Search Results (94)

This work presents an experimental study of the electromagnetic behavior of water and its interaction with gasoline in the frequency range of 1.9 to 2.6 GHz, corresponding to the UHF band. This interval lies within the dielectric relaxation region of water, where significant absorption and reflection phenomena occur. The results show qualitative differences in the electromagnetic responses of water, gasoline, and their mixtures, particularly in the stability of amplitudes and phase variability. The mixtures exhibit an intermediate behavior between the pure liquids, highlighting the direct influence of the dielectric properties of the medium on the reflected signal. Furthermore, it was identified that the band between 2400 and 2550 MHz presents a more predictable amplitude response, making it a promising frequency range for the non-invasive detection of gasoline as a contaminant in aquatic environments. Full article

This paper presents the design of a circularly polarized RFID ground mat antenna for UHF-band sports-event applications. Considering a practical sports-event timing system, the ground-based mat antenna with characteristics of a low-backward radiation and circular polarization is proposed. A multilayer square patch antenna using an acrylic dielectric substrate with a wideband branch-line coupler feeding network is employed to improve overall radiation efficiency, which, in turn, provides two excitation port with a phase difference of 90°. Thus, right-hand circular polarization can be obtained. Instead of a conventional FR4–air–FR4 structure, the proposed FR4–acrylic–FR4 composite configuration is adopted to substantially increase the antenna’s mechanical strength and durability against external pressure from runners. The antenna’s performance is attributed to the use of an effective composite dielectric constant and an optimized design of its parameters. Additionally, the patch antenna’s low-backward radiation characteristic helps reduce multipath interference in real-world applications. The measured results are in good agreement with the simulated data, validating the proposed antenna design. In order to further assess the practical performance of the antenna, outdoor measurements are carried out to validate the estimated reading distances derived from controlled anechoic chamber tests. The measured return loss remained below −10 dB across the frequency range of 755–990 MHz, exhibiting a slight discrepancy compared to the simulated bandwidth of 800–1030 MHz. For the characteristic of the circular polarization, the measured axial ratio is below 3 dB within the range of 860–920 MHz. While a more relaxed criterion of an axial ratio below 6 dB is considered, the operating frequency range extends from 560 MHz to 985 MHz, which falls within the frequency band relevant for RFID reader applications. Full article

The advancement of wearable technologies has resulted in significant interest in GNSS-integrated textile antenna development. Although existing literature surveys predominantly concentrate on flexible non-textile antenna systems operating within UHF and 5G frequency spectra, systematic investigations of textile-based antenna configurations in the 1–2 GHz GNSS band have been relatively scarce. Contemporary GNSS textile antenna architectures primarily target GPS frequency coverage, while the global proliferation of BeiDou Navigation Satellite System (BDS) infrastructure necessitates urgent development of BDS-compatible textile antenna solutions. This review methodically examines the structural configurations and radiation characteristics of 1–2 GHz textile antennas, bandwidth enhancement techniques, miniaturization methodologies, and gain optimization approaches, along with material selection criteria and manufacturing processes. Technical challenges persist in simultaneously achieving broadband operation, compact dimensions, and elevated gain performance. Primary manufacturing approaches encompassing laminated fabric assemblies, printed electronics, and embroidered conductive patterns are analyzed, while existing methodologies exhibit limited capacity for seamless garment integration. Despite remarkable progress in conductive material engineering, dielectric property modification studies demonstrate insufficient theoretical depth. Comprehensive mitigation strategies for multifaceted operational environments involving human proximity effects, mechanical deformation, and variable meteorological conditions remain notably underdeveloped. This comprehensive analysis aims to establish a foundational framework for next-generation BDS-oriented textile antenna development. Full article

