Search Results (53)

This paper presents a novel approach using machine learning methods for the automated segmentation of acceleration signals measured during ball burnishing (BB) operations performed on a computer numerical controlled (CNC) milling machine. The study addresses the challenge of accurately finding actual feedrates in that finishing operation, which often deviate from programmed values due to various dynamic reasons. The method involves a two-stage process: first, an automatic signal segmentation algorithm employing Gaussian Mixture Modeling (GMM) and K-means clustering is applied to the ball burnishing (BB) process and acceleration data. Second, a Taguchi L9 experimental design is used to assess the influence of some regime parameters on the actual feedrate and the BB’s cycle duration. Results show successful segmentation of the toolpaths based on X-axis accelerations and deforming force data, with the Calinski–Harabasz Index confirming good cluster separability. Programmed feedrate and the number of toolpath points were identified as the most significant factors affecting the percentage delay between programmed and obtained feedrates. The main contribution is the development and testing of a new method for segmenting different toolpath states in ball burnishing operations, based on measured accelerations and momentary deforming force magnitudes. The present work offers valuable insights into autonomous monitoring and control in BB operations. Full article

In this study, the tribological compatibility of ZrO₂-nanofiber-strengthened Al-matrix composites with graphene nanoplatelets (GNPs)-derived surface film acting as a solid lubricant was investigated. The substrate materials prepared by Spark Plasma Sintering (SPS) included the pure aluminum monolith (reference material) and two Al–ZrO₂ nanocomposites with either 1 or 3 wt.% of ZrO₂ nanofibers. The GNPs-derived solid lubricant films were dry mechanically burnished into the metallographically polished surfaces. The durability of these burnished films was evaluated by performing tribological friction experiments using a ball-on-disk method. Thus, a friction load capacity of GNP-derived tribofilms on the substrate materials and its effect on the coefficient of friction (COF) were evaluated. The results showed that the films burnished on the surfaces of Al–ZrO₂ nanofiber composites were more resistant to much higher loads than films burnished on monolithic aluminum. The obtained findings indicated that ZrO₂ nanofiber protrusions likely stabilize a GNP-derived carbon tribolayer on the polished composite surfaces. As a result, the reinforcement of aluminum with ceramic nanofibers led also to a significant reduction in COF. The highest improvement of tribological performance was observed for the Al–ZrO₂ nanofiber composite with 1 wt.% ZrO₂ nanofibers. The increase of ZrO₂ nanofibers up to 3 wt.% was no more efficient due to nanofiber clustering leading to lower stability of the carbon friction film. Our objective was to isolate the role of the aluminum substrate, specifically, ZrO₂ nanofiber protrusions in the formation and retention of a GNP-derived carbon tribofilm under room-temperature, ambient-air dry sliding. Full article

This study investigates the influence of ball burnishing (BB) path strategies on the surface integrity and functional performance of laser-cladded Inconel 718. Three BB strategies—(1) BB-Longitudinal, (2) BB-Transverse, and (3) BB-Crosshatch—relative to the laser scan trajectory were evaluated and compared against ground surfaces as a baseline. Post-processing BB treatment were demonstrated to be effective in modifying the subsurface layer of the cladded Inconel 718 material, extending to depths of up to 100 µm, increasing dislocation density by over 2.5 times, and enhancing hardness from 260 HV5 (ground) to as high as 461 HV5. These microstructural improvements led to significant gains in corrosion and impact resistance, despite a rise in surface roughness from Ra 0.35 µm (ground) to up to 2.38 µm for BB-Longitudinal surfaces. Impact testing revealed up to 35% reduction in indentation volume, particularly with BB-Transverse and BB-Crosshatch strategies. Nonetheless, sliding wear tests did not confirm improvements in wear resistance, as wear depths exceeded the hardened layer and abrasive wear remained dominant. Electrochemical testing in 3.5 wt.% NaCl solution showed a positive shift in corrosion potential (E_corr) exceeding 200 mV compared to the ground condition, indicating reduced corrosion susceptibility for BB-Longitudinal condition. Among the tested strategies, BB-Transverse offered the most balanced enhancements, highlighting the complex interplay between laser cladding heterogeneities and post-processing response in optimizing surface and mechanical properties of Inconel 718 claddings. Full article

