Search Results (27)

Continuous population growth will lead to further expansion and densification of urban environments. In this context, Urban Air Mobility (UAM) has emerged as a new transportation solution through the use of Vertical Take-Off and Landing (VTOL) aircraft, more precisely, configurations such as lift-plus-cruise tilt-rotors. During the conceptual design phase, propeller design methodologies commonly reported in the literature rely on vortex-based approaches or actuator disk theory. However, the accuracy of these methods strongly depends on the inflow angle and operating conditions. This paper introduces an analytical model to predict propeller thrust at a 90° inflow angle (edgewise flight), based on a correction of the thrust under axial flight conditions and the propeller geometry evaluated at 75% span. The approach relies on local velocity and angle of attack estimations derived from classical Blade Element Momentum Theory (BEMT) with an additional correction to account for stall effects at high angles of attack. This capability is particularly relevant for modeling lift-plus-cruise tilt-rotor configurations cruise phase during early design stages while maintaining minimal computational cost. The proposed model is validated against wind tunnel measurements for several propellers tested at different global pitch angles, varying from 0 m/s to 9.1 m/s of windspeed and 1300 to 6200 rpms, demonstrating the applicability of the developed formulation for blades with twist angles up to 16°. Full article

This study examines the performance variations and flow field characteristics of a submerged water-jet propulsor under complex oblique sailing conditions, providing theoretical insights for propulsor design optimization and ship maneuverability improvement. Both steady and unsteady numerical simulations were performed, with the unsteady analysis employing an actuator disk model. The results indicate that at a positive drift angle of 30°, the propulsor head decreases by approximately 6%, whereas at a negative drift angle of 30°, it drops significantly by 28%. The entropy generation distribution among the propulsor components was analyzed based on entropy generation theory, revealing that turbulent dissipation contributes the largest portion (64%) of the total entropy generation, with the impeller flow passage accounting for 47%. Furthermore, pressure fluctuations on the propulsor housing surface were evaluated under unsteady conditions. The findings show that a twin-jet configuration with an optimal spacing of 1.6D effectively minimizes flow field interference during maneuvering. Overall, the study provides a theoretical foundation for enhancing the design and hydrodynamic performance of submerged water-jet propulsion systems. Full article

Although the hub blockage effect is generally disregarded for large-sized horizontal axis wind machines, it can significantly affect the performance of small-sized turbines whose ratio between the hub and rotor radii can attain values up to 25–30%. This article proposes a generalisation of the Blade-Element/Momentum Theory (BE/M-T), accounting for the effects of the hub presence on the rotor performance. The new procedure relies on the quantitative evaluation of the radial distribution of the axial velocity induced by the hub all along the blade span. It is assumed that this velocity is scarcely influenced by the magnitude and type of the rotor load, and it is evaluated using a classical CFD approach applied to the bare hub. The validity and accuracy of the modified BE/M-T model are tested by comparing its results with those of a more advanced CFD-actuator-disk (CFD-AD) approach, which naturally and duly takes into account the hub blockage, the rotor presence, an and the wake divergence and rotation, and the results are validated against experimental data. The comparison shows that the correction for the hub blockage effects in the BE/M-T model significantly reduces the differences with the results of the reference method (CFD-AD) both in terms of global (power coefficient) and local (thrust and torque per unit length) quantities. Full article

Distributed electric propulsion has emerged as a prominent research area in aerospace engineering. The capabilities of shorter takeoff distance and efficient cruise flight are the important advantages of a distributed propulsion UAV over a traditional fixed-wing UAV, and the composition of multiple motors can significantly improve the safety of the aircraft. This paper proposed an overall design method for the power system of the distributed propulsion UAV with the mission requirements as inputs, using the Actuator Disk Theory and Vortex Lattice Method to analyze the aerodynamic performance corresponding to different propeller numbers and layouts, and combining with the BP neural network to obtain the optimal propeller position. Meanwhile, the Linear Quadratic Regulator method was employed to analyze different configurations of UAVs, and the effects of the number of propellers and thrust redundancy on their safety were explored. The parametric study revealed that as the number of propellers increased, the optimal horizontal distance between the propeller and the leading edge of the wing gradually decreased (closer to the wing), and the vertical distance also gradually decreased (lower to the wing). The safety study revealed that when the number of propellers reached eight or more, the UAV could maintain stable flight with a probability exceeding 70% even when two or three propulsion components fail. The computational method and safety analysis for different propeller combinations studied in this paper feature high efficiency and low computational consumption, which can provide an effective reference for the overall design phase of distributed propulsion aircraft. Full article

