Search Results (17)

Accidental ground surcharge loads can induce adverse effects such as segment cracking in underlying shield tunnel structures, with particularly pronounced impacts on pre-damaged tunnel segments. Cracks represent one of the most common initial damage forms in shield tunnel structures. To investigate through-crack failure mechanisms in shield tunnel segments with initial cracks under surcharge loading, this study conducted 1:8 scaled indoor model tests, considering factors including initial crack length, quantity, morphology, and surcharge position. Research findings demonstrate that increased initial crack length and quantity significantly reduce the critical load required for through-crack formation. Specifically, segments with 9 cm longitudinal initial cracks required 50.9% less load to develop through-cracks compared to intact segments. Similarly, segments containing two 9 cm circumferential initial cracks exhibited a 22.1% reduction in critical load relative to those with single circumferential cracks. Initial cracks in pre-damaged segments substantially influence the propagation path of new cracks during subsequent loading failures. The detrimental effects of staggered longitudinal-circumferential initial cracks exceed those of purely longitudinal cracks, which themselves pose greater risks than circumferential cracks alone. Bilateral surcharge loading significantly increases the critical load threshold for through-crack formation compared to unilateral loading. This highlights the severe structural risks associated with uneven load distribution. Full article

The high temperature performance of steel structures has long been a focus of research, but research on the damage and crack propagation mechanism of steel with initial defects at high temperature is relatively low. The high temperature performance of most steel structures in engineering has an important impact on the function and safety of the whole structure. At present, Peridynamics (PD) theory uses the integral method that has unique advantages compared with traditional methods to solve structural damage and fracture problems. Therefore, the effect of temperature change on steel properties is introduced into the PD, and the PD constitutive equation at high temperature is proposed. The damage and crack propagation mechanisms of 2D Q345 steel plates with bilateral cracks and different bolt holes at 20 °C, 300 °C, 400 °C and 600 °C were analyzed by applying temperature action and external load to double-cracked steel specimens by the direct thermostructural coupling method. At the same time, the damage values, displacement changes in X direction and Y direction under different temperatures were compared and analyzed, and the effects of temperature, bolt hole and external load on the damage, displacement and crack growth path of different parts of the structure were obtained. Full article

This work aims to study the compressive buckling and consequent blowup of jointed concrete pavements due to thermal rise. For this purpose, a simple and effective mixed FEM, originally introduced for performing static and buckling analyses of beams on elastic supports, is extended for performing a preliminary study of jointed concrete pavements. An elastic Euler–Bernoulli beam in frictionless and bilateral contact with an elastic support is considered. Three different elastic support models are assumed, namely a Winkler support, an elastic half-space (3D), and half-plane (2D). The transversal pavement joint or crack is modeled employing a hinge at the beam midpoint with nil rotational stiffness. Numerical tests are performed by determining critical loads and the corresponding modal shapes, with particular attention to the first minimum critical load related to pavement blowup. From a theoretical point of view, the results show that minimum critical loads converge to existing results in the case of Winkler support, whereas new results are obtained in the case of the 2D and 3D support types. Associated modal shapes have maximum upward displacements at the beam midpoint. The second and subsequent critical loads, together with the corresponding sinusoidal modal shapes, converge to existing results. From a practical point of view, minimum critical loads represent a lower bound for estimating axial forces due to thermal variation causing jointed pavement blowup. Full article

Infrared (IR) magneto-optical (MO) bi-imaging is an innovative method for detecting weld defects, and it is important to process both IR thermography and MO imaging characteristics of weld defects. IR thermography and MO imaging can not only run simultaneously but can also run separately in special welding processes. This paper studies the sensing processing of eddy current IR thermography and MO imaging for detecting weld defects of laser spot welding and butt joint laser welding, respectively. To address the issues of high-level noise and low contrast in eddy current IR detection thermal images interfering with defect detection and recognition, a method based on least squares and Gaussian-adaptive bilateral filtering is proposed for denoising eddy current IR detection thermal images of laser spot welding cracks and improving the quality of eddy current IR detection thermal images. Meanwhile, the image gradient is processed by Gaussian-adaptive bilateral filtering, and then the filter is embedded in the least squares model to smooth and denoise the image while preserving defect information. Additionally, MO imaging for butt joint laser welding defects is researched. For the acquired MO images of welding cracks, pits, incomplete fusions, burn-outs, and weld bumps, the MO image processing method that includes median filtering, histogram equalization, and Wiener filtering was used, which could eliminate the noise in an image, enhance its contrast, and highlight the weld defect features. The experimental results show that the proposed image processing method can eliminate most of the noise while retaining the weld defect features, and the contrast between the welding defect area and the normal area is greatly improved. The denoising effect using the Natural Image Quality Evaluator (NIQE) and the Blind Image Quality Index (BIQI) has been evaluated, further demonstrating the effectiveness of the proposed method. The differences among weld defects could be obtained by analyzing the gray values of the weld defect MO images, which reflect the weld defect information. The MO imaging method can be used to investigate the magnetic distribution characteristics of welding defects, and its effectiveness has been verified by detecting various butt joint laser welding weldments. Full article

