To commercialize supersonic and hypersonic passenger aircraft and reusable spaceplanes, we are developing a small-scale supersonic flight experiment vehicle as a flying testbed for technical demonstrations in high-speed flight environments. This experiment vehicle is equipped with a fuel tank and an oxidizer tank, and the propellants inside the tanks slosh due to changes in acceleration during flight. In this situation, there is a risk of gas entrainment during liquid discharge, which could potentially cause an engine malfunction. To avoid such a situation, we considered installing a propellant management device (PMD) inside the tank to suppress the gas entrainment. In this study, a capillary type PMD with a screen channel structure, commonly used in satellites featuring no moving parts, was adopted due to its applicability to a wide acceleration range. The PMD was designed with a structure featuring cylindrical mesh screen nozzles installed at the top and bottom of a cylindrical tank. A one-dimensional flow analysis model was developed taking into account factors such as the pressure loss across the mesh screens and the flow loss within the mesh screen nozzles, which enabled the identification of conditions under which gas entrainment occurred. In this analytical model, separate formulations were developed using Hartwig’s and Ingmanson’s formulas for evaluating the flow losses through the mesh screens. Furthermore, by applying the flow analysis model, the specifications of the mesh screens as key parameters of the PMD, together with the nozzle diameter and nozzle length, were selected. Moreover, we fabricated prototype PMDs with each nozzle and conducted visualization tests using a transparent tank. The tests were conducted under static conditions, where a gravitational acceleration acted downward, and the effects of the cylindrical mesh screen length and discharge flow rate on the free surface height at which gas entrainment occurred were investigated. This experiment demonstrated the effectiveness of the propellant acquisition mechanism of the present PMD. The height of the free surface was also compared with the experimental and analytical results, and it was shown that the results obtained by using Ingmanson’s formula for pressure loss through the screen mesh were closer to the experimental results. These findings demonstrated the validity of the one-dimensional flow analysis model. Full article

This work studies the feasibility of integrating a hydrogen-powered propulsion system in a regional aircraft at the conceptual design level. The developed system consists of fuel cells, which will be studied at three technological levels, and batteries, also studied for four hybridization factors (X = 0, 0.05, 0.10, 0.20). Hydrogen can absorb great thermal loads since it is stored in the tank at cryogenic temperatures and is used as fuel in the fuel cells at around 80 °C. Taking advantage of this characteristic, two thermal management system (TMS) architectures were developed to ensure the proper functioning of the aircraft during the designated mission: A1, which includes a vapor compression system (VCS), and A2, which omits it for a simpler design. The models were developed in MATLAB^® and consist of different components and technologies commonly used in such systems. The analysis reveals that A2, due to the exclusion of the VCS, outperformed A1 in weight (10–23% reduction), energy consumption, and drag. A1’s TMS required significantly more energy due to the VCS compressor. Hybridization with batteries increased system weight substantially (up to 37% in A2) and had a greater impact on energy consumption in A2 due to additional fan work. Hydrogen’s heat sink capacity remained underutilized, and the hydrogen tank was deemed suitable for a non-integral fuselage design. A2 had the lowest emissions (10–20% lower than A1 for X = 0), but hybridization negated these benefits, significantly increasing emissions in pessimistic scenarios. Full article

In the development of more electric aircraft, hydrogen powered fuel cells are one possible solution to progress towards emission reductions in aviation. Currently, there are numerous concepts for integrating fuel cells into future aircraft. The goal of this work was to develop a dynamic fuel cell model for simulations of the powertrain. The Modelica language together with the ThermoFluidStream (TFS) library from the German Aerospace Center (DLR) provided a suitable framework. The fuel cell model takes into account the electrochemical as well as thermodynamic behavior. Hence, the proposed multi-physics model allows simulating the whole fuel cell system, from the hydrogen tank to the electric grid. Under certain simplifications, this enables performing mission simulations of the complete powertrain of future aircraft. As such, polymer electrolyte membrane (PEM) fuel cells and solid oxide fuel cells (SOFC) were considered. The fuel cell models are checked for plausibility in a simple test case against data from the literature. Furthermore, two setups of possible applications are introduced: one for each fuel cell type, which come from two projects. The preliminary control systems of these architectures are presented. Afterwards, the first results of the fuel cell systems are discussed. These results show that the models ran robustly in various environments and operational states. They provided the desired accuracy to predict the behavior of a fuel cell, while maintaining low CPU times and being capable of enabling real-time simulations in the future. Full article