This paper presents a bio-inspired rigid–flexible continuum robot driven by flexible shaft tension–torsion synergy, tackling the trade-off between actuation complexity and flexibility in continuum robots. Inspired by the muscular arrangement of octopus arms, enabling versatile multi-degree-of-freedom (DoF) movements, the robot achieves 6-DoF motion and 1-DoF gripper opening and closing movement with only six flexible shafts, simplifying actuation while boosting dexterity. A comprehensive kinetostatic model, grounded in Cosserat rod theory, is developed; this model explicitly incorporates the coupling between the spinal rods and flexible shafts, the distributed gravitational effects of spacer disks, and friction within the guide tubes. Experimental validation using a physical prototype reveals that accounting for spacer disk gravity diminishes the maximum shape prediction error from 20.56% to 0.60% relative to the robot’s total length. Furthermore, shape perception experiments under no-load and 200 g load conditions show average errors of less than 2.01% and 2.61%, respectively. Performance assessments of the distal rigid joint showcased significant dexterity, including a 53° grasping range, 360° continuous rotation, and a pitching range from −40° to +45°. Successful obstacle avoidance and long-distance target reaching experiments further demonstrate the robot’s effectiveness, highlighting its potential for applications in medical and industrial fields. Full article

In the research field of rotorcraft aerodynamics, there are two fundamental challenges: resolving the complex vortex structures in rotor wakes and representing the moving rotor blades in the ambient airflow. In this paper, we address the first challenge by utilizing a third-order unstructured finite volume solver, which exhibits lower numerical dissipation than its second-order counterpart. This allows for sufficient resolution of small vortex structures on relatively coarse meshes. With this flow solver, the second challenge is addressed by modeling each rotor as an actuator disk (i.e., the actuator disk model (ADM)) or modeling each blade as an actuator line (i.e., the actuator line model (ALM)). Both of the two models are equipped with an improved tip loss correction, which is introduced in detail in the methodology section. In the section of numerical experiments, the numerical convergence properties of the two types of solvers have been compared in the case of two-dimensional infinite wing. In addition, the relationship between the ALM and the lifting line theory is discussed in the cases of fixed-wing calculations. Another goal of these cases is to validate the tip loss correction presented. The validation of the ALM/ADM and comparisons of computational efficiency are also demonstrated in simulations involving both hover and forward flight rotors. It was found that the combination of the third-order finite volume solver and the ALM/ADM with the improved tip loss correction presents an efficient way of performing the aerodynamic analysis of rotor-induced downwash flow. Full article

Tidal stream turbines (TST) are a promising option for electricity generation to meet the ever-increasing demand for energy. The actuator disk (AD) method is often employed to represent a TST, to evaluate the TST operating in a tidal flow. While this method can effectively reduce the computational cost and provide accurate prediction of far-wake flow conditions, it falls short of fully characterising critical hydrodynamics elements. To address this limitation, a hybrid method is implemented by coupling AD with the blade element momentum (BEM) theory, using detailed performance data, such as thrust, to enhance the prediction of the wake effects. This work focuses on the development of a hybrid BEM–AD method using Reynolds-Averaged Navier–Stokes (RANS) turbulence models within computational fluid dynamics (CFD). Two variations and a hybrid modification of an AD model are presented in this paper. The first modified variation is a velocity variation that takes into account velocity profile inflow into the disk’s configuration. The second modified variation is a radial variation that integrates the blade element theory into the disk’s configuration. The hybrid modified model combines both the velocity profiles influenced and blade element theory in the design and analysis of the actuator disk. Several key investigations on some of the pre-solver parameters are also investigated in this research such as the effect of changing velocity and radial distance on the porosity and loss coefficient of the actuator disk performance. Importantly, this work provides an improved method to evaluate the key wake effects from a TST array which is crucial to determine the power performance of the TST array. Full article

Current performance analysis processes for drag-dominant tidal turbines are unsuitable as disk actuator theory lacks support for varying swept blockage area, bypass flow downstream interaction, and parasitic rotor drag, whereas blade element momentum theory is computably effective for three-blade lift-dominated aerofoil. This study proposes a novel technique to calculate the optimal turbine tip speed ratio (TSR) with a cost-effective and user-friendly moment balancing algorithm. A reliable dynamic TSR matrix was developed with varying rotational speeds and fluid velocities, unlike previous works simulated at a fixed fluid velocity. Thrust and idle moments are introduced as functions of inlet fluid velocity and rotational speed, respectively. The quadratic relationships are verified through regression analysis, and net moment equations are established. Rotational speed was a reliable predictor for Pinwheel’s idle moment, while inlet velocity was a reliable predictor for thrust moment for both models. The optimal (C_p, TSR) values for Pinwheel and Savonius turbines were (0.223, 2.37) and (0.63, 0.29), respectively, within an acceptable error range for experimental validation. This study aims to improve prevailing industry practices by enhancing an engineer’s understanding of optimal blade design by adjusting the rotor speed to suit the inlet flow case compared to ‘trial and error’ with cost-intensive simulations. Full article

