Offshore wind farms are increasingly and rapidly expanding due to their ability to harness strong and consistent wind energy resources. Large offshore wind farms are connected to mainland grids through High-Voltage Direct Current (HVDC) technology. However, offshore wind farms can often experience disturbances related to sudden wind changes, voltage drops/dips, faults related to converter switching, and unbalanced grid conditions which affect both the HVDC operation and wind turbine output. As a result, there is a growing need for more advanced and reliable modeling and monitoring tools. Moreover, traditional proportional-integral (PI) controllers are widely applied in wind turbines and HVDC systems due to their simple structure, easy implementation, and reliability. However, PI controllers perform poorly under non-linear and abnormal/fast-changing conditions, especially during sudden drops in wind power and grid faults. With this background, this paper first develops a digital twin model of an offshore wind farm that enables remote operation and monitoring of individual wind turbines. Also, an artificial intelligence (AI)-based controller, namely a fuzzy logic controller (FLC), is proposed to maintain transient stability of a full digital twin-based offshore wind farm connected to the HVDC grid under fault conditions. The effectiveness of the proposed FLC is demonstrated by considering a digital twin-enabled 700 MW offshore wind farm. The performance of the proposed FLC has been compared with that of the PI controller. Simulations performed by the MATLAB/Simulink software show that during the moderate voltage dip at 15 s, the PI controller experienced a 29.8% power reduction with a recovery time of approximately 9 s, whereas the FLC reduced the power drop to 23.1% and recovered within 6 s. During the severe converter disturbance at 15 s, the PI controller recorded a 36.9% power reduction compared to 23.4% for the FLC. Similarly, during the short-duration turbulence at 15 s, the PI controller exhibited a 36.73% power drop and recovered in approximately 7 s, while the FLC limited the power reduction to 19.17% and recovered within 5s. Overall, the FLC provided improved voltage stability, faster recovery, reduced oscillations, and superior fault ride-through capability compared with the conventional PI controller, demonstrating its effectiveness for digital twin-enabled offshore wind farm application. Full article

Multi-terminal voltage-source-converter-based HVDC (VSC-MTDC) systems are increasingly used to integrate renewable energy and interconnect asynchronous AC grids, but conventional fixed-coefficient droop control cannot simultaneously limit DC-voltage deviations, reduce operating losses, and preserve converter power margins during operating-point switching. This paper hypothesizes that a rule-based fuzzy adjustment of the droop slope can provide smooth multi-objective coordination without inter-station communication. A dual Mamdani fuzzy controller is developed: one controller adjusts the weighting between loss-oriented and power-margin-oriented droop coefficients according to converter power margin, while the other introduces a voltage-deviation correction according to DC-bus voltage. The controller is implemented and verified in a five-terminal MMC-based VSC-MTDC model built in PSCAD/EMTDC, where simulation data are generated under heavy-load, light-load, and power-reference switching scenarios using specified line and converter parameters. Compared with conventional droop control, the proposed strategy improves power-margin utilization, reduces operating-point discontinuities, and raises the minimum DC voltage from 370.2 kV to 381.4 kV in the severe switching case. The results confirm that fuzzy-slope droop control can achieve smoother operating-point switching and better coordinated optimization among voltage stability, operating loss, and converter reserve margin. Full article

In the context of the new power system, modular multilevel converter high-voltage direct current (MMC-HVDC) has become a key technical solution for the large-scale grid integration of wind power. However, when a fault occurs in the AC grid at the system receiving end, the high-voltage direct current (HVDC) system faces challenges such as wind power redundancy, DC overvoltage, and equipment overcurrent. To address this, this paper proposes an energy storage-coordinated fault ride-through (FRT) control strategy suitable for different fault scenarios. The strategy optimizes the allocation of energy storage capacity according to the state of charge (SOC) of the energy storage units (ESUs), preventing individual ESUs from prematurely shutting down and reducing energy dissipation. Finally, a comparison with a conventional DC dissipation resistor scheme on the PSCAD/EMTDC platform demonstrates that the proposed strategy provides smoother power regulation characteristics and smaller DC voltage fluctuations, thereby enhancing the economic efficiency and reliability of system operation. Full article

