Search Results (26)

High-fidelity simulations are used to study the stability of a coupled parachute–payload system in different configurations. A 8.53 m ring–slot canopy is attached to two separate International Organization for Standardization (ISO) container payloads representing a Twenty Foot Equivalent (TEU). To minimize risk and as an alternative to a relatively expensive traditional test program, a multi-phase design and evaluation program using computational tools validated for uncoupled parachute system components was completed. The interaction of the payload wake suspended at different locations and orientations below the parachute were investigated to determine stability characteristics for both subsonic and supersonic freestream conditions. The DoD High-Performance Computing Modernization Program CREATE^TM-AV Kestrel suite was used to perform CFD and fluid–structure interaction (FSI) simulations using both delayed detached-eddy simulations (DDES) and implicit Large Eddy Simulations (iLES). After analyzing the subsonic test cases, the simulations were used to predict the coupled system’s response to the supersonic flow field during descent from a high-altitude deployment, with specific focus on the effect of the payload wake on the parachute bow shock. The FSI simulations included structural cable element modeling but did not include aerodynamic modeling of the suspension lines or suspension harness. The simulations accurately captured the turbulent wake of the payload, its coupling to the parachute, and the shock interactions. Findings from these simulations are presented in terms of code validation, system stability, and drag performance during descent. Full article

The current study investigates the performance of implicit Large Eddy Simulation (iLES) incorporating an unstructured third-order Weighted Essentially Non-Oscillatory (WENO) reconstruction method, alongside conventional Large Eddy Simulation (LES) using the Wall-Adapting Local Eddy Viscosity (WALE) model, for wall-bounded flows. Specifically, iLES is applied to the flow around a NACA0012 airfoil at a Reynolds number which involves key flow phenomena such as laminar separation, transition to turbulence, and flow reattachment. Simulations are conducted using the open-source computational fluid dynamics package OpenFOAM, with a second-order implicit Euler scheme for time integration and the Pressure-Implicit Splitting Operator (PISO) algorithm for pressure–velocity coupling. The results are compared against direct numerical simulation (DNS) for the same flow conditions. Key metrics, including the pressure coefficient and reattached turbulent velocity profiles, show excellent agreement between the iLES and DNS reference results. However, both iLES and LES predict a thinner separation bubble in the transitional flow region then DNS. Notably, the iLES approach achieved a 35% reduction in mesh resolution relative to wall-resolving LES, and a 70% reduction relative to DNS, while maintaining satisfactory accuracy. The study also captures detailed instantaneous flow evolution on the airfoil’s upper surface, with evidence suggesting that three-dimensional disturbances arise from interactions between separating boundary layers near the trailing edge. Full article

This is a comprehensive overview on our research work to link interdisciplinary modeling and simulation techniques to improve the predictability and reliability simulations (PARs) of compressible turbulence with shock waves for general audiences who are not familiar with our nonlinear approach. This focused nonlinear approach is to integrate our “nonlinear dynamical approach” with our “newly developed high order entropy-conserving, momentum-conserving and kinetic energy-preserving methods” in the quantification of numerical uncertainty in highly nonlinear flow simulations. The central issue is that the solution space of discrete genuinely nonlinear systems is much larger than that of the corresponding genuinely nonlinear continuous systems, thus obtaining numerical solutions that might not be solutions of the continuous systems. Traditional uncertainty quantification (UQ) approaches in numerical simulations commonly employ linearized analysis that might not provide the true behavior of genuinely nonlinear physical fluid flows. Due to the rapid development of high-performance computing, the last two decades have been an era when computation is ahead of analysis and when very large-scale practical computations are increasingly used in poorly understood multiscale data-limited complex nonlinear physical problems and non-traditional fields. This is compounded by the fact that the numerical schemes used in production computational fluid dynamics (CFD) computer codes often do not take into consideration the genuinely nonlinear behavior of numerical methods for more realistic modeling and simulations. Often, the numerical methods used might have been developed for weakly nonlinear flow or different flow types other than the flow being investigated. In addition, some of these methods are not discretely physics-preserving (structure-preserving); this includes but is not limited to entropy-conserving, momentum-conserving and kinetic energy-preserving methods. Employing theories of nonlinear dynamics to guide the construction of more appropriate, stable and accurate numerical methods could help, e.g., (a) delineate solutions of the discretized counterparts but not solutions of the governing equations; (b) prevent numerical chaos or numerical “turbulence” leading to FALSE predication of transition to turbulence; (c) provide more reliable numerical simulations of nonlinear fluid dynamical systems, especially by direct numerical simulations (DNS), large eddy simulations (LES) and implicit large eddy simulations (ILES) simulations; and (d) prevent incorrect computed shock speeds for problems containing stiff nonlinear source terms, if present. For computation intensive turbulent flows, the desirable methods should also be efficient and exhibit scalable parallelism for current high-performance computing. Selected numerical examples to illustrate the genuinely nonlinear behavior of numerical methods and our integrated approach to improve PARs are included. Full article

