Search Results (15)

Surface plasmon resonance (SPR) is a powerful tool for determining molecular interactions quantitatively. SPR imaging (SPRi) further improves the throughput of SPR technology and provides the spatially resolved capability for observing the molecular interaction dynamics in detail. SPRi is becoming more and more popular in biological and chemical sensing and imaging. However, SPRi suffers from low spatial resolution due to the imperfect optical components and delocalized features of propagating surface plasmonic waves along the surface. Diverse kinds of approaches have been developed to improve the spatial resolution of SPRi, which have enormously impelled the development of the methodology and further extended its possible applications. In this minireview, we introduce the mechanisms for building a high-spatial-resolution SPRi system and present its experimental schemes from prism-coupled SPRi and SPR microscopy (SPRM) to surface plasmonic scattering microscopy (SPSM); summarize its exciting applications, including molecular interaction analysis, molecular imaging and profiling, tracking of single entities, and analysis of single cells; and discuss its challenges in recent decade as well as the promising future. Full article

Soluble programmed death-ligand 1 (sPD-L1) levels vary widely among different stages of tumor development, so the direct quantification of sPD-L1 as a cancer biomarker is useful in cancer diagnosis, prognosis and therapeutic assessment. There is an urgent need for an sPD-L1 detection method with a broad detection range and high sensitivity for monitoring cancer progression and evaluating the effectiveness of immunotherapy in real time. Herein, we have reported an enzyme-free, label-free surface plasmon resonance imaging (SPRi) sensor based on an aptamer/sPD-L1/anti–PD-L1 sandwich structure with gold nanoparticle (AuNP) signal enhancement for the ultrasensitive quantitative measurement of sPD-L1 for the first time. The gold chip of the SPRi sensing platform was modified by DNA aptamers, sPD-L1 was specifically adsorbed on the surface of a DNA aptamer-modified gold chip and then coupled with anti–PD-L1. Thus, the detection of sPD-L1 at different concentrations was realized through the formation of an aptamer/sPD-L1/anti–PD-L1 sandwich structure. We also enhanced the SPR signal via AuNPs to further improve sensor sensitivity. The SPRi sensor is able to measure sPD-L1 within a linear range of 50 pM–10 nM and 100 fM–50 pM, and the minimum detection limit is 19 fM. The sensor is designed to be widely applicable, with better accuracy and reliability for more application scenarios. The prepared SPRi sensor shows great potential in improving the sensitivity of detecting sPD-L1. The proposed method demonstrates the excellent performance of the SPRi sensor and provides a possibility for the establishment of effective clinical assay methods in the future. Full article

Direct optical detection methods such as surface plasmon resonance imaging (SPRi) and photonic-integrated-circuits (PIC)-based biosensors provide a fast label-free detection of COVID-19 antibodies in real-time. Each technology, i.e., SPRi and PIC, has advantages and disadvantages in terms of throughput, miniaturization, multiplexing, system integration, and cost-effective mass production. However, both technologies share similarities in terms of sensing mechanism and both can be used as high-content diagnostics at or near to point of care, where the analyte is not just quantified but comprehensively characterized. This is significant because recent results suggest that not only the antibody concentration of the three isotypes IgM, IgG, and IgA but also the strength of binding (affinity) gives an indication of potential COVID-19 severity. COVID-19 patients with high titers of low affinity antibodies are associated with disease severity. In this perspective, we provide some insights into how SPR and PIC technologies can be effectively combined and complementarily used for a comprehensive COVID-19 severity monitoring. This opens a route toward an immediate therapy decision to provide patients a treatment in an early stage of the infection, which could drastically lowers the risk of a severe disease course. Full article

