Grid-connected battery energy storage systems are usually used 24/7, which could prevent the utilization of typical diagnosis and prognosis techniques that require controlled conditions. While some new approaches have been proposed at the laboratory level, the impact of real-world conditions could still be problematic. This work investigates both the impact of additional residential usage on the cells while charging and of inhomogeneities on the diagnosability of batteries charged from photovoltaic systems. Using Big-Data synthetic datasets covering more than ten thousand possible degradations, we will show that these impacts can be accommodated to retain good diagnosability under auspicious conditions to reach average RMSEs around 2.75%. Full article

The pathophysiology of cognitive impairment (CI) in multiple sclerosis (MS) remains unclear. Meningeal B cell aggregates may contribute to cortical grey matter pathology. Cerebrospinal fluid (CSF), kappa free light chains (KFLC), and KFLCs-Index (kappa-Index) are reliable quantitative markers of intrathecal synthesis, but few data have been presented exploring the association with CI, and no data are present for lambda FLC (LFLC) in MS. We evaluated cognition using the Brief International Cognitive Assessment for MS (BICAMS) battery and collected serum and CSF at diagnosis in newly diagnosed drug-naïve MS patients. We observed that patients with impaired verbal memory and overall CI showed increased CSF KFLCs (respectively p: 0.0003 and p: 0.003) and kappa-Index (respectively p: 0.01 and p: 0.02) compared to those with normal verbal memory and no CI. Patients with CI also displayed lower CSF LFLCs (p: 0.04) and lambda-Index (p: 0.001); however, only CSF KFLC negatively correlated with normalized results of verbal memory (for age, sex, and educational levels), even after correction for EDSS (r: −0.27 p: 0.01). Finally, CSF FKLC and kappa-Index were significant predictors of verbal memory in a multivariate analysis. Our results, suggest that intrathecal B cell activity might contribute to CI development in MS patients. Full article

A battery-operated biomedical wearable device gradually assists in clinical tasks to monitor patients’ health states regarding early diagnosis and detection. This paper presents the development of a self-powered portable electronic module by integrating an onboard energy-harvesting facility for electrocardiogram (ECG) signal processing and personalized health monitoring. The developed electronic module provides a customizable approach to power the device using a lithium-ion battery, a series of silicon photodiode arrays, and a solar panel. The new architecture and techniques offered by the developed method include an analog front-end unit, a signal processing unit, and a battery management unit for the acquiring and processing of real-time ECG signals. The dynamic multi-level wavelet packet decomposition framework has been used and applied to an ECG signal to extract the desired features by removing overlapped and repeated samples from an ECG signal. Further, a random forest with deep decision tree (RFDDT) architecture has been designed for offline ECG signal classification, and experimental results provide the highest accuracy of 99.72%. One assesses the custom-developed sensor by comparing its data with those of conventional biosensors. The onboard energy-harvesting and battery management circuits are designed with a BQ25505 microprocessor with the support of silicon photodiodes and solar cells which detect the ambient light variations and provide a maximum of 4.2 V supply to enable the continuous operation of an entire module. The measurements conducted on each unit of the proposed method demonstrate that the proposed signal-processing method significantly reduces the overlapping samples from the raw ECG data and the timing requirement criteria for personalized and wearable health monitoring. Also, it improves temporal requirements for ECG data processing while achieving excellent classification performance at a low computing cost. Full article

Early micro internal short circuit (ISC) fault diagnosis is crucial for the safe and reliable operation of lithium-ion batteries. In order to solve the problem that the early micro ISC fault is difficult to identify due to its weak fault characteristics, this paper proposes a fault diagnosis method based on the accumulated correlation coefficient. Specifically, the method uses the accumulated voltage value within the time window as the input feature, constructs an adjustment factor based on the distance difference of the accumulated voltage value to amplify the difference between the fault voltage correlation coefficient and the normal voltage correlation coefficient, and finally achieves the purpose of highlighting the faulty cell. The effectiveness and diagnostic capability of the proposed method are verified in experiments of short circuit faults of different severity. The results show that the proposed method can effectively identify and locate early micro ISC faults within 200 s, and improve the diagnostic capability up to 0.02 C short-circuit severity. In addition, a multi-level diagnostic warning mechanism can be established according to the decrease of the fault voltage correlation coefficient, so as to measure the severity of the fault and track the fault evolution process. Full article

