Search Results (46)

Search Parameters:
Keywords = DC-DC Cuk converter

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
9 pages, 1077 KiB
Proceeding Paper
Design and Simulation of Ripple Free Non-Inverting DC-DC Cuk Converter with Valley-Fill Circuit for LED Applications
by Lakshmi Praba Balakrishnan, Abhinaya Ravichandran, Seyezhai Ramalingam, Deeikshanyaa Sivasubramaniam and Harini Vasudevan Balamurugan
Eng. Proc. 2025, 93(1), 5; https://doi.org/10.3390/engproc2025093005 - 1 Jul 2025
Viewed by 242
Abstract
LED lighting plays a pivotal role in the illumination landscape owing to its substantial energy efficiency, prolonged operational lifespan, environmental advantages, superior light quality, and its capacity for advanced lighting control. Flicker in led lighting systems has emerged as a substantial concern and [...] Read more.
LED lighting plays a pivotal role in the illumination landscape owing to its substantial energy efficiency, prolonged operational lifespan, environmental advantages, superior light quality, and its capacity for advanced lighting control. Flicker in led lighting systems has emerged as a substantial concern and is appropriate to its potential opposing impacts on human health and visual comfort. Hence, this paper presents a comprehensive analysis, design, and mitigation strategy for flicker in a DC-DC led driver that incorporates a valley fill circuit. The initial stage of this investigation involves an analysis of a conventional cuk converter. However, it is noted that this converter produces an inverting output and experiences high current stress on the semiconductor switch. Consequently, to address these limitations, a non-inverting cuk converter (NICC) is introduced, resulting in a positive output, reduced voltage and current ripple and increased efficiency. To surmount these challenges, the implementation of a valley fill circuit is proposed. This addition facilitates the rapid attainment of a steady state, increases efficiency, and substantially reduces the output voltage and current ripple. An in-depth analysis of the stress imposed on the switch is conducted, leading to the development of a circuit designed to extend the operational life of the LED driver. Therefore, this paper compares the topologies of three different DC-DC cuk power converters. These converters include conventional cuk, non-inverting cuk (NICC), and non-inverting cuk with valley-fill. The performance metrics are examined and compared for all three topologies. The findings of this study affirm that the proposed driver circuit is highly effective in mitigating flicker, thereby enhancing the user experience and elevating the quality of led lighting, all while maintaining energy efficiency. The MATLAB simulations of these converters are performed to validate the theoretical results. Full article
Show Figures

Figure 1

29 pages, 9574 KiB
Review
Bidirectional DC-DC Converter Topologies for Hybrid Energy Storage Systems in Electric Vehicles: A Comprehensive Review
by Yan Tong, Issam Salhi, Qin Wang, Gang Lu and Shengyu Wu
Energies 2025, 18(9), 2312; https://doi.org/10.3390/en18092312 - 1 May 2025
Cited by 1 | Viewed by 2158
Abstract
Electric Vehicles (EV) significantly contribute to reducing carbon emissions and promoting sustainable transportation. Among EV technologies, hybrid energy storage systems (HESS), which combine fuel cells, power batteries, and supercapacitors, have been widely adopted to enhance energy density, power density, and system efficiency. Bidirectional [...] Read more.
Electric Vehicles (EV) significantly contribute to reducing carbon emissions and promoting sustainable transportation. Among EV technologies, hybrid energy storage systems (HESS), which combine fuel cells, power batteries, and supercapacitors, have been widely adopted to enhance energy density, power density, and system efficiency. Bidirectional DC-DC converters are pivotal in HESS, enabling efficient energy management, voltage matching, and bidirectional energy flow between storage devices and vehicle systems. This paper provides a comprehensive review of bidirectional DC-DC converter topologies for EV applications, which focuses on both non-isolated and isolated designs. Non-isolated topologies, such as Buck-Boost, Ćuk, and interleaved converters, are featured for their simplicity, efficiency, and compactness. Isolated topologies, such as dual active bridge (DAB) and push-pull converters, are featured for their high voltage gain and electrical isolation. An evaluation framework is proposed, incorporating key performance metrics such as voltage stress, current stress, power density, and switching frequency. The results highlight the strengths and limitations of various converter topologies, offering insights into their optimization for EV applications. Future research directions include integrating wide-bandgap devices, advanced control strategies, and novel topologies to address challenges such as wide voltage gain, high efficiency, and compact design. This work underscores the critical role of bidirectional DC-DC converters in advancing energy-efficient and sustainable EV technologies. Full article
Show Figures

