This paper presents a comparative analysis of electric field (E-field) mitigation in inductive power transfer (IPT) systems. It focuses on how distributed capacitor placement interacts with coil topology to influence E-field emissions. The study compares traditional sequential-winding coils and the alternating voltage phase coil (AVPC), which employs a sequential inversion winding (SIW) structure to enforce a 180° phase voltage opposition between adjacent turns. While capacitor segmentation is a known method for E-field reduction, this work is the first to systematically evaluate its effects across both conventional and phase-inverted coils. The findings reveal that capacitor placement serves as a topology-dependent design parameter. Finite Element Method (FEM) simulations and experimental validation show that while capacitor placement has a moderate influence on traditional coils due to in-phase voltage relationships, AVPC coils are highly sensitive to segmentation patterns. When capacitors align with the SIW phase structure, destructive interference significantly reduces E-field emissions. Improper capacitor placement disrupts phase cancellation and negates this benefit. This study resolves a critical design gap by establishing that distributed compensation acts as a tuning mechanism in conventional coils but becomes a primary constraint in phase-inverted topologies. The results demonstrate that precise capacitor placement aligned with the coil topology significantly enhances E-field mitigation up to 60% in AVPC coils, greatly outperforming traditional coil configurations and providing actionable guidance for high-power wireless charging applications. Full article

The aim of this work is the design of a 200 W transmitting coil for a high-power wireless power transfer (WPT) system based on magnetic resonant coupling (MRC) to charge the battery of a drone in 1 h equipped with a WPT receiving coil integrated into the landing gear. This innovative solution is based on the use of the landing gear as the receiving coil, thereby obviating the need for an additional component (e.g., separate receiving coil). The proposed landing gear is fabricated from aluminum, to reduce weight, and to improve mechanical robustness and electrical performance. Consequently, the design reduces overall weight and system complexity while minimizing potential destabilization of the drone’s flight dynamics. However, a specific design of the primary coil is required to ensure high efficiency even in case of an inaccurate landing of the drone on a ground pad. To this aim, a double-D configuration is here proposed and optimized for the transmitting coil, while a double coil receiver in combination with a charge controller that uses a maximum power point tracking (MPPT) algorithm is integrated into the landing gear. The results obtained from the simulations demonstrate that the proposed WPT system has excellent electrical efficiency and very high tolerance to coil misalignment in terms of the coupling coefficient due to imprecise landing. The transmission efficiency of the final test prototype can reach 95% with a coupling coefficient of k = 0.16, and it can drop to a minimum of 85% when misalignment occurs resulting in k = 0.06. Full article

Inductive power transfer (IPT) systems are transforming railway infrastructure by enabling efficient, wireless energy transmission for electric locomotives equipped with Li-ion batteries. This technology eliminates the need for overhead power lines and third rails, offering financial and operational advantages over conventional electric propulsion systems. Despite its potential, IPT deployment in rail applications faces significant challenges, including the fragility of materials (i.e., ferrite and Litz wires), thermal management during high-power transfers, and electromagnetic interference (EMI) on the transmitter side. This study discusses several factors affecting IPT efficiency and introduces magnetic concrete as a durable and cost-effective material solution for IPT systems. Magnetic concrete combines soft ferrite powder with water and coarse aggregates to enhance magnetic functionality while maintaining structural strength comparable to conventional concrete. Its durability and optimized magnetic properties promote consistent power transfer efficiency, making it a viable alternative to traditional ferrite cores. A comparative study has been performed on non-magnetic and magnetic concrete (with 33% ferrite powder) using both permeability tests and finite element analysis (FEA). The FEA includes both thermal and electromagnetic simulations using Ansys Maxwell (v.16), revealing that magnetic concrete can improve temperature management and EMI mitigation, and the findings underscore its potential to revolutionize IPT technology by overcoming the limitations of traditional materials and enhancing durability, cost-efficiency, and power transfer efficiency. By addressing the challenges of fragility, thermal management, and shielding of the unique coil topology design presented, this study lays the groundwork for improving IPT infrastructure in sustainable and efficient rail transport systems. Full article

