Search Results (88)

This paper demonstrates the benefits of adapting Zero Velocity Update (ZVU) algorithms in foot-mounted pedestrian inertial navigation by finely tuning the algorithm to account for the type of terrain over which the pedestrian travels. Conventional ZVU algorithms for foot-mounted inertial navigation are designed for indoor use and do not account for differences from various terrains. Different terrains affect the natural pedestrian gait and how zero velocity intervals (ZVIs) are identified. By tuning the algorithm to account for accelerometer and gyroscope magnitude and walking cycle duration across four terrains (concrete, grass, pebbles and sand), the accuracy is improved up to 31.04%, dependent on the terrain, and is viable for outdoor use. Full article

Accurate and reliable pedestrian positioning service is essential for providing Indoor Location-Based Services (ILBSs). Zero-Velocity Update (ZUPT)-aided Strapdown Inertial Navigation System (SINS) based on foot-mounted wearable Inertial Measurement Units (IMUs) has shown great performance in pedestrian navigation systems. Though the velocity errors will be corrected once zero-velocity measurement is available, the navigation system errors accumulated during measurement outages are yet to be further optimized by utilizing historical data during both stance and swing phases of pedestrian gait. Thus, in this paper, a novel Forward–Backward navigation and Rauch–Tung–Striebel smoothing (FB-RTS) navigation scheme is proposed. First, to efficiently re-estimate past system state and reduce accumulated navigation error once zero-velocity measurement is available, both the forward and backward integration method and the corresponding error equations are constructed. Second, to further improve navigation accuracy and reliability by exploiting historical observation information, both backward and forward RTS algorithms are established, where the system model and observation model are built under the output correction mode. Finally, both navigation results are combined to achieve the final estimation of attitude and velocity, where the position is recalculated by the optimized data. Through simulation experiments and two sets of field tests, the FB-RTS algorithm demonstrated superior performance in reducing navigation errors and smoothing pedestrian trajectories compared to traditional ZUPT method and both the FB and the RTS method, whose advantage becomes more pronounced over longer navigation periods than the traditional methods, offering a robust solution for positioning applications in smart buildings, indoor wayfinding, and emergency response operations. Full article

We are working on an innovative approach to outdoor human motion capture, using a wearable device that integrates a low-cost GNSS (Global Navigation Satellite System) receiver and an INS (Inertial Navigation System) via a zero-velocity update (ZUPT) methodology. In this study, we focused on using these devices to reconstruct the foot trajectory. Our work addresses the challenge of capturing precise foot movements in uncontrolled outdoor environments, a task traditionally constrained by the limitations of laboratory settings. We equipped devices that combine inertial measurement units (IMUs) with GNSS receivers in the following configuration: one on each foot and one on the head. We experimented with different GNSS data processing techniques, such as Post-Processed Kinematic (PPK) positioning with and without Moving Base (MB), and after the integration with the IMU, we obtained centimeter-level precision in horizontal and vertical positioning for various walking speeds. This integration leverages a loosely coupled GNSS/INS approach, where the GNSS solution is independently processed and subsequently used to refine the INS outputs. Enhanced by ZUPT and Madgwick filtering, this method significantly improves the trajectory reconstruction accuracy. Indeed, our research includes a study of the impact of moving speed on the performance of these low-cost GNSS receivers. These insights pave the way for future exploration into tightly coupled GNSS/INS integration using low-cost GNSS receivers, promising advancements in fields like sports science, rehabilitation, and well-being. This work seeks not only to contribute to the field of wearable technology, but also to open possibilities for further innovation in affordable, high-accuracy personal navigation and activity monitoring devices. Full article

When natural disasters such as earthquakes occur, accurate navigation and positioning information may not be available, making a purely inertial pedestrian navigation system particularly important for rescuers. In this paper, researchers propose a zero-velocity update architecture for pedestrian navigation based on the Informer model, which is integrated into wearable devices. This architecture modifies the fully connected layer of the Informer model to be used for the binary classification task of the zero-velocity update method (ZUPT), allowing for accurate identification of gait information at each moment using only inertial measurement data. By wearing the device on the foot during natural disasters like earthquakes, the location of the pedestrian can be more accurately determined, facilitating rescue efforts. During the experimental process, a Kalman filter model was constructed to achieve zero-velocity updating of the pedestrian’s motion trajectory. A 2000 m walking experiment and a 210 m mixed-gait experiment were conducted to accurately identify gait information at each moment, thereby reducing the cumulative error of the inertial system. Subsequently, a convolutional neural network (CNN) model and a model combining CNN with a long short-term memory network (CNN + LSTM) were introduced as comparative experiments to verify the performance of the proposed architecture. The experimental results demonstrate that the proposed architecture enhances the adaptability of the zero-velocity update algorithm in underground or sheltered spaces, with all results outperforming the other two models. Full article