Figure 1

32 pages, 8789 KiB
Review
Reduced Loss Tristate Converters
by Felix A. Himmelstoss
Electronics 2025, 14(7), 1305; https://doi.org/10.3390/electronics14071305 - 26 Mar 2025
Viewed by 370
Abstract
In a tristate converter the basic circuit topology is extended by an additional electronic switch and an additional diode. Three modes follow each other within one switching period. During the first mode M1, both electronic switches are on and both diodes are off. [...] Read more.
In a tristate converter the basic circuit topology is extended by an additional electronic switch and an additional diode. Three modes follow each other within one switching period. During the first mode M1, both electronic switches are on and both diodes are off. In the second mode M2, only the second switch is on and the first diode is conducting, and in mode M3, only the second diode is conducting. The voltage transformation ratio is a function of the two duty cycles of the electronic switches. In a typical tristate converter, the current flows through the second switch during the first two modes. In the converters treated here, the current is flowing through the second switch only during the second mode, so the losses are reduced compared to the normal tristate converter. This is shown for the Buck, the Buck–Boost, the Boost, the Zeta, the Cuk, the Super Boost, the quadratic Buck, and a reduced-duty cycle converter. The voltage transformation ratios are depicted in diagrams. As an example the reduced loss tristate Buck is used to demonstrate the derivation of the large and the small signal models. The transfer functions are also calculated and Bode plots are shown for an operating point. The voltage and the current stress of the converters are analyzed and the results are summarized in tables. The considerations are proved by simulations with the help of LTSpice. Full article
(This article belongs to the Special Issue Advanced Power Generation and Conversion Systems, 2nd Edition)
Show Figures

Figure 1

24 pages, 8060 KiB
Article
A Modular Step-Up DC–DC Converter Based on Dual-Isolated SEPIC/Cuk for Electric Vehicle Applications
by Ahmed Darwish and George A. Aggidis
Energies 2025, 18(1), 146; https://doi.org/10.3390/en18010146 - 2 Jan 2025
Viewed by 1166
Abstract
Fuel cells (FCs) offer several operational advantages when integrated as a power source in electric vehicles (EVs). Since the voltage of these cells is typically low, usually less than 1 V, the power conversion system requires a DC–DC converter capable of providing a [...] Read more.
Fuel cells (FCs) offer several operational advantages when integrated as a power source in electric vehicles (EVs). Since the voltage of these cells is typically low, usually less than 1 V, the power conversion system requires a DC–DC converter capable of providing a high voltage conversion ratio to match the input voltage of the motor propulsion system, which can exceed 400 V and reach up to 800 V. The modular DC–DC boost converter proposed in this paper is designed to achieve a high voltage step-up ratio for the input FC voltages through the use of isolated series-connecting boosting submodules connected. The power electronic topology employed in the submodules (SMs) is designed to provide a flexible output voltage while maintaining a continuous input current from the fuel cells with minimal current ripple to improve the FC’s performance. The proposed step-up modular converter provides several benefits including scalability, better controllability, and improved reliability, especially in the presence of partial faults. Computer simulations using MATLAB/SIMULINK® software (R2024a) have been used to study the feasibility of the proposed converter when connected to a permanent magnet synchronous motor (PMSM). Also, experimental results using a 1 kW prototype composed of four SMs have been obtained to validate the performance of the proposed converter. Full article
(This article belongs to the Special Issue Design and Control Strategies for Wide Input Range DC-DC Converters)
Show Figures

