Conventional synchronous grouting materials often exhibit low early strength, delayed setting, and insufficient utilization of excavated soil, hindering the green and efficient advancement of metro shield tunneling technology. To overcome these challenges, this study developed a high-performance grouting material by utilizing shield muck—primarily composed of quartz (71.47%) and calcite (15.3%)—as the main raw material, with sodium trimethylsilanolate (TMS-Na) introduced as a performance enhancer. Through orthogonal experiments and range analysis, the influences of cement content, slag content, and TMS-Na dosage on the workability and mechanical properties of synchronous grouting materials were systematically evaluated. Microstructural evolution was characterized using scanning electron microscopy (SEM), X-ray diffraction (XRD), Fourier-transform infrared spectroscopy (FTIR), thermogravimetric (TG) analysis, and mercury intrusion porosimetry (MIP) to elucidate the mechanism by which TMS-Na modifies the grout microstructure. The results demonstrate that incorporating 8% slag and 0.2% TMS-Na increases the utilization rate of shield muck to 60.8%. Compared with conventional grouts, the novel material exhibits approximately 97.4% and 93.3% enhancements in 3-day and 28-day compressive strength, respectively, alongside an impermeability grade reaching P10. The addition of slag improves the apparent density and early strength of the grout, although its contribution diminishes at later ages. TMS-Na effectively activates the hydration reactivity of slag, accelerates early hydration, reduces the setting time, and participates in a secondary hydration reaction with argillaceous siltstone present in the excavated soil, promoting the formation of additional calcium silicate hydrate (C-S-H). This process densifies the hardened grout matrix, refines the pore structure, and significantly enhances both mechanical performance and impermeability. Field application in a trial tunnel section confirms that the proposed grouting material achieves complete cavity filling, eliminates water leakage, controls ground deformation effectively, and offers favorable economic viability, demonstrating strong potential for large-scale engineering application. Full article

The Wanning Bridge is a critical component of Beijing’s Central Axis World Heritage site and the only Yuan Dynasty heritage bridge in Beijing still in service. Investigating its structural response under complex traffic conditions is therefore essential for ensuring the longevity of this ancient structure and the safety of the urban transport system. However, the application of traditional research methods, such as direct sampling, is often constrained by the cultural relic characteristics of heritage bridges. This study first conducted a macroscopic on-site survey to document its current appearance and global geometry. Subsequently, more accurate geometric and material parameters of the bridge were acquired through non-destructive testing techniques including 3D laser scanning, ground-penetrating radar, and ultrasonic testing. Subsequently, using a combined approach of experimental and numerical simulation, this study reveals key structural responses and damage conditions of the bridge through static, dynamic, and metro-induced vibration tests. Dynamic tests show a maximum deformation of 0.26 mm and a natural frequency of 10.547 Hz, indicating shear strain accumulation as the primary damage driver. Subway-induced vibrations are well within the safety limits for stone relics, and the structure’s current load-bearing capacity complies with Class-II highway standards. Full article