In recent years, the number of safety accidents in new-energy electric vehicles due to lithium-ion battery failures has been increasing, and the lithium-ion battery fault diagnosis technology is particularly important to ensure the safe operation of electric vehicles. This paper proposes a method for lithium-ion battery fault diagnosis based on the historical trajectory of lithium-ion battery remaining discharge capacity in medium and long time scales. The method first utilizes the sparrow search algorithm (SSA) to identify the parameters of the second-order equivalent circuit model of the lithium-ion battery, and then estimates the state of charge (SOC) of the lithium-ion battery using the extended Kalman filter (EKF). The remaining discharge capacity is estimated according to the SOC, and finally the feature vectors are used to diagnose the faults using box plots on the medium and long time scales. Experimental results verify that the root mean squared error (RSME) and mean absolute error (MAE) of the proposed SOC estimation method are 0.0049 and 0.0034, respectively. This method can accurately identify the faulty single cell in a battery pack with low-capacity single cells and promptly detect any abnormalities in the single cell when a micro-short circuit fault occurs. Full article

Fuel cells, as clean and efficient energy conversion devices, hold great potential for applications in the fields of hydrogen-based transportation and stand-alone power systems. Due to their sensitivity to load parameters, environmental parameters, and gas supply, the performance monitoring and fault diagnosis of fuel cell systems have become crucial research areas. Electrochemical impedance spectroscopy (EIS) is a widely applied analytical method in fuel cell systems. that can provide rich information about dynamic system responses, internal impedance, and transmission characteristics. Currently, EIS detection is primarily implemented by using simple topologies such as boost circuits. However, the injection of excitation signals often results in significant power fluctuations, leading to issues such as uneven temperature distributions within the cell, unstable gas supply, and damage to the proton exchange membrane. To address this issue, this paper proposes a real-time EIS detection technique for a proton exchange membrane fuel cell (PEMFC) system that connects a lithium-ion battery and injects the load voltage perturbation through a triple active bridge (TAB) converter. By applying the small-signal model of the TAB converter and designing a system controller using a decoupling control method, the PEMFC power remains stable after the disturbance injection across the entire frequency range under tests. Furthermore, the lithium-ion battery can instantly track load changes during fluctuations. The proposed EIS detection method can acquire EIS data in real time to monitor the state of the PEMFC. Simulation results validate the effectiveness and accuracy of the proposed method for EIS detection. Full article

In the automotive industry, ageing mechanisms and diagnosis of Li-ion batteries depending on charge rate are of tremendous importance. With this in mind, we have investigated the lifetime degradation of lithium-ion battery cells at three distinct charging rates using Electrochemical Impedance Spectroscopy (EIS). Impedance spectra of high-energy Panasonic NCR18650B batteries have been analysed in light of two distinct approaches, namely the time-dependent evaluation of the Constant Phase Element (CPE), and the single parameter investigation of resonance frequency of the circuit. SOH percentages were used to validate our approach. By monitoring the CPE-Q parameter at different charge rates of 0.5 C, 1 C, and 1.5 C, respectively, we applied a degradation speed analysis, allowing us to predict a quantitative value of the LIBs. The results are in complete agreement with the resonance frequency single parameter analysis, in which quite a similar trend was obtained after the spline fitting. Full article