This paper proposes a combined maximum efficiency tracking and improved active disturbance rejection control (ADRC) strategy for an inductive power transfer (IPT) system, addressing issues of reduced efficiency and voltage fluctuations under load variations. The transmission characteristics of the inductor–capacitor–capacitor and series (LCC-S) IPT system are analyzed, and the relationship between transmission efficiency and the secondary DC-DC converter’s duty cycle is derived. Maximum efficiency tracking is achieved by adjusting the secondary converter’s duty cycle via the primary side Buck converter. An improved ADRC controller enhances dynamic voltage regulation by reducing the extended state observer’s order and incorporating model information for better disturbance compensation. Experimental results show that the proposed approach improves average transmission efficiency by 12% and maintains constant output voltage under varying loads. The controller requires fewer parameters than linear active disturbance rejection control (LADRC), with faster responses and smaller voltage fluctuations than PI and LADRC controllers. Full article

Inductive Power Transfer (IPT) is evolving fast in many domains, but its efficiency, its extensive resource requirements, and its cost remain crucial problems for its development. Although the inverter is mainly responsible for its cost and material consumption, a considerable quantity of conductors is required for the coupling realization. Therefore, A drastic cost reduction is possible when comparing the traditional most efficient copper Litz wire with aluminum conductors for a similar volume and a lighter embedded system. However, alternative ribbon wire solutions are also characterized and seem promising as substitutes for such applications. First, standard electrical efficiency is evaluated for all cases, before the price and weight. To complement the results and as the alternative couplers imply different materials and production processes, a Life Cycle Assessment is performed. A comparison is carried out on copper and aluminum litz wires and copper and aluminum ribbons. Results demonstrate the promising interest in industrial application of such study, furthermore for systems requiring many couplers as Dynamic IPT (DIPT). Full article

Solid-State Transformers (SSTs) enable significant improvements in size and functionality compared to conventional power transformers. However, one of the key challenges in Solid-State Transformer design is achieving reliable insulation between the high-voltage and low-voltage sections. This proposal presents the design and optimization of a high-insulation Medium-Frequency Transformer (MFT) for 66 kV grids operating at 50 kHz and delivering up to 75 kW for SST applications using Inductive Power Transfer (IPT) technology. A fixed 50 mm gap between the primary and secondary windings is filled with dielectric oil to enhance insulation. The proposed IPT system employs a double-D coil design developed through iterative 2D and 3D finite element method simulations to optimize the magnetic circuit, thereby significantly reducing stray flux and losses. Notably, the double-D configuration reduces enclosure losses from 269.6 W, observed in a rectangular coil design, to 4.38 W, resulting in an overall system loss reduction of 42.4% while maintaining the electrical parameters required for zero-voltage switching operation. These advancements address the critical limitations in conventional Medium-Frequency Transformers by providing enhanced insulation and improved thermal management. The proposed IPT-based design offers a low-loss solution with easy thermal management for solid-state transformer applications in high-voltage grids. Full article

This study presents the design, analysis, and experimental validation of a 500 W inductive power transfer (IPT) system with a transmission distance of 250 mm for television applications. The proposed system incorporates an innovative wireless pad design featuring a four-teeth magnetic structure and an LCC-S compensation topology to optimize coupling coefficients, reduce copper losses, and improve overall efficiency. The system’s robustness under misalignment and load fluctuations was validated, with experimental results confirming over 80% efficiency for optimal configurations. The findings also highlight the sensitivity of the system to switching frequency variations, emphasizing the need to maintain resonance conditions for maximum power transfer. Compared to existing designs, the proposed system demonstrates superior performance in long-distance wireless power transfer, making it a promising solution for high-power applications in home appliances. Full article

Electric vehicles (EVs) wireless charging is enabled by inductive power transfer (IPT) technology, which eliminates the need for physical connections between the vehicle and the charging station, allowing power to be transmitted without the use of cables. However, in the present wireless charging equipment, the power transfer still needs to be improved. In this work, we present a power transfer structure using a unique “DD circular (DDC) power pad”, which mitigates the two major obstacles of wireless EV charging, due to the mitigating power of electromagnetic field (EMF) leakage emissions and the increase in misalignment tolerance. We present a DDC power pad structure, which integrates features from both double D(DD) and circular power pads. We first build a three-dimensional electromagnetic model based on the DDC structure. A detailed analysis is performed of the electromagnetic characteristics, and the device parameters regarding the power transfer efficiency, coupling coefficient, and mutual inductance are also presented to evaluate the overall performance. Then, we examine the performance of the DDC power pad under various horizontal and vertical misalignment circumstances. The coupling coefficients and mutual inductance, as two essential factors for effective power transmission under dynamic circumstances, are investigated. The findings of misalignment effects on coupling efficiency indicate that the misalignment does not compromise the DDC pad’s robust performance. Therefore, our DDC power pad structure has a better electromagnetic characteristic and a higher misalignment tolerance than conventional circular and DD pads. In general, the DDC structure we present makes it a promising solution for wireless EV charging systems and has good application prospects. Full article