The alkali-activated composites technique is a promising method for the in situ preparation of cavity filling/grouting materials from engineering waste soil. To investigate the feasibility of engineering waste soil utilization by the alkali activation process, the macroscopic and microscopic properties of the fly ash/slag-based alkali-activated composites, after solidification/stabilization (S/S) with sandy clay excavated at Baishitang Station of Shenzhen Metro, were studied. The unconfined compressive strength (UCS) test was conducted to evaluate the S/S effect of alkali-activated composites. The results show that the optimum quality ratio of slag and fly ash correspond to 7:3, the modulus of alkaline activator to 1.3, and the alkalinity of alkaline activator to 10%. The alkali-activated composite’s strength under these parameters can reach 45.25 MPa at 3 days, 49.85 MPa at 7 days, and 62.33 MPa at 28 days. A maximum 3-day UCS of 21.71 MPa, 75% of the 28-day UCS, was achieved by an engineering waste soil and alkali-activated composites mass ratio of 5:5, slaked lime content of 4.5%, and a water-to-solid ratio of 0.26, and it can also meet the required fluidity and setting time for construction well. Fluidity is primarily affected by the soil-to-binder ratio, which decreases as the ratio decreases, while the water-to-solid ratio increases fluidity. Slaked lime has minimal impact on fluidity. The setting time is mainly influenced by the soil-to-binder ratio, followed by slaked lime content and water-to-solid ratio, with setting time shortening as the soil-to-binder ratio and slaked lime content increase, and lengthening as the water-to-solid ratio increases. Through Fourier Transform Infrared Spectroscopy (FTIR), Scanning Electron Microscopy (SEM), and Energy Dispersive Spectroscopy (EDS) tests, microscopic analysis showed that loose granular units are firmly cemented by alkali-activated composites. Based on the results of on-site grouting tests in karst caves, the alkali-activated grout materials reached a strength of 5.2 MPa 28 days after filling, which is 162.5% of the strength of cement grouting material, satisfying most of the requirements for cavity filling in Shenzhen. Full article

In shield tunneling, the joint is one of the most vulnerable parts of the segmental lining. Opening of the joint reduces the overall stiffness of the ring, leading to structural damage and issues such as water leakage. Currently, the Winkler method is commonly used to calculate structural deformation, simplifying the interaction between segments and soil as radial and tangential Winkler springs. However, when introducing connection springs or reduction factors to simulate the joint stiffness of segments, the challenge lies in determining the reduction coefficient and the stiffness of the springs. Currently, the hyperstatic reflection method cannot simulate the discontinuity effect at the connection of the tunnel segments, while the state space method overlooks the nonlinear interaction between the tunnel and the soil. Therefore, this paper proposes a numerical simulation method considering the interaction between the tunnel and the soil, which is subjected to compression rather than tension, and the discontinuity of the joints between the segments. The model structure and external load are symmetrical, resulting in symmetrical calculation results. This method is based on the soft soil layers and shield tunnel structures of the Shanghai Metro, and the applicability of the model is verified through deformation calculations using three-dimensional laser scanning point clouds of sections from the Shanghai Metro Line 5. When the subgrade reaction coefficient is 5000 $\mathrm{k}\mathrm{N}/{\mathrm{m}}^3$, the model can effectively simulate the deformation of operational tunnels. By adjusting the bending stiffness of individual connection springs, we investigate the influence of bending stiffness reduction on the bending moment, radial displacement, and rotational displacement of the ring. The results indicate that a decrease in joint bending stiffness significantly affects the mechanical response of the ring, and the extent and degree of this influence are correlated with the joint position and the magnitude of joint bending stiffness. Full article

Acrylate is a popular polymer grouting material that has been widely used to control groundwater seepage. However, the vulnerability of acrylate slurry to dynamic water washout restricts its application in groundwater environments characterized by high flow velocity and water pressures. In this paper, lithium bentonite (Li-B) was used to modify the traditional magnesium acrylate (AC) grouting material. The influence of Li-B to AC ratios on the modified materials’ washout resistance was explored, and the modification mechanism was analyzed using X-ray diffraction (XRD), infrared spectroscopy (IR), and scanning electron microscopy (SEM). Finally, the anti-washout ability of the modified slurry was verified through engineering applications. Results revealed that LiB-AC grout had adjustable setting times (10.5 to 395.6 s), minimal bleeding (0.1%), higher viscosity (65 mPa·s) and expansibility (350%), stronger anti-water dispersibility (24 times that of pure AC slurry), higher mechanical strength (compressive strength is 0.386 MPa, tensile strength is 0.088 MPa), and better impermeability (2.23 × 10⁻⁸ m/s). The lithium bentonite was beneficial to the setting time, bleeding, viscosity, slurry retention rate, impermeability, and mechanical strength of the acrylate grout. However, it diminished the expansibility of the acrylate grout. At the optimal acrylate content (20%), the mechanical strength and impermeability of the LiB-AC grout were the highest. The better performance of LiB-AC grout was attributed to the formation of a more stable and dense interlaced spatial network structure after the modification by Li-B. The LiB-AC grout was used in the dynamic water grouting project of a metro shield tunnel segment and achieved better anti-washout performance than cement-water glass and pure AC slurry. Full article

