Search Results (45)

Diffractive optical elements (DOEs) offer significant advantages over conventional refractive optics, particularly in non-visible spectral regions such as ultraviolet, gamma rays, and X-rays, where material limitations restrict traditional optical components. Owing to their design flexibility, DOEs enable the generation of complex beam profiles—including circular, vortex, and Airy beams—across a wide range of wavelengths. Despite their structural simplicity and compatibility with micro- and nanoscale fabrication, conventional DOEs often suffer from limited focusing efficiency, frequently requiring additional refractive lenses that introduce optical aberrations, increased system complexity, and higher cost. In this work, we present an integrated design and fabrication approach for micro-scale diffractive optical elements capable of achieving high focusing performance without reliance on supplementary optical components. A machine learning-based decision tree method is employed to generate optimized writing paths, which are subsequently fabricated using direct laser lithography. The proposed integrated DOE structures enable efficient focusing of multiple customized beam profiles within a compact and standalone optical element. This approach improves optical efficiency while maintaining low fabrication cost and system simplicity. The demonstrated integrated micro-DOEs provide a scalable and versatile platform for advanced beam shaping and focusing applications in photonics, particularly where compactness and performance are critical. Full article

Tunable metalenses are planar optical elements that hold immense potential in the field of integrated optics, enabling reconfigurable focusing without the bulkiness associated with traditional lenses. This study proposes an electrically tunable metalens which integrates poly(3,4-ethylenedioxythiophene)–polystyrenesulfonate (PEDOT:PSS) with a metasurface. The focal length is electrically controlled through electrochemical modulation of the PEDOT:PSS film thickness and deintercalation in an electrolyte. The Fresnel zone plate (FZP) design is employed to simplify the phase profile and reduce optimization complexity. More importantly, the modulated PSO algorithm is implemented to inverse-design the units and suppress inter-unit phase crosstalk. Simulation results demonstrate that the metalens achieves diffraction-limited focusing, with a zoom ratio reaching 10:1. This work provides a feasible strategy for developing high-performance dynamically tunable metalens, with promising applications in miniaturized imaging, microscopy, and integrated photonic systems. Full article

This work presents a methodology for designing deployable reflector antennas that combine origami structures and the Fresnel zone plate lens to obtain a compact antenna structure. In particular, Miura and Yoshimura’s origami patterns have been considered for the design of the Fresnel reflector mirror and the conical horn antenna feeder, respectively. A set of memory-form alloy (MFA) actuators have been used to deploy the antenna. The MFA actuators are activated by a direct current aimed at increasing the temperature and activating the memorized shape. The combination of these techniques provides light, inexpensive, and very compact antennas, particularly suitable for satellite applications. A numerical and experimental assessment campaign has been carried out on antenna prototypes operating in the $K_u$ band at 15 GHz. The obtained experimental results are quite promising. Full article

Transcranial focused ultrasound (TcFUS) neuromodulation is hindered by skull-induced acoustic limitations. To enable synergistic multi-region brain stimulation, we designed non-coaxial multi-focal composite Fresnel acoustic lenses, including an overlapping Fresnel lens (OFL) and an alternating-segmented Fresnel lens (ASFL). These lenses convert planar ultrasound into multiple foci. Based on Fresnel theory, acoustic fields were analyzed via simulations and experiments, validating the generation of four non-coaxial foci (10/30 mm focal lengths) from a 1 MHz planar wave using both OFL and ASFL. The influence of lens parameters on focal pressure distribution was investigated, and morphology was quantified using a linear least-squares method. Significant differences in focal morphology and intensity between OFL and ASFL provide crucial guidance for optimizing multi-target TcFUS strategies. Full article

In this study, novel focusing performances of high-numerical-aperture (NA) micro-Fresnel zone plates (FZPs) with selective occlusion are identified and investigated through numerical calculations based on vectorial angular spectrum (VAS) theory, and further rigorously validated using the finite-difference time-domain (FDTD) method. The central occlusion of a standard micro-FZP can significantly extend the depth of focus while keeping the lateral size of the focusing spot essentially unchanged. When a standard micro-FZP only retains two separated transparent rings and all other rings are obstructed, it will result in multi-focus phenomena; at the same time, the number of focal points is equal to the difference in number between the two separated transparent rings. Furthermore, a focusing light needle can be generated by combining the central occlusion and wavelength shift of a standard micro-FZP. This study not only provides new ideas for the design and optimization of micro-FZPs but also provides reference for the expansion of practical applications of FZPs. Full article