Partial discharge (PD) in insulators will not only lead to the gradual degradation of insulation performance but even cause power system failure in serious cases. Because there is strong noise interference in the field, it is difficult to accurately locate the position of the PD source. Therefore, this paper proposes a three-dimensional spatial localization method of the PD source with a four-element ultra-high-frequency (UHF) array based on improved wavelet packet dynamic threshold denoising and the $G_{xx}-\beta$ generalized cross-correlation algorithm. Firstly, considering the field noise interference, the PD signal is decomposed into sub-signals with different frequency bands by the wavelet packet, and the corresponding wavelet packet coefficients are extracted. By using the improved threshold function to process the wavelet packet coefficients, the PD signal with low distortion rate and high signal-to-noise ratio (SNR) is reconstructed. Secondly, in order to solve the problem that the amplitude of the first wave of the PD signal is small and the SNR is low, an improved weighting function, $G_{xx}-\beta$, is proposed, which is based on the self-power spectral density of the signal and is adjusted by introducing an exponential factor to improve the accuracy of the first wave arrival time and time difference calculation. Finally, the influence of different sensor array shapes and PD source positions on the localization results is analyzed, and a reasonable arrangement scheme is found. In order to verify the performance of the proposed method, simulation and experimental analysis are carried out. The results show that the improved wavelet packet denoising algorithm can effectively realize the separation of PD signal and noise and improve the SNR of the localization signal with low distortion rate. The improved $G_{xx}-\beta$ weighting function significantly improves the estimation accuracy of the time difference between UHF sensors. With the sensor array designed in this paper, the relative localization error is 3.46%, and the absolute error is within 6 cm, which meets the requirements of engineering applications. Full article

The last few years have seen the introduction of new technologies in beekeeping, including RFID. Using readers and miniaturized tags, RFID systems work in the UHF frequency band, allowing reading distances to reach tens of centimeters. This work analyzes the propagation inside a full beehive, composed of 10 frames supported by a wooden structure. Each frame contains a layer of beeswax supported by metallic wires. The methodology employed involves measuring Received Signal Strength Indicator (RSSI) values and simulating the environment using CST Studio. The results show that tags located along the frame’s wires have more coverage than tags in the center positions, revealing coupling of the microtag antenna with the wire. Furthermore, obtaining coverage through simulations represents a more restrictive approach than through measurements. Frame selectivity is also observed, as most of the coverage is found within the three frames closest to the reader antenna. This result shows that RFID systems can find application in the identification and location of the queen bee in a hive. Full article

This paper presents a fully integrated bandpass filter (BPF) with high tunability based on a novel differential active inductor (DAI), designed for sensor interface circuits operating in the ultra-high frequency (UHF) band. The design of the proposed DAI is based on a symmetrical configuration, utilizing a differential amplifier for the feedforward transconductance and a common-source (CS) transistor for the feedback transconductance. By integrating a cascode scheme with a feedback resistor, the quality factor of the active inductor is significantly improved, leading to enhanced mid-band gain for the bandpass filter. To facilitate independent tuning of the BPF‘s center frequency and mid-band gain, an active resistor adjustment and bias voltage control are employed, providing precise control over the filter’s operational parameters. Post-layout simulations and process corner results are conducted with 0.13 µm CMOS technology at 1.2 V supply voltage. The proposed second order BPF achieves a broad tuning range of 280 MHz to 2.426 GHz, with a passband gain between 8.9 dB and 16.54 dB. The design demonstrates a maximum noise figure of 16.54 dB at 280 MHz, an input-referred 1 dB compression point of −3.78 dBm, and a third-order input intercept point (IIP3) of −0.897 dBm. Additionally, the BPF occupies an active area of only 68.2×30 µm², including impedance-matching part, and consumes a DC power of 14–20 mW. The compact size and low power consumption of the design make it highly suitable for integration into modern wireless sensor interfaces where performance and area efficiency are critical. Full article

In this paper, a conformal UHF antenna with a wide-angle radar cross section (RCS) reduction capability is proposed. The radiator of the design is a planar monopole antenna. Since the large physical size of the antenna in UHF band can generate a scatter beam with a large RCS in the high operating frequency of radars and other sensing applications, i.e., the X band, two types of ITO (Indium Tin Oxide) meta-absorber are proposed and loaded onto the monopole antenna to suppress the scatter. For the incident beam around the direction orthogonal to the radiator plane, the periodical meta-absorber can realize around a 20 dB RCS reduction in the X band. The incident wave around the parallel direction of the radiator is absorbed by the taper meta-absorber, which can greatly suppress the surface and then reduce the RCS in the horizontal plane. The combined effect means the antenna can achieve a wide-angle RCS reduction. It should be noted that the antenna can still produce a high-efficiency omnidirectional beam after the lossy meta-absorber is loaded. In our opinion, the advantages of the proposed antenna design, including good radiation performance in UHF band and high RCS reduction in X band, make it a suitable candidate for airborne and drone applications. Full article

