Lithium iron phosphate (LiFePO₄, LFP) batteries dominate grid-scale energy storage, yet their cycle life is capped by its capacity fade issues. Conventional failure workflows suffer from redundant tests, high cost, and long turnaround time because the underlying mechanisms remain unclear. Herein, multi-scale characterization coupled with electrochemical tests have been quantitatively established to reveal four synergistic fade modes of LFP: active-Li loss, FePO₄ secondary-phase formation, SEI rupture, and particle fracture. A two-tier “screen–validate” protocol is proposed to accurately and efficiently disclose its mechanism. In the screening tier, capacity, cyclic voltammetry, electrochemical impedance spectroscopy, low-magnification scanning electron microscopy, and snapshot X-ray diffraction (XRD) rapidly flag the most probable failure cause. The validation tier then deploys mechanism-matched in situ/ex situ tools (operando XRD, TEM, XPS, ToF-SIMS, etc.) to build a comprehensive evidence chain of dynamic structural evolution, materials loss tracking, and quantitative proof. The streamlined workflow preserves scientific rigor and reproducibility while cutting analysis time and cost, offering a closed-loop route for fast failure diagnosis and targeted optimization of next-generation LFP batteries. Full article

Due to the similar physical and chemical properties of ilmenite and olivine, separating them is challenging. The flotation process, with the use of collectors, is an effective method. In this study, a ternary collector consisting of aluminum ion (III), benzohydroxamic acid (BHA), and sodium oleate (NaOL) was prepared for the flotation separation of ilmenite and olivine. Through micro-flotation experiments, molecular dynamics simulation (MD), density functional theory (DFT), scanning electron microscopy (SEM), X-ray photoelectron spectroscopy (XPS), and time-of-flight secondary ion mass spectrometry (TOF-SIMS) analysis, the synergistic effect between the components of the ternary collector and the adsorption configuration on the surface of ilmenite was investigated. The results revealed that at pH = 8, Al (III), BHA, and NaOL could coordinate and adsorb effectively on the surface of ilmenite, enhancing its floatability for separation from olivine. The adsorption configuration differed from previous reports, showing a co-adsorption of multiple forms on the surface of ilmenite. Full article

Oxygen post annealing is a promising method for improving the quality of the SiC metal oxide semiconductor (MOS) interface without the introduction of foreign atoms. In addition, a low oxygen partial pressure annealing atmosphere would prevent the additional oxidation of SiC, inhibiting the generation of new defects. This work focuses on the effect and mechanism of low oxygen partial pressure annealing at different temperatures (900–1250 °C) in the SiO₂/SiC stack. N₂ was used as a protective gas to achieve the low oxygen partial pressure annealing atmosphere. X-ray photoelectron spectroscopy (XPS) characterization was carried out to confirm that there are no N atoms at or near the interface. Based on the reduction in interface trap density (D_it) and border trap density (N_bt), low oxygen partial pressure annealing is proven to be an effective method in improving the interface quality. Vacuum annealing results and time of flight secondary ion mass spectrometry (ToF-SIMS) results reveal that the oxygen vacancy (V[O]) filling near the interface is the dominant annealing mechanism. The V[O] near the interface is filled more by O₂ in the annealing atmosphere with the increase in temperature. Full article

The process of germanium–tannin complex is the oldest form of technology for extracting germanium from Ge-containing solutions. This reaction mechanism is relatively controversial as it imposes restrictions on ideas and methods for reducing the amount of tannin. In this paper, using SEM, TEM, FT-IR, XPS, NMR, TOF-SIMS and UV diffuse reflectance spectroscopy for a deep analysis of germanium–tannin complex, the mechanism of extracting germanium from Ge-containing solutions with tannins is investigated. The results show that the theoretical tannin complex mass is 30 times that of tannin mass, and the complex rate reaches 98.84%. The changes of -OH stretching band in FT-IR spectra, the emergence of C₃H₃GeO₇, C₂H₃GeO₆, and C₈H₇GeO₇ in TOF-SIMS images, and the shift of Ge and O banding energy in XPS detail spectra provided definitive evidence for the germanium–tannin complex process, highlighting that the formed complexes of tannins with germanium involve six coordinate Ge-O bonds, which are obtained through orthophenol hydroxyl groups in tannins reacting with Ge⁴⁺. Furthermore, the complex mode of germanium–tannins is layer polymerization, which finally forms an agglomeration of complex flocs. The findings of this research is innovative, and can have a profound impact on the future introduction of various methods to reduce the mass of tannins. Full article

