Search Results (23)

Search Parameters:
Keywords = Yagi-Uda antenna

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
17 pages, 7597 KiB
Article
Screen-Printed 1 × 4 Quasi-Yagi-Uda Antenna Array on Highly Flexible Transparent Substrate for the Emerging 5G Applications
by Matthieu Egels, Anton Venouil, Chaouki Hannachi, Philippe Pannier, Mohammed Benwadih and Christophe Serbutoviez
Electronics 2025, 14(14), 2850; https://doi.org/10.3390/electronics14142850 - 16 Jul 2025
Viewed by 259
Abstract
In the Internet of Things (IoT) era, the demand for cost-effective, flexible, wearable antennas and circuits has been growing. Accordingly, screen-printing techniques are becoming more popular due to their lower costs and high-volume manufacturing. This paper presents and investigates a full-screen-printed 1 × [...] Read more.
In the Internet of Things (IoT) era, the demand for cost-effective, flexible, wearable antennas and circuits has been growing. Accordingly, screen-printing techniques are becoming more popular due to their lower costs and high-volume manufacturing. This paper presents and investigates a full-screen-printed 1 × 4 Quasi-Yagi-Uda antenna array on a high-transparency flexible Zeonor thin-film substrate for emerging 26 GHz band (24.25–27.55 GHz) 5G applications. As part of this study, screen-printing implementation rules are developed by properly managing ink layer thickness on a transparent flexible Zeonor thin-film dielectric to achieve a decent antenna array performance. In addition, a screen-printing repeatability study has been carried out through a performance comparison of 24 antenna array samples manufactured by our research partner from CEA-Liten Grenoble. Despite the challenging antenna array screen printing at higher frequencies, the measured results show a good antenna performance as anticipated from the traditional subtractive printed circuit board (PCB) manufacturing process using standard substrates. It shows a wide-band matched input impedance from 22–28 GHz (i.e., 23% of relative band-width) and a maximum realized gain of 12.8 dB at 27 GHz. Full article
Show Figures

Figure 1

25 pages, 20259 KiB
Article
From Antenna Optimization to MIMO Structures: A Unified Design Framework
by Claudia Constantinescu, Claudia Pacurar, Adina Giurgiuman, Calin Munteanu, Sergiu Andreica, Marian Gliga and Laura Grindei
Technologies 2025, 13(4), 153; https://doi.org/10.3390/technologies13040153 - 10 Apr 2025
Viewed by 448
Abstract
Considering the improvements to modern communications and its requirements, antennas need to operate optimally at certain frequencies and have smaller dimensions. This study considered the optimization of two single antennas functioning at 2.4 GHz through geometry modification while preserving or even improving their [...] Read more.
Considering the improvements to modern communications and its requirements, antennas need to operate optimally at certain frequencies and have smaller dimensions. This study considered the optimization of two single antennas functioning at 2.4 GHz through geometry modification while preserving or even improving their bandwidth, while also considering their gain. At first, the research was conducted using numerical modeling and, based on the conclusions drawn following this analysis, the next step was the experimental analysis of the structures. Due to their different geometrical appearances, the optimized antennas were compared, and then an optimum two-antenna MIMO structure was determined for both structures using different methods to decrease the mutual coupling. The optimum structure was obtained for both antennas. The new antennas functioned at 2.4 GHz but had different dimensions, thus a study into the decoupling methods was needed to see if the same methods were best for both cases. It was determined that shifting the two antennas in the MIMO was the better method when leaving a distance of λ/2 cannot be considered due to an increase in the dimensions of the structures, followed by a 90° shifting of the antennas. Also, the modification of the gain representation was observed through implementing the different decoupling methods to determine their influence on the beamforming. Full article
Show Figures