The present research is related to the application of artificial intelligence (AI) approaches for classifying surface textures, specifically regular reliefs patterns formed by ball burnishing operations. A two-stage methodology is employed, starting with the creation of regular reliefs (RRs) on test parts by ball burnishing, followed by 3D topography scanning with Alicona device and data preprocessing with Gwyddion, and Blender software, where the acquired 3D topographies are converted into a set of 2D images, using various virtual camera movements and lighting to simulate the symmetrical fluctuations around the tool-path of the real camera. Four pre-trained convolutional neural networks (DenseNet121, EfficientNetB0, MobileNetV2, and VGG16) are used as a base for transfer learning and tested for their generalization performance on different combinations of synthetic and real image datasets. The models were evaluated by using confusion matrices and four additional metrics. The results show that the pretrained VGG16 model generalizes the best regular reliefs textures (96%), in comparison with the other models, if it is subjected to transfer learning via feature extraction, using mixed dataset, which consist of 34,037 images in following proportions: non-textured synthetic (87%), textured synthetic (8%), and real captured (5%) images of such a regular relief. Full article

This paper investigates the effect of plasticity ball burnishing on characteristics of surface integrity, residual stress and hardness of laser direct energy deposited (DEDed) Stellite 21 alloys, with a focus on the burnishing directional effect on surface and microstructural deformation. The results demonstrated that the burnishing improved surface finish, reducing Sa and Sz by 24% and 47%, respectively. The burnishing flattened and modified the cellular/columnar grains at a depth of 50 µm, with the most notable changes observed on the cross-sectional plane normal to the burnishing direction. Compared to the ground surface, the burnishing introduced higher and deeper compressive stresses along normal to the burnishing/grinding direction (−1341 MPa and 61 µm) as compared to that along the burnishing direction (−449 MPa and 56 µm). Likewise, the burnishing increased the full width at half maximum (FWHM) in the same fashion by broadening XRD peaks along normal to the burnishing direction. Due to higher grain modification and dislocation density, the burnishing has improved microhardness at a depth of 320 µm by 26% along normal to the burnishing direction. These findings demonstrate that the plasticity ball burnishing has a directional effect on plastic deformation and can be considered a plausible technique for tailored surface integrity, residual stress and hardness, which potentially improve the service performance of DEDed Stellite 21 alloy components. Full article

In the present study, an approach for determining the different states of ball burnishing (BB) operations aimed at forming regular reliefs’ patterns on planar surfaces is introduced. The methodology involves acquiring multi-axis accelerometer data from CNC-driven milling machine to capture the dynamics of the BB tool and workpiece, mounted on the machine table. Following data acquisition from an AISI 304 stainless steel workpiece, which is subjected to BB treatments at different toolpaths and feed rates, the recorded signals are preprocessed through noise reduction techniques, DC component removal, and outlier correction. The refined data are then transformed using a root mean square (RMS) operation to simplify further analysis. A Gaussian Mixture Model (GMM) is subsequently employed to decompose the compressed RMS signal into distinct components corresponding to various operational states during BB. The experimental trials at feed rates of 500 and 1000 mm/min reveal that increased feed rates enhance the distinguishability of these states, thus leading to an augmented number of statistically significant components. The results obtained from the proposed GMM based algorithm applied on compressed RMS accelerations signals is compared with two other methods, i.e., Short-Time Fourier Transforms and Continuous Wavelet Transform. The results from the comparison show that the proposed GMM method has the advantage of segmenting three to five different states of the BB-process from nonstationary accelerations signals measured, while the other tested methods are capable only to distinguish the state of work of the deforming tool and state of its rapid (re-)positioning between the areas of working, when there is no contact between the BB-tool and workpiece. Full article

The influence of regular relief formation modes on the microhardness of the formed groove surface near the apex at the bottom of the groove has been studied. It has been established that the rate of plastic deformation, expressed as the feed rate of the deforming element, has a significant impact on the plastic deformation mechanism, and the microstructure of the formed subsurface layer, as well as on the microhardness of the groove surface. The influence of the type of partially regular reliefs on the degree of plastic deformation was also investigated. It was found that the third type of partially regular relief, which has the highest groove density, provides higher microhardness values than the first and second types. This is explained by the significantly greater density of these type of partially regular relief grooves, which exert a mutual strengthening effect on the surface during formation. The experimental study conducted enabled the derivation of regression equations describing the influence of the feed rate of the deforming element and the type of partially regular relief created on the surface microhardness beneath the lateral ridges and the bottoms of the plastically deformed traces. Full article