Timely and accurate fault diagnosis for a lithium-ion battery pack is critical to ensure its safety. However, the early fault of a battery pack is difficult to detect because of its unobvious fault effect and nonlinear time-varying characteristics. In this paper, a fault diagnosis method based on relative entropy and state of charge (SOC) estimation is proposed to detect fault in lithium-ion batteries. First, the relative entropies of the voltage, temperature and SOC of battery cells are calculated by using a sliding window, and the cumulative sum (CUSUM) test is adopted to achieve fault diagnosis and isolation. Second, the SOC estimation of the short-circuit cell is obtained, and the short-circuit resistance is estimated for a quantitative analysis of the short-circuit fault. Furthermore, the effectiveness of our method is validated by multiple fault tests in a thermally coupled electrochemical battery model. The results show that the proposed method can accurately detect different types of faults and evaluate the short-circuit fault degree by resistance estimation. The voltage/temperature sensor fault is detected at 71 s/58 s after faults have occurred, and a short-circuit fault is diagnosed at 111 s after the fault. In addition, the standard error deviation of short-circuit resistance estimation is less than 0.12 Ω/0.33 Ω for a 5 Ω/10 Ω short-circuit resistor. Full article

Degradation is an inevitable companion in the operation of solid oxide fuel cell (SOFC) systems since it directly deteriorates the reliability of the system’s operation and the system’s durability. Both are seen as barriers that limit the extensive commercial use of SOFC systems. Therefore, diagnosis and prognosis are valuable tools that can contribute to raising the reliability of the system operation, efficient health management, increased durability and implementation of predictive maintenance techniques. Remaining useful life (RUL) prediction has been extensively studied in many areas like batteries and proton-exchange membrane fuel cell (PEM) systems, and a range of different approaches has been proposed. On the other hand, results available in the domain of SOFC systems are still relatively limited. Moreover, methods relying on detailed process models and models of degradation turned out to have limited applicability for in-field applications. Therefore, in this paper, we propose an effective, data-driven approach to predicting RUL where the trend of the health index is modeled by an adaptive linear model, which is updated at all times during the system operation. This allows for a closed-form solution of the probability distribution of the RUL, which is the main novelty of this paper. Such a solution requires no computational load and is as such very convenient for the application in ordinary low-cost control systems. The performance of the approach is demonstrated first on the simulated case studies and then on the data obtained from a long-term experiment on a laboratory SOFC system. From the tests conducted so far, it turns out that the quality of the RUL prediction is usually rather low at the beginning of the system operation, but then gradually improves while the system is approaching the end-of-life (EOL), making it a viable tool for prognosis. Full article

Accurately obtaining the state of charge (SOC) and health (SOH) of all individual batteries in a battery pack can provide support for data acquisition, state estimation, and fault diagnosis. To verify the real-time performance and accuracy of the joint estimation algorithm for high-voltage battery packs composed of 96 individual cells in series, this article applies Simulink to develop a joint estimation algorithm for SOC and SOH based on the first-order RC equivalent circuit model (1RC ECM) and implements the algorithm’s cyclic calling for series nodes, enhancing the algorithm’s scalability. In the algorithm, the recursive least square method with fitting factor (FFRLS) is applied to calculate OCV, R₀, and R₁ in the time domain, and dual adaptive extended Kalman filter (DAEKF) is applied to joint estimation of SOC and SOH at multiple time scales. Finally, with the help of dSPACE and FASECU controllers, hardware in the loop (HIL) testing was completed in multiple scenarios. The results showed that the algorithm can accurately calculate the state of individual cells in real time, and even under various initial value deviations, it still has good regression performance, laying the foundation for future applications of electric vehicles. Full article

