Magnetic shape memory alloys have attracted considerable attention due to their multifunctional properties. Among these materials, Ni-Mn-Ga alloys are distinguished by their ability to achieve up to 10% strain when exposed to a magnetic field, a characteristic predominantly observed in single-crystal samples. Consequently, it is essential to develop nanomaterials with a crystal structure closely resembling that of a single crystal. In this study, an epitaxial Ni-Mn-Ga thin film was fabricated using Pulsed Laser Deposition on an Al₂O₃ $\left(11\overline{2}0\right)$ single-crystal substrate. The crystal structure was characterised through X-ray diffraction methodologies, such as symmetrical $2\theta -\omega$ scans, pole figures, and reciprocal space maps. The results indicated that the sample was mainly in a slightly distorted cubic austenite phase, and some incipient martensite phase also appeared. A detailed microstructural analysis, performed by transmission electron microscopy, confirmed that certain regions of the sample exhibited an incipient transformation to the martensite phase. Regions closer to the substrate retained the austenite phase, suggesting that the constraint imposed by the substrate inhibits the phase transition. These results indicate that it is possible to grow high crystalline quality thin films of Ni-Mn-Ga by Pulsed Laser Deposition. Full article

Polymer-assisted deposition (PAD) has been widely used in the preparation of high-quality oxides and sulfides for basic research and applications. Specifically, diverse PAD-prepared magnetic material thin films such as ZnO, Ga₂O₃, SrRuO₃, LaCoO₃, LaMnO₃, Y₃Fe₅O₁₂, MoS₂, MoSe₂, and ReS₂ thin films have been grown, in which thickness-dependent, strain-modulated, doping-mediated, and/or morphology-dependent room-temperature ferromagnetism (RTFM) have been explored. Inspired by the discovery of intrinsic low-temperature FM in two-dimensional (2D) systems prepared using mechanical exfoliation, the search for more convenient methods to prepare 2D ferromagnetic materials with high-temperature FM has seen explosive growth, but with little success. Fortunately, the very recent synthesis of 2D NiO by PAD has shed light on this challenge. Based on these abovementioned developments, the difficulties of PAD when preparing a-few-nanometer single-crystalline materials and the opportunities in PAD for novel materials such as chiral magnetic soliton material Cr_1/3NbS₂ are discussed. Full article

We present the design, simulation, and characterization of a magnetic shape-memory alloy (MSMA) film actuator that transitions from bistable switching to resonant self-actuation when subjected to a stationary heat source. The actuator design comprises two Ni-Mn-Ga films of 10 µm thickness integrated at the front on either side of an elastic cantilever that moves freely between two heatable miniature permanent magnets and, thus, forms a bistable microswitch. Switching between the two states is induced by selectively heating the MSMA films above their Curie temperature Tc. When continuously heating the permanent magnets above Tc, the MSMA film actuator exhibits an oscillatory motion in between the magnets with large oscillation stroke in the frequency range of 50–60 Hz due to resonant self-actuation. A lumped-element model (LEM) is introduced to describe the coupled thermo-magnetic and magneto-mechanical performance of the actuator. We demonstrate that this performance can be used for the thermomagnetic energy generation of low-grade waste heat (T < 150 °C) with a high power output per footprint in the order of 2.3 µW/cm². Full article

In this work, dewetting process has been investigated in shape-memory Heuslers. To this aim, series of high-temperature annealing (1100–1150 K) have been performed at high vacuum (time is varied in the range of 55–165 min) in Ni-Mn-Ga epitaxial thin films grown on MgO(001). The process kinetics have been followed by studying the evolution of morphology and composition. In particular, we report the initiation of the dewetting process by the formation of symmetric holes in the films. The holes propagate and integrate, leaving micrometric and submicron islands of the material, increasing the average roughness of the films by a factor of up to around 30. The dewetting process is accompanied by severe Ga and Mn sublimation, and Ni-Ga segregation, which significantly modify the magnetic properties of the films measured at each stage. The annealed samples show a relatively weak magnetic signal at room temperature with respect to the pristine sample. Full article