The practical implementation of terahertz (THz) imaging and spectroscopic systems in real operational conditions requires them to be of a compact size, to have enhanced functionality, and to be user-friendly. This work demonstrates the single-sided integration of Fresnel-zone-plate-based optical elements with InGaAs bow-tie diodes directly on a semiconductor chip. Numerical simulations were conducted to optimize the Fresnel zone plate’s focal length and the InP substrate’s thickness to achieve constructive interference at 600 GHz, room-temperature operation and achieve a sensitivity more than an order of magnitude higher—up to 24.5 V/W—than that of a standalone bow-tie detector. Investigations revealed the strong angular dependence of the incident radiation on the Fresnel zone plate-integrated bow-tie diode’s response. These findings pave a promising avenue for the further development of single-sided integration of flat optics with THz detectors, enabling improved sensitivity, simplified manufacturing processes, and reduced costs for THz detection systems in a more compact design scheme. Full article

Based on additive manufacturing via photopolymerization, this study combines polymer-dispersed liquid crystal (PDLC) technology with 3D printing technology to produce tunable micro-optical components with switchable diffraction or focusing characteristics. The diffraction grating and Fresnel zone plate are the research targets. Their structures are designed and simulated to achieve expected optical functions. A liquid crystal display (LCD) 3D printer is used to produce structures on transparent conductive substrates. The printed structures are filled with PDLCs and covered with transparent conductive substrates to achieve tunable functions. The proposed configurations are implemented and verified. The experimental results show that the diffraction efficiency of the 0th order increases from 15% to 50% for the diffraction grating and the focusing spot intensity decreases from 74% to 12% after the application of an electric field. These results demonstrate the feasibility of the proposed tunable optical component configurations. Full article

The ability to manufacture complex 3D structures with nanometer-scale resolution, such as Fresnel Zone Plates (FZPs), is crucial to achieve state-of-the-art control in X-ray sources for use in a diverse range of cutting-edge applications. This study demonstrates a novel approach combining Electron Beam Lithography (EBL) and cryoetching to produce silicon-based FZP prototypes as a test bench to assess the strong points and limitations of this fabrication method. Through this method, we obtained FZPs with 100 zones, a diameter of 20 µm, and an outermost zone width of 50 nm, resulting in a high aspect ratio that is suitable for use across a range of photon energies. The process incorporates a chromium mask in the EBL stage, enhancing microstructure precision and mitigating pattern collapse challenges. This minimized issues of under- and over-etching, producing well-defined patterns with a nanometer-scale resolution and low roughness. The refined process thus holds promise for achieving improved optical resolution and efficiency in FZPs, making it viable for the fabrication of high-performance, nanometer-scale devices. Full article

This paper presents the mission analysis of ³Cat-8, a 6-Unit CubeSat mission being developed by the UPC NanoSat Lab for ionospheric research. The primary objective of the mission is to monitor the ionospheric scintillation of the aurora, and to perform several technological demonstrations. The satellite incorporates several novel systems, including a deployable Fresnel Zone Plate Antenna (FZPA), an integrated PocketQube deployer, a dual-receiver GNSS board for radio occultation and reflectometry experiments, and a polarimetric multi-spectral imager for auroral emission observations. The mission design, the suite of payloads, and the concept of operations are described in detail. This paper discusses the current development status of ³Cat-8, with several subsystems already developed and others in the final design phase. It is expected that the data gathered by ³Cat-8 will contribute to a better understanding of ionospheric effects on radio wave propagation and demonstrate the feasibility of compact remote sensors in a CubeSat platform. Full article

Ultrasonic focusing transducers have broad prospects in advanced ultrasonic non-destructive testing fields. However, conventional focusing methods that use acoustic concave lenses can disrupt the acoustic impedance matching condition, thereby adversely affecting the sensitivity of the transducers. In this paper, an active focusing planar ultrasonic transducer is designed and presented to achieve a focusing effect with a higher sensitivity. An electrode pattern consisting of multiple concentric rings is designed, which is inspired by the structure of Fresnel Zone Plates (FZP). The structural parameters are optimized using finite element simulation methods. A prototype of the transducer is manufactured with electrode patterns made of conductive silver paste using silk screen-printing technology. Conventional focusing transducers using an acoustic lens and an FZP baffle are also manufactured, and their focusing performances are comparatively tested. The experimental results show that our novel transducer has a focal length of 16 mm and a center frequency of 1.16 MHz, and that the sensitivity is improved by 23.3% compared with the conventional focusing transducers. This research provides a new approach for the design of focusing transducers. Full article