In the context of the “dual-carbon” target, the large-scale integration of renewable energy sources leads to an increased risk of transient voltage instability at the high voltage direct current (HVDC) transmission receiving end. The HVDC transmission system possesses fast and accurate power regulation capability. After a fault occurs near the inverter station, reducing the DC current enables the reactive power from the compensation devices to be released and injected into the receiving-end power grid, thereby providing emergency voltage support for the receiving-end grid. To reduce control costs, an optimization model constrained by transient voltage violation is established, and the DC current modulation is acquired via an online solution. To maintain system stability and meet the requirements of online applications, it is crucial to rapidly solve the optimization model based on the grid operating mode and contingency information to update the emergency control strategy table in the special protection system (SPS). Conventional global orthogonal collocation (GOC) and adaptive orthogonal collocation (AOC)-based solution methods transform the optimization model in the continuous time domain into a nonlinear programming (NLP) problem for solution, which addresses the low efficiency of traditional rolling optimization. However, the GOC- and AOC-based solution methods improve the discretization accuracy of the model by pursuing global uniform densification of collocation points, making it difficult to balance solution accuracy and solution efficiency. To this end, this paper proposes an efficient interval partition dynamic adaptive orthogonal collocation (IP-DAOC)-based solution method. Firstly, the overall optimization time window is interval-partitioned into multiple initial intervals, and an interval-partitioned transient voltage stability emergency control optimization model is established. Furthermore, the interval length and the number of collocation points are dynamically adjusted according to the curvature of interpolation polynomials at collocation points in different intervals. Finally, after interval adjustment, the dynamic equations discretized in adjacent intervals are made continuous by reconstructing the differential matrix. This solution method reduces the total number of collocation points, thereby decreasing the scale of the NLP problem and narrowing the search space, significantly improving solution efficiency while ensuring solution accuracy. To verify the effectiveness of the proposed solution method, simulations are carried out on a modified IEEE 14-bus system. The results are compared with those of the traditional GOC- and AOC-based solution methods, which further demonstrate the superiority of the proposed solution method. Full article

As renewable energy is increasingly integrated via high-voltage direct current (HVDC) transmission, hybrid multi-infeed receiving-end grids containing both line-commutated converters (LCC) and modular multilevel converters (MMC) have become common, and wideband resonance problems in power-electronized networks are growing more prominent. This paper proposes an active resonance analysis and suppression strategy for such systems. First, a wideband current source converter model and a wideband voltage source converter model are adopted to describe the LCC and MMC, respectively, and a positive-sequence s-domain model of the system is established. A two-stage s-domain nodal admittance matrix method is then applied to efficiently determine the wideband resonance modes and the corresponding mode shape eigenvectors. A dual criterion combining the matching degree between resonance frequencies and LCC characteristic harmonics with the modal damping ratio identifies high-risk resonance modes. On this basis, an active damping strategy that realizes a parallel virtual resistance on the AC side through MMC supplementary control is proposed, together with a quantitative design method for the virtual conductance. At the control implementation level, a modulation wave reconstruction bypass injection scheme superimposes the high-frequency damping command directly in the αβ stationary reference frame, thereby bypassing the PI controller and reducing the amplitude attenuation and phase distortion caused by the high-frequency limitation of the integral path. PSCAD/EMTDC simulation results on an IEEE 9-bus test system demonstrate that the proposed strategy effectively suppresses resonance amplification and wideband power oscillations excited by LCC characteristic harmonics without affecting the fundamental power transmission. Full article

Commutation failure is likely to occur when an AC fault occurs at the receiving end of an LCC-HVDC system. This threatens transient stability. Conventional commutation failure prevention (CFPREV) control mainly responds to commutation-voltage magnitude variation. However, commutation-voltage phase variation is not fully considered. Its fixed start-up threshold also makes it difficult to adapt to different fault severities. To address these problems, this paper establishes a transient nonlinear large-signal model of the inverter. The model incorporates power angle variation and describes the coupled effects of DC current rise, commutation-voltage drop, and power angle deviation on the extinction angle. Phase-portrait analysis is then used to illustrate the transient evolution and critical characteristics of first commutation failure (FCF). The critical commutation voltage is predicted under different fault severities and further converted into a dynamic CFPREV start-up threshold. Simulations based on the CIGRE LCC-HVDC benchmark model verify the prediction accuracy. They also show that the improved CFPREV strategy suppresses FCF mainly by starting up at an appropriate instant rather than increased compensation strength. Full article

