Obtaining new data on the gas-dynamic responses from the polymer samples (polytetrafluoroethylene, PTFE) irradiated by powerful VUV radiation from compressed plasma flows is in the focus of the present study. An erosion type magnetoplasma compressor (MPC), a type of plasma focus discharge, was used as a radiation source. The operating voltages of the MPC were between 15 and 25 kV, the maximum measured discharge current was 200 kA, and the radiation energy in the VUV range was ≈1–2 kJ. The VUV fluxes on the sample surface were high and equal to ≈10²²–10²⁴ photons cm⁻²·s⁻¹. Double-exposure laser holographic interferometry and schlieren photography were used to diagnose and visualize the gas-dynamic structures. The spatial distribution of the parameters (temperature, pressure and concentrations of electrons and ions) was defined based on the assumption of local thermodynamic equilibrium. It has been demonstrated that the maximum temperature ranged from ≈ 10 to 15 kK in the plasma layer. The electron concentration was ≈ (0.7–1.6) × 10¹⁸ cm⁻³ in this region. The used techniques of optical diagnostics and procedures of result processing make it possible to obtain data on the dynamics of polymer ablation, which occurs when their surface is exposed to powerful energy fluxes (thermal, shock-wave, radiation, and other extreme loads). Full article

The auto-ignition caused by oblique shocks was investigated experimentally in a supersonic flow regime, with the incoming flow at a Mach number of 2.5. The transient characteristics of the auto-ignition caused by shock evolvements were recorded with a schlieren photography system, and the initial flame kernel generation and subsequent propagation were recorded using a high-speed camera. The fuel mixing characteristics were captured using NPLS (nanoparticle-based planar laser scattering method). This work aimed to reveal the flame spread mechanism in a supersonic flow regime. The effects of airflow total temperature, fuel injection pressure, and cavity length in the process of auto-ignition and on the auto-ignitable boundary were investigated and analyzed. From this work, it was found that the initial occurrence of auto-ignition is first induced by oblique shocks and then propagated upstream to the recirculation region, to establish a sustained flame. The auto-ignition performance can be improved by increasing the injection pressure and airflow total temperature. In addition, a cavity with a long length has benefits in controlling the flame spread from the induced state to a sustained state. The low-speed recirculating region created in the cavity is beneficial for the flame spread, which has the function of flame-holding and prevents the flame from being blown away. Full article

To understand the effect of hydrogen addition on the laminar burning velocity (LBV) of ethanol–air mixtures, experiments were conducted in a constant volume combustion chamber with the high-speed schlieren photography technique. The experiments were carried out under the equivalence ratios (ERs) of 0.7–1.4, an initial temperature of 400 K, an initial pressure of 0.1 MPa, and hydrogen fractions of 30% and 90% by volume, respectively. The effects of ER, initial temperature, initial pressure, and hydrogen fractions on the LBV were investigated. Moreover, adiabatic flame temperature (AFT), heat release rate (HRR), flow rate sensitivity analysis, and ROP (rate of production) analysis were also performed. Results showed that LBV increased with increasing hydrogen addition and temperature but decreased with increasing pressure. The hydrogen addition significantly increased the HRR of ethanol–hydrogen–air flames. The sensitivity analysis showed that R5 (O₂ + H = O + OH) significantly influenced the LBV. Full article

In numerous turbomachinery applications, e.g., in aero-engines with regenerators for improving specific fuel consumption (SFC), heat exchangers with low-pressure loss are required. Pil low-plate heat exchangers (PPHE) are a novel exchanger type and promising candidates for high-speed flow applications due to their smooth profiles avoiding blunt obstacles in the flow path. This work deals with the overall system behavior and gas dynamics of pillow-plate channels. A pillow-plate channel was placed in the test section of a blow-down wind tunnel working with dry air, and compressible flow phenomena were investigated utilizing conventional and focusing schlieren optics; furthermore, static and total pressure measurements were performed. The experiments supported the assumption that the system behavior can be described through a Fanno–Rayleigh flow model. Since only wavy walls with smooth profiles were involved, linearized gas dynamics was able to cover important flow features within the channel. The effects of the wavy wall structures on pressure drop and Mach number distribution within the flow path were investigated, and a good qualitative agreement with theoretical and numerical predictions was found. The present analysis demonstrates that pressure losses in pillow-plate heat exchangers are rather low, although their strong turbulent mixing enables high convective heat transfer coefficients. Full article

This study discusses the main features of the irradiation of prospective multilayer coatings by VUV/UV radiation from compressed plasma flows. Such radiation is characterized by a broadband spectrum and high brightness fluxes. Oxide and Mo/Si bilayers were used as the basis of the reflective multilayers for the visible and UV ranges. A gas-dynamic response from the irradiated surfaces was studied with schlieren photography. The properties of original and irradiated multilayers were described with ultra violet visible infrared spectroscopy (UV-Vis-IR), X-ray diffraction (XRD), X-ray reflectometry, scanning electron microscopy (SEM) and other techniques. Data on the degradation of optical properties and surface morphology were obtained. Full article

This work explores several low-cost methods for the visualization and analysis of pulsed synthetic jets for cooling applications. The visualization methods tested include smoke, Schlieren imaging, and thermography. The images were analyzed using Proper Orthogonal Decomposition (POD) and numerical methods for videos. The results indicated that for the specific nozzle studied, the optimal cooling occurred at a frequency of 80 Hz, which also corresponded to the highest energy in the POD analysis. The combination of Schlieren photography and POD is a unique contribution as a method for the optimization of synthetic jets. Full article