This study investigates the optimization of the ball burnishing process for Al8090 aluminum–lithium alloy, focusing on surface quality, mechanical properties, and sustainability metrics. A mixed-design L₁₈ Taguchi experimental approach was employed to evaluate the effects of three critical parameters: burnishing force, feed rate, and number of passes under two lubrication conditions—dry and minimum quantity lubrication (MQL). Surface roughness, Brinell hardness, power and energy consumption, and carbon emissions were measured to assess technical and environmental performance. The results revealed that the MQL environment significantly improved surface roughness, achieving the lowest Ra value of 0.562 µm with a force of 200 N, a feed rate of 0.05 mm/rev, and four passes. In contrast, the highest Brinell hardness (43.6 HB) was observed in dry conditions with a force of 100 N, a feed rate of 0.1 mm/rev, and two passes. Energy consumption and carbon emissions were minimized in the MQL condition, with the lowest energy consumption recorded as 0.0169 kWh and corresponding carbon emissions of 0.0084 kg CO₂. These findings highlight the trade-offs between surface quality, hardness, and sustainability, providing valuable insights for optimizing the ball burnishing process for advanced materials like Al8090. Full article

This study investigates the optimization of ball burnishing parameters for enhancing the surface quality of pure Titanium (Ti) grade 2 titanium alloy under dry and Minimum Quantity Lubrication (MQL) conditions. Using a Taguchi L18 experimental design, the research systematically examines the effects of three critical parameters: burnishing force (50–200 N), feed rate (0.5–2 mm/min), and number of passes (1–4). Surface quality was evaluated through roughness measurements (Ra and Rz values), with Analysis of Variance (ANOVA) employed to determine the statistical significance of each parameter. The results demonstrate that MQL conditions consistently outperform dry burnishing, contributing 50.93% to the total variance in surface quality. The optimal surface finish (Ra = 0.306 μm) was achieved under MQL conditions with a burnishing force of 200 N, feed rate of 0.5 mm/min, and four passes. Statistical analysis revealed that the burnishing environment was the most influential factor, followed by the number of passes (23.87%) and burnishing force (9.97%). A regression model with an R-squared value of 87.66% was developed to predict surface roughness under various parameter combinations. These investigations will be helpful in the development of sustainable and efficient methods for the surface engineering of Ti-based materials for the aerospace and biomedical industries. Full article

The influence of ball burnishing on friction and wear at elevated temperatures under fretting conditions has not yet been reported. Fretting experiments were conducted using the Optimol SRV5 tester (Optimol Instruments, Munich, Germany) under dry gross fretting conditions. A ball of WC ceramic was pressed against a disc from the titanium alloy Ti6Al4V. Experiments were carried out at elevated temperatures of 100, 200, and 300 °C. The displacement frequency was 50 Hz, the stroke was 0.1 mm, and the test duration was 15 min. The normal loads used were 40, 60, and 80 N. Ball burnishing led to a substantial reduction in the roughness height and an increase in the microhardness of samples from the titanium alloy. Burnishing, in most cases, caused an improvement in the friction resistance of sliding assemblies. Ball burnishing also led to wear reduction compared to the turned disc sample. The best tribological performance of the sliding pair was achieved for the disc sample burnished with the highest pressure of 40 MPa. An increase in temperature from 100 to 200 °C caused small changes in disc wear volumes and coefficients of friction. A further increase in temperature to 300 °C led to an increase in disc wear rates and friction coefficients. Full article

Owing to their high producibility and resistance to corrosion, austenitic chromium–nickel steels are widely used in the chemical, petroleum, and food industries. However, their significant disadvantage lies in their poor structural performance, which cannot be improved by heat treatment. This significantly limits the usability of these steels in parts of machines that operate under friction loads. Hardening can be achieved by decreasing the size of grains and applying deformation-induced martensitic transformation. Nanostructuring burnishing (NSB) may be one of the technologies suited for producing parts of tribological assemblies with enhanced operating characteristics. Nanostructuring burnishing using a sliding indenter is being developed as a method of industrial surface nanocrystallization through severe plastic deformation used in the mechanical machining of various types of parts. This article investigates the possibility of enhancing the mechanical and tribological properties of nanocrystallized surfaces of austenitic steels, which are formed through nanostructuring burnishing using a tool with a natural diamond spherical indenter and a change in sliding speed from 40 to 280 m/min with one, three, and five passes. Increasing the tool sliding speed makes surface nanostructuring machining of big parts highly effective. This paper aims to establish the influence exerted by the sliding speed and number of indenter passes on the formation of a nanocrystalline structure, as well as on the modification of microhardness and residual stresses, texture, and tribological properties of the surface layer in the nanostructuring burnishing of AISI 304 steel. Transmission microscopy and microdurometry, 3D-profilometry, and tribological tests of surfaces nanocrystallized with the “ball-on-disk” scheme with dry and lubricated friction established the optimal values of speed and number of passes for a spherical indenter in nanostructuring burnishing. Full article