We propose a new vortex lens for producing multiple focused coaxial vortices with approximately equal intensities along the optical axis, termed equal-intensity multi-focus composite spiral zone plates (EMCSZPs). In this typical methodology, two concentric conventional spiral zone plates (SZPs) of different focal lengths were composited together and the alternate transparent and opaque zones were arranged with specific m-bonacci sequence. Based on the Fresnel–Kirchhoff diffraction theory, the focusing properties of the EMCSZPs were calculated in detail and the corresponding demonstration experiment was been carried out to verify our proposal. The investigations indicate that the EMCSZPs indeed exhibit superior performance, which accords well with our physical design. In addition, the topological charges (TCs) of the multi-focus vortices can be flexibly selected and controlled by optimizing the parameters of the zone plates. These findings which were demonstrated by the performed experiment may open new avenues towards improving the performance of biomedical imaging, quantum computation and optical manipulation. Full article

Similar to optical vortex beams, terahertz (THz) vortex beams (TVBs) also carry orbital angular momentum (OAM). However, little research has been reported on the generation of TVBs. In this paper, based on the detour phase technique, we design a series of spintronic terahertz emitters with a helical Fresnel zone plate (STE-HFZP) to directly generate focused TVBs with topological charges (TCs) of l = ±1, ±2 and ±3, respectively. The STE-HFZP is a hybrid THz device composed of a terahertz emitter and a THz lens, and it has a high numerical aperture (NA), achieving subwavelength focal spots. Its focus properties are surveyed systemically through accurate simulations. This STE-HFZP can also generate focused TVBs with higher order TCs. More importantly, the components of the focused electric field with OAM make up the majority of the intensity and have potential applications in the field of THz communications, THz imaging and atom trapping. Full article

Metalenses are planar optical components that have demonstrated immense potential for integrated optics. In particular, they are capable of high-efficiency subwavelength focusing without the bulkiness of traditional lenses. Dielectric metalenses operating in the C-band typically employ relatively tall, amorphous silicon structures arranged in a periodic array. Phase control spanning from 0 to 2π is accessed by varying the geometry of these scattering structures. The full 2π phase range is necessary to impose a hyperbolic focusing phase profile, but this is difficult to achieve without custom fabrication practices. In this work, we propose a binary phase Fresnel zone plate metalens designed for the standard 500 nm silicon-on-insulator platform. Our design uses subwavelength gratings with trapezoidal segmentation to form concentric rings. The effective index of the grating is set with the duty cycle using a single full-etch step to form the binary phase profile of the zone plate. The metalens design can be easily tuned to achieve longer focal lengths at different wavelengths. It offers a simple platform for high-throughput wavelength-scale focusing elements in free-space optics, including for microscopy and medical imaging. Full article

In this work, we present a comparative analysis of different numerical methods to obtain the focusing properties of the zone plates based on Fibonacci and Cantor sequences. The Fresnel approximation was solved numerically in order to obtain the axial irradiance provided by these diffractive lenses. Two different methods were applied. The first one is based on numerical integration, specifically the Simpson integration method and the two-dimensional Gaussian quadrature. The second consisted in the implementation of the Fast Fourier Transform in both one and two dimensions. The axial irradiance of the lenses, the relative error with respect to the analytical solution, and the calculation time required by each method are analyzed and compared. From this analysis it was concluded that the Gauss method presents the best balance between accuracy and computation time. This analysis could be useful to decide the most convenient numerical method to be used for the study of more complex diffractive structures. Full article

In recent years, micro-annular beams have been widely used, which has expanded the possibilities for laser processing. However, the current method of generating an annular beam still has shortcomings, such as spot energy at the center of the produced beam. In this study, a Fresnel zone plate with an annular structure was machined using a femtosecond laser. After focusing, an annular laser beam without a spot in the center was obtained, and the radius and focal length of the annular beam could be easily adjusted. In addition, two annular Fresnel zone plates were concentrically connected to obtain a concentric double-ring beam in the same focal plane. The simulation and experimental results were consistent, providing effective potential for applications related to nontraditionally shaped laser beams. Full article