The MEMS inertial sensors based on the pedestrian localization system assisted by the zero-velocity update (ZUPT) algorithm has gained widespread attention, due to its effective independent localization in indoor environments. However, in the realistic pedestrian localization test, the system often appears to drift because of the long-term error accumulation of inertial sensors and the limitation of the error suppression of traditional pedestrian localization algorithms. In this article, based on full analysis of existing constraint-based methods, a multi-condition constrained pedestrian localization algorithm is proposed, which integrates zero velocity detection based on phase threshold constraint, single and dual feet fusion constraint algorithms, to suppress drift and improve localization accuracy. The experimental results demonstrate that the multi-condition constraint algorithm can reduce localization errors by 59% compared to the unconstrained approach, and by 42% and 26% compared to algorithms using only single-foot or dual-feet constraints, respectively. The trajectory generated from the experiments further shows that the proposed algorithm produces a trajectory that more closely aligns with the actual walking path. Full article

The continuous, automated monitoring of sensor-based data for walking capacity and mobility has expanded gait analysis applications beyond controlled laboratory settings to real-world, everyday environments facilitated by the development of portable, cost-efficient wearable sensors. In particular, the integration of Inertial Measurement Units (IMUs) into smart shoes has proven effective for capturing detailed foot movements and spatiotemporal gait characteristics. While IMUs enable accurate foot trajectory estimation through the double integration of acceleration data, challenges such as drift errors necessitate robust correction techniques to ensure reliable performance. This review analyzes current literature on shoe-based systems utilizing IMUs to estimate spatiotemporal gait parameters and foot trajectory characteristics, including foot–ground clearance. We explore the challenges and advancements in achieving accurate 3D foot trajectory estimation using IMUs in smart shoes and the application of advanced techniques like zero-velocity updates and error correction methods. These developments present significant opportunities for achieving reliable and efficient real-time gait assessment in everyday environments. Full article

To suppress pedestrian positioning drift, a velocity constraint commonly known as zero-velocity update (ZUPT) is widely used. However, it cannot correct the error in the non-zero velocity interval (non-ZVI) or observe heading errors. In addition, the positioning accuracy will be further affected when a velocity error occurs in the ZVI (e.g., foot tremble). In this study, the foot, ankle, and shank were regarded as a triangular structure. Consequently, an angle constraint was established by utilizing the sum of the internal angles. Moreover, in contrast to the traditional ZUPT algorithm, a velocity constraint method combined with Coriolis theorem was constructed. Magnetometer measurements were used to correct heading. Three groups of experiments with different trajectories were carried out. The ZUPT method of the single inertial measurement unit (IMU) and the distance constraint method of dual IMUs were employed for comparisons. The experimental results showed that the proposed method had high accuracy in positioning. Furthermore, the constraints built by the lower limb structure were applied to the whole gait cycle (ZVI and non-ZVI). Full article

Particle swarm optimisation (PSO) is a swarm intelligence algorithm that finds candidate solutions by iteratively updating the positions of particles in a swarm. The decentralised optimisation methodology of PSO is ideally suited to problems with multiple local minima and deceptive fitness landscapes, where traditional gradient-based algorithms fail. PSO performance depends on the use of a suitable control parameter (CP) configuration, which governs the trade-off between exploration and exploitation in the swarm. CPs that ensure good performance are problem-dependent. Unfortunately, CPs tuning is computationally expensive and inefficient. Self-adaptive particle swarm optimisation (SAPSO) algorithms aim to adaptively adjust CPs during the optimisation process to improve performance, ideally while reducing the number of performance-sensitive parameters. This paper proposes a reinforcement learning (RL) approach to SAPSO by utilising a velocity-clamped soft actor-critic (SAC) that autonomously adapts the PSO CPs. The proposed SAC-SAPSO obtains a 50% to 80% improvement in solution quality compared to various baselines, has either one or zero runtime parameters, is time-invariant, and does not result in divergent particles. Full article