Characterization of surface integrity is possible with three critical metrics: microstructure, surface roughness, and residual stress. The latter two are discussed in this paper for low-alloyed aluminum material quality. Ball burnishing is a regularly used finishing procedure to improve surface roughness, shape accuracy, and fatigue life, taking advantage of the fact that it can favorably influence the variation in stress conditions in the material. The effect of burnishing is investigated using finite element simulation with DEFORM 2D software using the real surface roughness of the workpiece. The FEM model of the process is validated with experimental tests, the surface roughness is measured using an AltiSurf520 measuring device, and the residual stress is analyzed with a Stresstech Xstress 3000 G3R X-ray diffraction system (Stresstech, Vaajakoski, Finland). The results indicate that the burnishing process improves the surface roughness and stress conditions of AlCu6BiPb low-alloyed aluminum, and the study shows that there is good agreement between the FE and experimental results, further revealing the effect of the process parameters on the distribution of the compressive residual stress. Full article

The study presents the use of spatial imaging of the shape of the deformation formation area occurring at the point of contact between the burnished tool and the processed material surface in the burnishing process. In the analysis of changes in the shape of surfaces processed by ball and disc pressure burnishing, an integrated measurement station was used to measure surface stereometry (New Form Talysurf 2D/3D 120 by Taylor Hobson) and to carry out a series of axially shifted roundness measurements (Talyrond 365 by Taylor Hobson). The geometric parameters of the deformation zone determined in the direction of the circumference of the cylindrical surface (direction of the main movement) and in the axial direction (in the feed plane) are presented. The data obtained as a result of metrological measurements were analysed using specialized computer software. Full article

The Johnson–Cook model is widely used because of its ability to meet the simulation material requirements in various situations. However, under different working conditions, the accuracy of the model may have errors. In this work, based on Abaqus (Abaqus R2022 Education Edition, Dassault Systèmes, Paris, France) simulation software, Johnson–Cook (JC) constitutive model parameters and compression parameters were selected to simulate the improvement of surface roughness during the ball milling of a 7075-T651 aluminum alloy. In the numerical simulation of ball polishing, the changes in the residual stress field when the Johnson–Cook parameters change are analyzed. By comparing the numerically simulated residual stress fields under the JC parameters calculated at different strain rates, a set of parameters that agrees with the experimental values is selected. The results show that the residual stresses are in line with the experimental values when the strain rate is 10⁻⁴s ⁻¹. The changes in roughness corresponding to the selected parameters are analyzed. The results indicate that the simulated trend of roughness variation is consistent with the experimental values, and the optimal surface roughness value under a static pressure of 300 N is obtained. Full article

The surfaces of the mechanical parts involved in friction processes are made using different processing methods. Each of these processing methods leads to a certain profile of the asperities of the generated surfaces. When such surfaces are subjected to friction processes, it is possible to produce a change in time in the magnitude of the friction coefficient. For experimental research, the outer cylindrical surfaces of some steel test samples were generated using various machining methods such as turning, grinding, ball and diamond burnishing, and vibroburnishing. Later, using a device adapted to a lathe, experimental tests were carried out following the time variation of the value of the friction coefficient under conditions of dry friction and lubricated friction, respectively. The results of the experimental tests were processed mathematically, being determined by empirical mathematical models that highlight the influence of the final processing methods of the surface, the presence of the lubricant, and the test duration on the variation of the friction coefficient. It was found that first, there is an increase over time in the values of the friction coefficient, and then the values of this coefficient stabilize at certain values. The increase in the coefficient of friction until reaching the stabilization value takes place in a proportion of approximately 148–305%. Full article
