Nitridation of different materials using ion implantation is of considerable interest for many applications. As electronic components, oxynitride (SiO_xN_y) layers exhibit beneficial properties such as precise compositional variability, refractive index tunability, oxidation resistance, and low mechanical stress. In the present study we investigate nanoscale SiO_xN_y synthesized using ion implantation methods. To introduce N⁺ ions into a shallow Si subsurface region, both conventional ion beam implantation and plasma immersion ion implantation with subsequent high-temperature treatment in dry O₂ are used. The optical and morphological properties and chemical bonding of formed SiO_xN_y layers were studied by applying spectroscopic ellipsometry in the range of VIS-Near IR (SE) and IR (IR-SE), Raman spectroscopy and Atomic Force Microscopy (AFM). Monte Carlo modeling of implant profiles contributed to understanding physical and chemical processes and predicted different influences of the incorporated N⁺ ions on the oxidation mechanism, confirmed by the thickness dependence of SiO_xN_y/Si layers obtained from the SE data analysis. IR-SE spectral analysis established the formation of Si-O, Si-N, Si-N-O and Si-Si chemical bonds in the grown layers. The occurrence of amorphization of the Si crystal lattice due to incorporation of high-energy N⁺ ions into the Si lattice is confirmed by the Raman and ellipsometry results. The free Si atoms can congregate, forming nanocrystalline clusters. AFM imaging revealed that both implantation methods left the surface of the resulting SiO_xN_y layers considerably smooth with similar roughness parameter values. The results of the studies imply that the technological approaches used allow the production of high-quality nanoscale silicon oxynitride films with appropriate tunable composition and properties for possible application in advanced electronic devices for nanoelectronics, optoelectronics and sensor applications. Full article

Molecular dynamics simulations were used to study the interaction of Ar clusters with silicon and germanium single crystals at a fixed cluster size of 923 atoms and a total kinetic energy of 10 keV. A comparative analysis was conducted to examine the effects of argon cluster impacts on the surface morphology of silicon and germanium as the cluster incidence angle varied from 0° to 75° with respect to the surface normal. The depth of amorphization and the height of hillocks induced in silicon and germanium after argon cluster bombardment were estimated. Angular dependences of the crater diameters along and perpendicular to the cluster incidence direction were demonstrated. Comparisons of crater characteristics and the ratios of longitudinal to transverse crater dimensions revealed material-specific features of cluster–surface interactions. At oblique incidence, a peak in the ratio of displaced atoms in the amorphous layer to those above the surface was observed. The potential energy of silicon and germanium target atoms following cluster impact was visualized and estimated. Moreover, the redistribution patterns of the cluster’s initial kinetic energy among the target, scattered cluster atoms, and sputtered target atoms were compared for silicon and germanium at incidence angles from 0° to 75°. Full article

This study proposes a new fabrication process for terahertz Fresnel zone plates on high-resistivity silicon substrates. It involves ion implantation surface modification, ultra-precision diamond turning, and magnetron sputtering, followed by polishing. Ductile-regime cutting is used to form smooth microgrooves, which are selectively metallized to create alternating opaque and transparent zones for terahertz waves. Finite-element simulations are performed to design the zone structure and to evaluate the effect of process-induced radius errors. A 3 μm amorphous layer is formed via ion implantation, which significantly enhances the ductile-to-brittle transition depth of silicon from 55 nm to about 535 nm while causing only minor changes in terahertz transmittance. The results demonstrate that the proposed method can produce high-quality Fresnel zone plates on silicon and offers a practical route to compact diffractive terahertz components. Full article

