Search Results (3,435)

To investigate how lateral impact influences the residual axial resistance capacity of cross-shaped steel-reinforced concrete (CSRC) columns, the residual axial resistance test was carried out following impact test. A finite element model (FEM) was developed to simulate axial and lateral impact loading, and its accuracy was confirmed through comparison with test results. The analysis shows that the numerical model can simulate the impact force, deflection, deformation mode and residual axial resistance of the column with adequate accuracy. With the verified finite element models, the residual axial resistance (N_r) of CSRC columns under six different parameters was further analyzed. Results demonstrate that the column primarily undergoes flexural deformation under impact, whereas shear effects are localized at the impact zone. A higher structural steel ratio (α) and yield strength of the cross-shaped steel (q) contribute to improved N_r and reduced mid-span displacement (Δ_max). With the increase in compressive strength of concrete (c) and axial compression ratio (n), the N_r increases to a certain level and then decreases, and the Δ_max decreases first and then increases in a similar manner. The change in slenderness ratio (γ) in a small range can improve the N_r of the column, and the significant increase in γ results in instability and failure. In particular, when the slenderness ratio increases from 8 to 12, the residual bearing capacity of the column decreases by 19.4%. This study proposes a residual bearing capacity-prediction formula based on seven key influencing parameters, which shows high accuracy (R² = 0.93). A damage evaluation index based on flexural bearing capacity (D_dag) is introduced, and the structural state is accordingly classified into four damage levels. Compared with conventional numerical simulations that typically require more than 3 h of computation time, the proposed method can rapidly complete the damage assessment of columns within 5 min, providing an efficient approach for structural safety evaluation and response strategies. Full article

Timber beams have assumed a prominent role in contemporary structural engineering, driven by sustainability requirements and the advancement of engineered wood products. Despite the evident environmental and building advantages, the performance of timber beam elements under fire conditions remains one of the main design challenges, due to the strong nonlinearity of thermal behavior, progressive charring, and degradation of mechanical properties. In this context, numerical simulations have become a central tool for the thermal and thermomechanical assessment of timber beams exposed to fire. This study presents a technical and critical review of numerical approaches applied to timber beam elements, with emphasis on finite element–based models, thermal modeling strategies, representation of charring, thermomechanical coupling, and the use of reduced-order and surrogate models. The distinctive contribution of this work lies in an integrated and critical analysis of these approaches, explicitly articulating high-fidelity numerical models with reduced-order and symbolic models, aiming at their use as complementary tools in structural design. The analysis was conducted thematically, based on literature selected from major international databases, emphasizing modeling assumptions, levels of numerical complexity, and methodological limitations. The results indicate a predominance of transient finite element (FEM) models, widespread use of two-dimensional cross-sectional analyses, increasing adoption of enthalpy-based formulations for charring, and a prevalence of sequential thermomechanical coupling strategies. In contrast, the literature reveals strong heterogeneity in thermal parameters, limited standardization of validation procedures, restricted use of probabilistic approaches, and still incipient integration of reduced-order and symbolic models. It is concluded that future advances in the field depend on the standardization of modeling strategies, the expansion of thermal property databases, and, above all, the integration of high-fidelity models with interpretable reduced-order models, capable of supporting parametric analyses and performance-based structural design methodologies. Full article

In the current numerical simulation study of high-strength steel welding, ignoring the phase transformation plasticity effect in the coupling analysis led to a significant deviation between the simulated value of residual stress and the experimentally measured value. To investigate the influence mechanism of the Welding Residual Stresses (WRSs) of 30MnCrNiMo armor steel, the transformation plasticity (TP) coefficient (7.81 × 10⁻⁵ MPa⁻¹) was measured via a Gleeble 3500, and a Finite Element Model (FEM) of thermal–metallurgical–mechanical coupling considering yield strength, volumetric strain and TP behavior in Solid-State Phase Transformation (SSPT) was developed. The results show that the volume expansion during the SSPT is the main factor for the shift in WRS from tensile to compressive. In contrast, the TP effect reduces the peak longitudinal tensile stress in the Heat-Affected Zone (HAZ) by 51 MPa. It also ultimately neutralizes the compressive component in this region. When the martensite fraction ranges from 0.12 to 0.45, transformation plastic strain becomes the dominant factor, leading to a characteristic evolution of longitudinal stress that initially decreases and subsequently increases. The FEM incorporating the TP effect successfully captures the dual reversals of residual stress in the HAZ. The average relative error between the simulated longitudinal stress and the experimental data obtained via X-ray diffraction (cosα method) is 8.8%. The TP coefficient database and the developed multi-field coupling model markedly enhance the predictive accuracy for WRS in 30MnCrNiMo steel, offering a robust theoretical foundation for the design of stress corrosion resistance and the service life assessment of welded joints in armored vehicles. Full article