In hybrid-series-converter-based LCC-HVDC systems, controllable capacitor modules can provide additional voltage–time area during commutation, thereby improving inverter-side fault tolerance under AC faults. However, their switching behavior makes the commutation path impedance state-dependent, while most existing commutation-failure prediction methods still rely on fixed-reactance assumptions. To address this problem, this paper proposes a reactance-corrected predictive control and coordinated switching method. First, a capacitor switching coefficient is introduced to describe the insertion state of the controllable capacitor modules, and an equivalent commutation reactance of the HSC valve arm is derived. Then, the corrected reactance is incorporated into an extinction-angle margin index and an energy-margin index to quantify the influence of reactance variation on commutation capability. A segmented firing-angle controller with smooth compensation is further designed, and energy-margin feedback is coordinated with capacitor insertion control. PSCAD/EMTDC simulations verify that the proposed method reduces prediction error, provides a prediction lead time of 0.7–4.5 ms, and improves fault ride-through capability. Full article

In receiving-end modular multilevel converter (MMC)-based flexible high-voltage direct current (HVDC) grid-connected systems, high-frequency oscillation can significantly increase the peak values of the point of common coupling (PCC) voltage and grid current. To address this issue, this paper proposes a coordinated suppression strategy for high-frequency oscillation in receiving-end MMC grid-connected systems. First, an MMC impedance model is established based on harmonic linearization, and its frequency-domain interaction with the grid impedance is analyzed to clarify the formation mechanism of high-frequency oscillation and its main influencing factors. Then, considering the different roles of the voltage feedforward and current feedback channels in the target frequency band, a coordinated suppression strategy combining band-stop filtering in the voltage feedforward path with low-pass filtering and lead compensation in the current feedback path is designed. Hardware-in-the-loop experimental results show that the proposed method effectively identifies and suppresses high-frequency oscillation. Under the validated operating condition, the oscillation-induced peak increases in the PCC voltage and grid current are limited to within 20% and 12.5%, respectively, thereby suppressing further oscillation growth and reducing the risk of approaching the overvoltage and overcurrent protection thresholds. Full article

With the large-scale integration of renewable energy sources, the stability and control of flexible DC (VSC-HVDC) grid-connected systems have become critical issues. This paper proposes an optimal configuration strategy for the control parameters of grid-forming VSC-HVDC systems considering multiple operational constraints. First, a state-space model of the grid-forming VSC-HVDC system connected to a wind farm is established, and the effects of key control parameters on the small-signal stability are analyzed using eigenvalue and participation factor methods. Then, based on the stability analysis, an optimization model is constructed with the objectives of minimizing the steady-state DC operating voltage under operational constraints and maximizing system damping. To solve the optimization problem, the NSGA-II genetic algorithm is employed. Case studies in MATLAB/Simulink demonstrate that the proposed method effectively enhances the small-signal stability of the system across various operating points, reduces overshoot and settling time during power step changes, and ensures stable operation under the maximum transferable power limit. The results verify the robustness and effectiveness of the proposed parameter configuration strategy, providing a practical approach for the design and tuning of grid-forming VSC-HVDC systems in renewable energy integration applications. Full article

With the rising trend of replacing synchronous generators with inverter-based resources, the grid inertia, frequency control, voltage stability, and fault ride-through are compromised. The current research focuses on the coordinated control of Voltage Source Converter-based HVDC (VSC HVDC) and Battery Energy Storage Systems (BESS) for improving the grid stability in the presence of intermittent sources. Two models are created in the MATLAB/Simulink 2025a environment: one for the grid-connected PV system with the addition of BESS in grid-forming mode (GFM) and grid-following mode (GFL), and the other for the multi-terminal HVDC system with the integration of wind energy from the ocean. The results show that the grid-forming converters perform better than grid-following converters in the event of disturbances, and the coordinated control structure aligns with the IEEE 2800-2022 for low-inertia grids. Full article

This paper presents a measurement-based framework for studying and mitigating control interactions between power system stabilizers (PSSs) and HVDC modulation damping controllers in hybrid AC/DC systems. Using frequency-response data obtained from small-signal injections, the method embeds driving-point and transfer impedance directly into the control loops, eliminating reliance on simplified analytical models. A lightweight optimizer adjusts controller gains and lead–lag angles to enhance damping at the inter-area mode while ensuring HVDC-to-PSS dominance, magnitude-crossing consistency, and a minimum damping margin across the 0.3–1.5 Hz band. The approach, implemented in ETAP 16.0 and MATLAB R2024a (MathWorks, Natick, MA, USA), successfully improves damping and maintains stability under all tested conditions, providing a practical co-design strategy for coordinated PSS–HVDC control in weakly interconnected networks. Full article