Figure 1

22 pages, 8881 KiB
Article
A Modular Step-Up DC/DC Converter for Electric Vehicles
by Ahmed Darwish
Energies 2024, 17(24), 6305; https://doi.org/10.3390/en17246305 - 13 Dec 2024
Cited by 3 | Viewed by 1336
Abstract
A step-up DC/DC converter is required to match the fuel cell’s stack voltage with the DC-link capacitor of the propulsion system in fuel cell-based electric vehicles (FCEVs). Typically, the nominal voltage of a single fuel cell ranges from 0.5 V to 1 V, [...] Read more.
A step-up DC/DC converter is required to match the fuel cell’s stack voltage with the DC-link capacitor of the propulsion system in fuel cell-based electric vehicles (FCEVs). Typically, the nominal voltage of a single fuel cell ranges from 0.5 V to 1 V, and the DC-link voltage usually lies between 400 V and 800 V. This article proposes a new modular step-up DC/DC converter capable of providing a wide voltage-boosting range from the input to the output side using series-connected isolated boosting submodules (SMs). Modified versions of boost and Cuk converters are designed and used as the SMs to deliver a flexible output voltage, combining the voltage-boosting capability with the ability to embed a medium/high-frequency transformer, which provides both galvanic isolation and an additional degree of voltage boosting while drawing a continuous input current from the fuel cell with minimal ripple, enhancing performance. The proposed modular converter offers the advantages of improved controllability, scalability, and greater reliability, particularly during partial faults. The feasibility of the proposed converter is demonstrated through computer simulations conducted using MATLAB/SIMULINK® R2024a software where a DC link of 400 V is created from 50 V input sources. Additionally, a 1 kW small-scale prototype is designed and controlled using a TMS320F28335 digital signal processor to validate the mathematical analysis and simulation results, where the SMs are controlled to create a DC link of 100 V from four 25 V input sources with an electrical efficiency of approximately 95%. Full article
(This article belongs to the Section E: Electric Vehicles)
Show Figures

Figure 1

17 pages, 1201 KiB
Article
A Single-Output-Filter Double Dual Ćuk Converter
by Hector R. Robles-Campos, Julio C. Rosas-Caro, Antonio Valderrabano-Gonzalez and Johnny Posada
Electronics 2024, 13(10), 1838; https://doi.org/10.3390/electronics13101838 - 9 May 2024
Cited by 2 | Viewed by 1249
Abstract
This study introduces an innovative version of a recently studied converter. A Double Dual Ćuk Converter was recently studied with advantages like the possibility of designing it for achieving a low-input current ripple. The proposed converter, called the Improved Double Dual Ćuk Converter, [...] Read more.
This study introduces an innovative version of a recently studied converter. A Double Dual Ćuk Converter was recently studied with advantages like the possibility of designing it for achieving a low-input current ripple. The proposed converter, called the Improved Double Dual Ćuk Converter, maintains the advantages of the former one, and it is characterized by requiring one less capacitor and inductor than its predecessor. This allows addressing the challenge of optimizing the topology to reduce component count without compromising the operation; this work proposes an efficient design methodology based on theoretical analysis and experimental validation. Results demonstrate that the improved topology not only retains the advantages of the previous version, including high efficiency and robustness, but also enhances power density by reducing the number of components. These advancements open new possibilities for applications requiring compact and efficient power converters, such as renewable energy systems, electric vehicles, and portable power supply systems. This work underscores the importance of continuous innovation in power converter design and lays the groundwork for future research aimed at optimizing converter topologies. A detailed discussion of the operating principles and modeling of the converter is provided. Furthermore, simulation outcomes highlighting differences in steady-state duration, output voltage, input current ripple, and operational efficiency are shared. The results from an experimental test bench are also presented to corroborate the efficacy of the improved converter. Full article
(This article belongs to the Special Issue Advanced Technologies in Power Electronics and Electric Drives)
Show Figures