The aviation industry relies on continuous inspections to ensure infrastructure safety, particularly in confined spaces like aircraft fuel tanks, where human inspections are labor-intensive, risky, and expose workers to hazardous exposures. Robotic systems present a promising alternative to these manual processes but face significant technical and operational challenges, including technological limitations, retraining requirements, and economic constraints. Additionally, existing prototypes often lack open-source documentation, which restricts researchers and developers from replicating setups and building on existing work. This study addresses some of these challenges by proposing a modular, open-source framework for robotic inspection systems that prioritizes simplicity and scalability. The design incorporates a robotic arm and an end-effector equipped with three RGB-D cameras to enhance the inspection process. The primary contribution lies in the development of decentralized software modules that facilitate integration and future advancements, including interfaces for teleoperation and motion planning. Preliminary results indicate that the system offers an intuitive user experience, while also enabling effective 3D reconstruction for visualization. However, improvements in incremental obstacle avoidance and path planning inside the tank interior are still necessary. Nonetheless, the proposed robotic system promises to streamline development efforts, potentially reducing both time and resources for future robotic inspection systems. Full article

As aviation demand rises, fossil jet fuel consumption follows, thus increasing focus on sustainable aviation fuels to reduce aircraft greenhouse gas emissions. While advanced technologies and optimized operations play a role, alternative fuels, especially non-drop-in options like Liquefied Natural Gas (LNG) and methanol, offer promising potential for significant emission reductions if used in current aero-engines. LNG, a candidate near-term replacement of fossil jet fuel and methanol, even though a less conventional option in aviation, present advantages. Both fuels showcase the ability to generate the same thrust output by also achieving lower post-combustion temperatures, thereby enhancing component life and reducing emissions. Inversely, requesting equal post-combustion temperature as the baseline kerosene operation of the engine can produce greater thrust output, a much needed result for such fuels with low volumetric energy density, which causes greater take-off thrust demand mainly due to their larger tank requirements. This study uses advanced 0-D engine models coupled with detailed chemistry 1-D burner models and mission analysis tools to assess the aforementioned trends of LNG and methanol used to power a current geared turbofan engine. The aim of this work is to provide insights into the advantages, the limitations and the overall viability of the fuels in question as less polluting aviation fuels, addressing both environmental impact and operational feasibility in future aviation applications. According to findings of this article, when compared with Jet-A, LNG can reduce post-combustion temperature by an average of 1% or increase net-thrust by 3% while lowering $C{O}_2$, $N{O}_x$ and $CO$ emissions by 20%, 46% and 39%, respectively. Adversely, methanol is capable of lessening post-combustion temperature by 3% or enhancing thrust output by 10% while also reducing $C{O}_2$, $N{O}_x$ and $CO$ emissions by an average of 6%, 60% and 38%, respectively. Full article

Stringent sustainability goals are set for the next generation of aircraft. A promising novel airframe concept is the ultra-high aspect ratio Strut-Braced Wing (SBW) aircraft. Hydrogen-based concepts are active contenders for sustainable propulsion. The study compares a medium-range Liquid Hydrogen (LH2) to a kerosene-based SBW aircraft designed with the same top-level requirements. For both concepts, overall design, operating costs, and emissions are evaluated using the tool SUAVE. Furthermore, aerostructural optimizations are performed for the wing mass of SBW aircraft with and without wing-based fuel tanks. Results show that the main difference in the design point definition results from a higher zero-lift drag due to an extended fuselage housing the LH2 tanks, with a small reduction in the required wing loading. Structural mass increases of the LH2 aircraft due to additional tanks and fuselage structure are mostly offset by fuel mass savings. While the fuel mass accounts for nearly 25% of the kerosene design’s Maximum Take-Off Mass (MTOM), this reduces to 10% for the LH2 design. The LH2 aircraft has 16% higher operating costs with emission levels reduced to 57–82% of the kerosene aircraft, depending on the LH2 production method. For static loads, the absence of fuel acting as bending moment relief in the wing results in an increase in wing structural mass. However, the inclusion of roll rate requirements causes large wing mass increases for both concepts, significantly outweighing dry wing penalties. Full article