Existing methods to obtain position from inertial sensors typically use a combination of multiple sensors and orientation modeling; thus, obtaining position from a single inertial sensor is highly desirable given the decreased setup time and reduced complexity. The dead reckoning method is commonly chosen to obtain position from acceleration; however, when applied to upper limb tracking, the accuracy of position estimates are questionable, which limits feasibility. A new method of obtaining position estimates through the use of zero velocity updates is reported, using a commercial IMU, a push-to-make momentary switch, and a 3D printed object to house the sensors. The generated position estimates can subsequently be converted into sound through sonification to provide audio feedback on reaching movements for rehabilitation applications. An evaluation of the performance of the generated position estimates from a system labeled ‘Soniccup’ is presented through a comparison with the outputs from a Vicon Nexus system. The results indicate that for reaching movements below one second in duration, the Soniccup produces positional estimates with high similarity to the same movements captured through the Vicon system, corresponding to comparable audio output from the two systems. However, future work to improve the performance of longer-duration movements and reduce the system latency to produce real-time audio feedback is required to improve the acceptability of the system. Full article

The pipe jacking guidance system based on a fiber optic gyroscope (FOG) has gained extensive attention due to its high degree of safety and autonomy. However, all inertial guidance systems have accumulative errors over time. The zero-velocity update (ZUPT) algorithm is an effective error compensation method, but accurately distinguishing between moving and stationary states in slow pipe jacking operations is a major challenge. To address this challenge, a “MV + ARE + SHOE” three-conditional zero-velocity detection (TCZVD) algorithm for the fiber optic gyroscope inertial navigation system (FOG-INS) is designed. Firstly, a Kalman filter model based on ZUPT is established. Secondly, the TCZVD algorithm, which combines the moving variance of acceleration (MV), angular rate energy (ARE), and stance hypothesis optimal estimation (SHOE), is proposed. Finally, experiments are conducted, and the results indicate that the proposed algorithm achieves a zero-velocity detection accuracy of 99.18% and can reduce positioning error to less than 2% of the total distance. Furthermore, the applicability of the proposed algorithm in the practical working environment is confirmed through on-site experiments. The results demonstrate that this method can effectively suppress the accumulated error of the inertial guidance system and improve the positioning accuracy of pipe jacking. It provides a robust and reliable solution for practical engineering challenges. Therefore, this study will contribute to the development of pipe jacking automatic guidance technology. Full article

This paper presents a non-invasive methodology for structural health monitoring (SHM) integrated with inertial sensors and signal conditioning techniques. The proposal uses the signal of an IMU (inertial measurement unit) tri-axial accelerometer and gyroscope to continuously measure the displacements of a structure in motion due to seismic vibrations. A system, called the “Inertial Displacement Monitoring System” or “IDMS”, is implemented to attenuate the signal error of the IMU with methodologies such as a Kalman filter to diminish the influence of white noise, a Chebyshev filter to isolate the frequency values of a seismic motion, and a correction algorithm called zero velocity observation update (ZVOB) to detect seismic vibrations and diminish the influence of external perturbances. As a result, the IDMS is a methodology developed to measure displacements when a structure is in motion due to seismic vibration and provides information to detect failures opportunely. Full article

Analytical coarse alignment and Kalman filter fine alignment based on zero-velocity are typically used to obtain initial attitude for inertial navigation systems (SINS) on a static base. However, in the shipboard mooring state, the static observation condition is corrupted. This paper presents a rapid alignment method for SINS on swaying bases. The proposed method begins with a coarse alignment technique in the inertial frame to obtain an initial rough attitude. Subsequently, a Kalman filter with position updates is employed to estimate the remaining misalignment error. To enhance the filter estimation performance, an appropriate lower boundary is set to the target states’ variances according to a carefully designed relative convergence index. The variance-constraint Kalman filter (VCKF) approach is proposed in this paper, and the shipborne experiments validate its effectiveness. The results demonstrate that the VCKF approach significantly reduces the time requirement for fine alignment to achieve the same accuracy on a swaying base, from 90 min in the classic Kalman filter to 30 min. Additionally, the parameter estimation performance in the Kalman filter is also improved, particularly in situations where unpredicted external interference is involved during fine alignment. Full article