Epitaxial Ni-Mn-Ga thin films have been extensively investigated, due to their potential applications in magnetic micro-electro-mechanical systems. It has been proposed that the martensitic phase in the <1 1 0>_A-oriented film is much more stable than that in the <1 0 0>_A-oriented film. Nevertheless, the magnetic properties, microstructural features, and crystal structures of martensite in such films have not been fully revealed. In this work, the <1 1 0>_A-oriented Ni_51.0Mn_27.5Ga_21.5 films with different thicknesses were prepared by epitaxially growing on Al₂O₃(1 1 $\overline{2}$ 0) substrate by magnetron sputtering. The characterization by X-ray diffraction technique and transmission electron microscopy revealed that all the Ni_51.0Mn_27.5Ga_21.5 films are of 7M martensite at the ambient temperature, with their Type-I and Type-II twinning interfaces nearly parallel to the substrate surface. Full article

A multi-principal element FeMnNiAlC₁₀ bulk alloy was produced by vacuum arc melting. The same alloy was sintered as a thin film on a silicon substrate by ion beam sputter deposition. The bulk alloy has a multiphase structure the elements predominantly segregating into iron manganese carbides and nickel aluminium phases. The thin film is amorphous without detectable phase segregations. The absence of segregation is attributed to the film composition and deposition onto substrate at temperature below 400 K. The corrosion resistance of the thin film alloy was evaluated in 3.5% NaCl. The FeMnNiAlC₁₀ thin film alloy has better corrosion resistance than 304SS. The hardness of the thin film was approximately 7.2 ± 0.3 GPa and the reduced Young’s modulus was approximately 103 ± 4.6 GPa. FeMnNiAlC₁₀ thin film could be a good candidate for coating oil and gas extraction soft iron infrastructure. Full article

Rapid progress in material science and nanotechnology has led to the development of the shape memory alloys (SMA) and the shape memory polymers (SMP) based functional multilayered structures that, due to their capability to achieve the properties not feasible by most natural materials, have attracted a significant attention from the scientific community. These shape memory materials can sustain large deformations, which can be recovered once the appropriate value of an external stimulus is applied. Moreover, the SMAs and SMPs can be reprogrammed to meet several desired functional properties. As a result, SMAs and SMPs multilayered structures benefit from the unprecedented physical and material properties such as the shape memory effect, superelasticity, large displacement actuation, changeable mechanical properties, and the high energy density. They hold promises in the design of advanced functional micro- and nano-electro-mechanical systems (MEMS/NEMS). In this review, we discuss the recent understanding and progress in the fields of the SMAs and SMPs. Particular attention will be given to the existing challenges, critical issues, limitations, and achievements in the preparation and characterization of the SMPs and NiTi-based SMAs thin films, and their heterostructures for MEMS/NEMS applications including both experimental and computational approaches. Examples of the recent MEMS/NEMS devices utilizing the unique properties of SMAs and SMPs such as micropumps, microsensors or tunable metamaterial resonators are highlighted. In addition, we also introduce the prospective future research directions in the fields of SMAs and SMPs for the nanotechnology applications. Full article

In this paper, the surface properties of bare and film-covered gallium nitride (GaN) in wurtzite form, (0001) oriented, are summarized. Thin films of several elements—manganese, nickel, palladium, arsenic, and antimony—were formed by the physical vapor deposition method. The results of the bare surfaces, as well as the thin film/GaN(0001) phase boundaries presented, were characterized by X-ray and ultraviolet photoelectron spectroscopies (XPS, UPS). Basic information on the electronic properties of GaN(0001) surfaces are shown. Different behaviors of the thin films, after postdeposition annealing in ultrahigh vacuum conditions such as surface alloying and subsurface dissolving and desorbing, were found. The metal films formed surface alloys with gallium (MnGa, NiGa, PdGa), while the semimetal (As, Sb) layers easily evaporate from the GaN(0001) surface. However, the layer in direct contact with the substrate could react with it, modifying the surface properties of GaN(0001). Full article