It is difficult to detect and identify natural defects in welded components. To solve this problem, according to the Faraday magneto-optical (MO) effect, a nondestructive testing system for MO imaging, excited by an alternating magnetic field, is established. For the acquired MO images of crack, pit, lack of penetration, gas pore, and no defect, Gaussian filtering, bilateral filtering, and median filtering are applied for image preprocessing. The effectiveness of these filtering methods is evaluated using metrics such as peak signal–noise ratio (PSNR) and mean squared error. Principal component analysis (PCA) is employed to extract column vector features from the downsampled defect MO images, which then serve as the input layer for the error backpropagation (BP) neural network model and the support vector machine (SVM) model. These two models can be used for the classification of partial defect MO images, but the recognition accuracy for cracks and gas pores is comparatively low. To further enhance the classification accuracy of natural weld defects, a convolutional neural network (CNN) classification model and a ResNet50 classification model for MO images of natural weld defects are established, and the model parameters are evaluated and optimized. The experimental results show that the overall classification accuracy of the ResNet50 model is 99%. Compared with the PCA-SVM model and CNN model, the overall classification accuracy was increased by 7.4% and 1.8%, and the classification accuracy of gas pore increased by 10% and 4%, respectively, indicating that the ResNet50 model can effectively and accurately classify natural weld defects. Full article

Solid wood is renowned as a superior material for construction and furniture applications. However, characteristics such as dead knots, live knots, piths, and cracks are easily formed during timber’s growth and processing stages. These features and defects significantly undermine the mechanical characteristics of sawn timber, rendering it unsuitable for specific applications. This study introduces BDCS-YOLO (Bilateral Defect Cutting Strategy based on You Only Look Once), an artificial intelligence bilateral sawing strategy to advance the automation of timber processing. Grounded on a dual-sided image acquisition platform, BDCS-YOLO achieves a commendable mean average feature detection precision of 0.94 when evaluated on a meticulously curated dataset comprising 450 images. Furthermore, a dual-side processing optimization module is deployed to enhance the accuracy of defect detection bounding boxes and establish refined processing coordinates. This innovative approach yields a notable 12.3% increase in the volume yield of sawn timber compared to present production, signifying a substantial leap toward efficiently utilizing solid wood resources in the lumber processing industry. Full article

Underwater cracks are difficult to detect and observe, posing a major challenge to crack detection. Currently, deep learning-based underwater crack detection methods rely heavily on a large number of crack images that are difficult to collect due to their complex and hazardous underwater environments. This study proposes a new underwater image-processing method that combines a novel white balance method and bilateral filtering denoising method to transform underwater crack images into high-quality above-water images with original crack features. Crack detection is then performed based on an improved YOLOv9-OREPA model. Through experiments, it is found that the new image-processing method proposed in this study significantly improves the evaluation indicators of new images, compared with other methods. The improved YOLOv9-OREPA also exhibits a significantly improved performance. The experimental results demonstrate that the method proposed in this study is a new approach suitable for detecting underwater cracks in dams and achieves the goal of transforming underwater images into above-water images. Full article

Joints formed by inserting steel secondary beam (SSB) into concrete girders have been increasingly used in engineering practice (e.g., electric power). To demonstrate the static performance of these joints, two key variables including the construction method (prefabricated, cast-in-place) and the insertion form of SSB (unilateral, bilateral) were considered. The test results indicated that the failure mode of each joint was concrete punching by the inserted SSB. Compared with the joint specimens with unilateral insertion of SSB, the failure mode of the joint with bilateral insertion was changed from multiple to single cracking, exhibiting more obvious brittleness. When high-performance cement-based grouting materials were incorporated into the joint, the assembly and ductility of the joint were effectively improved. Compared with the cast-in-place counterparts, the displacement ductility coefficients of joints with prefabricated unilaterally and bilaterally inserted beams were enhanced by 22.9% and 41.3%, respectively. Moreover, a theoretical model was developed to evaluate the punching shear resistance of such joints with favorable accuracy. Full article