The surface defects on a shield subway tunnel can significantly affect the serviceability of the tunnel structure and may compromise operation safety. To effectively detect multiple surface defects, this study uses a tunnel inspection trolley (TIT) based on the mobile laser scanning technique. By conducting an inspection of the shield tunnel on a metro line section, various surface defects are identified with the TIT, including water leakage defects, dislocation, spalling, cross-section deformation, etc. To explore the root causes of the surface defects, association rules between different defects are calculated using an improved Apriori algorithm. The results show that: (i) there are significant differences in different association rules for various surface defects on the shield tunnel; (ii) the average confidence of the association rule “dislocation & spalling → water leakage” is as high as 57.78%, indicating that most of the water leakage defects are caused by dislocation and spalling of the shield tunnel in the sections being inspected; (iii) the weakest rule appears at “water leakage → spalling”, with an average confidence of 13%. The association analysis can be used for predicting the critical defects influencing structural reliability and operation safety, such as water leakage, and optimizing the construction and maintenance work for a shield subway tunnel. Full article

Preventing terrorist attacks at soft targets has become a priority for our society. The realization of sensor systems for automatic threat detection in crowded spaces, such as airports and metro stations, is challenged by the limited sensing coverage capability of the devices in place due to the variety of dangerous materials, to the scanning rate of the devices, and to the detection area covered. In this context, effectiveness of the physical configuration of the system based on the detectors used, the coordination of the sensor data collection, and the real time data analysis for threat identification and localization to enable timely reactions by the security guards are essential requirements for such integrated sensor-based applications. This paper describes a modular distributed architecture of a command-and-control software, which is independent from the specific detectors and where sensor data fusion is supported by two intelligent video systems. Furthermore, the system installation can be replicated at different locations of a public space. Person tracking and later re-identification in a separate area, and tracking hand-over between different video components, provide the command-and-control with localization information of threats to timely activate alarm management and support the activity of subsequent detectors. The architecture has been implemented for the NATO-funded DEXTER program and has been successfully tested in a big city trial at a metro station in Rome both when integrated with two real detectors of weapons and explosives and as a stand-alone system. The discussion focuses on the software functions of the command-and-control and on the flexibility and re-use of the system in wider settings. Full article

This research evaluated gender differences in the perception of safety in public transport in Santiago, Chile using quantitative and qualitative approaches. With data from the National Urban Citizen Security Survey 2019 (ENUSC), a gender comparison was made regarding the perception of safety in four scenarios: inside buses, inside the metro, at bus stops, and waiting for buses at night. Four ordinal logistic regression models were estimated to analyze how sociodemographic factors and variables associated with the perception of crime influence rider perceptions of safety in public transport. To complement the results, four focus groups were developed to obtain a deep understanding of the participants’ experiences with safety in the Santiago public transport system. We concluded that there is a high perception of insecurity in public transport for both men and women. In general, perceived insecurity inside buses, inside the metro, and waiting for public transport at night is greater among women, older people, and national citizens. Other influencing variables are the perception of insecurity regarding crime in general, the fear of being a victim of a crime, or negative situations that occur in the neighborhood, such as the presence of robberies, alcohol, and drug consumption. We proposed new variables such as fear of harassment, traffic accidents, discrimination, contagious diseases, and street protests among others. To carry out a precise public policy on this matter, a permanent scan on security issues in public transport should be developed, considering a complete set of variables. This result can be applied in Chile and all Latin American countries. Full article