Some previous studies argue that under the conditions of a double line to ground fault at the point of common coupling at the inverter end, the AC grid voltage of phases A and B will decrease along with the same level while the phase C will maintain at a stable steady state and this will lead to an excess increase in the voltage level of the high voltage direct current (HVDC) link. Presented in this paper is a model that comprises the hybrid multiterminal line commutated converters and the voltage source converter HVDC system. This model was mathematically modelled and implemented on Matlab/Simulink software in order to investigate the fault behavior, with a particular emphasis on double line to ground fault at different fault resistances. The system under study consists of a fault switch timer, photovoltaic solar array, wind energy conversion system, inverter control for the voltage source converter, Inductor–capacitor–inductor (LCL) filter and PI section line. The findings of this study indicated that during the double line to ground fault at varying fault resistances, the AC grid voltage in phase A will experience a more pronounced decrease compared to phase B. In contrast, phase C will exhibit only a slight reduction in voltage at the inverter end. Similarly, at the inverter end of the hybrid system, it was observed that the AC grid currents for the affected phases, specifically phases A and B, will experience an increase. It is further discovered that phase C will maintain relatively stable condition without increasing or decreasing during a double line to ground fault event. In addition, it is noted that the HVDC link voltage will decrease while the HVDC link current will increase depending on any fault resistance values. Thus, the inferences as a result of this study are presented in this paper. Full article

This paper presents a Nyquist-based method for assessing control interactions between a Power System Stabilizer (PSS) and an HVDC Modulation Supplementary Damping Controller (MSDC) in hybrid AC/DC networks. Loop-at-a-time perturbations are applied to reveal how one controller deforms the other’s Nyquist contour, directly exposing frequency-dependent coupling. A spectral-radius margin is introduced as a quantitative robustness indicator. Reduced-order transfer functions identified using the Matrix Pencil Method enable accurate frequency-response analysis from transient-stability data. Application to Kundur’s two-area system with an embedded LCC–HVDC link demonstrates that the method clearly exposes controller dominance, interaction severity, and gain-sensitivity effects. The proposed framework thus provides a practical and measurement-compatible means for visualizing and coordinating damping controllers in weak hybrid AC/DC networks. Full article

With the rising proportion of renewable energy in power systems, electricity markets are confronting escalating challenges driven by the accumulation of imbalance funds, especially in high renewable penetration sending-end grids with large-scale high voltage direct current (HVDC) transmission. Existing studies have not fully addressed the impact of renewable energy volatility and HVDC plan deviations on imbalance settlement, and lack an optimization framework that balances market fairness and system security constraints. This paper takes the electricity market of a northwestern province in China as the research object, first identifies the main sources of imbalance funds, and then develops a multi-objective settlement optimization model centered on minimizing imbalance funds, which integrates system power balance, nodal voltage limits, generation plan deviation, and HVDC transmission constraints. A responsibility attribution-based imbalance fund allocation mechanism is further proposed to improve market fairness. Empirical analysis based on actual market data shows that the optimized settlement mechanism reduces imbalance funds by an average of 28.9% under typical scenarios, and significantly improves market operational efficiency. This study provides a practical solution for the sustainable development of high renewable penetration electricity markets. Full article

Renovating the grid structure by converting existing transmission lines into VSC-HVDC transmission lines can address issues such as limited transmission capacity and excessive short-circuit current in load-concentrated areas. To effectively evaluate the effectiveness of grid structure renovation and provide a reference for selecting suitable renovation sites, this paper proposes a comprehensive evaluation method for assessing the effectiveness of grid structure renovation. Firstly, an evaluation indicator system is constructed from four aspects. Then, the Fuzzy Analytic Hierarchy Process (FAHP) and Entropy Weight Method (EWM) are used to determine the subjective weight and objective weight of each indicator, and a game theory-based combined weighting method is applied to obtain the combined weight, which is then used to calculate the comprehensive evaluation value before and after renovation to reflect the effectiveness of the renovation. Subsequently, the TOPSIS method is employed for comparative verification of the evaluation method’s validity, and a sensitivity analysis is conducted on the subjective weight to confirm the method’s robustness to subjective preference. Finally, based on the indicator data obtained from the PSD-BPA simulation, the effectiveness of renovating eight scenarios in a provincial power grid is evaluated. The results show that grid structure renovation can enhance power grid performance in load centers. Full article
