The church of Saint Felix in Girona (Spain) is crowned by an octagonal bell tower with a stone pinnacle at each corner. It was built using dry-joint stone masonry, a technique that involves laying stones in a precise pattern to create a solid and durable structure. In order to strengthen the connection between the stone blocks of the pinnacles, a wooden bar was placed through a central hole carved in the stone structure. Today, the inner structure has completely disappeared. During maintenance and repair work, it was decided to restore the functionality of the disappeared reinforcement by installing a titanium bar in its place. Due to the uncertainty associated with the pinnacle’s behaviour and the lack of both, a proper numerical model of the monument, and an extensive characterization of the materials, a strategy based on multiple approaches was designed. The proposed strategy was based on combining numerical and experimental models, the final objective being to determine the length and mechanical properties of the metallic inclusion, considering the effects of gravity, wind, and seismic forces. A scale model of the pinnacle was evaluated in laboratory conditions. The results were used to calibrate a numerical model representing the scale specimen. After calibration, the results were extrapolated to a full-scale numerical model. The experimental and numerical results showed that the pinnacles needed to be reinforced along their entire height. The tensile stresses cause by wind and seismic forces at different levels, could not be compensated without the contribution of the titanium bar inserted into the pinnacle. Full article

Bell towers, due to their slender geometry and structural configuration, are among the buildings most susceptible to deterioration from weathering and seismic events. These aspects influence the structural assessment of these historic towers, which is essential for their conservation and maintenance. The “Carmine Maggiore” bell tower in Naples (Italy) has been an important and prominent landmark of the city for centuries. It is square in plan and 72 m high. Over time, it suffered extensive damage and was severely damaged by the earthquake of 1456. Reconstruction began in the first decade of the 17th century and the original design was modified, adding two stories and changing the shape of the plan to octagonal. In the centuries that followed, the structure was damaged again and further interventions were carried out, adding tie-rods and replacing damaged elements. Today, the bell tower has very elaborate façades with mouldings and decorations, so that the supporting structure appears to be covered with plaster, stucco, and stone elements. This paper describes the results of FEM analyses of the bell tower, obtained from models with different levels of complexity to evaluate the influence of stone cladding elements on the seismic behaviour. In particular, the difference in the IS safety indices, calculated as the ratio of capacity to demand, exceeds 15%, due to the mechanical consistency of the cladding elements, which contribute significantly to both stiffness and strength. Full article

This study proposes a simplified approach for the experimental dynamic characterization of the historic Messina Bell Tower (northeastern Sicily) using passive seismic single-station surveys. The Horizontal-to-Vertical Spectral Ratio (HVSR) analysis identified a site resonance frequency of approximately 1.06 Hz, while the Multichannel Analysis of Surface Waves (MASW) survey contributed to the characterization of the shear wave velocity profile, providing a coherent geophysical framework useful for structural dynamic analysis. Spectral ratios analysis revealed four distinct vibration modes, including a fundamental rocking mode (~1.4 Hz), a torsional mode (3.5 Hz), and two higher-frequencies flexural modes. The structure’s dynamic behavior, notably its sensitivity to torsion and rocking, is attributed to the deformable subsoil. Damping ratios estimated via the Random Decrement Method (RDM) were below 1%, consistent with the expected linear elastic response under ambient vibrations. The results show strong agreement with previous long-term monitoring, validating the effectiveness of passive seismic techniques for rapid, non-invasive assessment. This study demonstrates that streamlined, time-efficient methodologies are capable of delivering modal parameters consistent with those obtained from more extensive and resource-intensive monitoring campaigns, thereby providing a reliable and practical approach for the seismic vulnerability assessment of heritage structures. Full article