This paper investigates the potential utilization of the Tunnel Boring Machine (TBM) muck generated from Doha’s Metro Gold Line in different construction applications. The properties of the raw TBM muck were studied, and the results were compared to the specifications of Qatari Construction Standards (QCS 2014) of concrete aggregates, fill material under buildings and road subgrades. Compared to the requirements of concrete aggregates, the results indicated that the gradation of the raw TBM muck does not comply with the QCS 2014 requirements, and hence, sieving and screening may be essential. Moreover, the tests’ results showed that the properties of the muck meet the requirements of the concrete coarse aggregates, except for the water absorption, loss by magnesium sulphate soundness, loss by Los Angeles abrasion and the acid-soluble sulphate. As fill material under buildings or road subgrades, the gradation of the TBM muck complies with the QCS 2014 requirements, while the liquid limit and plasticity index are higher than the QCS 2014 permissible limits. Additionally, the morphological structure and the elemental composition of the raw TBM muck were determined by employing Scanning Electron Microscopy (SEM) and Energy Dispersive X-ray analysis (EDX), respectively. Digital images were also taken at larger scale to draw a full picture of the TBM muck morphology. A mixture of rough-rounded to angular-elongated shaped particles with relatively large voids could be observed. The EDX analysis demonstrated the presence of silicon (Si) as the predominant component of the muck, which may alter the Coefficient of Thermal Expansion (CTE) values for mixtures prepared using TBM muck. Hence, further investigations should be performed on the mechanical and thermal properties of mixtures containing TBM muck as aggregates’ replacement, and further work should be directed toward this end. Full article

On-site manual inspection of metro tunnel leakages has been faced with the problems of low efficiency and poor accuracy. An automated, high-precision, and robust water leakage inspection method is vital to improve the manual approach. Existing approaches cannot provide the leakage location due to the lack of spatial information. Therefore, an integrated deep learning method of water leakage inspection using tunnel lining point cloud data from mobile laser scanning is presented in this paper. It is composed of three parts as follows: (1) establishment of the water leakage dataset using the acquired point clouds of tunnel linings; (2) automated leakage detection via a mask-region-based convolutional neural network; and (3) visualization and quantitative evaluation of the water leakage in 3D space via a novel triangle mesh method. The testing result reveals that the proposed method achieves automated detection and evaluation of tunnel lining water leakages in 3D space, which provides the inspectors with an intuitive overall 3D view of the detected water leakages and the leakage information (area, location, lining segments, etc.). Full article

One of the most important features of comprehensive land use and transport planning is an ability to identify candidate projects and policies that are adding value to the sustainable performance of transport networks and to the economy as a whole. Standard methods of identifying a shortlist of projects to assess are often qualitative in nature and/or influenced by prejudices of elected officials or their advisers without a systematic way of narrowing the many potential options to evaluate, in sufficient detail, a truly value-adding set. There is a case to be made for having a capability to undertake, in a timely manner, a scan of a large number of potentially worthy projects and policies that can offer forecasts of passenger and freight demand, benefit–costs ratios and economy-wide outcomes. Such a framework would then be meaningful in the sense of offering outputs that are similar to those that are the focus of assessments that are typically spread over many months, if not years, on very few projects, which may exclude those which have the greatest merit. This paper introduces MetroScan, a strategic-level transport and land use planning application system that allows for mapping of passenger and freight activity, as well as an endogenous treatment of the location of households and firms. We summarise the analytical framework of MetroScan and show its capability (including the many useful outputs) with a case study for a 25 percent reduction in public transport fares across the entire network. Full article

Subway structure safety detection is an important method to ensure the safe operation of trains. Efficient, high-precision, and automatic tunnel clearance detection is the key to ensure safe operations. This study introduces a mobile tunnel scanning system that integrates a scanner, an inertial measurement unit (IMU), and a rail car. Global Navigation Satellite System (GNSS) time and system hardware calibration are used to synchronize time and space information of the system; the attitude and speed are corrected using the control points from the tunnel to improve the accuracy of absolute positioning. The section coordinate system is converted using the control points and system calibration parameters to complete the tunnel clearance inspection, and the distance between the nearest point of the section and the clear height of the vault is given. Taking Fengxi Road’s Bashan tunnel section of Chongqing Metro Line 5 as an example, the overall system accuracy was tested. The accuracy of chord line measurements was within 1 mm, the internal coincidence accuracy of repeated measurements of the vault clear height was 1.1 mm, the internal coincidence accuracy of repeated measurements of the closest gauge point was 4.8 mm, and the system calibration accuracy was approximately 2 mm. Compared with the existing scheme, the system combines absolute measurement and relative measurement mode to judge the structural safety of tunnel section from multiple angles, high precision, and high efficiency. Full article

