Radar forward-looking imaging is critical in many civil and military fields, such as aircraft landing, autonomous driving, and geological exploration. Although the super-resolution forward-looking imaging algorithm based on spectral estimation has the potential to discriminate multiple targets within the same beam, the estimation of the angle and magnitude of the targets are not accurate due to the influence of sidelobe leakage. This paper proposes a multi-channel super-resolution forward-looking imaging algorithm based on the improved Fast Iterative Interpolated Beamforming (FIIB) algorithm to solve the problem. First, the number of targets and the coarse estimates of angle and magnitude are obtained from the iterative adaptive approach (IAA). Then, the accurate estimates of angle and magnitude are achieved by the strategy of iterative interpolation and leakage subtraction in FIIB. Finally, a high-resolution forward-looking image is obtained through non-coherent accumulation. The simulation results of point targets and scenes show that the proposed algorithm can distinguish multiple targets in the same beam, effectively improve the azimuthal resolution of forward-looking imaging, and attain the accurate reconstruction of point targets and the contour reconstruction of extended targets. Full article

Plagued by heterogeneous clutter, it is a serious challenge for airborne radars to detect low-altitude, weak targets. To overcome this problem, a novel matrix information geometry detector for airborne multi-channel radar is proposed in this paper. The proposed detector applies the given steering vector and array structure information to the matrix information geometry detection method so that it can be used for space–time adaptive detection. While improving the detection performance, the matrix information geometry detector’s original anti-clutter advantage is enhanced as well. The simulation experiment results indicate that the proposed detector has advantages in several of the properties related to space–time adaptive detection, while its computational complexity does not increase significantly. Moreover, experiment results based on the measured data verify the superior performance of the proposed method. Sea-detecting data-sharing-program data, mountaintop data, and phased-array radar data are employed to verify the performance advantage of the proposed method in heterogeneous clutter and the ability for weak target detection. Full article

Tomographic synthetic aperture radar (TomoSAR) obtains elevation resolution by adding multiple baselines successively in the direction perpendicular to the line of sight, thereby realizing three-dimensional (3D) reconstruction of complex scenes and significantly promoting the development of the 3D application field. However, a large data redundancy and long mapping time in traditional 3D imaging lead to a large data transmission burden, low efficiency, and high costs. To solve the above problems, this paper proposes a distributed SAR high-resolution and wide-swath (HRWS) 3D imaging technology scheme. The proposed scheme overcomes the size limitation of traditional single-satellite antennas through the multi-channel arrangement of multiple satellites in the elevation direction to achieve HRWS imaging; meanwhile, the distributed SAR system is integrated with tomographic processing technology to realize 3D imaging of difficult areas by using the elevation directional resolution of TomoSAR systems. HRWS 3D SAR increases the baseline length and channel number by transmission in turn, which leads to excessive pulse repetition frequency and causes echoes of different pulse signals to overlap in the same receiving cycle, resulting in range ambiguity and thus seriously affecting the quality of the 3D reconstruction. To solve this problem, this paper proposes a range ambiguity resolution algorithm based on multi-beam forming and verifies it on the measured data from airborne array SAR. Compared with the traditional TomoSAR, the distributed HRWS 3D SAR scheme proposed in this paper can obtain a greater mapping bandwidth with the same resolution in a single flight, thereby enhancing the time correlation, reducing data redundancy, and greatly improving mapping efficiency. Full article

Airborne array tomographic synthetic aperture radar (TomoSAR) can acquire three-dimensional (3D) information of the observed scene in a single pass. In the process of airborne array TomoSAR data imaging, due to the disturbance of factors such as inconsistent antenna patterns and baseline errors, there are spatially varying amplitude-phase inconsistency errors in the multi-channel Single-Look-Complex (SLC) images. The existence of the errors degrades the quality of the 3D imaging results, which suffer from positioning errors, stray points, and spurious targets. In this paper, a new calibration method based on multiple prominent points is proposed to calibrate the errors of amplitude-phase inconsistency. Firstly, the prominent points are selected from the multi-channel SLC data. Then, the subspace decomposition method and maximum interference spectrum method are used to extract the multi-channel amplitude-phase inconsistency information at each point. The last step is to fit the varying curve and to compensate for the errors. The performance of the method is verified using actual data. The experimental results show that compared with the traditional fixed amplitude-phase inconsistency calibration method, the proposed method can effectively calibrate spatially varying amplitude-phase inconsistency errors, thus improving on the accuracy of 3D reconstruction results for large-scale scenes. Full article