In this review article, we conceptually investigated the requirements of magnetic nanoparticles for their application in biosensing and related them to example systems of our thin-film portfolio. Analyzing intrinsic magnetic properties of different magnetic phases, the size range of the magnetic particles was determined, which is of potential interest for biosensor technology. Different e-beam lithography strategies are utilized to identify possible ways to realize small magnetic particles targeting this size range. Three different particle systems from 500 μm to 50 nm are produced for this purpose, aiming at tunable, vertically magnetized synthetic antiferromagnets, martensitic transformation in a single elliptical, disc-shaped Heusler Ni₅₀Mn_32.5Ga_17.5 particle and nanocylinders of Co₂MnSi-Heusler compound. Perspectively, new applications for these particle systems in combination with microfluidics are addressed. Using the concept of a magnetic on–off ratchet, the most suitable particle system of these three materials is validated with respect to magnetically-driven transport in a microfluidic channel. In addition, options are also discussed for improving the magnetic ratchet for larger particles. Full article

In this paper, the surface properties of bare and film-covered gallium nitride (GaN) of the wurtzite form, (0001) oriented are summarized. Thin films of several elements—manganese, nickel, arsenic and antimony—are formed by the physical vapour deposition method. The results of the bare surfaces as well as the thin film/GaN(0001) phase boundaries presented are characterized by X-ray and ultraviolet photoelectron spectroscopies (XPS, UPS). Basic information about electronic properties of GaN(0001) surfaces are shown. Different behaviours of thin films after post-deposition annealing in ultrahigh vacuum conditions, such as surface alloying, subsurface dissolving and desorbing, are found. The metal films form surface alloys with gallium (NiGa, MnGa), while the semi-metal (As, Sb) layers easily evaporate from the GaN(0001) surface. However, the layer in direct contact with the substrate can react with it modifying the surface properties of GaN(0001). Full article

Magnetic shape memory Heuslers have a great potential for their exploitation in next-generation cooling devices and actuating systems, due to their “giant” caloric and thermo/magnetomechanical effects arising from the combination of magnetic order and a martensitic transition. Thermal hysteresis, broad transition range, and twinning stress are among the major obstacles preventing the full exploitation of these materials in applications. Using Ni-Mn-Ga seven-modulated epitaxial thin films as a model system, we investigated the possible links between the phase transition and the details of the twin variants configuration in the martensitic phase. We explored the crystallographic relations between the martensitic variants from the atomic-scale to the micro-scale through high-resolution techniques and combined this information with the direct observation of the evolution of martensitic twin variants vs. temperature. Based on our multiscale investigation, we propose a route for the martensitic phase transition, in which the interfaces between different colonies of twins play the major role of initiators for both the forward and reverse phase transition. Linking the martensitic transition to the martensitic configuration sheds light onto the possible mechanisms influencing the transition and paves the way towards microstructure engineering for the full exploitation of shape memory Heuslers in different applications. Full article

Heusler type Ni-Mn-Ga ferromagnetic shape memory alloys can demonstrate excellent magnetic shape memory effect in single crystals. However, such effect in polycrystalline alloys is greatly weakened due to the random distribution of crystallographic orientation. Microstructure optimization and texture control are of great significance and challenge to improve the functional behaviors of polycrystalline alloys. In this paper, we summarize our recent progress on the microstructure control in polycrystalline Ni-Mn-Ga alloys in the form of bulk alloys, melt-spun ribbons and thin films, based on the detailed crystallographic characterizations through neutron diffraction, X-ray diffraction and electron backscatter diffraction. The presented results are expected to offer some guidelines for the microstructure modification and functional performance control of ferromagnetic shape memory alloys. Full article