New aerodynamic aircraft concepts enable the storage of volumetric liquid hydrogen (LH2). Additionally, the low temperatures of LH2 enable technologies such as the superconductivity of electrical fan drives and power distribution components. An increased power density of the onboard wiring harness and the electrical machine can be expected. The highest system efficiency and the smallest fuel and tank weight will be achieved with a highly efficient energy conversion by the fuel cell from LH2 to electrical energy. This publication shows a comprehensive study for cryogenic fan drives based on experimental-driven tape superconductor investigations, mission profile-based considerations, design analyses of superconducting electrical machines, and studies of the cooling concepts. A cryogenic system cannot be considered without a feasible cooling concept. Here, an approach with a safe He-based cooling system is proposed, using the LH2 flow to the fuel cell as a heat sink for the losses in the electrical system. Full article

This study investigates the dynamics of mass transfer between gas and liquid during the fuel scrubbing inerting process, utilizing a mixed inert gas (MIG) composed of CO₂, N₂, and trace amounts of O₂. The goal is to lower oxygen concentrations in aircraft fuel tanks, thereby reducing the risk of explosions. The experiments were conducted on a fuel scrubbing inerting platform, where an MIG was utilized to deoxygenate aviation fuel. Changes in the oxygen concentration in the ullage (OCU) and the dissolved oxygen concentration in the fuel (DOCF) were measured during the scrubbing process. Validated by these experimental data, Computational Fluid Dynamics (CFD) simulations demonstrated the reliability of the model. The discrepancies between CFD predictions and experimental measurements were 4.11% for OCU and 5.23% for DOCF. The influence of the MIG bubble diameter, MIG flow rate, and fuel loading rate on DOCF, gas holdup (GH), and the oxygen volumetric mass transfer coefficient (OVMTC) was comprehensively examined. The results reveal that larger MIG bubble diameters lead to an increased DOCF but reduced GH and OVMTC. In contrast, a higher MIG flow rate decreases DOCF while boosting GH and OVMTC. Additionally, a greater fuel loading rate increases DOCF but decreases GH and OVMTC. These findings offer important insights for optimizing fuel scrubbing inerting systems, underscoring the necessity of selecting suitable operating parameters to enhance oxygen displacement and ensure aircraft safety. Full article

Jet fuel in aircraft fuel tanks moves due to acceleration resulting from maneuvers. The movement mentioned here directly impacts the Center of Gravity (CG). The aircraft’s flight mechanics are significantly affected by the deviation of its CG on the aircraft body, and excessive deviation is undesirable. Preventing CG deviation is achieved by designing various baffles within the fuel tank. In this study, design details of the baffles were investigated with the help of an artificial neural network (ANN) model, 1D simulations, and computational fluid dynamics (CFD) calculations. The 1D simulations, which model the fuel movement, were used to understand the general behavior of the fluid in the tank. CFD calculations simulating turbulent fluid flow in three dimensions were used to confirm the results of the 1D simulations and provide more detailed information. A simulation set is created utilizing five parameters: barrier usage, volume fraction, cutout diameter, number of cutouts, and cutout location. Compared to the barrierless design, the barrier usage as a parameter changes either on baffle number 1, 3, and 6, or on baffle number 2, 4, and 7. The fuel volume fraction parameter accounts for 30%, 45%, and 60% of the interior volume. The diameters of the cutout holes vary between 30 mm and 156 mm and are used as categorized among the baffles. Cutout holes are applied on baffles in single, twin, and triplet forms and their locations are subjected to a divergence of either −20 mm or +20 mm from the z-axis. Based on these parameters, the maximum deviation and the retreat time of CG constitute the output parameters. The importance of the input parameters on the outputs was obtained with the help of an ANN algorithm created from the results of all possible combinations of a sufficient number of 1D simulations. To obtain more detailed results and confirm the importance of input parameters on outputs, selected cases were simulated with CFD. As a result of all analyses, it was revealed that barrier usage is the most dominant input parameter on CG deviation followed by volume fraction, cutout hole diameter, cutout divergence, and finally, the number of cutout holes. This study identifies the dominant input parameters to control fuel sloshing, specifically CG deviation and retreat time in the fuel tank, and proposes baffle designs to promote robust flight stability. Full article