Airborne array synthetic aperture radar (SAR) has made a significant breakthrough in the three-dimensional resolution of traditional SAR. In the airborne array SAR 3D imaging technology, the baseline length is the main factor restricting the resolution. Airborne array flexible SAR can increase the baseline length to improve the resolution and interference performance by mounting antennae on the wing. The existing research lacks results obtained using flexible actual data processing and specific motion compensation methods. Thus, this paper proposes a motion error estimation and compensation method for an airborne array flexible SAR based on a multi-channel interferometric phase. Firstly, a flexible channel motion compensation model is established based on the multi-channel interference phase of airborne array flexible SAR. Then, based on the rigid multi-channel data, combined with the ground control points, the least square method, and the global optimal search algorithm, the accurate rigid baseline length and the central incidence angle are obtained. Finally, according to the multi-channel interference phase inversion of the flexible motion error and combined with the motion compensation model, the flexible data are compensated in the time domain. The actual results indicate that, compared with traditional motion compensation methods, our method can obtain accurate flexible compensation data. This study improves the interference performance of multi-channel data of airborne array flexible SAR and lays a solid foundation for the high-precision 3D reconstruction of airborne array flexible SAR. Full article

The work is devoted to solving current scientific and applied problems of the development of radar imaging methods. These developments are based on statistical theory of optimal signal processing. These developments allow researchers to create coherent high-resolution information-enriched images as well as incoherent images. These methods can be practically applied in multichannel aerospace radars through the proposed programs and algorithms. Firstly, the following models of stochastic signals at the output of multichannel registration regions of scattered electro-magnetic fields, internal noise, and observation equations are developed and their statistical characteristics investigated. For the considered models of observation equations, the likelihood functional is defined. This definition is an important stage in optimizing spatial and temporal signal processing. These signals are distorted by internal receiver noises in radar systems. Secondly, by synthesising and analysing methods of measuring a radar cross section, the problem of incoherent imaging by aerospace radars with planar antenna array is solved. Thirdly, the obtained optimal mathematical operations are physically interpreted. The proposed interpretation helps to implement a quasi-optimal algorithm of radar cross section estimation in aerospace radar systems. Finally, to verify the proposed theory, a semi-natural experiment of real radio holograms processing was performed. These radio holograms are digital recordings of spatial and temporal signals by an airborne synthetic aperture radar (SAR) system. The results of the semi-natural experiment are presented and analysed in the paper. All the calculations, developments and results in this paper can be applied to new developments in areas such as remote sensing or non-destructive testing. Full article

In order to study the space-time characteristics of sea clutter, the sea clutter is always measured by the airborne multichannel radar; however, the sea clutter shows the heterogeneity between range gates, which means the space-time covariance matrix’s correspondence to the single range gate cannot be estimated accurately. Meanwhile, the measurement of the sea clutter data by the airborne radar is usually affected by the motion of the platform, which makes the analysis results unrepresentative of the space-time characteristics of the pure sea clutter. In this paper, a sea clutter measurement method based on L-band shore-based multichannel radar is proposed, where the transmit sub-array periodically moves with the pulse repetition period to obtain multiple sets of coherent processing interval pulses for each range gate. This measurement method can exclude the influences of the moving platform. Moreover, a sea clutter space-time signal model of the single range gate is proposed, and the model is used to simulate three-dimensional sea clutter data with space-time coupling characteristics. With verification of the measured and simulated data, it can be seen that the data composed of single range gate and multiple coherent processing interval pulses can accurately estimate the space-time covariance matrix corresponding to this single range gate. Furthermore, the space-time characteristics are analyzed based on the measured data. The results show that the eigenvalue spectrum and the spread width of space-time power spectrum are influenced by the backscattering coefficient of sea clutter and the speed of sea surface motion. In comparison, the decorrelation effect caused by the backscattering coefficient of sea clutter is stronger than that caused by the speed of the surface motion. The proposed method is helpful for guiding multichannel sea clutter measurement and the analysis results are of great significance to the clutter suppression algorithms of the marine multichannel radar. Full article

Ground moving targets with slow velocity and low radar cross-section (RCS) are usually embedded in the clutter Doppler spectrum. To achieve the detection and estimation of such targets, a novel method operating in the range-Doppler domain is developed for airborne multichannel radar systems. The interferometric phases that are sensitive to moving targets are obtained by coherent difference processing (CDP) for target detection. Moreover, the amplitude is utilized as complementary information to improve the detection performance. Then, a matched filter bank is designed and applied to the CDP processed data to complete the parameter estimation. The proposed method provides the benefits of high efficiency and robustness, since it does not involve matrix inversion, and it does not require homogeneous clutter assumption unlike adaptive algorithms. Experiments on real data acquired by an airborne X-band four-channel radar system demonstrate its effectiveness. Full article