Figure 1

9 pages, 3098 KiB
Article
Terahertz Reconfigurable Planar Graphene Hybrid Yagi–Uda Antenna
by Qimeng Liu, Renbin Zhong, Boli Xu, Jiale Dong, Gefu Teng, Ke Zhong, Zhenhua Wu, Kaichun Zhang, Min Hu and Diwei Liu
Nanomaterials 2025, 15(7), 488; https://doi.org/10.3390/nano15070488 - 25 Mar 2025
Viewed by 494
Abstract
In this paper, we design a frequency reconfigurable antenna for terahertz communication. The antenna is based on a Yagi design, with the main radiating elements being a pair of dipole antennas printed on the top and bottom of a dielectric substrate, respectively. The [...] Read more.
In this paper, we design a frequency reconfigurable antenna for terahertz communication. The antenna is based on a Yagi design, with the main radiating elements being a pair of dipole antennas printed on the top and bottom of a dielectric substrate, respectively. The director and reflector elements give the antenna end-fire characteristics. The ends of the two arms of the dipole are constructed by staggered metal and graphene parasitic patches. By utilizing the effect of gate voltage on the conductivity of graphene, the equivalent length of the dipole antenna arms are altered and thereby adjust the antenna’s operating frequency. The proposed reconfigurable hybrid Yagi–Uda antenna can operate in five frequency bands separately at a peak gain of 4.53 dB. This reconfigurable antenna can meet the diverse requirements of the system without changing its structure and can reduce the size and cost while improving the performance. Full article
Show Figures

Figure 1

23 pages, 4496 KiB
Article
LoRa Technology Enhanced with a Custom-Designed High-Gain Yagi-Uda Antenna for Data Transmission from Misti Volcano Monitoring to Arequipa City
by Flor de Milagro Yesit Arana Medina and Jorge Rendulich
IoT 2025, 6(1), 3; https://doi.org/10.3390/iot6010003 - 29 Dec 2024
Cited by 2 | Viewed by 1757
Abstract
This study details the design and implementation of a high-gain Yagi-Uda antenna network for the transmission of real-time monitoring data from the Misti Volcano to the city of Arequipa. As Misti is classified as a high-risk volcano due to its active volcanic nature [...] Read more.
This study details the design and implementation of a high-gain Yagi-Uda antenna network for the transmission of real-time monitoring data from the Misti Volcano to the city of Arequipa. As Misti is classified as a high-risk volcano due to its active volcanic nature and the close proximity of nearly one million inhabitants, the current monitoring infrastructure is insufficient to meet the demands of effective surveillance. In response, this project integrates Internet of Things (IoT) technology, the LoRa (Long Range) network, and an optimized seven-element Yagi-Uda antenna, developed using advanced optimization algorithms to enhance transmission efficiency. The primary objective is to facilitate the reliable collection and transmission of critical sensor data for subsequent analysis by volcanological experts, thereby supporting improved prediction and mitigation of potential volcanic hazards. Field tests have demonstrated that the Yagi-Uda antenna, when coupled with LoRa technology, achieved uninterrupted data transmission over a distance of 16 km. The integration of IoT, LoRa, and the optimized antenna design offers a scalable and resilient solution for the continuous monitoring and risk assessment of Misti, enabling the incorporation of advanced high-precision sensors for enhanced surveillance capabilities. Full article
Show Figures

Figure 1

8 pages, 1450 KiB
Proceeding Paper
Communication System Comparison of IoT Applications Using Custom-Designed Antennas: A Basic Experimental Study
by Marco Vinueza Bustamante, Jordan Guillén Arteaga, Carlos Yépez Vera, Aldrin Reyes Narváez and Hernan Barba Molina
Eng. Proc. 2024, 77(1), 16; https://doi.org/10.3390/engproc2024077016 - 4 Nov 2024
Viewed by 644
Abstract
A comparative study of the performance of a communication system for IoT applications is presented. The experiment is based on the bit error rate, which is obtained by varying the distance between two transceiver modules, each attached to a microcontroller Arduino Uno. Four [...] Read more.
A comparative study of the performance of a communication system for IoT applications is presented. The experiment is based on the bit error rate, which is obtained by varying the distance between two transceiver modules, each attached to a microcontroller Arduino Uno. Four scenarios are considered for our experimentation. Each scenario is mainly characterized by interchanging radiator elements which are attached to the transceiver modules. For this, two antennas are designed and implemented: a modified shape-optimized Landstorfer Yagi-Uda antenna and a printed turnstile antenna. The measurements show good agreement, with simulations having gain values of about 9 dBi and 3 dBi for the quasi Yagi-Uda structure and the turnstile antenna, respectively. System performance tests are conducted to compare the performance of the commercial solution at various distances to custom-designed antennas. These tests aim to evaluate the improvement achieved using a new set of antennas. The key to this solution is the use of a high-directivity antenna for data transmission and a circular polarized omnidirectional antenna for reception, which shows an improvement of around 60% in terms of the bit error rate during data transmission compared to the pair of commercial antennas included in the RF module. Full article
(This article belongs to the Proceedings of The XXXII Conference on Electrical and Electronic Engineering)
Show Figures

