition, the longer the PRP, the more serious the maximum transient field distortion. Moreover, an increase in TG intensifies the maximum field distortion under steady and transient states due to the enhancement of heterocharge accumulation. Full article

In an HVDC environment, space charge accumulated in polymeric insulators causes severe electric field distortion and degradation of breakdown strength. To analyze the breakdown characteristics, here, the space charge distribution was numerically evaluated using the bipolar charge transport (BCT) model, considering the temperature gradient inside the polymeric insulator. In particular, we proposed an electro-mechanical threshold energy condition, resulting in the modified molecular chain displacement model. The temperature gradient accelerates to reduce the breakdown strength with the polarity-reversal voltage, except during the harshest condition, when the temperature of the entire polymeric insulator was 70 °C. The energy imbalance inside the insulator caused by polarity-reversal voltage reduced the breakdown strength by 82%. Finally, this numerical analysis model can be used universally to predict the breakdown strength of polymeric insulators in various environments, and help in evaluating the electrical performance of polymeric insulators. Full article