Neural interfaces created using thin-film fabrication rely primarily on conductive metal traces for electrical interconnects. Here, we explore the use of tantalum (Ta) metal interconnects as a replacement for noble-metal interconnects such as Au, Pt or Ir. Ta has been investigated previously for interconnect metallization in flexible silicon ribbon cables, but the structure and properties of tantalum for neural device metallization have not been extensively reported. In the present work, Ta metal was sputter-deposited onto amorphous silicon carbide (a-SiC), with and without a base titanium (Ti) adhesion layer, and investigated as interconnect metallization. In the absence of a Ti adhesion layer, resistivity measurements revealed a factor of six difference between Ta resistivity depending on the presence of the Ti base layer, with direct deposition on a-SiC nucleating high resistivity β-Ta (ρ = 197 ± 31 µΩ·cm, mean ± standard deviation) and Ta deposited on Ti nucleating low resistivity α-Ta (ρ = 35 ± 6 µΩ·cm). X-ray diffraction confirmed the existence of the two crystal structures. Ta feature sizes of 2 µm were created using photolithography and reactive ion etching (RIE). Finally, planar microelectrode array test structures using α-Ta and Au trace metallization with low-impedance ruthenium oxide (RuO_x) electrodes were fabricated and investigated by cyclic voltammetry (CV) and current pulsing in saline. These devices underwent 500 CV cycles between −0.6 and +0.6 V without evidence of degradation. In response to charge-balanced, biphasic current pulses at 4 nC/phase, a 21 mV increase in access voltage was observed with α-Ta metallization compared to Au. These results warrant further investigation of Ta as thin-film metallization interconnects for neural interface devices. Full article

Thermally grown amorphous SiO₂ (a-SiO₂) on Si is widely used in microfluidic and biointerface devices, where surface charge governs capillary flows. We used amplitude-modulation Kelvin probe force microscopy (AM-KPFM) in air to test whether low-power visible light modulates a-SiO₂ surface potential and to derive mathematical charging-discharging models. Single-point contact potential difference (CPD) was recorded on ~0.6 µm p-type a-SiO₂ on p-type monocrystalline Si during repeated illumination cycles with continuous-wave diode lasers at 405, 505, and 685 nm delivered by optical fiber. The 405 and 505 nm wavelengths produced reproducible negative CPD shifts with steady-state values of ~−28 mV and ~−16 mV, while 685 nm stayed within noise (±2.5 mV). The 405 nm response followed bi-exponential kinetics with fast (tens of seconds) and slow (hundreds of seconds) components dominated by the slow process; after switch-off, CPD relaxed only from ~−28 to ~−23 mV over ~10³ s, indicating retention for ≥10³–10⁴ s. The 505 nm charging trace fit a single slower xponential, whereas discharging could not be fit robustly. These results demonstrate wavelength-dependent optical tuning of a-SiO₂ surface potential and provide compact kinetic descriptors for comparing charging, discharging, and retention. Full article

In this work, hydrogenated amorphous silicon carbide (a-SiC_x:H) and hydrogenated amorphous silicon oxide (a-SiO_x:H) films with similar optical bandgaps (E_g), refractive indices (n), and extinction coefficients (k) were fabricated using pulse-wave modulation (PWM) plasma technology by controlling the plasma turn-on to turn-off time ratio (t_on/t_off). These films were placed at the 1/5 position of the p/i and i/n interfaces of hydrogenated amorphous silicon (a-Si:H) p-i-n solar cells to investigate their influence on solar cell performance. The experimental results confirmed that the deviations in E_g, n, and k were controlled to within 0.2%, 1.4%, and 4.1%, respectively. Under these conditions, placing a-SiC_x:H and a-SiO_x:H films at the p/i and i/n interfaces successfully increased the open-circuit voltage (V_oc). However, this also led to a decrease in the short-circuit current due to valence band (ΔE_v) or conduction band (ΔE_c) offsets. The reduction in cell fill factor (FF) and efficiency (η) caused by placing a-SiC_x:H and a-SiO_x:H films at the p/i interface was greater than that caused by placing them at the i/n interface. Placing the a-SiC_x:H film at the p/i interface significantly improved the V_oc to 0.8998 V. Due to the n-type doping effect of oxygen atoms, the a-SiO_x:H film exhibited the lowest FF of 43.99% and η of 4.850% at the p/i interface; however, when placed at the i/n interface, it yielded an FF of 67.38% and an η of 7.43%, which are comparable to the standard cell. Appropriately placing the a-SiC_x:H film at the p/i interface and the slightly n-type a-SiO_x:H film at the i/n interface can effectively improve the V_oc, FF, and η of p-i-n solar cells. Full article