The explosion-suppression effects of NSSs on overpressures, flame propagation and flame tip velocities were explored under the initial pressures of 0.2 MPa, 0.3 MPa and 0.4 MPa. All experiments tested in a constant volume combustion bomb (CVCB). Explosion reaction of premixed propane–air gas in a new designed CVCB filled with nonmetallic spherical spacers (NSSs) was analyzed. The results showed that overpressures decreased under the different initial pressures. With the increase of filling density, the overpressure decreased, the time to reach explosion overpressure decreased, and the decay rate of explosion overpressure increased. It was also found that the explosion-suppression effects of NSSs on pressures. Flame front could be captured by high-speed schlieren photography. Combustion phenomena were captured including flame propagation, corrugated laminar flame, jet flame, corrugated turbulent flame as well as tulip flame under different initial pressures. Flame tip velocities also were captured. The results demonstrate that flame tip velocities decreased with the increase of filling densities. However, compared with unfilled CVCB, flame tip velocities increased after filling NSSs in CVCB under different initial pressures. NSSs suppressed the explosion overpressure in the cylinder, and promoted the flame propagation. In both cases, NSSs played a dual role. The suppression effect of NSSs was affected by both its suppression and promotion effect on the explosion. This work provides a scientific basis for the effective prevention of explosion accidents with propane–air premixtures and the development of explosion-suppression products. Full article

This research studies the macroscopic spray structure from a single-hole common rail diesel injector using gasoline-blended 5% biodiesel for use in compression ignition engines. To reduce the NO_X/PM trade-off emissions, researchers are investigating gasoline used in compression ignition engines, called gasoline compression ignition. As a result that gasoline is injected directly into the combustion chamber, its spray field has a significant effect on combustion and emissions. Due to its low lubricity, gasoline is blended with biodiesel 5%, as a lubricity enhancer, to prevent the failure of the high-pressure injection system. The macroscopic spray structures of this gasoline blend were investigated Schlieren photography and planar laser-induced fluorescence-particle image velocimetry. Injection pressure was handled by a conventional common rail system, while ambient pressure was controlled by supplying nitrogen into the constant-volume combustion chamber. The effects of injection pressure and ambient pressure on the gasoline spray elucidated by Planar laser-induced fluorescence coupled with particle-image velocimetry (PLIF-PIV) imagery and comparisons with variations in neat diesel spray. In addition, the flow field of gasoline spray that formed vortexes and vorticity was characterized. The results show that the injection pressure and back pressure had the same effects on the gasoline spray structure, in terms of the penetration tip and cone angle, as on the diesel spray. However, the injection pressure had a greater effect on the diesel spray than the gasoline at low ambient pressure due to the occurrence of cavitation. Moreover, the images show the remarkable turbulent structure of gasoline spray and indicate air entrainment at the spray tip region. Full article

The simultaneous visualization and characterization of heat transfer processes from hot vibrating objects is a challenging task. This article presents an experimental set-up for the investigation of thermomechanical oscillations in thin cylindrical heaters, allowing us to visualize convection processes using Schlieren photography, infrared photometry, and other methods. It is demonstrated that heat transfer considerably changes in the regions of parametric instability. Full article

A shock wave impact study on open and closed cell foam obstacles was completed to assess attenuation effects with respect to different front face geometries of the foam obstacles. Five different types of geometries were investigated, while keeping the mass of the foam obstacle constant. The front face, i.e., the side where the incident shock wave impacts, were cut in geometries with one, two, three or four convergent shapes, and the results were compared to a foam block with a flat front face. Results were obtained by pressure sensors located upstream and downstream of the foam obstacle, in addition to high-speed schlieren photography. Results from the experiments show no significant difference between the five geometries, nor the two types of foam. Full article

In the field of aerospace engineering, the study of the characteristics of vortical flows and their unsteady phenomena finds numerous engineering applications related to improvements in the design of tip devices, enhancement of combustor performance, and control of noise generation. A large amount of work has been carried out in the analysis of the shock wave diffraction around conventional geometries such as sharp and rounded corners, but the employment of splitters with lateral variation has hardly attracted the attention of researchers. The investigation of this phenomenon around two-dimensional wedges has allowed the understanding of the basic physical principles of the flow features. On the other hand, important aspects that appear in the third dimension due to the turbulent nature of the vortices are omitted. The lack of studies that use three-dimensional geometries has motivated the current work to experimentally investigate the evolution of the shock wave diffraction around two splitters with spike-shaped structures for Mach numbers of 1.31 and 1.59. Schlieren photography was used to obtain an insight into the sequential diffraction processes that take place in different planes. Interacting among them, these phenomena generate a complicated turbulent cloud with a vortical arrangement. Full article

Shock/boundary layer interaction (SBLI) is an undesirable phenomenon, occurring in high-speed propulsion systems. The conventional method to manipulate and control SBLI is using a bleed system that involves the removal of a certain amount of mass of the inlet flow to control boundary layer separation. However, the system requires a larger nacelle to compensate the mass loss, larger nacelles contribute to additional weight and drag and reduce the overall performance. This study investigates a novel type of flow control device called micro-ramps, a part of the micro vortex generators (VGs) family that intends to replace the bleed technique. Micro-ramps produce pairs of counter-rotating streamwise vortices, which help to suppress SBLI and reduce the chances of flow separation. Experiments were done at Mach 5 with two micro-ramp models of different sizes. Schlieren photography, surface flow visualization and infrared thermography were used in this investigation. The results revealed the detailed flow characteristics of the micro-ramp, such as the primary and secondary vortices. This helps us to understand the overall flow physics of micro-ramps in hypersonic flow and their application for SBLI control. Full article
