This paper presents a method for optimizing the inertia constants and damping coefficients of interconnected virtual synchronous generators (VSGs) using a genetic algorithm. The goal of optimization is to find a balance between minimizing the rate of change of frequency (RoCoF) and enhancing controllability. Five controllability-based metrics are tested: the minimum eigenvalue, the sum of the two smallest eigenvalues, the maximum eigenvalue, the trace, and the determinant of the controllability Gramian matrix. The approach includes the oscillatory modes’ damping ratio constraints to ensure the small-signal stability of the entire system. The results of optimization on the IEEE 9-bus system with three VSGs show that the proposed method improves controllability, reduces RoCoF, and maintains the desired oscillation damping. The proposed approach was tested through time-domain simulations. Full article

The integration of renewable energy sources (RESs) into power systems, particularly in microgrids, is becoming a prominent trend aimed at reducing dependence on traditional energy sources. Replacing conventional synchronous generators with grid-connected RESs through power electronic converters has significantly reduced the inertia of microgrids. This reduction negatively impacts the dynamics and operational performance of microgrids when confronted with uncertainties, posing challenges to frequency and voltage stability, especially in a standalone operating mode. To address this issue, this research proposes enhancing microgrid stability through frequency control based on virtual inertia (VI). Additionally, the Iterative Learning Control (ILC) method is employed, leveraging iterative learning strategies to improve the quality of output response control. Accordingly, the ILC-VI control method is introduced, integrating the iterative learning mechanism into the virtual inertia controller to simultaneously enhance the system’s inertia and damping coefficient, thereby improving frequency stability under varying operating conditions. The effectiveness of the ILC-VI method is evaluated in comparison with the conventional VI (C-VI) control method through simulations conducted on the MATLAB/Simulink platform. Simulation results demonstrate that the ILC-VI method significantly reduces the frequency nadir, the rate of change of frequency (RoCoF), and steady-state error across iterations, while also enhancing the system’s robustness against substantial variations from renewable energy sources. Furthermore, this study analyzes the effects of varying virtual inertia values, shedding light on their role in influencing response quality and convergence speed. This research underscores the potential of the ILC-VI control method in providing effective support for low-inertia microgrids. Full article

An intuitive method for estimating the inertia contribution from residual sources, such as induction motors and inverter-based power electronic facilities, in the Korea Electric Power Corporation (KEPCO) system is proposed. First, the method utilizes synchronized Phasor Measurement Units (PMUs) to obtain the measured system Rate of Change of Frequency (RoCoF) following an instantaneous power imbalance. Subsequently, the estimated system RoCoF for the same event is derived from simulations of the full dynamic model of the KEPCO system using Energy Management System (EMS) data. The estimated RoCoF accounts only for the inertia contribution from synchronous generators, as the dynamic model includes only these generators. The residual inertia of the entire power system is then estimated based on the ratio of the estimated RoCoF to the measured RoCoF, using the known inertia contribution from synchronous generators. The effectiveness of the proposed method is validated through dynamic simulations of the KEPCO system and demonstrated using real PMU and EMS data from actual disturbance events. The results illustrate that residual inertia was estimated at approximately 160 GW during daytime and around 67 GW during nighttime, indicating substantial variation in absolute terms. This finding highlights the importance of considering residual inertia contributions, particularly under varying load conditions. Full article

Focused on the contradiction between the steady-state error of active power and the dynamic oscillation caused by the virtual damping characteristics of the virtual synchronous generator (VSG) under disturbances during grid-connected operation, this article proposes an adaptive virtual inertia regulation and compensation method (PFFCVSG_AJ) based on an active power differential feedforward compensation strategy (PFFCVSG). Firstly, this article presents the working and control principles of VSG, analyzing its control mechanisms through a small-signal model. Models for VSG’s active power, reactive power, and virtual impedance components are established, with particular focus on the impact of the damping coefficient on active power regulation. Based on the PFFCVSG, an adaptive virtual inertia adjustment method is introduced to resolve the inherent inertia deficiency in PFFCVSG control, the influence of the moment of inertia on PFFCVSG is theoretically analyzed, and a dynamic adjustment mechanism for moment of inertia is developed based on the rate of change in frequency (RoCoF). Finally, simulation validation using MATLAB/Simulink (MathWorks, R2022b, Natick, MA, USA) demonstrates that the proposed PFFCVSG_AJ strategy effectively eliminates active power steady-state deviation, suppresses active power dynamic oscillation, and mitigates the frequency overshoot issue prevalent in traditional PFFCVSG. Experimental verification is conducted via a TMS320F28378DPTPS-based control platform, confirming the algorithm’s effectiveness under sudden load variations, and that the power quality of the power grid is not affected under the premise of efficient grid connection. Full article