The preservation of historical heritage requires a deep understanding of the interactions between physical and structural phenomena. This study investigates the influence of bells acoustic waves propagation on the dynamic behavior for the historical bell tower of the San Michele Arcangelo Cathedral in Caserta Vecchia, Italy. By combining environmental acoustic measurements with finite element modeling in ABAQUS, the research analyzes vibroacoustic coupling and identifies vibrational modes affected by the bell sounds. Harmonic analysis reveals the relationships between sound frequencies and structural vibrational modes, providing insights into the dynamics of historic towers subjected to repetitive acoustic loads. The findings demonstrate how sound can induce complex structural responses, offering valuable guidance for targeted conservation strategies. This interdisciplinary approach can be extended to other historic buildings, highlighting the critical role of vibroacoustic considerations in safeguarding cultural heritage. Full article

Historically, bell towers have been religious and architectural symbols in the landscape that summoned the faithful to celebrations and fulfilled a crucial territorial significance task. This function was assumed by the towers of some universities. The real need of the University Francisco de Vitoria to build a bell tower for its new chapel and to be significant both for its campus and the city is the pretext to investigate the need for this element in the current context through an academic exercise with architecture students. Traditionally, the religious autority proposed a concrete celebration space. In this case, architecture students were commissioned to propose a contemporary response for the new bell tower of their university campus through a Design Workshop. The workshop result raises interesting questions about what the architecture of a bell tower should be like in the XXI century, the relationship with public space, the construction of a landmark on an urban scale, the need to respond to both the city and the immediate environment at its different scales, the obsolescence of elements such as clocks or bells, and, above all, the relevance of symbols and the way that architecture raises questions in the contemporary landscape. Full article

This study introduces a design transformation model for AI-generated Chinese traditional architectural images (SD Lora&Canny) based on Stable Diffusion (SD). By integrating parameterization techniques such as Low-Rank Adaptation (Lora) and edge detection algorithms (Canny), the model achieves precise restoration of the architectural form, color elements, and decorative symbols in Chinese traditional architecture. Using the Beijing Drum Tower as the experimental subject, statistical analysis software (SPSS V28.0) was employed to conduct a quantitative evaluation and comparative analysis of architectural images generated by the DALL-E, MidJourney, SD, and SD Lora&Canny models. The results demonstrate that the SD Lora&Canny model significantly outperforms traditional generation tools in restoration accuracy and visual fidelity. Finally, this study applied the SD Lora&Canny model to create the digital cultural product AR Drum and Bell Tower Fridge Magnet, showcasing its practical application in digital cultural creation and verifying its innovative potential in the digital preservation and transmission of Chinese traditional architecture. Full article

This study examines change detection techniques in dense point clouds for the purpose of cultural heritage preservation, with a particular focus on the San Pietro Barisano Bell Tower in Matera, Italy. Dense point clouds, obtained via laser scanning, offer detailed 3D representations of heritage structures, facilitating the precise monitoring of changes over time. The investigation uses a variety of change detection algorithms, including the Iterative Closest Point (ICP) algorithm, which is renowned for its robust registration capabilities in aligning point clouds with high accuracy. The combination of ICP with deviation analysis and feature-based methods allows for the effective identification of alterations, including deformations, material loss, and surface degradation. This methodology establishes a comprehensive framework for the monitoring of cultural heritage, thereby enabling timely and targeted preservation efforts. The results emphasise the substantial contribution of dense point cloud analysis to the enhancement of heritage management and the safeguarding of vulnerable architectural sites. Full article

The seismic assessment of historical masonry bell towers is of significant interest, particularly in Italy, due to their widespread presence and inherent vulnerability given by their slenderness. According to technical codes and standard practice, the seismic evaluation of masonry bell towers can be conducted using a range of methodologies that vary in their level of detail. This paper presents a case study of a historical masonry bell tower located in the Caserta Province (Italy). Extensive investigative efforts were undertaken to determine the tower’s key geometric and structural characteristics, as well as to document ongoing damage phenomena. The dynamic behavior of the tower was assessed through ambient vibration testing, which enabled the identification of the principal modal shapes and corresponding frequencies, also highlighting peculiar dynamical characteristics caused by the damage conditions. Subsequently, the seismic assessment was carried out using both Level 1 (simplified mechanical) and Level 2 (kinematic limit analysis) methodologies. This assessment helped identify the most probable collapse mechanisms and laid the foundation for employing more advanced methodologies to design necessary retrofitting interventions. The study emphasizes the importance of Level 2 analyses for structures where out-of-plane failure mechanisms are likely due to pre-existing cracking. Both approaches provide less-than-unity acceleration factors, ranging from 0.45 for Level 1 (assuming non-ductile behavior) to 0.59 for Level 2, in this case specifically using the information available about existing cracking pattern. Full article