In radio frequency identification (RFID), differences in spectrum policies and tag misreading in different countries are the two main issues that limit its application. To solve these problems, this article proposes a composite right/left-handed transmission line (CRLH-TL)-based reconfigurable antenna for ultra-high frequency near-field and far-field RFID reader applications. The CRLH-TL is achieved using a periodically capacitive gap-loaded parallel plate line. By deploying the CRLH-TL operating at zeroth-order resonance, a loop antenna with in-phase radiating current is obtained, which contributes to a strong and uniform H-field and a horizontally polarized omnidirectional radiation pattern. By introducing additional tunable components, frequency and reading range reconfigurabilities are enabled. The frequency tuning range is from 833 MHz to 979 MHz, which covers the worldwide UHF RFID band. Moreover, each operation mode has a narrow frequency band, which means it can operate without violating different countries’ radio frequency policy and reduce the design difficulty of designing multiple versions of a reader. Both the near-field interrogation zone and maximum far-field reading distance of the antenna are adjustable. The near-field interrogation zone is 400 mm × 400 mm × 50 mm and can be further confined. The tuning range for far-field reading distance is from 2.71 m to 0.35 m. Full article

The production of consumer electronics using electrically conductive materials is a dynamically developing sector of the economy. E-textiles (electronic textiles) are also used in radio frequency identification technology, mainly in the production of tag antennas. For economic reasons, it is important that the finished product is universal, although frequencies in radio systems have different values in different regions of the world. Therefore, the antenna bandwidth must be sufficiently wide so that the read range of the tag is maximally large for all frequencies of the specified band. The bandwidth of an antenna depends on its type and geometric dimensions, but this parameter can also be influenced by the way a given type of antenna is made. The authors prepared samples of embroidered RFID tag antennas for the UHF band using various types of embroidery. Then, its impedance and the read range of the tag were examined in order to determine the exact influence of the type of embroidery on the parameter of interest (antenna bandwidth). The results obtained during the research indicate the influence of different embroidery styles is present; however, that influence is not significant. Full article

A design framework for developing full-textile reconfigurable dipole antennas is proposed for wearable applications. To this end, a precise embroidery process using conductive threads is applied to properly manage the antenna structure. Further, mechanical reconfiguration to enhance antenna operation by using solely clothing components is outlined. As a proof-of-concept, we present a full-textile embroidered dipole antenna with mechanical frequency reconfiguration. Specifically, reconfiguration is achieved by folding the dipole arms through a triangular formation. Conductive Velcro strips are employed to guide the necessary dipole arrangement. As shown, the proposed design methodology enables frequency tunability that ranges from 780 to 1330 MHz for UHF and L bands, with satisfactory radiation performance. The measured and simulated results are in good agreement, in terms of achieving similar frequency reconfiguration concept, as predicted by the electromagnetic simulation models. Full article

In recent years, the need for reliable signal transmission in forested areas has increasingly grown, and the past few decades have witnessed significant developments in related research. With the emergence of smart forestry and precision forestry, understanding the science behind enhancing signal reliability in forests—specifically, studying the patterns and models of radio wave attenuation in these environments—has become crucial. To this end, we conducted a comprehensive review based on bibliometrics to summarize and construct the existing academic literature, revealing current research trends and hotspots. Utilizing bibliometric techniques, we analyzed the literature on radio wave attenuation in forests to summarize and evaluate previous studies. Our analysis indicates that empirical models (67%), hybrid models (21%), and equivalent models (12%) are the three main research clusters in this field. We observed that studies on radio attenuation are more prevalent in urban and artificial forests, while there is a scarcity of research in complex conditions like tropical rainforests and extreme weather; studies are more focused on UHF, VHF, and SHF frequency bands, with lesser attention given to other bands. Previous research has not adequately considered the impact of seasonal factors on signal attenuation patterns nor the influence of forest working environments. Full article

Accurately measuring river flow is not only crucial for hydrologists monitoring hydrological processes but also important for all professionals involved in hydrological research. The ultrahigh frequency (UHF) band enables the surface flow velocity measurement at a deeper effective water depth, so it is less susceptible to the influence of wind drift. However, in curved river channels, the spatial variation in surface velocity is caused by the uneven erosion of the water flow, and this variation is influenced by both air shear stress and the curvature of the river. To mitigate the impact of water level on cross-sectional flow velocity estimation and address the nonlinear relationship between cross-sectional area and water level, this paper proposes a model that is independent of river water level. The nonlinear relationship between cross-sectional area and water level is calculated using a Taylor series expansion. The model was validated using experimental data collected from the Xiantao section of the Han River in Hubei, China, from March to July 2018. The data were discussed separately for high-flow and low-flow periods and were divided into training and validation sets in an 8:2 ratio. Compared to the previous method, our improved method reduces the Root Mean Square Error (RMSE) and Mean Absolute Percentage Error (MAPE) by approximately 2%. In the estimation of flow during the dry season, the improved method achieved a correlation coefficient of 0.9523, representing an increase of 0.1243 compared to the original method. The RMSE was 23.0383, and the MAPE was 0.0232, showing reductions of 23.144 and 0.0241, respectively, compared to the original method. In the estimation of discharge during the wet season, the improved method achieved a correlation coefficient of 0.9908, an increase of 0.0575 compared to the original method. The RMSE was 65.4929, and the MAPE was 0.0391, reflecting reductions of 75.1271 and 0.0338, respectively, compared to the original method. This advancement further enhances the application of UHF radar for discharge measurement in meandering rivers. Full article

