The performance of optoelectronic devices is affected by various noise sources. A notable factor is the 4.2% lattice mismatch at the Ge/Si interface, which significantly influences the efficiency of Ge-on-Si photodetectors. These noise sources can be analyzed by examining the impact of the Ge/Si interface and deep traps on dark and photocurrents. This study evaluates the impact of these charge traps on key photodetector performance metrics, including responsivity, photo-to-dark current ratio, noise equivalent power (NEP), and specific detectivity (D^*). The trapping effects on charge transport under both forward and reverse bias conditions are monitored through hysteresis analysis. When illuminated with an unmodulated 1550 nm laser, all the key performance metrics exhibit maximum variations at a specific reverse bias. This critical bias marks the transition from saturated to exponential charge transport regimes, where intensified electric fields enhance trap-assisted recombination and thus maximize metric fluctuations. Full article

Laser ranging is a high-precision geodetic technique that plays an indispensable role in the field of geodynamics. Avalanche photodiodes (APDs) offer a series of advantages over other photodetector technologies, including photomultiplier tubes (PMTs) and superconducting single-photon detectors (SNSPDs). These advantages include high sensitivity, small size, high integration, and low power consumption, which have contributed to the widespread use of APDs in laser ranging applications. This paper analyses the key role of APDs in enhancing the accuracy and stability of laser ranging through the examination of application examples, including Si-APD and InGaAs/InP APD. Finally, based on the technological needs of laser ranging, the future development directions of APDs are envisioned, aiming to provide a reference for the research of photodetectors in high-precision and high-frequency laser ranging applications. Full article

This paper presents two novel avalanche photodiode (APD) array structures designed to significantly enhance both detection area and bandwidth, overcoming the common trade-off between these parameters in conventional photodetectors. The impact of various parameters on the bandwidths of the two distinct array structures was theoretically simulated. Experimental validation using the self-fabricated 2 × 2 array on PCB board confirmed the bandwidth enhancement realized through inductor integration, with one APD array demonstrating an increase to 780 MHz (1.41 times greater) and another showing an increase to 1.21 GHz (1.35 times greater). Unlike prior works where array bandwidth is often lower than single detectors, our structures maintain high bandwidth while expanding the detection area. Structure 2 is particularly recommended over Structure 1 because of its lower noise, better signal-to-noise ratio (SNR), and reduced power consumption. Full article

Photodetectors with broad spectral response and high responsivity demonstrate significant potential in optoelectronic applications. This study proposes a Si/Ge avalanche photodiode featuring nanostructures that enhance light absorption. By optimizing the device epitaxial structure and these nanostructures, a wide spectral responsivity from 0.4 to 1.6 μm is achieved. The results demonstrate that introducing surface photon-trapping nanoholes and SiO₂ reflective grating nanostructures increases the average light absorptivity from 0.64 to 0.84 in the 0.4–1.1 μm range and from 0.31 to 0.56 in the 1.1–1.6 μm range. At an applied bias of 0.95 V_br-apd, the responsivity reaches 17.24 A/W at 1.31 μm and 17.6 A/W at 1.55 μm. This research provides theoretical insights for designing high-responsivity photodetectors in the visible–near-infrared broadband spectrum. Full article

Photodetectors play a critical role in space lidars designed for scientific investigations from orbit around planetary bodies. The detectors must be highly sensitive due to the long range of measurements and tight constraints on the size, weight, and power of the instrument. The detectors must also be space radiation tolerant over multi-year mission lifetimes with no significant performance degradation. Early space lidars used diode-pumped Nd:YAG lasers with a single beam for range and atmospheric backscattering measurements at 1064 nm or its frequency harmonics. The photodetectors used were single-element photomultiplier tubes and infrared performance-enhanced silicon avalanche photodiodes. Space lidars have advanced to multiple beams for surface topographic mapping and active infrared spectroscopic measurements of atmospheric species and surface composition, which demand increased performance and new capabilities for lidar detectors. Higher sensitivity detectors are required so that multi-beam and multi-wavelength measurements can be performed without increasing the laser and instrument power. Pixelated photodetectors are needed so that a single detector assembly can be used for simultaneous multi-channel measurements. Photon-counting photodetectors are needed for active spectroscopy measurements from short-wave infrared to mid-wave infrared. HgCdTe avalanche photodiode arrays have emerged recently as a promising technology to fill these needs. This paper gives a review of the photodetectors used in past and present lidars and the development and outlook of HgCdTe APD arrays for future space lidars. Full article

Detecting extremely low light signals is the basis of many scientific experiments and measurement techniques. For many years, a high-voltage photomultiplier has been the only practical device used in the visible and infrared spectral range. However, such a solution is subject to several inconveniences, including high production costs, the requirements of a supply voltage of several hundred volts, and a high susceptibility to mechanical damage. This paper presents two detection systems based on avalanche photodiodes, one cooled and the second operating at room temperature, in terms of their potential application in thermoluminescent dosimeter units. The results show that the detection system with an uncooled photodiode may successfully replace the photomultiplier tube commonly used in practice. Full article