With the increasing popularity of low-cost, clean, and environmentally friendly new energy sources, the proportion of grid-connected new energy units has increased significantly. However, since these units are frequency decoupled from the grid through a power electronic interface, they are unable to provide inertia support during active power perturbations, which leads to a decrease in system inertia and reduced frequency stability. In this study, the urgent need to accurately assess inertia is addressed by developing an energy-function-based inertia identification technique that eliminates the effect of damping terms. By integrating vibration mechanics, the proposed method calculates the inertia value after a perturbation using port measurements (active power, voltage phase, and frequency). Simulation results of the Western System Coordinating Council (WSCC) 9-bus system show that the inertia estimation error of the method is less than 1%, which is superior to conventional methods such as rate-of-change-of-frequency (RoCoF) and least squares methods. Notably, the technique accurately evaluates the inertia of synchronous generators and doubly fed induction generators (DFIGs) under virtual inertia control, providing a robust inertia evaluation framework for low-inertia power systems with high renewable energy penetration. This research deepens the understanding of inertial dynamics and contributes to practical applications in grid stability analysis and control strategy optimalization. Full article

Assessing the impact of electric vehicle (EV) integration on power systems is crucial, particularly regarding frequency stability, which often remains largely unaddressed, especially in developing countries. This paper examines the effects of EV penetration on the frequency stability of Curaçao’s power network, an aspect not previously studied for the island. As a key contribution, we present a representative model of Curaçao’s power network, adjusting the dynamic models of the speed governors of synchronous machines, using data available to the academic community. Additionally, we analyze the impacts of EVs on the grid’s frequency stability under different EV participation scenarios. To achieve this, simulations were conducted considering various EV participation scenarios and different types of chargers to assess their impact on grid stability. The study evaluates key frequency stability metrics, including the rate of change of frequency (RoCoF) as well as the highest and lowest frequency values during the transient period. The results indicated that higher EV penetration can significantly impact frequency stability. The observed increase in the RoCoF and frequency zenith values suggests a weakening of the grid’s ability to withstand frequency disturbances, particularly in high-EV-penetration scenarios. Full article

As a typical grid-forming control method, virtual synchronous generator (VSG) control enhances system inertia but introduces frequency oscillation issues. This problem becomes particularly severe in multi-VSG parallel systems when inconsistent virtual inertia exists among power sources, significantly compromising the security and stability of power system operation. Virtual inertia control can directly regulate the rate of change of frequency (RoCoF) under constant torque difference conditions to suppress frequency oscillations, offering faster response characteristics. Therefore, this paper proposes a distributed virtual inertia control strategy for multi-VSG parallel systems. First, a small-signal model of the multi-machine parallel system is established, and its small-signal stability is demonstrated. Second, a neighbor-communication-based distributed virtual inertia coordination control method is proposed. Through neighbor information exchange and local decision-making, this method enables dynamic adjustment of each unit’s virtual inertia, driving frequency synchronization among all units in the system. This effectively suppresses post-disturbance frequency oscillations and enhances the dynamic performance of low-inertia power systems. Furthermore, the stability of the proposed control strategy is rigorously proven through the construction of a Lyapunov energy function. Finally, MATLAB/Simulink simulations verify that the proposed virtual inertia control strategy can effectively mitigate frequency oscillations while reducing their settling time. Full article