Figure 1

22 pages, 12439 KiB
Communication
UWB Antenna with Enhanced Directivity for Applications in Microwave Medical Imaging
by Dawar Awan, Shahid Bashir, Shahid Khan, Samir Salem Al-Bawri and Mariana Dalarsson
Sensors 2024, 24(4), 1315; https://doi.org/10.3390/s24041315 - 18 Feb 2024
Cited by 7 | Viewed by 2357
Abstract
Microwave medical imaging (MMI) is experiencing a surge in research interest, with antenna performance emerging as a key area for improvement. This work addresses this need by enhancing the directivity of a compact UWB antenna using a Yagi-Uda-inspired reflector antenna. The proposed reflector-loaded [...] Read more.
Microwave medical imaging (MMI) is experiencing a surge in research interest, with antenna performance emerging as a key area for improvement. This work addresses this need by enhancing the directivity of a compact UWB antenna using a Yagi-Uda-inspired reflector antenna. The proposed reflector-loaded antenna (RLA) exhibited significant gain and directivity improvements compared to a non-directional reference antenna. When analyzed for MMI applications, the RLA showed a maximum increase of 4 dBi in the realized gain and of 14.26 dB in the transmitted field strength within a human breast model. Moreover, it preserved the shape of time-domain input signals with a high correlation factor of 94.86%. To further validate our approach, another non-directional antenna with proven head imaging capabilities was modified with a reflector, achieving similar directivity enhancements. The combined results demonstrate the feasibility of RLAs for improved performance in MMI systems. Full article
Show Figures

Figure 1

21 pages, 2577 KiB
Review
A Review on the Effects of Thermal Inversions and Electromagnetic Fields on Cell Cultures and Wireless Communications
by Cibrán López-Álvarez, María Elena López-Martín, Juan Antonio Rodríguez-González and Francisco José Ares-Pena
Sensors 2023, 23(23), 9567; https://doi.org/10.3390/s23239567 - 2 Dec 2023
Cited by 2 | Viewed by 2510
Abstract
Thermal inversions, typical in the winter season, consist of cold air at the Earth’s surface being trapped under a layer of warmer air. Such an effect keeps normal convective overturning of the atmosphere from penetrating through. This phenomenon highly increases the toxicity of [...] Read more.
Thermal inversions, typical in the winter season, consist of cold air at the Earth’s surface being trapped under a layer of warmer air. Such an effect keeps normal convective overturning of the atmosphere from penetrating through. This phenomenon highly increases the toxicity of the atmosphere, while modifying its dielectric constant, resulting in major implications in terms of public health and wireless communications. Indeed, air pollution in large cities (related, in most cases, to particulate matter that consists of different chemical components, which can have warming or cooling effects) is primarily caused by chemical and photochemical reactions in the atmosphere. Appropriate usage of array antennas allows the effective tracking of changes in humidity (e.g., coated Yagi-Uda antennas, which do not interfere with 5G) and in the dielectric constant (e.g., optimized quasi-Yagi-Uda antennas, yielding to accurate measurements of sulfides and black carbon concentration). Remarkably, important health effects come from the combined action of electromagnetic fields with fine and coarse black carbon particles. The appearance of ducts, which are caused by thermal inversions, provokes the creation of super-refractive regions in the troposphere as well, which result in the anomalous propagation of wireless communications. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

21 pages, 10180 KiB
Article
High Gain Improved Planar Yagi Uda Antenna for 2.4 GHz Applications and Its Influence on Human Tissues
by Claudia Constantinescu, Claudia Pacurar, Adina Giurgiuman, Calin Munteanu, Sergiu Andreica and Marian Gliga
Appl. Sci. 2023, 13(11), 6678; https://doi.org/10.3390/app13116678 - 30 May 2023
Cited by 8 | Viewed by 5995
Abstract
Considering the technological enhancements nowadays, antennas tend to be smaller in order to be easily integrated in devices. The most used antennas today in small high-tech devices close to the human body are planar antennas. In this paper, a Yagi Uda planar antenna [...] Read more.
Considering the technological enhancements nowadays, antennas tend to be smaller in order to be easily integrated in devices. The most used antennas today in small high-tech devices close to the human body are planar antennas. In this paper, a Yagi Uda planar antenna operating at a frequency of 2.4 GHz is HF analyzed and optimized by increasing its bandwidth and gain while maintaining its initial dimensions. The methods used to optimize the antenna’s operation are the use of different dielectrics, different numbers of directors, and different dimensions for directors, placing new conductor elements, all while keeping the same dimensions for its implementation on the planar device. The optimized structure of the planar Yagi Uda antenna has a 10% increase in bandwidth and a 30% increase in gain, reaching a peak value of 4.84 dBi. In our daily activities, we use devices with such antennas very often, so an analysis of the antenna’s influence on the human body is performed: the SAR, electric and magnetic field and radiation power density are determined, represented and reported to the standards in force. For the frequency considered, the SAR should be below 4 W/kg for the head/torso when the exposure is more than six minutes, which is a value exceeded by the antenna in its near vicinity. The calculated maximum electric field limit is 0.349 V/m and the maximum magnetic field value is 28.441 V/m for an exposure between 6 and 30 min values, which is also exceeded in the immediate vicinity of the antenna. The results allow us to suggest that such an antenna should be placed further from the human body, or some protection should be placed between the body and the antenna. From the radiation power density point of view for the modeled antenna, it can be said that a distance from the antenna greater than 0.5 m is considered to be safe. Full article
Show Figures