Figure 1

27 pages, 11263 KiB
Article
Bus Voltage Stabilization of a Sustainable Photovoltaic-Fed DC Microgrid with Hybrid Energy Storage Systems
by Rudi Uswarman, Khalid Munawar, Makbul A. M. Ramli and Ibrahim M. Mehedi
Sustainability 2024, 16(6), 2307; https://doi.org/10.3390/su16062307 - 11 Mar 2024
Cited by 5 | Viewed by 2108
Abstract
Renewable energy sources play a great role in the sustainability of natural resources and a healthy environment. Among these, solar photovoltaic (PV) systems are becoming more economically viable. However, as the utility of solar energy conversion systems is limited by the availability of [...] Read more.
Renewable energy sources play a great role in the sustainability of natural resources and a healthy environment. Among these, solar photovoltaic (PV) systems are becoming more economically viable. However, as the utility of solar energy conversion systems is limited by the availability of sunlight, they need to be integrated with electrical energy storage systems to be more sustainable. This paper aims to improve the control performance of a hybrid energy storage system (HESS) with PV power generation as the primary power source. HESSs stabilize DC microgrid systems by compensating for demand generation mismatches. Batteries and supercapacitors are chosen as energy storage elements; batteries have a high energy density and are capable of supplying and absorbing energy over a long duration, while supercapacitors can store and deliver energy very quickly. To enhance the stability of the system, each storage element is connected to the DC bus using a bidirectional Ćuk converter, which offers high efficiency, a continuous current, and minimal switching losses. This study proposes a proportional–integral (PI) controller combined with the fast nonsingular integral terminal sliding mode control (FNITSMC) for HESSs to adjust the power balance in a DC microgrid. FNITSMC has the advantage of enhancing the system states to reach the equilibrium point of a long sliding surface with a fast convergence rate. The reference current for FNITSMC is obtained using a PI controller combined with a low-pass filter (LPF), which eliminates the peaking current spikes on the battery and diverts them towards the supercapacitor. The effectiveness of the proposed control scheme is validated through the real-time hardware-in-the-loop (HIL) simulations on Typhoon™ HIL-402 with added uncertainties, including load variations at various temperatures and irradiances. Full article
Show Figures

Figure 1

25 pages, 10467 KiB
Article
Experimental Evaluation of a 2 kW/100 kHz DC–DC Bidirectional Converter Based on a Cuk Converter Using a Voltage-Doubler Concept
by Wanderson Francisco Lopes, Mário Lúcio da Silva Martins, Attilio Converti, Hugo Valadares Siqueira and Carlos Henrique Illa Font
Energies 2024, 17(2), 362; https://doi.org/10.3390/en17020362 - 11 Jan 2024
Cited by 2 | Viewed by 1542
Abstract
This paper presents a theoretical analysis of steady-state operation, control-oriented modeling for voltage control, and the experimental results of a DC–DC bidirectional converter based on a Cuk converter using a voltage-doubler concept. Due to the voltage-doubler concept, the voltage stress across semiconductors is [...] Read more.
This paper presents a theoretical analysis of steady-state operation, control-oriented modeling for voltage control, and the experimental results of a DC–DC bidirectional converter based on a Cuk converter using a voltage-doubler concept. Due to the voltage-doubler concept, the voltage stress across semiconductors is reduced when compared with the conventional Cuk converter; this allows for the use of semiconductors with reduced drain–source on-resistance. Moreover, due to the input and output current source characteristics, the converter presents advantages, such as draining/injecting currents on both sides with low-ripple currents. Furthermore, the theoretical analysis is verified by experimental results obtained from a proof-of-concept prototype designed with a 250 V input voltage, a 360 V output voltage, 2 kW rated power, and 100 kHz switching frequency. Full article
(This article belongs to the Special Issue Green Technologies for Energy Transition)
Show Figures