This comprehensive overview presents our continued efforts in high-order finite difference method (FDM) development for adaptive numerical dissipation control in the long-time integration of direct numerical simulation (DNS), large eddy simulation (LES), and implicit LES (ILES) computations of compressible turbulence for gas dynamics and MHD. The focus is on turbulence with shock wave numerical simulations using the adaptive blending of high-order structure-preserving non-dissipative methods (classical central, Padé (compact), and dispersion relation-preserving (DRP)) with high-order shock-capturing methods in such a way that high-order shock-capturing methods are active only in the vicinity of shock/shear waves, and high-gradient and spurious high-frequency oscillation regions guided via flow sensors. Any efficient and high-resolution high-order shock-capturing methods are good candidates for the blending of methods procedure. Typically, the adaptive blending of more than one method falls under two camps: hybrid methods and nonlinear filter methods. They are applicable to unstructured finite volume, finite element, discontinuous Galerkin, and spectral element methods. This work represents the culmination of over 20 years of high-order FDM developments and hands-on experience by the authors and collaborators in adaptive numerical dissipation control using the “high order nonlinear filter approach”. Extensions of these FDM versions to curvilinear nonuniform, freestream-preserving moving grids and time-varying deforming grids were also developed. By examining the construction of these two approaches using the high-order multistage type of temporal discretization, the nonlinear filter approach is made more efficient and less CPU-intensive while obtaining similar accuracy. A representative variety of test cases that compare the various blending of high-order methods with standalone standard methods is illustrated. Due to the fact that our nonlinear filter methods are not well known in compressible turbulence with shock waves, the intent of this comprehensive overview is for general audiences who are not familiar with our nonlinear filter methods. For readers interested in the implementation of our methods into their computer code, it is hoped that the long overview will be helpful. Full article

The resolution of small near-wall eddies encountered in high-Reynolds number flows using large eddy simulation (LES) requires very fine meshes that may be computationally prohibitive. As a result, the use of wall-modeled LES as an alternative is becoming more popular. In this paper, the near-wall domain decomposition (NDD) approach that was originally developed for Reynolds-averaged Navier–Stokes simulations (RANSs) is extended to the hybrid RANS/LES zonal decomposition. The algorithm is implemented in two stages. First, the solution is computed everywhere with LES on a coarse grid using a new non-local slip boundary condition for the instantaneous velocity at the wall. The solution is then recomputed in the near-wall region with RANS. The slip boundary conditions used in the first stage guarantee that the composite solution is smooth at the inner/outer region interface. Another advantage of the model is that the turbulent viscosity in the inner region is computed based on the corresponding RANS velocity. This shows improvement over those hybrid models that have only one velocity field in the whole domain obtained from LES. The model is realized in the open source code OpenFOAM with different approximations of turbulent viscosity and is applied to the planar channel flow at frictional Reynolds numbers of ${\mathrm{Re}}_{\tau }=950$, 2000, and 4200. Mean streamwise velocity and Reynolds stress intensities are predicted reasonably well in comparison to the solutions obtained with unresolved LES and available DNS benchmarks. No additional forcing at the interface is required, while the log–layer mismatch is essentially reduced in all cases. Full article

