To address the shortcomings of existing robot collision detection algorithms that use six-dimensional force sensors, a force compensation algorithm based on Kane’s dynamics is proposed, along with a collision detection algorithm that uses the six-dimensional force sensor data combined with the robot’s outer surface equations to derive the robot body’s collision point coordinates. Firstly, a collision detection model for a joint-type collaborative robot is presented. Secondly, based on Kane’s dynamics equations, a force compensation model for the joint-type collaborative robot is established and the corresponding force compensation algorithm is derived. Thirdly, a collision detection algorithm is derived, and an example using a cylindrical joint robot with a link’s outer surface equation is used to solve the collision point. The collision is categorized into nine cases, and the coordinates of the collision point are solved for each case. Finally, force compensation and collision detection experiments are conducted on an AUBO-I5 joint-type collaborative robot. The results of the force compensation show that the comparison curves for forces/torques in three directions are consistent, and the relative error is below 5.6%. The collision detection results indicate that the computed collision positions match the actual collision positions, thus verifying the correctness of the theoretical analysis of the force compensation and collision detection algorithms. The research results provide a theoretical basis for ensuring safety in human–robot collaboration. Full article

Due to the complex growth positions of dragon fruit and the difficulty in robotic picking, this paper proposes a six degrees of freedom dragon fruit picking robot and investigates the manipulator’s motion characteristics to address the adaptive motion issues of the picking manipulator. Based on the agronomic characteristics of dragon fruit cultivation, the structural design of the robot and the dimensions of its manipulator were determined. A kinematic model of the dragon fruit picking robot based on screw theory was established, and the workspace of the manipulator was analyzed using the Monte Carlo method. Furthermore, a dynamic model of the manipulator based on the Kane equation was constructed. Performance experiments under trajectory and non-trajectory planning showed that trajectory planning significantly reduced power consumption and peak torque. Specifically, Joint 3’s power consumption decreased by 62.28%, and during the picking, placing, and resetting stages, the peak torque of Joint 4 under trajectory planning was 10.14 N·m, 12.57 N·m, and 16.85 N·m, respectively, compared to 12.31 N·m, 15.69 N·m, and 22.13 N·m under non-trajectory planning. This indicated that the manipulator operates with less impact and smoother motion under trajectory planning. Comparing the dynamic model simulation and actual testing, the maximum absolute error in the joint torques was −2.76 N·m, verifying the correctness of the dynamic equations. Through field picking experiments, it was verified that the machine’s picking success rate was 66.25%, with an average picking time of 42.4 s per dragon fruit. The manipulator operated smoothly during each picking process. In the study, the dragon fruit picking manipulator exhibited good stability, providing the theoretical foundation and technical support for intelligent dragon fruit picking. Full article

Based on the Newton-Euler method, a coupling rigid-body dynamics model of a Trans-Medium Vehicle (TMV) separating from an Unmanned Underwater Vehicle (UUV) has been established. The modeling is based on the “holistic method” and “Kane” ideas respectively, so that most of the equations can be derived without considering the internal forces between the two bodies. The separation propulsion force, which is an internal force, only appears in the relative glide dynamics equation of the TMV along the axis of the separation tube that is installed on the UUV. This greatly reduces the workload of modeling and derivation. The UUV works entirely underwater, while the hydrodynamic shape of the TMV changes continuously during the process of the TMV separating from the UUV. Therefore, accurate hydrodynamic calculations for the UUV and TMV are the basis of numerical resolution for the two rigid bodies’ coupling dynamics model in water. A large number of numerical simulations was conducted using CFD methods to investigate the hydrodynamic performance of the UUV and TMV under various conditions. These simulations aim to establish a hydrodynamic database, and accurate hydrodynamic models were developed through fitting methods and online interpolation. In the process of solving the coupling dynamics of two bodies, the hydrodynamic model is used to calculate the hydrodynamic force experienced by the UUV and TMV. This balances the accuracy and efficiency of a numerical simulation. Finally, numerous simulations and comparative analyses were conducted under various operational conditions and separation parameters. The simulation results indicate that the impact of TMV separation on the motion state of the UUV becomes more prominent with smaller UUV to TMV mass ratios or deeper TMV separation depths. This effect can further influence the stability control of the UUV. The coupling rigid body dynamics analysis method established in this paper provides a fast and effective prediction method for use during the scheme design and separation safety evaluation phases of creating UUV-TMV systems. Full article