This study examines the seismic stability of an underground powerhouse cavern located in the Lesser Himalayan region of Nepal. Both static and seismic loading conditions are analyzed using the finite element method (FEM) and the distinct element method (DEM). Rock mass properties are derived from field investigations and laboratory testing, while empirical correlations are applied to estimate rock mass strength and deformation modulus. Pseudo-static analyses are performed using the FEM-based software Rock and Soil-2-Dimensionsl (RS²) Version 11.027, and dynamic analyses are conducted using the DEM-based software Universal Distinct Element Code (UDEC) Version 5.0 to evaluate deformation and stress redistribution around the cavern. Seismic fragility curves are developed to quantify the probability of damage under varying seismic intensities. Results indicate that a peak ground acceleration (PGA) of 0.25 g increases cavern wall deformation by approximately 15–20 mm compared to static conditions. Fragility analysis shows a probability exceeding 68% for slight damage, while the probability of collapse remains low at approximately 1.7%. Seismic loading also significantly alters stress redistribution along the cavern boundary. Overall, the combined use of numerical modeling and fragility analysis provides a probabilistic framework for assessing seismic risk in underground caverns, offering valuable insights for the design and safety evaluation of hydropower projects in seismically active Himalayan regions. Full article

Notch wear in austenitic stainless steel turning develops rapidly and remains a key productivity limitation with carbide tools. This work identifies the initiation mechanism of notch wear when turning EN 1.4307 stainless steel using CVD-coated cemented carbide inserts with an Al₂O₃ top layer. Turning tests were performed under dry conditions, followed by optical wear measurements and chip surface analysis. The tool–chip interface chemistry and material transfer were characterized using SEM/EDS, while high-frequency acoustic emissions were recorded to resolve the dynamics of adhesive events. Thermo-mechanical FEM simulations were conducted to map contact pressure and temperature along the cutting edge. The results show that adhesive wear initiates immediately at engagement and governs notch formation: polluted SiO₂ deposits act as an active bonding medium, and repeated bond formation/rupture removes extremely thin flakes of tool and coating material, evidenced by Al₂O₃ and Ti(C,N) fragments on the chip and by characteristic acoustic cluster waves. A new tool–chip contact model is presented, indicating that high pressure and high temperature within the polluted SiO₂ near the chip’s outmost side promote larger, stronger adhesive bonds together with the absence of ceramic particles near the rake in the notch area. Oxidation and diffusion are assumed to be secondary processes that become relevant after local coating loss, while adhesion remains the primary removal mechanism during early and intermediate stages. Full article

The seamless flatness roll is a critical inspection device in cold-rolled strip flatness control systems. Prolonged service causes cracks and scratches on the roll surface, while repeated grinding gradually removes the hardened layer, potentially rendering the roll unusable. To address the risk of thermal damage to internal sensors during the laser cladding repair of seamless flatness rolls, this study proposes a process optimization strategy using the Finite Element Method (FEM) and Response Surface Methodology (RSM). Focusing on an 820 mm roll, a regression prediction model for laser spot and internal component temperatures was constructed using a Box–Behnken design (BBD) based on an experimentally calibrated FEM model. Multi-objective optimization determined the optimal process parameters: laser power of 1.43 kW, laser radius of 3.73 mm, scanning speed of 23.45 mm/s, and overlap rate of 50.40%. Under these conditions, the average error between the predicted and experimental results was only 4.14%. The results confirm that the optimized process ensures the formation of a molten pool while maintaining internal components within safety thresholds, validating the feasibility of this non-destructive repair method. Full article

This research investigates the colonnade of Tomb 7 at the UNESCO World Heritage site of the Tombs of the Kings in Paphos, Cyprus. Specifically, a multi-drum column located at the south-east corner of the tomb is examined from both geometric and structural perspectives. Being the only standing element to support the entablature on that side of the tomb, the column is crucial for maintaining the structural stability of the monument. Numerical structural analyses are performed on the column via the finite element method (FEM), supported by close-range recording techniques—particularly terrestrial laser scanning (TLS)—to generate finite element (FE) models. Several modelling strategies capable of converting point cloud data into reliable structural models are developed and compared with the aim of identifying the most effective and cost-efficient approach. Each method is analyzed in detail to evaluate its workflow, assumptions, strengths, and limitations in the context of heritage structures with complex irregular geometries. Linear static and dynamic analyses are performed on five different FE models to assess the column’s mechanical response and to understand how differences in geometric representation affect the structural behaviour. The results indicate that all approaches adequately capture the general structural response. The comparison of the different modelling strategies highlights the trade-offs between geometric accuracy, computational efficiency, and practical usability. These outcomes indicate the potential and the current limitations of exploiting point cloud data for structural analysis and contribute to the development of more robust and accurate scan-to-FEM methodologies for the conservation and assessment of cultural heritage structures. Full article