A novel actuator disk model (ADM) coupled with lifting-line theory is proposed in this paper. Several virtual planform blades are placed on a disk plane with a constant azimuthal interval, and the lifting-line theory is applied to each blade to predict the effective angle of attack. The proposed model considers the local lift and drag forces acting on disk surface cells by interpolating the predicted effective angle of attack with various azimuth angles to the actuator disk plane; therefore, the proposed model considers individual blade tip vortices without tip loss functions. Experimental data for hover and forward flight rotors are used to validate the proposed model. For hovering flight, sectional thrust based on collective pitch angles predicted by the modified ADM was similar to that obtained in the experiments. For forward flight, the inflow above the rotor estimated by the proposed ADM was similar to that obtained in the experiments and by using other numerical methods. Thus, the developed ADM can be used for rotor performance analysis under the main flight conditions of V/STOL. Full article

The interaction between the slipstream of the propellers and the wing of an aircraft with distributed electric propulsion (DEP) could benefit aerodynamics. A conceptual design and optimization are carried out in order to increase the range of an electric general aviation aircraft without affecting its takeoff and landing velocity in the same fuselage condition. Propellers are modelled using the actuator disk (AD) theory, and the aircraft is modelled using the vortex lattice method (VLM) to obtain DEP aircraft’s aerodynamics in conceptual design. The DIRECT method is used for global optimization. To concentrate on the layout of the propellers and wing, a propeller with the same chord distribution, twist distribution, and number of blades is selected. The design and optimization of DEP aircraft’s range is carried out with the objective of achieving the maximum product of the lift–drag ratio with propeller efficiency under force balance constrains. Additionally, to decrease the takeoff and landing distance, the DEP aircraft’s takeoff and landing performance are optimized with the objective of the smallest velocity at an angle near the tail down angle under the constrains of acceleration bigger than 0 and a Mach number at the tip of blades smaller than 0.7. The CFD simulation was used to confirm the DEP aircraft’s pretty accurate aerodynamics. Compared to the reference aircraft, the improved DEP aircraft with 10 high-lift propellers on the leading edge of the wing and 2 wing-tip propellers may boost cruise performance by 6% while maintaining takeoff and landing velocity. Furthermore, it has been shown that the stall speed of DEP aircraft with smaller wings would rise proportionally when compared to conventional design aircraft, and the power need of DEP aircraft will be increased as a result of the operation of high-lift propellers. The conceptual design and optimal approach suggested in this work has some reference value for the design and research of the fixed-wing DEP general aviation aircraft. Full article

The efficiency increase that distributed propulsion could deliver for future hybrid-electric aircraft is in line with the urgent demand for higher aerodynamic performances and a lower environmental impact. Several consolidated proprietary tools (not always available) are developed worldwide for distributed propulsion simulation. Therefore, prediction and comparisons of propeller performances, with computational fluid dynamic codes featuring different implementation of solvers, numerical schemes, and turbulence models, is of interest to a wider audience of research end-users. In this framework, the paper presents a cross-comparison study among different CFD solvers, the SU2 Multiphysics Simulation and Design Software, the CIRA proprietary flow solver UZEN, and the commercial ANSYS-FLUENT code, for the simulation of a wing section with a tractor propeller at different flow attitudes. The propeller is modelled as an actuator disk according to the general momentum theory and is accounted for in the flow solvers as a boundary condition, for the momentum and energy equations. In this study, a propeller with a fixed advance ratio $J=0.63$ is considered, while propeller performances are assumed variable along with the radius. To perform the comparisons among the solvers, an in-house procedure, which provides the input thrust and torque distributions in a unified format among the three solvers, is developed. Steady RANS simulations are performed at $R{e}_{\infty }=1.7\times {10}^6$ and $M_{\infty }=0.11$, for the flowfield of an isolated propeller. Successively, a wing section with a fixed forward-mounted propeller configuration with no nacelle, is studied at $\alpha =0^{\circ },4^{\circ },$ and $8^{\circ }$ angles of attack. The comparisons in terms of the lift coefficient show a good agreement among the three flow solvers both in power-off and power-on conditions. Simulations also evidenced the strong stability preserving property of upwind schemes, applied to propeller simulation at low-Mach number. Some discrepancies in the drag coefficient are observed and related to different levels of numerical diffusion between the three codes, which affects the downstream wake. Differences in flow properties in near disk region are observed and explained considering the different hub implementations. Full article