Highly sensitive infrared photodetectors are needed in numerous sensing and imaging applications. In this paper, we report on extended short-wave infrared (e-SWIR) avalanche photodiodes (APDs) capable of operating at room temperature (RT). To extend the detection wavelength, the e-SWIR APD utilizes a higher indium (In) composition, specifically In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures. The detection cut-off wavelength is successfully extended to 2.6 µm at RT, as verified by the Fourier Transform Infrared Spectrometer (FTIR) detection spectrum measurement at RT. The In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures are lattice-matched to GaSb substrates, ensuring high material quality. The noise current at RT is analyzed and found to be the shot noise-limited at RT. The e-SWIR APD achieves a high multiplication gain of $M~190$ at a low bias of $V_{bias}=-2.5\mathrm{V}$ under illumination of a distributed feedback laser (DFB) with an emission wavelength of 2.3 µm. A high photoresponsivity of $\mathfrak{R}>140\mathrm{A}/\mathrm{W}$ is also achieved at the low bias of $V_{bias}=-2.5\mathrm{V}$. This type of highly sensitive e-SWIR APD, with a high internal gain capable of RT operation, provides enabling technology for e-SWIR sensing and imaging while significantly reducing size, weight, and power consumption (SWaP). Full article

Avalanche photodiodes have emerged as a promising technology with significant potential for various medical applications. This article presents an overview of the advancements and applications of avalanche photodiodes in the field of medical imaging. Avalanche photodiodes offer distinct advantages over traditional photodetectors, including a higher responsivity, faster response times, and superior signal-to-noise ratios. These characteristics make avalanche photodiodes particularly suitable for medical-imaging modalities that require a high detection efficiency, excellent timing resolution, and enhanced spatial resolution. This review explores the key features of avalanche photodiodes, discusses their applications in medical-imaging techniques, and highlights the challenges and future prospects in utilizing avalanche photodiodes for medical purposes. Special attention is paid to the recent progress in silicon-compatible avalanche photodiodes. Full article

InAs/AlSb is a material system that can be used as a low-noise avalanche detector and operates in the short-wave infrared band. The interface parameters determine the wave function overlap (WFO). Maximizing the WFO of InAs/AlSb superlattices improves the quantum efficiency (QE) of infrared avalanche photodetectors (APDs). However, this remains a huge challenge. Here, the 8-band k·p perturbation method based on Bloch wave envelope function approximation was used to calculate the energy level structure of InAs/AlSb superlattices. The results indicate that the WFO is enhanced with increasing InSb interface thickness or when the InSb (or AlAs) interface is far from the intersection of InAs and AlSb. As the AlAs interface thickness increases, the WFO enhances and then reduces. The maximum increase in WFO is 15.7%, 93%, and 156.8%, respectively, with three different models. Based on the stress equilibrium condition, we consider the interface engineering scheme proposed for enhancing WFO with an increase of 16%, 114%, and 159.5%, respectively. Moreover, the absorption wavelength shift is less than ±0.1 μm. Therefore, the interface layer thickness and position can be designed to enhance the WFO without sacrificing other properties, thereby improving the QE of the device. It provides a new idea for the material epitaxy of APDs. Full article

Single-pixel imaging lidar is a novel technology that leverages single-pixel detectors without spatial resolution and spatial light modulators to capture images by reconstruction. This technique has potential imaging capability in non-visible wavelengths compared with surface array detectors. An avalanche photodiode (APD) is a device in which the internal photoelectric effect and the avalanche multiplication effect are exploited to detect and amplify optical signals. An encapsulated APD detector, with an APD device as the core, is the preferred photodetector for lidar due to its high quantum efficiency in the near-infrared waveband. However, research into APD detectors in China is still in the exploratory period, when most of the work focuses on theoretical analysis and experimental verification. This is a far cry from foreign research levels in key technologies, and the required near-infrared APD detectors with high sensitivity and low noise have to be imported at a high price. In this present study, an encapsulated APD detector was designed in a linear mode by integrating a bare APD tube, a bias power circuit, a temperature control circuit and a signal processing circuit, and the corresponding theoretical analysis, circuit design, circuit simulation and experimental tests were carried out. Then, the APD detector was applied in the single-pixel imaging lidar system. The study showed that the bias power circuit could provide the APD with an operating voltage of DC 1.6 V to 300 V and a ripple voltage of less than 4.2 mV. Not only that, the temperature control circuit quickly changed the operating state of the Thermo Electric Cooler (TEC) to stabilize the ambient temperature of the APD and maintain it at 25 ± 0.3 °C within 5 h. The signal processing circuit was designed with a multi-stage amplification cascade structure, effectively raising the gain of signal amplification. By comparison, the trial also suggested that the encapsulated APD detector and the commercial Licel detector had a good agreement on the scattered signal, such as a repetition rate and pulse width response under the same lidar environment. Therefore, target objects in real atmospheric environments could be imaged by applying the encapsulated APD detector to the near-infrared single-pixel imaging lidar system. Full article