Figure 1

13 pages, 1888 KiB
Communication
Stereoscopic UWB Yagi–Uda Antenna with Stable Gain by Metamaterial for Vehicular 5G Communication
by Yuanxu Fu, Tao Shen, Jiangling Dou and Zhe Chen
Sensors 2023, 23(9), 4534; https://doi.org/10.3390/s23094534 - 6 May 2023
Cited by 3 | Viewed by 2399
Abstract
In this paper, a stereoscopic ultra-wideband (UWB) Yagi–Uda (SUY) antenna with stable gain by near-zero-index metamaterial (NZIM) has been proposed for vehicular 5G communication. The proposed antenna consists of magneto-electric (ME) dipole structure and coaxial feed patch antenna. The combination of patch antenna [...] Read more.
In this paper, a stereoscopic ultra-wideband (UWB) Yagi–Uda (SUY) antenna with stable gain by near-zero-index metamaterial (NZIM) has been proposed for vehicular 5G communication. The proposed antenna consists of magneto-electric (ME) dipole structure and coaxial feed patch antenna. The combination of patch antenna and ME structure allows the proposed antenna can work as a Yagi–Uda antenna, which enhances its gain and bandwidth. NZIM removes a pair of C-notches on the surface of the ME structure to make it absorb energy, which results in two radiation nulls on both sides of the gain passband. At the same time, the bandwidth can be enhanced effectively. In order to further improve the stable gain, impedance matching is achieved by removing the patch diagonally; thus, it is able to tune the antenna gain of the suppression boundary and open the possibility to reach the most important characteristic: a very stable gain in a wide frequency range. The SUY antenna is fabricated and measured, which has a measured −10 dBi impedance bandwidth of approximately 40% (3.5–5.5 GHz). Within it, the peak gain of the antenna reaches 8.5 dBi, and the flat in-band gain has a ripple lower than 0.5 dBi. Full article
Show Figures

Figure 1

5 pages, 675 KiB
Proceeding Paper
A Novel Yagi–Uda Antenna-Based Wireless Power Transmission (WPT) System Using Passive Reflectors
by Raza Jafri and Ghous Narejo
Eng. Proc. 2023, 32(1), 19; https://doi.org/10.3390/engproc2023032019 - 5 May 2023
Viewed by 1155
Abstract
This work examines how reflections from various reflective surfaces affect the reception of RF electromagnetic waves and how the latter impacts wireless power transmission. The frequency range used was 469.5 MHz to 773.5 MHz, and three reflective materials of almost 20% variation in [...] Read more.
This work examines how reflections from various reflective surfaces affect the reception of RF electromagnetic waves and how the latter impacts wireless power transmission. The frequency range used was 469.5 MHz to 773.5 MHz, and three reflective materials of almost 20% variation in the reflection coefficient were tested with a Yagi–Uda antenna at the receiving end. Additionally, the orientation of the antenna was changed in terms of elevation and azimuthal angles. The results were then assessed, and a conclusion was drawn. Full article
Show Figures