An accurate choice of the inflow parameters has been shown to affect the CFD results significantly. In this study, the actuator disk method (AD) is used to investigate the effects of the widely used inflow formulations, the logarithmic and power-law formulations, in the neutral atmospheric boundary layer simulations. Based on the one-dimensional momentum theory, the AD model is a rapid method that replaces the turbine with a permeable disk and is among the most used methods in the literature. The results of the k-$\omega$ AD simulation indicated that in spite of the logarithmic method’s widespread use, the power law formulation gives a better description of the velocity field. Furthermore, an actuator disk thickness study also showed that given the effect of actuator disk thickness on the rate of convergence, more attention should be dedicated towards finding a suitable disk thickness value. The combination of an optimized mesh and a suitable choice of AD thickness can help with the rate of convergence which in turn shortens the simulation’s run time. Full article

This paper started with the explanation of the conditions for using the momentum equation and with the presentation of the actuator disc theory. Focusing on the flow model used in actuator disk theory, both the Froude-Rankine theorem and Betz’s law have been examined. It has been found that the Froude-Rankine theorem is not justified because a stream-tube that is used as the control volume does not really exist (pseudo stream-tube). The theorem is also not justified because an unfounded velocity (v₂) is used to connect the thrust of the actuator disc with the total power loss. Two flaws have been identified in Betz’s law. First, the use of both the unjustified Froude-Rankine theorem and the incorrect flow model totally violates the condition of determining the thrust of the actuator disc using the momentum equation. Second, the unfounded velocity (v₂) from the Froude-Rankine theorem is misinterpreted and used for the volumetric flow rate through the actuator disc. These two main flaws lead to diverse computational contradictions and paradoxes, particularly when considering the case of an impermeable circular disc. The flaws in Betz’s law become evident when the law is applied to a rectangular actuator plate of infinite length. The possible solution for the actuator disc flow has been presented. This includes the additional consideration of energy dissipation in the flow downstream of the actuator disc, similar to the method used to calculate the Borda-Carnot shock loss. Full article

Currently, the actuator disk theory (ADT) and the rotating annular stream-tube theory (RAST), both of which predicate on the axial momentum and generalized momentum theories, among others, are commonly used in investigating the aerodynamic characteristics of horizontal axis wind turbines (HAWTs). These theories, which are based on a rotor with an infinite number of blades, typically do not properly capture the flow physics of wind blowing past the rotors of HAWTs. A vortex ring theory (VRT) that analyzes HAWTs based solely on the characteristics of fluids flowing past obstructions is proposed. The VRT is not predicated on the assertion that the induced velocity in the wake is twice the induced velocity at the rotor. On the contrary, it splits the axial induction factor in the wake into two components, namely, the induction or interference factor due to the solidity of the rotor and the induction factor due to the wake of the rotor a_w; a_w and its azimuthal counterpart are determined using the Biot–Savart law. The pressure differences across the rotor segments of a HAWT are derived from the Bernoulli equation for all the three theories. Blade segment/local areas based on the blade sectional geometry of the rotor are used in the case of the VRT to estimate the local forces. All the calculations in this study are based on the design parameters of the 5 MW National Renewable Energy Laboratory’s reference offshore wind turbine. Pressure differences are plotted as functions of local radii using the calculated axial and azimuthal induction factors for each theory. The local power coefficient is plotted as a function of the local tip-speed ratio, while the local thrust coefficient is plotted as a function of the local radii for all the three theories. There is piece-wise agreement between the VRT, the ADT, the RAST and numerical and experimental data available in the literature. Full article

The proper evaluation of the Rudder–Propeller interactions is mandatory to correctly predict the manoeuvring capability of a modern ship, in particular considering the commonly adopted ship layout (rudder often works in the propeller slipstream). Modern Computational Fluid Dynamics (CFD) solvers can provide, not only the performance of the whole system but also an insight into the flow problem. In the present paper, an open-source viscous flow solver has been validated against available literature experimental measurements in different conditions. After an extensive analysis of the numerical influence of the mesh arrangement and the turbulent quantities on the rudder provided forces, the study focused its attention on the forces generated by the rudder varying the propeller loading conditions and the mutual position between the two devices. These analyses give a hint to describe and improve a commonly-used semi-empirical method based on the actuator disk theory. These analyses also demonstrate the ability of these numerical approaches to correctly predict the interaction behaviour in pre-stall conditions with quite reasonable computational requests (proper also for a design stage), giving additional information on the sectional forces distribution along the span-wise rudder direction, useful to further develop a new semi-empirical rudder model. Full article