Currently, titanium dioxide films are widely used as the electron transport layer material in perovskite solar cells. An alternative to titanium dioxide for this role could be niobium pentoxide (Nb₂O₅), an n-type conducting semiconductor oxide. However, the application of Nb₂O₅ in perovskite solar cells is hindered by a lack of data on its electron transport properties, electrophysical parameters, and current–voltage characteristics. Amorphous niobium pentoxide films were obtained by magnetron sputtering. To study their electrical and capacitive properties, a structure of heavily doped n⁺-silicon (n⁺)/niobium oxide/aluminum was used. Based on the analysis of the I–V curves, it was concluded that for a sample at 25 °C, the electron mean free path is greater than the width of the Schottky barrier layer, allowing electrons to pass through this layer without collisions. At temperatures of 35 °C and higher, electrons experience numerous collisions within the Schottky barrier layer. The height of the Schottky barrier for the contact between niobium pentoxide and aluminum was determined. The obtained capacitance frequency plots were explained using the concepts of dipole-relaxation polarization in a dielectric, where electric dipoles can reorient in an external electric field. It has been shown that the use of magnetron sputtering to produce amorphous niobium pentoxide films leads to a reduction in the effective Schottky barrier height. This allows for high electron injection density at low voltages when using such an oxide semiconductor as an electron transport layer, thereby potentially increasing the efficiency of solar cells. Full article

Phosphogypsum (PG) and phosphorus tailings (PT) are bulk solid wastes generated by the phosphorus chemical industry whose stockpiling poses significant environmental risks and represents a waste of resources. To achieve the goals of “treating waste with waste” and large-scale disposal, this study proposes a technical pathway involving the co-pyrolysis of phosphogypsum and phosphorus tailings to produce artificial soil-like materials. The effects of raw material ratio, pyrolysis temperature and duration, and biomass addition on the speciation transformation, leaching toxicity, and matrix characteristics of phosphorus (P) and fluorine (F) in the products were systematically investigated. Characterization techniques, including X-ray diffraction (XRD), Fourier transform infrared spectroscopy (FTIR), and scanning electron microscopy (SEM), were employed to elucidate the synergistic immobilization mechanism. The results indicate that under optimized conditions (PG:PT mass ratio of 6:4, pyrolysis temperature of 800 °C, duration of 2–3 h, and biomass addition of 20%–30%), the active forms of harmful elements in the product were significantly reduced. The proportion of water-soluble fluorine decreased from ~39% in raw phosphogypsum to less than 3%, with apatite phosphorus becoming the dominant form of phosphorus. Mechanistic studies reveal that the immobilization process follows a “multi-pathway synergy” mechanism: thermal activation promotes the in situ formation of thermodynamically stable fluorapatite through the reaction of Ca²⁺, PO₄³⁻, and F⁻ (chemical fixation); iron/aluminum oxides in phosphorus tailings and the biochar derived from added biomass provide adsorption sites for surface complexation (physicochemical fixation); and the melting of silicon–aluminum components forms an amorphous silicate network that physically encapsulates pollutant microcrystals. This study provides crucial theoretical foundations and process parameters for the synergistic disposal and soil-like resource utilization of phosphogypsum and phosphorus tailings, demonstrating significant environmental and economic benefits. Full article

Programmable photonic integrated circuits implement optical switching and processing by interconnecting reconfigurable 2 × 2 cells in mesh topologies. Directional couplers are widely used in these cells, often combined with phase-shifting mechanisms to enable tunability. However, conventional directional couplers in dense meshes typically require submicron gaps and tight etching tolerances, which increase sensitivity to fabrication variations and can introduce excess loss and variability. In addition, interconnected waveguides (e.g., S-bends and crossings) increase layout complexity, footprint, and bending-related penalties, while thermo-optic control may introduce power consumption and thermal crosstalk. Here, we propose a shallow-rib strip directional coupler in hydrogenated amorphous silicon (a-Si:H) for 1 µm × 1 µm multimode waveguides. The proposed geometry enables efficient coupling for waveguide separations ≥ 1 µm by shifting the coupling control from the lateral gap to the slab height, allowing smoother transitions and a relaxed fabrication flow. The analysis combines coupled-mode theory and beam propagation method simulations. As an application example, the layout of a 4 × 4 thermo-optically reconfigurable switching matrix is designed and simulated using 2 × 2 shallow-rib strip coupler cells. Full article