Non-fluidic array SPR imaging (SPRi) with appropriate biosensors is a new tool for the determination of various biomarkers in body fluids. Numerous biomarkers can be determined without signal enhancement or preliminarily preconcentration. The introduction of a new material solution of the chip may increase the scope of the application of this technique. Solutions with adhesive separating foil and an Ag/Au chip were compared with the previously used two-paint separating polymer and pure gold chip. These solutions were tested using the example of a biosensor for cathepsin D (Cath D), which consisted of pepstatin A (a Cath D inhibitor) immobilized via a cysteamine linker using the NHS/EDC protocol. Four material versions of the Cath D biosensor proved adequate in terms of range of linearity, LOQ, precision and recovery. All four versions of the biosensor were used for the determination of Cath D in the blood serum patients with glioblastoma and control samples, producing very similar results and showing an elevated biomarker concentration in the case of cancer. Therefore, the problem of determining the correct level of Cath D in the serum of healthy individuals has been resolved, correcting literature data which ranged over three orders of magnitude. Full article

Anthrax lethal factor (LF) is one of the enzymatic components of the anthrax toxin responsible for the pathogenic responses of the anthrax disease. The ability to screen multiplexed ligands against LF and subsequently estimate the effective kinetic rates ($k_{on}$ and $k_{off}$) and complementary binding behavior provides critical information useful in diagnostic and therapeutic development for anthrax. Tools such as biolayer interferometry (BLI) and surface plasmon resonance imaging (SPRi) have been developed for this purpose; however, these tools suffer from limitations such as signal jumps when the solution in the chamber is switched or low sensitivity. Here, we present multiplexed antibody affinity measurements obtained by the interferometric reflectance imaging sensor (IRIS), a highly sensitive, label-free optical biosensor, whose stability, simplicity, and imaging modality overcomes many of the limitations of other multiplexed methods. We compare the multiplexed binding results obtained with the IRIS system using two ligands targeting the anthrax lethal factor (LF) against previously published results obtained with more traditional surface plasmon resonance (SPR), which showed consistent results, as well as kinetic information previously unattainable with SPR. Additional exemplary data demonstrating multiplexed binding and the corresponding complementary binding to sequentially injected ligands provides an additional layer of information immediately useful to the researcher. Full article

The array SPR imaging (SPRi) technique is well suited to the determination of biomarkers in body fluids, called liquid biopsy. No signal enhancement or analyte preconcentration is required. With the aim of achieving signal enhancement and lowering the cost of a single determination, the replacement of gold-covered chips by silver–gold chips was investigated. The aim of this work was to investigate the analytical characteristics of a biosensor formed on a Ag/Au chip and to compare them with those of a biosensor formed on a gold chip. A biosensor for the determination of cathepsin S (Cath S) was chosen as an example. The biosensor consisted of the linker cysteamine and an immobilized rat monoclonal antibody specific for cathepsin S. Both biosensors exhibited a Langmuirian response to Cath S concentration, with linear response ranging from LOQ to 1.5 ng mL⁻¹. The LOQ is 0.1 ng mL⁻¹ for the biosensor formed on the Ag/Au chip, and 0.22 ng mL⁻¹ for that formed on the gold chip. Recoveries and precision for medium and high Cath S concentrations were acceptable for both biosensors, i.e., precision better than 10% and recoveries within the range 102–105%. However, the results for the lowest Cath S concentration were better for the biosensor formed on the Ag/Au chip (9.4 and 106% for precision and recovery, respectively). Generally, no significant differences in analytical characteristics were observed between the Ag/Au and Au chips. The two biosensors were also compared in the determination of Cath S in real samples. Nine plasma samples from healthy donors and nine from patients with ovarian cancer were analyzed for Cath S concentration with the biosensors formed on Ag/Au and Au chips. The results obtained with the two biosensors were very similar and show no significant differences on the Bland–Altman plot. The Cath S concentration in the blood plasma of ovarian cancer patients was elevated by one order of magnitude as compared with the control (12.6 ± 3.6 vs. 1.6 ± 1.2 ng mL⁻¹). Full article