The concept of pseudocapacitance is explored as a rapid and universal method for the state of health (SOH) determination of batteries and supercapacitors. In contrast to this, the state of the art considers the degradation of a series of full charge/discharge cycles. Lithium-ion batteries, sodium-ion batteries and supercapacitors of different cell chemistries are studied by impedance spectroscopy during lifetime testing. Faradaic and capacitive charge storage are distinguished by the relationship between the stored electric charge and capacitance. Batteries with a flat voltage–charge curve are best suited for impedance spectroscopy. There is a slight loss in the linear correlation between the pseudocapacitance and Ah capacity in regions of overcharge and deep discharge. The correct calculation of quantities related to complex impedance and differential capacitance is outlined, which may also be useful as an introductory text and tutorial for newcomers to the field. Novel diagram types are proposed for the purpose of the instant performance and failure diagnosis of batteries and supercapacitors. Full article

Blended electrodes are becoming increasingly more popular in lithium-ion batteries, yet most modeling approaches are still lacking the ability to separate the blend components. This is problematic because the different components are unlikely to degrade at the same pace. This work investigated a new approach towards the simulation of blended electrodes by replicating the complex current distributions within the electrodes using a paralleling model rather than the traditional constant-current method. In addition, a blending model was used to generate three publicly available datasets with more than 260,000 unique degradations for three exemplary blended cells. These datasets allowed us to showcase the necessity of considering all active components of the blend separately for diagnosis and prognosis. Full article

Second-life applications for lithium-ion batteries offer the industry opportunities to defer recycling costs, enhance economic value, and reduce environmental impacts. An accurate prognosis of the remaining useful life (RUL) is essential for ensuring effective second-life operation. Diagnosis is a necessary step for the establishment of a reliable prognosis, based on the aging modes involved in a cell. This paper introduces a method for characterizing specific aging phenomenon in Graphite/Lithium Iron Phosphate (G/LFP) cells. This method aims to identify aging related to the loss of active material at the negative electrode (LAM_NE). The identification and tracking of the state of health (SoH) are based on Incremental Capacity Analysis (ICA) and Differential Voltage Analysis (DVA) peak-tracking techniques. The remaining capacity of the electrode is thus evaluated based on these diagnostic results, using a model derived from half-cell electrode characterization. The method is used on a G/LFP cell in the format 18650, with a nominal capacity of 1.1 Ah, aged from its pristine state to 40% of state of health. Full article

The power battery constitutes the fundamental component of new energy vehicles. Rapid and accurate fault diagnosis of power batteries can effectively improve the safety and power performance of the vehicle. In response to the issues of limited generalization ability and suboptimal diagnostic accuracy observed in traditional power battery fault diagnosis models, this study proposes a fault diagnosis method utilizing a Convolutional Block Attention Capsule Network (CBAM-CapsNet) based on a stacked sparse autoencoder (SSAE). The reconstructed dataset is initially input into the SSAE model. Layer-by-layer greedy learning using unsupervised learning is employed, combining unsupervised learning methods with parameter updating and local fine-tuning to enhance visualization capabilities. The CBAM is then integrated into the CapsNet, which not only mitigates the effect of noise on the SSAE but also improves the model’s ability to characterize power cell features, completing the fault diagnosis process. The experimental comparison results show that the proposed method can diagnose power battery failure modes with an accuracy of 96.86%, and various evaluation indexes are superior to CNN, CapsNet, CBAM-CapsNet, and other neural networks at accurately identifying fault types with higher diagnostic accuracy and robustness. Full article

The diagnosis and prognosis of PV-connected batteries are complicated because cells might never experience controlled conditions during operation as both the charge and discharge duty cycles are sporadic. This work presents the application of a new methodology that enables diagnosis without the need for any maintenance cycle. It uses a 1-dimensional convolutional neural network trained on the output from a clear sky irradiance model and validated on the observed irradiances for 720 days of synthetic battery data generated from pyranometer irradiance observations. The analysis was performed from three angles: the impact of sky conditions, degradation composition, and degradation extent. Our results indicate that for days with over 50% clear sky or with an average irradiance over 650 W/m², diagnosis with an average RMSE of 1.75% is obtainable independent of the composition of the degradation and of its extent. Full article