Calcium phosphate–poly(methyl-methacrylate) composite layers have been synthetized on silicon substrates in magnetron sputtering discharge by adjusting the radio-frequency power. The electron energy distribution function measured at holder substrate position shifts to lower energies when the radio-frequency power applied to the magnetron source increases from 50 to 150 W and the poly(methyl-methacrylate) molecule dissociation is augmented. The optical emission spectral analysis indicated the dynamics of the excitation and ionization processes in the Ar–calcium phosphate–poly(methyl-methacrylate) plasma mixture, as well as the dissociation patterning of the polymer molecules. The Ca I, P I, and H_α atomic lines and CaO, PO, POH, CO, CH and C₂ molecular bands characteristic to the calcium phosphate and poly(methyl-methacrylate) decomposition were evidenced. At 150 W radio-frequency power a reduction in the polymer content in the composite layer volume was observed even if the α-CH₃ main chain and the C=O molecular bands are still present. More C-C/C-H, C-OH/C-O-C polymeric bonds were revealed at the layer surface, indicating the formation of plasma polymers. The Ca/P ratio changes from 1.72 to 1.9 at 50 to 150 W, respectively, maintaining the amorphous structure of the layers. In this power range, the transition of layer surface morphologies from grain-like to worm-like plasma polymer characteristics is connected to an increase in plasma ion density and layer thickness. Full article

This study investigates the deposition of amorphous silicon carbon nitride (a-SiCN) films using a microwave sheath–voltage combination plasma (MVP) source under duty-cycle-controlled deposition conditions. Duty ratios of 10, 30, 50, and 70% resulted in substrate temperatures of 180, 600, 980, and 1040 °C, respectively. The deposition rate reached a maximum of approximately 208 μm/h at a duty ratio of 30%. The atomic ratios of C, N, and Si remained nearly constant for duty ratios from 30% to 70%. X-ray diffraction confirmed that all films were amorphous. Raman spectra revealed features characteristic of amorphous carbon (a-C) for duty ratios of 30% or higher, suggesting the incorporation of a-C-like structures into the a-SiCN matrix. The film hardness increased as the duty-cycle-controlled deposition conditions shifted from 10% to 50% (180 to 980 °C), reaching a maximum of 22.65 ± 6.78 GPa at a duty ratio of 50%, and then decreased at 70% (1040 °C). These variations in hardness are suggested to be associated with coupled changes in hydrogen incorporation, C–N bonding, and the evolution of sp²-rich carbon clustering (graphite-like short-range ordering) under elevated temperature and ion-bombardment conditions. Full article

In this study, we investigated the electrochemical properties and performance characteristics of Co_xS_y and silicon–carbon-based heterostructures synthesized on nickel foam substrates for energy storage applications. Cobalt sulfide films were successfully electrodeposited on nickel foam (NF) using cyclic voltammetry (CV) from the solutions with different Co²⁺ concentrations. The presence of a silicon–carbon sublayer promotes the deposition of cobalt sulfide material. The amorphous phase of α-CoS was observed by the X-ray diffraction technique. Raman spectroscopy confirmed the formation of CoS and CoS₂ phases. A significant increase in electrode areal capacitance is observed with the silicon–carbon film sublayer from 0.5 to 1.3 F·cm⁻² and from 1.6 to 2.3 F·cm⁻² at 3 mA·cm⁻² for samples prepared from solutions with CoCl₂·6H₂O concentrations of 0.005 M and 0.02 M, respectively. In the case of gravimetric capacitance, an increase is observed in the presence of a silicon–carbon sublayer for the SiC@CoS_0.005 sample, rising from 690 F·g⁻¹ to 748 F·g⁻¹ at 4 A·g⁻¹. Conversely, the SiC@CoS_0.02 sample shows a decrease from 1287 F·g⁻¹ to 6590 F·g⁻¹. It was shown that the capacitance of all the electrodes derives from the mix of diffusion-controlled and surface-controlled capacitance processes. The electrochemical impedance spectroscopy (EIS) analysis indicates that the formation of heterostructure materials significantly alters the electrochemical properties by reducing both R_f and R_s. Full article