Airborne array tomographic synthetic aperture radar (TomoSAR) is a major breakthrough, which can obtain three-dimensional (3D) information of layover scenes in a single pass. As a high-resolution SAR, airborne array TomoSAR has considerable potential for 3D applications. However, the original TomoSAR elevation resolution is limited by the baseline and platform length. In this study, a novel method for enhancing the elevation resolution is proposed. First, the actual curve trajectory observation model of airborne array TomoSAR is established. Subsequently, multi-channel image data are substituted into the model to obtain the observation equation. Furthermore, the azimuth and elevation directions of the two-dimensional observation scene are modeled uniformly. The scene reconstruction is realized through the two-dimensional joint solution. Finally, the observation equation is sparsely solved according to the sparse distribution characteristics of the target to obtain the image. The performance of the proposed method is verified via simulation and real-data experiments. The experimental results indicate that, compared with the traditional elevation resolution enhancement method, the proposed method improves the elevation resolution by two times. The proposed method also provides a new thinking for high-resolution SAR 3D imaging. Full article

This article presents the hardware implementation and a behavioral model-based RF system modeling and simulation (M&S) study of compressive sensing (CS) based 2D angle-of-arrival (AoA) measurement system for 2–18 GHz radar electronic support measures (RESM). A 6-channel ultra-wideband RF digital receiver was first developed using a PXIe-based multi-channel digital receiver paired with a 6-element random-spaced 2D cavity-backed-spiral-antenna array. Then the system was tested in an open lab environment. The measurement results showed that the system can measure AoA of impinging signals from 2–18 (GHz) with overall RMSE of estimation at 3.60, 2.74, 1.16, 0.67 and 0.56 (deg) in L, S, C, X and Ku bands, respectively. After that, using the RF high-fidelity M&S (RF HF-M&S) approach, a 6-channel AoA measurement system behavioral model was also developed and studied using a radar electronic warfare (REW) engagement scenario. The simulation result showed that the airborne AoA measurement system could successfully measure an S-band ground-based target acquisition radar signal in the dynamic REW environment. Using the RF HF-M&S model, the applicability of the system in other frequencies within 2–18 (GHz) was also studied. The simulation results demonstrated that the airborne AoA measurement system can be used for 2–18 GHz RESM applications. Full article

The post-Doppler adaptive matched filter (PD-AMF) with constant false alarm rate (CFAR) property was developed for adaptive detection of moving targets, which is a standardized version of the post-Doppler space–time adaptive processing (PD-STAP) in practical applications. However, its detection performance is severely constrained by the training data, especially in a dense signal environment. Improper training data and contamination of moving target signals remarkably degrade the performance of disturbance suppression and result in target cancellation by self-whitening. To address these issues, a novel post-Doppler parametric adaptive matched filter (PD-PAMF) detector is proposed in the range-Doppler domain. Specifically, the detector is introduced via the post-Doppler matched filter (PD-MF) and the lower-diagonal-upper (LDU) decomposition of the disturbance covariance matrix, and the disturbance signals of the spatial sequence are modelled as an auto-regressive (AR) process for filtering. The purpose of detecting ground moving targets as well as for estimating their geographical positions and line-of-sight velocities is achieved when the disturbance is suppressed. The PD-PAMF is able to reach higher performances by using only a smaller training data size. More importantly, it is tolerant to moving target signals contained in the training data. The PD-PAMF also has a lower computational complexity. Numerical results are presented to demonstrate the effectiveness of the proposed detector. Full article

Synthetic Aperture Radar (SAR) is an established remote sensing technique that can robustly provide high-resolution imagery of the Earth’s surface. However, current space-borne SAR systems are limited, as a matter of principle, in achieving high azimuth resolution and a large swath width at the same time. Digital beamforming (DBF) has been identified as a key technology for resolving this limitation and provides various other advantages, such as an improved signal-to-noise ratio (SNR) or the adaptive suppression of radio interference (RFI). Airborne SAR sensors with digital beamforming capabilities are essential tools to research and validate this important technology for later implementation on a satellite. Currently, the Microwaves and Radar Institute of the German Aerospace Center (DLR) is developing a new advanced high-resolution airborne SAR system with digital beamforming capabilities, the so-called DBFSAR, which is planned to supplement its operational F-SAR system in near future. It is operating at X-band and features 12 simultaneous receive and 4 sequential transmit channels with 1.8 GHz bandwidth each, flexible DBF antenna setups and is equipped with a high-precision navigation and positioning unit. This paper aims to present the DBFSAR sensor development, including its radar front-end, its digital back-end, the foreseen DBF antenna configuration and the intended calibration strategy. To analyse the status, performance, and calibration quality of the DBFSAR system, this paper also includes some first in-flight results in interferometric and multi-channel marine configurations. They demonstrate the excellent performance of the DBFSAR system during its first flight campaigns. Full article