A two-axis stabilizing gimbal is a device that ensures a sensor is working properly on a moving platform. When classical mechanics (Newton–Euler and Lagrange) is employed to model a two-axis stable gimbal, its limitations can complicate the modeling process. To address this issue, a method for establishing a dynamic model for a two-axis stabilizing platform based on the Kane method is proposed in this paper. The Kane method offers the advantage of a simple model structure and computational efficiency. Initially, utilizing a generalized coordinate system, expressions of the generalized velocities, deflection velocities and angular velocities are derived. Subsequently, the generalized active forces and inertial forces acting on the two-axis stabilized gimbal are analyzed. Finally, by combining force and velocity with the Kane equation, the dynamic model of the two-axis stable platform is obtained, demonstrating the validity of the Kane method for establishing the two-axis stable platform model. To ensure the pointing accuracy stability of the two-axis stabilizing platform, a Novel Particle Swarm Optimization Proportion Integration Differentiation (NPSO-PID) controller is designed using the PSO algorithm. It is then simulated in MATLAB/Simulink and compared with a classical PID controller. Simulation results demonstrate that NPSO-PID exhibits superior object tracking performance compared to classical PID controllers and better optimization of control parameters compared to traditional PSO-PID controllers. Full article

The application of the Kane equation in analyzing airdrop dynamics problems is rare. The main objective of this paper is to apply the Kane equation dynamics model to the analysis of the status continuity problem during the out-of-cabin process and the line sail phenomenon during the extra-vehicular process. In the out-of-cabin process, an analysis of off-aircraft security and traction ratio impact was conducted. Furthermore, the BP neural network model was trained to predict the status transition of the payload for a multiple airdrop mission. In the extra-vehicular process, the spring network method was used together with the Kane equation to analyze the form and overload of the parachute line. The modeling avoids complex equations and derivations. The results suggest significant potential applications of the Kane equation in precision airdrop missions during out-of-cabin and extra-vehicular processes without heavy reliance on experimental data. Full article

The space target capturing task using the spacecraft-manipulator system (SMS) has special significance in on-orbit servicing due to its theoretical challenges and practical value. The contact force between the end effector (gripper) and the target exerted by the tumbling motion of the space target destabilizes the spacecraft base. A full-dimensional controllable damping mechanism (FDCDM) with a cross-axis structure was designed to buffer the transient impact force on the end joint. The introduction of a damping mechanism gives the space robot a variable stiffness and damping system, and a stiffness estimation algorithm is proposed to calibrate the system stiffness, as stiffness cannot be measured directly. The full-dimensional controllable damping mechanism (FDCDM) with a cross-axis structure is equivalent to a four-DOF tandem joint, and the whole-body dynamic model of the SMS endowed with a full-dimensional controllable damping mechanism (FDCDM) was established using the Kane equation. Then, an unknown input observer (UIO)-based identification theory is proposed to precisely estimate the internal flexibility torque and the corresponding joint stiffness. A model-based neural learning algorithm is proposed to update the variable parameter matrix of the observer. The simulation experiment results demonstrate that the flexibility torque and joint stiffness could be accurately estimated within the expected error, illustrating the feasibility and effectiveness of the proposed method. Full article

In this paper, the attitude-orbit coupled control problem for multi-spacecraft formation with limited communication capability and actuator failure is investigated. For the purpose of solving this problem, an event-triggered attitude-orbit coupled fault-tolerant control strategy is proposed. First, an integrated nonlinear dynamic model including the coupling characteristics of the attitude and orbit is established based on the Kane equation. Second, the nonlinear dynamic model is linearized at the reference state to facilitate the controller design. Third, a dynamic event-triggered mechanism is designed and an event-triggered fault-tolerant control law is developed. The stability of closed-loop control systems can be ensured under the designed control law and a sufficient condition that Zeno’s behavior can be avoided is presented. Finally, simulation results are given to show the effectiveness of the proposed control method. Full article

A linear dynamic model of a front-loading type washing machine was developed in this study. The machine was conceptualized with three moving rigid bodies, revolute joints, springs, and dampers along with prescribed rotational drum motion. Kane’s method was employed for deriving the equations of motion of the idealized washing machine. Since the modal and transient characteristics can be conveniently investigated with a linear dynamic model, the linear model can be effectively used for the design of an FL type washing machine. Despite the convenience, however, the reliability of the linear dynamic model is often restricted to a certain range of system parameters. Parameters relevant to the reliability of the linear dynamic model were identified and the parameters’ ranges that could guarantee the reliability of the proposed linear dynamic model were numerically investigated in this study. Full article

Aiming at the soft contact problem of space docking, a bionic docking mechanism for space target acquisition is proposed to realize the buffering and unloading of six–dimensional spatial collision through flexible rotating and linear components. Using the Kane method, an integrated dynamic equation of the bionic docking mechanism in space docking is established, and the stiffness optimization strategy is carried out based on angular momentum conservation. Based on the particle swarm optimization (PSO), a stiffness optimization scheme was realized. Through the numerical simulation of the bionic docking mechanism in space docking, the stiffness optimization was achieved and the soft contact machine process is verified. Finally, through the docking collision experiments in Adams, the results indicate that the proposed bionic docking mechanism can not only prolong the collision time to win time for space acquisition, but also buffer and unload the six–dimensional spatial collision caused by space target docking. Full article