Gas-phase infiltration of the carbonylchloridogold(I), Au(CO)Cl precursor into the pores of HKUST-1 ([Cu₃(BTC)₂(H₂O)₂], Cu-BTC) SURMOFs (surface-mounted metal-organic frameworks; BTC = benzene-1,3,5-tricarboxylate) leads to Au(CO)Cl decomposition within the MOF through hydrolysis with the aqua ligands on Cu. Small Au_x clusters with an average atom number of x ≈ 5 are formed in the medium-sized pores of the HKUST-1 matrix. These gold nanoclusters are homogeneously distributed and crystallographically ordered, which was supported by simulations of the powder X-ray diffractometric characterization. Au_x@HKUST-1 was further characterized by scanning electron microscopy (SEM) and infrared reflection absorption (IRRA) as well as Raman spectroscopy, time-of-flight secondary ion mass spectrometry (ToF-SIMS), X-ray photoelectron spectroscopy (XPS) and inductively coupled plasma optical emission spectroscopy (ICP-OES). Full article

Poly(ethylene terephthalate)—PET—is one of the most frequently used polymers in biomedical applications. Due to chemical inertness, PET surface modification is necessary to gain specific properties, making the polymer biocompatible. The aim of this paper is to characterize the multi-component films containing chitosan (Ch), phospholipid 1,2-dioleoyl-sn-glycero-3-phosphocholine (DOPC), immunosuppressant cyclosporine A (CsA) and/or antioxidant lauryl gallate (LG) which can be utilized as a very attractive material for developing the PET coatings. Chitosan was employed owing to its antibacterial activity and also its ability to promote cell adhesion and proliferation favorable for tissue engineering and regeneration purposes. Moreover, the Ch film can be additionally modified with other substances of biological importance (DOPC, CsA and LG). The layers of varying compositions were prepared using the Langmuir—Blodgett (LB) technique on the air plasma-activated PET support. Then their nanostructure, molecular distribution, surface chemistry and wettability were determined by atomic force microscopy (AFM), time-of-flight secondary ion mass spectrometry (TOF-SIMS), X-ray photoelectron spectroscopy (XPS), contact angle (CA) measurements and the surface free energy and its components’ determination, respectively. The obtained results show clearly the dependence of the surface properties of the films on the molar ratio of components and allow for a better understanding of the coating organization and mechanisms of interactions at the molecular level both inside the films and between the films and the polar/apolar liquids imitating the environment of different properties. The organized layers of this type can be helpful in gaining control over the surface properties of the biomaterial, thus getting rid of the limitations in favor of increased biocompatibility. This is a good basis for further investigations on the correlation of the immune system response to the presence of biomaterial and its physicochemical properties. Full article

The major problem with Carlin-type gold deposit flotation is that the high dolomite content in the concentrate decreases the quality of gold. Further, the activation mechanisms involved in dolomite flotation are still not fully understood. Herein, the correlation of Fe²⁺ conversion with xanthate adsorption and dolomite flotation was investigated to reveal the effect of dolomite embedded with pyrite. Flotation tests suggested that Fe²⁺ rather than Fe³⁺ improved the floatability of dolomite from 20% to 45%. Contact angles and thermodynamic tests indicated that the hydrophobicity of Fe²⁺-modified dolomite corresponds to the adsorption of xanthate. Importantly, time-of-flight secondary ion mass spectroscopy (Tof-SIMS) and x-ray photoelectron spectroscopy (XPS) attributed the activation of dolomite flotation to the formation of Fe(OH)₂ and FeCO₃. The coordination model of flotation successfully elucidated the selective adsorption of xanthate between Fe(OH)₂, FeCO₃ and FeOOH surfaces. The density function theory (DFT) simulation calculation was performed to identify the reaction rate at the atomic level, and the density of states (DOS) was also conducted to verify the conclusions at the electronic level. This study presents important surface chemistry evidence for understanding and regulating the poor selectivity in the flotation of Carlin-type gold deposits. Full article

