The virtual synchronous generator (VSG) scheme has proven to be an attractive solution in grid-forming converter applications integrated into distributed generation (DG) systems. Thus, this paper presents the dynamic performance of power flow control using the VSG approach under Thevenin impedance variations seen by the grid-forming converter. The dynamic analysis is based on a discrete-time model that describes the power flow transient characteristics of the system operating in medium- and high-voltage networks. Based on the proposed model, a controller design procedure for the discrete-time VSG scheme is presented. This methodology aims to assist researchers in implementing VSG control in digital environments. Then, the Thevenin impedance parameters’ influence on the discrete-time VSG strategy dynamic performance is discussed. The VSG technique’s performance in different operating scenarios is assessed by means of simulation results. A case study is provided to validate the effectiveness of the theoretical analysis and the discrete-time VSG control scheme. The results assess the effectiveness of the theoretical analysis performed. Full article

In distributed microgrid systems, inverters serve as the core components when distributed generation (DG) modules are integrated into the grid. Traditional inverters typically employ droop control; however, they lack damping and inertia mechanisms. Consequently, fluctuations in the grid frequency and voltage occur when system loads change, leading to a suboptimal power distribution. To address these limitations, this paper introduces an adaptive strategy into conventional droop control. Based on an adaptive algorithm, the real and reactive power are dynamically computed. Through coordinate transformation, decoupled control, and adaptive frequency compensation, the inverter’s output frequency and voltage are effectively regulated. By adjusting the reference current in a dual-loop control scheme, the active and reactive power distribution is optimized. Additionally, an improved adaptive algorithm is developed to compute the inverter’s AC frequency compensation, enabling the self-adaptive adjustment of the PI controller’s output. This facilitates frequency compensation in droop control, ensuring that the inverter’s output current and voltage remain synchronized with the grid phase, thereby enhancing grid stability during connection. Finally, the feasibility of the proposed algorithm is validated through Simulink simulations. Full article

The advent of large-scale distributed generation (DG) has introduced several challenges to the voltage control of active distribution networks (ADNs). These challenges include the heterogeneity of control devices, the complexity of models, and their inherent fluctuations. To maintain ADN voltage stability more economically and quickly, a data-driven ADN voltage control scheme is proposed in this paper. Firstly, based on the multi-run state sensitivity matrix, buses with similar voltage responses are clustered, and critical buses are selected to downsize the scale of the model. Secondly, a linear voltage-to-power dynamics model in high-dimensional state space is trained based on the offline data of critical bus voltages, DGs, and energy storage system (ESS) outputs, utilizing the Koopman theory and the Extended Dynamic Mode Decomposition (EDMD) method. A linear model predictive voltage controller, which takes ADN stability and control cost into account, is also proposed. Finally, the effectiveness and applicability of the method are verified by applying it to an improved 33-bus ADN system. The proposed control method can respond more quickly and accurately to the voltage fluctuation problems caused by source-load disturbances and short-circuit faults. Full article

With the increasing proportion of distributed generators (DGs), distribution networks usually include grid forming (GFM) and grid following (GFL) converters. However, the incompatibility of dynamic performance caused by different control methods of the GFM and GFL converters may bring instability problems and power quality risks to the distribution network. To solve this issue, the models of the GFM and GFL converters are established first to lay a good foundation for stability analysis and power quality improvement control. On this basis, an inner loop parameters design scheme is developed for GFM converters based on the D-Partition method, which facilitates the stability boundary characterization. Meanwhile, a current injection strategy is proposed to enhance the voltage support capacity of the GFL converter during grid faults. Moreover, for the distribution network with multi-converters, a compensation current control based on the analytic hierarchy process and coefficient of variation is proposed to ensure a balance between minimal capacity and optimal power quality. In this manner, DGs can be plug-and-play without considering stability and power quality issues. Finally, the effectiveness of the proposed strategy is validated with simulation results. Full article