The rapid and accurate detection of road cracks is of great significance for road health monitoring, but currently, this work is mainly completed through manual site surveys. Low-altitude UAV remote sensing can provide images with a centimeter-level or even subcentimeter-level ground resolution, which provides a new, efficient, and economical approach for rapid crack detection. Nevertheless, crack detection networks face challenges such as edge blurring and misidentification due to the heterogeneity of road cracks and the complexity of the background. To address these issues, we proposed a real-time edge reconstruction crack detection network (ERNet) that adopted multi-level information aggregation to reconstruct crack edges and improve the accuracy of segmentation between the target and the background. To capture global dependencies across spatial and channel levels, we proposed an efficient bilateral decomposed convolutional attention module (BDAM) that combined depth-separable convolution and dilated convolution to capture global dependencies across the spatial and channel levels. To enhance the accuracy of crack detection, we used a coordinate-based fusion module that integrated spatial, semantic, and edge reconstruction information. In addition, we proposed an automatic measurement of crack information for extracting the crack trunk and its corresponding length and width. The experimental results demonstrated that our network achieved the best balance between accuracy and inference speed compared to six established models. Full article

Bridge inspection methods using unmanned vehicles have been attracting attention. In this study, we devised an efficient and reliable method for visually inspecting bridges using unmanned vehicles. For this purpose, we developed the BIRD U-Net algorithm, which is an evolution of the U-Net algorithm that utilizes images taken by unmanned vehicles. Unlike the U-Net algorithm, however, this algorithm identifies the optimal function by setting the epoch to 120 and uses the Adam optimization algorithm. In addition, a bilateral filter was applied to highlight the damaged areas of the bridge, and a different color was used for each of the five types of abnormalities detected, such as cracks. Next, we trained and tested 135,696 images of exterior bridge damage, including concrete delamination, water leakage, and exposed rebar. Through the analysis, we confirmed an analysis method that yields an average inspection reproduction rate of more than 95%. In addition, we compared and analyzed the inspection reproduction rate of the method with that of BIRD U-Net after using the same method and images for training as the existing U-Net and ResNet algorithms for validation. In addition, the algorithm developed in this study is expected to yield objective results through automatic damage analysis. It can be applied to regular inspections that involve unmanned mobile vehicles in the field of bridge maintenance, thereby reducing the associated time and cost. Full article

To improve the automation, welding efficiency, and welding quality of duckbill welding of the cotton seeder, this study designed a cotton seeder duckbill welding robot. According to the characteristics of the duckbill weldment and welding requirements, the overall structure of the welding robot was determined, including the girdle feeding mechanism, static duckbill feeding mechanism, hinge feeding mechanism, welding fixture, welding actuator, and control system. To realize the continuous automatic feeding, positioning, fixing, welding, and unloading of the workpiece in the duckbill welding, the feeding mechanism adopts the method of cooperative cooperation of inductive proximity switch, electromagnet, and cylinder. The main body of the welding fixture adopts the pneumatic clamping method; the welding actuator adopts the synchronous belt module electric drive so that the welding torch can move in a straight line along the X axis and the Z axis. The welding process of the duckbill was simulated by Simufact Welding software, and the deformation and stress changes of the weldment were compared and analyzed when the single-sided single welding, the bilateral symmetrical double welding torch, two welding forms, and two welding process parameters were used to determine the welding process parameters of the welding robot. The prototype was made and the welding test was carried out. The test results show that the duckbill welding robot of the cotton seeder has stable feeding, solid clamping, accurate positioning, and high welding efficiency. According to the national standard, the appearance of the duckbill weld is inspected. The surface of the duckbill weld and the heat-affected zone has no cracks, incomplete fusion, slag inclusion, crater, and porosity. The forming quality of the welded parts is good. The design of the duckbill welding robot for cotton seeder is helpful in solving the problems of cumbersome positioning and clamping and low efficiency in manual and semi-automatic duckbill welding robots, which provides a strong guarantee for the large-scale and standardized welding production of the dibbler duckbill. Full article

Two case reports and an updated critical review on bilateral fractures of the femoral neck are presented. Bilateral fractures of the femoral neck have been investigated for at least 80 years and are treated as rare cases. The primary cause is usually considered an external shock; however, aside from high energy shocks (e.g., falling and impact with hard, rigid surfaces, traffic accidents, etc.) the underlying causes of femoral neck frailty have not yet been fully understood. Although not exhaustive, the review spans cases reported as early as 1944 and compares their conclusions in line with medicine developments at the time of the reports until present. The discussion is perhaps controversial at times; it brings to the fore the energy balance between shock waves and stress waves. The two cases reported here add to the review, one highlighting the biomechanics, and the other supporting more recent findings on metabolic disorders, which ultimately lead to enhanced frailty of the femoral neck. Investigation of the fractures has been performed with X-ray radiographs, MRI, and CT, with a follow up using a Doppler US to check blood flow in the lower zone of the limbs. The second case was investigated both for fractures and metabolic diseases, e.g., type I diabetes and kidney failure (dialysis). In Case 1 the second fracture was not observable at the time of admission, and therefore two surgery operations were performed at seven days interval. Taperloc Complete prostheses (Zimmer Biomet) were applied. Case 2 suffered a second fracture in the right hip in the segment above the knee and required better fixation with cables. Despite this, she returned one month later with a new crack in the femur. Case 1 is a typical case of wear consequences on the biomechanics of the hill pad-tibia-femur-femoral neck system, where tension of the neck occurred due to a stress wave rather than a shock wave. This can be proven by the absence of a second fracture from the images first acquired, the only evidence being pain and walking difficulty. Case 2 shows that metabolic diseases can dramatically enhance the frequency of bilateral femoral neck fractures. Full article