Motion control in dynamic environments is one of the most important problems in using mobile robots in collaboration with humans and other robots. In this paper, the motion control of a four-Mecanum-wheeled omnidirectional mobile robot (OMR) in dynamic environments is studied. The robot’s differential equations of motion are extracted using Kane’s method and converted to discrete state space form. A nonlinear model predictive control (NMPC) strategy is designed based on the derived mathematical model to stabilize the robot in desired positions and orientations. As a main contribution of this work, the velocity obstacles (VO) approach is reformulated to be introduced in the NMPC system to avoid the robot from collision with moving and fixed obstacles online. Considering the robot’s physical restrictions, the parameters and functions used in the designed control system and collision avoidance strategy are determined through stability and performance analysis and some criteria are established for calculating the best values of these parameters. The effectiveness of the proposed controller and collision avoidance strategy is evaluated through a series of computer simulations. The simulation results show that the proposed strategy is efficient in stabilizing the robot in the desired configuration and in avoiding collision with obstacles, even in narrow spaces and with complicated arrangements of obstacles. Full article

The gait and the Foot Placement Estimation (FPE) has recently been extended to 3-D spaces by adopting a specific form of a spherical inverted pendulum (SIP). The approach is very attractive, as it does not involve dynamics, but it is based solely on energies and momenta, however the authors (DeHart et al.) introduced several questionable approximations, in order to reach a manageable solution. The scope of the present paper is to revisit this spherical inverted pendulum applied to biped walking, offering an exact solution to the gait and the FPE by using symbolic computation. This is facilitated by exploiting the Kane’s approach to dynamical modelling, and his software environment for symbolic manipulation, called Autolev. It generates explicit formulas describing the energies and angular momenta before/after the impact, along with the mechanics of the impact. As the resulting equations, function of (measurable) angular positions and velocities, are very compact, embedded in a numerical nonlinear solver, are suitable to be implemented in real time and used in practice to control biped robots or lower limb exoskeletons. The two main contributions of the paper are: the recovery of the balance by stepping, in the presence of a push in an arbitrary direction and omnidirectional walking. In this last respect, this specific form of SIP emphasizes the expenditure of energy in the walk. For the first time, at our knowledge, the walk of the SIP, based on energy, has been compared to the simulation of a 12 degrees of freedom biped robot tracking preview signals using the Zero Moment Point (ZMP) of the Linear Inverted Pendulum (LIPM). This quantitatively shows the inefficiency, in terms of energy, of the ZMP-based walk, and the gain due to the recovery of the collision of the flying foot. Similarity in the sagittal plane and differences in the frontal plane of the center of mass trajectories of the two approaches are shown, to open the road to an integration of fully actuated and underactuated controls, for an efficient full-dimensional robot gait to be developed in a future paper. Full article

The paper uses Kane’s formalism to study two degrees of freedom (DOF) mechanisms with elastic elements = employed in a wind water pump. This formalism represents an alternative, in our opinion, that is simpler and more economical to Lagrange’s equation, used mainly by researchers in this type of application. In the problems where the finite element method (FEM) is applied, Kane’s equations were not used at all. The automated computation causes it to be reconsidered in the case of mechanical systems with a high DOF. Analyzing the planar transmission mechanism, these equations were applied for the study of an elastic element. An analysis was then made of the results obtained for this type of water pump. The matrices coefficients of the obtained equations were symmetric or skew-symmetric. Full article

The Lagrange’s equation remains the most used method by researchers to determine the finite element motion equations in the case of elasto-dynamic analysis of a multibody system (MBS). However, applying this method requires the calculation of the kinetic energy of an element and then a series of differentiations that involve a great computational effort. The last decade has shown an increased interest of researchers in the study of multibody systems (MBS) using alternative analytical methods, aiming to simplify the description of the model and the solution of the systems of obtained equations. The method of Kane’s equations is one possibility to do this and, in the paper, we applied this method in the study of a MBS applying finite element analysis (FEA). The number of operations involved is lower than in the case of Lagrange’s equations and Kane’s equations are little used previously in conjunction with the finite element method (FEM). Results are obtained regardless of the type of finite element used. The shape functions will determine the final form of the matrix coefficients in the equations. The results are applied in the case of a planar mechanism with two degrees of freedom. Full article

The space-borne manipulator has been playing an important part in docking tasks. Docking collision can easily lead to instability of both the manipulator and floating base. Aiming at the problem of soft capture, a novel soft-contact joint with dual working modes is developed, especially to buffer and unload the spatial collision momentum. Furthermore, considering a series-wound soft-capture manipulator with multi-joints, a generalized modeling method was established by using the Kane approach. Both the benefits of soft-contact joint and the effectiveness of dynamics equations are verified in MATLAB and Adams software by simulations of a two-joint manipulator with eight-DOF. The comparative simulation results showed the advantages of the proposed soft-contact joint in reducing instability from spatial impact. Full article