Stiffened panels are fundamental structural components that maintain the integrity of engineering structures subjected to torsional loading, making accurate strength assessment essential in design and evaluation. Conventional finite element method (FEM) analyses often involve complex geometric modeling and extensive pre-processing, which can reduce efficiency and limit practical applicability. This study presents a structured FEM-based framework supported by a Python-based interface that streamlines model generation while preserving analytical rigor. The interface assists in geometry definition, meshing, material assignment, and boundary condition implementation, thereby improving consistency and reducing pre-processing time without altering the numerical formulation. Nine stiffened panel configurations were investigated by combining three plate thicknesses with three longitudinal stiffener geometries. The results indicate that increasing plate thickness significantly enhances torsional resistance. Stiffener geometry also markedly influences structural response: the 80 × 80 × 8 stiffener provides the highest resistance under general torsional loading, whereas the 100 × 65 × 9 stiffener exhibits superior performance under pure torque conditions. Overall, the results demonstrate that the proposed framework provides a consistent and efficient approach for evaluating the torsional strength of stiffened panels. Full article

Elastomer-based nanocomposites combining polymer flexibility with conductive nanofillers provide lightweight, stretchable systems with tunable electromechanical properties for wearable electronics, soft robotics, and self-powered sensors. However, predicting their nonlinear response remains challenging because the observed piezoelectric-like response arises from strain-dependent interfacial polarization and evolving piezoresistive conduction pathways within heterogeneous microstructures. We introduce a continuum electro-hyperelastic framework combining the Mooney–Rivlin model for large-strain elasticity with a Helmholtz free-energy approach for electrostatic coupling. Analytical expressions for stress, electric displacement, and apparent piezoelectric coefficients are derived and implemented in finite element simulations. The model accurately reproduces the experimental mechanical, dielectric, and electromechanical behaviour of polydimethylsiloxane (PDMS) nanocomposites with 0.1–1 wt% graphene. These show increased stiffness, relative permittivity (from 3.4 to 4.0, ≈18%), and quasi-static d₃₃ coefficients (from −5.6 to −10.0 pC N⁻¹, ≈80% enhancement). Analytical and finite element method (FEM) results show consistent trends across the full deformation range, with Maxwell stress agreement within 10% at lower deformation levels, while deviations of 33–40% for coupled electromechanical quantities at an axial displacement u_z = ~−1 mm (~16.7% compressive strain) are attributable to three-dimensional shear effects absent from the uniaxial analytical assumption. Simulations reveal that graphene boosts Maxwell stress, yielding a four-fold increase at lower stretch ratios. This reframes PDMS–graphene composites as electro-hyperelastic materials, offering a predictive, extensible framework. It highlights apparent piezoelectricity as an emergent, tunable effect from charge redistribution in a compliant hyperelastic matrix—guiding the design of next-generation flexible devices leveraging field-induced coupling over intrinsic polarization. Full article

Reliable ultrasonic inspection of welded structures requires a quantitative understanding of how defect morphology and depth influence detectability. In this study, a simulation-based signal-response Probability of Detection (POD) framework is developed to investigate ultrasonic wave interaction with representative planar and volumetric weld defects. Two-dimensional finite-element shear-wave simulations were conducted to model wave propagation and scattering from planar flaws (toe and root cracks) and volumetric flaws (porosity) across defined inspection depth zones. Peak terminal voltage was used as a continuous response metric for regression-based POD analysis. The results demonstrate that defect morphology dominates the influence on ultrasonic detectability. Planar defects produced systematically higher signal responses than volumetric defects of comparable size, resulting in lower characteristic detection limits. The estimated a₉₀ value for planar flaws was 2.96 mm, compared to 5.64 mm for volumetric flaws under identical threshold conditions. Depth-dependent analyses further revealed morphology-specific behavior: planar defects exhibited consistently high detection probabilities across depth zones (POD > 0.98), whereas volumetric defects showed a reduction in detectability with depth, with POD decreasing from approximately 0.32 in shallow zones to 0.16 in deeper regions. The resulting POD trends are interpreted as comparative, trend-based indicators of morphology and depth-dependent ultrasonic detectability under idealized inspection conditions. These findings quantitatively demonstrate how ultrasonic detectability is governed by wave-defect interaction mechanisms associated with defect morphology and inspection depth. Full article