A magnitude (Mw) 7.4 Maduo earthquake occurred on 22 May 2021 in the northern Qinghai-Tibet Plateau, with predominantly left-lateral strike-slip faulting and a component of normal faulting within the Bayan Har Block. The co-seismic surface rupture extended in a NWW direction for ~160 km with a complicated geometry along a poorly known young fault: the Jiangcuo Fault. The main surface rupture propagated bilaterally from the epicenter and terminated eastward in horsetail splays. The main rupture can be divided into five segments with two rupture gaps. Field surveys and detailed mapping revealed that the co-seismic surface ruptures were characterized by a series of left-lateral offsets, en echelon tensional cracks and fissures, compressional mole tracks, and widespread sand liquefication. The observed co-seismic left-lateral displacements ranged from 0.2 m to ~2.6 m, while the vertical displacements ranged from 0.1 m to ~1.5 m, much lower than the InSAR inverse slip maximum of 2–6 m. Based on the comprehensive analysis of the causative fault geometry and the tectonic structure of the northern Bayan Har Block, this study suggests that the multiple NWW trending sub-faults, including the Jiangcuo Fault, developed from the East Kunlun fault northeast of the Bayan Har Block could be regarded as the sub-faults of the East Kunlun Fault system, constituting a broad and dispersive northern boundary of the Block, controlling the inner strain distribution and deformation. Full article

Magnetic-liquid double suspension bearing (MLDSB) is a new type of suspension bearing with electromagnetic suspension as the main part and hydrostatic supporting as the auxiliary part. It can greatly improve the bearing capacity and stiffness of rotor bearing system and is suitable for medium speed, heavy load, and frequent starting occasions. The electromagnetic system adopts PD control, and hydrostatic system adopts constant pressure supply model to adjust and control the rotor’s displacement in real time. Once bearing electromagnetic system fails, the “dropping-collision” phenomenon of the rotor will be triggered in operation process, leading to cracking and shedding of magnetic sleeve plating and magnetic pole plating. Then the operational reliability and stability of MLDSB will be greatly reduced. So in this paper, Firstly, the drop impact-rubbing equation of the single DOF bearing system under four failure models (upper unit failure, lower unit failure, bilateral failure, and power amplifier failure) is established. Secondly, the paper simulates influence laws of different structure and operation parameters (plating/liquid film thickness and oil pocket pressure, bias current) on falling rotor impact-rubbings behavior. The results show that: (1) the degree of “dropping-collision” of the rotor under the four failure models is successively as follows: power amplifier failure > upper unit failure > bilateral failure > lower unit failure. (2) Due to the impact-rubbing damping effect of hydraulic oil, it plays a certain inhibitory and buffering role on the phenomenon of “drop-collision”. The degree and probability of “dropping-collision” of rotor can be effectively reduced by increasing the pressure of oil chamber appropriately. (3) The rotor drop impact-rubbing behavior obtained from the test is basically consistent with the theoretical simulation, and the correctness of the theoretical simulation can be effectively verified. The research provides a theoretical basis for fault prevention and diagnosis of MLDSB. Full article

A notch-induced high-speed splitting method was developed for high-quality cropping of metal bars using a new type of electric-pneumatic counter hammer. Theoretical equations and FE models were established to reveal the crack initiation and fracture mode. Comparative tests were conducted for notched and unnotched bars of four types of steels, i.e., AISI 1020, 1045, 52100, and 304, and the section quality and microfracture mechanism were further investigated. The results show that damage initiates at the bilateral notch tips with peak equivalent plastic strain, and propagates through the plane induced by the notch tip; the stress triaxiality varies as a quasi-sine curve, revealing that the material is subjected to pure shearing at the notch tip, and under compression at the adjacent region. High precision chamfered billets were obtained with roundness errors of 1.1–2.8%, bending deflections of 0.5–1.5mm, and angles of inclination of 0.7°–3.4°. Additionally, the notch effectively reduced the maximum impact force by 21.6–23.9%, splitting displacement by 7.6–18.6%, and impact energy by 27.8–39.1%. The crack initiation zone displayed quasi-parabolic shallow dimples due to shear stress, and the pinning effect was larger in AISI 52100 and 1045 steel; the final rupture zone was characterized by less elongated and quasi-equiaxial deeper dimples due to the combination of shear and normal stress. Full article