Figure 1

15 pages, 5386 KiB
Article
Bandwidth Enhancement and Generation of CP of Yagi-Uda-Shape Feed on a Rectangular DRA for 5G Applications
by Inam Bari, Javed Iqbal, Haider Ali, Abdul Rauf, Muhammad Bilal, Naveed Jan, Usman Illahi, Muhammad Arif, Muhammad Amir Khan and Rania M. Ghoniem
Micromachines 2022, 13(11), 1913; https://doi.org/10.3390/mi13111913 - 4 Nov 2022
Cited by 11 | Viewed by 2462
Abstract
A wideband circularly polarized rectangular dielectric resonator antenna (DRA) fed by a single feeding mechanism has been studied theoretically and experimentally. The purpose of the study is to determine how adding a parasitic strip next to the flat surface metallic feed would affect [...] Read more.
A wideband circularly polarized rectangular dielectric resonator antenna (DRA) fed by a single feeding mechanism has been studied theoretically and experimentally. The purpose of the study is to determine how adding a parasitic strip next to the flat surface metallic feed would affect various far- and near-field antenna characteristics. Initially, the basic antenna design, i.e., the T-shape feed known as antenna A, produced a 4.81% impedance matching bandwidth (|S11| −10 dB). Due to the narrow and undesirable results of the initial antenna design, antenna-A was updated to the antenna-B design, i.e., Yagi-Uda. The antenna-B produced a decent result (7.89% S11) as compared to antenna-A but still needed the bandwidth widened, for this, a parasitic patch was introduced next to the Yagi-Uda antenna on the rectangular DRA at an optimized location to further improve the results. This arrangement produced circular polarization (CP) waves spanning a broad bandwidth of 28.21% (3.59–3.44 GHz) and a broad impedance |S11| bandwidth of around 29.74% (3.71–3.62 GHz). These findings show that, in addition to producing CP, parasite patches also cause the return loss to rise by a factor of almost three times when compared to results obtained with the Yagi-Uda-shape feed alone. Computer simulation technology was used for the simulation (CST-2017). The planned antenna geometry prototype was fabricated and measured. Performance indicators show that the suggested antenna is a good fit for 5G applications. The simulated outcomes and measurements match up reasonably. Full article
(This article belongs to the Special Issue Microwave Antennas: From Fundamental Research to Applications)
Show Figures

Figure 1

18 pages, 11508 KiB
Article
Transforming Linear to Circular Polarization on Horn Antennas by Using Multiple-Layer Frequency Selective Surfaces
by Adelaida Heiman and Razvan D. Tamas
Sensors 2022, 22(20), 7838; https://doi.org/10.3390/s22207838 - 15 Oct 2022
Cited by 4 | Viewed by 4091
Abstract
This article presents a technique for transforming the polarization of a pyramidal horn antenna by adding multiple layers of frequency-selective surfaces in front of the aperture, in order to rotate the direction of the electric field. Thus, two orthogonal components with the same [...] Read more.
This article presents a technique for transforming the polarization of a pyramidal horn antenna by adding multiple layers of frequency-selective surfaces in front of the aperture, in order to rotate the direction of the electric field. Thus, two orthogonal components with the same magnitude, phase-shifted by 90°, are generated. Each frequency-selective surface consists of skewed λ/2 dipoles. Compared to other similar structures, our antenna system combines the field radiated from the horn aperture with the field scattered by parallel frequency-selective surface structures spaced on the same principle as that for designing a Yagi-Uda antenna array. The proposed horn antenna with multiple frequency-selective surfaces can be used as a feed element for a parabolic reflector antenna for maritime satellite communication systems in the X-band or in the lower part of the Ku band, or as part of a sensor for finding the direction of arrival of a wave, in order to orientate an antenna system. The concept was successfully validated on the basis of simulation and measurements. The proposed technique provides a close to unit axial ratio together with a 3 dB increase in gain compared to the conventional horn antenna, at low manufacturing costs. Full article
(This article belongs to the Special Issue Antennas for Integrated Sensors Systems)
Show Figures

Figure 1

12 pages, 2973 KiB
Article
Lightweight 3D-Printed Fractal Gradient-Index Lens Antenna with Stable Gain Performance
by Yeonju Kim, Duc Anh Pham, Ratanak Phon and Sungjoon Lim
Fractal Fract. 2022, 6(10), 551; https://doi.org/10.3390/fractalfract6100551 - 29 Sep 2022
Cited by 4 | Viewed by 3095
Abstract
This paper proposes a millimeter-wave lens antenna using 3-dimensional (3D) printing technology to reduce weight and provide stable gain performance. The antenna consists of a four-layer cylindrical gradient-index (GRIN) lens fed by a wideband Yagi antenna. We designed a fractal cell geometry to [...] Read more.
This paper proposes a millimeter-wave lens antenna using 3-dimensional (3D) printing technology to reduce weight and provide stable gain performance. The antenna consists of a four-layer cylindrical gradient-index (GRIN) lens fed by a wideband Yagi antenna. We designed a fractal cell geometry to achieve the desired effective permittivity for a GRIN lens. Among different candidates, the honeycomb structure is chosen to provide high mechanical strength with light weight, low dielectric loss, and lens dispersion for a lens antenna. Therefore, the measured peak gain was relatively flat at 16.86 ± 0.5 dBi within 25−31.5 GHz, corresponding to 1 dB gain bandwidth = 23%. The proposed 3D-printed GRIN lens is cost-effective, with rapid and easy manufacturing. Full article
Show Figures