With the growing use of unmanned surface vehicles (USVs) for underwater exploration, efficient wireless charging solutions like inductive power transfer (IPT) are crucial for addressing power limitations. This paper presents a novel IPT system for USVs and introduces a systematic design approach for optimizing magnetic couplers. The proposed design addresses three critical challenges: misalignment tolerance, lightweight construction, and thermal safety, which are intricately linked through a magnetic field. In terms of misalignment, this paper demonstrates that the coil length is a key factor in determining misalignment tolerance. For a lightweight design, replacing the ferrite plate with ferrite bars can significantly reduce the weight of the coupler without causing core saturation. The design is further validated through a two-way coupled electromagnetic–thermal simulation. The results reveal that, with proper thermal management, the system avoids thermal risks in underwater environments compared to air. Finally, a 3 kW prototype is constructed and tested in fresh water, achieving 55 V and 50 A wireless charging at an 85.7% full-load dc-to-dc efficiency, thus confirming the practicality and performance of the design. Full article

Field implementations of fully underground sensor networks face many practical challenges that have limited their overall adoption. Power management is a commonly cited issue, as operators are required to either repeatedly excavate batteries for recharging or develop complex underground power infrastructures. Prior works have proposed wireless inductive power transfer (IPT) as a potential solution to these power management issues, but misalignment is a persistent issue in IPT systems, particularly in applications involving moving vehicles or obscured (e.g., underground) coils. This paper presents an automated methodology to sense misalignments and align IPT coils using robotic actuators and sequential Monte Carlo methods. The misalignment of a Class EF inverter-driven IPT system was modeled by tracking changes as its coils move apart laterally and distally. These models were integrated with particle filters to estimate the location of a hidden coil in 3D, given a sequence of sensor measurements. During laboratory tests on a Cartesian robot, these algorithms aligned the IPT system within 1 cm (0.025 coil diameters) of peak lateral alignment. On average, the alignment algorithms required less than four sensor measurements for localization. After laboratory testing, this approach was implemented with an agricultural sensor platform at the Utah Agricultural Experiment Station in Kaysville, Utah. In this implementation, a buried sensor platform was successfully charged using an aboveground, vehicle-mounted transmitter. Overall, this work contributes to the field of underground sensor networks by successfully integrating a self-aligning wireless power delivery system with existing agricultural infrastructure. Furthermore, the alignment strategy presented in this work accomplishes coil misalignment correction without the need for complex sensor or coil architectures. Full article

In order to reduce the sensitivity of an inductive power transfer (IPT) system to the misalignment coupling coil, an S-SP-compensated IPT system with high misalignment tolerance based on a switch-controlled capacitor (SCC) is proposed. Firstly, the mathematical model of the S-SP compensation topology is established, the output characteristics and impedance characteristics of the system are analyzed, and a sensitivity analysis of the compensation element parameters is carried out using the compensation topology. An improved switching capacitor structure is proposed to dynamically compensate the S-SP IPT system. Finally, an experimental prototype was set up to validate the correctness of the theoretical analysis. The experimental results show that the proposed method can ensure that the system can operate in the resonant state with high efficiency when the coupling pad’s horizontal misalignment is within 30% (with the coupling coefficient varying from 0.22 to 0.14). Full article

This paper describes a numerically efficient method for optimizing the high power transfer efficiency (PTE) of a resonant cavity-based Wireless Power Transfer (WPT) system for the wireless charging of smart clothing. The WPT system under study unitizes a carbon steel closet intended to store smart clothing overnight as a resonant cavity. The WPT system is designed to operate at 865.5 MHz; however, the operating frequency can be adjusted over a wide range. The main reason behind choosing a resonant cavity-based WPT system is that it has several advantages over the competitive WPT methods. Specifically, in contrast to its Far-field Power Transfer (FPT) and Inductive Power Transfer (IPT) counterparts, resonant cavity-based WPTs do not exhibit path loss and significant PTE sensitivity to the distance between the Tx and Rx coils and misalignment, respectively. The non-uniformity of the fields within the closet is addressed by using an optimized Yagi-like transmitting antenna with an additional element affecting the waveguide mode phases. The changes in the mode phases increase the volume inside the cavity, where the PTE values are higher than 50% (the high PTE region). In the present study, the model decomposition method is adapted to substantially accelerate the process of finding the optimal WPT system parameters. Additionally, the decomposition method explains the mechanism responsible for extending the high PTE region. The generalized scattering matrices are computed using the full-wave simulator Ansys HFSS for three sub-models. Then, the calculated S matrices are combined to evaluate the system’s PTE. The decomposition method is validated against full-wave simulations of the original WPT system’s model for several different parameter value combinations. The simulated results obtained for a sub-optimal model are experimentally verified by measuring the PTE of a real-life closet-based WPT system. The measured and calculated results are found to be in close agreement with the maximum measured PTE, as high as 60%. Full article