Figure 1

20 pages, 20846 KiB
Review
State-Space Modeling, Design, and Analysis of the DC-DC Converters for PV Application: A Review
by M. Usman Khan, Ali Faisal Murtaza, Abdullah M. Noman, Hadeed Ahmed Sher and Maria Zafar
Sustainability 2024, 16(1), 202; https://doi.org/10.3390/su16010202 - 25 Dec 2023
Cited by 16 | Viewed by 7629
Abstract
Small-signal models of dc-dc converters are often designed using a state-space averaging approach. This design can help discuss and derive the control-oriented and other frequency-domain attributes, such as input or output impedance parameters. This paper aims to model the dc-dc converters for PV [...] Read more.
Small-signal models of dc-dc converters are often designed using a state-space averaging approach. This design can help discuss and derive the control-oriented and other frequency-domain attributes, such as input or output impedance parameters. This paper aims to model the dc-dc converters for PV application by employing a capacitor on the input side. The modeling, design, and analysis of the dc-dc converters regarding the input capacitor is limited in the literature. Five dc-dc converters, including buck, boost, buck-boost, ĆUK, and SEPIC converters, are designed and implemented using the state-space average modeling approach in MATLAB/Simulink. The circuit topology of each converter and the state-space matrices are derived considering every constraint. A rigorous and compelling analysis of the dc-dc converters is carried out to compare system stability and, ultimately, the dynamic performance. The output of the resulting small-signal models has been demonstrated in the time-domain against topology simulations. All the converters are exposed to unpredictable weather conditions and the simulations are carried out in the PSIM software. The perturb and observe (P&O) maximum power point tracking (MPPT) algorithm is applied in all the converters to ensure maximum power point (MPP) achievement. The results showcase that the boost converter outperforms all other converters in terms of stability, settling time, and overshoot. Full article
Show Figures

Figure 1

17 pages, 6696 KiB
Article
High Step-Up Boost-Cuk-Forward Converter with Reduced Switch Voltage Stress and Ripple-Free Input Current
by Reza Heidari, Mohammad Ali Ghanbari, Ehsan Adib, Kwang-Il Jeong and Jin-Woo Ahn
Energies 2023, 16(17), 6391; https://doi.org/10.3390/en16176391 - 3 Sep 2023
Cited by 1 | Viewed by 1861
Abstract
A new combined boost-Cuk-forward (CBCF) converter with ripple-free input current and low switch voltage stress is proposed for high step-up applications. Two coupled inductors are applied to achieve low switch voltage stress as well as balanced dc-link voltages, wherein the former is placed [...] Read more.
A new combined boost-Cuk-forward (CBCF) converter with ripple-free input current and low switch voltage stress is proposed for high step-up applications. Two coupled inductors are applied to achieve low switch voltage stress as well as balanced dc-link voltages, wherein the former is placed in series with the boost diode, and the latter is formed as a forward converter. Because these inductors are coupled with the output Cuk inductor, a ripple-free input current is also attained. The proposed converter is run at discontinuous conduction mode (DCM) by applying a low output-side Cuk inductance to reduce the switching loss by providing a ZCS turn-on of MOSFET and removing the diode reverse recovery current. In addition, the proposed converter does not have a problem with ground leakage current. The practical results verify the performance and effectiveness of the proposed CBCF high step-up converter. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

16 pages, 2624 KiB
Article
A Solar Photovoltaic Array and Grid Source-Fed Brushless DC Motor Drive for Water-Pumping Applications
by Tanmay Shukla and Srete Nikolovski
Energies 2023, 16(17), 6133; https://doi.org/10.3390/en16176133 - 23 Aug 2023
Cited by 13 | Viewed by 2362
Abstract
This article presents a brushless DC motor drive using a solar photovoltaic (PV) array and grid. Solar PV array-fed drive systems typically need a DC–DC converter stage in order to optimize the solar PV array-generated power utilizing a maximum power point (MPP) tracking [...] Read more.
This article presents a brushless DC motor drive using a solar photovoltaic (PV) array and grid. Solar PV array-fed drive systems typically need a DC–DC converter stage in order to optimize the solar PV array-generated power utilizing a maximum power point (MPP) tracking technique. In this work, a boost DC–DC converter is used for MPP tracking purposes. This work utilizes an incremental conductance (INC) MPP-tracking algorithm. A bridgeless asymmetrical converter without a bridge rectifier is used at the grid side to improve power quality at supply mains. The presented asymmetrical converter is an amalgamation of a second order (buck boost) with a fourth-order (Cuk) converter, which lowers the net system’s order. The input inductor of the Cuk converter manages the input current profile and, thus, eradicates the need for the filter at the grid mains. The bridgeless asymmetrical converter comes with several advantages, such as rectifier removal, component reduction, and input filter elimination. The performance of the brushless DC motor is examined in this article in all three scenarios: first, when grid and solar energy are both present; second, when solar energy is the only source of energy; and third, when grid energy is the only source of energy. The dual-source-based brushless DC motor drive system has been developed on matrix-laboratory/Simulink. The results are deployed and discussed to verify the drive-system performance. The article also presents a detailed stability analysis and mathematical modeling of the presented power-quality converter and MPP tracking converter to verify different converters’ stability using a bode diagram and a pole-zero plot. Full article
(This article belongs to the Special Issue Advances on Solar Energy Materials and Solar Cells)
Show Figures