Masonry towers are peculiar structures with complex structural behavior despite biased conclusions deriving from their geometrical regularity and simplicity. Their geometrical features and the epistemic uncertainty that masonry material bears strongly influence their static and seismic behavior. This paper investigates a remarkable and representative case study. The bell tower of Portogruaro (Italy) is a 57 m high tall construction, built in the XII-th century, and has a notable inclination. The Italian Guideline for the safety assessment of masonry towers is a key focus in this paper, highlighting the pros and cons of different suggested approaches. Some relevant proposals are presented in this paper in order to address the seismic safety assessment of masonry bell towers. The findings show that very slender structures do not meet the guidelines recommendations due to limitations in their current stress state. In addition, in similar cases, the recommended values for the mechanical properties of masonry material led to predicting non-withstanding structural behavior, questioning the correct choice of the adapted material properties. Advanced pushover analysis has been conducted in order to investigate the results of the simplified approach in terms of failure patterns and seismic safety estimation. The simulations are implemented for four different hypothetical scenarios of the existing masonry mechanical properties. The results obtained for the case study tower reflect a different perspective in the seismic assessment of masonry towers when specific approaches are defined. The preliminary results on the safety of Portogruaro Tower show a significant variability of seismic safety based on the adopted scenario, highlighting the necessity to pay attention to the preservation state of the present case and of similar ones. Full article

When profit-driven renewal is difficult to implement, many historic districts in China become “frozen” under protection. In the recent social context of “building cities for the people”, public value-oriented renewal of urban historic areas has become crucial in city transformation. This study investigates strategies for historic district regeneration in China by integrating spatial form, urban governance, and public value. We propose a novel framework to analyze the regeneration of historic districts, using Taiyuan’s Bell Tower Street as a case study. The framework distinguishes between two dimensions: spatial and economic–social. In the spatial dimension, we focus on the transformation of spatial form to regenerate public value, emphasizing the attribute of “publicness” as central to urban regeneration efforts. This involves a tiered approach to excavating and upgrading historic districts at macro, meso, and micro levels. The economic–social dimension explores urban governance to enhance public value through collaboration between government, market, and societal actors. This study employs a mixed-methods approach, including document reviews, interviews, field observations, and statistical data analysis. The analysis highlights that a public value-oriented approach to heritage regeneration can balance historical preservation with contemporary urban needs, offering a sustainable model for other cities. Full article

Mechanical parking lots and spaces are known as the “energy saver” of urban space because of their small footprint, high efficiency, and environmental protection. However, the location and number of mechanical parking lots and space planning have become an important part of effectively exerting the function of mechanical parking lots. In order to explore the planning problem of mechanical parking lots, this study used the gradient boosting decision tree–Shapley additive explanations (GBDT-SHAPs) to measure the non-linear impact of the urban built environment on the mechanical parking spaces ratio and extract the optimal threshold of key variables. The results show that land use mix and distance to Bell Tower (CBD) are two key variables affecting mechanical parking space planning, and both have a non-linear relationship with the built environment. The threshold values are 0.83 and 7 km. The results will provide urban and transport planners with strategies for planning mechanical parking lots and spaces. Full article