In this work, we examine the possibility of converting a light propeller-driven aircraft, powered by a spark-ignition, reciprocating piston, and internal combustion engine running on AVGAS, into one powered by an electric motor driven by a proton exchange membrane fuel cell stack running on hydrogen. Our studies suggest that storing hydrogen cryogenically is a better option than storing hydrogen under pressure. In comparison to cryogenic tanks, high-pressure tanks are extremely heavy and unacceptable for light aircraft. We show that the modified aircraft (including batteries) is no heavier than the original, and that the layout of the major components results in lower movement of the aircraft center-of-gravity as the aircraft consumes hydrogen. However, we acknowledge that our fuel cell aircraft cannot store the same amount of energy as the original running on AVGAS. Therefore, despite the fact that the fuel cell stack is markedly more efficient than an internal combustion engine, there is a reduction in the range of the fuel cell aircraft. One of our most important findings is that the quantity of energy that we need to dissipate to the surroundings via heat transfer is significantly greater from a fuel cell stack than from an internal combustion engine. This is particularly the case when we attempt to run the fuel cell stack at high current densities. To control this problem, our strategy during the cruise phase is to run the fuel cell stack at its maximum efficiency, where the current density is low. We size the fuel cell stack to produce at least enough power for cruise, and when we require excess power, we add the energy stored in batteries to make up the difference. Full article

Aircraft failures can result in the leakage of fuel, hydraulic oil, or other lubricants onto the runway during landing or taxiing. Damage to fuel tanks or oil lines during hard landings or accidents can also contribute to these spills. Further, improper maintenance or operational errors may leave oil traces on the runway before take-off or after landing. Identifying oil spills in airport runway videos is crucial to flight safety and accident investigation. Advanced image processing techniques can overcome the limitations of conventional RGB-based detection, which struggles to differentiate between oil spills and sewage due to similar coloration; given that oil and sewage have distinct spectral absorption patterns, precise detection can be performed based on multispectral images. In this study, we developed a method for spectrally enhancing RGB images of oil spills on airport runways to generate HSI images, facilitating oil spill detection in conventional RGB imagery. To this end, we employed the MST++ spectral reconstruction network model to effectively reconstruct RGB images into multispectral images, yielding improved accuracy in oil detection compared with other models. Additionally, we utilized the Fast R-CNN oil spill detection model, resulting in a 5% increase in Intersection over Union (IOU) for HSI images. Moreover, compared with RGB images, this approach significantly enhanced detection accuracy and completeness by 25.3% and 26.5%, respectively. These findings clearly demonstrate the superior precision and accuracy of HSI images based on spectral reconstruction in oil spill detection compared with traditional RGB images. With the spectral reconstruction technique, we can effectively make use of the spectral information inherent in oil spills, thereby enhancing detection accuracy. Future research could delve deeper into optimization techniques and conduct extensive validation in real airport environments. In conclusion, this spectral reconstruction-based technique for detecting oil spills on airport runways offers a novel and efficient approach that upholds both efficacy and accuracy. Its wide-scale implementation in airport operations holds great potential for improving aviation safety and environmental protection. Full article

This paper proposes a performance analysis of a medium-range airliner powered by liquid hydrogen (LH₂) propulsion. The focus is on operating performance in terms of achievable payload and range. A non-conventional box-wing architecture was selected to maximize operating performance. An optimization-based multidisciplinary design framework was developed to retrofit a baseline medium-range box-wing aircraft by designing and integrating the fuel tanks needed to store the LH₂; several solutions were investigated for tank arrangement and layout by means of sensitivity analyses. As a main outcome, a performance analysis of the proposed LH₂-powered box-wing aircraft is provided, highlighting the impact of the introduction of this energy carrier (and the integration of the related tank systems) on aircraft operating performance; a comparative study with respect to a competitor LH₂-retrofitted tube-and-wing aircraft is also provided, to highlight the main possible operating differences between the two architectures. The findings reveal that the retrofitted box-wing can achieve long-range flights at the cost of a substantially reduced payload, mainly due to the volume limitations imposed by the installation of LH₂ tanks, or it can preserve payload capacity at the expense of a significant reduction in range, as the trade-off implies a reduction in on-board LH₂ mass. Specifically, the studied box-wing configuration can achieve a range of 7100 km transporting 150 passengers, or shorter ranges of 2300 km transporting 230 passengers. The competitor LH₂-retrofitted tube-and-wing aircraft, operating in the same category and compatible with the same airport apron constraints, could achieve a distance of 1500 km transporting 110 passengers. Full article