Figure 1

21 pages, 6003 KiB
Article
Single-Switch Non-Isolated Resonant DC-DC Converter for Single-Input Dual-Output Applications
by Cristian Díaz-Martín, Eladio Durán, Salvador P. Litrán, José Luis Álvarez and Jorge Semião
Appl. Sci. 2023, 13(15), 8798; https://doi.org/10.3390/app13158798 - 30 Jul 2023
Cited by 5 | Viewed by 2947
Abstract
This paper describes a new configuration of Cuk and SEPIC (Single-Ended Primary Converter) ZVS-QR (zero-voltage switching quasi-resonant) combination DC-DC converter for bipolar output with a single switch. The proposed topology employs a single ground-referenced power switch, which simplifies the gate drive design with [...] Read more.
This paper describes a new configuration of Cuk and SEPIC (Single-Ended Primary Converter) ZVS-QR (zero-voltage switching quasi-resonant) combination DC-DC converter for bipolar output with a single switch. The proposed topology employs a single ground-referenced power switch, which simplifies the gate drive design with a single L-C resonant network and provides a bipolar output voltage with good regulation, acceptable efficiency and a step-down/up conversion ratio. This configuration provides dual-output voltage by switching the power switch to zero voltage, which is an interesting alternative for many applications where small size, light weight and high power density are very important aspects. In order to verify its performance, a SEPIC–Cuk Combination ZVS-QR prototype with a cost-effective commercial resonant controller was designed and tested. The experimental results show that the proposed combined topology is suitable for Single-Input Dual-Output (SIDO) applications. Full article
(This article belongs to the Special Issue Research and Development on DC-DC Power Converters)
Show Figures

Figure 1

19 pages, 4636 KiB
Article
Design of a Series–Parallel All-DC Power Generation System Based on a New DC Wind Turbine
by Qingfeng Kong, Guobing Song, Zhanlong Li and Xiangjun Wang
Electronics 2023, 12(13), 2967; https://doi.org/10.3390/electronics12132967 - 5 Jul 2023
Cited by 3 | Viewed by 1961
Abstract
Wind energy is a good alternative to fossil fuels, as the use of fossil fuels has seriously exacerbated the emission of greenhouse gases such as carbon dioxide and has greatly affected the environment. Conventional AC wind farms and AC transmission systems inevitably face [...] Read more.
Wind energy is a good alternative to fossil fuels, as the use of fossil fuels has seriously exacerbated the emission of greenhouse gases such as carbon dioxide and has greatly affected the environment. Conventional AC wind farms and AC transmission systems inevitably face problems involving reactive currents and overvoltage in the context of large-scale, large-capacity, and long-distance transmission. However, the use of all-DC wind turbines, together with DC convergence and DC transmission systems, has obvious advantages over AC transmission in terms of transmission losses and expandability. Such technology does not require bulky frequency transformers and can well solve the aforementioned problems of reactive currents and overvoltage. This paper proposes a new series–parallel structure for an all-DC wind power generation system. The series end uses a DC/DC converter based on the Cuk circuit to solve the current consistency and power balancing problems of the series wind turbine through current control, whereas the parallel end uses a large-capacity DC/DC converter based on the capacity transfer principle, to solve the problem of voltage consistency at the grid-connected end. The series part is used to increase the voltage level of the system, which can reduce the huge construction costs of offshore platforms, and the parallel part is used to increase the capacity of the system, which enables its incorporation into large-scale wind farms to achieve the replacement of fossil fuel energy. Full article
Show Figures