This review aims to summarize the recent advances and progress of plasmonic biosensors based on patterned plasmonic nanostructure arrays that are integrated with microfluidic chips for various biomedical detection applications. The plasmonic biosensors have made rapid progress in miniaturization sensors with greatly enhanced performance through the continuous advances in plasmon resonance techniques such as surface plasmon resonance (SPR) and localized SPR (LSPR)-based refractive index sensing, SPR imaging (SPRi), and surface-enhanced Raman scattering (SERS). Meanwhile, microfluidic integration promotes multiplexing opportunities for the plasmonic biosensors in the simultaneous detection of multiple analytes. Particularly, different types of microfluidic-integrated plasmonic biosensor systems based on versatile patterned plasmonic nanostructured arrays were reviewed comprehensively, including their methods and relevant typical works. The microfluidics-based plasmonic biosensors provide a high-throughput platform for the biochemical molecular analysis with the advantages such as ultra-high sensitivity, label-free, and real time performance; thus, they continue to benefit the existing and emerging applications of biomedical studies, chemical analyses, and point-of-care diagnostics. Full article

Gold nanoparticles (AuNPs) display surface plasmon resonance (SPR) as a result of their irradiation at a targeted light frequency. SPR also results in heat production that increases the temperature of the surrounding environment, affecting polymerization. The aim was to investigate the SPR effect of AuNPs on a dimethacrylate-based photopolymer system. The tested composites were designed to overlap the illumination required for the polymerization and the plasmon effect. The 5 nm-sized dodecanethiol capped AuNPs were applied in different concentrations in the matrix that were irradiated with green light (λ = 532 nm), where the Irgacure 784 photoinitiator also absorbs the light. The plasmonic effect was investigated for the refractive index change by surface plasmon resonance imaging (SPRi) supplemented by ellipsometry. Moreover, optical transmission and transmission electron micrographs (TEM), diametral tensile stress (DTS), and confocal Raman spectroscopy was performed to determine the degree of conversion (DC) at 1.0, 1.4, and 2.0 mW/cm² light intensities. It was found that the optimal conditions were at 0.0208 wt% AuNPs concentration and 1.4 mW/cm² light intensity at which the refractive index change, DTS, and DC data were all maximal. The study confirmed that AuNPs are applicable to improve the polymerization efficiency of dental composite resin. Full article

Label-free evaluation and monitoring of living cell conditions or functions by means of chemical and/or physical sensors in a real-time manner are increasingly desired in the field of basic research of cells and clinical diagnosis. In order to perform multi-parametric analysis of living cells on a chip, we here developed a surface plasmon resonance (SPR) imaging (SPRI)-impedance sensor that can detect both refractive index (RI) and impedance changes on a sensor chip with comb-shaped electrodes. We then investigated the potential of the sensor for label-free and real-time analysis of living cell reactions in response to stimuli. We cultured rat basophilic leukemia (RBL)-2H3 cells on the sensor chip, which was a glass slide coated with comb-shaped electrodes, and detected activation of RBL-2H3 cells, such as degranulation and morphological changes, in response to a dinitro-phenol-conjugated human serum albumin (DNP-HSA) antigen. Moreover, impedance analysis revealed that the changes of impedance derived from RBL-2H3 cell activation appeared in the range of 1 kHz–1 MHz. Furthermore, we monitored living cell-derived RI and impedance changes simultaneously on a sensor chip using the SPRI-impedance sensor. Thus, we developed a new technique to monitor both impedance and RI derived from living cells by using a comb-shaped electrode sensor chip. This technique may enable us to clarify complex living cell functions which affect the RI and impedance and apply this to medical applications, such as accurate clinical diagnosis of type I allergy. Full article

The surface plasmon resonance (SPR) sensor is an important tool widely used for studying binding kinetics between biomolecular species. The SPR approach offers unique advantages in light of its real-time and label-free sensing capabilities. Until now, nearly all established SPR instrumentation schemes are based on single- or several-channel configurations. With the emergence of drug screening and investigation of biomolecular interactions on a massive scale these days for finding more effective treatments of diseases, there is a growing demand for the development of high-throughput 2-D SPR sensor arrays based on imaging. The so-called SPR imaging (SPRi) approach has been explored intensively in recent years. This review aims to provide an up-to-date and concise summary of recent advances in SPRi. The specific focuses are on practical instrumentation designs and their respective biosensing applications in relation to molecular sensing, healthcare testing, and environmental screening. Full article