With the integration of a high proportion of distributed generators (DGs), the imbalance between source and load power intensifies, causing the distribution grid to become ‘weak’ during certain periods, which can easily lead to voltage over-limit for the distribution grid. Due to the coupling of active and reactive power in weak power grids for voltage regulation, the effectiveness of single reactive voltage regulation for voltage over-limit is not satisfactory. This paper uses an Energy Storage type Intelligent Soft Open Point (E-SOP) with grid-forming controlled energy storage to simultaneously adjust the active and reactive power between different grid clusters to suppress voltage over-limit for a weak grid. Firstly, based on the system architecture and bus load characteristics, the distribution grid is divided into clusters, and the cluster Thevenin equivalent model is established. Then, different voltage support schemes are compared and analyzed through the cluster active power-voltage (P-V) curve. Through simulation verification of the IEEE 33-bus system containing DGs, it is concluded that the scheme of installing E-SOP in the distribution grid containing DGs enhances the active power transmission capability of the grid and provides better voltage support compared to traditional reactive power compensation and system capacity expansion schemes. Full article

This paper focuses on the distributed generation (DG) controller of a PV-based microgrid. An independent DG controller (IDGC) is designed for PV applications to improve Maximum-Power Point Tracking (MPPT). The Extreme-Learning Machine (ELM)-based MPPT method exactly estimates the controller’s reference input, such as the voltage and current at the MPP. Feedback controls employ linear PI schemes or nonlinear, intricate techniques. Here, the converter controller is an IDGC that is improved by directly measuring the converter duty cycle and PWM index in a single DG PV-based MG. It introduces a fast-learning Extreme-Learning Machine (ELM) using the Moore–Penrose pseudo-inverse technique and online sequential ridge methods for robust control reference (CR) estimation. This approach ensures the stability of the microgrid during PV uncertainties and various operational conditions. The internal DG control approach improves the stability of the microgrid during a three-phase fault at the load bus, partial shading, irradiance changes, islanding operations, and load changes. The model is designed and simulated on the MATLAB/SIMULINK platform, and some of the results are validated on a hardware-in-the-loop (HIL) platform. Full article

In islanded operation, precise power sharing is an immensely critical challenge when there are different line impedance values among the different-rated inverters connected to the same electrical network. Issues in power sharing and voltage compensation at the point of common coupling, as well as the reverse circulating current between inverters, are problems in existing control strategies for parallel-connected inverters if mismatched line impedances are not addressed. Therefore, this study aims to develop an improved decentralized controller for good power sharing with voltage compensation using the predictive control scheme and circulating current minimization between the inverters’ current flow. The controller was developed based on adaptive virtual impedance (AVI) control, combined with finite control set–model predictive control (FCS-MPC). The AVI was used for the generation of reference voltage, which responded to the parameters from the virtual impedance loop control to be the input to the FCS-MPC for a faster tracking response and to have minimum tracking error for better pulse-width modulation generation in the space-vector form. As a result, the circulating current was maintained at below 5% and the inverters were able to share an equal power based on the load required. At the end, the performance of the AVI-based control scheme was compared with those of the conventional and static-virtual-impedance-based methods, which have also been tested in simulation using MATLAB/Simulink software 2021a version. The comparison results show that the AVI FCS MPC give 5% error compared to SVI at 10% and conventional PI at 20%, in which AVI is able to minimize the circulating current when mismatch impedance is applied to the DGs. Full article

In recent years, the penetration rate of intermittent distributed generation (DG) in active distribution networks has been steadily increasing, leading to prominent issues such as voltage violations and network congestion. Coordinated operation of soft open points (SOPs) and distributed energy storage systems (DESSs) enable flexible resource management in both spatial and temporal dimensions, allowing real-time voltage regulation and flow control. This enhances the controllability, sustainability, and economic efficiency of the distribution network, ultimately improving user satisfaction. The optimization of this coordinated configuration has become a central challenge in research. Taking the different characteristics of DESSs and SOPs into account, this paper proposes a coordinated configuration method by introducing local marginal price (LMP) under the configuration scheme. The framework is modeled as a three-level problem, including planning and operation levels. Initially, typical scenarios are generated to address the uncertainty of distributed generation operation. At the upper level, the DESS configuration is optimized to minimize annual operational costs, while at the middle level, SOPs are planned based on the annual comprehensive operational cost of the distribution network. At the lower level, the objective is set as social welfare maximization to reflect user satisfaction by incorporating LMP as a planning indicator. It is then transformed and solved as a mixed-integer second-order programming model with a hybrid optimization algorithm. The model is established with the modified IEEE 33-node distribution system as a case study to validate the feasibility of the proposed configuration method. The case study results demonstrate the effectiveness of the proposed approach in optimally configuring SOPs with DESSs to reduce overall annual operating costs and enhance the economic efficiency of the system. Full article