The aim of this investigation is to show the solution for the critical Reynolds number in the flow around the sphere on the basis of theory of stochastic equations and equivalence of measures between turbulent and laminar motions. Solutions obtained by numerical methods (DNS, LES, RANS) require verification and in this case the theoretical results have special value. For today in the scientific literature, there is J. Talor’s implicit formula connecting the critical Reynolds number with the parameters of the initial fluctuations in the flow around the sphere. Here the derivation of the explicit formula is presented. The results show a satisfactory correspondence of the obtained theoretical dependence for the critical Reynolds number to the experiments in the flow around the sphere. Full article

The present paper contains the results of the numerical analysis of the interaction between a Newtonian incompressible turbulent flow and a linear elastic slender body, together with the influence of the fluid–structure interaction (FSI) on the noise generation and propagation. The purpose is to evaluate the differences in term of acoustic pressure between the case where the solid body is rigid (infinite stiffness) and the case where it is elastic (finite stiffness). A partitioned and implicit algorithm with the arbitrary Lagrangian–Eulerian method (ALE) is used for the interaction between the fluid and solid. For the evaluation of the turbulent fluid motion, we use a large eddy simulation (LES) with the Smagorinsky subgrid scale model. The equation for the solid is solved through the Lagrangian description of the momentum equation and the second Piola–Kirchoff stress tensor. In addition, the acoustic analogy of Lighthill is used to characterize the acoustic source (the slender body) by directly using the fluid dynamic fields. In particular, we use the Ffowcs Williams and Hawkings (FW-H) equation for the evaluation of the acoustic pressure in the fluid medium. As a first numerical experiment, we analyze a square cylinder immersed in a turbulent flow characterized by two different values of stiffness: one infinite (rigid case) and one finite (elastic case). In the latter case, the body stiffness and mean flow velocity are such that they induce the lock-in phenomenon. Finally, we evaluate the differences in terms of acoustic pressure between the two different cases. Full article

In the simulation of compressible turbulent flows via a high-order flux reconstruction framework, the artificial viscosity model plays an important role to ensure robustness in the strongly compressible region. However, the impact of the artificial viscosity model in under-resolved regions on dissipation features or resolving ability remains unclear. In this work, the performance of a dilation-based (DB) artificial viscosity model to simulate under-resolved turbulent flows in a high-order flux reconstruction (FR) framework is investigated. Comparison is conducted with results via several typical explicit subgrid scale (SGS) models as well as implicit large eddy simulation (iLES) and their impact on important diagnostic quantities including turbulent kinetic energy, total dissipation rate of kinetic energy, and energy spectra are discussed. The dissipation rate of kinetic energy is decomposed into several components including those resulting from explicit SGS models or Laplacian artificial viscosity model; thus, an explicit evaluation of the dissipation rate led by those modeling terms is presented. The test cases consist of the Taylor-Green vortex (TGV) problem at $Re=1600$, the freely decaying homogeneous isotropic turbulence (HIT) at $M{a}_{t0}=0.5$ (the initial turbulent Mach number ), the compressible TGV at Mach number 1.25 and the compressible channel flow at $R{e}_b=$ 15,334 (the bulk Reynolds number based on bulk density, bulk velocity and half-height of the channel), Mach number 1.5. The first two cases show that the DB model behaves similarly to the SGS models in terms of dissipation and has the potential to improve the insufficient dissipation of iLES with the fourth-order-accurate FR method. The last two cases further demonstrate the ability of the DB method on compresssible under-resolved turbulence and/or wall-bounded turbulence. The results of this work suggest the general suitability of the DB model to simulate under-resolved compressible turbulence in the high order flux reconstruction framework and also suggest some future work on controlling the potential excessive dissipation caused by the dilation term. Full article