This work studies two copper-based alloys as potential antimicrobial weapons for sectors where surface hygiene is essential. Effects of different alloying elements addition at the same Cu content (92.5% by weight) on the corrosion resistance and the antibacterial performance of two copper alloys were studied in an aerated disinfectant solution (0.25% v/v Aniosurf Premium (D)) by electrochemical corrosion, X-ray photoelectron spectroscopy (XPS), time-of-flight secondary ion mass spectroscopy (ToF-SIMS) and antibacterial tests. Results showed that the nature of the alloying elements had a clear influence on the corrosion resistance and antibacterial performance. Electrochemical impedance results and surface analyses demonstrate the presence of organic compounds bound on the substrate and that a film covers part of the total active surface and may act as a protective barrier by preventing the interaction between metal and solution, decreasing the antimicrobial performance of copper-based materials. Low zinc and silicon contents in copper alloys allows for better aging behavior in D solution while maintaining good antibacterial performance. The XPS and ToF-SIMS results indicated that artificial aging in disinfectant enhanced Cu enrichment in the organic film formed, which could effectively stimulate the release of Cu ions from the surface. Full article

Recently, several studies have shown the positive effect of sulfidization flotation on malachite surfaces and its enhancing methods. Therefore, this paper was focused on the effect of ammonium sulfide and sodium sulfide on the sulfidization of malachite, respectively; this was investigated using different devices such as the micro-flotation tests, Zeta potential measurements, ToF–SIMS, XPS analysis, and FTIR. Thus, Fourier transform infrared spectroscopy results demonstrated that a new characteristic peak of Cu-S bonds was formed and adsorbed on malachite surfaces at 1694 cm⁻¹, as confirmed by XPS analysis. Notably, malachite with ammonium sulfide ions had a significantly higher flotation recovery than malachite with an excess of sodium sulfide ions, as concerns of sulfidization types. Conclusively, all the experiments in this study confirmed that additional copper sulfide products were formed on the malachite surface, increasing the hydrophobicity of the malachite. Full article

Herein, a novel hybrid bilayer membrane is introduced as a platform to study the aggregation of amyloid-β_1–42 (Aβ_1–42) peptide on surfaces. The first layer was covalently attached to a glassy carbon electrode (GCE) via diazonium electrodeposition, which provided a highly stable template for the hybrid bilayer formation. To prepare the long-chain hybrid bilayer membrane (lcHBLM)-modified electrodes, GCE surfaces were modified with 4-dodecylbenzenediazonium (DDAN) followed by the modification with dihexadecyl phosphate (DHP) as the second layer. For the preparation of short-chain hybrid bilayer membrane (scHBLM)-modified electrodes, GCE surfaces were modified with 4-ethyldiazonium (EDAN) as the first layer and bis(2-ethylhexyl) phosphate (BEHP) was utilized as the second layer. X-ray photoelectron spectroscopy (XPS) and time-of-flight secondary ion mass spectrometry (ToF-SIMS) were used to characterize the bilayer formation. Both positively charged [Ru(NH₃)₆]³⁺ and negatively charged ([Fe(CN)₆]^3-/4-) redox probes were used for electrochemical characterization of the modified surfaces using cyclic voltammetry (CV) and electrochemical impedance spectroscopy (EIS). EIS results showed a decrease in charge transfer resistance (R_ct) upon incubation of Aβ_1–42 on the hybrid bilayer-modified surfaces. This framework provides a promising electrochemical platform for designing hybrid bilayers with various physicochemical properties to study the interaction of membrane-bound receptors and biomolecules on surfaces. Full article

The development of bioactive coatings for orthopedic implants has been of great interest in recent years in order to achieve both early- and long-term osseointegration. Numerous bioactive materials have been investigated for this purpose, along with loading coatings with therapeutic agents (active compounds) that are released into the surrounding media in a controlled manner after surgery. This review initially focuses on the importance and usefulness of characterization techniques for bioactive coatings, allowing the detailed evaluation of coating properties and further improvements. Various advanced analytical techniques that have been used to characterize the structure, interactions, and morphology of the designed bioactive coatings are comprehensively described by means of time-of-flight secondary ion mass spectrometry (ToF-SIMS), X-ray photoelectron spectroscopy (XPS), Fourier transform infrared spectroscopy (FTIR), atomic force microscopy (AFM), scanning electron microscopy (SEM), transmission electron microscopy (TEM), 3D tomography, quartz crystal microbalance (QCM), coating adhesion, and contact angle (CA) measurements. Secondly, the design of controlled-release systems, the determination of drug release kinetics, and recent advances in drug release from bioactive coatings are addressed as the evaluation thereof is crucial for improving the synthesis parameters in designing optimal bioactive coatings. Full article