Fuel level gauging in aircraft presents a significant flight mechanics challenge due to the influence of aircraft movements on measurements. Moreover, it constitutes a multidimensional problem where various sensors distributed within the tank must converge to yield a precise and single measurement, independent of the aircraft’s attitude. Furthermore, fuel distribution across multiple tanks of irregular geometries complicates the readings even further. These issues critically impact safety and economy, as gauging errors may compromise flight security and lead to carrying excess weight. In response to these challenges, this research introduces a multi-stage project in aircraft fuel gauging systems, as a continuum of studies, where this first article presents a computational tool designed to simulate aircraft fuel sensor data readings as a function of fuel level, fuel tank geometry, sensor location, and aircraft attitude. Developed in an open-source environment, the tool aims to support the statistical inference required for accurate modeling in which synthetic data generation becomes a crucial component. A discretization procedure accurately maps fuel tank geometries and their mass properties. The tool, then, intersects these geometries with fuel-level planes and calculates each new volume. It integrates descriptive geometry to intersect these fuel planes with representative capacitive level-sensing probes and computes the sensor readings for the simulated flight conditions. The method is validated against geometries with analytical solutions. This process yields detailed fuel measurement responses for each sensor inside the tank, and for different analyzed fuel levels, providing insights into the sensors’ signals’ non-linear behavior at each analyzed aircraft attitude. The non-linear behavior is also influenced by the sensor saturation readings at 0 when above the fuel level and at 1 when submerged. The synthetic fuel sensor readings lay the baseline for a better understanding on how to compute the true fuel level from multiple sensor readings, and ultimately optimizing the amount of used sensors and their placement. The tool’s design offers significant improvements in aircraft fuel gauging accuracy, directly impacting aerostructures and instrumentation, and it is a key aspect of flight safety, fuel management, and navigation in aerospace technology. Full article

To reduce aviation’s climatic impact, there are international, regional and national policies in place and under development. The most firm policy measure to reduce net CO₂ emissions from aviation is ReFuelEU Aviation, requiring 70% of fuel tanked in the EU to be net CO₂-free in 2050. Considering the technological options available, expected improvements in airline operational efficiency and aircraft efficiency, as well as considering behavioral factors that influence aviation travel demand, a path for the complete decarbonization of the Dutch aviation market is provided. The path implies increasing the share of CO₂-free energy carriers to 100% in 2050 for all departing and arriving flights. Methodologically, first, the aggregate ticket price increase as a result of this policy is estimated. Second, demand price elasticity factors are applied to the price increase to estimate the impact of complete decarbonization on the number of passengers carried by the Dutch aviation sector in 2050. The findings outline that a shift to exclusively CO₂-free energy carriers will result in a 15% reduction in the number of passengers in 2050 compared to the market development under ReFuelEU Aviation obligations. The Dutch aviation sector will still grow from 81 million passengers in 2019 to between 98 and 138 million in 2050, but the growth rate will be significantly lower than before 2019. The expected sustainable energy requirements will be 171 PJ per year in 2050, with a likely range between 146 and 206 PJ, representing no substantial change from the 2019 level of 166 PJ. Full article

Inert gas distribution has a great influence on the inerting effect, especially for the multiple-bay fuel tank. In order to find out the optimal scheme, an optimization method based on the entropy-weight improvement TOPSIS method is proposed, and an experimental system of inert gas distribution is established to measure the speed index and uniformity index. The results show that the position of the inlet and outlet has a significant effect on the overall inerting effect. The inerting scheme designed by the entropy-weight improvement TOPSIS method can not only reduce the flow demand of inert gas but also make the oxygen distribution more uniform. The optimization inerting scheme of the Boeing 747 aircraft has improved the average speed index by 3.01% and the average uniformity index by 26.18%. The smoke visualization experiment also showed that the scheme designed by the entropy-weight improvement TOPSIS method has the denser white smoke, which means that the scheme has better performance. Full article