We employ numerically implicit subgrid-scale modeling provided by the well-known streamlined upwind/Petrov–Galerkin stabilization for the finite element discretization of advection–diffusion problems in a Large Eddy Simulation (LES) approach. Whereas its original purpose was to provide sufficient algorithmic dissipation for a stable and convergent numerical method, more recently, it has been utilized as a subgrid-scale (SGS) model to account for the effect of small scales, unresolvable by the discretization. The freestream Mach number is 2.5, and direct comparison with a DNS database from our research group, as well as with experiments from the literature of adiabatic supersonic spatially turbulent boundary layers, is performed. Turbulent inflow conditions are generated via our dynamic rescaling–recycling approach, recently extended to high-speed flows. Focus is given to the assessment of the resolved Reynolds stresses. In addition, flow visualization is performed to obtain a much better insight into the physics of the flow. A weak compressibility effect is observed on thermal turbulent structures based on two-point correlations (IC vs. supersonic). The Reynolds analogy ($u^{\prime }$ vs. $t^{\prime }$) approximately holds for the supersonic regime, but to a lesser extent than previously observed in incompressible (IC) turbulent boundary layers, where temperature was assumed as a passive scalar. A much longer power law behavior of the mean streamwise velocity is computed in the outer region when compared to the log law at Mach 2.5. Implicit LES has shown very good performance in Mach 2.5 adiabatic flat plates in terms of the mean flow (i.e., $C_f$ and $U_{VD}^{+}$). iLES significantly overpredicts the peak values of $u\prime$, and consequently Reynolds shear stress peaks, in the buffer layer. However, excellent agreement between the turbulence intensities and Reynolds shear stresses is accomplished in the outer region by the present iLES with respect to the external DNS database at similar Reynolds numbers. Full article

The ability of high-fidelity computational fluid mechanics simulation to quantitatively predict the influence of ground roughness on the evolution of the wake of a three-bladed horizontal axis wind turbine model is tested by comparison with wind tunnel measurements. The approach consists of the implicit approximate deconvolution large-eddy simulation formulation of Hickel et al., (2006), that is, for the first time, combined with a wall-stress model for flow over rough surfaces and with the actuator line approach (ALM) for modeling of the rotor. A recycling technique is used for the generation of turbulent inflow that matches shear exponents $\alpha =0.16$ (medium roughness) and $\alpha =0.32$ (high roughness) and turbulence level of the reference experiments at hub height. Satisfactory agreement of the spectral content in simulation and experiment is achieved for a grid resolution of 27 cells per rotor radius. Except for minor differences due to neglecting nacelle and tower in the simulation the LES reproduces the shapes of mean flow and Reynolds stress profiles in the wake. The deviations between measurement and simulation are more prominent in a vertical cut plane through the rotor center than in a horizontal cut plane. Simulation and experiment deviate with respect to the roughness influence on the development of the wake width; however, the relative change of the maximum wake deficit and of the vertical wake center position due to changes in ground roughness is reproduced very well. Full article

A spectral/hp element methodology is utilised to investigate the SAE Notchback geometry with 20${}^{\circ }$ backlight and 3${}^{\circ }$ diffuser at $Re=2.3\times {10}^6$. The study presented here considered two different mesh approaches: one focusing on classical h-type refinement with standard solution polynomial order (HFP3) and a second case considering relatively coarse mesh combined with high solution polynomial order (HCP5). For the same targeted number of degrees of freedom in both meshes, the results show significant differences in vorticity, flow structures and surface pressure. The first guidelines for hp refinement strategy are deduced for complex industrial cases. Further work on investigating the requirements for these hybrid techniques is required in order to maximize the benefits of the solution and mesh refinements in spectral/hp element method simulations. Full article