Amorphous soft magnetic materials (AMMs) have demonstrated significant advantages in electric machines due to their low core losses, high permeability, high tensile strength, and superior energy efficiency at high operating frequencies. Despite these benefits, their adoption in electric vehicle (EV) motors remains limited. This review explores the key technological, economic, and industrial barriers preventing the widespread use of AMMs in EV applications. An overview of the AMM fundamentals, including the material composition, manufacturing processes, and recent advancements, is first presented. To quantitatively assess their potential in traction applications, a numerical study is conducted on two 5.5 kW synchronous reluctance machines with identical geometries, employing AMM and conventional silicon steel stators, respectively. The machines are compared in terms of electromagnetic torque and efficiency, highlighting the impact of AMM properties on machine performance. These results are discussed alongside the findings from the existing literature to evaluate the core loss reduction, electromagnetic behavior, mechanical robustness, and thermal considerations. Special attention is given to the emerging commercial applications of AMMs in EV motors, which have only recently begun to materialize. Finally, the study highlights the gap between academic research and industrial implementation and identifies critical research areas needed to accelerate AMM adoption. Full article

Hydrogenated amorphous silicon (a-Si:H) is a mature thin-film technology for large-area devices and thin-film sensors, and its low-temperature growth via Plasma-Enhanced Chemical Vapor Deposition (PECVD) makes it particularly suitable for biomedical flexible and wearable platforms. However, the reliable integration of a-Si:H sensors on polymer substrates requires a quantitative assessment of their electrical stability under mechanical stress, since bending-induced variations may affect sensor accuracy. In this work, we provide a quantitative, direction-dependent evaluation of the static-bending robustness of both single-doped a-Si:H layers and complete p-i-n junction stacks on polyimide (Kapton^®), thereby linking material-level strain sensitivity to device-level functionality. First, n- and p-doped a-Si:H layers were deposited on 50 µm thick Kapton^® and then structured as two-terminal thin-film resistors to enable resistivity extraction under bending conditions. Electrical measurements were performed on multiple samples, with the current path oriented either parallel (longitudinal) or perpendicular (transverse) to the bending axis, and resistance profiles were determined as a function of bending radius. While n-type layers exhibited limited and mostly gradual variations, p-type layers showed a stronger sensitivity to mechanical stress, with a critical-radius behavior under transverse bending and a more progressive evolution in the longitudinal one. This directional response identifies a practical bending condition under which doped layers, particularly p-type films, are more susceptible to strain-induced degradation. Subsequently, a linear array of a-Si:H p-i-n sensors was fabricated on Kapton^® substrates with two different thicknesses (25 and 50 µm thick) and characterized under identical bending conditions. Despite the increased strain sensitivity observed in the single-layers, the p-i-n diodes preserved their rectifying behavior down to the smallest radius tested. Indeed, across the investigated radii, the reverse current at −0.5 V remained consistent, confirming stable junction operation under bending. Only minor differences, related to substrate thickness, were observed in the reverse current and in the high-injection regime. Overall, these results demonstrate the mechanical robustness of stacked a-Si:H junctions on polyimide and support their use as sensors for wearable biosensing architectures. By establishing a quantitative, orientation-aware stability benchmark under static bending, this study supports the design of reliable a-Si:H flexible sensor platforms for curved and wearable surfaces. Full article

This work presents an advanced electro-physical model for hydrogenated amorphous silicon (a-Si:H) Junction Field Effect Transistors (JFETs) to enable the design of devices with energy-efficient analog interface building blocks for Lab-on-Chip (LoC) systems. The presence of this device can support monolithic integration with thin-film sensors and circuit-level design through a validated compact formulation. The model accurately describes the behavior of a-Si:H JFETs addressing key physical phenomena, such as the channel thickness dependence on the gate-source voltage when the channel approaches full depletion. A comprehensive framework was developed, integrating experimental data and mathematical refinements to ensure robust predictions of JFET performance across operating regimes, including the transition toward full depletion and the associated current-limiting behavior. The model was validated through a broad set of fabricated devices, demonstrating excellent agreement with experimental data in both the linear and saturation regions. Specifically, the validation was carried out at 25 °C on 15 fabricated JFET configurations (12 nominally identical devices per configuration), using the mean characteristics of 9 devices with standard-deviation error bars. In the investigated bias range, the devices operate in a sub-µA regime (up to several hundred nA), which naturally supports µW-level dissipation for low-power interfaces. This work provides a compact, experimentally validated modeling basis for the design and optimization of a-Si:H JFET-based LoC front-end/readout circuits within technology-constrained and energy-efficient operating conditions. Full article