Figure 1

12 pages, 2189 KiB
Article
Optical Ultracompact Directional Antennas Based on a Dimer Nanorod Structure
by Fangjia Zhu, María Sanz-Paz, Antonio I. Fernández-Domínguez, Mauricio Pilo-Pais and Guillermo P. Acuna
Nanomaterials 2022, 12(16), 2841; https://doi.org/10.3390/nano12162841 - 18 Aug 2022
Cited by 7 | Viewed by 2231
Abstract
Controlling directionality of optical emitters is of utmost importance for their application in communication and biosensing devices. Metallic nanoantennas have been proven to affect both excitation and emission properties of nearby emitters, including the directionality of their emission. In this regard, optical directional [...] Read more.
Controlling directionality of optical emitters is of utmost importance for their application in communication and biosensing devices. Metallic nanoantennas have been proven to affect both excitation and emission properties of nearby emitters, including the directionality of their emission. In this regard, optical directional nanoantennas based on a Yagi–Uda design have been demonstrated in the visible range. Despite this impressive proof of concept, their overall size (~λ2/4) and considerable number of elements represent obstacles for the exploitation of these antennas in nanophotonic applications and for their incorporation onto photonic chips. In order to address these challenges, we investigate an alternative design. In particular, we numerically study the performance of a recently demonstrated “ultracompact” optical antenna based on two parallel gold nanorods arranged as a side-to-side dimer. Our results confirm that the excitation of the antiphase mode of the antenna by a nanoemitter placed in its near-field can lead to directional emission. Furthermore, in order to verify the feasibility of this design and maximize the functionality, we study the effect on the directionality of several parameters, such as the shape of the nanorods, possible defects in the dimer assembly, and different positions and orientations of the nanoemitter. We conclude that this design is robust to structural variations, making it suitable for experimental upscaling. Full article
Show Figures

Figure 1

23 pages, 9495 KiB
Article
Super Directional Antenna—3D Phased Array Antenna Based on Directional Elements
by Benzion Levy, Ely Levine and Yosef Pinhasi
Electronics 2022, 11(14), 2233; https://doi.org/10.3390/electronics11142233 - 17 Jul 2022
Cited by 1 | Viewed by 4734
Abstract
This paper describes an antenna design approach for achieving super directivity in an AESA (Active Electronic Scanned Array) radar using an unconventional 3D phased array (PA) antenna concept based on directional Yagi–Uda elements. The proposed scheme is shown to have a wider scanning [...] Read more.
This paper describes an antenna design approach for achieving super directivity in an AESA (Active Electronic Scanned Array) radar using an unconventional 3D phased array (PA) antenna concept based on directional Yagi–Uda elements. The proposed scheme is shown to have a wider scanning feature, with higher directivity in comparison to the same geometry dipole array without increasing the element number. The antenna’s microwave design includes an antipodal Yagi–Uda antenna element that is implemented efficiently on a microstrip PCB using a balun (balance–unbalance)-fed network. This type of antenna is valuable in restricted aperture scans for achieving a narrow antenna beam that increases the angular resolution and measurement precision of tracked targets and also enlarges the detection range or, alternatively, achieves the same performance with a lower number of elements—meeting the goal of low-cost production. The notable result of the high antenna directivity was obtained by both the element and the array architecture, which allowed for improvements in the Array Factor (AF) directivity by increasing the element’s spacing and broadening the scan sector, achieved via the suppression of the element’s Grating Lobe (GL). Another important benefit of this antenna design is the superior coupling reduction caused by its enlarged element distances, which are very significant in electronic scans. An outstanding opportunity to exploit this low coupling can be found in separated MIMO radar architecture. Other benefits of this design’s architecture are the support of a combined module and antenna on a unified board thanks to the End-Fire radiation pattern, its low frequency sensitivity, and its low-cost manufacturing. Full article
Show Figures

Figure 1