To ensure the reliability and security of Colombia’s national power system, there is an ongoing necessity for upgrades in monitoring and protection mechanisms. Approximately sixteen years ago, the introduction of synchrophasor measurements enabled the swift detection of potentially network-detrimental events. Subsequent advancements have seen the deployment of Phasor Measurement Units (PMUs), currently tallying 150 across 25 substations, facilitating real-time monitoring and analysis. The growth of the PMU network is pivotal for the modernization of the National Control Center, particularly in the face of complexities introduced by renewable energy sources. There is an increasing demand for data analytics platforms to support operators in responding to threats. This paper explores the development of the Colombian Wide-Area Measurement System (WAMS) network, highlighting its milestones and advancements. Significant contributions include the technological evolution of the WAMS for real-time monitoring, an innovative high-speed data analytics strategy, and tools for the monitoring of frequency, rate of change of frequency (RoCoF), angular differences, oscillations, and voltage recovery, alongside industry-specific criteria for real-time assessment. Implemented within an operational WAMS, these tools enhance situational awareness, thereby assisting operators in decision-making and augmenting the power system’s reliability, security, and efficiency, underscoring their significance in modernization and sustainability initiatives. Full article

Virtual synchronous generators (VSGs) have been developed to mitigate the increase in the rate of change of frequency (ROCOF) in power systems by replacing synchronous generators (SGs) with inverter-based resources. VSGs mimic the dynamics and control of SGs; however, the mechanical delay typical of an SG’s turbine is often excluded, limiting improvements to the VSG’s response. The fast frequency response (FFR) of VSGs can help reduce ROCOF and enhance emulated inertia. This implies that the effective inertia (EI) of VSGs can exceed the set inertia parameter, posing challenges for operators in allocating sufficient VSG capacity considering the inertia required for stable operation. In this study, we quantitatively analyzed the difference between the EI of a VSG and the set inertia parameter by separating the active power output into inertia and governor responses. The quantitative analysis revealed that when the VSG provides FFR within the inertia-time domain, the EI exceeds the set inertia parameter. Furthermore, the sensitivities of the VSG set parameters and VSG capacity ratio, which is related to synchronizing power coefficients and the initial sharing ratio, for the EI were analyzed. These factors were theoretically considered, and the simulations validated their characteristics. Full article

A power system is never in a steady state due to continuous load variations, disturbances, maneuvers, and the operation of protection systems. A generation deficit causes a frequency drop in the system that must be controlled. If this frequency deviation is not properly managed, it can result in the loss of synchronism between generators and, eventually, lead to a partial or even total system collapse. This article presents a load shedding scheme applied to the IEEE 39-bus New England system. The scheme considers an N-1 contingency space to evaluate the dynamic frequency response, aiming to determine the appropriate settings for low-frequency relays activated by the rate of change of frequency (ROCOF). Full article

Modern power systems are growing in complexity due to the installation of large generators, long transmission lines, the addition of inertialess renewable energy resources (RESs) with zero inertia, etc., which can all severely degrade the system frequency stability. This can lead to under-/over-frequency load shedding, damage to turbine blades, and affect frequency-sensitive loads. In this study, we propose a methodology to improve the two critical frequency stability indices, i.e., the frequency nadir and the rate of change of frequency (RoCoF), by formulating an optimization problem. The size and placement location of battery energy storage systems (BESSs) are considered to be the constraints for the proposed optimization problem. Thereafter, the optimization problem is solved using the three metaheuristic optimization algorithms: the particle swarm optimization, firefly, and bat algorithm. The best performing algorithm is then selected to find the optimal sizing and placement location of the BESSs. The analyses are all performed on the IEEE 9-bus and IEEE 39-bus test systems. Several scenarios which consider multiple generator outages, increased/decreased loading conditions, and the addition of RESs are also considered for both test systems in this study. The obtained results show that under all scenarios, the proposed method can enhance system frequency compared to the existing method and without BESSs. The proposed method can be easily upscaled for a larger electrical network for obtaining the optimized BESS size and location for the improvement of the system frequency stability. Full article