This work introduces an integrated Material Point Method (MPM) framework for optimizing tendon-driven hyperelastic robots under extreme 3D deformations. To overcome the mesh distortion limitations of the traditional FEM at large strains, we develop a coupled MPM–tendon hyperelastic model that integrates Yeoh constitutive laws with discrete tendon actuation forces. The model enables robust simulation of anisotropic stress propagation through Lagrangian particle tracking and Eulerian grid discretization, eliminating mesh entanglement artifacts. A strain-gradient-driven tendon path algorithm ensures mechanical efficiency using Fréchet distance-based similarity metrics and curvature smoothness screenin, enforcing spatial continuity in complex topologies. Validation demonstrates: (1) Sub 3 mm geometric errors and about 89% volumetric overlap in worm-inspired deformations; (2) optimal computational efficiency at 0.4–0.6 mm grid densities, balancing accuracy and resource overhead; and (3) projected alignment errors of 0.8 mm (XY), 1.3 mm (XZ), and 2.9 mm (YZ) in multi-view spatial analyses. The framework achieves about 89% ± 2% volumetric overlap in quadrupedal morphing via agonist–antagonist tendon optimization, demonstrating efficacy for extreme 3D deformation control. Full article

Background/Objectives: This study evaluated the influence of key biomechanical parameters—orthodontic force magnitude, loading direction, and insertion depth—on stress and strain distribution in orthodontic mini-implants using three-dimensional finite element analysis (FEM). Methods: A three-dimensional model of a titanium orthodontic mini-implant inserted into a mandibular bone segment was developed and analyzed under varying force magnitudes (1–10 N), loading directions (30°, 45°, and 60°), and insertion depths (2–4 mm). Cortical and cancellous bone components were included, and static loading conditions were applied using simplified, linear elastic material assumptions. Results: Stress and strain levels increased with higher force magnitudes, with implant stresses approaching critical values at loads above 9 N. Cortical bone stresses remained within physiological limits, whereas cancellous bone exceeded the microdamage strain threshold at forces greater than 3 N. A 60° loading direction reduced implant bending and strain, while deeper insertion significantly decreased strain and displacement, indicating improved primary stability. Conclusions: Within the limits of this computational model, optimal mechanical behavior was observed under 1–3 N forces, a 60° loading direction, and a 2–4 mm insertion depth. Loads above 9 N approached fatigue and interfacial risk. These findings provide computational insight into the biomechanical behavior of orthodontic mini-implants under the modeled conditions. Full article

In this work we investigate the behavior of a toroidal photoacoustic resonator to provide compact, physics-guided analytical relationships that link its geometry to two key parameters: resonance frequency and quality factor. Finite-element data are combined with reduced-order analytical models to refine a corrected toroidal-resonance frequency model that accounts for effective propagation length and thermo-viscous effects. For the quality factor, a simple law motivated by a boundary-layer dissipation model is proposed. Derived models are validated by experimental tests performed using three 3D printed toroidal resonators in different sizes. Experimental results confirm the prediction both for the first and third resonance frequencies with an average relative error below 1%, outperforming cylindrical and uncorrected baseline models available in the literature. The results also confirm the predicted trend of the quality factor with respect to the torus’s minor radius, highlighting a direct relationship between the cross-sectional area and acoustic losses, which governs the balance between stored acoustic energy and thermo-viscous dissipation. Overall, the framework provides quick, interpretable design rules that reduce dependence on extensive finite-element method simulation campaigns for first-pass estimation of resonant behavior during the early design phase and guiding the optimization of high-performance PAS devices while preserving accuracy. Full article

This study proposes a novel redesign of a solar water heater prototype by integrating a stationary compound parabolic concentrator (CPC) internally within a standard collector housing. Unlike conventional flat-plate systems or external trough collectors, this design aims to enhance thermal efficiency while maintaining a compact footprint suitable for residential retrofitting in tropical climates. The system’s thermal performance was analyzed using a 3D finite element method (FEM) based on the convection-diffusion equation, with a specific focus on a 2 cm focal length configuration designed to fit spatial constraints. The simulation results indicated a maximum water temperature of 62.9 °C under concentrated solar flux, while the experimental prototype achieved a maximum temperature of 55.0 °C under corresponding field conditions. The comparative analysis reveals a temperature discrepancy of approximately 8 °C (12.5%), which is attributed to the simplified boundary conditions neglecting radiative losses in the model. Despite this deviation, the proposed parabolic design demonstrated a distinct thermal enhancement compared to the conventional baseline. These findings validate the technical feasibility of the compact internal concentrator, offering a low-cost, high-performance alternative for domestic water heating applications. Full article

In recent decades, Artificial Neural Networks (ANNs) have become a robust tool for addressing complex engineering challenges. This paper implements an ANN-based methodology to determine the natural frequencies of rotating sandwich composite beams with core defects. The study focuses on the influence of rotation speed and defect characteristics (size and location) on a beam made of carbon fiber face-sheets and a honeycomb core, selected for its high strength-to-weight ratio in next-generation designs. The primary novelty lies in providing a simplified model that, through an ANN-based surrogate, establishes an automated and high-speed process for frequency prediction. This approach bypasses the prohibitive computational costs of 3D-FEM simulations, enabling near-instantaneous results essential for real-time Structural Health Monitoring (SHM) applications. Full article