To regulate the energy flow in orchard ecosystems and maintain the environment, weeding has become a necessary measure for fruit farmers, and the use of automated mowers can help reduce labor costs and improve the economic efficiency of orchards. However, due to the complexity of the geographic and spatial environment of the orchard, in particular, the loose and undulating road surface, the interference of satellite signals by large trees, etc., which decreases the positioning accuracy and stability of the positioning system of the mower, and the high cost of the sensor also affect the popularization of intelligent mowers for these applications. To address the above problems, this paper constructs a positioning system through a low-cost global navigation satellite system (GNSS), inertial measurement unit (IMU), and odometry, and utilizes the Kalman filter algorithm based on the error state for a combined GNSS/IMU positioning so that the inertial navigation system can maintain a more accurate positioning when the GNSS signals are poor. Considering the side-slip and error accumulation problems of the odometry of the traction mower, the combined GNSS/IMU positioning information is used to optimize the odometry model and improve the navigation and positioning accuracy. To reduce the measurement error of the IMU and the problem of error accumulation, this paper utilizes the nonholonomic constraint (NHC) of a lawn mower to suppress the dispersion of IMU measurement errors and constructs periodic and nonperiodic zero-velocity updating (ZUPT) strategies in combination with the travel paths of lawn mower navigation operations in the region to update the IMU data to improve the positioning accuracy and stability of the positioning system. The experiments show that the average error of the constructed positioning system is controlled within 0.15 m, the maximum error is maintained at approximately 0.3 m, and the positioning system constructed by using low-cost sensors can achieve a positioning accuracy similar to that of the differential global navigation satellite system (DGNSS), which is beneficial for the promotion and application of intelligent mowers in orchards. Full article

In the pedestrian navigation system, researchers have reduced measurement errors and improved system navigation performance by fusing measurements from multiple low-cost inertial measurement unit (IMU) arrays. Unfortunately, the current data fusion methods for inertial sensor arrays ignore the system error compensation of individual IMUs and the correction of position information in the zero-velocity interval. Therefore, these methods cannot effectively reduce errors and improve accuracy. An error compensation method for pedestrian navigation systems based on a low-cost array of IMUs is proposed in this paper. The calibration method for multiple location-free IMUs is improved by using a sliding variance detector to segment the angular velocity magnitude into stationary and motion intervals, and each IMU is calibrated independently. Compensation is then applied to the velocity residuals in the zero-velocity interval after zero-velocity update (ZUPT). The experimental results show a significant improvement in the average noise performance of the calibrated IMU array, with a 3.01-fold increase in static noise performance. In the closed-loop walking experiment, the average horizontal position error of a single calibrated IMU is reduced by 27.52% compared to the uncalibrated IMU, while the calibrated IMU array shows a 2.98-fold reduction in average horizontal position error compared to a single calibrated IMU. After compensating for residual velocity, the average horizontal position error of a single IMU is reduced by 0.73 m, while that of the IMU array is reduced by 64.52%. Full article

The inertial navigation system (INS) and global satellite navigation system (GNSS) are two of the most significant systems for land navigation applications. The inertial measurement unit (IMU) is a kind of INS sensor that measures three-dimensional acceleration and angular velocity measurements. IMUs based on micro-electromechanical systems (MEMSs) are widely employed in vehicular navigation thanks to their low cost and small size, but their magnitude and noisy biases make navigation errors diverge very fast without external constraint. The zero-velocity update (ZVU) function is one of the efficient functions that constrain the divergence of IMUs for a stopped vehicle, and the key of the ZVU is the correct stationary detection for the vehicle. When a land vehicle is stopped, the idling engine produces a very stable vibration, which allows us to perform frequency analysis and a comparison based on the fast Fourier transform (FFT) and IMU measurements. Hence, we propose a stationary detection method based on the FFT for a stopped land vehicle with an idling engine in this study. An urban vehicular navigation experiment was carried out with our GNSS/IMU integration platform. Three stops for 10 to 20 min were set to analyze, generate and evaluate the FFT-based stationary detection method. The FFT spectra showed clearly idling vibrational peaks during the three stop periods. Through the comparison of FFT spectral features with decelerating and accelerating periods, the amplitudes of vibrational peaks were put forward as the key factors of stationary detection. For the consecutive stationary detection in the GNSS/IMU integration process, a three-second sliding window with a one-second updating rate of the FFT was applied to check the amplitudes of peaks. For the assessment of the proposed stationary detection method, GNSS observations were removed to simulate outages during the three stop periods, and the proposed detection method was conducted together with the ZVU. The results showed that the proposed method achieved a 99.7% correct detection rate, and the divergence of the positioning error constrained via the ZVU was within 2 cm for the experimental stop periods, which indicates the effectiveness of the proposed method. Full article