With the continuous development of renewable energy worldwide, the issue of frequency stability in power systems has become increasingly serious. Enhancing the inertia level of power systems by configuring battery storage to provide virtual inertia has garnered significant research attention in academia. However, addressing the non-linear characteristics of frequency stability constraints, which complicate model solving, and managing the uncertainties associated with renewable energy and load, are the main challenges in planning energy storage for high-proportion renewable power systems. In this context, this paper proposes a battery storage configuration model for high-proportion renewable power systems that considers minimum inertia requirements and the uncertainties of wind and solar power. First, frequency stability constraints are transformed into minimum inertia constraints, primarily considering the rate of change of frequency (ROCOF) and nadir frequency (NF) indicators during the transformation process. Second, using historical wind and solar data, a time-series probability scenario set is constructed through clustering methods to model the uncertainties of wind and solar power. A stochastic optimization method is then adopted to establish a mixed-integer linear programming (MILP) model for the battery storage configuration of high-proportion renewable power systems, considering minimum inertia requirements and wind-solar uncertainties. Finally, through a modified IEEE-39 bus system, it was verified that the proposed method is more economical in addressing frequency stability issues in power systems with a high proportion of renewable energy compared to traditional scheduling methods. Full article

This study introduced a novel control approach based on fuzzy logic control (FLC) to enhance the frequency regulation capacity of variable-speed wind turbines (VSWTs). The proposed method integrates FLC within droop and inertia control loops. Real-time measurements of the system frequency and the rate of change of frequency (ROCOF) serve as inputs to the FLC, enabling the method to improve the frequency response by VSWTs. In addition, the method employs FLC for pitch angle frequency control, optimizing reserve power for frequency regulation under varying wind speed levels. The innovative aspect of this study lies in the simultaneous application of FLC to pitch angle frequency control and droop/inertia control, leading to the enhanced frequency regulation capability of VSWTs and smoother operation across a range of wind speeds. Compared with traditional methods, the proposed approach provides a comprehensive and effective solution to the challenges associated with frequency regulation in VSWTs. Through simulations across different wind speed scenarios, the proposed control method demonstrated the best performance among various mature methods, highlighting the efficacy of the proposed method on the frequency regulation of VSWTs under different wind speeds. This study’s findings highlight the potential of the proposed FLC-based method to optimize frequency regulation and contribute to more reliable and efficient wind energy systems. Full article

To achieve an energy sector independent from fossil fuels, a significant increase in the penetration of variable renewable energy sources, such as solar and wind power, is imperative. However, these sources lack the inertia provided by conventional thermo-electric power stations, which is essential for maintaining grid frequency stability. In this study, a grid resembling Madeira Island’s power generation mix was modeled using the Matlab/Simulink platform. The model included solar, wind, hydro, and thermo-electric generation to accurately represent the energy landscape of Madeira Island. Three scenarios were examined: one reflecting the current power generation on Madeira Island, a future scenario with a substantial rise in the percentage of photovoltaic (PV) generation, and the same future scenario but incorporating a battery energy storage system (BESS). Various analyses were conducted to assess the impact on frequency stability during a ground fault and rapid load/generation changes. In the future scenario without a BESS, the thermoelectric power plant generator desynchronized, leading to system collapse in several simulations. However, with the addition of a BESS, a significant improvement in frequency stability was observed. The thermoelectric power plant generator could return to a steady state after each disturbance. Furthermore, both the maximum frequency deviation and the absolute value of the Rate of Change of Frequency (ROCOF) were reduced, indicating enhanced system performance and stability. Full article

Frequency regulation and droop control of doubly fed induction generators (DFIGs) can quickly respond to frequency changes and reduce the maximum rate of frequency (MROFF) in power systems. However, due to real-time dynamic changes in the MPPT control loop, the ability to improve the lowest frequency point is limited. Therefore, this article first describes an in-depth analysis of the dynamic characteristics of the incremental power of frequency regulation with droop control using an equivalent linear model. The limitations of improving the lowest frequency point under the influence of dynamic changes in the MPPT control loop are revealed. Secondly, to address the impact of these dynamics, an improved decoupling frequency regulation (IDFR) strategy based on power tracking is proposed, aiming to increase the maximum frequency deviation (MFD) and MROCOF. Then, in order to overcome the difficulty of adjusting control coefficients in the IDFR strategy, an adaptive control coefficient tuning fuzzy control method based on frequency deviation and ROCOF was proposed to flexibly adjust control requirements under various working conditions, thereby improving the control stability and performance of the system and effectively solving the problem of control coefficient allocation. Finally, to verify the frequency regulation performance of the proposed IDFR strategy under various operating conditions, simulations were conducted based on different disturbances and wind conditions. The results show that the proposed IDFR strategy significantly improves the system MFD and MROCOF improvement ability under various conditions. Full article