More and more distributed generations (DGs), such as wind, PV or battery bank sources, are connected to electric systems or customer loads. However, the locations of these DGs are based on the highest energy that can be potentially harvested for electric power generation. Therefore, these locations create different line impedances based on the distance from the DGs to the loads or the point of common coupling (PCC). This paper presents an adaptive virtual impedance (AVI) in the predictive control scheme in order to ensure power sharing accuracy and voltage stability at the PCC in a microgrid network. The reference voltage from mismatched feeder impedances was modified by utilizing the suggested AVI-based predictive control for creating equal power sharing between the DGs in order to avoid overburdening any individual DG with low-rated power. The AVI strategy used droop control as the input control for generating equal power sharing, while the AVI output was used as the reference voltage for the finite control set–model predictive control (FCS-MPC) for creating a minimum voltage error deviation for the cost function (CF) for the inverter’s vector switching pattern in order to improve voltage stability at the PCC. The proposed AVI-based controller was tested using two DG inverter circuits in a decentralized control mode with different values of line impedance and rated power. The performance of the suggested controller was compared via MATLAB/Simulink with that of a controller based on static virtual impedance (SVI) in terms of efficiency of power sharing and voltage stability at the PCC. From the results, it was found that (1) the voltage transient magnitude for the AVI-based controller was reduced within less than 0.02 s, and the voltage at the PCC was maintained with about 0.9% error which is the least as compared with those for the SVI-based controller and (2) equal power sharing between the DGs increased during the change in the load demand when using the AVI-based controller as compared with using the SVI-based controller. The proposed controller was capable of giving more accurate power sharing between the DGs, as well as maintaining the voltage at the PCC, which makes it suitable for the power generation of consumer loads based on DG locations for future energy communities. Full article

To alleviate the hassle of false data injection (FDI) attacks on distributed generators (DGs) in microgrids, a communication encryption-based distributed cooperative control is proposed in this paper. Compared to the conventional distributed control strategies, the proposed control scheme is simpler with much less complex evaluation mechanism by upgrading the secondary control to a second-order control based on the finite-time control theory while combining an encryption strategy. The proposed algorithm provides constant injections to eliminate the impact of FDI attacks based on a robust communication system. The effectiveness and high efficiency of the proposed control scheme is validated in an IEEE 34 Node Test Feeder system with six DGs as a microgrid cyber-physical system (CPS) under different FDI attacks. Full article

Due to unbalanced load growth among different regions and the increasing integration of distributed generators (DGs), distribution station areas (DSAs) currently face issues such as voltage violations, curtailment of renewable energy generation, and imbalanced load rates among DSAs. Interconnecting DSAs to form an AC–DC hybrid distribution network (DN) can not only address the aforementioned problems but also provides more efficient interfaces for DC devices. In order to coordinate the controllable devices within the flexible interconnected DSAs and achieve an optimal operational state, centralized optimal dispatch strategies are mainly used, which requires the deployment of an additional central controller and entails heavy communication and computation burdens. To overcome the drawbacks of centralized dispatch, a fully decentralized optimal dispatch scheme based on the alternating direction method of multipliers (ADMM) is proposed. Based on the network partitioning results, the introduction of auxiliary variables that replicate the coupling variables between areas further eliminates the need for a coordinating center in the standard ADMM, achieving a fully decentralized optimal dispatch. Additionally, two network partitioning methods are proposed for implementing decentralized dispatch. Both partitioning methods can achieve the goals of load rate balance and voltage profile improvement when implementing decentralized dispatch. Their key distinction lies in their effectiveness in improving the voltage profiles on the DC side. The partitioning method that treats the entire DC side as a separate area, resulting in higher investment, achieves better results in improving the DC voltage profiles than the other one. The choice of partitioning method can be based on practical engineering requirements. Full article