Ultrahigh-frequency (UHF) sensing is one of the most promising techniques for assessing the quality of power transformer insulation systems due to its capability to identify failures like partial discharges (PDs) by detecting the emitted UHF signals. However, there are still uncertainties regarding the frequency range that should be evaluated in measurements. For example, most publications have stated that UHF emissions range up to 3 GHz. However, a Cigré brochure revealed that the optimal spectrum is between 100 MHz and 1 GHz, and more recently, a study indicated that the optimal frequency range is between 400 MHz and 900 MHz. Since different faults require different maintenance actions, both science and industry have been developing systems that allow for failure-type identification. Hence, it is important to note that bandwidth reduction may impair classification systems, especially those that are frequency-based. This article combines three operational conditions of a power transformer (healthy state, electric arc failure, and partial discharges on bushing) with three different self-organized maps to carry out failure classification: the chromatic technique (CT), principal component analysis (PCA), and the shape analysis clustering technique (SACT). For each case, the frequency content of UHF signals was selected at three frequency bands: the full spectrum, Cigré brochure range, and between 400 MHz and 900 MHz. Therefore, the contributions of this work are to assess how spectrum band limitation may alter failure classification and to evaluate the effectiveness of signal processing methodologies based on the frequency content of UHF signals. Additionally, an advantage of this work is that it does not rely on training as is the case for some machine learning-based methods. The results indicate that the reduced frequency range was not a limiting factor for classifying the state of the operation condition of the power transformer. Therefore, there is the possibility of using lower frequency ranges, such as from 400 MHz to 900 MHz, contributing to the development of less costly data acquisition systems. Additionally, PCA was found to be the most promising technique despite the reduction in frequency band information. Full article

In recent years, communication systems, including RFID, have been used in intelligent beehives for beekeeping. RFID systems in the UHF frequency band offer reading distances of tens of centimetres, allowing the localisation and identification of the queen bee inside the hive. With this purpose, this work proposes an analysis of an environment of propagation that consists of a honeycomb frame, where the reader is placed within the frame, and the tag is placed in different positions over it. A honeycomb frame consists of a wooden box containing a honey wax panel, supported by metallic wires. The environment is modelled theoretically using its S-parameters and simulated in CST Studio. An analysis of these results and empirical measurements is performed. The results show that a periodicity in the received power of the tag is found with respect to the distance to the reader when the tag is located in a direction parallel to the wire, where local maximum and minimum values are found. Additionally, when the tag is placed over a wire of the frame, a higher received power is obtained compared to the case where the tag is placed between two wires. Furthermore, it has been observed that the reading range has increased with respect to free space, covering the full frame. Full article

In answer to the demand for high sensitivity and miniaturization of ultra-high frequency (UHF) sensors for partial discharge (PD) detection in power equipment, this paper proposes research on miniaturized UHF-sensing technology for PD detection in power equipment based on symmetric cut theory. The symmetric cut theory is applied for the first time to the miniaturization of PD UHF sensors for power equipment. A planar monopole UHF sensor with a size of only 70 mm × 70 mm × 1.6 mm is developed using an exponential asymptotic feed line approach, which is a 50% size reduction. The frequency–response characteristics of the sensor are simulated, optimized and tested; the results show that the standing wave ratio of the sensor developed in this paper is less than 2 in the frequency band from 427 MHz to 1.54 GHz, and less than 5 in the frequency band from 300 MHz to 1.95 GHz; in the 300 MHz~1.5 GHz band; the maximum and average gains of the sensor E-plane are 4.76 dB and 1.02 dB, respectively. Finally, the PD simulation experiment platform for power equipment is built to test the sensor’s sensing performance; the results show that the sensor can effectively detect the PD signals; the sensing sensitivity is improved by about 95% relative to an elliptical monopole UHF sensor. Full article