In this article, the performance and design considerations of the planar structure of germanium on silicon avalanche photodiodes are presented. The dependences of the breakdown voltage, gain, bandwidth, responsivity, and quantum efficiency on the reverse bias voltage for different doping concentrations and thicknesses of the absorption and multiplication layers of germanium on the silicon avalanche photodiode were simulated and analyzed. The study revealed that the gain of the avalanche photodiode is directly proportional to the thickness of the multiplication layer. However, a thicker multiplication layer was also associated with a higher breakdown voltage. The bandwidth of the device, on the other hand, was inversely proportional to the product of the absorption layer thickness and the carrier transit time. A thinner absorption layer offers a higher bandwidth, but it may compromise responsivity and quantum efficiency. In this study, the dependence of the photodetectors’ operating characteristics on the doping concentration used for the multiplication and absorption layers is revealed for the first time. Full article

A high-speed and high-sensitivity avalanche photodetector (APD) is a critical component of a high-data-rate and low-power optical-communication link. In this paper, we study a high-speed and high-efficiency Ge/Si heterostructure APD. First, we numerically study the speed performance of the APD by analyzing frequency response. An optimized epitaxial structure of the high-speed APD is designed. In the absence of RC time effects, the APD exhibits a fast pulse response (full-width at half-maximum) of 10 ps and a high 3 dB bandwidth of 33 GHz at a high-gain value of 10. Taking device size and the corresponding RC time effects into account, the APD still achieves a high 3 dB bandwidth of 29 GHz at a gain value of 10. Moreover, a novel subwavelength periodic hole array is designed on the normal-incidence APD for enhancing light absorption without sacrificing speed performance. Near-perfect absorption is almost achieved by an infinite-period hole array due to the coupling of dual-resonance modes. A high-absorption efficiency of 64% is obtained by a limited-sized hole array in the high-speed APD. This work provides a promising method to design high-speed and high-efficiency normal-incidence Ge/Si heterostructure APDs for optical interconnect systems. Full article

Ge/Si separate absorption, charge, and multiplication avalanche photodiodes (SACM APDs) coupled with waveguides have shown significant potential as high-sensitivity, low-noise, and high-speed photodetectors for optical communications. In this study, we present a waveguide-integrated Ge/Si SACM APD fabricated on an eight-inch silicon photonics platform. The device exhibits a primary responsivity of 0.68 A/W at the unit gain voltage of 6 V for the O-band (1310 nm) wavelength, with a 10 μm-long and 1 μm-wide Ge layer. Additionally, the device demonstrates a 3 dB bandwidth of 25.7 GHz, with an input optical power of −16.8 dBm. The largest gain bandwidth product (GBP) is 247 GHz at a gain of 9.64 and a bias voltage of 15.7 V. The eye diagram is open at the bias voltage of 16 V, with a capacity to receive 28 Gbps of data. This APD shows potential for application in high-speed data transmission systems. Full article

Accurate detection of weak optical signals is a key function for a wide range of applications. A key performance parameter is the receiver signal-to-noise ratio, which depends on the noise of the photodetector and the following electrical circuitry. The circuit noise is typically larger than the noise of photodetectors that do not have internal gain. As a result, a detector that provides signal gain can achieve higher sensitivity. This is accomplished by increasing the photodetector gain until the noise associated with the gain mechanism is comparable to that of the output electrical circuit. For avalanche photodiodes (APDs), the noise that arises from the gain mechanism, impact ionization, increases with gain and depends on the material from which the APD is fabricated. Si APDs have established the state-of-the-art for low-noise gain for the past five decades. Recently, APDs fabricated from two Sb-based III-V compound quaternary materials, Al_xIn_1-xAs_ySb_1-y and Al_xGa_1-xAs_ySb_1-y, have achieved noise characteristics comparable to those of Si APDs with the added benefit that they can operate in the short-wave infrared (SWIR) and extended SWIR spectral regions. This paper describes the materials and device characteristics of these APDs and their performance in different spectral regions. Full article

This paper reports the implementation of two critical technologies used in light detection and ranging for space applications: (1) a microchip Q-switched laser breadboard; (2) a breadboard of an indium gallium arsenide avalanche photodiode working at 292 K with high reverse polarization voltages. Microchip Q-switched lasers are small solid-state back-pumped lasers that can generate high-energy short pulses. The implemented breadboard used an erbium and ytterbium co-doped phosphate glass, a Co:Spinel crystal with 98% initial transparency, and an output coupler with 98% reflectivity. For the sensor test, a system for simultaneous operation in vacuum and a wide range of temperatures was developed. Avalanche photodiodes are reverse-polarized photodiodes with high internal gain due to their multiple layer composition, capable of building up high values of photocurrent from small optical signals by exploiting the avalanche breakdown effects. The test avalanche photodetector was assembled to be operated in two modes: linear and Geiger mode. The produced photocurrent was measured by using: (1) a passive quenching circuit; (2) a transimpedance amplifier circuit. These two technologies are important for mobile light detection and ranging applications due to their low mass and high efficiencies. The paper describes the breadboard’s implementation methods and sensor characterization at low and room temperatures with high bias voltages (beyond breakdown voltage). Full article