Coherent optical transponders are widely deployed in today’s long haul and metro optical networks using dense wavelength division multiplexing. To increase the data carrying capacity, the coherent transponder utilizes the high order modulation format and operates at a high baud rate. The limited bandwidth and the nonlinearity are two critical impairments for the coherent in-phase quadrature transmitter. These impairments can be mitigated by digital filters. However, to accurately determine the coefficients of these filters is difficult because the impairment from the limited bandwidth and the impairment from nonlinearity are coupled together. In this paper, we present a novel method to solve this problem. During the initial power-up, we apply a sinusoidal stimulus to the coherent IQ transmitter. We then scan the frequency and amplitude of the stimulus and monitor the output power. By curve-fitting with an accurate mathematical model, we determine the limited bandwidth, the nonlinearity, the power imbalance, and the bias point of the transponder simultaneously. Optimized coefficients of the digital filters are determined accordingly. Furthermore, we utilize a coherent IQ transponder and demonstrate that the limited bandwidth is improved by the finite impulse response filter, while nonlinearity is mitigated by the memoryless Volterra filter. Full article

The use of artificial freezing can change the mechanical properties of marine clay. In the construction of cross passages in metro tunnels in which the artificial ground freezing (AGF) method is applied, freeze–thaw circulation and cyclic loading could weaken the engineering properties of the clay, thus resulting in differential settlement. In this paper, the authors studied the dynamic properties of frozen–thawed soils under cyclic loading, with the help of dynamic triaxial testing. According to the dynamic triaxial test results and the images from scanning electron microscopy (SEM), the authors explained the weakening effect of both the freeze–thaw cycle and dynamic loading on soft soil. After freezing, the number of large pores increased. In addition, after cyclic loading, the pore structure of the soil showed a tendency towards compaction, which led to the large pores breaking into small ones. Subsequently, the potential reasons for the change of macroscopic dynamic characteristics were explained from a micro-scale point of view. Full article

This paper presents a novel framework to extract metro tunnel cross sections (profiles) from Terrestrial Laser Scanning point clouds. The entire framework consists of two steps: tunnel central axis extraction and cross section determination. In tunnel central extraction, we propose a slice-based method to obtain an initial central axis, which is further divided into linear and nonlinear circular segments by an enhanced Random Sample Consensus (RANSAC) tunnel axis segmentation algorithm. This algorithm transforms the problem of hybrid linear and nonlinear segment extraction into a sole segmentation of linear elements defined at the tangent space rather than raw data space, significantly simplifying the tunnel axis segmentation. The extracted axis segments are then provided as input to the step of the cross section determination which generates the coarse cross-sectional points by intersecting a series of straight lines that rotate orthogonally around the tunnel axis with their local fitted quadric surface, i.e., cylindrical surface. These generated profile points are further refined and densified via solving a constrained nonlinear least squares problem. Our experiments on Nanjing metro tunnel show that the cross sectional fitting error is only 1.69 mm. Compared with the designed radius of the metro tunnel, the RMSE (Root Mean Square Error) of extracted cross sections’ radii only keeps 1.60 mm. We also test our algorithm on another metro tunnel in Shanghai, and the results show that the RMSE of radii only keeps 4.60 mm which is superior to a state-of-the-art method of 6.00 mm. Apart from the accurate geometry, our approach can maintain the correct topology among cross sections, thereby guaranteeing the production of geometric tunnel model without crack defects. Moreover, we prove that our algorithm is insensitive to the missing data and point density. Full article