A gold-silver alloy film based spectral surface plasmon resonance imaging (SPRi) sensor has been prepared for in-situ quantitative detection of biochemical analytes at the sensor surface. This novel sensor has lower detection cost yet higher sensitivity relative to the conventional counterpart with a gold film. Using the laboratory-made multifunctional SPR sensing platform, both the resonant color images and the resonant spectra for the Au-Ag alloy film were measured at different incident angles. The quantitative relationship between the resonant wavelength and the average hue of corresponding resonant color image was established. With this relationship the most hue-sensitive spectral range was determined. After setting the initial resonant wavelength in the hue-sensitive spectral range, the refractive-index sensitivity of the Au-Ag alloy film based SPRi sensor was measured as Δhue/Δn_c = 29,879/RIU, being 8 times higher than that obtained with the gold-film SPRi sensor. The immunodetection of benzo(a)pyrene (BaP) in water was fulfilled using the Au-Ag alloy film based SPRi sensor. The average hue of the SPR color image linearly increases with increasing the BaP concentration up to C = 0.5 μg/L and the slope is Δhue/ΔC = 132.2/(μg/L). The sensor is responsive to a change of BaP concentration as low as ΔC = 0.01 μg/L. Full article

SPR cytometry entails the measurement of parameters from intact cells using the surface plasmon resonance (SPR) phenomenon. Specific real-time and label-free binding of living cells to sensor surfaces has been made possible through the availability of SPR imaging (SPRi) instruments and researchers have started to explore its potential in the last decade. Here we will discuss the mechanisms of detection and additionally describe the problems and issues of mammalian cells in SPR biosensing, both from our own experience and with information from the literature. Finally, we build on the knowledge and applications that has already materialized in this field to give a forecast of some exciting applications for SPRi cytometry. Full article

In this paper we review the underlying principles of the surface plasmon resonance (SPR) technique, particularly emphasizing its advantages along with its limitations regarding the ability to discriminate between the specific binding response and the interfering effects from biological samples. While SPR sensors were developed almost three decades, SPR detection is not yet able to reduce the time-consuming steps of the analysis, and is hardly amenable for miniaturized, portable platforms required in point-of-care (POC) testing. Recent advances in near-field optics have emerged, resulting in the development of SPR imaging (SPRi) as a powerful optical, label-free monitoring tool for multiplexed detection and monitoring of biomolecular events. The microarrays design of the SPRi chips incorporating various metallic nanostructures make these optofluidic devices more suitable for diagnosis and near-patient testing than the traditional SPR sensors. The latest developments indicate SPRi detection as being the most promising surface plasmon-based technique fulfilling the demands for implementation in lab-on-a-chip (LOC) technologies. Full article

Surface plasmon resonance (SPR) is a label-free detection method which has emerged during the last two decades as a suitable and reliable platform in clinical analysis for biomolecular interactions. The technique makes it possible to measure interactions in real-time with high sensitivity and without the need of labels. This review article discusses a wide range of applications in optical-based sensors using either surface plasmon resonance (SPR) or surface plasmon resonance imaging (SPRI). Here we summarize the principles, provide examples, and illustrate the utility of SPR and SPRI through example applications from the biomedical, proteomics, genomics and bioengineering fields. In addition, SPR signal amplification strategies and surface functionalization are covered in the review. Full article

Non-invasive real-time observations and the evaluation of living cell conditions and functions are increasingly demanded in life sciences. Surface plasmon resonance (SPR) sensors detect the refractive index (RI) changes on the surface of sensor chips in label-free and on a real-time basis. Using SPR sensors, we and other groups have developed techniques to evaluate living cells’ reactions in response to stimuli without any labeling in a real-time manner. The SPR imaging (SPRI) system for living cells may visualize single cell reactions and has the potential to expand application of SPR cell sensing for clinical diagnosis, such as multi-array cell diagnostic systems and detection of malignant cells among normal cells in combination with rapid cell isolation techniques. Full article