Figure 1

18 pages, 1162 KiB
Article
A Critical Comparison of the Cuk and the Sheppard–Taylor Converter
by Alfredo Alvarez-Diazcomas, Juvenal Rodríguez-Reséndiz, Roberto V. Carrillo-Serrano, Adyr A. Estévez-Bén and José Manuel Álvarez-Alvarado
World Electr. Veh. J. 2023, 14(6), 148; https://doi.org/10.3390/wevj14060148 - 4 Jun 2023
Cited by 3 | Viewed by 2194
Abstract
The use of and interest in renewable energy have increased in recent years due to the environmental impact of the technologies currently used to generate electricity. Switched converters play a fundamental role in renewable energy systems. The main goal is to manipulate the [...] Read more.
The use of and interest in renewable energy have increased in recent years due to the environmental impact of the technologies currently used to generate electricity. Switched converters play a fundamental role in renewable energy systems. The main goal is to manipulate the output signal of the renewable energy source to meet the requirements of different loads. Therefore, the increase in research on renewable energy sources has resulted in an increase in studies on switched converters. However, many DC–DC converters can be used in a particular application, and there is no clear guidance on which converter to use. The choice of whether to use one converter over another is highly reliant on the expertise of the researcher. Two examples of DC–DC converters are the Sheppard–Taylor converter and the Cuk converter. In this work, a critical comparison is made between these converters. The parameters considered in this comparison are the number of components, gain, stress on parts, and others. The simulation results were obtained to evaluate the performance of the converters in different scenarios. Finally, we conclude that the only application for which the use of the Sheppard–Taylor converter is justified are those that require high specific power and power density. Full article
(This article belongs to the Special Issue Power Converters and Electric Motor Drives)
Show Figures

Figure 1

17 pages, 6816 KiB
Article
A New Cuk-Based DC-DC Converter with Improved Efficiency and Lower Rated Voltage of Coupling Capacitor
by Khaled A. Mahafzah, Ali Q. Al-Shetwi, M. A. Hannan, Thanikanti Sudhakar Babu and Nnamdi Nwulu
Sustainability 2023, 15(11), 8515; https://doi.org/10.3390/su15118515 - 24 May 2023
Cited by 20 | Viewed by 4661
Abstract
DC-DC converters play a crucial role in recent and advanced applications, enabling efficient power conversion and management for renewable energy systems, electric vehicles, portable devices, and advanced communication systems. In line with this, the objective of this paper is to introduce a new [...] Read more.
DC-DC converters play a crucial role in recent and advanced applications, enabling efficient power conversion and management for renewable energy systems, electric vehicles, portable devices, and advanced communication systems. In line with this, the objective of this paper is to introduce a new DC-DC configuration based on the Cuk converter named as Mahafzah converter, which utilizes a coupling capacitor with a lower rated voltage. The paper aims to demonstrate the effectiveness of the proposed converter in terms of improved efficiency, reduced size, and reduced semiconductor device currents compared to the conventional Cuk converter. The proposed configuration comprises the same components as the Cuk converter, but in a different arrangement, without any additional elements. The main advantage of the proposed converter is using a coupling capacitor with a much lower rated voltage than the Cuk converter, resulting in a smaller capacitor size, reduced printed circuit board (PCB) size, and manufacturing cost. Additionally, the proposed converter reduces the currents of the semiconductor devices compared to those in the Cuk converter. To demonstrate its effectiveness, the converter is operated under continuous current mode (CCM) with a constant duty cycle and switching frequency. The study provides an in-depth discussion of the various operating modes by making use of equations relating to currents, voltages, duty cycles, and voltage gains. It also provides detailed illustrations of the limits between CCM and discontinuous current mode (DCM). The effectiveness of the proposed converter is demonstrated through a design example with operating parameters of 1 kW, 200 V/−300 V, and 20 kHz. Additionally, a low voltage–low power prototype (12/−18 V, 3.24 W, 20 kHz) is established to verify the operation of the proposed converter. Simulation and experimental verification of the proposed configuration achieved the desired results to improve efficiency and reduce the rate. The results clearly indicate that the efficiency of the proposed converter surpasses that of the conventional Cuk converter under identical operating conditions, reaching approximately 88% at rated load conditions. Full article
Show Figures

Figure 1