When multiple paralleled distributed generation (DG) units operate in an islanded microgrid, accurate power sharing of each DG unit cannot be achieved with a conventional droop control strategy due to mismatched feeder impedance. In this paper, a small AC signal (SACS)-injection-based modified droop control method is presented for accurate active and reactive power sharing among DG units. The proposed control method adjusts the voltage amplitude of each DG unit by injecting small AC signals to form a reactive power control loop. This strategy does not need communication links or to specifically obtain the physical parameter of the feeder impedance and only requires the local information. Moreover, the parameter design procedure and stability analysis are given full consideration. Finally, simulation and experimental results verify the effectiveness of the proposed control scheme, and accurate active and reactive power sharing can be achieved. Full article

The abrupt transfer from grid-connected (GC) to stand-alone (SA) operation modes is one of the major issues that may threaten the stability of a distributed generation (DG) system. Furthermore, if the islanding mode happens, it is vital to take into consideration the load voltages or load current waveforms as soon as feasible. This paper develops an advanced control technique based on a super-twisting sliding mode controller (ST-SMC) for a three-phase inverter operating in both the GC and SA modes. This control scheme is proposed to ensure a smooth transition from the GC to SA mode and enhance the load voltage waveforms under the islanding mode. In addition, to minimize the operational costs of the system and the complexity of the studied model, a digital Luenberger observer (DLO) with a proper design is adopted for estimating the inverter-side current. The control scheme of the whole system switches between a current control mode during the GC mode and a voltage control mode during the SA mode. The super-twisting control algorithm is applied to the outer voltage control loop involved in the cascaded voltage/current control scheme in the SA mode. Simulation tests of a three-phase inverter are performed for the purpose of assessing the suggested control performance by using the PowerSim (PSIM) software and comparing it with a classical PI controller. Furthermore, a processor-in-the-loop (PIL) implementation in a DSP board TMS32F28335 while debugging is conducted using code composer studio 6.2.0. The obtained results show efficient control properties, such as a smooth transition among the microgrid (MG) operating modes, as well as effectiveness and robustness during both the GC and SA operation modes. Full article

An islanding operation of distributed generations (DGs) in emergencies due to a fault in distribution systems can be a means of power supply for important loads in outage areas by facilitating the self-sufficient capability of DGs forming microgrids. This paper presents an optimization-based intentional islanding scheme to derive a near-optimal service restoration (SR) plan. The anti-parallel operation of DGs is considered a new constraint that avoids more than two DGs in an island thereby, enabling simpler control and operation of the distribution system in an emergency. Each island is created by an island partitioning scheme based on the tree representation of the network and fast searching scheme for the tree structure considering load importance, and a genetic algorithm (GA) is utilized to explore possible SR solutions. Case studies on IEEE 69-bus distribution system according to various fault locations are conducted, and the simulation results show that the proposed scheme can restore more loads with higher priority in outage areas by the intentional islanding of DGs. Furthermore, the time for deriving the optimal solution can be reduced since the evaluations for infeasible solutions are not performed. Full article

In response to the rapid changes in the international energy environment, developing renewable energy (RE)-based distributed generation (DG) and various smart micro-grid systems is crucial for creating a robust electric power grid and new energy industries. In this aspect, there is an urgent need to develop hybrid power systems suitable for coexistent AC and DC power grids, integrated by high-performance wide ban gap (WBG) semiconductor-based power conversion interfaces and advanced operating and control strategies. Due to the intrinsic feature of variation in RE-based power generation, the design and integration of energy storage devices, real-time regulation of power flow, and intelligent energy control schemes are key technologies for further promoting DG systems and micro-grids. This paper investigates an integrated control scheme for multiple GaN-based power converters in a small- to medium-capacity, grid-connected, and RE-based power system. This is the first time that a complete design case demonstrating three GaN-based power converters with different control functions integrated with a single digital signal processor (DSP) chip to achieve a reliable, flexible, cost effective, and multifunctional power interface for renewable power generation systems is presented. The system studied includes a photovoltaic (PV) generation unit, a battery energy storage unit, a grid-connected single-phase inverter, and a power grid. Based on system operation condition and the state of charge (SOC) of the energy storage unit, two typical operating modes and advanced power control functions are developed with a fully digital and coordinated control scheme. Hardware of the GaN-based power converters and digital controllers are designed and implemented. The feasibility and effectiveness of the designed controllers and overall performance of the proposed control scheme are verified with results from simulation and experimental tests on a 1-kVA small-scale hardware system. Full article