In this study, modal and structural identification of a historic masonry bell tower in Čuntići, Croatia, damaged during the recent Petrinja earthquake, was performed. The results of the ambient vibration tests (AVT) and operational modal analysis (OMA) were used to update the finite element numerical model of the bell tower. Three modes were experimentally determined: the first two were bending modes (f₁ = 4.395 Hz and f₂ = 4.639 Hz), and the third was a torsional mode (f₃ = 10.303 Hz). The experimentally determined and the originally calculated (preliminary NM) modal shapes agreed well, but in terms of modal frequencies, the correlation was poor. After model updating, some structural parameters were identified, and a reliable finite element numerical model was established. The proposed method can provide a reliable evaluation of the structural parameters of historic masonry buildings. Full article

Senile trees in historic church gardens have natural, aesthetic, historical, and cultural value. Cutting them down too hastily annihilates the achievements of entire generations. We should try to preserve the greenery surrounding historic churches and integrate it into a clear compositional arrangement with the sacral architecture. The primary purpose of the paper was to describe the process of inventorying 200-year-old trees and to present the revalorization project for the garden around the historic Orthodox church in Horostyta, located in the Lublin Voivodeship, in southeastern Poland. The church complex consists of a wooden 18th-century building, bell tower, garden, and cemetery. Within the church garden’s boundaries, there are 15 trees, with two predominant species: Acer pseudoplatanus L. and Tilia cordata Mill. These trees are of varying ages and health conditions. We used acoustic tomography to perform tree health diagnostics. Three trees, for which the initial visual assessment was disturbing, were examined thanks to detailed tomography tests. Then, through a project adapting the church garden to the health conditions of the ancient trees, they were separated from users by flowerbeds and no small architectural objects were placed around them. The presented development concept forms a compromise between tradition and the modern user’s needs. In 2007, a general renovation of the temple building was completed. Currently, the presented project for the church garden is being implemented. Full article

In seismic-prone areas, ecclesiastical masonry complexes have shown very high vulnerability, as detected after the last Italian earthquakes, such as those that occurred in L’Aquila (2009), Emilia-Romagna (2012), Central Italy (2016), and Ischia (2017). Partial collapses often affect these types of aggregate buildings due to the presence of highly vulnerable elements, such as bell towers. Preliminary analyses, including straightforward and quick methods, are necessary to assess their vulnerability. This paper proposes a simplified method to analyse bell tower dynamic behaviour and the results obtained are compared with several different approaches. The first is based on the dynamics of two rigid blocks (bell tower and lower building), and the second concerns a single block (bell tower only). The proposed method can be considered as a quick procedure involving few parameters to provide a preliminary analysis before use of more complex models such as finite element models. It aims to provide a valuable tool for the initial evaluation of the stability and risk index of the structure. The double-block model considers the associations between the rocking of the bell tower and the sliding motion of the underlying building. A parametric evaluation for different friction coefficients is proposed. The results are represented as rotation time histories and compared with analysis of the single vulnerable element, i.e., the bell tower subjected to the floor spectrum. The results show that high excitation frequency and friction coefficient values make the bell tower stable, and that the simplified model provides a clear safety advantage. Full article

Resonance frequencies of a masonry bell tower were estimated by means of ambient noise measurements and compared with those computed by using fixed base, Winkler, and FE numerical, including subsoil. Given the geological complexity that characterizes the subsurface of the analyzed area, despite the presence of massive volcanic outcrops near the bell tower, we carried out a geophysical characterization of the subsoil by using active and passive seismic surveys. These surveys have identified a soft substrate underneath the construction; for this reason, the dynamic identification of the tower was performed, including the interaction with the soil. The resonance frequencies of the masonry bell tower computed by the models are very similar to those obtained using ambient noise. Results suggest that building resonance frequencies, estimated by ambient noise surveys, can be used because of their reliability especially when quick analyses are required at historical buildings located in seismically active areas needing plan actions to reduce their vulnerability. Moreover, such analyses, being performed on samplings acquired within the structure, allow for estimating its dynamic response, taking into account the effect of subsurface characteristics as well. Full article