We developed a new approach to attach particles onto a conductive layer as a working electrode (WE) in a microfluidic electrochemical cell with three electrodes. Nafion, an efficient proton transfer molecule, is used to form a thin protection layer to secure particle electrodes. Spin coating is used to develop a thin and even layer of Nafion membrane. The effects of Nafion (5 wt% 20 wt%) and spinning rates were evaluated using multiple sets of replicates. The electrochemical performance of various devices was demonstrated. Additionally, the electrochemical performance of the devices is used to select and optimize fabrication conditions. The results show that a higher spinning rate and a lower Nafion concentration (5 wt%) induce a better performance, using cerium oxide (CeO₂) particles as a testing model. The WE surfaces were characterized using atomic force microscopy (AFM), scanning electron microscopy-focused ion beam (SEM-FIB), time-of-flight secondary ion mass spectrometry (ToF-SIMS), and X-ray photoelectron spectroscopy (XPS). The comparison between the pristine and corroded WE surfaces shows that Nafion is redistributed after potential is applied. Our results verify that Nafion membrane offers a reliable means to secure particles onto electrodes. Furthermore, the electrochemical performance is reliable and reproducible. Thus, this approach provides a new way to study more complex and challenging particles, such as uranium oxide, in the future. Full article

This work presents a surface analytical study of the corrosion inhibitor 2-phenylimidazole (2PhI) adsorbed on a Cu surface from 3 wt.% NaCl solution. X-ray photoelectron spectroscopy (XPS) and time-of-flight secondary ion mass spectrometry (ToF-SIMS) were used to investigate the surface phenomena. Various XPS experiments were performed, i.e., survey- and angle-resolved high-resolution XPS spectra measurements, gas cluster ion beam sputtering in conjunction with XPS measurements, and XPS imaging in conjunction with principal component analysis. These measurements were used to detail the composition of the surface layer at depth. In addition, various ToF-SIMS experiments were performed, such as positive ion ToF-SIMS spectral measurements, ToF-SIMS imaging, and cooling/heating in conjunction with ToF-SIMS measurements. This study shows that organometallic complexes were formed between 2PhI molecules and Cu ions, that the surface layer contained entrapped NaCl, that the surface layer contained some Cu(II) species (but the majority of species were Cu(I)-containing species), that the surface was almost completely covered with a combination of 2PhI molecules and organometallic complex, and that the temperature stability of these species increases when 2PhI is included in the organometallic complex. Full article

Thermal treatment conditions of solid polymer polymer electrolyte (SPE) were studied with respect to their impact on the surface morphology, phase composition and chemical composition of an imidazolium ionic-liquid-based SPE, namely PVDF/NMP/[EMIM][TFSI] electrolyte. These investigations were done using scanning electron microscopy, Raman spectroscopy, Fourier transform infrared spectroscopy, differential scanning calorimetry as well as X-ray photoelectron spectroscopy and time-of-flight secondary ion mass spectroscopy. A thoroughly mixed blend of polymer matrix, ionic liquid and solvent was deposited on a ceramic substrate and was kept at a certain temperature for a specific time in order to achieve varying crystallinity. The morphology of all the electrolytes consists of spherulites whose average diameter increases with solvent evaporation rate. Raman mapping shows that these spherulites have a semicrystalline structure and the area between them is an amorphous region. Analysis of FTIR spectra as well as Raman spectroscopy showed that the β-phase becomes dominant over other phases, while DSC technique indicated decrease of crystallinity as the solvent evaporation rate increases. XPS and ToF-SIMS indicated that the chemical composition of the surface of the SPE samples with the highest solvent evaporation rate approaches the composition of the ionic liquid. Full article

In this study, we report on the deposition of a highly crystalline AlN interfacial layer on GaN at 330 °C via plasma-enhanced atomic layer deposition (PEALD). Trimethylaluminum (TMA) and NH₃ plasma were used as the Al and N precursors, respectively. The crystallinity and mass density of AlN were examined using X-ray diffraction (XRD) and X-ray reflectivity (XRR) measurements, respectively, and the chemical bonding states and atomic concentrations of the AlN were determined by X-ray photoelectron spectroscopy (XPS). The AlN/n-GaN interface characteristics were analyzed using TOF-SIMS and STEM, and the electrical characteristics of the AlN were evaluated using metal-insulator-semiconductor (MIS) capacitors. The PEALD process exhibited high linearity between the AlN thickness and the number of cycles without any incubation period, as well as a low carbon impurity of less than 1% and high crystal quality even at a low deposition temperature of 330 °C. Moreover, the GaN surface oxidation was successfully suppressed by the AlN interfacial layer. Furthermore, enhanced electrical characteristics were achieved by the MIS capacitor with AlN compared to those achieved without AlN. Full article