After a traditional one-time rocket is launched, most of its parts will fall into the atmosphere and burn or fall into the ocean. The parts cannot be recycled, so the cost is relatively high. Multi-stage rockets can be recovered after launch, which greatly reduces the cost of space launches. Moreover, recycling rockets can reduce the generation of waste and reduce pollution and damage to the environment. With the reduction in rocket launch costs and technological advances, space exploration and development can be carried out more frequently and economically. It provides technical support for the sustainable use of space resources. It not only promotes the sustainable development of the aerospace field but also has a positive impact on global environmental protection, resource utilization, and economic development. In order to adapt to the stage-by-stage separation structure of the rocket, this paper proposes a new multi-stage rocket inductive power transfer (IPT) system to power the rocket microgrid. The planar coil structure is used to form wireless power transfer between each stage of the rocket, reducing the volume of the magnetic coupling structure. The volume of the circuit topology structure is reduced by introducing an auxiliary coil. An equivalent three-stage S/T topology is proposed, and the constant voltage output characteristics of multiple loads are analyzed. A multi-stage coil structure is proposed to supply power to multiple loads simultaneously. In order to eliminate undesired magnetic coupling between coils, ferrite cores are added between coils for effective electromagnetic shielding. The parameters of the magnetic coupling structure are optimized based on the finite element method (FEM). A prototype of the proposed IPT system is built to simulate a multi-stage rocket. A series of experiments are conducted to verify the advantages of the proposed IPT system, and the three-stage rocket system efficiency reached 88.5%. This project is theoretical. Its verification was performed only in the laboratory conditions. Full article

In an underground inductive power transfer (IPT), it is inevitable to produce the phenomenon of misalignment between the transmitter and the receiver, which will reduce the output current, voltage and output efficiency of the whole IPT system. Aiming to solve this problem, a universal hybrid coupler is proposed, which can still stabilize the output in the expected range and has the ability of anti-misalignment when the X and Z directions are misaligned. The coupler is composed of a BP coupler and $\Gamma$ type network. The secondary edge of the coupler introduces a $\Gamma$ network, which decouples the two main coils on the same side of the receiver from the auxiliary coil and reduces the complexity of the system. The coupler can effectively reduce the coupling fluctuation caused by physical movement between the downhole transmitting end and the receiving end, thereby ensuring the stable output of the coupler. As a widely used IPT system, it can access the rest of the circuit topology whose output is independent of the load and achieve misalignment-tolerant output. Finally, based on the proposed hybrid IPT coupler theory, a 500 W misalignment-tolerant coupler prototype was built, and the compensation topologies were configured as series–series (SS) and series/inductance/capacitance/capacitor (S/LCC) structures. When the X and Z direction is misaligned, the constant current and voltage independent of the load can be output by switching the compensation topology. The experimental results are the same as the theoretical analysis. Full article

Capacitive power transfer (CPT) is a technology that is emerging as an alternative to inductive power transfer (IPT) in applications requiring low to medium power. A great interest has been developed in the implementation of CPT systems in battery charging systems, where a condition to compete with IPT systems is the need to increase the power transfer in the CPT systems without significant losses. This paper puts forth a design methodology for a stabilizing network, which has been applied to a CPT system. This methodology has been developed through impedance analysis of the circuit, in order to achieve maximum power transfer, with total gains of voltage and current reaching a value close to unity. The methodology allows for the calculation of the value of the components of the stabilizing network, which has been designed with the objective of stabilizing the resonant frequency against changes in the capacitance of the transmission plates. To validate the design procedure, an experimental prototype was developed at 25 W and an operational frequency of 1.55 MHz. The results obtained validate the design methodology. Full article