The turbulent flow over the DrivAer fastback model is here investigated with an order-adaptive discontinuous Galerkin (DG) method. The growing need of high-fidelity flow simulations for the accurate determination of problems, e.g., vehicle aerodynamics, promoted research on models and methods to improve the computational efficiency and to bring the practice of Scale Resolving Simulations (SRS), like the large-eddy simulation (LES), to an industrial level. An appealing choice for SRS is the Implicit LES (ILES) via a high-order DG method, where the favourable numerical dissipation of the space discretization scheme plays directly the role of a subgrid-scale model. Implicit time integration and the p-adaptive algorithm reduce the computational cost allowing a high-fidelity description of the physical phenomenon with very coarse mesh and moderate number of degrees of freedom. Two different models have been considered: (i) a simplified DrivAer fastback model, without the rear-view mirrors and the wheels, and a smooth underbody; ($ii$) the DrivAer fastback model, without rear-view mirrors and a smooth underbody. The predicted results have been compared with experimental data and CFD reference results, showing a good agreement. Full article

Marine propulsors are identified as the main contributor to a vessel’s underwater radiated noise as a result of tonal propeller noise and broadband emissions caused by its induced cavitation. To reduce a vessel’s signature, spectral limits are set for the propulsion industry, which can be experimentally obtained for a complete vessel at the full-scale; however, the prediction capability of the sound sources is still rudimentary at best. To adhere to the regulatory demands, more accurate numerical methods for combined turbulence and two-phase modeling for a high-quality prediction of acoustic sources of a propeller are required. Several studies have suggested implicit LES as a capable tool for propeller cavitation simulation. In the presented study, the main objective was the evaluation of the tip and hub vortex cavitating flows with implicit LES focusing on probable sound source representation. Cavitation structures for free-running propeller test cases were compared with experimental measurements. To resolve the structure of the tip vortex accurately, a priory mesh refinement was employed during the simulation in regions of high vorticity. Good visual agreement with the experiments and a fundamental investigation of the tip cavity structure confirmed the capability of the implicit LES for resolving detailed turbulent flow and cavitation structures for free-running propellers. Full article

Methods to predict underwater acoustics are gaining increased significance, as the propulsion industry is required to confirm noise spectrum limits, for instance in compliance with classification society rules. Propeller–ship interaction is a main contributing factor to the underwater noise emissions by a vessel, demanding improved methods for both hydrodynamic and high-quality noise prediction. Implicit large eddy simulation applying volume-of-fluid phase modeling with the Schnerr-Sauer cavitation model is confirmed to be a capable tool for propeller cavitation simulation in part 1. In this part, the near field sound pressure of the hydrodynamic solution of the finite volume method is examined. The sound level spectra for free-running propeller test cases and pressure pulses on the hull for propellers under behind ship conditions are compared with the experimental measurements. For a propeller-free running case with priory mesh refinement in regions of high vorticity to improve the tip vortex cavity representation, good agreement is reached with respect to the spectral signature. For behind ship cases without additional refinements, partial agreement was achieved for the incompressible hull pressure fluctuations. Thus, meshing strategies require improvements for this approach to be widely applicable in an industrial environment, especially for non-uniform propeller inflow. Full article

The simulation of fully turbulent, three-dimensional, cavitating flow over Delft twisted foil is conducted by an implicit large eddy simulation (LES) approach in both smooth and tripped conditions, the latter by including leading-edge roughness. The analysis investigates the importance of representing the roughness elements on the flow structures in the cavitation prediction. The results include detailed comparisons of cavitation pattern, vorticity distribution, and force predictions with the experimental measurements. It is noted that the presence of roughness generates very small cavitating vortical structures which interact with the main sheet cavity developing over the foil to later form a cloud cavity. Very similar to the experimental observation, these interactions create a streaky sheet cavity interface which cannot be captured in the smooth condition, influencing both the richness of structures in the detached cloudy cavitation as well as the extent and transport of vapour. It is further found to have a direct impact on the pressure distribution, especially in the mid-chord region where the shed cloud cavity collapses. Full article