In a multichannel geosynchronous spaceborne–airborne bistatic synthetic aperture radar (GEO-SA-BiSAR) system, the airborne receiver can obtain high-resolution microwave images with good signal-to-noise ratios (SNRs) by passively receiving echoes from the desired area. Since the Doppler modulation and range history of a moving target are obviously different from a stationary target, a signal geometry model for moving targets in multichannel GEO-SA-BiSAR is established in this paper. According to simulation results, the along track velocity introduces target defocusing in azimuth, and the slant range velocity mainly causes multiple false targets. To resolve these problems, a modified multichannel reconstruction method in azimuth channel GEO-SA-BiSAR is proposed according to the azimuth multichannel impulse response of the imaged moving target. Before azimuth multichannel raw data combination, both spatial-variant range cell migration correction (RCMC) and azimuth nonlinear chirp scaling (ANLCS) should be performed to reduce the influence of the range offset and lower the Doppler bandwidth of the whole raw data, respectively. Afterward, a novel azimuth multichannel reconstruction algorithm is carried out via the modified reconstruction matrix based on the estimated target velocity. The target slant range velocity estimation is implemented by introducing the signal intensity ratio (SIR). Compared with the conventional method for the stationary target to handle the raw data of the moving target, the false targets could be obviously suppressed by using the proposed approach. Imaging results on both simulated point and distributed scene targets validate the proposed multichannel reconstruction approach. Full article

This study takes on the challenge of resolving upper ocean surface currents with a suite of airborne remote sensing methodologies, simultaneously imaging the ocean surface in visible, infrared, and microwave bands. A series of flights were conducted over an air-sea interaction supersite established 63 km offshore by a large multi-platform CASPER-East experiment. The supersite was equipped with a range of in situ instruments resolving air-sea interface and underwater properties, of which a bottom-mounted acoustic Doppler current profiler was used extensively in this paper for the purposes of airborne current retrieval validation and interpretation. A series of water-tracing dye releases took place in coordination with aircraft overpasses, enabling dye plume velocimetry over 100 m to 10 km spatial scales. Similar scales were resolved by a Multichannel Synthetic Aperture Radar, which resolved a swath of instantaneous surface velocities (wave and current) with 10 m resolution and 5 cm/s accuracy. Details of the skin temperature variability imprinted by the upper ocean turbulence were revealed in 1–14,000 m range of spatial scales by a mid-wave infrared camera. Combined, these methodologies provide a unique insight into the complex spatial structure of the upper ocean turbulence on a previously under-resolved range of spatial scales from meters to kilometers. However, much attention in this paper is dedicated to quantifying and understanding uncertainties and ambiguities associated with these remote sensing methodologies, especially regarding the smallest resolvable turbulent scales and reference depths of retrieved currents. Full article

Synthetic aperture radar (SAR) equipped on the hypersonic air vehicle in near space has many advantages over the conventional airborne SAR. However, its high-speed maneuvering characteristics with curved trajectory result in serious range migration, and exacerbate the contradiction between the high resolution and wide swath. To solve this problem, this paper establishes the imaging geometrical model matched with the flight trajectory of the hypersonic platform and the multichannel azimuth sampling model based on the displaced phase center antenna (DPCA) technology. Furthermore, based on the multichannel signal reconstruction theory, a more efficient spectrum reconstruction model using discrete Fourier transform is proposed to obtain the azimuth uniform sampling data. Due to the high complexity of the slant range model, it is difficult to deduce the processing algorithm for SAR imaging. Thus, an approximate range model is derived based on the minimax criterion, and the optimal second-order approximate coefficients of cosine function are obtained using the two-population coevolutionary algorithm. On this basis, aiming at the problem that the traditional Omega-K algorithm cannot compensate the residual phase with the difficulty of Stolt mapping along the range frequency axis, this paper proposes an Exact Transfer Function (ETF) algorithm for SAR imaging, and presents a method of range division to achieve wide swath imaging. Simulation results verify the effectiveness of the ETF imaging algorithm. Full article
